transistors modified with TFMBT thiol (0.086 cm2V-1s-1). The
increased OFET performance should be attributed to the
decreased contact resistance induced by: a) the increased grain
size at the IPr-Au/pentacene interface; and b) the enhanced
charge injection as a result of the IPr-assembling on the Au
surface. In summary, we have demonstrated that IPr is an
exceptionally valuable alternative to thiols as a modifier on the
Au surface in the application of OFET devices.
Table 2. The charge carrier mobilites () and calculated work functions for
gold surfaces modified with three NHCs.[7e]
Work Function
NHCs
Au
Chemical Structure
/cm2V-1s-1
/eV
---
5.17
3.0E-2
N
N
Acknowledgements
IPr
4.13
1.5E-1
We thank Sebastian Lamping for analytical support. This work
was supported by the Germany–China Joint Project TRR61
(DFG–NSFC
Transregio
Project),
the
Deutsche
Forschungsgemeinschaft (SFB 858 and Leibniz Award), the
National Natural Science Foundation of China (91227201,
21527805, 21661132006),the Program for Professor of Special
Appointment (Eastern Scholar) at Shanghai Institutions of
Higher Learning. Generous financial support by the Alexander
von Humboldt Foundation (K.M.C.) is gratefully acknowledged.
iPr2bimy
3.90
7.8E-2
N
N
N
N
IiPr
3.84
5.0
4.5E-2
---
Keywords: carbene • surface modification • OFETs • contact
resistance • Au electrodes
[1]
a) F. von Wrochem, D. Gao, F. Scholz, H.-G. Nothofer, G. Nelles and J.
M. Wessels, Nat. Nano. 2010, 5, 618-624; b) Y. Zhou, C. Fuentes-
Hernandez, J. Shim, J. Meyer, A. J. Giordano, H. Li, P. Winget, T.
Papadopoulos, H. Cheun, J. Kim, M. Fenoll, A. Dindar, W. Haske, E.
Najafabadi, T. M. Khan, H. Sojoudi, S. Barlow, S. Graham, J.-L. Brédas,
S. R. Marder, A. Kahn and B. Kippelen, Science, 2012, 336, 327-332;
c) L. J. Wang, G. J. Liu, H. B. Wang, D. Song, B. Yu and D. H. Yan,
Appl. Phys. Lett. 2007, 91, 153508; d) X. J. Yan, J. Wang, H. B. Wang,
H. Wang and D. H. Yan, Appl. Phys. Lett. 2006, 89, 053510; e) R. W.
Zehner, B. F. Parsons, R. P. Hsung and L. R. Sita, Langmuir, 1999, 15,
1121-1127.
Pentacene
---
Furthermore, we investigated the characteristics of pentacene
transistors with Au electrodes modified by the NHCs iPr2bipy
and IiPr (Table 2). Compared to IPr, these two NHCs showed
larger grain size of pentacene films at the interfaces (Figure
S5d& S5e) but much lower mobilities. Hence the morphological
characteristics at the interface could not explain the OFET
performance of pentacene transistors. DFT calculations indicate
that NHCs can reduce the work function of Au surfaces while IPr
leads to slightly smaller reduction of the work function compared
to iPr2bipy and IiPr.[7e] We attribute this effect to the additional
coordination of the aromatic substituents to the Au surface.
Among the three NHCs tested, the work function of the Au
[2]
[3]
[4]
N. K. Kim, D. Khim, Y. Xu, S. H. Lee, M. Kang, J. Kim, A. Facchetti, Y.
Y. Noh and D. Y. Kim, ACS Appl. Mater. Interfaces, 2014, 6, 9614-9621.
X. S. Chen, S. N. Zhang, K. J. Wu, Z. Y. Xu, H. W. Li, Y. C. Meng, X. M.
Ma, L. W. Liu and L. Q. Li, Adv. Electron. Mater. 2016, 2, 1500409.
a) J. J. Gooding and S. Ciampi, Chem. Soc. Rev. 2011, 40, 2704-2718;
b) J. B. Schlenoff, M. Li and H. Ly, J. Am. Chem. Soc. 1995, 117,
12528-12536; c) C. Vericat, M. E. Vela, G. Benitez, P. Carro and R. C.
Salvarezza, Chem. Soc. Rev. 2010, 39, 1805-1834; d) R. G. Nuzzo and
D. L. Allara, J. Am. Chem. Soc. 1983, 105, 4481-4483; e) P.
Chinwangso, A. C. Jamison and T. R. Lee, Acc. Chem. Res. 2011, 44,
511-519.
surface modified with IPr shows the smallest difference to the
HOMO of pentacene (-5.0 eV).[15,
Therefore, compared to
18]
pure Au electrodes, the charge injection was greatly enhanced,
indicated by the maximal current increase from 18 A to 51 A
(Figure 2a&2c). Though the work function of pure gold mostly
matches the HOMO of pentacene, it seems that the high charge
trap density induced by the small grain size at the interface
(Figure 4a) has largely deteriorated the OFET performance of
pentacene transistors. Therefore, proper structure adjustments
of the NHCs are important for OFET performance.
In conclusion, surface modifications of Au electrodes with
NHCs have been successfully applied in pentacene OFET
transistors. IPr displayed the best OFET performance among the
three investigated NHCs. And 5 mM IPr in toluene was the best
concentration for reaction of IPr with pre-patterned Au
electrodes. Annealing experiments at 200 oC in air demonstrated
that IPr-Au bonds were much stronger than the S-Au bonds. By
using IPr as the electrode modifier, the pentacene transistors
showed highly increased hole mobility from 0.03 cm2V-1s-1 to
0.15 cm2V-1s-1, which was higher than that of pentacene
[5]
a) E. Delamarche, B. Michel, H. Kang and C. Gerber, Langmuir, 1994,
10, 4103-4108; b) M. H. Schoenfisch and J. E. Pemberton, J. Am.
Chem. Soc. 1998, 120, 4502-4513; c) R. G. Nuzzo, B. R. Zegarski and
L. H. Dubois, J. Am. Chem. Soc. 1987, 109, 733-740; d) F. P. Cometto,
E. M. Patrito, P. P. Olivera, G. Zampieri and H. Ascolani, Langmuir,
2012, 28, 13624-13635.
[6]
[7]
