A Conjoined Thienopyrrole Oligomer
Formed by Using DNA as a Molecular
Guide
Selvi Srinivasan and Gary B. Schuster*
School of Chemistry and Biochemistry, Georgia Institute of Technology, Atlanta,
Georgia, 30332
schuster@gatech.edu
Received May 28, 2008
ABSTRACT
A thienopyrrole oligomer conjoined to DNA was prepared by means of a templated synthesis protocol. The oligomer was formed by reaction,
initiated with HRP/H2O2, of thieno[3,2-b]pyrrole monomers attached to cytosine bases. The thienopyrrole oligomer was characterized
spectroscopically.
The creation and manipulation of well-defined nanoscale
structures with high precision depends ultimately on the
implementation of synthetic methods that result in the “atom-
level” control of their fabrication. In this context, DNA is a
promising material for the construction of a variety of well-
defined nanomaterials as a result of its highly sequence-
specific self-assembling properties and its ability to form a
flexible, well-ordered helical structure.1-4 DNA-templated
synthesis has proven to be a versatile tool useful for
fabricating molecular nanostructures5-8 including nanow-
ires9-11 and nanomachines.12-14
(5) Gartner, Z. J.; Tse, B. N.; Grubina, R.; Doyon, J. B.; Snyder, T. M.;
Liu, D. R. Science 2004, 305, 1601–1605
(6) Li, X.; Liu, D. R. Angew. Chem., Int. Ed. 2004, 43, 4848–4870
(7) Park, S. H.; Pistol, C.; Ahn, S. J.; Reif, J. H.; Lebeck, A. R.; Dwyer,
C.; LaBean, T. H. Angew. Chem., Int. Ed. 2006, 45, 735–739
(8) Seeman, N. C. Nature 2003, 421, 427–431
.
.
.
.
(9) Braun, E.; Eichen, Y.; Sivan, U.; Ben-Yoseph, G. Nature 1998, 391,
775–778
.
(10) Burley, G. A.; Gierlich, J.; Mofid, M. R.; Nir, H.; Tal, S.; Eichen,
Y.; Carell, T. J. Am. Chem. Soc. 2006, 128, 1398–1399
.
(1) Chen, J.; Seeman, N. C. Nature 1991, 350, 631–633
(2) Lin, C.; Ke, Y.; Liu, Y.; Mertig, M.; Gu, J.; Yan, H. Angew. Chem.,
Int. Ed. 2007, 46, 6089–6092
(3) Mirkin, C. A.; Letsinger, R. L.; Mucic, R. C.; Storhoff, J. J. Nature
1996, 382, 607–609
(4) Simmel, F. C.; Dittmer, W. U. Small 2005, 1, 284–299
.
(11) Nguyen, K.; Monteverde, M.; Filoramo, A.; Goux-Capes, L.;
Lyonnais, S.; Jegou, P.; Viel, P.; Goffman, M.; Bourgoin, J.-P. AdV. Mater.
.
2008, 20, 1099–1104.
(12) Bath, J.; Turberfield, A. J. Nat. Nanotechnol. 2007, 2, 275–284
(13) Liang, X.; Nishioka, H.; Takenaka, N.; Asanuma, H. ChemBioChem
2008, 9, 702–703
.
.
.
.
10.1021/ol801137t CCC: $40.75
Published on Web 08/08/2008
2008 American Chemical Society

Extensive investigation of the properties of DNA has
revealed that its electrical characteristics are not well-suited
for functions that require the rapid and efficient transport of
charge over long distances.15-18 The application of DNA to
molecular electronics as a “wire” therefore requires its major
modification9,19-22 or an appropriate restructuring of the
DNA itself23,24 while continuing to take advantage of its self-
organizing and self-recognizing properties. An example of
this approach is metallization procedures9-11 that form
conductive structures along a path originally defined by the
DNA. Similarly, the fabrication of DNA attached to semi-
conductor nanoparticles19,25 or to conducting polymers26-28
offers considerable promise.
Conducting polymers such as polypyrrole and polya-
niline26-29 have been synthesized by taking advantage of
electrostatic interactions to organize their positively charged
monomers along the negatively charged phosphate backbone
of DNA. This strategy is easy to execute, but it does not
allow for specific attachment of the conducting polymer and
does not take advantage of the sequence information inherent
in DNA. We have been examining the possibility of forming
DNA-linked conducting polymers that are attached co-
valently at specified bases, thus combining the templating
and scaffolding roles of DNA. As an initial step toward this
goal, we recently showed that either horseradish peroxidase
(HRP) under mild oxidizing conditions or electrochemical
methods can be employed to form polyaniline (PANI) from
aniline derivatives linked to the bases of an oligonucleotide
without destroying the duplex.30,31 In this communication,
we report the extension of this strategy to a heterocyclic
monomer. Thieno[3,2-b]pyrrole monomers attached to cy-
tosine bases through a flexible three-carbon chain were
Figure 1. Schematic representation of the DNA oligomers used in
this work. The symbol X stands for a cytosine nucleobase having
a covalently attached thienopyrrole monomer prepared by postsyn-
thetic modification of the oligonucleotide, as is shown.
oxidized, and optical absorption experiments indicated that
this reaction results in the formation of a conducting polymer.
