An optimized facile procedure to synthesize and purify allicin

Article abstract of DOI:10.3390/molecules22050770

Allicin is a reactive sulfur species (RSS) and defence substance from garlic (Allium sativum L.). The compound is a broad-spectrum antibiotic that is also effective against multiple drug resistant (MDR) strains. A detailed protocol for allicin synthesis based on diallyl-disulfide (DADS) oxidation by H₂O₂ using acetic acid as a catalyst was published in 2001 by Lawson and Wang. Here we report on improvements to this basic method, clarify the mechanism of the reaction and show that it is zero-order with respect to DADS and first-order with respect to the concentration of H₂O₂. The progress of allicin synthesis and the reaction mechanism were analyzsd by high-performance liquid chromatography (HPLC) and the identity and purity of the products was verified with LC-MS and ¹H-NMR. We were able to obtain allicin of high purity (>98%) and >91% yield, with standard equipment available in any reasonable biological laboratory. This protocol will enable researchers to prepare and work with easily and cheaply prepared allicin of high quality.

Full text of DOI:10.3390/molecules22050770

molecules
Article
An Optimized Facile Procedure to Synthesize and
Purify Allicin
Frank Albrecht 1,†, Roman Leontiev 1,2,†, Claus Jacob 2 and Alan J. Slusarenko 1,
*
1
Department of Plant Physiology, RWTH Aachen University, D-52056 Aachen, Germany;
frank.albrecht@rwth-aachen.de (F.A.); roman_leontiev@gmx.de (R.L.)
Division of Bioorganic Chemistry, School of Pharmacy, Campus B2 1, University of Saarland,
D-66123 Saarbruecken, Saarland, Germany; c.jacob@mx.uni-saarland.de
Correspondence: alan.slusarenko@bio3.rwth-aachen.de
2
*
†
These authors contributed equally to this work.
Academic Editors: Thomas J. Schmidt and Derek J. McPhee
Received: 1 March 2017; Accepted: 5 May 2017; Published: 10 May 2017
Abstract: Allicin is a reactive sulfur species (RSS) and defence substance from garlic
(Allium sativum L.). The compound is a broad-spectrum antibiotic that is also effective against multiple
drug resistant (MDR) strains. A detailed protocol for allicin synthesis based on diallyl-disulfide
(DADS) oxidation by H2O2 using acetic acid as a catalyst was published in 2001 by Lawson and Wang.
Here we report on improvements to this basic method, clarify the mechanism of the reaction and show
that it is zero-order with respect to DADS and first-order with respect to the concentration of H2O2.
The progress of allicin synthesis and the reaction mechanism were analyzsd by high-performance
liquid chromatography (HPLC) and the identity and purity of the products was verified with LC-MS
and 1H-NMR. We were able to obtain allicin of high purity (>98%) and >91% yield, with standard
equipment available in any reasonable biological laboratory. This protocol will enable researchers to
prepare and work with easily and cheaply prepared allicin of high quality.
Keywords: allicin; Allium sativum; diallyl-disulfide; catalytic oxidation; reactive sulfur species;
dipropyl-disulfide; thiosulfinate
1. Introduction
The sulfur-containing compound allicin (2-Propene-1-sulfinothioic acid S-2-propenyl ester, or
diallyl-thiosulfinate, DATS) is produced in damaged tissue of garlic (Allium sativum), ramsons
(Allium ursinum), and hooker chives (Allium hookeri) and gives these plants their typical odours [1].
Garlic is highly valued in the cuisines of many nations because of its excellent flavour and its pungent
smell. Additionally, it has long been believed that allicin, or at least garlic consumption, is beneficial to
health [
aureus and other bacteria in liquid culture [
often selectively, in mammalian cancer cells cultured in vitro
cells of yeast (Saccharomyces cerevisiae), a model fungal eucaryote [
into a highly interesting compound for clinical investigations. Stoll and Seebeck first reported the
synthesis of allicin in 1947, but without specifying experimental details [ ]. Their chemical synthesis of
2
]. In 1944 Cavallito and Bailey demonstrated that allicin inhibited the growth of Staphylococcus
]. Furthermore, allicin was shown to induce apoptosis,
], in intact tissues in vivo ], and in
]. These properties turn allicin
3
[4
,5
[6
7
8
allicin was based on the oxidation of diallyl-disulfide (DADS) by peracetic acid as a mild oxidizing
agent. A more detailed protocol of this basic method was published by Lawson and Koch in 1994
and Lawson and Wang in 2001 [9,10]. Other methods to synthesize allicin utilizing magnesium
monoperoxyphthalate [11] or chloroperbenzoic acid have also been reported [12
still challenging to obtain pure allicin in acceptable yields.
,13]. Nevertheless, it is
Molecules 2017, 22, 770; doi:10.3390/molecules22050770
www.mdpi.com/journal/molecules

