Enzymatic synthesis of highly fluorescent 8-azapurine ribosides using a purine nucleoside phosphorylase reverse reaction: Variable ribosylation sites

Article abstract of DOI:10.3390/molecules181012587

Various forms of purine-nucleoside phosphorylase (PNP) were used as catalysts of enzymatic ribosylation of selected fluorescent 8-azapurines. It was found that the recombinant calf PNP catalyzes ribosylation of 2,6-diamino-8-azapurine in a phosphate-free medium, with ribose-1-phosphate as ribose donor, but the ribosylation site is predominantly N7 and N8, with the proportion of N8/N7 ribosylated products markedly dependent on the reaction conditions. Both products are fluorescent. Application of the E. coli PNP gave a mixture of N8 and N9-substituted ribosides. Fluorescence of the ribosylated 2,6-diamino-8-azapurine has been briefly characterized. The highest quantum yield, ~0.9, was obtained for N9-β-D-riboside (λ_max 365 nm), while for N8-β-D-riboside, emitting at ~430 nm, the fluorescence quantum yield was found to be close to 0.4. Ribosylation of 8-azaguanine with calf PNP as a catalyst goes exclusively to N9. By contrast, the E. coli PNP ribosylates 8-azaGua predominantly at N9, with minor, but highly fluorescent products ribosylated at N8/N7.

Full text of DOI:10.3390/molecules181012587

Molecules 2013, 18, 12587-12598; doi:10.3390/molecules181012587
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Enzymatic Synthesis of Highly Fluorescent 8-Azapurine
Ribosides Using a Purine Nucleoside Phosphorylase Reverse
Reaction: Variable Ribosylation Sites
1
,
1
2
Alicja Stachelska-Wierzchowska *, Jacek Wierzchowski , Beata Wielgus-Kutrowska
3
and Goran Mikleušević
1
Department of Biophysics, University of Varmia & Masuria, 4 Oczapowskiego St., 10-719 Olsztyn,
Poland; E-Mail: jacek.wie@uwm.edu.pl
2
3
Division of Biophysics, Institute of Experimental Physics, University of Warsaw,
Zwirki i Wigury 93, 02-089 Warsaw, Poland; E-Mail: beata@biogeo.uw.edu.pl
Division of Physical Chemistry, Rudjer Bošković Institute, POB 180, HR-10002 Zagreb, Croatia;
E-Mail: Goran.Mikleusevic@irb.hr
*
Author to whom correspondence should be addressed; E-Mail: alicja.stachelska@uwm.edu.pl;
Tel.: +48-5233406; Fax: +48-5234547.
Received: 30 August 2013; in revised form: 25 September 2013 / Accepted: 30 September 2013 /
Published: 11 October 2013
Abstract: Various forms of purine-nucleoside phosphorylase (PNP) were used as catalysts of
enzymatic ribosylation of selected fluorescent 8-azapurines. It was found that the recombinant
calf PNP catalyzes ribosylation of 2,6-diamino-8-azapurine in a phosphate-free medium, with
ribose-1-phosphate as ribose donor, but the ribosylation site is predominantly N7 and N8, with
the proportion of N8/N7 ribosylated products markedly dependent on the reaction conditions.
Both products are fluorescent. Application of the E. coli PNP gave a mixture of N8 and
N9-substituted ribosides. Fluorescence of the ribosylated 2,6-diamino-8-azapurine has been
briefly characterized. The highest quantum yield, ~0.9, was obtained for N9-β-D-riboside
(λmax 365 nm), while for N8-β-D-riboside, emitting at ~430 nm, the fluorescence quantum yield
was found to be close to 0.4. Ribosylation of 8-azaguanine with calf PNP as a catalyst goes
exclusively to N9. By contrast, the E. coli PNP ribosylates 8-azaGua predominantly at N9,
with minor, but highly fluorescent products ribosylated at N8/N7.
Keywords:
8-azapurines;
nucleosides;
enzymatic
synthesis;
fluorescence;
purine-nucleoside phosphorylase

