PAPER
Benzo[a]phenoxazines and benzo[a]phenothiazine
from vitamin K3: synthesis, molecular structures,
DFT studies and cytotoxic activity†
Cite this: RSC Adv., 2015, 5, 57917
Dattatray Chadar,a Soniya S. Rao,a Ayesha Khan,a Shridhar P. Gejji,a
a
b
a
*
Kiesar Sideeq Bhat, Thomas Weyhermuller and Sunita Salunke-Gawali
¨
Synthesis and characterization of fluorescent benzo[a]phenoxazines viz., M-1B (10-chloro-6-methyl-
7a,11a-dihydro-5H-benzo[a]phenoxazin-5-one), M-2B 6,10-dimethyl-7a,11a-dihydro-5H-benzo[a]-
phenoxazin-5-one), M-3B (6-methyl-7a,11a-dihydro-5H-benzo[a]phenoxazin-5-one) and benzo[a]-
phenthiazine, M-4B (6-methyl-5H-benzo[a]phenothiazin-5-one) were carried out. 1H and 13C chemical
shifts were assigned from the 2DgHSQCAD NMR experiments. Compound M-1B crystallizes in the
orthorhombic space group P212121, while M-2B and M-4B crystallize in the monoclinic space group P21/c.
The crystal network of M-1B showed slipped p–p stacking and Cl/Cl interactions, while M-2B
facilitated ladder like p–p stacked polymeric chains. The C/S contacts were observed in the crystal
environment of M-4B. All these structures possess C–H/O interactions. Electronic structure and charge
distribution in terms of molecular electrostatic potential and frontier orbital analyses based on the MO6-
2X based density functional theory further showed that monomer and dimer structures are in keeping
with the single crystal X-ray data and provide insights for the growth of the crystal network.
Antiproliferative activity of M-1B–M-4B was determined from the MTT assay against a human breast
adenocarcinoma cell line (MCF-7), human carcinoma cell line (HeLa) and normal skin cell line. All these
compounds showed significant cytotoxic activity against MCF-7 and HeLa by inducing apoptosis and
thus can be viewed as potential candidates for antitumor therapy. Compounds M-2B and M-4B were
further found to be topoisomerase II inhibitors.
Received 8th May 2015
Accepted 26th June 2015
DOI: 10.1039/c5ra08496b
www.rsc.org/advances
inammatory,12 anti-tuberculosis13 and multidrug resistance
activities14 prevent human amyloid disorders15 and protect
neuronal cells from death by oxidative stress.16,17 Furthermore, it
Introduction
Benzo[a]phenoxazines are uorescent molecules with a wide
range of pharmacological applications.1 Phenoxazine derivatives
viz., benzo[a]phenoxzinium salts, show absorption maxima
higher than 600 nm and the strong red uorescence thereof
facilitates their use as long wavelength uorophores.2,3 Preferred
for biological applications4–9 these encompass labelling of small
synthetic molecules as well as large biomolecules including
proteins, antibodies or nucleotides in DNA studies. Phenox-
azines possessing antiproliferative,10 antitumor,11 anti-
was shown that the use of phenothiazine derivatives belonging to
neuroleptic drugs,18 reduce tumor-antigen expression19 and
cytotoxicity against myelogeneous leukemia cell lines.20 The
underlying mechanism for antiproliferative activity of phenox-
azine derivatives stem from DNA intercalative binding facilitated
via noncovalent interactions or p–p stacking21,22 which render
stability to these planar polycycles. Alternatively phenoxazine
systems engender free radical intermediates leading to oxidative
stress.23 Some of these phenoxazine derivatives displayed
apoptotic activity against different cell lines, both in caspase
dependent and independent manner.24,25 Fluorescent heterocycle
of phenoxazines are valuable for staining nucleic acids in solu-
tions, electrophoretic gels, matrices, blotting experiments and
assays employing intact, live cells.26 Furthermore, modications
of phenoxazine moiety yield compounds those directly bind to
proteins through hydrophobic interactions which subsequently
are utilized in monitoring protein conformation alterations or for
therapeutic purposes.
aDepartment of Chemistry, Savitribai Phule Pune University, Pune 411007, India.
E-mail: sunitas@chem.unipune.ac.in; Fax: +91 2025693981; Tel: +91 2025601397
ext. 531
b
¨
¨
MPI fur Chemische Energiekonversion, Stistr. 34-36, 45470 Mulheim an der Ruhr,
Germany
† Electronic supplementary information (ESI) available: Characterization of M-1B
to M-4B by FT-IR (Fig. S1–S5 and S22), GC-MS (Fig. S6–S9), DSC (Fig. S10–S13) and
1H,13
C
and 2DgHSQCAD NMR (Fig. S14–S21). Crystallography gures
Fig. S23–S27, cytotoxicity assay Fig. S28–S30. Table S1 (FT-IR data) and
crystallographic Table S2–S12. CCDC 1039204–1039206. For ESI and
crystallographic data in CIF or other electronic format see DOI:
10.1039/c5ra08496b
Topoisomerase are the enzymes those control the DNA
topology, a requisite for division or proliferation of cells. These
This journal is © The Royal Society of Chemistry 2015
RSC Adv., 2015, 5, 57917–57929 | 57917