Molecules 2017, 22, 770
2 of 13
In the original protocol, DADS was stirred into a mixture of acetic acid and H2O2 and incubated
at room temperature (RT) for 4 h with constant stirring. The reaction was stopped by adding
five volumes of water and extracted with dichloromethane (DCM) to retrieve allicin along with
unreacted DADS, some acetic acid, and DCM-soluble reaction byproducts. The lipophilic undissociated
acid catalyst in the DCM phase was neutralized with aqueous sodium carbonate solution which
facilitated partitioning of the hydrophilic sodium acetate generated into the aqueous phase. DCM was
removed by rotary evaporation at RT at reduced pressure to yield an oily residue of allicin, unreacted
DADS, and byproducts. Further purification of allicin was based on the differential partitioning
of the constituents of the oily residue between n-hexane and an aqueous phase (two washes).
Unreacted DADS and some allicin accumulated in the n-hexane phase, but allicin, which is more polar
than DADS, concentrated to some extent in the aqueous phase. The separation method was inefficient,
however, and allicin losses occurred at this stage. Finally, the allicin-containing aqueous phase was
partitioned against DCM to isolate allicin and dried over anhydrous CaSO4. Allicin was obtained as
an oily residue after evaporation of the DCM under reduced pressure at RT.
This synthesis consists of at least two reaction steps. Firstly, the organic peracid is formed by
oxidation of the organic acid by H2O2. Secondly, DADS is oxidized by the peracid, thus regenerating
the parent organic acid. It has been reported that peracids, such as performic and peracetic acids,
are adequately soluble in the organic phase [14], but DADS is immiscible with the aqueous H2O2
solution and the reactions therefore take place in a two phase system.
In the optimized method described in this paper we used a formic acid catalyst instead of acetic
◦
acid, which enabled us to carry out the reaction at 0 C under more controlled conditions and we
systematically varied the concentrations of the reactants, while following the progress of the reaction
using HPLC. Furthermore, we developed a silica gel column chromatography protocol for allicin
purification which avoided the losses associated with the original solvent partitioning procedure.
A reaction mechanism for Stoll and Seebeck’s synthesis was postulated by Nikolic et al. [15
]
proposing oxidative cleavage of the S–S bond in DADS by hydroxyl-radicals generated from the acidic
H2O2 to give allyl-sulfenic acid which condenses to yield allicin (Scheme 1). In contrast, an alternate
mechanism, namely direct oxidation of one of the S-atoms in DADS without oxidative cleavage of
the S–S bond, is also plausible (Scheme 1). Here we provide data supporting an oxidative cleavage
mechanism and condensation of two sulfenic acid molecules to yield allicin, but without a need
for hydroxyl-radicals.
Scheme 1. Allicin synthesis from diallyl-disulfide (DADS) through oxidation by a peracid generated
with H2O2 in the reaction mixture. The organic acid serves as an intermediate catalyst.
2. Results and Discussion
2.1. Comparison of DADS Oxidation Catalyzed by Acetic Acid or Formic Acid
Preliminary experiments substituting formic acid for acetic acid at RT resulted in rapid overheating
of the reaction mixture accompanied by massive byproduct formation, therefore, we carried out the

Molecules 2017, 22, 770
3 of 13
formic acid catalyzed allicin syntheses at 0 ◦C. The progress of the oxidation reactions was followed
by HPLC analysis; i.e., disappearance of the DADS peak and appearance of the allicin peak. In a
first attempt, we withdrew small samples of the proceeding reaction, diluted them with methanol
and measured the amount of allicin and DADS. This approach was not reliable, however, due to the
fact that the reaction mixture was an emulsion. It was, therefore, difficult, despite thorough mixing,
to guarantee the same distribution of content in withdrawn samples and the remainder of the reaction
mix in the flask. Measurements confirmed these concerns and showed unrealistic kinetics (data not
shown). Therefore, in a second approach, the reaction was carried out in several parallel aliquots on
a micro-scale and each aliquot was diluted with methanol as a whole to give a single data point. Thus,
every time point presented in Fig. 1 shows an independent parallel reaction run. Reaction progress was
followed by calculating the percentage ratio of actual allicin yield divided by the theoretical maximum
yield (100% of DADS converted to allicin) to indicate the percent conversion during the course of the
reaction. Despite the lower reaction temperature, allicin was formed more rapidly and to a greater
yield (78% conversion by 4 h) with formic acid as catalyst than with acetic acid (58% conversion at 4 h)
(Figure 1).
100
90
80
70
60
50
40
30
Acetic acid
20
Formic acid
10
0
0
1
2
3
4
5
6
7
8
time (h)
Figure 1. Kinetics of allicin synthesis. The oxidation of DADS to allicin was catalyzed by either
acetic acid at 20 ◦C or formic acid at 0 ◦C. All reactions took place in sealed 2 mL reaction tubes in
temperature-controlled rotary shakers and via continual shaking at 1200 rpm to ensure optimal mixing.
The products were separated by HPLC and quantified with a UV detector at 254 nm. Reaction progress
was followed by calculating the percentage ratio of actual allicin yield divided by the theoretical
maximum yield to indicate the percentage of conversion during the course of the reaction.
Byproducts detectable by HPLC and presumably arising via decomposition, were observed
increasingly with incubation times longer than 4 h. Quantitatively slightly lower amounts ◦of
◦
byproducts were observed at 0 C with formic acid as a catalyst than with acetic acid at 20 C
(Figure 2).
Lesser byproduct formation using formic acid at 0 ◦C as shown in Figure 2 may be explained
by allicin’s increased reactivity and inherent instability at higher temperatures. The instability of
allicin at higher temperatures was reported to be increased by hydrophobic solvents such as any
residual DADS [16]. For those reasons, the reaction should be stopped at the latest after 4 h, by adding
five volumes of H2O, even though conversion is incomplete. Furthermore, if not tempered to 20 ◦C
different RTs will lead to different kinetics for the reaction and the need for new calibrations. Therefore,

