A direct route to 6,6′-disubstituted-2,2′-bipyridines by double Diels-Alder/retro Diels-Alder reaction of 5,5′-bi-1,2,4-triazines

Article abstract of DOI:10.3390/10010274

Inverse electron demand Diels-Alder reaction of functionalized 5,5′-bi-1,2,4-triazines with bicyclo[2.2.1]hepta-2,5-diene in boiling p-cymene leads to a range of 6,6′-disubstituted-2,2′-bipyridines in good yield.

Full text of DOI:10.3390/10010274

Molecules 2005, 10, 274-278
molecules
ISSN 1420-3049
http://www.mdpi.org
A Direct Route to 6,6’-Disubstituted-2,2’-Bipyridines by Double
Diels-Alder/retro Diels-Alder Reaction of 5,5’-bi-1,2,4-Triazines†
Danuta Branowska*
Institute of Chemistry, University of Podlasie, ul. 3 Maja 54, PL-08-110 Siedlce, Poland;
Fax:(+48) 25-644-2045
*Author to whom correspondence should be addressed; e-mail: dankab@ap.siedlce.pl
† Part 29 in 1,2,4-Triazines in Organic Synthesis; for Part 28, see [1]
Received: 5 September 2004; in revised form: 3 January 2005 / Accepted: 3 January 2005 / Published:
31 January 2005
Abstract: Inverse electron demand Diels-Alder reaction of functionalized 5,5’-bi-1,2,4-
triazines with bicyclo[2.2.1]hepta-2,5-diene in boiling p-cymene leads to a range of 6,6’-
disubstituted-2,2’-bipyridines in good yield.
Keywords: 5,5’-bi-1,2,4-triazines, norbornadiene, Diels-Alder reaction
Introduction
2,2’-Bipyridine is one of the most widely used ligands in coordination and supramolecular
chemistry [2]. Particularly interesting and useful are its 5,5’- and 6,6’-disubstituted derivatives in view
of their numerous applications in the construction of many larger supramolecular species [3]. The
preparation of 6,6’-disubstituted-2,2’-bipyridines is generally allowed by the extension of Ullmann
procedure involving Ni- or Pd- catalyzed homo-coupling reactions of the corresponding 6-substituted-
2-halopyridines [4]. Despite their efficiency, these methods have been most widely investigated with
2-bromo-6-methylpyridine [5]. Other derivatives bearing different end groups were obtained by the
further functionalization of substitutes, i.e., methyl or bromine in the combined pyridine rings [5], by
using extrusion procedures involving organophosphorus [6] and organosulfur [7] compounds, or via
ring transformation reactions of bis(triazolo)pyridines [8]. More recent approaches employ the
intermolecular Diels-Alder/retro Diels-Alder (DA-rDA) reaction of 3- or 5-(2-pyridyl)-1,2,4-triazines

275
Molecules 2005, 10
[9] or 5,5’-bi-1,2,4-triazines 2 [10]. Previous studies in this laboratory have shown that the latter
compounds are excellent substrates for the synthesis of symmetrical cycloalkeno[c]fused 2,2’-
bipyridines by the DA-rDA reaction of 2 with cyclic enamines [11]. Now we show that intermolecular
DA-rDA reactions of 3,3’-disubstituted-5,5’-bi-1,2,4-triazines 2a-e with appropriate dienophiles
provide ready access to the symmetrical 6,6’-disubstituted-2,2’-bipyridines 6a-e.
Results and Discussion
The variously substituted 5,5’-bi-1,2,4-triazines 2a-e were prepared using a modified literature
procedure [12], namely the direct dimerization of 3-substituted-1,2,4-triazines 1 (available in
multigram quantities by condensation reactions staring from glyoxal and the corresponding
carbamidrazones [13] or N-alkylthiosemicarbazones [13, 14]), with a 1.5 molar excess of potassium
cyanide in water. The highest yields of the 5,5’-bi-1,2,4-triazines 2a-e were obtained when the
reactions were carried out at room temperature for 1 hour. The bitriazines 2a-e were isolated by
extraction with chloroform, and then used in crude form for the synthesis of 2,2’-bipyridines 6a-e
(Scheme 1, Table 1).
Scheme 1
N
N
N
N
N
3
N
N
N
X
6
+ traces of
+ traces of
N
X
N
X
-N2
N
N
N
N
N
X
5
6
X
2
1
4
_
5
_
N2
N
N
X
X
X = SCH3, SCH(CH3)2, CH3, OCH3, Ph
Table 1. Yields of 5,5’-disubstituted-1,2,4-triazines 2a-e
Comp.
2a
X
-SCH3
-SCH(CH3)2
-CH3
-OCH3
-Ph
Yield (%) M.p. (ºC)
Lit. M.p. (ºC)
168.5-170 [12]
174-175 [15]
151-152 [11]
175-176.5 [12]
-
94
98
67
95
93
166-167
173-174
150-151
175-176
301-302
2b
2c
2d
2e
It has been shown previously that 3,3’-bis(methylsulfanyl)-5,5’-bi-1,2,4-triazine (2a, X=SCH3)
undergoes the regiospecific DA-rDA reaction with 1-vinylimidazole (3) in boiling bromobenzene to
give a single cycloaddition product 5 together with traces of 6,6’-bis(methylsulfanyl)-2,2’-bipyridine

