Study of N-Benzylidene derivatives synthesized as corrosion
inhibitors for copper in HCl solution
a,*
a
a
Mohsen Behpour , Mehdi Shabani-Nooshabadi , Faezeh Sadat Razavi , Masood Hamadanian
b,c
a
,
Vajihe Nejadshafiee
a
Department of Analytical Chemistry, Faculty of Chemistry, University of Kashan, Kashan,
P.O. Box 87317-51167, I.R. Iran
b
Institute of Nanosciences and Nanotechnology, University of Kashan, Kashan, Iran
c
Department of Physical Chemistry, Faculty of Chemistry, University of Kashan, Kashan, Iran
E-mail: m.behpour@kashanu.ac.ir
*
corresponding author:
E-mail address: m.behpour@kashanu.ac.ir
Fax No: +983155912935, Tel No:+983155912930
1

RSC Advances
Page 2 of 36
View Article Online
DOI: 10.1039/C5RA00561B
Abstract
Corrosion inhibition of the two N- Benzylidene derivative compounds, namely N-benzylidene
Pyridin – 2 amine (NBPA) and N-(4-choloromethylbenzylidene) Pyridin – 2 amine (NCMBPA) as
corrosion inhibitors for copper in hydrochloric acid 6.0 M have been studied by electrochemical
methods such as potentiodynamic polarization measurements and electrochemical impedance
spectroscopy. Potentiodynamic polarization results show that corrosion potentials shift to anodic
regions in the presence of N- Benzylidene compounds compared to blank solution. The
electrochemical measurements indicated that the inhibition efficiency for NCMBPA about 92% and
NBPA about 85%. The adsorption of inhibitors on the copper surface follows from Langmuir
*
adsorption isotherm. Activation energy (E ), Gibbs free energy (ΔG ), enthalpy (ΔH ), and entropy
a
ads
*
(
ΔS ) of corrosion process are determined by using the experimental measurements.
Keywords: Acid inhibition; Corrosion; Copper; Impedance spectroscopy; Polarization
1
. Introduction
Copper and its alloys are extensively applied in many fields on account of their electrical,
thermal and mechanical properties such as ductility, hardness, strength and low price. Safety of
1
-6
copper is of exacting interest, particularly in acidic media, which also includes chloride ions .
Copper is susceptible against corrosion in such separate surroundings, although it is highly
resistant in practically neutral or slightly alkaline aqueous environment. The utilization of suitable
inhibitor to offer an explanation the particular corrosion mechanism of copper in acidic chloride
environments is essential. It is commonly accepted that anodic dissolution of copper in chloride
environments is influenced by the chloride concentration and the acidity of the medium. At chloride
2

Page 3 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
concentrations lower than 1.0 M, the dissolution of copper occurs through formation of CuCl which is
-
not defensive enough and is changed to the soluble CuCl by reacting with excess chloride.
2
-2
Alternatively, at concentrations higher than 1.0 M, higher copper complexes such as CuCl3 and
-3
- 7
CuCl are formed, in addition to the ones with fewer chlorides, such as CuCl and CuCl
.
4
2
Most of acid corrosion inhibitors are organic compounds containing electronegative atoms (such
as, N, S, P, O, etc.), the unsaturated bounds (such as, double bonds or triple bonds, etc.) and the plane
8
-13
conjugated systems containing all kinds of aromatic cycles
compounds is usually attributed to their interactions with copper surface by their adsorption
usage of nitrogen and sulfur containing organic compounds as corrosion inhibitor for copper has been
. The inhibiting action of these
1
4-16
.The
1
7-27
commonly investigated
. Some Schiff bases have been recently studied as corrosion inhibitors for
2
8–32
different metals and alloys in acid media
. These materials usually become effective by
adsorption on the metal surface. The adsorbed species protect the metal from the aggressive medium,
which causes decay of the metal. Adsorption depends on not only the nature and charge of the metal
but also on the chemical structure of the inhibitor.
Increasing popularity of Schiff bases in the field of corrosion inhibition science based on the
ease of synthesis from relatively inexpensive starting materials and their eco-friendly or low toxic
3
3, 34
properties
. The high inhibitory performance of these compounds results from the substitution of
different heteroatoms (N, O, Cl and Br) and π-electrons in their structure in besides the presence of
3
5, 36
imine ( —C=N— ) functional group
. This organic compound having general formula R–C=N–R'
where R and R' are aryl, alkyl or cycloalkyl or heterocyclic groups formed by the condensation of an
amine and a carbonyl group, is a potential inhibitor. These molecules normally form a very thin and
persistent adsorbed film that lead to decrease in the corrosion rate due to the slowing down of
3

RSC Advances
Page 4 of 36
View Article Online
DOI: 10.1039/C5RA00561B
37–39
cathodic, anodic reaction or both
. In order to improve the inhibitive force, synergistic inhibition
4
0
effect is an effective method .
In the present work, the inhibition effect of NBPA and NCMBPA on the corrosion of copper in
.0 M HCl solution was firstly investigated by potentiodynamic polarization curves, electrochemical
6
impedance spectroscopy (EIS). The adsorption isotherm and adsorption free energy were found and
discussed. Effects of inhibitor concentration, temperature on the corrosion inhibition were fully
investigated. Quantum chemical calculation of including the solvent effect is applied to study the
difference in theoretical parameters between neutral inhibitor molecule and protonated inhibitor
molecule. It is estimated to collect useful information on the inhibition effect of NBPA and
NCMBPA on copper corrosion in HCl solution.
2
. Experimental
2
2
.1. Material
.1.1. General procedure for the synthesis of Schiff base ligands
All the di dentate Schiff base ligands were prepared by condensation between aldehyde and
pyridine-2-amine in ethanol (EtOH) and purified by recrystallization from ethanol through the partial
evaporation of the more volatile dichloromethane. Schiff base ligands prepared by dissolving
aldehyde (1 mmol) and pyridine-2-amine (1 mmol) in ethanol with stirring in one portion. The
stirring was continued to completion of the reaction. The progress of the reaction was monitored by
thin layer chromatography (TLC). After the completion of the reaction, a colored substance was
obtained. The solid product was filtered and washed with cold EtOH. The crude product was purified
by recrystallization from ethanol and the pure Schiff base was obtained in high yield after leaving for
4
1
the appropriate time (Fig 1) .
4