Molecules 2017, 22, 770
4 of 13
we propose that it is advantageous for reasons of increased yield and reaction consistency to use formic
acid as a catalyst and to carry out the reaction on ice at 0 ◦C.
1200
Acetic acid
1000
Formic acid
800
600
400
200
0
0
2
4
6
8
10 12 14 16 18 20 22 24 26 28 30 32 34
time (min)
Figure 2. Comparison of representative end point traces of the products of routine allicin syntheses
with either acetic or formic acids.
2.2. Reaction Order with Respect to Individual Reactants
The kinetics shown in Figure 1 not only reveal a faster reaction when formic acid is used as
a catalyst, but also give information about the reaction order. Thus, after 2 h—48%, after 4 h—76% and
after 6 h—90% of the DADS was converted to allicin. This is an approximate halving of the amount of
DADS every 2 h indicating that the overall reaction followed first order kinetics. We investigated the
reaction kinetics in more detail and showed that the shaking conditions for the two phase reaction
were a limiting factor for the reaction speed (Figure 3). The reaction rate can be seen to increase
proportionally up to 1200 rpm, which was thus chosen as the routine shaking velocity for micro-scale
synthesis reactions.
30
25
20
15
10
5
0
0
500
1000
1500
shaking velocity (rpm)
Figure 3. The effect of shaking velocity on the reaction rate. Micro-scale reactions using a pre-incubated
◦
mixture of H2O2 and formic acid (the reagent mix was stored two weeks at 4 C) and shaken at various
◦
speeds at 0 C to mix the reactants. Reactions were stopped after 5 min. The maximum reaction rate
was achieved by 1200 rpm and statistical analysis according to the Holm-Sidak method showed no
significant difference between the rates at 1200 rpm and 1400 rpm.
Since the oxidation of DADS occurs in the organic DADS phase by peracid dissolved in it,
varying the amount of DADS in the reaction mix does not actually affect its concentration relative

Molecules 2017, 22, 770
5 of 13
to the peracid. Therefore, the reaction follows a pseudo-zero-order kinetic with respect to DADS.
Furthermore, it was observed that with pre-incubation of H2O2 and formic acid a higher rate of DADS
conversion to allicin was achieved than when all reactants were mixed at once, suggesting that peracid
formation was a rate-limiting step. This aspect will be investigated in the next section.
In contrast, varying the concentration of H2O2 affected the rate of product formation. As shown
in Figure 4 there was a linear relationship between the concentration of H2O2 and product formation.
Therefore, the reaction follows first-order kinetics with respect to the concentration of H2O2.
Figure 4. The rate of allicin formation in relation to the H2O2 concentration. Micro-scale reactions were
performed with varying H2O2 concentrations. The reactions were stopped after 30 min, when turnover
of H2O2 was between 14% (start conc. 2.74 M) and 0.9% (start conc. 0.082 M), the linear progression
indicates that neither H2O2 nor DADS were limiting in the reaction.
2.3. Preformation of Performic Acid
We observed that when H2O2 and formic acid were mixed 3 h before the addition of DADS,
a 37% conversion of DADS to allicin was observed within seconds and that the conversion was >80%
complete after 120 min (Figure 5).
100
90
80
70
60
50
40
30
20
10
0
0
50
100
time (min)
◦
Figure 5. Effect of allowing 3 h at 0 C for the preformation of performic acid on the rate of conversion
of DADS to allicin. H2O2 and formic acid were mixed according to the micro-scale reaction procedure
and incubated on ice for 3 h before DADS was added. The reactions were stopped with methanol,
separated by HPLC and quantified with a UV detector at 254 nm.

