A ratiometric fluorescent probe for alkaline phosphatase with high sensitivity

Article abstract of DOI:10.1016/j.cclet.2019.04.037

Alkaline phosphatase (ALP) is one of essential biomarkers in mammalian tissue. Here we report a ratiometric probe for ALP, which is rationally designed and synthesized by employing ESIPT fluorophore N-(3-(benzo[d]thiazol-2-yl)-4-hydroxyphenyl)benzamide (B

Full text of DOI:10.1016/j.cclet.2019.04.037

Accepted Manuscript
Title: A ratiometric fluorescent probe for alkaline phosphatase
with high sensitivity
Authors: Yangyang Yang, Chen Zhang, Rizhao Pan, Shiwei
Zhang, Shengtai Yao, Yao Tang, Weilong Zhu, Liyue Wang,
Weiping Zhu, Yufang Xu, Xuhong Qian
PII:
DOI:
Reference:
S1001-8417(19)30207-4
https://doi.org/10.1016/j.cclet.2019.04.037
CCLET 4930
To appear in:
Chinese Chemical Letters
Received date:
Revised date:
Accepted date:
12 March 2019
15 April 2019
15 April 2019
Please cite this article as: Yangyang Y, Chen Z, Rizhao P, Shiwei Z, Shengtai Y, Yao
T, Weilong Z, Liyue W, Weiping Z, Yufang X, Xuhong Q, A ratiometric fluorescent
probe for alkaline phosphatase with high sensitivity, Chinese Chemical Letters (2019),
https://doi.org/10.1016/j.cclet.2019.04.037
This is a PDF file of an unedited manuscript that has been accepted for publication.
As a service to our customers we are providing this early version of the manuscript.
The manuscript will undergo copyediting, typesetting, and review of the resulting proof
before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that
apply to the journal pertain.

Communication
A ratiometric fluorescent probe for alkaline phosphatase with high sensitivity
a,*
a
a
a
a
a
a
Yangyang Yang , Chen Zhang , Rizhao Pan , Shiwei Zhang , Shengtai Yao , Yao Tang , Weilong Zhu ,
a
a
a,*
a,b,*
Liyue Wang , Weiping Zhu , Yufang Xu , Xuhong Qian
a
Shanghai Key Laboratory of Chemical Biology, School of Pharmacy, East China University of Science and Technology, Shanghai 200237, China
State Key Laboratory of Bioreactor Engineering, East China University of Science and Technology, Shanghai 200237, China
b
*Corresponding authors.
E-mail addresses: triyang@ecust.edu.cn (Y. Yang), yfxu@ecust.edu.cn (Y. Xu), xhqian@ecust.edu.cn (X. Qian).
ARTICLE INFO
Article history:
Received
Received in revised form
Accepted
Available online
Graphical abstrcat
Alkaline phosphatase (ALP) is one of essential biomarkers in mammalian tissue. Here we report a ratiometric probe for ALP, which is
rationally designed and synthesized by employing ESIPT fluorophore N-(3-(benzo[d]thiazol-2-yl)-4-(hydroxyphenyl) benzamide)
(BTHPB). The enzymatic dephosphorylation converts the probe to BTHPB, which exhibits a large spectral red-shift (120 nm),
allowing extremely high sensitivity of ALP sensing at 0.004 mU/mL.
ABSTRACT
Alkaline phosphatase (ALP) is one of essential biomarkers in mammalian tissue. Here we report a ratiometric probe for ALP, which is rationally
designed and synthesized by employing ESIPT fluorophore N-(3-(benzo[d]thiazol-2-yl)-4-hydroxyphenyl)benzamide (BTHPB). The enzymatic
dephosphorylation converts the probe to BTHPB, which exhibits a large spectral red-shift (120 nm), allowing extremely high sensitivity of ALP
sensing at 0.004 mU/mL. The probe also shows excellent biocompatibility and has been applied for monitoring the endogenic ALP in living cells.
Keywords:
Fluorescent probe
Alkaline phosphatase
Ratiometric
ESIPT
Biomarker
Alkaline phosphatase (ALP) exists in mammalian tissues and mediates dephosphorylation of biomolecules [1,2]. The abnormal
fluctuation of the ALP concentration in serum has been established as an important biomarker for diagnosis of such diseases as
hepatobiliary disease, bone disease associated with increased osteoplastic activity, breast cancer and prostate cancer [3,4]. Therefore, a
rapid and reliable assay against ALP can facilitate disease diagnosis in clinical settings.
Fluorescence based techniques are versatile and valuable for analysis and imaging of the biomolecules in vitro or in vivo studies
because of its high sensitivity and feasibility for direct use in complex milieu. For the ALP fluorescent sensing, various synthetic
probes have been reported for the detection and the activity monitoring of the ALP [5-22] which were typically designed by
modification of the electron donating group of a fluorescent dye and the fluorescent signals were generated by hydrolyzing the