Molecules 2013, 18
. Introduction
Enzymatic ribosylation of purine analogues has been proposed as an alternative to chemical
12588
1
synthesis of a variety of biologically active nucleosides [1–4]. We have been interested in fluorescent
analogues of natural purine nucleosides and nucleotides, since they have found numerous applications
in enzymology, particularly in mechanistic and dynamic studies (for reviews, see [5–7]). Among these,
8
-azapurine nucleosides are known as fluorescent species, isosteric with natural purine nucleosides,
and may substitute for them in many biochemical processes [8,9]. They are suitable for mechanistic
investigations, including probing of the active sites of purine-related enzymes and ribozymes [10–14],
as well as for analytical purposes [15,16]. In the present work, we examined a possibility of enzymatic
synthesis of ribosides of 2,6-diamino-8-azapurine (Figure 1), a highly fluorescent purine analog [17],
using as catalysts various forms of purine-nucleoside phosphorylase (PNP, for a review see [18]),
particularly trimeric calf PNP and hexameric E. coli PNP, and α-D-ribose-1-phosphate (R1P) as a
ribose donor. Ribosides and deoxyribosides of 2-amino-8-azaadenine have been long ago synthesized
by Montgomery [19] and Seela and Lampe [20], but their fluorescence properties were not described.
The parent purine nucleoside, 2,6-diaminopurine riboside, is known to possess interesting
biochemical properties [21–23] and was recently applied to mechanistic studies of the hairpin
ribozyme [24], which expressed full activity when the crucial guanine residue was replaced by
2,6-diaminopurine (Figure 1). However, 2,6-diaminopurine and its nucleoside are only moderately
fluorescent [21], and therefore are not easily applicable to fluorescent investigations in biological
systems. By contrast, the 2,6-diamino-8-azapurine (2-amino-8-azaadenine) ribosides and related
compounds exhibit very intense fluorescence in neutral aqueous media, as shown below.
Figure 1. Structures of 2,6-diamino-8-azapurine (left) and 2,6-diaminopurine. The
compounds are shown in one of several possible tautomeric forms. Purine numbering is
maintained in both systems for simplicity.
7
1
8
9
3
2
. Results and Discussion
2
.1. Fluorescence of 2,6-diamino-8-azapurine Base and its Alkyl Derivatives
In contrast to the parent, weakly fluorescent 2,6-diaminopurine, its 8-aza analogue
(
2,6-diamino-8-azapurine, DaaPur), exhibits strong fluorescence in neutral aqueous medium, with a
maximum at 365 nm and 40% yield, described in details in our previous paper [17]. This fluorescence
was ascribed to the N(9)H protomer, on the basis of comparison with the emission properties of
N9-alkoxyphosphono-derivative of DaaPur (see Figure 1). Other N-alkyl derivatives, N8-methyl and
N7-methyl-DaaPur, are characterized by red-shifted UV absorption [25], and N8-methyl-DaaPur

Molecules 2013, 18
12589
additionally exhibits intense fluorescence centered at 410 nm (Figure 2). On the basis of the foregoing
observations, we expected that ribosides of DaaPur may exhibit favorable emission properties, useful
for analytical and structural studies.
Figure 2. Absorption (left, solid lines) and emission (right, points) spectra of the neutral
forms of DaaPur (green), N9-propoxyphosphono-DaaPur (blue) and N8-methyl-DaaPur
(
red) in aqueous medium, pH 6–7 (Data from [17]). Fluorescence spectra were normalized
to the lowest-energy UV absorption bands and multiplied by the respective quantum yields.
10000
9000
8000
7000
6000
5000
4000
3000
2000
1000
0
220
260
300
340
380
420
460
500
540
wavelength [nm]
2
.2. Enzymatic Ribosylation of DaaPur Using Various Forms of PNP as a Catalyst
Although 2,6-diaminopurine, like adenine, is not a substrate for the mammalian forms of PNP in the
reverse (synthetic) pathway [18], its 8-aza analog, DaaPur, has been found to be a modest substrate for
both calf and E. coli PNP’s (wild types), with either ribose-1-phosphate or N7-methylguanosine as
ribose donors. Reaction progress can be followed using UV and/or fluorescence spectroscopy, as
shown in Figure 3 for the reaction between ribose-1-phosphate and DaaPur. The reaction rate for the
calf enzyme at pH 6.6 is about 5% that of the 8-azaGua and ~0.4% of Gua ribosylation (see Table 1).
For the E. coli PNP, ribosylation of DaaPur runs at ~2% of the ribosylation of guanine.