Molecules 2017, 22, 770
6 of 13
Without preformation of the performic acid the reaction needs ~1.5 h to reach >35% conversion
and showed >80% conversion only after ~4 h (Figure 1). This illustrates clearly that the formation of
performic acid is rate limiting for allicin synthesis, therefore, we decided to investigate systematically
the effect of the pre-incubation time of H2O2 and formic acid on the conversion rate of DADS to allicin
in order to optimize this step in the protocol (Figure 6).
90
80
70
60
50
40
30
RT
20
1 °C
10
0
0
50
100
150
200
250
300
time (min)
Figure 6. The effect on the pre-incubation time for performic acid formation on the rate of DADS
conversion to allicin. H2O2 and formic acid were mixed according to the micro-scale reaction
procedure and incubated at room temperature or 1 ◦C for the indicated times before DADS was
added. The reactions were stopped after 5 min by addition of methanol, separated by HPLC and
quantified with a UV detector at 254 nm. A maximal turnover was reached after 100 min at RT,
indicating that maximum performic acid formation was achieved after that time.
We investigated the turnover of DADS to allicin depending on the pre-incubation time of the
standard amounts of H2O2 and formic acid at 0 ◦C and at RT. The maximum turnover was reached
between 100 and 180 min, followed by decrease of the turnover. Our observations are in accordance
with those of Filippis et al. [17] who showed, that the formation of performic acid was a slow
temperature dependent mechanism. In their experimental setup the maximum turnover of 25%
of the H2O2 was reached after 100 min at 30 ◦C; thereafter the concentration started to decrease due
to performic acid decomposition. Thus, in our optimized allicin synthesis protocol we recommend
a 100 min pre-incubation step at RT to pre-form the performic acid.
2.4. Influence of Formic Acid Concentration and Amount of H2O2 on the Conversion of DADS to Allicin
Having established that preformation of performic acid greatly enhanced the conversion of
DADS to allicin, we analysed the procedure with respect to formic acid and H2O2 concentrations.
In micro-scale reactions higher amounts of acid and H2O2 increased the rate of the reaction (Figure 7),
but when the reaction volume was scaled up this effect was less pronounced. See Section 2.5.

Molecules 2017, 22, 770
7 of 13
120
100
80
60
40
20
0
ratio peroxide to DADS:
2.16 fold
1.1 fold
1.0 fold
35
45
55
65
75
85
formic acid (%)
Figure 7. The influence of formic acid concentration and amount of H2O2 on the conversion of
DADS to allicin. In a series of microscale reactions, the amount of H2O2 was varied three times
from 1 mol H2O2 per mol DADS to 2.16 mol H2O2 per mol DADS, indicated with different data
point styles. The concentration of formic acid was also varied between 40% and 85% in the reaction.
All H2O2-formic acid mixtures were pre-incubated for 3 h on ice. The lower black data points (50%
formic acid; 47% conversion) are conform to standard micro-scale reaction conditions. The figure shows
that higher concentrations of acid and peroxide enhance the speed of the reaction.
2.5. Accelerated Allicin Synthesis
Not all of the advantages observed by altering parameters in the micro-scale reactions were
completely transferable to scaled up reactions. The reaction speed was not as high as on the microscale
and the formation of byproducts became more prevalent (data not shown). The latter are problems
which could be due lesser mixing inefficiency and emulsion formation on the larger scale. In order
to avoid inadequate mixing, we used methanol to combine the two phases and prevent emulsion
formation (Section 3.2.3). In this way, a conversion of >98.46
(Figure 8).
±
0.45% in just 15 min was achieved
600
500
400
300
200
100
0
0
5
10
15
20
25
30
35
time [min]
Figure 8. Chromatogram of crude allicin after synthesis using pre-formed performic acid. The reaction
was extracted with dichloromethane (DCM) and the solvent was removed by rotary evaporation.
The crude product already showed good purity.

