Synthesis of (3alpha,7beta,17alpha)-7-methyl-19-norpregn-5(10)-en-20-yne-3,7,17-triol, a metabolite of ORG OD14, and its 7-epimer.

Article abstract of DOI:10.1016/S0039-128X(00)00233-6

The syntheses of the 7beta-hydroxy metabolite of ORG OD14 (Livial((R))), (3alpha,7beta,17alpha)-7-methyl-19-norpregn-5(10)-en-20-yne-3,7,17-triol (35), and its 7-epimer, (3alpha,7alpha,17alpha)-7-methyl-19-norpregn-5(10)-en-20-yne-3,7,17-triol (11), are described.

Full text of DOI:10.1016/S0039-128X(00)00233-6

Steroids 66 (2001) 117–126
Synthesis of (3␣,7␤,17␣)-7-methyl-19-norpregn-5(10)-en-20-yne-3,7,17-
triol, a metabolite of ORG OD14, and its 7-epimer
Ralf Plate*, Rob C.A.L. van Wuijtswinkel, Christan G.J.M. Jans, Marinus B. Groen
Medicinal Chemistry Department, N.V. Organon, P.O. Box 20, 5340 BH Oss, The Netherlands
Received 17 February 2000; received in revised form 4 April 2000; accepted 12 April 2000
Abstract
The syntheses of the 7␤-hydroxy metabolite of ORG OD14 (Livial®), (3␣,7␤,17␣)-7-methyl-19-norpregn-5(10)-en-20-yne-3,7,17-triol
(35), and its 7-epimer, (3␣,7␣,17␣)-7-methyl-19-norpregn-5(10)-en-20-yne-3,7,17-triol (11), are described. © 2001 Elsevier Science Inc.
All rights reserved.
Keywords: Tibolone; Livial; ORG OD14; 7-Hydroxy steroids
1. Introduction
2. Experimental
Livial® is of great interest in hormone replacement ther-
apy in menopausal women at risk of osteoporosis [1,2]. The
active principle of Livial® is ORG OD14 (generic name:
tibolone, scientific name: (7␣,17␣)-17-hydroxy-7-methyl-
19-norpregn-5(10)-en-20-yn-3-one) I [3]. Recently, the me-
tabolism of ORG OD14 in rat and human hepatocytes has
been reported [4]. In both rat and human hepatocytes the
metabolism of this steroid was found to be virtually com-
plete. Among the metabolites detected, the 7-hydroxy de-
rivative III is a result of phase II metabolism (sulfate con-
jugation) of its precursor 35, which is produced by phase I
metabolism (hydroxylation) of II (Scheme 1). Cytochrome
P450 enzymes [5] are known to be involved in the phase I
7-hydroxylation of endogenous steroids, such as choles-
terol, pregnenolone and dehydroepiandrosterone. Although
not proven, these enzymes are candidates for the conversion
of II into 35.
2.1. General methods
1H and 13C NMR spectra were recorded on a Bruker
spectrometer (200 MHz, 400 and 600 MHz) with deu-
teriochloroform was as the solvent unless stated other-
wise. Chemical shifts are reported as ␦ values (parts per
million) relative to tetramethylsilane as an internal stan-
dard, and coupling constants are expressed in Hertz. Thin
layer chromatography was performed on pre-coated
Merck Silica gel 60 F254 plates and visualized with UV
light and/or with sulfuric acid in ethanol solution or the
Usui reagent. Column chromatography was performed on
Merck Silica gel 60 (230–400 mesh or 400–600 mesh).
Melting points were determined on a Bu¨chi 535 apparatus
and are uncorrected. Fast atom bombardment (FAB) mass
spectra were recorded with a Finnigan MAT 90 mass
spectrometer (Finnigan MAT, Bremen, FRG). Samples
were dissolved in methanol and mixed with the matrix
compounds on standard stainless steel targets. Exact
masses of the protonated molecular ions were determined
with the peak matching technique at a mass resolution
of Ͼ 7500 (10% valley definition) in the positive ion
mode using reference masses 369 and 461 from glycerol.
Average exact masses were calculated from at least 10
computer-controlled measurements using the bracketing
method.
The 7-hydroxy derivative III has been found in an in
vivo metabolism study of ORG OD14 in rat, but it could not
be detected in human. Structure verification as well as an
understanding of the pharmacology of this drug metabolite
urged us to develop the synthesis of 35 as described below.
* Corresponding author. Tel.: ϩ31-412-661957; fax: ϩ31-412-
662546.
E-mail address: R.Plate@organon.oss.akzonobel.nl (R. Plate).
0039-128X/01/$ – see front matter © 2001 Elsevier Science Inc. All rights reserved.
PII: S0039-128X(00)00111-2

118
R. Plate et al. / Steroids 66 (2001) 117–126
acetate whereas maintaining the temperature below 10°C.
Water (250 ml) was added. After stirring for 1 h, the
mixture was filtered over a Decalite pad and extracted with
ethyl acetate. The extract was successively washed with
ammonium chloride, sodium bicarbonate solution, and
brine. The organic layer was dried (Na2SO4) and evaporated
to dryness. The residue was purified by column chromatog-
raphy [heptane/ethyl acetate (8:2)] to give 4 (24.9 g, 72.3
1
mM, 51%). Rf 0.55 [toluene/ethyl acetate (1:1 v/v)]. H
NMR: (CDCl3, 200 MHz) ␦ 0.88 (s, 3H, 18CH3), 2.43 (m,
1H, 9␣H), 2.63 (m, 1H, 8␤H), 2.91 (m, 1H, 6-H), 3.12 (m,
1H, 6-H), 3.78 (s, 3H, Ar-OCH3), 3.93 (m, 4H, ketal), 4.15
(m, 1H, 7␤H), 6.64 (d, 1H, Ar-4H), 6.75 (dd, 1H, Ar-2H),
7.25 (d, 1H, Ar-1H).
Scheme 1.
2.1.4. 3-Methoxyestra-1,3,5(10)-triene-7,17-dione cyclic
17-(1,2-ethanediyl acetal) (5)
2.1.1. 3-Methoxyestra-1,3,5(10),6-tetraen-17-one cyclic
1,2-ethanediyl acetal (2)
Chromic acid (3 ml, 8N, 24 mM) was added to a solution
of 4 (2 g, 5.8 mM) in acetone (30 ml) at Ϫ20°C. The
reaction was stirred for 6 h, whereas the temperature raised
to 20°C. Ethanol (10 ml) was added, and the mixture was
poured into a saturated solution of sodium bicarbonate.
Then, the mixture was filtered over a Decalite pad, extracted
with ethyl acetate, and washed successively with sodium
bicarbonate, ammonium chloride, water, and brine. The
organic layer was dried (Na2SO4) and evaporated to dry-
ness. Purification by column chromatography [heptane/eth-
yl acetate (8:2)] gave 5 (1.31 g, 3.8 mM, 66%). Rf 0.7
[toluene/ethyl acetate (1:1 v/v)]. 1H NMR: (CDCl3, 200
MHz) ␦ 0.87 (s, 3H, 18CH3), 2.65 (m, 1H, 8␤H), 3.59 (s,
2H, 6-H), 3.80 (s, 3H, Ar-OCH3), 3.93 (m, 4H, ketal), 6.67
(d, 1H, Ar-4H), 6.81 (dd, 1H, Ar-2H), 7.24 (d, 1H, Ar-1H).
Triethyl orthoformate (66 ml) and p-toluenesulphonic
acid (990 mg) were added to a solution of 1 (33.1 g, 117
mM) in ethylene glycol (330 ml) and CH2Cl2 (50 ml).
After stirring at room temperature for 6 h, the reaction
mixture was poured into sodium bicarbonate solution and
extracted with ethyl acetate. The extract was washed with
water and brine, dried (Na2SO4), and evaporated to dry-
ness to give 2 (42.5 g, 100% crude). Rf 0.8 [toluene/ethyl
acetate (8:2 v/v)]. 1H NMR: (CDCl3, 200 MHz) ␦ 0.88 (s,
3H, 18CH3), 3.80 (s, 3H, Ar-OCH3), 3.93 (m, 4H, ketal),
6.01 (dd, J ϭ 2Hz, 1H, 7-H), 6.45 (dd, J ϭ 3 Hz, 1H,
6-H), 6.65 (d, 1H, Ar-4H), 6.74 (dd, 1H, Ar-2H), 7.16 (d,
1H, Ar-1H).
