Design and Synthesis of Novel Macrocyclic Mer Tyrosine Ki-
nase Inhibitors
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Xiaodong Wang,±* Jing Liu, ±† Weihe Zhang, ±† Michael A. Stashko, ± James Nichols,₸ Michael J Miꢀ
ley,§ Jacqueline NorrisꢀDrouin, ± Zhilong Chen,± Mischa Machius,§ Deborah DeRyckere,ǁ Edgar Wood,₸
Douglas K. Graham,ǁ₸ H Shelton Earp, §₸ Dmitri Kireev, ± Stephen V. Frye ±¶₸
±Center for Integrative Chemical Biology and Drug Discovery, Division of Chemical Biology and Medicinal Chemistry,
Eshelman School of Pharmacy
₸Meryx, Inc., 450 West Dr., Chapel Hill, NC 27599, USA
§ Department of Pharmacology, University of North Carolina at Chapel Hill, Chapel Hill, NC 27599, USA
ǁAflac Cancer and Blood Disorders Center of Children’s Healthcare of Atlanta, Department of Pediatrics, School of Mediꢀ
cine, Emory University, Atlanta, GA 30322, USA
¶Lineberger Comprehensive Cancer Center, Department of Medicine, School of Medicine, University of North Carolina at
Chapel Hill, Chapel Hill, NC 27599, USA
KEYWORDS. Mer inhibitors, MerTK, macrocycle, pyrrolopyrimidine, TAM kinase, structure-based drug design.
ABSTRACT: Mer tyrosine kinase (MerTK) is aberrantly elevated in various tumor cells and has a normal antiꢀinflammatory role
in the innate immune system. Inhibition of MerTK may provide dual effects against these MerTKꢀexpressing tumors through reducꢀ
ing cancer cell survival and redirecting the innate immune response. Recently, we have designed novel and potent macrocyclic pyrꢀ
rolopyrimidines as MerTK inhibitors using a structureꢀbased approach. The most active macrocycles had an EC50 below 40 nM in a
cellꢀbased MerTK phosphorꢀprotein ELISA assay. The Xꢀray structure of macrocyclic analogue 3 complexed with MerTK was also
resolved and demonstrated macrocycles binding in the ATP binding pocket of the MerTK protein as anticipated. In addition, the
lead compound 16 (UNC3133) had a 1.6 hr halfꢀlife and 16% oral bioavailability in a mouse PK study.
Mer tyrosine kinase (MerTK) belongs to the TAM (Tyro3,
Axl, MerTK) family and regulates adult tissues and organ
systems that are subject to continuous challenge and renewal
throughout life.1,2 Aberrant expression of MerTK in various
hematological and solid tumors promotes cancer cell survival,
chemoresistance and invasive motility.3,4 In addition, MerTK
triggers macrophage engulfment of apoptotic material (efꢀ
ferocytosis) and promotes an antiꢀinflammatory response,
preventing excessive inflammation and autoimmune disease.
Unfortunately, within the tumor microenvironment this supꢀ
presses antiꢀtumor innate immune responses.5ꢀ9 Therefore,
inhibition of MerTK may provide dual therapeutic effects
against MerTKꢀexpressing tumors by reducing cancer cell
survival, invasion, and metastasis as well as stimulating antiꢀ
tumor immune responses.
In addition, TAM family members are used by many envelꢀ
oped viruses, such as West Nile (WNV), Dengue (DENV),
HIVꢀ1, Ebola, Marburg, Zika, and Chikungunya, to attach and
gain access to cells through apoptotic mimicry (a phosphatiꢀ
dylserine (PtdSer)ꢀdependent process).10ꢀ12 Inhibition of
MerTK may also lower the infectivity of an important class of
enveloped viruses.13
structure of a complex of MerTK protein with UNC2025
failed, the Xꢀray structure of compound UNC569 (2) comꢀ
plexed with MerTK protein kinase domain was successfully
resolved at a resolution of 2.69 Å (Figure 1a & 1b).15 UNC569
formed three hydrogen bonds with MerTK protein, two with
the hinge region of the protein and the third one with R727.
UNC2025 is expected to bind MerTK in a similar fashion.14
One interesting observation from this Xꢀray structure was that
thermal motions of the butyl amine side chain and the 4ꢀ
aminocylcohexylmethyl group could bring them close enough
to be connected by a short linker, thus forming a macrocycle.