phosphate group of the probe. However, such probes are usually limited in that the fluorescence emission wavelengths of the probe and
the product are not well separated so that the signal from the probe constitutes a background, which compromises the detection of low
concentration of ALP. Therefore, we wish to report a novel probe which totally eliminates the background signal and render sensitive
and accurate detection of ALP especially of low concentration. Excited-state intramolecular proton transfer (ESIPT) is a well-known
photochemical process, which allows an unusual large stokes shifts during the alteration the conjugation system of the fluorophore
[
2 2
23]. It has been gained much attention in the fluorescence sensing of various substrates such as hydrazine [24], H O [25],
phosphatase MKP-6 [26] and superoxide [27]. Several ESIPT based fluorescent probes for ALP detection have been reported recently.
Tang and coworkers presented a ratiometric probe based on a phosphorylated chalcone derivative with AIE characteristics and ESIPT
performances, enabling a detection limit as low as 0.15 mU/mL. [15]. Another ESIPT probe for ALP was reported by Fan and co-
workers, however, in which the red-shift wavelength was only 70 nm and the detection limit reached 1.3 mU/mL [28]. Until now, the
lowest detection limit of ALP has reached 0.035 mU/mL, however, it was developed by employing the copper nanoparticle [29]. The
reported lowest detection limit of ALP from small fluorescence probe is 0.0077 mU/mL [30].
The fluorophore N-(3-(benzo[d]thiazol-2-yl)-4-hydroxyphenyl)benzamide (BTHPB) has been reported as an excellent fluorescent
molecule based on ESIPT [31], which exhibits two emission bands originating from enol and keto forms at 425 nm and 545 nm,
respectively [32,33]. The two emissions are well separated by nearly 120 nm, which is sufficient to allow the signals of two bands non-
overlapping. Based on this molecule, fluorescent sensors for fluoride, palladium species and mercury, in which all of them exhibited
extreme low detection limit [34-36]. Therefore, in this work, we present an ALP probe 1 (4-benzamio-2-(benzo[d]thiazol-2-yl)phenyl
dihydrogen phosphate, Scheme 1) by employing BTHPB as the fluorescent reporting molecule. We coupled phosphate group with
BTHPB together to obtain a more sensitive fluorescent probe 1 which enables “turn-on” ratiometric fluorescence signal toward ALP
addition.
Scheme 1. (A) The sensing mechanism of ALP by using probe 1. The phosphate group was released because of ALP catalysis, resulting the BTHPB. (B)
Synthesis route of the fluorophore BTHPB and the probe 1 for ALP sensing. Reagents and conditions: (a) polyphosphoric acid, 180 °C, 3 h, yield 49%; (b)
benzoyl chloride, pyridine, 0 °C−r.t., 8 h, yield 23%; (c) (EtO)
HCl, H O/CH CN, r.t., 30 min, HPLC, yield 64%.
2 3 3 2 2
POCl, t-BuOK, THF, r.t., overnight, yield 43%; (d) BSTFA, (CH ) SiI, CH Cl , 0 °C−r.t., 1 h; (e)
2
3
As illustrated in Scheme 1A, probe 1 was designed by transforming the hydroxyl group of BTHPB into the corresponding phosphate
group and the benzoamide group could reduce the pH interference of the probe as well. In the presence of ALP, probe 1 was
hydrolyzed and the BTHPB was released, which exhibited large emission spectral red-shift (~120 nm) because of the recovery of
ESIPT process. The synthesis of probe 1 was shown in Scheme 1B, which was obtained by a four-step synthesis [37] and the structure
1
13
was confirmed by H NMR, C NMR and HR-MS. Besides, the UV-vis absorption and the fluorescence spectra of the probe 1 and the
hydrolysis product (BTHPB) were investigated (Fig. S1 in Supporting information). It has been known that the ALP is most stable in
the pH range 7.5–9.5 [38] and the pH optimum for the enzyme activity is pH 8–10 [39]. First, the spectral studies of the pH titration
were carried out by investing the absorbance change and fluorescence intensity separately (Fig. S2 in Supporting information). The
absorbance decreased when the pH value below 6.5 (Fig. S2a), which mainly because of the intramolecular hydrogen bond change
between the phosphonate group and benzothiazole moiety in the probe. The fluorescence intensity gradually increased at 425 nm by
changing the pH value from 1 to 7 and reached a stable value from pH 7 to pH 12. Therefore pH 8.0 is suitable for measuring the ALP
activity in this work. Besides, the quantum yield of probe 1 was calculated to be 0.028 by using quinine sulfate in sulfuric acid as the
reference.

