Study of Photochemical Cytosine to Uracil Transition
via Ultrafast Photo-Cross-Linking Using
Vinylcarbazole Derivatives in Duplex DNA
Siddhant Sethi ID , Shigetaka Nakamura and Kenzo Fujimoto *
Department of Advanced Science and Technology, Japan Advanced Institute of Science and Technology,
1-1 Asahidai, Nomi, Ishikawa 923-1211, Japan; siddhant@jaist.ac.jp (S.S.); s-nakamu@jaist.ac.jp (S.N.)
* Correspondence: kenzo@jaist.ac.jp; Tel.: +81-761-51-1671
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 7 March 2018; Accepted: 2 April 2018; Published: 4 April 2018
Abstract: Gene therapies, including genome editing, RNAi, anti-sense technology and chemical
DNA editing are becoming major methods for the treatment of genetic disorders. Techniques like
CRISPR-Cas9, zinc finger nuclease (ZFN) and transcription activator-like effector-based nuclease
(TALEN) are a few such enzymatic techniques. Most enzymatic genome editing techniques have
their disadvantages. Thus, non-enzymatic and non-invasive technologies for nucleic acid editing
has been reported in this study which might possess some advantages over the older methods of
DNA manipulation. 3-cyanovinyl carbazole (CNVK) based nucleic acid editing takes advantage of
photo-cross-linking between a target pyrimidine and the CNVK to afford deamination of cytosine and
convert it to uracil. This method previously required the use of high temperatures but, in this study,
it has been optimized to take place at physiological conditions. Different counter bases (inosine,
guanine and cytosine) complementary to the target cytosine were used, along with derivatives of
CNVK (NH2VK and OHVK) to afford the deamination at physiological conditions.
Keywords: deamination; C to U transition; cyanovinylcarbazole; photo-cross-linking; genome editing
1. Introduction
Nucleic acid chemistry and its biological applications have great potential for developing futuristic
drugs and curing many diseases [1]. Enzymatic methods for nucleic acid manipulation, such as
PCR-plasmid based DNA manipulation, have been used for many years to create directed mutations,
recombination, deletion and insertion of desired genes in the genome but these methods have
limited applications in vivo
us methods for genome editing using proteins, RNA and other chemical agents. Currently, the major
enzymatic techniques used for genome editing are meganuclease [ ], zinc finger nuclease (ZFN) [ ],
transcription activator-like effector-based nuclease (TALEN) [ ] and clustered regularly interspaced
[2]. Recent developments in the field of genome editing have given
3
4
5
short palindromic repeats-associated system (CRISPR-Cas system) [6–9].
Currently, the CRISPR-Cas system is considered one of the most advanced techniques for specific
genetic manipulation [10]. CRISPR-Cas9 is a two-component based system, wherein one of the
components is an endonuclease (Cas9) and a guide RNA (gRNA), a 20-nucleotide sequence that
determines target specificity [11]. Despite the high specificity of the CRISPR system, unintended
mutations at sites other than target sites are one of the major drawbacks of the system [12].
Along with CRISPR, ZFN and TALEN have been used for genome editing by using enzymes
that cleave the DNA at specific sites to induce double stranded breaks, which lead to deletion and
frame-shift mutations [13
,14]. Although useful, these systems have shown cytotoxicity and the cost
of producing the enzymes is high [15]. Besides enzymatic methods for DNA manipulation, chemical
Molecules 2018, 23, 828; doi:10.3390/molecules23040828
www.mdpi.com/journal/molecules

Molecules 2018, 23, 828
2 of 12
methods such as sodium bisulphite nucleobase editing have been developed [16]. Bisulphite based
nucleobase editing is disadvantageous as it requires deleterious chemicals and the technique is highly
non-specific. Due to limitations in the chemical methods, certain photochemical methods were
developed that use azobenzene and psoralen incorporated in the DNA strand and could undergo
either photoisomerization or photo-cross-linking by UV irradiation to form a stable cross-linked
duplex [17–20]. These photoactive compounds have been used in the DNA to induce anti-sense effects
and form stable DNA structures [21–23].