276
Molecules 2005, 10
(6a) [16]. The reaction took a different course during microwave irradiation of the reaction mixture.
Under these conditions the proportion of compound 6a increased considerably and bipyridine 6a was
obtained in 35% yield when the reaction mixture was irradiated for 4 hrs at 150˚C. Attempts to
increase the cycloaddition yields failed, even when longer times are used. In our search for a more
effective route to 6a, we explored the DA-rDA reaction between 2a and bicyclo[2.2.1]hepta-2,5-diene
(4), which can be considered as an acetylene equivalent. When this dienophile was used instead of
1-vinylimidazole (3), a mixture was obtained that contained compound 6a as its major component. In
order to optimize this step, a variety of solvents were tested under various conditions. The progress of
the reaction was followed on TLC after workup of an aliquot. The highest yield of 6,6’-bis(methyl-
sulfanyl)-1,2,4-triazine (6a), isolated by column chromatography from the reaction mixture, was
obtained when the reaction was carried out in p-cymene at 170 ˚C. The utility of this reaction was
further demonstrated by the one step synthesis of a range of 6,6’-disubstituted 2,2’-bipyridines 6b-e
(Scheme 1).
The treatment of sterically crowded 2b with 4 under the same reaction conditions affords 6b in
reasonable yield. The extension of this study by using 3,3’-bis(methyl)- (2c) and 3,3’-bis(methoxy)-
(2d) -5,5’-bi-1,2,4-triazines clearly showed the generality of this ring transformation process, since the
2,2’-bipyridines 6c and 6d were obtained in good to moderate yields. The formation of 6,6’-
bis(methoxy)-2,2’-bipyridine (6d) was less favorable, and more time for its completion was required
than the reaction which yielded methyl or methylsulfanyl derivatives. 3,3’-Bis(phenyl)-5,5’-bi-1,2,4-
triazine (2e) also reacted smoothly with 4, affording 2,2’-bipyridine (6e), respectively. Table 2 shows
the reaction conditions, yields and melting points of compounds 6a-e.
Table 2. Reaction times and yields of 6,6’-disubstituted-2,2’-bipyridines 6a-e
Comp.
6a
X
-SCH3
-SCH(CH3)2
-CH3
-OCH3
-Ph
Reaction time (hrs)
Yield (%) M.p. (ºC) Lit. M.p. (ºC)
30
26
25
110
28
80
48
88
59
60
130-131
105-106
88-89
117-118
175.5-176
130-131 [17]
105-107 [18]
88-89 [19]
118 [20]
6b
6c
6d
6e
176-177 [21]
Conclusions
In summary, we described a new, simple method of gaining access to 6,6’-disubstituted 2,2’-
bipyridines 5, which are valuable components for the construction of larger supramolecular species.
Acknowledgments
The author is grateful to Prof. Andrzej Rykowski of the University of Podlasie for fruitful
discussions.