2.1.2. (6␣,7␣)-6,7-Epoxy-3-methoxyestra-1,3,5(10) -trien-
17-one cyclic 1,2-ethanediyl acetal (3)
2.1.5. (7␣)-7-Hydroxy-3-methoxy-7-methylestra-1,3,5(10)-
trien-17-one cyclic 1,2-ethanediyl acetal (6)
3-Chloroperoxybenzoic acid (44.4 g, 260 mM) was
added to a solution of 2 (42 g, crude) in ethyl acetate (420
ml) under nitrogen was added and stirred at room tem-
perature for 6 h. Then, the reaction mixture was poured
into saturated sodium bicarbonate solution and extracted
with ethyl acetate. The extract was washed with ammo-
nium chloride solution, treated with sodium thiosulfate
solution, filtered, washed with brine, and evaporated to
dryness to give 3 (48.4 g, 100% crude). Rf 0.5 [toluene/
Cerium(III) chloride heptahydrate (560 mg, 1.5 mM)
was finely ground in a mortar and placed into in a 50 ml
necked flask. The flask was put in an oil bath, evacuated,
and heated to 140°C, whereas the powder was stirred with
a magnetic stirring bar for 16 h. Then, while the flask was
still hot, nitrogen was introduced, the flask was cooled to
0°C, and tetrahydrofuran (5 ml) was added. The flask was
put in an ultrasound bath, and the suspension was stirred for
1 h. After cooling to 0°C, methylmagnesium chloride (0.75
ml of a 2.0-M solution in tetra- hydrofuran, 1.5 mM) was
added to the suspension. After stirring for 1.5 h at 0°C, a
solution of 5 (356 mg, 1 mM) in tetrahydrofuran (3 ml) was
added to the mixture. After 0.5 h of stirring at 0°C, the
reaction mixture was poured into saturated ammonium chlo-
ride solution and extracted with ethyl acetate. The extract
was washed successively sodium bicarbonate, water, and
brine. The organic layer was dried (Na2SO4) and evaporated
to dryness to give the crude product. Purification by column
chromatography [heptane/ethyl acetate (7:3)] gave 6 (190
mg, 0.5 mM, 53%). Rf 0.5 [toluene/ethyl acetate (1:1 v/v)].
1H NMR: (CDCl3, 200 MHz) ␦ 0.88 (s, 3H, 18CH3), 1.32
1
ethyl acetate (8:2 v/v)]. H NMR: (CDCl3, 200 MHz) ␦
0.89 (s, 3H, 18CH3), 3.58 (d, 1H, 7-H), 3.82 (s, 3H,
Ar-OCH3), 3.85 (d, 1H, 6-H), 3.95 (m, 4H, ketal), 6.85
(dd, 1H, Ar-2H), 6.97 (d, 1H, Ar-4H), 7.16 (d, 1H,
Ar-1H).
2.1.3. (7␣)-7-Hydroxy-3-methoxyestra-1,3,5(10)-trien-17-
one cyclic 1,2-ethanediyl acetal (4)
A solution of 3 (48.4 g, crude) in tetrahydrofuran (480
ml) to a suspension of lithium aluminum hydride (25.7 g,
678 mM) in tetrahydrofuran (300 ml), was added dropwise.
The mixture was heated to reflux. After stirring for 1.5 h, the
mixture was cooled to Ϫ15°C and quenched with ethyl

R. Plate et al. / Steroids 66 (2001) 117–126
119
(s, 3H, 7-CH3), 2.33 (m, 1H, 9␣H), 2.48 (m, 1H, 8␤H), 2.72
(d, J ϭ 16 Hz, 1H, 6␣H), 2.94 (d, J ϭ 16Hz, 1H, 6␤H), 3.78
(s, 3H, Ar-OCH3), 3.92 (m, 4H, ketal), 6.64 (d, 1H, Ar-4H),
6.76 (dd, 1H, Ar-2H), 7.22 (d, 1H, Ar-1H).
into a solution of saturated sodium bicarbonate and ex-
tracted with ethyl acetate. The extract was washed succes-
sively with sodium bicarbonate, water, and brine, dried
(Na2SO4), and evaporated to dryness. The residue was crys-
tallized (dichloro methane/acetone) to give 10 (1.07 g, 3.5
mM, 56%) as white crystals; m.p. 247°C. Rf 0.8 [ethanol/
ethyl acetate (1:1 v/v)]. 1H NMR: (CDCl3, 600 MHz) ␦ 0.90
(s, 3H, 18-CH3), 1.28 (m, 1H, 11␤H), 1.31 (m, 1H, 12␣H),
1.36 (s, 3H, 7-CH3), 1.53 (m, 1H, 2␤H), 1.80 (m, 1H,
12␤H), 1.81 (m, 1H, 14␣H), 1.82 (m, 1H, 6␣H), 1.82 (m,
1H, 15␤H), 1.83 (m, 1H, 4␤H), 1.89 (m, 1H, 9␣H), 1.91 (m,
1H, 2␣H), 1.97 (m, 1H, 1␤H), 2.08 (m, 1H, 11␣H), 2.11 (m,
1H, 16␣H), 2.16 (m, 1H, 1␣H), 2.21 (m, 1H, 4␣H), 2.24 (m,
1H, 6␤H), 2.30 (m, 1H, 15␣H), 2.45 (m, 1H, 16␤H), 3.85
(m, 1H, 3␤H). 13C-NMR (CDCl3, 150 MHz) 14.6 (q, 18-
CH3), 25.1 (t, C11), 25.4 (t, C15), 26.3 (t, C1), 29.5 (q,
7-CH3), 31.8 (t, C2), 31.9 (t, C12), 36.0 (t, C16), 39.3 (t,
C4), 43.3 (d, C9), 46.6 (d, C8), 46.6 (d, C14), 47.9 (t, C6),
49.4 (s, C13), 67.1 (d, C3), 71.0 (s, C7), 123.4 (s, C5), 129.2
(s, C10), 222.2 (s, C17).
2.1.6. (7␣)-7-Hydroxy-3-methoxy-7-methylestra-2,5(10)-
dien-17-one cyclic 1,2-ethanediyl acetal (7)
Lithium metal (1.1 g, 158 mM) was cut into small pieces
and dissolved in liquid ammonia (90 ml). After stirring for
0.5 h at Ϫ65°C, a solution of 6 (4.53 g, 11.67 mM) in
tetrahydrofuran (45 ml) was added dropwise. After stirring
at Ϫ35°C for 4.5 h, ethanol (40 ml) was added. After
evaporation of the ammonia, the reaction mixture was
poured into a saturated ammonium chloride solution and
extracted with ethyl acetate. The extract was washed suc-
cessively with sodium bicarbonate, water, and brine. The
organic layer was dried (Na2SO4) and evaporated to dryness
to give 7 (4.83 g, 100% crude). Rf 0.45 [heptane/ethyl
1
acetate (1:1 v/v)]. H NMR: (CDCl3, 400 MHz) ␦ 0.88 (s,
3H, 18CH3), 1.31 (s, 3H, 7-CH3), 3.54 (s, 3H, 3-OCH3),
3.90 (m, 4H, ketal), 4.64 (m, 1H, 2-H).
2.1.10. (3␣,7␣,17␣)-7-Methyl-19-norpregn-5(10)-en-20-
yne-3,7,17-diol (11)
2.1.7. (7␣)-7-Hydroxy-7-methylestr-5(10)-ene-3,17-dione
cyclic 17-(1,2-ethanediyl acetal) (8)
Acetylene gas was passed through a suspension of po-
tassium tert-butoxide (1.49 g, 13.3 mM) in tetrahydrofuran
(5 ml) at 0°C. After 0.5 h, a suspension of 10 (0.9 g, 2.96
mM) in tetrahydrofuran (10 ml) was added, and the mixture
was stirred for 1 h at 0°C. Then, nitrogen was passed
through the suspension. The reaction mixture was extracted
with ethyl acetate, the extract was washed successively with
sodium bicarbonate and brine, dried (Na2SO4) and evapo-
rated to dryness. Purification by column chromatography
[methylene chloride/acetone (8:2)], followed by crystalliza-
tion from ethyl acetate/acetone gave 11 (580 mg, 1.76 mM,
59%), m.p. 197°C. 1H NMR: (CDCl3, 400 MHz) ␦ 0.86 (s,
3H, 18-CH3), 1.23 (m, 1H, 11␤H), 1.27 (s, 3H, 7-CH3), 1.41
(m, 1H, 8␤H), 1.51 (m, 1H, 2␤H), 1.60 (m, 1H, 12␤H), 1.63
(m, 1H, 15␤H), 1.77 (m, 1H, 6␣H), 1.78 (m, 1H, 12␣H),
1.83 (m, 1H, 4␤H), 1.87 (m, 1H, 9␣H), 1.93 (m, 1H, 2␣H),
1.96 (m, 1H, 16␤H), 1.97 (m, 1H, 14␣H) 1.98 (m, 1H,
1␤H), 1.98 (m, 1H, 15␣H), 2.05 (m, 1H, 11␣H), 2.17 (m,
1H, 1␣H), 2.19 (m, 1H, 4␣H), 2.19 (m,1H, 6␤H), 2.25 (m,
1H, 16␣H), 2.58 (s, 1H, C ϵ CH), 3.83 (m, 1H, 3␤ H).