Consecutively, new non-enzymatic and non-invasive techniques for manipulating nucleic acids
have been reported. In 2010, we reported on this enzyme-free technique for nucleic acid editing that
takes advantage of cytosine deamination to induce single point mutations in the DNA/RNA sequence
, K
using photoreactive 3-cyanovinylcarbazole nucleotides (CNVK) [24 25]. Upon incorporation of CNV
into oligodeoxyribonucleic acid (ODN), the ODN becomes responsive towards UV radiation and can
undergo cross-linking with cytosine at
1 position with respect to CNVK in a sequence specific manner.
−
Upon cross-linking, the aromaticity of cytosine is lost, making it prone to nucleophilic attack by water
to undergo deamination. The major drawback of this reaction is the requirement of high temperature
to accomplish deamination.
In 2015, we showed the effect of hydrogen bonding on the rate of the photo-cross-linking reaction
by changing the counter-base of cytosine [26], which led to the idea that hydrogen bonding could
also play a role in the deamination reaction. In 2017, we further proved our hypothesis by showing
that certain counter-bases, especially inosine, of cytosine are better for deamination than other bases
due to a specific type of hydrogen bonding in the cross-linked cytosine [27]. Furthermore, we also
reported that not only hydrogen bonding, but also the polarity around the cytosine-photo-adduct, is
responsible for the velocity of the deamination reaction at lower temperatures using derivatives of
vinylcarbazole [28].
In this report, we have shown the combined effect of hydrogen bonding and polarity by taking
varying combinations of counter-bases (inosine, guanine and cytosine) and vinylcarbazole derivatives
(3-cyanovinyl carbazole, 3-amidovinylcarbazole and 3-carboxyl vinyl carbazole) and incorporating
them in the ODN to accomplish deamination at physiological conditions (Figure 1).
Figure 1.
(a) Overview of photo-cross-link based cytosine deamination. (b) Chemical structures of
counter bases and photo-cross-linkers.

Molecules 2018, 23, 828
3 of 12
2. Results and Discussion
In order to find the best combination of photo-active nucleobase and counter base of the target,
various combinations were studied for deamination. For the counter base: inosine, guanine and
cytosine were chosen. For the photo-active nucleobase, 3-cyanovinyl carbazole (CNVK), along with
two derivatives of CNVK: 3-amidevinyl carbazole and 3-carboxyl vinyl carbazole were chosen. In our
previous reports, these bases showed promising results when studied individually, therefore, we
chose the combinations based on the previous singular studies. Firstly, 15mer ODNs containing
various combinations (Table 1), namely: ODN(GCNVK), ODN(GNH2VK), ODN(GOHVK), ODN(CCNVK),
ODN(CNH2VK), ODN(COHVK), ODN(ICNVK), ODN(INH2VK) and ODN(IOHVK), were synthesized
using a DNA synthesizer (AB 3600, Foster City, CA, USA). The ODNs were designed so the counter
base gets placed complementary to the target cytosine and the photo-active nucleotide gets placed at
the −1 position with respect to the target cytosine present in the complementary strand.
Table 1. The sequence of oligodeoxyribonucleic acid (ODN) containing photo-cross-linker.
0
0
Entry
Sequence of ODNs (5 to 3 )
ODN(GCNVK)
ODN(GNH2VK)
ODN(GOHVK)
ODN(CCNVK)
ODN(CNH2VK)
ODN(COHVK)
ODN(ICNVK)
ODN(INH2VK)
ODN(IOHVK)
AAATGCGCNVKACGTCCC
AAATGCGNH2VKACGTCCC
AAATGCGOHVKACGTCCC
AAATGCCCNVKACGTCCC
AAATGCCNH2VKACGTCCC
AAATGCCOHVKACGTCCC
AAATGCICNVKACGTCCC
AAATGCINH2VKACGTCCC
AAATGCIOHVKACGTCCC
The two ODNs, Cy3-modified cODN(C) and ODN(XK) (10 µM each), where X = G, C and I;
and K = CNVK, NH2VK and OHVK, in 50 mM sodium cacodylate buffer containing 100 mM sodium
◦
chloride (pH 7.4) were irradiated with 366 nm UV radiation for 120 s at 4 C using UV-LED(ZUV-C10,
Kyoto, Japan). The solutions were analyzed by 15% denaturing Polyacrylamide gel electrophoresis
(PAGE) and the result is shown in Figure 2. In case of ODN(ICNVK), ODN(INH2VK) and ODN(IOHVK),
The band corresponding to cODN(C) decreased depending on photoirradiation time and the band of
ODN(XK<>C) appeared. Then all ODNs were cross-linked in 60 s with a yield of >90% as analyzed
by denaturing PAGE analysis. These photoadducts were purified using high performance liquid
chromatography (HPLC).