Fig. 1. Fluorescent assay of the dephosphorylated reaction of probe 1 at 24 °C. (a) The time-dependent fluorescent intensities of probe 1 reacted with ALP (1
mU/mL) were recorded under certain intervals for 60 min. Inset: plot of peak intensities (orange dot) at 545 nm and (blue triangle) at 425 nm vs. reaction time.
(b) Ratiometric fluorescence response (I545/I425) and the linear fit of probe 1 in 35 min. (c) Fluorescence spectra of probe 1 after the incubation with the different
concentration of ALP for over 1 h at 24 °C. (d) Fluorescence emission ratio (I545/I425) of probe 1 vs. concentration of ALP. The reaction buffer: 20 mmol/L Tris-
HCl, pH 8.0, 0.01% Trition-X, 1% DMSO; probe 1: 5 μmol/L; excitation wavelength: 340 nm.
Fig. 1a demonstrates the kinetic studying of dephosphorylation reation by the titration of ALP into probing solution. The ALP (1
mU/mL) was added into a solution of probe 1 (5 μmol/L) in Tris buffer (20 μmol/L, pH 8.0) containing 0.01% of Triton-X with 1%
DMSO as a co-solvent. The fluorescence emission spectra were recorded at 5 min intervals over 60 min with excitation at 340 nm. In
Fig. 1a, there is a dramatic fluorescence emission intensity enhancement at the wavelength of 545 nm while another fluorescence signal
decrement occurred at the wavelength of 425 nm. The quantum yield of the BTHPB reached 0.16 after the enzymatic reaction. The
wavelength red-shift is as much as 120 nm and there is almost no overlap between two emission bands. From the inset data in Fig. 1a,
it can be seen that the fluorescent signal tended to be stable in the last 15 min, indicating that the enzyme reaction was almost
completed in 45 min. Moreover, the peak intensities at 545 nm and 425 nm varied as an exponential or logarithmic function with the
reaction time, respectively. And the ratiometric fluorescent plot (I545/I425) of probe 1 exhibited an excellent linear relationship within
reaction time of 35 min (Fig. 1b). No matter the fluorescence intensity vs. time or the fluorescent ratio change vs. time, the results
indicated that the probe 1 might be applied not only for the ALP sensing but also for the further kinetic analysis of ALP. Meanwhile,
ALP-enzymatic reaction was examined by employing high performance liquid chromatography (HPLC) (Fig. S3 in Supporting
information). Same retention time of the hydrolyzing product and the BTHPB was observed, indicating that the BTHPB was produced
after the addition of ALP as expected.
Furthermore, the quantitative analysis of ALP activity was examined. Fluorescence spectra were recorded after incubation of
different amounts of ALP with probe 1 of same concentration (5 μmol/L) for over 1 h. Besides, the fluorescence spectrum of a solution
containing BTHPB of 5 μmol/L was also collected as the control. As shown in Figs. 1c and d, the addition of ALP resulted in the
dramatic fluorescence emission intensity enhancement at wavelength of 545 nm. Moreover, it can be seen that 2 mU/mL ALP can fully
hydrolyze the probe 1 to BTHPB to reach almost the same fluorescence intensity by taking the fluorescence intensity of BTHPB as the
contrast. In Fig. 1c, the emission ratio (I545/I425) of probe 1 varied from 0.145 to 17.76 upon the concentration of ALP increased from
0
.1 mU/mL to 0.4 mU/mL, a ca. 122-fold enhancement was obtained, demonstrating that probe 1 has extreme high sensitivity.
Meanwhile, the emission ratio also exhibited a linear relationship with ALP activity under the low concentration range (Fig. 1d). The
detection limit of probe 1 to ALP was calculated and determined to be 0.004 mU/mL (S/N = 3, Fig. S4 in Supporting information).
Besides, we also examined the selectivity performances of probe 1 over a series of enzymes including acetylcholinesterase (AChE),
trypsin and lysozyme. The results were illustrated in Fig. 2. It can be observed that the probe 1 exhibited excellent selectivity of ALP
over other enzymes while other three enzymes showed negligible fluorescence changes under the same conditions.