13C-NMR (CDCl3, 100 MHz) 13.5 (q, 18-CH3), 25.7 (t,
C11), 26.6 (t, C15), 26.9 (t, C1), 29.9 (q, 7-CH3), 32.3 (t,
C2), 33.2 (t, C12), 39.1 (t, C16), 39.7 (t, C4), 43.1 (d, C9),
45.4 (d, C14), 47.7 (d, C8), 48.1 (t, C6), 49.0 (s, C13), 67.6
(d, C3), 71.6 (s, C7), 74.4 (d, C-H ϵCH), 78.9 (s, C17),
88.0 (s, CϵCH), 123.5 (s, C5), 129.8 (s, C10). Exact mass
calculated for [MϩHϩGlyc.]ϩ is 423.2747, Found:
423.2745.
Oxalic acid (1.17 g, 13.0 mM) was added to a solution of
7 (4.83 g, crude) in acetone (120 ml) and water (30 ml).
After stirring for 6 h, the mixture was poured into a satu-
rated solution of sodium bicarbonate and extracted with
ethyl acetate. The extract was washed successively with
sodium bicarbonate, water, and brine. The organic layer was
dried (Na2SO4) and evaporated to dryness to give the crude
product. Purification by column chromatography [heptane/
ethyl acetate (1:1)] gave 8 (2.21 g, 6.4 mM, 49%). Rf 0.3
[heptane/ethyl acetate (4:6 v/v)].1H NMR: (CDCl3, 400
MHz) ␦ 0.89 (s, 3H, 18CH3), 1.32 (s, 3H, 7-CH3), 2.65 (d,
1H, 4-H), 2.78 (d, 1H, 4-H), 3.92 (m, 4H, ketal).
2.1.8. (3␣,7␣)-3,7-Dihydroxy-7-methylestr-5(10)-en-17-
one cyclic 1,2-ethanediyl acetal (9)
A suspension of lithium tri-tert-butoxy aluminum hy-
dride (3.69 g, 14.52 mM) in THF (30 ml) was added drop-
wise to a solution of 8 (2.21 g, 6.3 mM) in THF (20 ml)
under nitrogen and at room temperature. After 3 h, the
reaction mixture was poured into saturated ammonium chlo-
ride solution and extracted with ethyl acetate. The extract
was washed successively with water, brine and dried
(Na2SO4), and evaporated to dryness to give 9 (2.18 g, 6.3
mM, 98%). Rf 0.2 [heptane/ethyl acetate (2:8 v/v)].1H
NMR: (CDCl3, 400 MHz) ␦ 0.88 (s, 3H, 18CH3), 1.29 (s,
3H, 7-CH3), 3.83 (m, 1H, 3␤H), 3.92 (m, 4H, ketal).
2.1.9. (3␣,7␣)-3,7-Dihydroxy-7-methylestr-5(10)-en-17-
one (10)
Hydrochloric acid (5 ml of a 0.1N HCl solution) was
added to a solution of 9 (2.18 g, 6.3 mM) in acetone (20 ml)
and water (2 ml). After 4 h, the reaction mixture was poured
2.1.11. (17␤ )-17-Hydroxy-3-methoxyestra-1,3,5(10)-trien-
6-one (13)
19-Nortestosterone 12 (46 g, 168 mM) and potassium
acetate (25g, 255 mM) were dissolved in dry DMF (500 ml)

120
R. Plate et al. / Steroids 66 (2001) 117–126
and heated to 120°C. The solution was stirred for 6 h
whereas oxygen gas was passed through. The reaction mix-
ture was cooled to room temperature, potassium carbonate
(138 g, 1 mol) and methyl iodide (80 ml, 1.29 mol) were
added and the solution was stirred for 18 h at room tem-
perature. The reaction mixture was poured into saturated
ammonium chloride solution and extracted with ethyl ace-
tate. The organic layer was dried (Na2SO4) and evaporated
to dryness to give the crude product that was purified by
column chromatography [silica gel, heptane/ethyl acetate
(9:1 v/v)], to give 13 (37.7 g, 125 mM, 75%). Rf 0.5
(Na2SO4) and evaporated to dryness. The crude product was
purified by column chromatography [silica gel, heptane/
ethyl acetate (9:1 v/v)] to give 15 (24 g, 56.1 mM, 63%). Rf
0.3 [heptane/ethyl acetate (9:1 v/v)]. 1H NMR: (CDCl3, 600
MHz) ␦ 0.01 (s, 6H), 0.75 (s, 3H, 18CH3), 0.90 (s, 9H), 1.09
(d, J ϭ 8 Hz, 3H, 7-CH3), 1.25 (m, 1H, 12␣H), 1.31 (m, 1H,
15␤H), 1.42 (m, 1H, 14␣H), 1.49 (m, 1H, 16␤H), 1.56 (m,
1H, 11␤H), 1.58 (m, 1H, 15␣H), 1.91 (m, 1H, 12␤H), 1.95
(m, 1H, 16␣H), 2.04 (m, 1H, 8␤H), 2.40 (m, 1H, 11␣H),
2.64 (m, 1H, 7␤H), 2.67 (m, 1H, 9␣H), 3.68 (t, 1H, 17␣H),
3.84 (s, 3H, Ar-OCH3), 7.10 (dd, 1H, Ar-2H), 7.34 (d, 1H,
Ar-1H), 7.57 (d, 1H, Ar-4H). 13C-NMR (CDCl3, 100 MHz)
␦ -4.9 (q, CH3Si), 9.7 (q, 7-CH3), 11.0 (q, C18), 18.5 (s,
C-TBDMS), 21.9 (t, C15), 25.9 (q, CH3-TBDMS), 26.1 (t,
C11), 30.6 (t, C16), 36.0 (d, C9), 36.7 (t, C12), 41.8 (d, C8),
43.1 (d, C7), 43.8 (s, C13), 45.0 (d, C14), 55.0 (q, Ar-
OCH3), 81.2 (d, C17), 109.3 (d, C4), 121.2 (d, C2), 126.6
(d, C1), 132.6 (s, C10), 139.5 (s, C5), 158.5 (s, C3), 202.4
(s, C6). Exact mass calculated for [MϩH]ϩ is 429.2825,
Found: 429.2833.
1
[heptane/ethyl acetate (1:1 v/v)]. H NMR: (CDCl3, 600
MHz) ␦ 0.79 (s, 3H, 18CH3), 1.34 (m, 1H, 14␣H), 1.34 (m,
1H, 15␤H), 1.35 (m, 1H, 12␣H), 1.50 (m, 1H, 16␤H), 1.61
(m, 1H, 11␤H), 1.68 (m, 1H, 15␣H), 1.94 (m, 1H, 8␤H),
2.02 (m, 1H, 12␤H), 2.14 (m, 1H, 16␣H), 2.21 (dd, J ϭ 13.4
Hz, 1H, 7␣H), 2.39 (m, 1H, 11␣H), 2.48 (m, 1H, 9␣H), 2.75
(dd, J ϭ 3.2 Hz, 1H, 7␤H), 3.75 (t, 1H, 17␣H), 3.75 (s, 3H,
Ar-OCH3), 7.10 (dd, 1H, Ar-2H), 7.34 (d, 1H, Ar-1H), 7.56
(d, 1H, Ar-4H). 13C-NMR (CDCl3, 150 MHz) ␦ 11.3 (q,
C18), 23.2 (t, C15), 25.9 (t, C11), 30.8 (t, C16), 36.7 (t,
C12), 40.5 (d, C8), 43.4 (d, C9), 43.5 (s, C13), 44.4 (t, C7),
50.3 (d, C14), 55.9 (q, Ar-OCH3), 81.9 (d, C17), 110.0 (d,
C1), 122.0 (d, C4), 127.0 (d, C2), 133.8 (s, C10), 140.0 (s,
C5), 158.6 (s, C3), 198.4 (s, C6).