Molecules 2017, 22, 770
8 of 13
2.6. Purification of Allicin
After quenching the reaction by addition of H2O, the reaction mixture consists of allicin, DADS,
formic acid, H2O2, and byproducts. The organic compounds were extracted by partitioning against
either dichloromethane (DCM) or diethyl-ether. In the Lawson method remaining acetic acid was
removed by washing the organic phase with Na2CO3 solution or extracting several times with water.
This, however, leads to a loss of allicin, some of which partitions into the aqueous phase. A further
advantage of using formic acid as a catalyst becomes apparent here. Formic acid is more volatile than
acetic acid and, therefore, more easily removable under reduced pressure at room temperature, thus
switching to evaporation instead of washing and, hence, avoiding the Na2CO3 washing step.
After rotary evaporation, separating allicin, DADS and byproducts is challenging, due to the
similar physical properties of these compounds. The Lawson method partitioned repeatedly between
n-hexane and water to accumulate allicin in the aqueous phase. The calculated logP values (clogP)
of allicin (1.35), DADS (2.95), and probable byproducts such as vinyl-dithiine (2.69) and ajoene (1.97)
(Chemdraw, see Section 3) indicate that allicin is the least hydrophobic molecule. Nonetheless, repeated
extractions lead to further losses of allicin. To circumvent this we used silica gel chromatography to
separate allicin from the other compounds (Figure 9). The structure of the final product was confirmed
and the purity was determined by 13C-NMR and 1H-NMR, respectively.
1200
1000
crude
800
600
400
200
0
purified
0
2
4
6
8
10 12 14 16 18 20 22 24 26 28 30 32 34
time (min)
Figure 9. Chromatograms of crude allicin after synthesis using formic acid as a catalyst and rotary
evaporation and afterwards purification by silica gel chromatography. The crude product contained
impurities with retention times of about 2 min and 18 min, respectively, whilst the purified product
showed >98% purity. Respresentative traces of our repeated routine syntheses are shown.
2.7. Reaction Mechanism
We reasoned that if allicin synthesis proceeded by direct oxidation of DADS (1) without oxidative
cleavage of the S–S bond, then a mixture of DADS and dipropyl-disulfide (DPDS, 2) would yield
allicin (DATS, 3) and dipropyl-thiosufinate (propicin, DPTS, 6) only. In contrast, if oxidative
cleavage of the S–S bond occurred, then mixed allyl-propyl thiosulfinates should be further products
because of random condensation of the respective sulfenic acids (Scheme 2). Thus, formation of
S-allyl-propane-1-sulfinothioate (4) and S-propyl-prop-2-ene-1-sulfinothioate (5) would be predicted.
A mixture of DADS (1) and DPDS (2) was oxidized by performic acid, as described in Section 3.2.4.
After the reaction was quenched products were extracted with DCM. LC-MS analysis of the crude
extracts showed, in addition to single peaks at 6 min and 11 min, which were identified as allicin (3)
and propicin (6), respectively, a double peak at 8 min from the mixed thiosulfinates (4,5). Data in
Figure 10 are a combination of the UV absorption chromatogram detected by HPLC and the mass
signals detected with LC-MS. These data indicate that oxidation of alkyl disulfides to thiosulfinates by
peracids proceeds via oxidative cleavage of the S–S bond, but does not formally rule out parallel direct
S-atom oxidation without S–S bond cleavage. Therefore, we suggest the reaction mechanism shown in
Scheme 3.

Molecules 2017, 22, 770
9 of 13
Scheme 2. The basic reaction for mixed thiosulfinate synthesis from DADS and DPDS by oxidation by
peracid generated with H2O2 in the reaction mixture.
Figure 10. Synthesis of mixed thiosulfinates. According to Scheme 2 a reaction mechanism via the
formation of sulfenic acid would be expected to produce mixed thiosulfinates from a mixture of reacting
alkyl disulfides. The chromatogram was obtained by HPLC and quantified with a UV detector at 254 nm.
Masses were identified in a separate LC-MS analysis using the same column and gradient. Insets show
the m/z ratios in MS-traces and the respective structures of the major ions. The masses obtained fit to the
expected molecules: 6 min, 162.92 Da—allicin (3); 8 min, 165.00 Da—S-allyl-propane-1-sulfinothioate
(4) and S-propyl-prop-2-ene-1-sulfinothioate (5); 11 min, 166.92 Da—propicin (6).
Scheme 3. The oxidation of disulfides proceeds via the formation of an allyl cation and an allylsulfenic
acid in the first step. In a second step the allyl cation reacts with water to form a second allylsulfenic
acid. The resulting sulfenic acids condense in a third step to form allicin.