Page 5 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
2
.1.2. Solutions and samples
The corrosive solution is prepared by dilution of analytical grade hydrochloric acid 11.0 M with
double distilled water. The concentration range of employed inhibitors is 0.01 to 0.0005 M in 6.0 M
HCl.
The metal of this study was copper having 99.9% purity. Copper panels were rectangular in size
(1.0 cm, 1.0 cm, 0.1 cm). The panels were soldered with Cu-wire for electrical connection and
mounted into the epoxy resin to offer only one active flat surface exposed to the corrosive
environment. Prepare panels incorporated abrasion with SiC abrasive paper 400-2500 grades. The
above samples were ultrasonically cleaned with ethanol and double distilled water, respectively.
Then, they were dried at room temperature before immersion in experimental solution.
2
.2. Electrochemical measurement
Electrochemical studies were carried out using an AUTOLAB model PGSTAT 30. The usual
three electrode system was used for this purpose. Copper specimen was used as a working electrode.
-
Pt electrode and silver-silver chloride Ag/AgCl (3.0 M Cl ) served as counter and reference
electrodes, respectively. All polarization and impedance curves were recorded at room temperature
0
(
25±2 C). The working electrode was immersed in the test solution for 1000 seconds until a steady
state open-circuit potential was attained. NOVA software was used for fitting impedance data in an
equivalent circuit as well as for extrapolating Tafel slopes. Experiments were carried out in triplicate
to ensure reproducibility of results.
2
.3. Electrochemical impedance spectroscopy study
5

RSC Advances
Page 6 of 36
View Article Online
DOI: 10.1039/C5RA00561B
The EIS measurements were performed over the frequency range 100 kHz to 100 mHz at the
open circuit potential by superimposing alternating current (AC) signal of 0.01V after immersion for
1
000 second in the corrosive media. The inhibition efficiencies for each inhibitor concentration were
calculated using the eq 1:
ꢂꢃꢄꢅꢂꢆ
ꢀ
ꢁ
ꢇꢈꢉꢉ
(1)
ꢂꢃꢄ
where R and R are the charge transfer resistances in the presence and absence of the inhibitor
ct
0
respectively.
2
.4. Potentiodynamic polarization
The potentiodynamic polarization curves were recorded from -200 to 200 mV (vs. Ag/AgCl (3.0
-
-1
M Cl )) corresponding to the corrosion potential with scan rate of 0.01 mV s . The inhibition
efficiencies at different inhibitor concentrations were estimated using the eq 2:
ꢊ
ꢊ
ꢆꢋ ꢌ
ꢀ
ꢁ
ꢇꢈꢉꢉ
(2)
ꢊꢆ
where ꢍ and ꢏ are the corrosion current densities in the absence and presence of the inhibitor,
ꢎ
ꢐ
respectively.
2
.5. Quantum chemical study
All the calculations were performed with of complete geometry optimization by using the
standard Gaussian 98 software package with semi-empirical methods including the Austin Model
B3LYP with 6-311G** basis set and Conductor-like Screening Model' or COSMO method which
4
2
includes PCM and CPCM methods . COSMO is a calculation method for determining the
electrostatic interaction of a molecule with a solvent. The polarizable continuum model (PCM) is a
commonly used method in computational chemistry to model solvation effects. If it were necessary to
6

Page 7 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
consider each solvent molecule as a separate molecule, the computational cost of modeling a solvent-
mediated chemical reaction would grow prohibitively high. Modeling the solvent as a polarizable
continuum, rather than individual molecules, makes initio computation feasible. Two types of PCMs
have been popularly used: dielectric PCM (D-PCM) which deals the continuum as a polarizable
dielectrics and conductor-like PCM (C-PCM) which deals the continuum as a conductor-like picture
6
9,70
similar to COSMO Solvation Model
View 3.0.
. The molecule sketch of Schiff bases was drawn in Gauss
2
.6. Scanning electron microscopy (SEM) studies
In order to get insight into the changes on surface of corrosive samples before and after the
addition of inhibitors, the specimens were first immersed in 6.0 M HCl in the absence and presence of
0
.01 M NBPA or NCMBPA for 3 h, respectively. Then taken out from the test solutions, cleaned
with double-distilled water and dried at room temperature. The SEM images were conducted using a
Philips scanning electronic microscope model XL30.
3
. Result and discussion
.1. Electrochemical impedance spectroscopy measurements
Fig. 2 shows the Nyquist plots of copper in a 6.0 M HCl solution in the absence and presence of
3
NBPA and NCMBPA in different concentrations. As seen in Fig. 2. The Nyquist plots of blank
solutions (hydrochloric acid 6.0 M) show Warburg impedance at low frequencies (Fig. 3) and only
one depressed capacitive loop. Warburg impedance in the absence of inhibitors shows that the
dissolution mechanism of copper is controlled by mass transport rate. The diffusion step of copper
dissolution in several papers is ascribed to the transport of chloride ions to the surface or the transport
of chloride-copper complexes43, and the depressed capacitive loop has been ascribed to roughness
7