2.1.14. (6␣,7␣,17␤)-17-[[(1,1-Dimethylethyl)dimethyl-
silyl]oxy]-3-methoxy-7-methylestra-1,3,5(10)-trien-6-ol
(16)
Compound 15 (31 g, 72.4 mM), dissolved in dry THF
(170 ml), was added dropwise over 1 h to a suspension of
lithium aluminumhydride (11 g, 290 mM) in dry THF (120
ml). After 0.5 h of stirring at room temperature, saturated
sodium sulfate solution was added dropwise until the excess
of LiAlH4 was quenched. Water was added, and the reaction
mixture was extracted with ethyl acetate, dried (Na2SO4),
and evaporated to dryness to give 16 (32 g, 100% crude). Rf
0.2 [heptane/ethyl acetate (8:2 v/v)]. 1H NMR: (CDCl3, 200
MHz) ␦ 0.01 (d, 6H), 0.76 (s, 3H, 18CH3), 0.80 (d, J ϭ 7.2
Hz), 7-CH3) 0.90 (s, 9H), 3.66 (t, 1H, 17␣H), 3.81 (s, 3H,
Ar-OCH3), 4.87 (m, 1H, 6-H) 6.78 (dd, 1H, Ar-2H), 7.18 (d,
1H, Ar-1H), 7.20 (d, 1H, Ar-4H).
2.1.12. (17␤)-17-[[(1,1-Dimethylethyl)dimethylsilyl]oxy]-
3-methoxyestra-1,3,5(10)-trien-6-one (14)
Imidazole (26.6 g, 391 mM) was added to a solution of
13 (65.3 g, 217 mM) in methylene chloride (500 ml). tert-
Butyldimethylsilylchloride (54 g, 358 mM) was added, and
the orange reaction mixture was stirred for 4 h at room
temperature. The solution was poured into saturated ammo-
nium chloride solution, extracted with ethyl acetate, and
dried (Na2SO4). During evaporation of the solvent, the
product crystallized. The crystals were collected by filtra-
tion and dried in vacuo to give 14 (46.9 g, 113 mM, 52%).
Rf 0.85 [heptane/ethyl acetate (1:1 v/v)]. 1H NMR: (CDCl3,
200 MHz) ␦ 0.05 (d, 6H), 0.75 (s, 3H, 18CH3), 0.9 (s, 9H),
2.20 (dd, J ϭ 13.4 Hz, 1H, 7␣H), 2.74 (dd, J ϭ 3.2 Hz, 1H,
7␤H), 3.66 (t, 1H, 17␣H), 3.85 (s, 3H, Ar-OCH3), 7.10 (dd,
1H, Ar-2H), 7.34 (d, 1H, Ar-1H), 7.56 (d, 1H, Ar-4H).
2.1.15. (17␤)-17-[[(1,1-Dimethylethyl)dimethylsilyl]oxy]-
3-methoxy-7-methylestra-1,3,5(10),6-tetraene (17)
Compound 16 (20 g, 46.4 mM) was dissolved in toluene
(2 liters), and Amberlyst 15 (4 g) was added. The mixture
was heated to reflux for 5 h. The reaction mixture was
cooled to room temperature, filtered and evaporated to dry-
ness. The crude product was dissolved in methylene chlo-
ride (90 ml), and imidazole (6 g, 88 mM) was added. Then,
tert-butyldimethylsilylchloride (54 g, 358 mM) was added,
and the reaction mixture was stirred for 18 h at room
temperature. The solution was poured into water, extracted
with ethyl acetate, and washed with saturated sodium chlo-
ride solution. The organic layer was dried (Na2SO4), evap-
orated to dryness, and purified by column chromatography
[silica gel, heptane/ethyl acetate (98:2 v/v)] to give 17 (11.8
g, 28.6 mM, 67%). Rf 0.85 [heptane/ethyl acetate (8:2 v/v)].
2.1.13. (7␣,17␤)-17-[[(1,1-Dimethylethyl)dimethyl-
silyl]oxy]-3-methoxy-7-methylestra-1,3,5(10)-trien-6-one
(15)
Potassium tert-butoxide (10.3 g, 91.5 mM) was added to
a solution of 14 (37.5 g, 90.6 mM) in dimethoxyethane (500
ml). Methyl iodide (13 g, 91.5 mM), dissolved in dime-
thoxyethane (50 ml), was added to the red solution over in
30-min interval. The reaction mixture was stirred for 1 h at
room temperature. Then, the solution was poured into 2N
HCl, extracted with ethyl acetate, and washed with saturated
sodium chloride solution. The organic layer was dried

R. Plate et al. / Steroids 66 (2001) 117–126
121
1H NMR: (CDCl3, 400 MHz) ␦ 0.05 (d, 6H), 0.74 (s, 3H,
18CH3), 1.00 (s, 9H), 1.95 (s, 3H, 7-CH3), 3. 61 (t, 1H,
17␣H), 3.78 (s, 3H, Ar-OCH3), 6.20 (s, 1H, H-6), 6.56 (d,
1H, Ar-4H), 6.69 (dd, 1H, Ar-2H), 7.16 (d, 1H, Ar-1H).
lithium aluminum hydride (136 mg, 3.6 mM) in dry THF (3
ml). The reaction mixture was heated to reflux for 1.5 h.
Then, saturated sodium sulfate solution was added dropwise
until the excess of LiAlH4 was quenched. Water was added,
and the reaction mixture was extracted with ethyl acetate,
dried (Na2SO4) and evaporated to dryness to give 22 (300
mg, 0.70 mM, 93%). Data are shown below.
2.1.16. (6␤,7␤,17␤)-17-[[(1,1-Dimethylethyl)dimethyl-
silyl]oxy]-6,7-epoxy-3-methoxy-7-methylestra-1,3,5(10)-
triene (19)
Compound 17 (21g, 51 mM) was dissolved in THF (170
ml). Water (20 ml) was added, and the solution was cooled
to 0°C. N-chlorosuccinimide (6.8 g, 51 mM) was added, and
the reaction mixture was stirred for 18 h at room tempera-
ture. Then, water was added, and the solution was extracted
with ethyl acetate, dried (Na2SO4), and evaporated to dry-
ness to give crude (6␤,7␣,17␤)-7-chloro-17-[[(1,1-dimeth-
ylethyl)dimethylsilyl]oxy]-3-methoxy-7-methylestra-1,3,5
(10)-trien-6-ol 18 (Rf 0. 5 [heptane/ethyl acetate (8:2 v/v)],
which was used in the next step without further purification.
Crude 18 (25 g) was dissolved in THF (330 ml), potassium
tert-butoxide (5.7 g, 51 mM) was added, and the reaction
mixture was stirred for 1.5 h at room temperature. Then, the
solution was poured into water, extracted with ethyl acetate,
and washed with saturated sodium chloride solution. The
organic layer was dried (Na2SO4) and evaporated to dryness
to give the crude product 19 [Rf 0.6 (heptane/ethyl acetate
(8:2 v/v)]. Purification by column chromatography (silica
gel, heptane/ethyl acetate 9/1 (v/v) gave 19 (1 g, 2.3 mM,
2.1.17.2. From 20. Mesyl chloride (3.7 g, 32.6 mM) was
added to a cooled (0°C) solution of 20 (3.6 g, 8.1 mM) and
triethylamine (3.3 g, 32.6 mM) in methylene chloride (50
ml). The reaction mixture was stirred for 1.5 h at 0°C and
then for3 h at room temperature. Then, the mixture was
poured into a saturated solution of ammonium chloride,
extracted with methylene chloride, dried (Na2SO4), and
evaporated to dryness to give crude 6␣-O-mesylate 21. Rf
0.55 [heptane/ethyl acetate (8:2 v/v)]. Crude 21(5 g), dis-
solved in dry THF (45 ml), was added to a suspension of
lithium aluminum hydride (1.48 g, 39.1 mM) in dry THF
(45 ml). The reaction mixture was heated to reflux for 1.5 h.