Molecules 2013, 18
12590
Figure 3. Fluorescence changes during the enzymatic ribosylation of DaaPur (~10 µM)
with ribose-1-phosphate (0.25–0.5 mM), using recombinant E. coli (left) and calf spleen
right) purine-nucleoside phosphorylase as catalysts. Reactions were carried out in 25 mM
(
HEPES, pH 6.6, at 25 °C, for ~1.5 h. Spectra were measured every 5 min for 30 min and
every 20 min afterwards. Excitation wavelength was at 310 nm.
450
400
350
300
250
200
150
100
3
00
A
250
B
2
1
1
00
50
00
5
0
0
50
0
300
350
400
450
500
550
3
00
350
400
450
500
550
wavelength [nm]
wavelength [nm]
Table 1. Kinetic parameters for the enzymatic ribosylation of purine analogues with
various form of PNP as catalysts, and α-D-ribose-1-phosphate as a co-substrate. Data refer
to pH 6.5.
a
Compound
Relative kcat
K
m
[µM]
54
Enzyme source
calf spleen
E. coli
2
,6-diamino-8-azapurine
~0.4%
2
%
65
b
2
,6-diaminopurine
<0.1%
-
calf spleen
E. coli
c
>
120%
21%
~7
c
8
-azaguanine
100
calf spleen
E. coli
~
4 U/mg
>200
a
b
c
relative to those determined for guanine (=100%); data from [15], at pH 7; relative to the parameters
determined for N7-methylguanosine phosphorolysis at pH 6.5 (=100).
It is evident from the spectra recorded during the reaction course that in both cases the ribosylation
product(s) involve species absorbing at ~310 nm and strongly emitting near 430 nm, thus markedly
differing from the substrate. These products must be distinct from the typical N9-riboside, and spectrally
resembling the N8-alkyl derivative of DaaPur (cf. Figures 2 and 3). At the endpoint of the reaction
catalyzed by calf PNP (Figure 2B) the short-wavelength band at 365 nm virtually disappears, suggesting
that little or no N9-riboside is produced. Occasionally, a lack of the isoemissive point was observed
(see Figure 2), indicating existence of more than one product, likely N8- and N7-ribosides, confirmed by
the HPLC analysis (see below). In the case of the E. coli PNP, the reaction mixture contained a marked
component of the N9-riboside as well, emitting at ~365 nm, further documented below.
We have separated the ribosylation products using HPLC, with C-8 column (Kromasil) in the
reverse-phase mode, with diode array absorption detector (see Experimental section for details). The
elution profiles, given in Figure 4, confirm that the ribosylation of DaaPur with calf PNP as a catalyst
gives two main products, with UV absorption spectra extending much >300 nm.

Molecules 2013, 18
12591
Figure 4. Elution profiles for the HPLC analysis of the enzymatic ribosylation of DaaPur,
catalyzed by: (a) E. coli PNP; (b) calf spleen PNP, 4 h reaction in the absence of
phosphate; (c) calf spleen PNP, 8 h reaction in the presence of 0.5 mM phosphate.
Detection was at 280 nm (solid line) and 315 nm (broken line). Peak near 10 min retention
time is the substrate.
Table 2. Ionization constants (pK values) and spectral parameters for 2,6-diamino-8-
a
azapurine, its ribosides and selected derivatives. The UV and fluorescence spectral data for
DaaPur and derivatives are from [8,17,19,20,25], additionally checked in the present work.
b
Form
UV absorption
Fluorescence
Compound
pK
a
a
−1
−1
(
pH)
λ
max [nm]
ε
max [M cm ]
8500
λ
max [nm]
ϕ
2,6-diamino-8-azapurine 3.68; 7.68
n (6)
280
363
370
410
367
0.40
0.36
0.27
0.80
ma (10)
cat (2.5)
n (7)
290
6400
253
9500
c
N9-phoshonomethoxy-
3.4
4.85
4.3
284
nd
propyl(PMP)-
N8-methyl-
n (7)
cat (2.5)
n (7)
307
284
309
282
286
313
314
8100
12000
6200
412
410
nd
0.85
~0.4
nd
N7-methyl-
cat (2)
n (7)
7900
nd
nd
N9-β-D-ribofuranosyl-
N8-β-D-ribofuranosyl-
N7-β-D-ribofuranosyl-
~3.2
4.9
10000
8200
367
430
420
~0.9
0.41
0.06
n (7)
4.1
n (7)
~5500
a
b
n—neutral form; cat—cation; ma—monoanion; molar absorptivities for the ribosides has been determined relative to
c
that of DaaPur, following enzymatic phosphorolysis; nd—not determined.
Both products are fluorescent, with emission maxima at 420–430 nm (see Table 2). The products,
a
differing by the protonation constants (pK ), were identified as N8- and N7-ribosides by comparing
spectral data with those published in refs [19,20], and with data reported for the alkyl derivatives of
DaaPur [17].