The ODN(XK<>C) (5 µM) in 50 mM sodium cacodylate buffer and 100 mM sodium chloride
(pH 7.4) were incubated for 7 days at 37 ◦C. Samples were removed at 1 day intervals and the ODNs
were photo-split using 312 nm UV radiation for 15 min at 37 ◦C. The photo-split ODNs were then
analyzed by Ultra-high performance liquid chromatography (UPLC). The conversion of C
→
U was
studied by comparing peak areas under the curves of UPLC depicting the individual cODN(C) and
cODN(U) shown in the Figures 3–5. The photo-splitted ODNs were also subjected to enzymatic
digestion using Nuclease P1 and alkaline phosphatase to digest the ODNs to a single nucleotide and
to confirm the deamination reac◦tion (Figure S2). In the case of inosine as a counter base, deamination
occurred by incubation at 37 C using ODN(IOHVK), ODN(INH2VK) and ODN(ICNVK). The peak
identical to ODN(C) was observed before incubation. The peak decreased upon incubation and a
new peak identical to ODN(U) appeared (Figure 3). Surprisingly, in the case of ODN(IOHVK<>C),
deamination occurred approximately 70% upon incubation at 37 ◦C for a week. We observed that
deamination proceeded at the maximum rate (k = 7.1
Deamination reaction rates were intermediate when ODN(INH2VK<>C) and ODN(ICNVK<>C) were
used, with k = 3.5
10−3 h−1 and 4.7 10−3 −1, respectively. It is interesting to note here that
the rate of deamination while using ODN(ICNVK) in 7 days is 4.7 10−3 h−1, whereas, while using
ODN(IOHVK) the rate has increased almost 1.6 folds. This has definitely shown an improvement over
×
10−3 −1) in the case of ODN(IOHVK<>C).
h
×
×
h
×

Molecules 2018, 23, 828
4 of 12
our previous results where we obtained ~35% conversion in 3 days [27]. Also, with ODN(IOHVK<>C),
the rate of deamination of cytosine to uracil was 2-fold faster than that with ODN(INH2VK<>C).
◦
In the case of guanine as a counter base, the deamination occurred by incubation at 37 C using
ODN(GOHVK<>C), ODN(GNH2VK<>C) and ODN(GCNVK<>C). The peak identical to ODN(C) was
observed before incubation. The peak decreased upon incubation and a new peak identical to cODN(U)
appeared (Figure 4).
Figure 2. Polyacrylamide gel electrophoresis (PAGE) analysis of the mixture of ODN(XK) and
Cy3-modified cODN(C) after photo-cross-linking using various times. [ODN] = 10 µM in 50 mM
sodium cacodylate buffer (pH 7.4) containing 100 mM NaCl. Photoirradiation at 366 nm was performed
◦
at 4 C. Ultra-high performance liquid chromatography (UPLC) chromatograms for photo-cross-linking
are shown in Figure S1.
Figure 3. UPLC analysis of the deamination reaction of the photo-cross-linked duplex consisting of
ODN(IK) and cODN(C). [ODN(IK<>C)] = 5 µM in 50 mM Na-cacodylate buffer (pH 7.4) containing
100 mM NaCl. incubated at 37 ◦C, photo splitting was performed with transilluminator (312 nm) at
◦
37 C. Peak marked with asterisk (*) indicate the newly formed ODN(U).

Molecules 2018, 23, 828
5 of 12
Figure 4. UPLC analysis of the deamination reaction of the photo-cross-linked duplex consisting of
ODN(GK) and cODN(C). [ODN(GK<>C)] = 5 µM in 50 mM Na-cacodylate buffer (pH 7.4) containing
100 mM NaCl. incubated at 37 ◦C, photo splitting was performed with transilluminator (312 nm) at
◦
37 C. Peak marked with asterisk (*) indicate the newly formed ODN(U).
Figure 5. UPLC analysis of the deamination reaction of the photo-cross-linked duplex consisting of
ODN(CK) and cODN(C). [ODN(CK<>C)] = 5 µM in 50 mM Na-cacodylate buffer (pH 7.4) containing
100 mM NaCl. incubated at 37 ◦C, photo splitting was performed with transilluminator (312 nm) at
37 ◦C. Peak marked with asterisk (
newly formed ODN(U).