Then, saturated sodium sulfate solution was added, drop-
wise until the excess of LiAlH4 was quenched. Water was
added and the reaction mixture was extracted with ethyl
acetate and washed with saturated sodium chloride solution.
The organic portion was dried (Na2SO4) and evaporated to
dryness to give the crude product, which was purified by
column chromatography [silica gel, heptane/ethyl acetate
(9:1 v/v)] to give 22 (1.8 g, 4.2 mM, 51%). Rf 0.35 [heptane/
ethyl acetate (8:2 v/v)] 1H NMR: (CDCl3, 400 MHz) ␦ 0.05
(d, 6H), 0.79 (s, 3H, 18CH3), 0.90 (s, 9H),1.14 (s, 3H,
7-CH3), 2.77 (d, J ϭ 16.2 Hz, 1H, 6␣H), 2.96 (d, J ϭ 16.2
Hz, 1H, 6␤H), 3. 63 (t, 1H, 17␣H), 3.77 (s, 3H, Ar-OCH3),
6.57 (d, 1H, Ar-4H), 6.73 (dd, 1H, Ar-2H), 7.20 (d, 1H,
Ar-1H).
1
5%) H NMR: (CDCl3, 400 MHz) ␦ 0.05 (d, 6H), 0.67 (s,
3H, 18CH3), 0.89 (s, 9H), 1.52 (s, 3H, 7-CH3), 3.4 (s, 1H,
H-6), 3. 65 (t, 1H, 17␣H), 3.81 (s, 3H, Ar-OCH3), 6.84 (dd,
1H, Ar-2H), 7.06 (d, 1H, Ar-2H), 7.17 (d, 1H, Ar-1H).
Further elution gave an additional 4 g of a more polar
compound, characterized as (6␣,7␤,17␤)-17-[[(1,1-
dimethylethyl)dimethylsilyl]oxy]-3-methoxy-7-methylestra-
1,3,5(10)-triene-6,7-diol 20 (4g, 9.0 mM, 20%). Rf 0.15 [hep-
1
tane/ethyl acetate (8:2 v/v)]. H NMR: (DMSO, 600 MHz) ␦
0.01 (s, 6H), 0.71 (s, 3H, 18CH3), 0.83 (s, 3H, 7-CH3), 0.86 (s,
9H) 1.19 (m, 1H, 12␣H), 1.30 (m, 1H, 16␤H), 1.33 (m, 1H,
14␣H), 1.38 (m, 1H, 11␤H), 1.65 (m, 1H, 15␤H), 1.72(m, 1H,
12␤H), 1.81 (m, 1H, 15␣H), 1.82 (m, 1H, 16␣H), 1.88 (m, 1H,
8␤H), 2.11 (m, 1H, 9␣H), 2.28 (m, 1H, 11␣H), 3.61 (t, 1H,
17␣H), 3.70 (s, 3H, Ar-OCH3), 3.90 (d, 1H, H6) 6.76 (d, 1H,
Ar-4H), 6.78 (dd, 1H, Ar-2H), 7.20 (dd, 1H, Ar-1H). 13C-NMR
(CDCl3, 100 MHz) ␦ -4.8 (q, CH3Si), 11.7 (q, C18), 18.2 (s,
C-TBDMS), 18.8 (q, 7-CH3), 25.9 (q, CH3-TBDMS), 26.1 (t,
C15), 27.5 (t, C11), 31.3 (t, C16), 37.6 (t, C12), 41.6 (d, C8), 43.2
(d, C9), 45.0 (s, C13), 45.6 (d, C14), 55.5 (q, Ar-OCH3), 73.6 (s,
C7), 77.1 (d, C6), 81.6 (d, C17), 115.4 (d, C2), 115.7 (d, C4),
127.7 (d, C1), 131.2 (s, C10), 137.4 (s, C5), 158.5 (s, C3).
2.1.18. (7␤,17␤)-3-Methoxy-7-methylestra-1,3,5(10)-tri-
ene-7,17-diol (23)
Hydrochloric acid (2N, 3.5 ml) was added to a solution
of 22 (1.75 g, 4.1 mM) in acetone (25 ml), and the reaction
mixture was stirred at room temperature for 5 h. Aqueous
sodium bicarbonate was added, and the solution was ex-
tracted with ethyl acetate. The organic portion was dried
(Na2SO4) and evaporated to dryness to give the crude prod-
uct, which was purified by column chromatography [silica
gel, heptane/ethyl acetate (9:1–7:3 v/v)] to give 23 (1.15 g,
3.63 mM, 89%). Rf 0.2 [heptane/ethyl acetate (1:1 v/v)]. 1H
NMR: (CDCl3, 600 MHz) ␦ 0.81 (s, 3H, 18-CH3), 1.14 (s,
3H, 7-CH3), 1.28 (m, 1H, 12␣H), 1.40 (m, 1H, 14␣H), 1.48
(m, 1H, 16␤H), 1.55 (m, 1H, 11␤H), 1.72 (m, 1H, 8␤H),
1.75 (m, 1H, 15␤H), 1.88 (m, 1H, 15␣H), 1.94 (m, 1H,
12␤H), 2.10 (m, 1H, 16␣H), 2.28 (m, 1H, 9␣H), 2.35 (m,
1H, 11␣H), 2.78 (d, J ϭ 16.2 Hz, 1H, 6␣H), 2.97 (d, J ϭ
16.2 Hz, 1H, 6␤H), 3.70 (t, 1H, 17␣H), 3.77 (s, 3H, Ar-
OCH3), 6.57 (d, 1H, Ar-4H), 6.74 (dd, 1H, Ar-2H), 7.19 (d,
2.1.17. (7␤,17␤)-17-[[(1,1-Dimethylethyl)dimethyl-
silyl]oxy]-3-methoxy-7-methylestra-1,3,5(10)-trien-7-ol
(22)
2.1.17.1. From 19. Compound 19 (320 mg, 0.75 mM),
dissolved in dry THF (3 ml), was added to a suspension of

122
R. Plate et al. / Steroids 66 (2001) 117–126
1H, Ar-1H). 13C-NMR (CDCl3, 150 MHz) 11.7 (q, 18-
CH3), 21.5 (q, 7-CH3), 26.2 (t, C15), 28.1 (t, C11), 31.1 (t,
C16), 37.5 (t, C12), 43.8 (d, C9) 44.7 (s, C13), 46.8 (d,
C14), 48.0 (t, C6), 48.5 (d, C8), 55.6 (q, Ar-OCH3), 72.6 (s,
C7), 81.7 (d, C17) 112.7 (d, C4), 113.9 (d, C2), 127.4 (d,
C1), 130.5 (s, C10), 136.9 (s, C5), 158.1 (s, C3).
cyclic 1,2-ethanediyl acetal 27 (770 mg, crude), Rf 0.3 [hep-
tane/ethyl acetate (8:2 v/v)]. 27 (770 mg, crude), dissolved in
dry THF (7 ml), was added to a suspension of lithium alumi-
num hydride (569 mg, 15 mM) in dry THF (15 ml). The
reaction mixture was heated to reflux for 0.5 h. Then, saturated
sodium sulfate solution was added dropwise until the excess of
LiAlH4 was quenched. Water was added, and the reaction
mixture was extracted with ethyl acetate and washed with
saturated sodium chloride solution. The organic portion was
dried (Na2SO4) and evaporated to dryness to give the crude
product, which was purified by column chromatography [silica
gel, heptane/ethyl acetate 8/2 (v/v)] to give 28 (280 mg, 0.78
mM, 26%), Rf 0.1 [heptane/ethyl acetate (8:2 v/v)]. 1H NMR:
(CDCl3, 400 MHz) ␦ 0.94 (s, 3H, 18CH3), 1.18 (s, 3H, 7-CH3),
2.77 (d, J ϭ 16 Hz, 1H, 6␣H), 2.97 (d, J ϭ 16 Hz, 1H, 6␤H),
3.77 (s, 3H, Ar-OCH3), 3.92 (m, 4H, ketal) 6.57 (d, 1H,
Ar-4H), 6.73 (dd, 1H, Ar-2H), 7.21 (d, 1H, Ar-1H).