RSC Advances
Page 8 of 36
View Article Online
DOI: 10.1039/C5RA00561B
44
and in-homogeneities on the surface during corrosion . This behaviour is unchanged by the presence
of the inhibitor, indicating the activation-controlled nature of the reaction throughout a one-charge
transfer process. All EIS spectra were analyzed by the equivalent circuit in Fig. 3, which shows a
single transfer reaction and fits well with our experimental results. R represents the ohmic resistance
s
of the solution and R represents the charge transfer resistance whose value is an estimation of
ct
electron transfer across the surface and is contrary relative to corrosion rate. The constant phase
element, CPE, is introduced in the circuit instead of a pure double layer capacitor to give a more
4
5
accurate fit . The impedance of the CPE is expressed by the eq 3:
ꢙ ꢅꢐ
ꢑꢒꢓꢔ ꢁ[ꢕ (ꢗꢘ) ꢚ
ꢎꢖ
(3)
where Y is the magnitude of the CPE, ω the angular frequency (ω = 2πf, where f is the AC
0
frequency), j is the imaginary unit and n the CPE exponent (phase shift). When the value of n is 1, the
CPE behaves like an ideal double-layer capacitance (Cdl).
The experiments are repeated three times and fitted spectra are listed in Table 1. The data of
Table 1 show that the R values are very small contrast to the R values. R is a measure of electron
s
ct
ct
transfer across the surface and is inversely proportional to corrosion rate. The R values increased
ct
with inhibitor concentrations may suggest the formation of a protective layer on the electrode surface.
4
6
This layer makes a barrier for mass and charge-transfer . The R value of the blank solution is about
ct
2
2
9
8.6 Ω cm , while the R for NBPA inhibited solution increases to about 847.4 Ω cm and for
ct
2
NCMBPA inhibited solution increase about 1257.8 Ω cm . The results show the inhibited molecules
on the copper surface might be a barrier to the communication between oxide species and ionic
solution.
3
.2. Potentiodynamic polarization measurements
8

Page 9 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
The potentiodynamic polarization curves of copper in 6.0 M HCl with and without different
concentrations of NBPA and NCMBPA are shown in Fig. 4. As shown in the figures, the presence of
inhibitors causes a major decrease in the corrosion current. Decrease of current densities indicates in
both anodic and cathodic Tafel curves. This phenomenon indicates that both anodic metal dissolution
and cathodic hydrogen evolution reaction are suppressed, meanwhile, the inhibition of these reactions
is more pronounced with the increasing inhibitor concentration.
The values of corrosion potential (Ecorr), cathodic Tafel slope (bc), anodic Tafel slope (ba),
corrosion current (icorr) and the inhibition efficiency (ƞ) are given in Table 2. These values are
getting by extrapolating the Tafel lines to the related corrosion potentials.
Examination of Table 2 shows that values of the corrosion current of copper in the inhibited
,
solutions are lesser than that in the bare solution, and with the increasing concentration of Schiff s
base inhibitors, the inhibition efficiency is increased. The inhibition efficiency finds from polarization
experiments is created opposite the order:
(NBPA) < (NCMBPA).
However, the difference of the inhibition efficiency between the two inhibitors is high, which
can be featured to the difference between the structures of the two molecules. Alternatively,
synergistic effect shows the increase in the efficiency of a corrosion inhibitor in the presence of a
derivative species. The synergism effect has been reported due to the increased surface coverage on
account of ion pair contacts between an organic cation and the halide anion. In inhibiting solution
halide ion initially adsorbs on the corroding surface with making oriented dipoles and it eases the
-
adsorption of inhibitor cations on the dipoles, consequently. Halide ions, especially Cl can increase
-
the speed or inhibit the copper corrosion. The synergism among the Cl ions and organic inhibitors is
very well shown. The purpose of protection is the protection in the presence of both the halide ion
and the organic inhibitor in solution.
9

RSC Advances
Page 10 of 36
View Article Online
DOI: 10.1039/C5RA00561B
The inhibitor classified as cathodic or anodic type, if the displacement in Ecorr is exceeds 85 mV
with respect to Ecorr of the blank and if the displacement in Ecorr is below 85 mv, the inhibitor can be
4
7
mixed type . In the presence of NBPA and NCMBPA, the corrosion potential of copper shifted to
-
the positive side more than 85 mV (vs. Ag/AgCl (3.0 M Cl )). The NBPA and NCMBPA act can be
understood as anodic type inhibitors.
3
.3. Adsorption isotherm
The adsorption of inhibitor molecules is one of the most important topics in corrosion
researches. Its importance comes from not only due to its ability to provide structural information of
the double layer but also due to the thermodynamic information can provide. There are two categories
from the adsorption of organic molecules on the electrode surface. First, adsorb the molecules with
keeping their chemical individuality. This interaction is rather feeble. This is a reversible type of
adsorption. On the contrary, the interaction among molecule and the surface may be very strong. This
phenomenon may cause a charge transfer between them and results new species form. This is the
irreversible type adsorption.
Adsorption isotherms can offer the important information on the relations between the active
sites on copper surface and the inhibitor molecules. The degrees of surface coverage (θ) for different
concentrations of inhibitor in 6.0 M HCl solution have been calculated from the consequences of
4
8, 49
potentiodynamic polarization or EIS measurements with the eq 4
:
ꢜ
ꢛꢁ
(4)
ꢐꢎꢎ
In this paper, with the intention of identify the nature and the strength of adsorption a series of
experimental adsorption isotherms were obtained as shown in Fig 5. It is clear that all linear
correlation coefficients (r) are approximately equal to 1, and the slope values are also close to 1,
1
0

Page 11 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
which shows the adsorption of NBPA and NCMBPA on copper surface obeys Langmuir adsorption
isotherm. It is represented by the eq 5:
ꢝꢞꢟꢠ
ꢡ
ꢐ
ꢁꢢ ꢦꢝꢧꢨꢩ
(5)
ꢣꢤꢥ
where Cinh is the concentration of inhibitor, θ is the degree of surface coverage Values for different
concentrations of the inhibitors in acidic solution; respectively. That equation has been calculated
with the EIS measurements.
The Kads is the adsorption equilibrium constant, which is -0.85, -0.92 reveals more proficient
5
0
adsorption thus better inhibition efficiency of NCMBPA on the copper surface . The equilibrium
constant for the adsorption - desorption process is concerned to the standard free energy of adsorption
ΔG ads as said by the eq 6:
ꢐ
ꢅꢴꢵꢣꢤꢥ
ꢶꢷ
ꢪꢫꢬꢭ
ꢁ
ꢰꢱꢲꢳ
ꢸ
(6)
ꢮꢮꢯꢮ
that R is gas constant, T is temperature in Kelvin and 55.5 is the molar concentration of water per liter
solution. It is noticeable that the high value of ΔG ads turns to the best adsorption ability of organic
compounds onto the metal surface. The estimated value of ΔG ads for NBPA is -33.7 kJ mol-1 and
for NCMBPA is -32.6 kJ mol-1.
In general, if the values of ΔG ads are below the value of -20 kJ mol-1, they are consistent with
the electrostatic interaction between the charged molecules and the charged metal (physical
-1
adsorption), while those above -40 kJ mol are associated with chemisorption as a result of sharing or
5
1-53
transfer of electrons from organic species to the metal surface to form a metal bond
.
-1
-1
As mentioned in above, the calculated value for ΔGads is -33.7 kJ mol and -32.6 kJ mol
indicating that the adsorption mechanism of NBPA and NCMBPA on copper is the chemisorption
5
4
and physisorption .
1
1