Molecules 2017, 22, 770
10 of 13
3. Materials and Methods
3.1. Materials
DADS (
≥
80%) was purchased from Sigma Aldrich (Munich, Germany). DPDS (98%) was
98%, p.a.) was purchased from Carl Roth (Karlsruhe,
purchased from Sigma Aldrich. Formic acid (
Germany). H2O2 (30%) was purchased from Merck (Darmstadt, Germany). Acetic acid (100%,
p.a.) was purchased from Carl Roth. TLC was performed using Merck TLC Silica gel 60 F254 with
≥
concentration zone. Solvent A (n-hexane
acetate 99.5% p.s.) was purchased from Carl Roth. Liquid chromatography was performed using
silica gel 60 (0.04–0.063 mm (230–400 mesh)) purchased from Carl Roth. HPLC was performed
using a Bischoff Chromatography Hyperchrome HPLC column 150 mm 4.6 mm packed with
Prontosil Kromaplus 100-5-C18 5.0 m (Leonberg, Germany) in a Jasco System composed of: a Jasco
≥
99% p.s.) was purchased from Carl Roth. Solvent B (ethyl
≥
×
µ
DG-2080-53 3-Line-Degasser, a Jasco LG-980-02 ternary gradient unit, a Jasco PU-980 intelligent
HPLC pump, a Jasco CO-2060Plus Intelligent column thermostat, a Jasco AS-1555 intelligent sampler,
a Jasco UV-2077 multi-wavelength UV-VIS detector, and a Jasco LC-Net II/ADC. Jasco ChromPass
Chromatography Data System Version 1.8.6.1 was used for control and analysis (Groß-Umstadt,
Germany). Solvent A (H2O) was obtained using a Satorius Stedim Biotech Arium® Pro VF (Goettingen,
Germany). Solvent B (methanol (ultra) Gradient HPLC Grade) was purchased from J.T. Baker.
(Center Valley, PA, USA). LC-MS was performed using a Bischoff Chromatography Hyperchrome
HPLC Column 150 mm
1200 System (Santa Clara, CA, USA). To solvent A 0.1% formic acid (
Germany)) was added. Shaking of the micro-scale reactions was performed using an Eppendorf
Thermomixer comfort (Hamburg, Germany) to define 20 ◦C and a Hettich Benelux MKR 23
(Geldermalsen, The Netherlands) to define 0 C. Calculation of logP values was performed using
×
4.6 mm packed with Prontosil Kromaplus 100-5-C18 5.0
µm in an Agilent
≥
98%, p.a.; Carl Roth (Karlsruhe,
◦
ChemDraw Professional 16.0.0.82 (PerkinElmer, Waltham, MA, USA).
3.2. Methods
3.2.1. Distillation of DADS
DADS is commercially only available at 80% purity. For further purification we used distillation
under reduced pressure. To enhance the efficacy of distillation a Vigreux column (600 mm) was used.
The crude DADS was stirred and tempered in an oil bath. The pressure was reduced to approximately
◦
50 mbar. At an oil bath temperature of 120 C the DADS fraction evaporated. The boiling point under
these conditions was 80.5 ◦C. A purity of 98% was determined by HPLC.
3.2.2. Synthesis of Allicin without Pre-Formed Performic Acid
Distilled diallyl disulfide (DADS; 2 g, 13.7 mmol) was mixed in 5 mL formic acid and stirred for
◦
5 min at 0 C. H2O2 (30%; 3 mL, 29.6 mmol) was added slowly to the mixture. The reaction was stopped
after approximately 4 h by addition of 25 mL distilled water and the mixture was extracted three times
with DCM. The solvent was removed under reduced pressure and the product was dissolved in the
eluent, a mixture of n-hexane and ethyl-acetate (2:1).
Separation was performed via liquid chromatography using 150 mm silica gel 60 in a column
with a diameter of 30 mm. Fractions were collected into tubes cooled in an ice bath and TLC was used
to identify fractions containing solely allicin. Those fractions were combined, dried over amorphous
anhydrous sulfate (e.g., MgSO4 or CaSO4) and filtered. The solvents were removed under reduced
pressure at RT to yield a clear, oily substance that smells like garlic. Yield: 1.64 g, 10.1 mmol, 74%.
1H-NMR (500 MHz, CDCl3):
δ
3.70–3.75 (m, 4H); 5.14–5.42 (m, 4H); 5.68–5.88 (m, 2H); 13C-NMR:
(125 MHz, CDCl3) δ35.08, 59.82, 119.11, 124.10, 125.78, 132.8.

Molecules 2017, 22, 770
11 of 13
3.2.3. Synthesis of Allicin Using Pre-Formed Performic Acid
Distilled diallyl-disulfide (DADS; 0.5 g, 3.5 mmol) was mixed in 2.5 mL methanol and stirred for
5 min at 0 ◦C. Performic acid solution (2.0 mL) (as described in Section 3.2.6.) was added slowly to
the mixture. The reaction was quenched after 15 min by addition of 25 mL distilled water and the
mixture was extracted three times with DCM. The solvent was removed under reduced pressure and
the product was dissolved in a mixture of n-hexane and ethyl-acetate (2:1).
Separation was performed via liquid chromatography using 150 mm silica gel 60 in a column
with a diameter of 30 mm and n-hexane and ethyl acetate (2:1) as eluent. Fractions were collected
into tubes cooled in an ice bath and TLC was used to identify fractions solely containing allicin.
Those fractions were combined, dried over an anhydrous sulfate, and filtered. The solvents were
removed under reduced pressure at RT to yield a clear, oily substance that smells like garlic. Yield:
0.52 g, 3.204 mmol, 92%.
1H-NMR (500 MHz, CDCl3):
δ
3.70–3.75 (m, 4H); 5.14–5.42 (m, 4H); 5.68–5.88 (m, 2H); 13C-NMR
(125 MHz, CDCl3): δ35.08, 59.82, 119.11, 124.10, 125.78, 132.8.
3.2.4. Synthesis of Mixed Thiosulfinates
Diallyl disulfide (DADS; 1 g, 6.84 mmol) and dipropyl disulfide (DPDS; 1g, 6.65 mmol) were
mixed in 5 mL formic acid and stirred for 5 min at 0 ◦C. H2O2 (30%; 3 mL, 29.6 mmol) was added
slowly to the mixture. The reaction was quenched after approximately 4 h by addition of 25 mL
distilled water and the mixture was extracted three times with DCM. The solvent was removed under
reduced pressure and the crude products were analysed by HPLC and HPLC-MS.
3.2.5. Micro-Scale Reaction
DADS (10 mg, 68.4
µ
mol) was mixed in 25
µ
L of either formic or acetic acid in a 2.◦0 mL reaction
tube on ice. The formic acid-containing tubes were placed in a cooling shaker at 0 C, the acetic
acid-containing tubes were placed in a shaker at 20 ◦C. Then H2O2 solution (30%, 15
µL, 148 µmol)
was added to the mixture and the reaction was initiated by shaking at 1200 rpm. For sample collection,
single tubes were removed and the reaction was quenched by diluting the mixture to 2 mL with
methanol. The samples were stored at −20 ◦C prior to HPLC analysis.
3.2.6. Performic acid Pre-Formation
If not explained differently, H2O2 and formic acid were mixed (in a ratio of 3:5) and incubated at
RT for 90 min. In micro-scale reactions, for instance, 40 µL of that mixture was used instead of adding
25 µL formic acid and 15 µL H2O2.
3.2.7. High-Performance Liquid Chromatography (HPLC) Analysis
Reaction mixtures were analyzed by loading each 20 L sample onto the HPLC. Separation was
µ
performed using H2O as mobile phase A and methanol as mobile phase B with the following gradient:
56% A (pre-run); 53% A (10 min); 7% A (15 min); 7%A (30 min); 56% A (31 min); 56% A (35 min)
at a flow rate of 1 mL/min and a column thermostat temperature of 25 ◦C. Under these conditions
retention times were 4.8 min for allicin and 18.2 min for DADS. Byproducts appearing at 14.9 min
and 17.7 min due to their calculated logP values are assumed to be forms of ajoene and vinyldithiine,
but were not investigated further at this stage. To quantify allicin and DADS, external standards
were used.
3.2.8. Liquid Chromatography-Mass Spectrometry (LC-MS)
The LC-MS protocol used the same gradient and column as the HPLC protocol, except for the
use of 0.1% formic acid, which was used instead of pure water. The following source conditions
were employed: heater—350 ◦C; sheath gas flow rate machine settings (without units)—30; auxiliary