2.1.19. (7␤)-7-Hydroxy-3-methoxy-7-methylestra-1,3,5(10)-
trien-17-one (24)
Compound 23 (1.15 g, 3.6 mM) and N-methylmorpho-
line-N-oxide (1.1 g, 9.5 mM) were dissolved in acetone (50
ml). A catalytic amount of tetra-n-propylammonium perru-
thenate(VII) (70 mg, 0.2 mM) was added, and the reaction
mixture was stirred for 1.5 h at room temperature. The
solution was filtered over dicalite, rinsed with ethyl acetate,
evaporated to dryness, and filtered over a short silica gel
column using heptane/ethyl acetate (8:2 v/v) as eluent to
give 24 (1.0 g, 3.2 mM 88%). Rf 0.3 [heptane/ethyl acetate
1
2.1.21. (7␤)-7-Hydroxy-7-methylestr-5(10)-ene-3,17-dione
cyclic 17-(1,2-ethanediyl acetal) (30)
(1:1 v/v)]. H NMR: (CDCl3, 400 MHz) ␦ 0.96 (s, 3H,
18CH3), 1.21 (s, 3H, 7-CH3), 2.82 (d, J ϭ 16 Hz, 1H, 6␣H),
3.01 (d, J ϭ 16 Hz, 1H, 6␤H), 3.78 (s, 3H, Ar-OCH3), 6.58
(d, 1H, Ar-4H), 6.74 (dd, 1H, Ar-2H), 7.21 (d, 1H, Ar-1H).
Ammonia (ca. 20 ml) was condensed in a three-necked
flask equipped with a thermometer, dry ice cooler and ad-
dition funnel. Lithium (342 mg, 49 mM) was added, and the
blue solution was stirred for 20 min at Ϫ78°C. 28 (280 mg,
0.78 mM) dissolved in THF (5 ml), was added to the blue
solution over a 5 min interval. The dry ice bath was re-
moved, and the reaction mixture was refluxed at Ϫ35°C for
3 h. Then, isopropanol ( Ϯ 10 ml) was added over 15 min
until the color of the reaction mixture changed from blue to
white. The excess ammonia evaporated upon standing, wa-
ter was added, and the reaction mixture was extracted three
times with ethyl acetate. The organic layers were combined,
washed with saturated sodium chloride solution, dried
(Na2SO4), and evaporated to dryness to give (7␤)-7-Hy-
droxy-3-methoxy-7-methylestra-2,5(10) -dien-17-dione cy-
clic (1,2-ethanediyl acetal) 29 (258 mg, 0.72 mM, 92%), Rf
0.5 [heptane/ethyl acetate (1:1 v/v)]. 29 (256 mg, 0.71 mM)
was dissolved in methylene chloride (3 ml) and SiO2 (49
mg) was added. Then, a solution of oxalic acid (63 mg, 0.7
mM) and 1 drop of water in methanol (1 ml) was added, and
the reaction mixture was stirred for 15 min at room tem-
perature. The suspension was filtered and rinsed with meth-
ylene chloride, and the filtrate was washed successively
with saturated NaHCO3 solution and saturated sodium chlo-
ride solution. The organic layer was dried (Na2SO4) and
evaporated to dryness to give 240 mg of a 1/1 mixture of 30,
Rf 0.25 [heptane/ethyl acetate (1:1 v/v)], and (7␤)-7-hy-
droxy-7-methylestr-5(10)-ene-3,17-dione 31, Rf 0.15 [hep-
tane/ethyl acetate (1:1 v/v)]. This mixture was used in the
next step without further purification.
2.1.20. (7␤)-7-Hydroxy-3-methoxy-7-methylestra-1,3,5(10)-
trien-17-one cyclic 1,2-ethanediyl acetal (28)
Compound 24 (1 g, 3.2 mM), ethylene glycol (4 ml), and
p-toluenesulfonic acid (30 mg) were dissolved in triethylortho-
formate (7 ml) and stirred for 30 min at 60°C. Water was
added, and the mixture was extracted with ethyl acetate and
washed successively with water and saturated sodium chloride
solution. The organic portion was dried (Na2SO4), evaporated
to dryness, and filtered over a short silica gel column using
heptane/ethyl acetate 9/1 (v/v) as eluent to give crude 3-me-
thoxy-7-methylestra-1,3,5(10),6-tetraen-17-one cyclic 1,2-
ethanediyl acetal 25, Rf 0.85 [heptane/ethyl acetate (8:2 v/v)].
25 (1 g, crude) was dissolved in THF (10 ml). Water (1 ml)
was added, and the solution was cooled to 0°C. N-Chlorosuc-
cinimide (400 mg, 3 mM) was added, the ice bath was re-
moved, and the reaction mixture was stirred for 18 h at room
temperature. Then, water was added, and the solution was
extracted with ethyl acetate, dried (Na2SO4), and evaporated to
dryness to give crude (6␤,7␣)-7-chloro-6-hydroxy-3-methoxy-
7-methylestra-1,3,5(10)-trien-17-one cyclic 1,2-ethanediyl ac-
etal 26 (Rf 0.15 [heptane/ethyl acetate (8:2 v/v)], which was
used in the next step without further purification. Crude 26 (1.2
g) was dissolved in THF (20 ml), potassium tert-butoxide (337
mg, 3 mM) was added and the reaction mixture was stirred for
1 h at room temperature. Then, another portion potassium
tert-butoxide (300 mg, 2.7 mM) was added, and the reaction
mixture was stirred for another hour. The solution was poured
into water, extracted with ethyl acetate, and washed with sat-
urated sodium chloride solution. The organic layer was dried
(Na2SO4) and evaporated to dryness to give crude (6␤,7␤)-
6,7-epoxy-3-methoxy-7-methylestra-1,3,5(10) -trien-17-one
2.1.22. (3␣,7␤)-3,7-Dihydroxy-7-methylestr-5(10)-en-17-
one (34)
Lithium tri-tert-butoxy aluminum hydride (406 mg, 1.6
mM) in THF (4 ml) was added dropwise to a solution of 30

R. Plate et al. / Steroids 66 (2001) 117–126
123
and 31 (240 mg, 0.7 mM) dissolved in THF (4 ml). The
reaction mixture was stirred for 1.5 h at room temperature,
poured into saturated ammonium chloride solution, and
extracted two times with ethyl acetate. The combined or-
ganic layers were washed successively with water and sat-
urated sodium chloride solution, dried (Na2SO4), and evap-
orated to dryness to give 236 mg of a 1/1 mixture of
(3␣,7␤)-3,7-Dihydroxy-7-methylestr-5(10)-en-17-one cy-
clic 1,2-ethanediyl acetal 33, Rf 0.55 (ethyl acetate), and
(3␣,7␤,17␤)-7-methylestr-5(10)-ene-3,7,17-triol 32, Rf 0.4
(ethyl acetate). This mixture was dissolved in acetone (5
ml), and a 0.1 N HCl (0.5 ml) solution was added. The
solution was stirred for 5 h at room temperature, saturated
sodium bicarbonate solution was added, and the mixture
was extracted with ethyl acetate. The organic layer was
dried (Na2SO4) and evaporated to dryness to give the crude
product mixture, which was separated by column chroma-
tography [silica gel, toluene/ethanol 95/5 (v/v)] to give 34
(75 mg, 0.25 mM, 37%), Rf 0.35 [toluene/ethanol (8:2 v/v)].
1H NMR: (CD3OD, 400 MHz) ␦ 0.92 (s, 3H, 18-CH3), 1.11
(s, 3H, 7-CH3), 3.70 (m, 1H, 3␤H), exact mass calculated
for [MϩH]ϩ is 305.2117, Found: 305.2090, and 32 (25 mg,
0.08 mM, 12%), Rf 0.2 [toluene/ethanol (8:2 v/v)], m.p.