Molecules 2013, 18
12592
By contrast, using E. coli PNP as catalyst leads to production of two well separated and spectrally
distinct products (Figure 3), one of which was identified as N8-riboside, identical to that produced by
the calf PNP, and the second as N9-riboside, which was also highly fluorescent, but with maximum
close to 367 nm, very similar to the N9-alkylated DaaPur (Table 2).
It is interesting that the relative proportion of the products in both cases depends markedly on the
reaction conditions, and particularly on the presence of free inorganic phosphate. When no phosphate
was present initially, the main products were N7-riboside and N8-riboside for the reaction catalyzed by
the calf and E. coli PNP, respectively. But when the reaction was started in the presence 0.5 mM
phosphate, or if the reaction was allowed to proceed for 24 h, the apparent trans-ribosylation occurred,
resulting in much higher proportion of the N8-riboside in the case of calf PNP catalysis (see Figure 4),
and of N9-riboside in the reaction catalyzed by the E. coli enzyme (data not shown). This phenomenon
is of interest not only from the mechanistic point of view, but also as a tool of selective synthesis of
ribosides of DaaPur.
2
.3. Spectral and Biochemical Properties of the Ribosylation Products
Spectral parameters of the purified ribosides, compared to those of DaaPur and its alkyl derivatives
are summarized in Table 2. It is evident that N9-β-D-ribofuranosyl-DaaPur and N8-β-D-ribofuranosyl-
DaaPur are the most intensely fluorescent nucleosides, comparable to 2-aminopurine riboside
6
(
ϕ ~ 0.6 [21]), and 1,N -ethenoadenosine (ϕ = 0.55 [26]). Since the N9-riboside is isosteric with
natural purine nucleosides, it is particularly suitable for biophysical applications. It is also interesting that
in acidic media both N8- and N7-riboside reveal fluorescence spectra characteristic for the neutral forms
(data not shown), which is due to rapid deprotonation of the excited cations (to be reported elsewhere).
We have also examined substrate properties of the DaaPur ribosides towards PNP in the presence of
inorganic phosphate (phosphorolytic pathway). The N9-β-D-ribofuranosyl of DaaPur is not a substrate
for the calf enzyme, similarly to the analogous riboside of 2,6-diaminopurine [18]. Only traces
of activity were recorded for N8-β-D-ribofuranosyl-DaaPur. By contrast, the N7-isomer was
m
phosphorolysed with the rate constant (kcat/K ) ca. 2% that of N7-methyguanosine phosphorolysis. All
three ribosides were phosphorolysed by the E. coli enzyme, and the greatest rate constant was recorded
for the N8-riboside [16]. The fluorogenic effect observed during the phosphorolysis of N7- and
N8-ribosides may be analytically useful, as reported elsewhere [16].
2.4. Comparison with Enzymatic Ribosylation of 8-azaguanine and Other 8-azapurines
As previously reported [9], 8-azagauanine (8-azaGua) is effectively ribosylated using calf PNP in
phosphate-free media, at pH ≤ 8, with either R1P or N7-methylguanosine as ribose donors. The
E. coli PNP is a less effective catalyst, with k only of ~1% that for guanosine synthesis, while for the
cat
calf PNP this value is increased to ~20%. Until now, we have assumed, mainly on the basis of
UV absorption spectral changes, that in both cases the only ribosylation product is 8-azaguanosine
(N9-β-D-8-azaguanine riboside). The unexpected findings obtained for DaaPur ribosylation prompted
us to re-examine the ribosylation of 8-azaGua, using fluorescence spectroscopy and HPLC, with
results shown on Figure 5. The reaction was carried out at pH 7.3, which was not optimal from the