Molecules 2017, 22, 770
12 of 13
gas flow rate—5; sweep gas flow rate—0; ion spray voltage—400 kV; capillary temperature—250 ◦C;
capillary voltage—82,5 V; tube lens—120 V in a ThermoFischer LTQ XL (Waltham, MA, USA).
3.2.9. Thin Layer Chromatography (TLC)
Approximately 2 µL of the reaction mixture was loaded on a silica plate. After drying, the
substances were separated using n-hexane/ethyl-acetate mixture (in a ratio of 2:1) as mobile phase.
Under these conditions spots were visible under UV light (254 nm). Allicin’s Rf value was 0.70 and
DADS’s Rf value was 0.95.
4. Conclusions
Our data provide evidence that the reaction mechanism underlying the conversion of DADS
to allicin in the presence of formic acid and H2O2 is similar to that already proposed by Nikolic,
but without the need for hydroxyl radicals. The unpaired electrons in such radicals might delocalize
and would surely result in a number of additional side products for which we see no evidence. As the
four possible products from the mixture of disulfides (DPDS and DADS) were formed in approximately
equal amounts, we surmise that direct oxidation of the disulfides without chain cleavage is probably
not quantitatively significant and, thus, we suggest an oxidative cleavage mechanism for the reaction
as shown in Scheme 3.
We also show that the optimized method we describe here to synthesize allicin is an improvement
on the previously-published procedures based on the one of Lawson [10]. Not only does the utilization
of formic acid as a catalyst lead to a purer product, since the formation of by-products is decreased,
the reaction also occurs faster and is easier to perform under standard conditions. Formic acid
offers another advantage during the purification of the product allicin because it is more volatile
than acetic acid and therefore easily removed under reduced pressure. Other peroxy-acids such as
magnesium monoperoxyphthalate, or chloroperbenzoic acid have also been used [11–13]. In light of
economical reasoning, however, the price of formic acid compared to aromatic peroxy-acids is just
another argument, which points to formic acid as the catalyst of choice for the synthesis of allicin.
Additionally, formic acid, as a naturally-occurring organic molecule produced, for example, by red ants
and stinging nettles, is more eco-friendly than most alternatives (with the possible exception of acetic
acid) and certainly ‘greener’ than the aromatic alternatives. The use of silica gel chromatography offers
the advantage whereby a separation of the product and byproducts can be achieved without further
diluting the allicin excessively. Therefore, it is possible to continue the reaction until a maximal turnover
is reached, purify the crude product, and obtain pure allicin rather easily. A suggested optimized
protocol for the synthesis of allicin, taking into account the various individual improvements we
describe here are, therefore, as follows:
1.
Use redistilled DADS and add methanol to combine the aqueous and organic phases
(see Section 3.2.3.) or keep the final reaction volume small to promote efficient mixing and
achieve a high conversion rate.
2.
3.
4.
5.
Use formic acid as the acid catalyst and pre-form performic acid as described in Section 3.2.6.
Cool the reagents and carry out the reaction on ice.
Slowly add performic acid solution.
Continually stir the reactants as efficiently as possible and carry out the reaction at 0 ◦C for just
15 min.
6.
Quench the reaction with water.
Acknowledgments: F.A. and A.J.S. gratefully acknowledge financial support from RFwN and RWTH Aachen
University. R.L. gratefully acknowledges the financial support from University of the Saarland, Saarbruecken,
and RWTH Aachen University. The NMR laboratories in the chemistry departments of the RWTH Aachen
University (Ines Bachmann-Remy) and Saarbruecken University are thanked for providing NMR facilities and
Kilian Smith for the use of the LC-MS facilities in the Institute of Ecotoxicology, RWTH Aachen University.