MHz) ␦ 0.86 (s, 3H, 18-CH3), 1.03 (s, 3H, 7-CH3), 1.19 (m,
1H, 11␤H), 1.38 (m, 1H, 2␤H), 1.52 (t, 1H, 8␤H), 1.58 (m,
1H, 9␣H),1.61 (m, 1H, 12␤H), 1.73 (m, 1H, 15␤H), 1.78
(m, 1H, 4␤H), 1.82 (m, 1H, 12␣H), 1.83 (dd, 1H, 6␣H),
1.86 (m, 1H, 14␣H), 1.90 (m, 1H, 15␣H), 1.90 (m, 1H,
16␤H), 1.92 (m, 1H, 1␤H), 1.92 (m, 1H, 2␣H), 1.99 (m, 1H,
11␣H), 2.13 (m, 1␣H), 2.13 (dd, 1H, 6␤H), 2.15 (m, 1H,
4␣H), 2.20 (m, 1H, 16␣H), 2.87 (s,1H, CϵCH), 3.7 (m, 1H,
3␤H). 13C-NMR (CD3OD, 150 MHz) 13.9 (q, 18-CH3),
20.8 (q, 7-CH3), 26.3 (t, C15), 27.4 (t, C11), 28.6 (t, C1),
33.7 (t, C2), 34.8 (t, C12), 40.6 (t, C16), 41.1 (t, C4), 47.0
(d, C9), 47.6 (d, C14), 49.3 (s, C13), 49.5 (d, C8), 49.6 (t,
C6), 68.5 (D, C3), 73.0 (t, C7), 75.1 (d, ϵCH), 80.2 (s,
C17), 89.4 (s, Cϵ), 126.4 (s, C5), 130.0 (s, C10). Exact
mass calculated for [MϩHϩGlyc.]ϩ is 423.2747, Found:
423.2748.
3. Results and discussion
Here, we describe our approaches toward the synthesis of
the 7-␤-hydroxy metabolite of Org OD 14, 35, as well as its
isomeric 7-␣-hydroxy derivative 11.
1
202°C. H NMR: (CD3OD, 400 MHz) ␦ 0.78 (s, 3H, 18-
CH3), 1.03 (s, 3H, 7-CH3), 1.10 (m, 1H, 12␣H), 1.20 (m,
1H, 11␤H), 1.29 (m, 1H, 14␣H), 1.36 (m, 1H, 2␣H), 1.42
(m, 1H, 16␤H), 1.53 (t, 1H, 8␤H), 1.60 (m, 1H, 9␣H), 1.67
(m, 1H, 15␤H), 1.77 (m, 1H, 4␣H), 1.82 (m, 1H, 6␣H), 1.83
(m, 1H, 12␤H), 1.85 (m, 1H, 15␣H), 1.90 (m, 1H, 1␣H),
1.92 (m, 1H, 2␤H), 1.93 (m, 1H, 11␣H), 1.95 (m, 1H,
16␣H), 2.11 (m, 1␤H), 2.12 (m, 1H, 6␤H), 2.14 (m, 1H,
4␤H), 3.58 (t, 1H, 17␣H), 3.70 (m,1H, 3␤H). 13C-NMR
(CD3OD, 100 MHz) 12.2 (q, 18-CH3), 20.7 (q, 7-CH3), 26.7
(t, C15), 27.2 (t, C11), 31.3 (t, C16), 33.6 (t, C2), 38.4 (t,
C1), 38.8 (t, C12), 40.9 (t, C4), 45.8 (s, 13C), 47.9 (d, C14),
48.4 (d, C9), 48.6 (d, C8), 49.7 (t, C6), 68.9 (d, C3), 72.9 (s,
C7), 82.6 (d, C17), 126.4 (s, C5), 130.1 (s, C10). Exact mass
calculated for [MϩHϩGlyc.]ϩ is 399.2747, Found:
399.2740.
3.1. Synthesis of (3␣,7␣,17␣ )-7-methyl-19-norpregn-
5(10)-en-20-yne-3,7,17-triol (11)
In our first approach toward 7-hydroxy Org OD 14 de-
rivatives, a synthetic route via the key intermediate 5 was
elaborated commencing with the ⌬6-estrone derivative 1
(Scheme 2). Ketalization of the readily available starting
material 1 gave the corresponding 17-acetal 2. Epoxidation
of the ⌬6-double bond, using 3-chloro-peroxybenzoic acid
as a reagent, gave the (6␣,7␣)-6,7-epoxy-3-methoxyestra-
1,3,5(10)-trien-17-one cyclic 1,2-ethanediyl acetal (3). Ring
opening of the epoxy function, using lithium aluminum
hydride as a reagent, gave the (7␣)-7-hydroxy-3-me-
thoxyestra-1,3,5 (10)-trien-17-one cyclic 1,2-ethanediyl ac-
etal (4). Oxidation of 4, using the Jones reagent, gave the
desired
17,17-ethylenedioxy-3-methoxyestra-1,3,5(10)-
2.1.23. (3␣,7␤,17␣ )-7-Methyl-19-norpregn-5(10)-en-20-
yne-3,7,17-triol (35)
trien-7-one (5) in moderate yield. Attempts to introduce a
methyl group at the 7-keto position of derivative 5, either
using methyllithium or methylmagnesium chloride as re-
agents, failed in that no reaction occurred. This failure may
be attributed to complete enolization of the keto function
under these conditions. Application of a modified method
[6] gave the desired addition product 17,17-ethylenedioxy-
3-methoxy-7␤-methylestra-1,3,5(10)-trien-7␣-ol (6) in 55%
yield. The stereochemistry observed (7␣-OH, 7␤-Me) was
surprising and could not be rationalized with the Felkin–
Anh principle [7,8]. Birch reduction of 6 gave 7, which
upon mild, selective hydrolysis, gave 17,17-ethylenedioxy-
7␣-hydroxy-7␤-methylestr-5(10)-en-3-one (8). Reduction
of the 3-ketofunction of 8, using lithium tri-tert-butoxy
aluminum hydride as a reagent, gave the 3␣-hydroxy deriv-
ative 9. Finally, deprotection of the 17-ketal function, gave
Potassium tert-butoxide (258 mg, 2.3 mM) was dis-
solved in dry THF (3 ml). The solution was cooled to 0°C
and stirred for 30 min whereas nitrogen was passed through.
Then, although the temperature was kept at 0°C, acetylene
was passed through the solution for 1 h. 34 (70 mg, 0.23
mM), dissolved in THF (3 ml), was added to the white
suspension, and the reaction mixture was stirred for 1 h at
0°C. Then, the yellow suspension was poured into saturated
ammonium chloride solution and extracted with ethyl ace-
tate. The organic layer was dried (Na2SO4) and evaporated
to dryness to give the crude product, which was purified by
column chromatography [silica gel, toluene/ethanol 95/5
(v/v)] to give 35 (40 mg, 0.12 mM, 53%), Rf 0.3 [toluene/
ethanol (8:2 v/v)], m.p. 175°C. 1H NMR: (CDCl3, 600

124
R. Plate et al. / Steroids 66 (2001) 117–126
Scheme 3. a) 1: O2, KOAc, DMF, 120°C; 2: CH3I, K2CO3, RT, 75%; b)
TBDMS-Cl, CH2Cl2, 52%; c) KOtBu, CH3I, DME, RT, 63%; d) LiAlH4,
THF, RT, 100%; e) 1: Amberlyst 15, toulene, reflux; 2: TBDMS-Cl,
CH2Cl2, 67%; f) N-chlorosuccinimide, THF, H2O; g) KOtBu, THF; h)
column chromatography; i) Mesylchloride, TEA, CH2Cl2; j) LiAlH4, THF,
22 from 19 93%, 22 from 20 51%; k) 2n HCl, acetone, 90%.
Scheme 2. a) glycol, PTSA, TEOF (95%) b) mCPBA, EtOAc (90%); c)
LiAlH4, THF (50%); d) CrO3, acetone (55%); e) CeCl3, CH3MgCl, THF
(55%); f) Li, NH3, THF (90%); g) oxalic acid, acetone, water (50%); h)
Li(tert-BuO)3AlH, THF (80%); i) HCl, acetone (85%); j) ethyne, KOtBu
(62%).