RSC Advances
Page 12 of 36
View Article Online
DOI: 10.1039/C5RA00561B
3
.4. Effect of temperature:
The study on the temperature effect of inhibition efficiency from acid-metal reaction is very
difficult, for the reason that several changes take place on the metal surface, for example quick
5
5
etching desorption of inhibitor and the inhibitor may undergo decomposition .
The effect of the temperature on the corrosion rate was studied in 6.0 M HCl both in the
absence and presence of 0.01 M of the inhibitor. Consequently, the polarization analysis was carried
out at different temperatures from 250C to 65 0C in the absence and presence of 0.01 M inhibitors.
The electrochemical factors were extracted and summarized in Table 4. The results in Table 3 show
that the corrosion (ɳ) increases with increasing temperature in the absence and presence of inhibitor
but the ɳ increases more quickly with temperature in the uninhibited solution. It is for reason that
higher temperature increases the speed of hot-movement of the organic molecules and weakens the
5
6, 57
adsorption ability of inhibitor on the metal surface
The energy of activation for the corrosion process was calculated from the Arrhenius equation
eq 7):
ꢍꢹꢺꢻꢻ ꢁꢼꢽꢾꢿꢳꣀ ꢸꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖꢖ(7)
.
(
ꢔ
ꣁ
ꢂꣂ
where E represents apparent activation energy, R the gas constant, A is the pre-exponential factor.
a
Values of E for copper in 6.0 M HCl in uninhibited and inhibited solution were estimated by linear
a
-1
regression between log (i ) and 1/T. The value of E is higher for inhibited solution (32.18 kJ mol
corr
a
-1
-1
for NBPA, 36.86 kJ mol for NCMBPA) than that for uninhibited solution (28.18 kJ mol ).
The high values of E show that more energy barrier for the corrosion reaction in the presence of
a
the inhibitor is achieved. Therefore the adsorbed inhibitor molecules avoided charging or mass
transferring from the copper surface.
1
2

Page 13 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
*
*
The Thermodynamic parameters like enthalpy (ΔH ) of corrosion process and entropy (ΔS )
were calculated with the transition state eq 8:
ꢂꣂ
ꢴ꣆꣇
ꢅꢴ꣈꣇
ꣃꢂꢖ ꢁꢳ ꢸꢽꢾꢿꢳ ꢸꢽꢾꢿꢳ ꢂꣂ
ꢸ
(8)
꣄
ꣅ
ꢂ
where h is Plank’s constant and N is Avogadro’s number, respectively. A plot of Ln (icorr /T) vs. 1/T
*
*
provides a straight line with slope = -ΔH /T and intercept = Ln (R/Nh) +ΔS /R. The plots of Ln
(icorr/T) vs. 1/T for the corrosion of copper in the presence of different concentrations of inhibitor are
shown in Fig. 6. The calculated values of activation parameters are tabulated in Table 3. The increase
in activation energy (E ) of inhibited solutions compared to the uninhibited shows that inhibitor is
a
physically adsorbed on the corroding metal surface, while each unchanged or lower energy of
58-62
activation in the presence of inhibitor shows chemisorption
. The entropy of activation in the
presence and absence of the inhibitors are large and negative. Great negative values of entropies show
that the activated complex in the speed determining step is connected before disconnection step
indicate that a decrease in disordering happen on available from reactants to the activated complex.
*
-1
The positive signs of the enthalpies (ΔH ), 25.7, 26.3 and 35.2 kJ mol for 6.0 M HCl, NBPA and
NCMBPA reflect the endothermic nature of the copper dissolution process, respectively and mean
that the dissolution of copper is difficult.
3
.5. Quantum chemical calculations
Quantum chemical calculations were performed in order to analyze the effect of molecular
structure and also electronic parameters on present inhibitor performance. The computed quantum
chemical parameters including the energy of highest occupied molecular orbital (EHOMO (ev)), energy
of lowest unoccupied molecular orbital (ELUMO (ev)), HOMO–LUMO energy gap (ΔE(ev)) and dipole
moment (μ (D)) have been presented in Table 5. According to the frontier molecular orbital theory,
1
3

RSC Advances
Page 14 of 36
View Article Online
DOI: 10.1039/C5RA00561B
the formation of a transition state is due to an interaction between the frontier orbitals (HOMO and
6
3
LUMO) of reactants . The HOMO is known as an orbital which could act as an electron donor
because it is the outermost orbital containing electrons, having highest energy level. On the contrary,
6
4
The LUMO is the innermost orbital which can accept electrons through its vacant room . Basically,
EHOMO and ELUMO are directly related to the ionization potential and the electron affinity of an organic
molecule, respectively. The HOMO–LUMO gap, ΔE(ev), is an important stability index so that a
6
5
large ΔE(ev) value implies high stability for the molecule in chemical reactions . Inspection of
Table 5 shows nearly similar value for EHOMO for both compounds while NCMBPA has lower
ELUMO(ev) than NBPA. It may be deduced that both inhibitors have an equal ability to offer electrons
to the unoccupied d-orbital of the copper, however the higher ability of accepting the electron is
expected for NCMBPA in comparison with NBPA. Considering the ΔE(ev) values, the higher
tendency in order to adsorb onto metal surface is measured for NCMBPA, having lower ΔE(ev)
compared to NBPA. In the case of the dipole moment, it seems to be no agreement in the literature
concerning the correlation between the dipole moment and the inhibition effectiveness, as yet. Since
water is a polar solvent, there is a higher tendency for molecules with similar size to adsorb onto the
66
metal surface for those who have a lower dipole moment . In this study, NBPA has a lower dipole
moment and molecular size in comparison with NCMBPA while both inhibitors show good inhibition
efficiency. According to the above discussion, it may be concluded that both inhibitors, considering
their molecular weight and dipole moment, have a tendency to adsorb onto metal surface. For
instance, the higher molecular weight and dipole moment make an affinity for NCMBPA to leave the
solution and get adsorbed onto surface. It should be noted that molecular electronic parameters are
not confident parameters which certainly determines the corrosion inhibition performance because
corrosion inhibition is a complex phenomenon.
1
4