*) indicate the newly formed ODN(U) with asterisk indicate the

Molecules 2018, 23, 828
6 of 12
◦
In the case of cytosine as counter base, deamination occurred by incubation at 37 C using
ODN(CCNVK<>C), ODN(COHVK<>C) and ODN(CNH2VK<>C). A peak identical to that of ODN(C)
was observed before incubation. A peak decreased on incubation and a new peak identical to
ODN(U) appeared (Figure 5). It can be noted that the highest conversion of C
by ODN(IOHVK<>C) (~70%) in 7 days. In general, among all the counter-bases, inosine containing
ODNs showed maximum C U conversion in combination with the photo-cross-linkers. ODNs
→
U was achieved
→
containing cytosine and guanine showed almost similar reaction rates for all the photo-cross-linkers.
The difference in the rate of deamination in the photo-cross-linked ODNs can be attributed to hydrogen
bonding pattern. Due to cross-linking, the overall planarity of cytosine is perturbed and a tilt appears
in the non-planar part of cytosine towards the central axis pertaining to change in the hydrogen
bonding pattern. These changes lead to a hydrogen bond between the adjacent base of cytosine and the
amino group of cytosine, specifically observed in case of ODN with inosine. These hydrogen bonding
patterns are comparable to hydrogen bonding observed near the active site of yeast cytosine deaminase
(yCD), wherein a special network of hydrogen bonds has been observed in the enzyme [29,30]. This
special network of hydrogen bonding is critical for the protonation of N3 of cytosine through the Glu64
and conformational changes of cytosine giving accessibility to water attack facilitated by zinc-bound
water on C4 of cytosine. The patterns observed in the cross-linked cytosine of hydrogen bonding
are equivalent to these patterns observed in yCD. Prior to cross-linking, the hydrogen bonding is
according to Watson-Crick base-pairing, whereas, after cross-linking, due to change in planarity of
cytosine, the hydrogen is with adjacent base facilitating the nucleophile attack on C4. Furthermore, the
hydrogen bonding N3 is also crucial for proton shuttling.
Therefore, the number of hydrogen bonds in the photoadduct directly affected the rate of
deamination, wherein fewer H-bonds between the target cytosine and counter-base facilitated the
deamination reaction. Upon comparing the photo-cross-linkers, the same pattern was observed. In this
photochemical deamination, the hydrophilicity around the C4 in the target cytosine is the important
factor because of cytosine deamination requires water molecules. To assess the correlation between
the hydrophilicity of photo-cross-linked dsDNA and rate of deamination reaction, we calculated the
partition coefficient (LogP) [31,32] of photo-cross-linked dsDNA using their HPLC retention times
(Table 2). The hydrophilicity of ODNs positively correlated with their ability to convert cytosine to
uracil in a photo-responsive manner. Photo-cross-linked ODN(IOHVK<>C), ODN(GOHVK<>C) and
ODN(COHVK<>C) have the highest hydrophilicity value (LogP = 0.52, 0.54 and 0.57 respectively)
among all the ODNs due to presence of highly hydrophilic photo-cross-linker OHVK (Table 2 and Figure
S3). Among these ODNs, it has been observed that the highest rate of cytosine to uracil conversion has
been observed in ODN(IOHVK<>C) having the highest hydrophilicity. Similar pattern for deamination
of cytosine has been observed in the ODNs containing NH2VK. The highest rate has been observed in
ODN(INH2VK<>C) followed by ODN(GNH2VK<>C) and ODN(CNH2VK<>C) (Figure 6), having their
LogP in the similar order, that is, highest hydrophilicity is shown by ODN(INH2VK<>C) among these
three. Even in the ODNs with CNVK, the relation between LogP (hydrophilicity) and deamination
reaction rate constant is positive correlation (Table S2 and Figure S4). ODNs containing OHVK are the
most hydrophilic therefore shows highest rate of cytosine to uracil conversion. Thus, upon careful
analysis of the results it is evident that the two major factors required for high rate of deamination
in the vinyl carbazole based photo-cross-link assisted cytosine deamination are hydrogen bonding
in the target cytosine and the hydrophilicity of the photo-cross-linker. Upon combining these two
factors, the maximum C
→
U conversion can be achieved by using ODN containing inosine and
OHVK at physiological conditions, therefore ODN(IOHVK<>C) having the highest hydrophilicity and
optimum hydrogen bonding has shown highest rate of deamination among all the other ODNs.