4
3
2
1
0
ALP
AChE Trypsin Lysozyme Blank
Fig. 2. Fluorescent intensity ratio (I545/I425) changes of probe 1 (5 μmol/L) in the presence of ALP, AChE, trypsin and lysozyme (0.15 mU/mL). The reaction
buffer: 20 mmol/L Tris-HCl, pH 8.0, 0.01% Trition-X, 1% DMSO (for lysozyme the pH value is 6.5); excitation wavelength: 340 nm; reaction time: 90 min.
1
00%
8
0%
6
0%
4
0%
0%
2
0
5
10
15
20
[
probe 1] (mol/L)
Fig. 3. Cell viability assay of probe 1 on HeLa cells.
Fig. 4. Fluorescence images of HeLa cells in the absence or in the presence of probe 1. (a, c, e) Bright field images corresponding to the fluorescence images
with (b) no probe 1, (d) probe 1 (5 μmol/L) and (f) inhibitor levamisole hydrochloride (5 mmol/L) and probe 1 (5 μmol/L). Excitation wavelength: 330−400 nm.
Scale bar: 50 μm.
Furthermore, we monitored the endogenous ALP activity in living cell by adding the probe to HeLa cells, of which the ALP was
overexpressed. We first examined cytotoxicity of probe 1 by MTT assay. As shown in Fig. 3, there was almost no reduction in cell
viability after the cells were incubated with the probe (from 5 μmol/L to 20 μmol/L), demonstrating that the probe has low toxicity.
Then the imaging of endogenous ALP of HeLa cells was investigated by incubating the cells with probe 1 and the results were all
illustrated in Fig. 4. By comparing with the control test (Fig. 4b), Fig. 4d showed fluorescence enhancement under the UV excitation,
demonstrating the existence of endogenous ALP in HeLa cells and the generation of dephosphorylation product of probe 1. After the
cells were pre-incubated with ALP inhibitor levamisole hydrochloride for 10 min and then the probe 1 was added, it was observed that
the yellow fluorescence decreased (Fig. 4f), indicating that our probe can specifically probe overexpressed endogenic ALP in living
cells.
In summary, we designed and synthesized a fluorescent ratiometric probe for alkaline phosphatase detection based on the ESIPT
mechanism. The probe was hydrolyzed by the ALP and the ESIPT fluorophore was produced, which accomplished a large red-shift
(120 nm) of the fluorescent emission wavelength from 425 nm to 545 nm. The ratiometric value of two emissions vs. the low
concentration of the ALP exhibited an excellent linear relationship, demonstrating that our probe is suitable for quantitative analysis of