View Article Online
RSC Advances
Paper
enzymes are important target for cancer chemotherapy and
assist numerous DNA transactions through a complex series of
DNA strand breakage and rejoining reactions. Topoisomerases
resolves the entanglement problems generated during DNA
replication, repair and transcription processes. Depending on
the DNA breaks there are two types of topoisomerases; Topo I,
which break single strand DNA, while Topo II generate double
strand DNA breaks.27,28 Topo II enzymes plays key role in DNA
metabolism and chromosome structure29 and it is the primary
cytotoxic target for the potent anticancer drugs, which include
anthracyclines, acridines and epipodo phyllotoxins.30 Depend-
ing on the mode of action the topoisomerase II inhibitors are
classied as (i) topoisomerase II poisons, which involves in
breaking–rejoining reaction of the enzyme that involves trap-
ping of covalent reaction intermediates, usually referred as the
cleaved complexes, or (ii) catalytic inhibitors inhibiting the
activity of topoisomerase II prior to the formation of the cleaved
complex.31 Heteroatom planar polycyclic compounds are used
in cancer chemotherapy as topoisomerase inhibitor/poison.32–39
DNA intercalation has been believed to be a prefer mode of
action for such compounds.
Scheme 1 General reaction scheme for synthesis of M-1B to M-4B.
In present endeavour, benzo[a]phenoxazines were synthe-
sized by reacting vitamin K3 (menadione, 2-methyl-1,4-
naphthoquinone) with 2-aminophenols (M-1B to M-3B) and
Fig. 1 UV-visible and fluorescence spectra of M-1B to M-4B in DMSO.
Fig. 2 1H and 13C NMR chemical shifts of M-1B to M-4B.
57918 | RSC Adv., 2015, 5, 57917–57929
This journal is © The Royal Society of Chemistry 2015

View Article Online
Paper
RSC Advances
2-aminothiophenol (M-4B) derivatives. Molecular structures of the density functional based calculations. The antiproliferative
M-1B, M-3B and M-4B have been studied by single crystal X-ray activity against human carcinoma HeLa cell line, drug uptake
diffraction studies, which revealed their p–p stacking abilities. and topoisomerase II inhibitor activity of these compounds
The structural investigations were combined with those from have further been investigated.
Fig. 3 ORTEP plots of M-1B, M-2B and M-4B.
This journal is © The Royal Society of Chemistry 2015
RSC Adv., 2015, 5, 57917–57929 | 57919

View Article Online
RSC Advances
Paper
nm (of parent MQ) showed shi ꢃ25 to 30 nm (ꢃ355 nm). Two
another bands observed in UV region ꢃ260 nm to 290 nm were
assigned to p–p* transitions. The n–p* transition was observed
ꢃ450 nm (M-1B to M-3B) which shis to ꢃ480 nm in M-4B. A
uorescence emission band was observed between 450–700 nm.
M-2B showed maximum uorescent intensity than other
compounds despite using the same concentrations in recording
of the spectra.
Results and discussion
Synthesis
Benzo[a]phenoxazine derivatives were synthesized by conden-
sation of vitamin K3 (1) with 4-R-2-aminophenols (R ¼ Cl ¼ M-
1B, CH3 ¼ M-2B, H ¼ M-3B) reuxed in methanol, while M-4B
ꢀ
was obtained at room temperature (26 C) by reacting vitamin
K3 and 2-aminothiophenol (Scheme 1). 6-Methyl-5H-benzo[a]
phenoxazine-5-one and 6-methyl-5H-benzo[a]phenothiazin-5-
one (M-3B and M-4B respectively in present investigation)
were previously synthesized by reactions of alkyl radicals on
corresponding 5H-benzo[a]phenoxazine-5-one40 and 5H-benzo
[a]phenothiazin-5-one41 respectively.
1H and 13C chemical shi were assigned to all compounds
and are presented in Fig. 2.
Single crystal X-ray diffraction studies of M-1B, M-2B and M-4B
M-1B crystallizes in orthorhombic space group P212121, while
M-2B and M-4B crystallize in monoclinic space group P21/c.
ORTEP plots are presented in Fig. 3, and the crystallographic
1
FT-IR, UV-visible, uorescence, H and 13C NMR studies
The nC]O frequency in all compounds was assigned at 1629 ꢁ 1 data is summarized in Table 1. All the crystallized compounds
cmꢂ1, while nC]N stretching frequency42–45 was assigned at 1585 showed planar polycycles. The carbonyl distance C(2)–O(1) was
ꢁ 10 cmꢂ1 in the FT-IR spectra except in M-1B it was observed at observed as ꢃ1.23 A in M-1B and M-2B,10,42–45 while it was longer
˚
1574 cmꢂ1 (Fig. S22 and Table S1 in ESI†). The para-naph- in M-4B (1.246 A). The bond distance of C(9)–N(10) was found to
˚
thoquinone (p-NQ) vibration10 of quinonoid ring (ꢃ1260 cmꢂ1
)
be ꢃ1.30 A similar to the imino functional moiety (C]N) of the
˚
was absent in all compounds however a peak due to nC–O was naphthoquinoneoximes.46 The bond distances in all these
observed ꢃ1240 cmꢂ1 in M-1B, M-3B and M-4B and ꢃ1226 cmꢂ1 crystalline systems usually by and large, match with those for
in M-2B. vC–Cl stretching frequency was assigned to 736 cmꢂ1 in quinonoid bond distances in ring B (Scheme 1).
M-1B.
Each M-1B molecule was in vicinity to eight neighbouring
There were mainly two bands observed in UV-Visible spectra molecules (Fig. S23†) via C–H/O, C–H/Cl, Cl/Cl (Table 2)
of parent vitamin K3 in DMSO at 266 nm and 330 nm and four and p–p stacking interactions. Slipped p–p stacking were
bands to all compounds (Fig. 1). In M-1B to M-3B the band ꢃ330 observed in neighbouring molecules, carbon C(8)/C(11)