Thus, ODN(IOHVK<>C) was then further incubated for 20 days at 37 ◦C to determine the extent of
deamination that can be achieved in this period. It has been observed from the UPLC chromatogram
that the deamination reached a stationary phase and the reaction proceeded only minimally in the
later stage of deamination (Figure 7).

Molecules 2018, 23, 828
7 of 12
Figure 6.
(a) Time course of the deamination reactions of the photo-adducts ODN(XK<>C). (b)
Deamination reaction rate constants of the photo-adducts ODN(XK<>C). The values besides the
bars are reaction rate constants and the values in braces indicate the acceleration ratio compared to the
case of CCNVK. Photoreaction rate constants were estimated from the time course of the deamination
reaction with an assumption of first-order reaction kinetics.
Table 2. Partition coefficient (LogP).
Entry
Retention Time (min)
LogP
ODN(IOHVK<>C)
ODN(GOHVK<>C)
ODN(COHVK<>C)
ODN(INH2VK<>C)
ODN(GNH2VK<>C)
ODN(ICNVK<>C)
ODN(GCNVK<>C)
ODN(CCNVK<>C)
ODN(CNH2VK<>C)
13.8
14.2
14.7
15.4
16.0
16.3
16.6
17.3
17.8
0.52
0.54
0.57
0.61
0.64
0.66
0.68
0.72
0.75
In this paper, 7 days of reaction at physiological conditions gives ~70% conversion, which is
optimum for in vivo applications under physiological conditions. These results give hope that, in the

Molecules 2018, 23, 828
8 of 12
future, this non-enzymatic technique of site-directed mutagenesis might be used in vivo for curing
and treating various disorders arising because of mutations in the genome.
Figure 7.
(a) Scheme and sequence of deamination and time course of deamination reaction. (b) UPLC
analysis of the deamination reaction of the photo-cross-linked duplex consisting of ODN(IK) and
cODN(C) for a duration of 20 days. [ODN(IK<>C)] = 5 µM in 50 mM Na-cacodylate buffer (pH 7.4)
containing 100 mM NaCl. incubated at 37 ◦C, photo splitting was performed with transilluminator
◦
(312 nm) at 37 C. Peak marked with asterisk (*) indicate the deaminated product.
3. Materials and Methods
3.1. General
1H nuclear magnetic resonance (NMR) spectra were recorded on a AVANCE III 400 system
(Bruker, Billerica, MA, USA). Mass spectra were recorded on a Voyager PRO-SF, (Applied Biosystems,
Foster City, CA, USA). HPLC was performed on a Chemcosorb 5-ODS-H column with JASCO PU-980,
HG-980-31, DG-980-50 system equipped with a JASCO UV 970 detector (JASCO, Tokyo, Japan) at
260 nm. Reagents for DNA synthesis such as A, G, C, T-β-cyanoethyl phosphoramidite and CPG
support were purchased form Glen Research (Sterling, VA, USA).
3.2. Synthesis and Preparation of Modified Oligonucleotides
The phosphoramidite of OMeVK and CNVK were prepared following to Scheme 1 and previous
reports [28,
33]. The modified oligonucleotides containing CNVK or OMeVK were prepared, per standard
phosphoramidite chemistry using DNA synthesizer (ABI 3400 DNA synthesizer, Applied Biosystems,
Foster City, CA, USA). The ODN containing OMeVK was post modified to ODN containing OMeVK,
OHVK, or NH2VK in deprotection step (Scheme 2). Synthesized ODN were detached from the support by

Molecules 2018, 23, 828
9 of 12
soaking in concentrated aqueous ammonia for 1 h at ◦room temperature. Deprotection was conducted
by heating the aqueous concentration for 4 h at 65 C, before removing the concentrated aqueous
ammonia by speedvac and purifying the crude oligomer by reverse phase HPLC equipped with
InertSustainTM C18 column CosmosilTM 5C18-AR-II column (5
µ
m, 10
×
150 mm, (Nacalai tesque,
Kyoto, Japan), Flow rate of 3.0 mL/min, 60 ◦C) and lyophilizing it. Synthesis of ODN was confirmed
by MALDI-TOF-MS. Other ODNs were purchased from Fasmac (Kanagawa, Japan).
