Porphyrin Arrays Responsive to Additives. Fluorescence
Tuning
,
†
†
†
‡
Takeshi Yamamura,* Shingo Suzuki, Tomotaka Taguchi, Akira Onoda,
§
⊥
Toshiaki Kamachi, and Ichiro Okura
Department of Chemistry, Faculty of Science, Science UniVersity of Tokyo, Kagurazaka,
Shinjuku-ku, Tokyo 162-0825, Japan, Department of Applied Chemistry, Graduate School of
Engineering, Osaka UniVersity, 2-1 Yamadaoka, Suita, Osaka 565-0871, Japan, Department of
Molecular Design and Engineering, Graduate School of Engineering, Nagoya UniVersity,
Chikusa, Nagoya 464-8603, Japan, and Department of Bioscience and Biotechnology,
Tokyo Institute of Technology, 4259 Nagatsuta-cho, Midori-ku, Yokohama-shi,
Kanagawa Pref. 226-8501, Japan
Received December 20, 2008; E-mail: tyamamur@rs.kagu.tus.ac.jp
Abstract: The application of low-flux sunlight begins with the synthesis of effective antenna systems. This
requires the development of dye integrates with optimized dye orientation for effective energy transfer. We
here report a series of peptide-linked porphyrin arrays, denoted by Boc-(PorZn,S
)
-OBu (n ) 2, 4, and 8),
t
n
that change their dye orientation to increase fluorescence responsively to additive reagents. The B-band
absorption (AB) regions of the arrays show blue shifts (dimer, 407.6 nm; tetramer, 408.2 nm; octamer,
Zn,S
t
4
07.8 nm) in organic solvents as compared to that of Boc-Por -OBu (monomer, 422.6 nm) and the
1.5
fluorescence yield Φ′ of the arrays decreases with increasing n, obeying the relationship Φ′ ) 0.03/n
;
however, the arrays are tuned up in fluorescence emission by the addition of 1,2-diaminoethane (en). The
addition of a sufficient amount of en increases the fluorescence of the porphyrins in monomer, dimer,
tetramer, and octamer by ∼5, ∼12, ∼12, and >730 times, respectively, when compared with that observed
in the absence of en. This also causes asymptotic red shifts in absorption (AB) bands (B-band λmax: 410
to 429-430 nm), as well as changes in circular dichroism (CD) spectra, and makes porphyrins approach
new mutual asymmetric orientations. Our results show the potentiality of the tunable dye polymers that are
a posteriori optimized in dye orientation and fluorescence emission by additive reagents for the development
of effective light-harvesting materials.
1
. Introduction
The application of low-flux sunlight begins with the synthesis
systems mimicked by chemists for the synthesis of artificial
light-harvesting systems. The beautiful arrangement of Chls
observed in these systems led to the introduction of π-π stacked
of effective antenna systems. This requires the development of
dye integrates equipped with optimized dye orientation for
effective energy transfer. However, photon energies absorbed
in integrated dye systems are easily lost through thermal
quenching when the mutual orientations of the dyes are
unsuitable for energy transfer. Therefore, it is required to
develop dye integrates that achieve optimal orientations for
effective energy transfer. Antenna chlorophylls (Chls) observed
in LH1, LH2, chlorosomes, green plants, and cyanobac-
teria, as well as that of Fenna-Matthews-Olson (FMO)
proteins, are good solutions to this orientation control problem.
Among these natural systems, LH1 and LH2 were the first
8
-10
and flat-ring arrays of porphyrins.
On the other hand, the antenna Chls of cyanobacteria, green
plants, and FMO are not π-π-stacked. The nearest-neighbor
Chls of these light-harvesting systems are asymmetrically
1
2
3,4
5