Molecules 2013, 18
12593
kinetic point of view [9], but allowed sensitive detection of the product(s) when excitation wavelength
is set at 300 nm.
Figure 5. Fluorescence changes recorded during the enzymatic ribosylation of 8-azaGua
(
(
~10 µM) catalyzed by the recombinant purine nucleoside phosphorylase from calf
left panel) or E. coli (right panel) PNP, with ribose-1-phosphate as a ribose donor.
Reactions were carried out in 20 mM HEPES, pH 7.3 at 25 °C. Excitation was at 300 nm.
1
1
1
40
120
20
00
1
00
B
A
8
6
4
2
0
0
0
0
0
80
60
40
20
0
300
350
400
450
500
550
300
350
400
450
500
550
Wavelength [nm]
Wavelength [nm]
Initially, the substrate (8-azaGua) is mostly in the anionic form (pK 6.5), which is weakly
a
fluorescent in these conditions and the observed fluorescence band with λmax 395 nm is due mostly to
the small fraction of the neutral form present [9]. During the reaction course (Figure 5), a new band
with a maximum at 360 nm appears, ascribed to the strongly fluorescent anionic form of the
a
N9-β-D-riboside (pK 8.0). With the reaction catalyzed by calf PNP, this is the only fluorescent
product formed, since at the reaction endpoint the fluorescence spectrum of the final mixture is
independent of excitation wavelength (data not shown). By contrast, when the E. coli PNP was applied
as catalyst, the appearance of the second, minor fluorescent product was evident, since the resultant
fluorescence was red-shifted (Figure 5B) and excitation-dependent, with emission maximum shifting
to ~415 nm with excitation at 315 nm (data not shown). The long-wavelength fluorescence is most
likely due to N8- and/or N7-ribosides.
The foregoing observations were confirmed by HPLC analysis (data not shown). The reaction
catalyzed by E. coli PNP gave clearly two nucleoside products, with spectral properties corresponding
to N9- (major product, λmax = 256 nm) and N8-riboside (minor, highly fluorescent product). The
proportion of two products was nearly 20:1. For the reaction catalyzed by the calf PNP, the minor peak
was absent.
The ribosylation site ambiguity described here for DaaPur has also been observed for 8-azaadenine
and 8-azaisoguanine, when these were ribosylated using E. coli PNP (unpublished data), as well as for
8
-azaxanthine, when ribosylated in similar conditions using xanthosine phosphorylase from E. coli as a
catalyst [27]. It should be recalled, at this point, that the non-typical N7-β-D- and N3-β-D-ribosides of
natural purine bases are moderate to good substrates for both mammalian and bacterial enzymes in the
phosphorolytic pathway [28,29], so the presence of these ribosides in the reverse reaction is not as
surprising, as is perhaps their absence in the reactions catalyzed by the mammalian enzymes.

Molecules 2013, 18
12594
The absence of N9-riboside product during the ribosylation of DaaPur with the calf PNP is
understandable in view of the general properties of mammalian PNP’s, which for the effective
catalysis require interaction between purine N(1)-H, which is absent in DaaPur, and the essential
glutamate residue of the enzyme (Glu-201 in the calf PNP) [18]. This interaction is not necessary for
the E. coli PNP, as well in some mutants of the calf enzyme. It is difficult to explain the mechanism of
the ribosylation at N7, not observed for the parent 2,6-diaminopurine. One possibility is binding of the
8
-azapurine substrate turned by 180 degrees around the long axis, with amine group interacting with
Glu201 and N9 replacing N7 in interaction with Asn243 (cf. ref. [18]).
The slow trans-ribosylation of DaaPur ribosides from N7 to N8 position, and from N8 to N9,
observed for the reactions catalyzed by the calf and E. coli PNP, respectively, is important for
synthetic applications, allowing selective synthesis of the required ribosides. Its mechanism is not
clear, and probably different than that used by Mikhailopulo et al. [30] for synthesis of nucleoside
analogs. It apparently requires the presence of both ribose-1-phosphate and free inorganic phosphate,
and the latter does not inhibit the reaction up to concentrations of ca. 0.5 mM. The key question,
whether this process involves repeated ribosylation-phosphorolysis cycle or perhaps some other
activity, will be addressed in a separate paper.
3
. Experimental
3
.1. General
Recombinant E. coli and calf spleen PNP were obtained and purified as described elsewhere [31,32].
2
,6-Diamino-8-azapurine sulfate, N7-methylguanosine and 8-azaguanine were from Sigma-Aldrich
(
St. Louis, MO, USA.), the latter was re-crystallized as a monosodium salt. N7-methylguanosine was
used without further purification. α-D-Ribose-1-phosphate was prepared enzymatically from
N7-methylguanosine and inorganic phosphate, and assayed by previously described fluorimetric
method [15]. The recombinant calf PNP was used as a catalyst, and the second reaction product,
N7-methylguanine, was removed in nearly 97% by crystallization. All buffers were of analytical grade.
Fluorescence was measured on a Varian Eclipse instrument (Varian Corp., Palo Alto, CA, USA), using
4
-mm pathlength semi-micro cuvettes. Fluorescence quantum yields were determined either relative to
tryptophan in water (ϕ = 0.15, [33]), or, in the case of the nucleosides, relative to DaaPur in water
ϕ = 0.40, [17]). The yields were determined with excitation at 280 nm, and are accurate to ±15%.
(
3
.2. Enzymatic Reactions and Separation of the Products
Ribosylation of 2,6-diamino-8-azapurine and 8-azaguanine was carried out on a semi-micro scale,
according to the following procedures:
(
1) 5 mM DaaPur, diluted from the ammonium salt solution, in 25 mM HEPES, pH 6.6, reacted
with ~7 mM ribose-1-phosphate in 1 mL volume, at 35 °C, for 3 h. Recombinant calf PNP
(
4 µL of 12.7 mg/mL solution) was used as a catalyst. Reaction progress was monitored
fluorimetrically. After 3 h the reaction was stopped by boiling in a microwave oven for ~20 s
and the resultant mixture was analyzed by HPLC (see Figure 4). The overall yields of N7-β-D-
and N8-β-D-riboside were ca. 25% and 7%, respectively.