However, connecting these two groups directly was synthetiꢀ
cally challenging. Retaining the cyclohexyl ring and the hyꢀ
droxyl group, the key hydrogen bond donor, would introduce
new stereogenic centers in the newly formed macrocycles. To
provide a proof of concept for the macrocycle hypothesis, a
simplified macrocycle 3 with an amide linker was proposed
(Figure 1c). Although UNC569 belongs to the pyrazolopyrimꢀ
idine series, we have previously shown that pyrrolopyrimꢀ
idines have similar structureꢀactivity relationships (SAR) and
better solubility (solubility of the HCl salt of 1 is 47 mg/mL at
pH 7.4).13 Therefore, we used a pyrrolopyrimidine core to
form macrocycle 3.
Recently, we reported UNC2025 (1), a potent MerTK/Flt3
dual inhibitor.14 Although, our attempt to obtain an Xꢀray
1
ACS Paragon Plus Environment

ACS Medicinal Chemistry Letters
Page 2 of 7
and Tyro3 (IC50 2000 nM), respectively, and similar activity
1
2
3
4
5
6
7
8
against Flt3 (IC50 160 nM) in our inꢀhouse microfluidic capilꢀ
lary electrophoresis (MCE) assay.21ꢀ23 The Xꢀray structure of 3
complexed with the MerTK kinase domain was also resolved
at a 2.55 Å resolution (Figure 2). Overall, the structure was in
agreement with the preliminary docking hypothesis (Figure 1).
The major difference between MerTK binding by 3 and 2, was
that, the amide group of 3, was only able to form a hydrogen
bond with N728 because of its limited freedom of motion,
while the 4ꢀaminocylcohexyl substituent in 2 could simultaneꢀ
ously bind to three residues, R727, N728 and D741 (Figure 2).
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 1. a. The structure of UNC569; b. Xꢀray crystal strucꢀ
ture of UNC569 in complex with MerTK (kinase domain)
(PDB code 3TCP); c. The structure of proposed macrocycle 3.
Macrocycles have been prominent in drug structures for
decades although most macrocyclic drugs on the market are
macrolides or cyclic peptides derived from natural products.
The structural preorganization and incomplete rigidity providꢀ
ed by cyclization with flexible linkers may facilitate interacꢀ
tions with target protein through favorable entropies and nuꢀ
merous, spatially distributed binding interactions, thus, inꢀ
creasing both binding affinity and selectivity.16 Furthermore,
some reports suggest that cyclization has a favorable impact
on other essential properties required for drugs, such as memꢀ
brane permeability,17 metabolic stability, and overall pharmaꢀ
cokinetics.18,19 Currently, a handful de novo designed macroꢀ
cyclic kinase inhibitors are in clinical development.16 Howevꢀ
er, limited opportunities in lead optimization, potential inꢀ
creased costs for scale up, and poor understanding of macroꢀ
cycle absorption, distribution, metabolism, execration, and
toxicity (ADMET) are still concerns for drug discovery efforts
in this field. With this background, we explored introduction
of macrocycles into MerTK inhibitors.20
Figure 2. Xꢀray structure of macrocyclic compound 3 comꢀ
plexed with Mer protein (kinase domain) (PDB code 5K0K).
To improve the hydrogen bonding capability of 3, we inꢀ
stalled an amino or a hydroxyl group in the macrocycle as
shown in structures I & II (Table 1). The closest analogues to
3 from structures I & II were compounds 4 & 10 respectively
which had a similar ring size while 4 had an amino group and
10 had a hydroxyl group attached to the macrocycles (insepaꢀ
rable racemic mixture). As proof of concept, both compounds
were prepared, and indeed were 15ꢀfold more active against
MerTK than 3. Changing the ring size of the macrocycles
would affect not only the conformation of the molecule but
also the location of the amino/hydroxyl group, which is crucial
for forming the desired hydrogen bond. Thus, we next exꢀ
plored the SAR of the ring size of molecules I & II.
Indeed, compound 3 proved active against MerTK (IC50 65
nM) with 20ꢀ and 30ꢀfold selectivity over Axl (IC50 1300 nM)
Table 1. SAR of the ring size
Structure
Compound
m
n
IC50 (nM)a
EC50 (nM)a
pMerTK ELISA
>1000
MerTK
Axl
33 ± 17
Tyro3
Flt3
2
4
6
2
4
6
1
1
1
2
2
2
3.9 ± 2.7
39 ± 16
20 ± 9.6
4
5
6
7
8
9
17 ± 1.9 300 ± 170 110 ± 26 100 ± 11
>1000
30 ± 3.8 170 ± 31
8.9 ± 4.4 150 ± 90
2.2 ± 0.8 11 ± 8.2
0.8 ± 0.1 4.2 ± 1.9
170 ± 28 70 ± 2.6
130 ± 74 130 ± 45
>1000
>1000
13 ± 6.1
12 ± 3.2
34 ± 26
7.5 ± 9.2 2.5 ± 2.6
160 ± 43
2