Scheme 1. Synthetic scheme for preparation of photo-responsive nucleotide.
Scheme 2. Post-modification of photo-cross-linker in ODN.
3.3. Denaturing PAGE Analysis
Polyacrylamide gel electrophoresis (PAGE) was performed with 15% polyacrylamide containing
8M urea. After the electrophotresis (150 V, 80 min), a fluorescent image was taken by luminescent
image analyzer (LAS3000, Fujifilm, Tokyo, Japan).
3.4. Isolation of Photo-Cross-Linked dsDNA
The cODN (C) (15 µM) and ODN (XK), where X is the counter base and K is the photo-cross-linker,
(15 µM) in a buffer solution (100 mM NaCl, 50 mM sodium cacodylate, pH 7.6), was photoirradiated at
366 nm for 120 s using UV-LED illuminator (OMRON Inc., Tokyo, Japan, 1600 mW) at 37 ◦C. And the
solution was purified by reverse phase HPLC and the concentration of photo-cross-linked dsDNA was
determined by absorbance at 260 nm.

Molecules 2018, 23, 828
10 of 12
3.5. Deamination
The solution of 15
µM ODN(XK) and ODN(C) in buffer solution was annealed and photoirradiated
at 366 nm. The photoirradated solution was purified by a reversible HPLC to obtain the purified
photo-cross-linked dsDNA. The 5
µM photo-cross-linked dsODN in a buffer solution (50 mM
Na-cacodylate buffer (pH 7.4) containing 100 mM NaCl) was incubated at 37 ◦C.
3.6. Photo-Splitting and UPLC Analysis
◦
After the photo-splitting with irradiation of 312 nm (15 min at 37 C, transillluminator, (Funakoshi,
Tokyo, Japan)), the reaction mixture was analyzed with the UPLC system (Aquity, Waters, Milord,
MA, USA); elution was with 0.05 M ammonium formate containing 3–6.5% CH3CN, linear gradient
(10 min) at a flow rate of 0.2 mL/min.
3.7. Partition Coefficient (LogP)
LogP of photo-cross-linked DNA was measurement by their retention time following OECD
protocol. 10 µM photo-cross-linked dsDNA was analyzed with HPLC system; elution was with 0.05 M
ammonium formate containing 98–50% CH3CN, linear gradient (60 min) at flow rate of 1 mL/min.
4-Acetylpyridine, Aniline, Acetanilide, Phenol, Benzonitrile and Acetophenone were used as control
compound to create calibration curve [26,27].
3.8. Enzymatic Digestion
◦
ODNs after photo-splitting were incubated with 0.2 unit/
the solution was treated with alkaline phosphatase (0.1 unit/
µ
L Nuclease P1 for 24 h at 37 C. Further,
µ
L) for 24 h at 37 ◦C and analyzed with
HPLC system. Elution was with 1–20% MeCN in 50 mM ammonium formate buffer for 30 min at a
linear gradient with a column temperature 60 ◦C and a flow rate of 1 mL/min.
4. Conclusions
The major factors responsible for the rate of 3-vinyl carbazole based photo-cross-link assisted
cytosine deamination at physiological conditions are the hydrophilicity of the photo-cross-linker
and the hydrogen bonding of the target cytosine. Thus, the best combination of counter-base and
photo-cross-linker can result in the highest conversion of C
→
U in the least time at physiological
conditions, when inosine is used as the counter-base and OHVK is used as the photo-cross-linker.
Supplementary Materials: The MS data, UPLC result and enzymatic digestion of deamination product is
available online.
Acknowledgments: This study was supported by JSPS KAKENHI Grant Number 17H03085 (Grant-in-Aid for
Scientific Research (B)) and Asahi Glass Foundation.
Author Contributions: Kenzo Fujimoto conceived the experiments and provided funding and intellectual support.
Shigetaka Nakamura and Siddhant Sethi performed the experiments and analyzed the data. Siddhant Sethi wrote
the paper with additional support from Shigetaka Nakamura and Kenzo Fujimoto in editing and proof-reading.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
4.
Cascalho, M. Advantages and disadvantages of cytidine deamination. J. Immunol. 2004, 172, 6513–6518.
[CrossRef] [PubMed]
Storici, F.; Lewis, L.K.; Resnick, M.A. In vivo site-directed mutagenesis using oligonucleotides. Nat. Biotechnol.