Molecules 2013, 18
12595
(
(
2) To the same starting solution 0.5 mM inorganic phosphate was added. The reaction was
allowed to run for 8 h at 32 °C. Analysis of the products (Figure 4) shown ca. 40% yield of the
N8-β-D-riboside, with ~10% yield of the N7-β-D-riboside.
3) Reaction was conducted for ~5 h under the conditions as indicated in (1) above, except that
E. coli PNP was used as a catalyst. The resultant mixture contained N8-β-D-riboside
(
~30%, retention time ~17.5 min) and N9-β-D-riboside (~10%, 29–33 min).
Products were separated by reversed-phase HPLC (RP-HPLC) on a UFLC system from Shimadzu
Kyoto, Japan) equipped with UV (diode-array) detection at 280 nm and 315 nm. The column used
(
was a Kromasil reversed-phase analytical C8 column (250 × 4.6 mm, 5-μm particle size). The eluent
was deionized water (solvent A) and 80% methanol in water (solvent B). The solvent program was:
0
5
–10 min, 100% solvent A (isocratic); 10–50 min, a linear gradient from 0 to 30% solvent B;
0–60 min, a linear gradient to 100% solvent B; 60–70 min, 100% solvent B.
4
. Conclusions
We have shown that 2,6-diamino-8-azapurine undergoes enzymatic ribosylation by PNP in
phosphate-free media, and the reaction products, N9-, N8- and N7-β-D-ribofuranosides, exhibit high
fluorescence yields, which makes them applicable in analytical and mechanistic enzymology. With
regards to fluorescence, the N8-riboside in particular seems to be an excellent indicator of the E. coli
PNP in biological samples, while the N7-riboside is almost specific for the mammalian enzyme [16].
The assays based on these compounds may be important in view of the recent application of E. coli
PNP in cancer gene therapy in the so-called suicidal gene strategy [34].
Various types of PNP may be used to selectively ribosylate the nucleobase analog in the desired
location, and, as shown in the present paper, ribosylation sites are additionally dependent on the reaction
conditions. Although the catalysis rates in this case are rather slow, we can expect that the application of
various mutated forms of PNP, obtained via the site-directed mutagenesis [31,35], or enzymes from
different sources [18,36] may lead to more efficient and more selective synthetic methods.
Acknowledgments
This work was supported by University of Varmia & Masuria in Olsztyn, the Ministry of Science,
Education and Sports of the Republic of Croatia, grant No. 098-1191344-2943, and Polish Ministry of
Science and Higher Education grant NN301 044939. The authors thank Agnieszka Bzowska for
helpful discussions.
Conflicts of Interest
The authors declare no conflict of interest.
References
1
.
Krenitsky, T.A.; Koszalka, G.W.; Tuttle, J.V. Purine nucleoside synthesis: An efficient method
employing nucleoside phosphorylases. Biochemistry 1981, 20, 3615–3621.