Page 15 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
In order to validate such correlations between calculated quantum parameters (eq 9) of
experimental inhibition efficiencies for the two Schiff bases, the non-linear multiple regressions were
obtained by B3LYP/6-311G method. The results of this calculation are shown in Table 6.
(
꣌꣍꣎ꢇꢔ꣏꣐꣑꣐꣍ꢒꢇꢔ꣒꣓꣑꣐꣍꣔ꢇ꣕)ꢒ꣖
꣉ꢹ꣊꣋ꢖ
ꢀꢁ
ꢇꢈꢉꢉ
(9)
ꢐ꣍(꣌꣍꣎ꢇꢔ꣏꣐꣑꣐꣍ꢒꢇꢔ꣒꣓꣑꣐꣍꣔ꢇ꣕)ꢒ꣖
The calculated efficiencies (E %) from the eq 9 at different concentrations of these compounds show
cal
2
good correlations to experimental efficiencies (E %) with correlation coefficients R = 0.89 for
exp
2
67
NBPA and R = 0.91 for NCMBPA . The plot of the experimental and the calculated inhibition
efficiency (from COSMO method) for NBPA and NCMBPA compounds were presented in Fig.
8
.The similar plots were obtained for the other methods (not shown).
3
.6. SEM analysis
The SEM images of copper specimens exposed to 6.0 M HCl for 3 h with and without 0.01M
NBPA and NCMBPA are given in Fig. 9. It can be obviously observed from Fig. 8b that the surface
morphology was severely corroded in the absence of inhibitors. However, in the presence of
inhibitors, the destruction of copper surfaces is clearly reduced and even the polishing lines can be
observed (Fig. 9c and d). This observation clearly proves that NBPA and NCMBPA can show good
inhibiting ability on copper surface. The inhibitors may form protective films adsorbed on metal
surface, resulting in a decrease in the contact between copper and the corrosive solution.
4
. Conclusion
The studied two N- Benzylidene derivative compounds are professional inhibitors for the
corrosion of copper in 6.0 M hydrochloric acid solutions. Polarization curves show that corrosion
1
5

RSC Advances
Page 16 of 36
View Article Online
DOI: 10.1039/C5RA00561B
potentials shift toward the anodic region at presence of the examined two N- Benzylidene derivative
compounds.
The results of impedance demonstrate that as the additive concentration is increased the
polarization resistance increases. Adsorption of the inhibitor molecules onto the copper surface
follow by the Langmuir isotherm. The activation parameters of corrosion process such as activation
*
*
energy (E ), activation enthalpy (ΔH ) and activation entropy (ΔS ), are calculated from the
a
dependence of corrosion rates on the temperature.
Through the quantum calculation methods used, the B3LYP/6-311G** and COSMO methods shows
that the best correlation for some of the parameters studied and experimental results. The fact that
inhibition efficiencies increase when the ELUMO decrease shows that feedback bonds form between the
Schiff bases and copper surface. Quantum chemical calculations were further applied to explain the
4
5,68
experimental results
.
Acknowledgments
We are grateful to University of Kashan for supporting this work with Grant 256450-12.
Reference
[
1] G. Tansug, T. Tuken, E.S. Giray, G. Fındıkkıran, G. Sıg ırcık, O. Demirkol, M. Erbil,
Corros. Sci. 84 (2014) 21-29.
[
[
[
[
2] M.M. Antonijevic, B.M.B. Petrovic, Electrochem. Sci. 3 (2008) 1–28.
3] M.M. Antonijevic, S.M. Milic, M.B. Petrovic, Corros. Sci. 51 (2009) 1228–1237.
4] S.Sudheer, M.A. Quraishi, Corros. Sci. 70 (2013) 161–169.
5] M. Scendo, Corros. Sci, 47 (2005) 1738–1749.
1
6

Page 17 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
[
[
[
6] E. S.Zocs, Gy.Vastag, A. Shaban, E. Kalman, Corros. Sci, 47 (2005) 893–908.
7] E.M. Sherif, Su-Moon Park, Electrochim. Act , 51 (2006), 4665-4671
8] M. Behpour, S. M. Ghoreishi, M. Khayat Kashani, N. Soltani, mater, Corros.Sci, 53
(
2011) 2489-2501.
9] M. Behpour, S. M. Ghoreishi, N. Soltani, M. Salavati-Niasari, Corros. Sci, 51 (2009)
073-1089.
[
1
[
[
[
10] S. Li, H. Ma, S. Lie, R. Yu, S. Chen, D.Liu, Corros, 54 (1998), 947-953.
11] T. T. Qin, J. Li, H.Q. Luo, M.Li, N.B. Li, Corros.Sci, 53 (2011) 1072-1078.
12] M. Behpour, S. M. Ghoreishi, N.Soltani, M. Salavati-Niasari, Corros.Sci,52.(2010),
4
046-4057.
[
[
13] M.G. Fontana and N. D. Greece, McGraw-Hill, Corros. Eng, New York, (1986).
14] Y. Abboud, A. Abourriche, T. Saffaj, M. Berrada, M. Charrouf, A. Bennamara, N. Al
Himidi, H. Hannache, Mater.Chem. Phy,105( 2007)1-142.
15] M. Lebrini, M. Lagren´ee, H. Vezin, L. Gengembre. F.Bentis, Corros. Sci. 47 (2005)
85.
[
4
[
[
[
[
[
16] I. Dehri, M. Ozcan, Mater, Chem. Phys, 98 (2006) 316.
17] F. Zucchi, G. Trabanelli, M. Fonsati, Corros. Sci, 38 (1996) 2019–2029.
18] M. Finšgar, Corros. Sci, 77 (2013) 350– 359.
19] H.O. Curkovic, E. Stupnisek-Lisac, H. Takenouti, Corros. Sci, 51 (2009) 2342–2348.
20] R. Vera, F. Bastidas, M. Villarroel, A. Oliva, A. Molinari, D. Ramirez, R. del Rio,
Corros. Sci, 50 (2008) 729–736.
[
[
21] F. Zucchi, G. Trabanelli, C. Monticelli, Corros. Sci, 38 (1996) 147–154.
22] K.F. Khaled, Mater, Chem. Phys, 125 (2011) 427–433.
1
7

