Donor–acceptor (E)-2-[2-(2,2'-bithiophen-5-yl)vinyl]benzo[d]thiazole:
synthesis, optical, electrochemical studies and charge
transport characteristics
Sergey D. Tokarev,a Yulia A. Sotnikova,a Alexander V. Anisimov,a Yurii V. Fedorov,b
Gediminas Jonusauskas,c Dmitriy A. Lypenko,d Vladimir V. Malov,d Alexey R. Tameev,d
Eugene I. Mal’tsevd and Olga A. Fedorova*a,b
a Department of Chemistry, M. V. Lomonosov Moscow State University, 119991 Moscow, Russian Federation.
Fax: +7 495 932 8568; e-mail: fedorova@ineos.ac.ru
b A. N. Nesmeyanov Institute of Organoelement Compounds, Russian Academy of Sciences, 119991 Moscow,
Russian Federation. Fax: +7 499 135 5085
c Laboratoire Ondes et Matière d’Aquitaine – UMR CNRS 5798, Bordeaux University, Talence 33405, France
d A. N. Frumkin Institute of Physical Chemistry and Electrochemistry, Russian Academy of Sciences,
199071 Moscow, Russian Federation. Fax: +7 495 952 5308
DOI: 10.1016/j.mencom.2019.09.030
Condensation of 2-methylbenzothiazole with 2,2'-bithio-
phene-5-carbaldehyde affords the title compound, a new
chromophore. This compound was used for the doping of
poly[9,9-bis(6-diethoxylphosphorylhexyl)fluorene], and the
obtained composites demonstrated high electron mobility
(1.50×10–4 cm2 V–1 s–1) in contrast to dopant-free matrixes.
ꢄ
ꢅ
ꢅ
ꢄ
ꢅ
PꢂꢃEP
ꢅ
ꢄ
ꢅ
ꢅ
ꢄ
ꢅ
ꢅ
ꢅ
N
S
S
S
IꢁO
SiO2
Al
ꢅ
ꢄ
ꢅ
ꢄ
V
Small molecular chromophores have attracted much attention as
active components in organic photonic devices due to their
reproduciblepreparation, easyfunctionalization, facilepurification
and high monodispersity.1–6 Donor–acceptor (D–A) typed
p-conjugated organic compounds are widely explored as active
materials for organic solar cells7–10 with the aim to reduce the
band gap for broadening the range of absorption.1,2,11 Moreover,
they were shown to have a great potential to get high power
conversion efficiency (PCE) and demonstrated good ease of
device fabrication.12 Another important field of application is the
use of molecular organic semiconductors (MOSs) as active
charge transporting layers in various devices of flexible
electronics.13–15 The relationship between the structure and
properties of p-type, n-type and ambipolar semiconductors is
still intensively studied. The latter have been developed to a
much lesser extent although they are key components for
realizing complementary metal-oxide semiconductor (CMOS)
digital integrated circuits16–19 and organic light-emitting
transistor (OLET) devices.20–22
poly[9,9-bis(6-diethoxylphosphorylhexyl)fluorene]
(PF-EP).
Compound 1 contains a p-electron donor thiophene moieties
connected through a double bond as a linker with a p-electron
heterocyclic acceptor. The synthesis of compound 1 involved the
Vilsmeier–Haack formylation of 2,2'-bithiophene.23 Obtained
2,2'-bithiophene-5-carbaldehyde was subjected to condensation
with 2-methylbenzothiazole in the presence of KOH (see Online
Supplementary Materials).
n
(EtO)2(O)P(CH2)6 (CH2)6P(O)(OEt)2
PF-EP
The absorption and emission maxima of compound 1 in
different solvents are outlined in Table 1 and Figure 1. The
positions of absorption and fluorescence bands are not
dependent on the solvent nature, whereas the quantum yield
and life time of excited state increase remarkably in DMSO as
compared with acetonitrile and ethyl acetate. The effect could
be connected with the higher viscosity of DMSO. The low
value of the fluorescence quantum yield is known for
styrylthiophene derivatives and is due to the occurrence of
competitive fast ISC (intersystem crossing) process or non-
radiative relaxation.24 It is noteworthy that large Stokes shift
(>120 nm) was observed for compound 1. The redox potentials
of compound 1 are summarized in Table 1. The cyclic
voltammogram in MeCN is shown in Figure S6 (see Online
Supplementary Materials).†
We synthesized and studied bithiophene derivative 1 containing
vinylbenzo[d]thiazole moiety (Scheme 1) for the doping of
i
S
S
H
S
S
O
S
ii
N
S
S
1, 62%
In contrast to fluorescence, irradiation of compound 1 with
light at l = 436 nm brings about E,Z-photoisomerization with
Scheme 1 Reagents and conditions: i, Me2NCHO, POCl3, CH2Cl2; ii,
2-methylbenzothiazole, KOH, DMSO.
© 2019 Mendeleev Communications. Published by ELSEVIER B.V.
on behalf of the N. D. Zelinsky Institute of Organic Chemistry of the
Russian Academy of Sciences.
– 567 –

Mendeleev Commun., 2019, 29, 567–569
Table 1 Optical and electrochemical characteristics of dye 1.a
Solvent
l
abs/nm
lfl/nm
Ffl
F
E–Z/FZ–E
t/ps
tradiative/ns
E/eV HOMO
E/eV LUMO
EtOAc
MeCN
DMSO
474
472
474
596
597
605
0.005
0.0045
0.014
55
30
11
0.55/0.13
6.7
7.5
–5.87
–3.23
105
a labs – maximum absorption position, lfl – maximum fluorescence position, Ffl – quantum yield of fluorescence, FE–Z/FZ–E – quantum yields of forward and
backward E–Z-photoisomerization, t – excited state lifetime, tradiative – radiative excited state lifetime, E HOMO – energy level of the highest occupied
electronic level, E LUMO – energy level of the lowest unoccupied electronic level.
ꢄaꢅ
ꢄ
ꢅ
ꢅ
ꢄ
ꢅ
PꢂꢃEP
ꢅ
0.ꢀ
0.ꢁ
0.ꢂ
0.2
ꢄ
ꢅ
ꢅ
Absorꢆtion
ꢇluorescence
ꢄ
ꢄ
ꢅ
ꢅ
ꢅ
N
S
IꢁO
S
S
Al
ꢅ
SiO2
0.1
0.0
ꢅ
ꢄ
V
ꢂ00
ꢁ00
ꢀ00
ꢈ00
ꢉ00
ꢋavelengthꢃnm
Figure 2 Schematic diagram of MIS-CELIV measurement device.