Molecules 2013, 18
12596
2.
3.
4.
Mikhailopulo, I.A. Biotechnology of nucleic acid constituents—State of the art and perspectives.
Curr. Org. Chem. 2007, 11, 317–335.
Mikhailopulo, I.A.; Miroshnikov, A.I. Biologically important nucleosides: Modern trends in
biotechnology and application. Mendeleev Commun. 2011, 21, 57–68.
Stepchenko, V.A.; Seela, F.; Esipov, R.S.; Miroshnikov, A.I.; Sokolov, Y.A.; Mikhailopulo, I.A.
Enzymatic synthesis of 2-deoxy-β-d-ribonucleosides of 8-azapurines and 8-aza-7-deazapurines.
Synlett 2012, 23, 1541–1545.
5
6
7
.
.
.
Jameson, D.M.; Eccleston, J.F. Fluorescent nucleotide analogs: Synthesis and applications.
Methods Enzymol. 1997, 278, 363–390.
Sinkeldam, R.W.; Greco, N.J.; Tor, Y. Fluorescent analogs of biomolecular building blocks:
Design, properties, and applications. Chem. Rev. 2010, 110, 2579–2619.
Tanpure, A.A.; Pawar, M.G.; Srivatsan, S.G. Fluorescent nucleoside analogs: Probes for
investigating nucleic acid structure and function. Israel J. Chem. 2013, 53, 366–378.
Albert, A. Chemistry of 8-azapurines. Adv. Heterocycl. Chem. 1986, 39, 117–178.
Wierzchowski, J.; Wielgus-Kutrowska, B.; Shugar, D. Fluorescence emission properties of
8
.
.
9
8
-azapurines and their nucleosides, and application to the kinetics of the reverse synthetic reaction
of PNP. Biochim. Biophys. Acta 1996, 1290, 9–17.
1
0. Wierzchowski, J.; Bzowska, A.; Stępniak, K.; Shugar, D. Interactions of calf spleen purine
nucleoside phosphorylase with 8-azaguanine, and a bisubstrate analogue inhibitor: Implications
for the reaction mechanism. Z. Naturforschung 2004, 59c, 713–725.
1
1
1
1
1. Da Costa, C.P.; Fedor, M.J.; Scott, L.G. 8-Azaguanine reporter of purine ionization states in
structured RNAs. J. Am. Chem. Soc. 2007, 129, 3426–3432.
2. Liu, L.; Cottrell, J.W.; Scott, L.G.; Fedor, M.J. Direct measurement of the ionization state of an
essential guanine in the hairpin ribozyme. Nat. Chem. Biol. 2009, 5, 351–357.
3. Cottrell, J.W.; Scott, L.G.; Fedor, M.J. The pH dependence of hairpin ribozyme catalysis reflects
ionization of an active site adenine. J. Biol. Chem. 2011, 286, 17658–17664.
4. Seela, F.; Jiang, D.; Budow, S. Triplexes with 8-aza-2′-deoxyisoguanosine replacing protonated
dC: Probing third strand stability with a fluorescent nucleobase targeting duplex DNA.
ChemBioChem 2010, 11, 1443–1450.
1
1
1
5. Wierzchowski, J.; Ogiela, M.; Iwańska, B.; Shugar, D. Selective fluorescent and fluorogenic
substrates for purine-nucleoside phosphorylases from various sources, and direct fluorimetric
determination of enzyme levels in human and animal blood. Anal. Chim. Acta 2002, 472, 63–74.
6. Wierzchowski, J.; Stachelska-Wierzchowska, A. Two fluorogenic substrates for purine-nucleoside
phosphorylase, selective for mammalian and bacterial forms of the enzyme. Anal. Biochem. 2013,
submitted.
7. Wierzchowski, J.; Mędza, G.; Szabelski, M.; Stachelska-Wierzchowska, A. Properties of
2,6-diamino-8-azapurine, a highly fluorescent purine analog and its N-alkyl derivatives:
Tautomerism and excited-state proton transfer reactions. Photochem. Photobiol. A 2013, 265, 49–57.
8. Bzowska, A.; Kulikowska, E.; Shugar, D. Purine nucleoside phosphorylases: Properties, functions,
and clinical aspects. Pharmacol. Therapeutics 2000, 88, 349–425.
1
1
9. Montgomery, J.A.; Shortnacy, A.T.; Secrist, J.A., III. Synthesis and biological evaluation of
2
-fluoro-8-azaadenosine and related compounds. J. Med. Chem. 1983, 26, 1483–1489.