RSC Advances
Page 18 of 36
View Article Online
DOI: 10.1039/C5RA00561B
[
23] D. Gopi, K.M. Govindaraju, V.C.A. Prakash, D.M.A. Sakila, L. Kavitha, Corros. Sci,
1 (2009) 2259–2265.
5
[
[
[
24] G. Kear, B.D. Barker, F.C. Walsh, Corros. Sci, 46 (2004) 109–135.
25] M. Scendo, Corros. Sci, 50 (2008) 1584–1592.
26] F. Rosalbino, R. Carlini, F. Soggia, G. Zanicchi, G. Scavino, Corros. Sci, 58 (2012)
1
39–144.
[
[
[
27] M.B. Valcarce, M. Vazquez, Corros. Sci, 52 (2010) 1413–1420.
28] A. A. Farag, M.A. Hegazy, Corros. Sci, 74 (2013) 168–177.
29] M. Gopiraman, N. Selvakumaran, D. Kesavan, R. Karvembu, Prog. Org. Coat. 73
(2012) 104–111.
[
[
[
[
30] S.T. Zhang, Z.H. Tao, W.H. Li, B.R. Hou, Appl. Surf. Sci, 255 (2009) 6757–6763.
31] M. Lashgari, M Arshadi, S. Miandari, Electrochim. Acta, 55 (2010) 6058–6063.
32] A.Yuce, G.Kardas, Corros. Sci, 58 (2012) 86– 94.
33] Issaadi, T. Douadi, A. Zouaoui, S. Chafaa, M.A. Khan, G. Bouet, Corros. Sci, 53
(
2011) 1484 1488.
34] M.A. Migahed, Ahmed A. Farag, S.M. Elsaed, R. Kamal, H. Abd El-bary, Chem. Eng.
Commun, 199 (2012) 1335–1356.
[
[
[
[
35] I. Ahamad, R. Prasad, M.A. Quraishi, Mater. Chem. Phys, 124 (2010) 1155–1165.
36] H.A. Mohamed, A.A. Farag, B.M. Badran, J. Appl. Poly. Sci, 117 (2010) 1270–1278.
37] Serpil. Safak, Berrin. Duran, Aysel. Yurt, Gulsen. Turkoglu, Corros. Sci, 54 (2012)
2
51– 259.
[
[
38] A.A. Farag, M.R. Noor El-Din, Corros. Sci, 64 (2012) 174–183.
39] K.C. Emregul, O. Atakol, Mater. Chem. Phys, 83 (2004) 373– 379.
1
8

Page 19 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
[
[
40] I.B. Obot, N.O. Obi-Egbedi, S.A. Umoren, Corros. Sci, 51 (2009) 276–282.
41] H. Naeimi, Z. S. Nazifi. Bull. Chem. Soc. Ethiop, 27 (2013) 143-149.
[
[
42] A. Klamt, G. Schuurmann. J. Chem. Soc. Perkin Trans, 2 (1993) 799-805.
43] W.Deng , P. Lin, Q. Li, G. Mob. Corros.Sci, 74 (2013) 44–49
[
44] S.S. de Assunção Araújo Pereira, M.M. Pegas, T.L. Fernández, M. Magalhães, T.G.
Schöntag, D.C. Lago, L.F. de Senna, E. D’Elia, Corros. Sci, 65 (2012) 360–366.
45] M. Behpour, S.M. Ghroreishi, N. Soltani, M. Salavati-Niasari, M. Hamadanian, A.
Gandomi, Corros. Sci, 50 (2008) 2172–2181.
[
[
[
46] K.F. Khaled, Mater. Chem. Phys, 112 (2008), 104-111.
47] M.Behpour, N.Mohammadi, E.Alian, Journal of Iron and Steel Research
International, 21 (2014) 121-124.
[
48] L. Li, Q. Qu, W. Bai, F.C. Yang, Y.J. Chen, S.W. Zhang, Z.T. Ding, Corros. Sci, 59
(2012) 249–257.
[
[
49] A.Y. Musa, R.T.T. Jalgham, A.B. Mohamad, Corros. Sci, 56 (2012) 176–183.
50] A. Popova, M. Christov, J. Univ. Chem. Technol. Metall, 43 (2008) 37–47.
[
51] A. Yurt, G. Bereket, A. Kivrak, A. Balaban, B. Erk, J. Appl. Electrochem, 35 (2005)
1
025–1032.
[
[
[
[
[
[
[
52] A.M. Fekry, R.R. Mohamed, Electrochim. Acta, 55 (2010) 1933–1939.
53] V.R. Saliyan, A.V. Adhikari, Corros. Sci, 50 (2008) 55–61.
54] L.M. Vracar, D.M. Drazic , Corros. Sci, 44 (2002) 1669–1680.
55] J. Alijourani, K. Raeissi, M.A. Golozar, Corros. Sci, 51 (2009) 1836–1843.
56] D. Daoud, T. Douadi, S. Issaadi, S. Chafaa, Corros Sci, 79 (2014) 50–58.
57] W. Li, X. Zhao, F. Liu, B. Hou, Corros. Sci, 50 (2008) 3261–3266.
58] L. Larabi, O. Benali, Y. Harek, Mater. Lett, 61(2007) 3287-3293.
1
9