277
Molecules 2005, 10
Experimental
General
Melting points are uncorrected. IR spectra were measured with a Magna IR-760
1
spectrophotometer. The H-NMR spectra were recorded in deuteriochloroform on a Varian-Gemini
200 MHz spectrometer. Mass spectra were measured with an AMD 604 (AMD Intectra GmbH,
Germany). Column chromatography was performed on silica gel (230-400 mesh, 60 Merck). All the
solvents used were dried and distilled according to standard procedures [22]. Merck 60F254 plates were
used for analytical (TLC) chromatography.
Typical procedure: Preparation of 3,3’-Bis(phenyl)-5,5’-bi-1,2,4-triazine (2e)
A solution of 3-phenyl-1,2,4-triazine (0.87g, 5.54 mmol) in water (50 mL) was stirred until
complete dissolution. An excess of KCN (0.54 g, 8.31 mmol, 1.5 eq) was then added as a solid in 5
portions. A precipitate (intensively colored) was formed immediately. The reaction mixture was
extracted with chloroform (30 x 20 mL). The combined organic extracts were dried over MgSO4, then
filtered and concentrated in vacuo. The crude product was purified by recrystallization from ethanol to
1
give analytically pure compound 2e (0.82 g, 95 %) as a yellow solid, m.p. 301-302˚C; H-NMR δ:
.
7.62-7.65 (m, 6 H), 8.68-8.73 (m, 4 H), 10.36 (s, 2 H); Anal. Calcd for C18H12N6 0.25 H2O: C, 67.96;
H, 4.19; N, 26.23. Found: C, 68.25; H, 3.95; N, 26.54.
The synthesis of 6,6’-disubstituted-2,2’-bipyridines 6a-e. General procedure.
The solution of the corresponding 3,3’-disubstituted-5,5’-bi-1,2,4-triazine (1 mmol) in p-cymene
(10 mL) and bicyclo[2.2.1]hepta-2,5-diene (10 eq) was heated at reflux (for the reaction times see
Table 2). The crude products were purified by column chromatography on silica gel (Merck type 60,
230-400 mesh), using a 10:1 hexane-chloroform mixture as eluent, followed by recrystallization from
ethanol to give compounds 6a-e as white solids.
References and Notes
1. Branowska, D. Molecules 2005, 10, 265-273.
2. (a) Lehn, J.-M. Supramolecular Chemistry: Concepts and Perspectives; VCH: Weinheim, 1995;
(b) Steel, P. J. Adv. Heterocycl. Chem. 1997, 67, 1.
3. Kaes, C.; Katz, A.; Hosseini, M. Chem. Rev. 2000, 100, 3553.
4. Fanta, P. E. Synthesis, 1974, 9.
5. Newkome, G. R.; Patri, A. K.; Holder, E.; Schubert, S. Eur. J. Org. Chem. 2004, 235.
6. Newkome, G. R.; Hager, D. C. J. Am. Chem. Soc. 1978, 100, 5567.
7. Kawai, T.; Furukawa, N. Tetrahedron Lett. 1984, 25, 2549.
8. Oae, S.; Takeda, T. Wakabayashi, S. Tetrahedron Lett. 1988, 29, 4445.
9. Pabst, G. R.; Sauer, J. Tetrahedron Lett. 1998, 39, 6687.

278
Molecules 2005, 10
10. Rykowski, A.; Branowska, D.; Kielak, J. Tetrahedron Lett. 2000, 41, 3657.
11. Branowska, D. Synthesis, 2003, 2096.
12. Krass, D. K.; Chen, T.-K.; Paudler, W. W. J. Heterocyclic Chem. 1973, 10, 343.
13. Neunhoeffer, H.; Henning, H.; Frühauf, H.-W.; Mutterer, M. Tetrahedron Lett. 1969, 3147.
14. Paudler, W. W.; Chen, T.-K. J. Heterocycl. Chem. 1970, 7, 767.
15. Branowska, D.; Kielak, J. Polish J. Chem. 2003, 77, 1149.
16. Branowska, D.; Rykowski, A. Synlett, 2002, 1892.
17. Kawai, T.; Furokawa, N.; Oae, S. Tetrahedron Lett. 1984, 25, 2549.
18. Tiecco, M.; Tingoli, M.; Testaferri, L.; Bartoli, D.; Chianeli, D. Tetrahedron 1989, 45, 2857.
19. Newkome, G. R.; Puckett, W. E.; Kiefer, G. E.; Gupta, V. K.; Xia, Y.; Coreil, M.; Hackney, M. A.
J. Org. Chem. 1982, 47, 4116.
20. Manandhar, S.; Singh, R. P.; Eggers, G. V.; Shreeve, J. M. J. Org. Chem. 2002, 67, 6415.
21. Constable, E. C.; Elder, S. M.; Healy, J.; Tocher, D. A. J. Chem. Soc., Dalton Trans. 1990, 1405.
22. Perrin D.D.; Armarego W. L. F. Purification of Laboratory Chemicals; Pergamon: Oxford, U.K.
1992.
Sample Availability: Available from the author.