Molecules 2013, 18
12597
2
2
0. Seela, F.; Lampe, S. 8-Aza-2′-deoxyguanosine and related 1,2,3-triazolo[4,5-d]pyrimidine
′-deoxyribofuranosides. Helv. Chim. Acta 1993, 72, 2388–2397.
2
1. Ward, D.C.; Reich, E.; Stryer, L. Fluorescence studies of nucleotides and polynucleotides. I.
Formycin, 2-aminopurine riboside, 2,6-diaminopurine riboside, and their derivatives. J. Biol.
Chem. 1969, 244, 1228–1237.
2
2
2
2. Ottink, O.M.; Nelissen, F.H.T; Derks, Y.; Wijmenga, S.S.; Heus, H.A. Enzymatic stereospecific
preparation of fluorescent S-adenosyl-L-methionine analogs. Anal. Biochem. 2010, 396, 280–283.
3. Olsen, A.G.; Dahl, O.; Petersen, A.B.; Nielsen, J.N.; Nielsen, P.E. A novel pseudo-complementary
PNA G-C base pair. Artif. DNA: PNA XNA 2011, 2, 33–37.
4. Kath-Schorr, S.; Wilson, T.J.; Li, N.-S.; Lu, J.; Piccirilli, J.A.; Lilley, D.M.J. General
acid-base catalysis mediated by nucleobases in the hairpin ribozyme. J. Am. Chem. Soc. 2012, 134,
1
6717–16724.
5. Albert, A.; Taguchi, H. V-triazolo(4,5-d)pyrimidines (8-azapurines). 8. Synthesis, from
,2,3-triazoles, of 1- and 2-methyl derivatives of 5,7-disubstituted V-triazolo(4,5-d)pyrimidines
7- and 8-methyl 2,6-disubstituted 8-azapurines). J. Chem. Soc. Perkin Trans. I 1972, 4, 449–456.
2
1
(
2
6. Leonard, N.J. Etheno-substituted nucleotides and coenzymes: Fluorescence and biological activity.
CRC Crit. Rev. Biochem. 1984, 15, 125–199.
2
7. Kierdaszuk, B.; Wierzchowski, J. 8-Azapurines as substrates for the E. coli purine nucleoside
phosphorylase—II (xanthosine phosphorylase): Does the ribosylation always go to the aza-purine
N(9)? Collect. Symp. Series 2005, 7, 489–491.
2
8. Bzowska, A.; Ananiev, A.V.; Ramzaeva, N.; Alksnis, E.; Maurins, J.A.; Kulikowska, E.;
Shugar, D. Purine nucleoside phosphorylase: Inhibition by purine N(7)- and
N(9)-acyclonucleosides; and substrate properties of 7-β-D-ribofuranosylguanine and
7
-β-D-ribofuranosylhypoxanthine. Biochem. Pharmacol. 1994, 48, 937–947.
9. Bzowska, A.; Kulikowska, E.; Poopeiko, N.E.; Shugar, D. Kinetics of phosphorolysis of
-(β-D-ribofuranosyl)adenine and 3-(β-D-ribofuranosyl)hypoxanthine, non-conventional substrates
2
3
3
3
3
of purinenucleoside phosphorylase. Eur. J. Biochem. 1996, 239, 229–234.
0. Roivainen, J.; Elizarova, T.; Lapinjoki, S.; Mikhailopulo, I.A.; Esipov, R.S.; Miroshnikov, A.I.
An enzymatic transglycosylation of purine bases. Nucleosides, Nucleotides Nucleic Acids 2007,
2
6, 905–909.
1. Mikleušević, G.; Štefanić, Z.; Narczyk, M.; Wielgus-Kutrowska, B.; Bzowska, A.; Luić, M.
Validation of the catalytic mechanism of Escherichia coli purine nucleoside phosphorylase by
structural and kinetic studies. Biochimie 2011, 93, 1610–1622.
2. Wielgus-Kutrowska, B.; Breer, K.; Hashimoto, M.; Hikishima, S.; Yokomatsu, T.; Narczyk, M.;
Dyzma, A.; Girstun, A.; Staroń, K.; Bzowska, A. Trimeric purine nucleoside phosphorylase:
Exploring postulated one-third-of-the-sites binding in the transition state. Bioorg. Med. Chem.
2
012, 20, 6758–6769.
3
3. Suzuki, K.; Kobayashi, A.; Kaneko, S.; Takehira, K.; Yoshihara, T.; Ishida, H.; Shiina, Y.;
Oishi, S.; Tobita, S. Reevaluation of absolute luminescence quantum yields of standard solutions
using a spectrometer with an integrating sphere and a back-thinned CCD detector. Phys. Chem.
Chem. Phys. 2009, 11, 9850–9860.

Molecules 2013, 18
12598
3
4. Portsmouth, D.; Hlavaty, J.; Renner, M. Suicide genes for cancer therapy. Mol. Aspects Med.
007, 28, 4–41.
2
3
5. Štefanić, Z.; Mikleušević, G.; Narczyk, M.; Wielgus-Kutrowska, B.; Bzowska, A.; Luić, M. Still
a long way to fully understanding the molecular mechanism of Escherichia coli Purine
Nucleoside Phosphorylase. Croat. Chem. Acta 2013, 86, 117–127.
3
6. Zhou, X.; Szeker, K.; Janocha, B.; Böhme, T.; Albrecht, D.; Mikhailopulo, I.A.; Neubauer, P.
Recombinant purine nucleoside phosphorylases from thermophiles: Preparation, properties and
activity towards purine and pyrimidine nucleosides. FEBS J. 2013, 280, 1475–1490.
Sample Availability: Samples of the compounds are available from the authors.
©
2013 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
http://creativecommons.org/licenses/by/3.0/).
(