RSC Advances
Page 20 of 36
View Article Online
DOI: 10.1039/C5RA00561B
[
[
[
59] A. Popova, E. Sokolova, S. Raicheva, M. Christov, Corros. Sci, 45 (2003) 331-345.
60] T. Szauer, A. Brandt, Electrochim. Acta, 26 (1981) 1209.
61] M. Bouklah, N. Benchat, B. Hammouti, A. Aouniti, S. Kertit, Mater. Lett, 60
(2006)2840-2843.
[
62] E. A. Noor, A.H. Al-Moubaraki, Mater. Chem. Phys, 110 (2008) 145-154.
[
[
[
[
[
63] M. Finsgar, A. Lesar, A. Kokalj, I. Milosev, Electrochim. Acta 53 (2008) 8287–8297.
64] H. Ju, Z. Kai, Li. Y.Corros. Sci. 50 (2008) 865–871.
65] G. Gece.Corros. Sci. 50 (2008) 2981-2992.
66] A. Kokalj. Electrochim. Acta 56 (2010) 745-755.
67] A. Kokalj, S. Peljhan, M. Fins gar, I. Milosev. J. Am. Chem. Soc. 132 (2010) 16657–
1
6668.
[
[
[
68] H. Ashassi-Sorkhabi, B. Shaabani, D. Seifzadeh. Appl. Surf. Sci. 239 (2005) 154.
69] J.Tomasi, B.Mennucci, R.Cammi. Chem. Rev. 105(2005): 2999-3094.
70] M.Nadia Rega, G.Scalmani, V.Barone. J. Comput. Chem. 24(2003): 669-681.
Figure captions
Fig. 1. The chemical structure of the investigated Schiff bases
Fig. 2. The Nyquist plots of copper in hydrochloric acid 6.0 M with the various concentrations
of: (a) NBPA, (b) NCMBPA
Fig. 3. Equivalent circuit model of impedance spectra in (a) Blank, (b) The different
concentration of inhibitors
Fig. 4. Polarization curves for copper in hydrochloric acid 6.0 M solution with the (a) NBPA,
(b) NCMBPA, in different concentrations
Fig. 5. The Langmuir isotherm for adsorption of NBPA and NCMBPA on the copper surface
2
0

Page 21 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
Fig. 6. The plots of Ln (i /T) vs. 1000/T for copper in hydrochloric acid 6.0 M in the absence
corr
and presence of 0.01M of inhibitors
Fig.7. The plots of Ln (i ) vs. 1000/T for copper in hydrochloric acid 6.0 M in the absence and
corr
presence of 0.01M of inhibitors
Fig. 8. The correlation between experimental inhibition efficiency and calculated inhibition
efficiency obtained from COSMO method.
Fig. 9. The SEM images of the copper surface after 3 h immersion period (a) before corrosion,
(b) 6.0 M HCl, (c) 6.0 M HCl + 0.01M NBPA, (d) 6.0 M HCl + 0.01M NCMBPA,
Table captions
Table.1. The results of the impedance spectra for copper in the absence and presence of various
Concentrations of inhibitors in hydrochloric acid 6.0 M at 25 ºC
Table.2. Electrochemical kinetic parameters obtained by Tafel polarization technique for copper
in the absence and presence of various concentrations of inhibitors in hydrochloric acid 6.0 M at
2
5 ºC
Table.3. ΔG , E , ΔH*, ΔS*, of dissolution reaction of copper in hydrochloric acid 6.0 M
ads
a
solution
Table.4. Polarization parameters and corresponding inhibition efficiency for the corrosion of the
copper in hydrochloric acid 6.0 M without and with addition of 0.01 M the inhibitors at
different temperatures
Table.5. Quantum chemical parameters of used Schiff bases obtained from quantum method
Table 6. Coefficients of Eq (9) obtained from quantum chemical parameters for applied
quantum method.
2
1

RSC Advances
Page 22 of 36
View Article Online
DOI: 10.1039/C5RA00561B
Table.1. The results of the impedance spectra for copper in the absence and presence of
various Concentrations of inhibitors in hydrochloric acid 6.0 M at 25 ºC
Inhibitor
Concentration
Rs
(Ω cm )
Rct
(Ω cm )
Y0
(µF cm )
n
η%
2
2
-2
(
M)
Blank
-
3.3±0.041
98.6±0.10
-4
-3
-3
-2
-4
-3
-3
-2
-6
-6
-6
-6
NBPA
5×10
2.2±0.059 603.89±0.59
0.001860±0.6×10
0.001060±0.6×10
0.000974±0.3×10
0.000647±0.7×10
0.49±0.0053 84.0±0.8
0.52±0.0059 86.0±1.2
0.55±0.0059 87.0±0.9
1
5
1
×10
×10
×10
2.3±0.013
2.0±0.019
2.0±0.039
1.3±0.059
1.5±0.059
1.8±0.053
2.1±0.053
687.77±1.5
734.19±2.3
847.44±3.6
580.20±1.5
681.00±2.1
866.90±3.4
1257.8±9.6
0.56±0.0059
88.0±1
-6
NCMBPA
5×10
0.00270±0.6×10
0.00112±0.6×10
0.00110±0.6×10
0.00068±0.7×10
0.48±0.0053 83.0±0.8
0.54±0.0059 86.0±1.1
0.54±0.0059 89.0±0.9
-6
1
5
1
×10
×10
×10
-6
-6
0.55±0.0059
92.0±1
2
2