Thienopyrrole is an electron-rich heteroaromatic bicyclic
compound containing pyrrole and thiophene units fused
together. This compound is more easily oxidized (Eox ) 0.6
V vs Ag/Ag+) than thiophene as a consequence of its greater
π-electron delocalization. It has been predicted from ab initio
theoretical calculations that poly(thienopyrrole) has a pre-
dominant R-R′ linkage between the monomer units. Simi-
larly, poly(thienopyrrole) is expected to have good conduc-
tivity and be easily transformed between its oxidized and
reduced states,32 making it an ideal candidate for use as a
nanowire conjoined to DNA. Moreover, preparation of
oligonucleotides having thienopyrole groups on cytosines
seemed straightforward and in fact was readily accomplished.
The DNA oligomers used in the current study are shown
in Figure 1 where X represents the modified cytosine bearing
the thienopyrrole moiety. They were prepared by postsyn-
thetic modification of the appropriate oligonucleotides.
1-(3-Aminopropyl)thieno[3,2-b]pyrrole (TP) was prepared
from thieno[3,2-b]pyrrole (5), which in turn was effi-
ciently obtained from thiophene-2-carboxaldehyde (1) by
Hemetsberger-Knittel reaction methodology (see Scheme
1).33 DNA(1) and DNA(2) are sequences with six and one
TP units, respectively. The arrangement of alternating X and
T nucleotides of DNA(1) was selected on the basis of
molecular mechanics calculations so that the monomers were
properly spaced for reaction. DNA(3) is a normal, unmodified
sequence used in control experiments. DNA(4) and DNA(5)
are the complementary sequences to the above oligonucle-
otides. All DNA oligomers were purified by reverse-phase
HPLC, and the structures were confirmed by optical and ESI
mass spectrometry.
(14) Niemeyer, C. M.; Adler, M. Angew. Chem., Int. Ed. 2002, 41, 3779–
3783
.
(15) Cai, L. T.; Tabata, H.; Kawai, T. Appl. Phys. Lett. 2000, 77, 3105–
3106
.
(16) Cai, L. T.; Tabata, H.; Kawai, T. Nanotechnology 2001, 12, 211–
216
.
(17) Porath, D.; Bezryadin, A.; de Vries, S.; Dekker, C. Nature 2000,
403, 635–638
.
(18) Storm, A. J.; van Noort, J.; de Vries, S.; Dekker, C. Appl. Phys.
Lett. 2001, 79, 3881–3883
(19) Coffer, J. L.; Bigham, S. R.; Li, X.; Pinizzotto, R. F.; Rho, Y. G.;
Pirtle, R. M.; Pirtle, I. L. Appl. Phys. Lett. 1996, 69, 3851–3853
(20) Keren, K.; Berman, R. S.; Buchstab, E.; Sivan, U.; Braun, E. Science
2003, 302, 1380–1382
(21) Keren, K.; Krueger, M.; Gilad, R.; Ben-Yoseph, G.; Sivan, U.;
Braun, E. Science 2002, 297, 72–75
(22) Richter, J.; Seidel, R.; Kirsch, R.; Mertig, M.; Pompe, W.; Plaschke,
J.; Schackert, H. K. AdV. Mater. 2000, 12, 507–510
(23) Gu, J. H.; Tanaka, S.; Otsuka, Y.; Tabata, H.; Kawai, T. Appl. Phys.
Lett. 2002, 80, 688–690
(24) Lee, H. Y.; Tanaka, H.; Otsuka, Y.; Yoo, K. H.; Lee, J. O.; Kawai,
T. Appl. Phys. Lett. 2002, 80, 1670–1672
.
.
.
.
.
.
.
(25) Dittmer, W. U.; Simmel, F. C. Appl. Phys. Lett. 2004, 85, 633–
635
.
(26) Bae, A.-H.; Hatano, T.; Numata, M.; Takeuchi, M.; Shinkai, S.
Macromolecules 2005, 39, 1609–1615
(27) Ma, Y. F.; Zhang, J. M.; Zhang, G. J.; He, H. X. J. Am. Chem.
Soc. 2004, 126, 7097–7101
(28) Nagarajan, R.; Liu, W.; Kumar, J.; Tripathy, S. K. Macromolecules
2001, 34, 3921–3927
(29) Nickels, P.; Dittmer, W. U.; Beyer, S.; Kotthaus, J. P.; Simmel,
F. C. Nanotechnology 2004, 15, 1524–1529
(30) Chen, W.; Josowicz, M.; Datta, B.; Schuster, G. B.; Janata, J.
Electrochem. Solid-State Lett. 2008, 11, E11-E14
(31) Datta, B.; Schuster, G. B. J. Am. Chem. Soc. 2008, 130, 2965–
2973
.
Duplex DNA oligomers were prepared by hybridization
of the appropriate single strands and probed by examination
of their thermal melting behavior, first to confirm that
duplexes are formed, but primarily to ensure that they are
.
.
.
.
(32) Lassaroni, R.; De Pryck, A.; Debaisieux, C.; Riga, J.; Verbist, J.
Synth. Met. 1987, 21, 189–195.
.
(33) Hemetsberger, H.; Knittel, D. Monatsh. Chem. 1972, 103, 194.
3658
Org. Lett., Vol. 10, No. 17, 2008

Scheme 1. Synthetic Route Used for the Preparation of
1-(3-Aminopropyl)thieno[3,2-b]pyrrole
Figure 2