ALP especially at low concentrations. The probe exhibits extreme high sensitivity to the ALP, the low detection limit is as low as 0.004
mU/mL, which is quite outstanding compared with the reported “turn-on” fluorescent sensors and provides an efficient approach for
the ALP analyzing. The fluorescent probe could also be applied for probing the biogenic ALP directly in living cells, which provides
an excellent tools for quick detection and imaging biomarkers and shows potential applications in future point-of-care diagnosis.
Acknowledgments
This work was supported by the Shanghai Sailing Program, National Natural Science Foundation of China (No. 31600802), Science
and Technology Commission of Shanghai Municipality (No. 18DZ1112703) and the Fundamental Research Funds for the Central
Universities.
References
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
[
1] J.L. Millán, Mammalian Alkaline Phosphatases: From Biology to Applications in Medicine and Biotechnology, Wiley-VCH, Weinheim, 2006.
2] R.B. McComb, G.N. Bowers, S. Posen, Alkaline Phosphatase, Plenum Press, New York, 1979.
3] G. Ramaswamy, V.R. Rao, L. Krishnamoorthy, et al., Indian J. Clin. Biochem. 15 (2000) 110-113.
4] D. Goltzman, D. Miao, Encyclopedia Endocr. Dis. 1 (2004) 164-169.
5] Z. Xu, X. Huang, X. Han, et al., Chem 7 (2018) 1609-1628.
6] W. Chen, Y. Pan, J. Chen, et al., Chin. Chem. Lett. 29 (2018) 1429-1435.
7] X, Han, Y. Liu, G. Liu, et al., Chem.-Asian J. 14 (2019) 890-895.
8] Z. Xu, J. Chen, L.L. Hu, et al., Chin. Chem. Lett. 28 (2017) 1935-1942.
9] Z. Xu, L. Xu, J. Zhou, et al., Chem. Commun. 48 (2012) 10871-10873.
10] B. Li, Z. He, H. Zhou, H. Zhang, T. Cheng, Chin. Chem. Lett. 28 (2017) 1929-1934.
11] J. Zhu, P. Jia, N. Li, et al., Chin. Chem. Lett. 29 (2018) 1445-1450.
12] D. Yue, M. Wang, F. Deng, et al., Chin. Chem. Lett. 29 (2018) 648-656.
13] J. Park, Y. Kim. Bioorg. Med. Chem. Lett. 23 (2013) 2332-2335.
14] H. Gong, G. Little, M. Cradduck, et al., Talanta 84 (2011) 941-946.
15] Z.G. Song, R.T.K. Kwok, E.G. Zhao, et al., ACS Appl. Mater. Interfaces 6 (2014) 17245-17254.
16] X.B. Wang, Z.Y. Zhang, X.Y. Ma, et al., Talanta137 (2015) 156-160.
17] X. Zhou, Y. Jiang, X. Zhao, Y. Zhu, Molecules 21 (2016) 1619-1628.
18] M.H. Lee, J.S. Kim, J.L. Sessler, Chem. Soc. Rev. 44 (2015) 4185-4191.
19] Y. Tan, L. Zhang, K. Man, et al., ACS Appl. Mater. Interfaces 9 (2017) 6796-6803.
20] C. Chen, J. Zhao, Y. Lu, J. Su, X. Yang, Anal. Chem. 90 (2018) 3505-3511.
21] P. Ou, R. Zhang, Z. Liu, et al., Angew. Chem. Int. Ed. 58 (2019) 2261-2265.
22] H. Wang, Z. Feng, S.J.D. Signore, A.A. Rodal, B. Xu, J. Am. Chem. Soc. 140 (2018) 3505-3509.
23] J. Zhao, S. Ji, Y. Chen, H. Guo, P. Yang, Phys. Chem. Chem. Phys. 14 (2012) 8803-8817.
24] S. Goswami, S. Das, K. Aich, et al., Org. Lett. 15 (2013) 5412-5415.
25] G. Li, D. Zhu, Q. Liu, L. Xue, H. Jiang, Org. Lett. 15 (2013) 924-927.
26] T. Kim, H. Kang, G. Han, S. Chung, Y. Kim, Chem. Comm. 2 (2009) 5895-5897.
27] D. Murale, H. Kim, W. Choi, D. Churchill, Org. Lett. 15 (2013) 3946-3949.
28] C. Fan, S. Luo, H. Qi, Luminescence 31 (2016) 423-427.
29] J. Li, L. Si, J. Bao, Z. Wang, Z. Dai, Anal. Chem. 89 (2017) 3681-3685.
30] W. Zhang, H. Yang, N. Li, N. Zhao, RSC Adv. 8 (2018) 14995-15000.
31] R. Hu, S. Li, Y. Zeng, et al., Phys. Chem. Chem. Phys. 13 (2011) 2044-2051.
32] S. Li, Q. Wang, Y. Qian, et al., J. Phys. Chem. A 111 (2007) 11793-11800.
33] S.R. Grando, C.M. Pessoa, M.R. Gallas, et al., Langmuir 25 (2009) 13219-13223.
34] R. Hu, J. Feng, D. Hu, et al., Angew. Chem. Int. Ed. 49 (2010) 4915-4918.
35] L. Cui, W. Zhu, Y. Xu, X. Qian, Anal. Chim. Acta 786 (2013) 139-145.
36] M. Santra, B. Roy, K.H. Ahn, Org. Lett. 13 (2011) 3422-3425.
37] E. Barni, P. Savarino, M. Marzona, M. Piva, J. Heterocycl. Chem. 20 (1983) 1517-1521.
38] M. Fosset, D. Chappelet-Tordo, M. Lazdunski, Biochemistry 13 (1974) 1783-1788.
39] H.N. Fernley, P.D. Boyer (Eds.), The Enzymes, Vol. 4, Academic Press, New York, 1971, pp. 417-447.