Page 23 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
Table.2. Electrochemical kinetic parameters obtained by Tafel polarization technique for copper
in the absence and presence of various concentrations of inhibitors in hydrochloric acid 6.0 M at 25
ºC
-
E vs
Ag/Agcl(3 M Cl )
mV)
Concentration
M)
ba
-bc
Icorr
(µA cm
η
-
Inhibitor
-1
-1
-2 )
(
(mV dec ) (mV dec )
%
(
Blank
-
131.2±1
223.3±1
225.6±2
195.1±1
171.0±2
212.4±1
133.5±3
123.1±2
83.4±1
120.4±1
106.5±2
107.4±1
102.3±4
102.4±1
124.9±1
100.0±3
98.7±1
482.1±3
201.9±2
198.4±1
197.7±1
201.7±2
215.6±1
205.6±3
204.2±1
185.2±1
230.1±0.07 -
-
4
NBPA
5×10
47.3±0.04 79.0±0.6
45.4±0.05 80.0±0.2
36.3±0.01 84.0±0.2
32.6±0.06 86.0±0.5
62.4±0.05 73.0±0.1
33.7±0.02 85.0±0.3
28.5±0.02 88.0±0.1
16.8±0.01 93.0±0.9
-3
-3
-2
-4
-3
-3
-2
1
5
1
×10
×10
×10
NCMBPA 5×10
1
5
1
×10
×10
×10
59.8±1
2
3

RSC Advances
Page 24 of 36
View Article Online
DOI: 10.1039/C5RA00561B
Table.3. ΔG , E , ΔH*, ΔS*, of dissolution reaction of copper in hydrochloric acid 6 M
ads
a
solution
Inhibitor
*
*
Kads
ΔGads
(KJ mol )
Ea
ΔH
ads
-1
ΔS
ads
-1 -1
2
R
-
3
-1
-1
(
×10 )
(KJ mol )
(KJ mol )
(J mol k )
Blank
NBPA
-
-
28.18
25.7
-128.7
20
0.99
0.99
-33.7
-32.6
32.18
36.86
26.3
35.2
-119.2
-102.3
NCBMPA
12.5
2
4

Page 25 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
Table.4. Polarization parameters and corresponding inhibition efficiency for the corrosion of the
copper in hydrochloric acid 6 M without and with addition of 0.01 M the inhibitors at different
temperatures
-
E vs
Temperatur
ba
-bc
Ag/Agcl(3
M Cl )
Icorr
(µA cm
Inhibitor
Blank
e
η%
-1
-1
-
-2 )
(
mV dec ) (mV dec )
0
(
C)
(mV)
35
123.1±1
109.6±2
153.9±2
130.9±1
159.8±1
64.90±3
81.00±2
123.9±1
97.90±1
107.3±2
46.60±3
167.5±2
104.7±1
198.5±1
204.8±3
95.80±2
318.0±2
98.30±1
249.4±1
77.00±1
138.1±3
71.90±1
451.0±1
482.8±1
453.5±1
458.5±2
184.8±1
423.0±2
440.2±3
430.2±1
201.4±1
337.9±2
446.3±1
202.2±0.07
213.1±0.07
260.6±0.04
310.0±03
-
4
5
6
5
5
5
-
-
-
NBPA
35
42.60±0.04
64.20±0.01
90.90±0.05
120.8±0.07
31.40±0.03
56.40±0.02
80.70±0.03
79.0±1.2
70.0±1.4
65.0±0.8
61.0±1.6
84.0±1.3
74.0±1.1
69.0±0.5
4
5
6
5
5
5
NCBMPA
35
4
5
5
5
2
5

RSC Advances
Page 26 of 36
View Article Online
DOI: 10.1039/C5RA00561B
Table.5. Quantum chemical parameters of used Schiff bases obtained from quantum method
method
Parameters
Inhibitor
NBPA
NCMBPA
EHomo(ev)
ELumo(ev)
ΔE(ev)
µ(D)
-0.2362
-0.0771
0.1591
3.4076
-0.2343
-0.0819
0.1524
4.5691`
B3LYP /6- 311G**
EHomo(ev)
ELumo(ev)
ΔE(ev)
µ(D)
-0.2362
-0.0771
0.1591
3.4076
-0.2343
-0.0819
0.1524
4.5691
PCM
EHomo(ev)
ELumo(ev)
ΔE(ev)
µ(D)
-0.2398
-0.0811
0.1587
4.0109
-0.2376
-0.0848
0.1528
4.6504
CPCM
2
6

Page 27 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
Table 6. Coefficients of Eq (9) obtained from quantum chemical parameters for applied
quantum methods.
state*
Coefficient
A
B
C
D
ǀ
19851.16
21940.67
27409.14
26902.70
1013032.35
100903.37
730.65
65.54
B3LYP /6-
11G**
3
ǁ
PCM
ǀ
21938.22
22870.07
26891.24
26665.90
100908.27
100850.15
65.58
66.50
CPCM
ǀ
*
In state I, the D coefficient is equal zero
2
7

RSC Advances
Page 28 of 36
View Article Online
DOI: 10.1039/C5RA00561B
N
N
E-N-benzylidenepyridin-2-amine
(
NBPA )
N
H C
N
3
Cl
N-(4-choloromethylbenzylidene) Pyridin – 2 amine
NCMBPA )
Fig. 1. The chemical structure of the investigated Schiff bases.
(
2
8

Page 29 of 36
RSC Advances
View Article Online
DOI: 10.1039/C5RA00561B
3
2
2
1
1
00.00
50.00
00.00
50.00
00.00
a
Blank
0
0
0
0
.0005M
.001M
.005M
.01M
5
0.00
0
.00
0
.00
150.00
300.00
450.00
600.00
750.00
2
Z (ohm cm )
re
3
2
2
1
1
00.00
50.00
00.00
50.00
00.00
b
Blank
.0005M
0
0
0
0
.001M
.005M
.01M
5
0.00
0
.00
0
.00
150.00
300.00
Z (ohm cm )
450.00
600.00
750.00
2
re
Fig. 2. The Nyquist plots of copper in hydrochloric acid 6M with the various concentrations of:
a) NBPA, (b) NCMBPA.
(
2
9