2001, 19, 773–776. [CrossRef] [PubMed]
Esvelt, K.M.; Wang, H.H. Genome-scale engineering for systems and synthetic biology. Mol. Syst. Biol. 2013
9, 1–17. [CrossRef]
,
Tan, W.S.; Carlson, D.F.; Walton, M.W.; Fahrenkrug, S.C.; Hackett, P.B. Precision editing of large animal
genomes. Adv. Genet. 2012, 80, 37–97. [CrossRef] [PubMed]

Molecules 2018, 23, 828
11 of 12
5.
6.
7.
8.
9.
Puchta, H.; Fauser, F. Gene targeting in plants: 25 years later. Int. J. Dev. Biol. 2013, 57, 629–637. [CrossRef]
[PubMed]
Sanger, J.D.; Joung, J.K. CRISPR-Cas systems for editing, regulating and targeting genomes. Nat. Biotechnol.
2014, 32, 347–355. [CrossRef]
Mali, P.; Yang, L.; Esvelt, K.M.; Aach, J.; Guell, M.; DiCarlo, J.E.; Norville, J.E.; Church, G.M. RNA-guided
human genome engineering via Cas9. Science 2013, 339, 823–826. [CrossRef] [PubMed]
Jiang, W.; Bikard, D.; Cox, D.; Zhang, F.; Marraffini, L.A. RNA-guided editing of bacterial genomes using
CRISPR-Cas systems. Nat. Biotechnol. 2013, 31, 233–239. [CrossRef] [PubMed]
Javier, N.D.; Michael, N.S. Altering the pathway of immunoglobulin hypermutation by inhibiting uracil-DNA
glycosylase. Nature 2002, 419, 43–48. [CrossRef]
10. White, M.K.; Kaminski, R.; Young, W.B.; Roehm, P.C.; Khalili, K. CRISPR Editing Technology in Biological
and Biomedical Investigation. J. Cell. Biochem. 2017, 117, 3586–3594. [CrossRef] [PubMed]
11. Cho, S.W.; Kim, S.; Kim, J.M.; Kim, J.S. Targeted genome engineering in human cells with the Cas9
RNA-guided endonuclease. Nat. Biotechnol. 2013, 31, 230–232. [CrossRef] [PubMed]
12. Zhang, X.H.; Tee, L.Y.; Wang, X.G.; Huang, Q.S.; Yang, S.H. Off-target Effects in CRISPR/Cas9-mediated
Genome Engineering. Mol. Ther.-Nucleic Acids 2015, 4, e264. [CrossRef] [PubMed]
13. McMahon, M.A.; Rahdar, M.; Porteus, M. Gene editing: Not just for translation anymore. Nat. Methods 2012
9, 28–31. [CrossRef] [PubMed]
,
14. Smith, J.; Grizot, S.; Arnould, S.; Duclert, A.; Epinat, J.C.; Chames, P.; Prieto, J.; Redondo, P.; Blanco, F.J.;
Bravo, J.; et al. A combinatorial approach to create artificial homing endonucleases cleaving chosen sequences.
Nucleic Acids Res. 2006, 34, e149. [CrossRef] [PubMed]
15. Kim, H.; Kin, J. A guide to genome engineering with programmable nucleases. Nat. Rev. Genet. 2014, 15,
321–334. [CrossRef] [PubMed]
16. Frommer, M.; McDonald, L.E.; Millar, D.S.; Collis, C.M.; Watt, F.; Grigg, G.W.; Molloy, P.L.; Paul, C.L. A
genomic sequencing protocol that yields a positive display of 5-methylcytosine residues in individual DNA
strands. Proc. Natl. Acad. Sci. USA 1992, 89, 1827–1831. [CrossRef] [PubMed]
17. Yamana, K.; Yoshikawa, A.; Nakano, H. Synthesis of a new photoisomerizable linker for connecting two
oligonucleotide segments. Tetrahedron Lett. 1996, 37, 637–640. [CrossRef]
18. Lee, B.L.; Blake, K.R.; Miller, P.S. Interaction of psoralen-derivatized oligodeoxyribonucleoside
methylphosphonates with synthetic DNA containing a promoter for T7 RNA polymerase. Nucleic Acids Res.