Molecules 2017, 22, 770
13 of 13
Author Contributions: F.A. and R.L. contributed equally to the practical work and writing the manuscript.
A.J.S. provided supervision and wrote and edited the manuscript. C.J. edited the manuscript.
Conflicts of Interest: The authors declare no conflict of interest. The founding sponsors had no role in the design
of the study; in the collection, analyses, or interpretation of data; in the writing of the manuscript, and in the
decision to publish the results.
References
1.
Rhyu, D.Y.; Park, S.H. Characterization of alkyl-thiosulfinate in Allium hookeri root using HPLC-ESI-MS.
J. Korean Soc. Appl. Biol. Chem. 2013, 56, 457–459. [CrossRef]
2.
3.
Block, E. Garlic and Other Alliums-The Lore and The Science; RSC Publishing: Cambridge, UK, 2010.
Cavallito, C.C.J.; Bailey, J.J.H. Allicin, the Antibacterial Principle of Allium sativum. I. Isolation,
Physical Properties and Antibacterial Action. J. Am. Chem. Soc. 1944, 66, 1950–1951. [CrossRef]
Miron, T.; Wilchek, M.; Sharp, A.; Nakagawa, Y.; Naoi, M.; Nozawa, Y.; Akao, Y. Allicin inhibits cell growth
4.
and induces apoptosis through the mitochondrial pathway in HL60 and U937 cells. J. Nutr. Biochem. 2008
19, 524–535. [CrossRef] [PubMed]
,
5.
6.
Gruhlke, M.; Nicco, C.; Batteux, F.; Slusarenko, A. The Effects of Allicin, a Reactive Sulfur Species from
Garlic, on a Selection of Mammalian Cell Lines. Antioxidants (Basel) 2017, 6, 1. [CrossRef] [PubMed]
Arditti, F.D.; Rabinkov, A.; Miron, T.; Reisner, Y.; Berrebi, A.; Wilchek, M.; Mirelman, D. Apoptotic killing of
B-chronic lymphocytic leukemia tumor cells by allicin generated in situ using a rituximab-alliinase conjugate.
Mol. Cancer Ther. 2005, 4, 325–331. [PubMed]
7.
Gruhlke, M.C.H.; Portz, D.; Stitz, M.; Anwar, A.; Schneider, T.; Jacob, C.; Schlaich, N.L.; Slusarenko, A.J.
Allicin disrupts the cell’s electrochemical potential and induces apoptosis in yeast. Free Radic. Biol. Med.
2010, 49, 1916–1924. [CrossRef] [PubMed]
8.
9.
Stoll, A.; Seebeck, E. Über Alliin, die genuine Muttersubstanz des Knoblauchöls. Experientia 1947, 3, 114–115.
[CrossRef] [PubMed]
Koch, H.P.; Lawson, L.D. Garlic: The Science and Therapeutic Application of Allium sativum L. and Related Species;
Williams & Wilkins: Baltimore, MD, USA, 1996.
10. Lawson, L.D.; Wang, Z.J. Low allicin release from garlic supplements: A major problem due to the sensitivities
of alliinase activity. J. Agric. Food Chem. 2001, 49, 2592–2599. [CrossRef] [PubMed]
11. Cruz-Villalon, G. Synthesis of allicin and purification by solid-phase extraction. Anal. Biochem. 2001, 290,
376–378. [CrossRef] [PubMed]
12. Small, L.D.; Bailey, J.H.; Cavallito, C.J. Alkyl Thiosulfinates. J. Am. Chem. Soc. 1947, 69, 1710–1713. [CrossRef]
[PubMed]
13. Jansen, H.; Müller, B.; Knobloch, K. Allicin characterization and its determination by HPLC. Planta Med.
1987, 53, 559–562. [CrossRef] [PubMed]
14. Cortese, B.; De Croon, M.; Hessel, V. High temperature epoxidation of soybean oil in flow speeding up
elemental reactions wanted and unwanted. Ind. Eng. Chem. Res. 2012, 1680–1689. [CrossRef]
15. Nikolic, V.; Stankovic, M.; Nikolic, L.J.; Cvetkovic, D. Mechanism and kinetics of synthesis of allicin.
Pharmazie 2004, 59, 10–14. [PubMed]
16. Ilic, D.; Nikolic, V.; Nikolic, L. Allicin and related compounds: Biosynthesis, synthesis and pharmacological
activity. Facta Univ. Physics, Chem. Technol. 2011, 9, 9–20. [CrossRef]
17. De Filippis, P.; Scarsella, M.; Verdone, N. Peroxyformic acid formation: A kinetic study. Ind. Eng. Chem. Res.
2009, 48, 1372–1383. [CrossRef]
Sample Availability: Samples of the compounds are not available from the authors.
©
2017 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