10, which upon ethynylation, gave the desired (3␣,7␣,17␣)-
7-methyl-19-norpregn-5(10)-en-20-yne-3,7,17-triol (11).
of the attack of the intermediate formed carbocation at the
6-position with the A-ring aromat. Reaction of the ⌬6-
double bond of 17 with N-chlorosuccinimide in aqueous
THF gave 17␤-(tert-butyldimethylsilyl)oxy-7␣-chloro-3-
methoxy-7␤-methyl-estra-1,3,5(10)-trien-6␤-ol (18). Ring
closure of 18 gave the 17␤-(tert-butyldimethylsilyl)oxy-3-
methoxy-7␣-methyl-6␤,7␤-epoxyestra-1,3,5(10)-triene
(19). In small-scale experiments, the epoxide 19 was iso-
lated after column chromatography in 30% yield. In larger
scale experiments, only 5% of 19 was isolated, whereas the
major portion of the epoxide underwent ringopening during
column chromatography to give 17␤-(tert-
butyldimethylsilyl)oxy-3-methoxy-7␣-methyl-estra-
1,3,5(10)-trien-6␣,7␤-diol (20). Epoxide 19 was found to be
unstable at room temperature. Reduction of the epoxide
function of 19, using lithium aluminum hydride as a re-
agent, gave 17␤-(tert-butyldimethylsilyl)oxy-3-methoxy-
7␣-methylestra-1,3,5(10)-trien-7␤-ol (22). Alternatively, 22
was prepared from 20 by mesylation and subsequent reduc-
tion of 21. Deprotection of 22 gave 3-methoxy-7␣-
methylestra-1,3,5(10)-trien-7␤,17␤-diol (23).
3.2. Synthesis of (3␣,7␤,17␣ )-7-methyl-19-norpregn-
5(10)-en-20-yne-3,7,17-triol (35)
In our second approach toward 7-hydroxy Org OD 14
derivatives, a route commencing with 17␤-hydroxyestr-4-
en-3-one (12, 19-nortestosterone) was devised (Scheme 3)
[9]. The oxidation of 12 with oxygen in dimethylform-
amide, followed by in situ methylation with methyliodide,
gave
17␤-hydroxy-3-methoxyestra-1,3,5(10)-trien-6-one
(13). Protection of the 17-hydroxy function of 13 with the
tert-butyldimethylsilyl group gave 17␤-(tert-butyldimethyl-
silyl)oxy-3-methoxyestra-1,3,5(10)-trien-6-one (14). Selec-
tive methylation at the 7-position, using methyliodide in
dimethoxyethane as a reagent, gave 17␤-(tert-butyldimeth-
ylsilyl)oxy-3-methoxy-7␣-methyl-estra-1,3,5(10)-trien-6-
one (15). Reduction of the keto function of 15 with lithium
aluminum hydride gave 17␤-(tert-butyldimethylsilyl)oxy-3-
methoxy-7␣-methyl-estra-1,3,5(10)-trien-6␣-ol (16). Dehy-
dration of 16 into 17␤-(tert-butyldimethylsilyl)oxy-3-me-
thoxy-7-methylestra-1,3,5(10),6-tetraene (17) was carried
out using Amberlyst 15 in refluxing toluene at high dilution.
This was necessary to prevent the formation of dimers e.g.
these dimers are formed in concentrated solution as a result
Oxidation of 23, using N-methylmorpholine N-oxide
and a catalytic amount of tetra-n-propylammonium perru-
thenate (VII) as reagents, gave 7␤-hydroxy-3-methoxy-7␣-
methylestra-1,3,5(10)-trien-17-one (24) (Scheme 4). Ketal-
ization of 24, at 60°C using ethylene glycol and a catalytic

R. Plate et al. / Steroids 66 (2001) 117–126
125
Scheme 4. 1) NMO, TPAP, acetone, 80%; m) glycol, PTSA, TEOF; n) N-chlorosuccinimide; THF, H2O; o) KOtBu, THF; p) LiAlH4, THF, 28 from 25 26%;
q) Li, NH3, THF, 92%; r) oxalic acid, SiO2, MeOH, H2O, CH2Cl2; s) Li(tert-BuO)3A1H, THF; t) 0.1N HCl, acetone, 34 37%; u) ethyne, KOtBu, 52%.
amount of p-toluene sulfonic acid in triethylorthoformate as
reagents, led to the undesired elimination of the 7-hydroxy
moiety and gave a mixture of 17,17-ethylenedioxy-3-me-
thoxy-7-methyl-estra-1,3,5(10),6-tetraene (25), the 7-exom-
ethylene derivative, and other alkenes. Because of the ob-
served liability of the reaction intermediates (viz. 17 3 19),
the alkene 25 was converted into the 7␣-chloro-17,17-ethyl-
enedioxy-3-methoxy-7␤-methyl-estra-1,3,5(10)-trien-6␤-ol
(26) 6,7␤-epoxy-17,17-ethylenedioxy-3-methoxy-7␣-meth-
yl-estra-1,3,5(10)-triene (27) and 17,17-ethylenedioxy-
3-methoxy-7␣-methyl-estra-1,3,5(10)-trien-7␤-ol (28), ac-
cording to the sequence described above. Later, the ketal-
ization of 24 into 28 was successfully carried out using
1,2-bis-((trimethylsilyl)oxy)ethane and a catalytic amount
of trimethylsilyl triflate in methylene chloride at Ϫ78°C.
Birch reduction of 28 gave 17,17-ethylenedioxy-3-me-
thoxy-7␣-methyl-estra-2,5(10)-dien-7␤-ol (29). Hydrolysis
of the ketal function of 29, using oxalic acid in the presence
of silica gel [10], gave a 1:1 mixture of 17,17-ethyl-
enedioxy-7␤-hydroxy-7␣-methyl-estra-5(10)-en-3-one (30)
and 7␤-hydroxy-7␣-methyl-estra-5(10)-diene-3,17-dione
(31). This mixture was reduced with lithium tri-tert-butoxy
aluminum hydride to 17,17-ethylenedioxy-7␣-methyl-estr-
5(10)-ene-3␣,7␤-diol (33) and 7␣-methyl-estr-5(10)-ene-
3␣,7␤,17␤-triol (32). Hydrolysis of 33 gave 7␣-methyl-
estr-5(10)-en-3␣,7␤-diol-17-one (34), and finally,
ethynylation gave the desired target molecule (3␣,7␤,17␣)-
7-methyl-19-norpregn-5(10)-en-20-yne-3,7,17-triol (35).
The pharmacological properties of the 7-hydroxy deriv-
atives of ORG OD14, namely 11 and 35, will be described
elsewhere.
Acknowledgments
We wish to thank F. Martens, R. Aspers (NMR-spec.),
and G. Schmeits (Mass-spec.) for their help in interpretation
of the spectral data.
References
[1] Tibolone (Livial). A new steroid for the menopause. Drug Ther Bull
1991;29:77–8.
[2] Moore RA. Systematic and economic review for Livial. In: Rymer J
(Ed.), Livial: A review of clinical studies. Br J Gynaecol 1999;106(3
Suppl. 19) 1.
[3] Van Vliet NP, Broess AIA, Peters JAM, van den Broek AJ, Leemhuis
JAJ, Zeelen FJ. An alternative synthesis of 17␤-hydroxy-7␣-methyl-

126
R. Plate et al. / Steroids 66 (2001) 117–126
19-nor-17␣-pregn-5(10)-en-20-yn-3-one (ORG OD14). Recl Trav
Chim Pays-Bas 1986;105:111–5.
presence of cerium chloride. J Am Chem Soc 1989;111:4392–
8.
[4] Sandker GW, Vos RME, Delbressine LPC, Slooff MJH, Meijer DKF,
Groothuis GMM. Metabolism of three pharmacologically active
drugs in isolated human and rat hepatocytes: analysis of interspecies
variability and comparison with metabolism in vivo. Xenobiotica
1994;24:143–55.
[5] Doostzadeh J Cotillon AC, Benalycherif A, Morfin R. Inhibition of
dehydroandrosterone 7␣- and 7␤-hydroxylation in mouse. Steroids
1998;63:608–14.
[7] Cherest M, Felkin H. Torsional strain involving partial bonds. The
steric course of the reaction between allyl magnesium bromide and
4-t-butyl-cyclohexanone. Tetrahedron Lett 1976:2205–8.
[8] Anh NT, Eisenstein O. Induction asymetrique 1–2: comparison ab
initio des modeles de Cram, de Conforth, de Karabatsos et de Felkin.
Tetrahedron Lett 1976:155–8.
[9] Buzby GC, Capaldi E, Douglas GH, et al. Totally synthetic steroid
hormones J Med Chem 1966;9:338–41.
[6] Imamoto T, Takiyama N, Nakamura K, Hatajima T. Kamiya Y.
Reactions of carbonyl compounds with grignard reagents in the
[10] Lui LG, Zhang T, Li Z-S. Silica gel promoted selective hydrolysis of
3-methoxy-2,5(10)-diene steroids. Synth Commun 1996;26:2999–3006.