1988, 16, 10681–10697. [CrossRef] [PubMed]
19. Montes, C.V.; Memczak, H.; Gyssels, E.; Torres, T.; Madder, A.; Schneider, R.J. Photoinduced Cross-Linking
of Short Furan-Modified DNA on Surfaces. Langmuir 2017, 33, 1197–1201. [CrossRef] [PubMed]
20. Kurz, M.; Gu, K.; Lohse, P.A. Psoralen photo-crosslinked mRNA-puromycin conjugates: A novel template
for the rapid and facile preparation of mRNA-protein fusions. Nucleic Acids Res. 2000, 28, 83. [CrossRef]
21. Liang, X.; Wakuda, R.; Fujioka, K.; Asanuma, H. Photoregulation of DNA transcription by using
photoresponsive T7 promoters and clarification of its mechanism. FEBS J. 2010, 277, 1551–1561. [CrossRef]
22. Liu, J.; Geng, Y.; Pound, E.; Gyawall, S.; Ashton, J.R.; Hickey, J.; Woolley, A.T.; Harb, J.N. Metallization of
branched DNA origami for nanoelectronic circuit fabrication. ACS Nano 2011, 5, 2240–2247. [CrossRef]
[PubMed]
23. Iwase, R.; Namba, M.; Yamaoka, T.; Murakami, A. Gene regulation by decoy approach (I): Synthesis and
properties of photo-crosslinked oligonucleotides. Nucleic Acids Symp. Ser. 1997, 37, 203–204.
24. Fujimoto, K.; Konishi-Hiratsuka, K.; Sakamoto, T.; Yoshimura, Y. Site-specific photochemical RNA editing.
Chem. Commun. 2010, 46, 7545–7547. [CrossRef]
25. Fujimoto, K.; Konishi-Hiratsuka, K.; Sakamoto, T.; Yoshimura, Y. Site-Specific Cytosine to Uracil Transition
by Using Reversible DNA Photo-crosslinking. ChemBioChem 2010, 11, 1661–1664. [CrossRef] [PubMed]
26. Sakamoto, T.; Ooe, M.; Fujimoto, K. Critical Effect of Base Pairing of Target Pyrimidine on the Interstrand
Photo-Cross-Linking of DNA via 3-Cyanovinylcarbazole Nucleoside. Bioconj. Chem. 2015, 26, 1475–1478.
[CrossRef] [PubMed]
27. Sethi, S.; Ooe, M.; Sakamoto, T.; Fujimoto, K. Effect of nucleobase change on cytosine deamination through
DNA photo-cross-linking reaction via 3-cyanovinylcarbazole nucleoside. Mol. BioSyst. 2017, 13, 1152–1156.
[CrossRef] [PubMed]

Molecules 2018, 23, 828
12 of 12
28. Sethi, S.; Yasuharu, T.; Nakamura, S.; Fujimoto, K. Effect of substitution of photo-cross-linker in
photochemical cytosine to uracil transition in DNA. Bioorg. Med. Chem. Lett. 2017, 27, 3905–3908. [CrossRef]
[PubMed]
29. OECD Guidline for Testing of Chemicals. Available online: http://www.oecd.org/chemicalsafety/risk-
assessment/1948177.pdf (accessed on 15 December 2017).
30. Borges, N.M.; Kenny, P.W.; Montanari, C.A.; Prokopozyk, I.M.; Ribeiro, J.F.; Rocha, J.R.; Sartori, G.R. The
influence of hydrogen bonding on partition coefficients. J. Comput.-Aided Mol. Des. 2017, 31, 163–181.
[CrossRef] [PubMed]
31. Sklenak, S.; Yao, L.; Cukier, R.I.; Yan, H. Catalytic mechanism of yeast cytosine deaminase: An ONIOM
computational study. J. Am. Chem. Soc. 2004, 126, 14879–14889. [CrossRef] [PubMed]
32. Zhang, X.; Zhao, Y.; Yan, H.; Cao, Z. Combined QM(DFT)/MM molecular dynamics simulations of the
deamination of cytosine by yeast cytosine deaminase (yCD). J. Comput. Chem. 2016, 37, 1163–1174. [CrossRef]
[PubMed]
33. Yoshimura, Y.; Fujimoto, K. Ultrafast reversible photo-cross-linking reaction: Toward in situ DNA
manipulation. Org. Lett. 2008, 10, 3227–3230. [CrossRef]
Sample Availability: Samples of the compounds are available from the authors.
©
2018 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
