Zn(II) Curcuminate Complexes with 2,2’-bipyridine
and Carboxylates
Sabina Grabner * and Barbara Modec *
Faculty of Chemistry and Chemical Technology, Večna pot 113, 1000 Ljubljana, Slovenia
* Correspondence: barbara.modec@fkkt.uni-lj.si (B.M.); sabina.grabner@fkkt.uni-lj.si (S.G.);
Tel.: +00-3861-479-8526 (B.M.); +00-3861-479-8523 (S.G.)
Received: 27 June 2019; Accepted: 9 July 2019; Published: 11 July 2019
–
Abstract: Two novel zinc(II) compounds with curcuminate (abbreviated as cur ),
[Zn(CH
3
COO)(cur)(bpy)](1)·CH
3
OH·2H O (bpy = 2,2’-bipyridine) and [Zn(PhCOO)(cur)(bpy)]
2
(2)·CH OH, have been synthesized and characterized. Their composition has been determined by
3
single-crystal X-ray structure analysis. Complexes 1 and 2 are similar: in both a five-fold
coordination environment of zinc(II) consists of a monodentate carboxylate, a chelating bidentate
2,2’-bipyridine, and curcuminate, which is bound via a deprotonated 1,3-dione moiety. In 1, 2,2’-
bipyridine nitrogen atoms and curcuminate oxygen atoms form the base of a square pyramid,
whereas the acetate oxygen occupies its apex. The O
3
N2 donor set in 2 defines a polyhedron which
more closely resembles a trigonal bipyramid. The packing in the crystal lattices of both compounds
is governed by hydrogen-bonds. Complexes 1 and 2 display higher stability than curcumin in
–
buffered media at pH = 7.0, however, the degradation of coordinated cur is comparable to that of
yellow pigment curcumin (curH) when the pH is raised to 7.2. Both complexes 1 and 2 in DMSO
−1
exhibit fluorescence with Stokes shifts of 5367 and 4634 cm , respectively.
Keywords: curcumin; Zn(II) complexes; stability; crystal structures
1. Introduction
The Indian spice turmeric (Curcuma Longa L) is used in food processing (as a curry ingredient,
flavor, and dye), fabric dyeing and cosmetics, and has also been used as a medical herb in Ayurvedic
medicine for centuries [1]. Yellow pigment curcumin (abbreviated as curH), the major component of
curcuminoids isolated from turmeric powder, is known to have a broad spectrum of medicinal
benefits. Over the past five decades, numerous laboratory and clinical studies have shown the
multitargeting pharmacological behavior of curH as an anticancer and anti-inflammatory agent, a
promising therapeutic for neurodegenerative (e.g., Alzheimer’s disease), or metabolic diseases (e.g.,
diabetes, obesity), etc. [2–9].
The structure of curH, ((1E,6E)-1,7-bis(4-hydroxy-3-methoxyphenyl)hepta-1,6-diene-3,5-dione),
consists of two phenols with methoxy groups in the ortho position joined by a seven-carbon flexible
spacer with a β-diketone moiety and two carbon–carbon double bonds [10,11]. The diketone group
exhibits tautomerism with the β-diketone and two equivalent asymmetric keto-enol tautomers
(Scheme 1).
Molecules 2019, 24, 2540; doi:10.3390/molecules24142540
www.mdpi.com/journal/molecules

Molecules 2019, 24, 2540
2 of 20
Scheme 1. Keto-enol tautomers of curcumin with the atom numbering.
NMR investigations of curH in solvents of different polarity, i.e., chloroform, methanol, acetic
acid, DMSO, and DMSO/water mixtures, have shown that the keto-enol tautomer exists in solutions
as the only form [12]. CurH, a weak Brønsted acid, has enolic and two phenolic protons with pKa
values of 8.4, 9.9, and 10.5, respectively [13]. CurH is almost insoluble in acidic and neutral aqueous
solutions. Its solubility increases at pH > 7, but already at physiological pH curcumin rapidly
degrades in an autoxidation reaction to a major bicyclopentadione product [14–16]. CurH binding
through its monoanionic enol form to metal ions is one of the possible approaches to overcome its
degradation [17–19].
–
Complexation of curcuminate (cur ) with a plethora of metal ions ( Ru(II), Zn(II), V(IV), Cu(II),
Gd(III), Co(III), Ln(III), Pt(II) or Pd(II)) not only improves its stability but also expands its possible
6
medicinal use [18,20–25]. For example, the Ru(II) complex with η -arene, curcuminato, and chlorido
ligands, ([(η6-p-cymene)RuCl(cur)]), displays a good cytotoxic activity in breast MCF7 and ovarian
A2780 cell lines [26]. A DNA docking study of this complex revealed the same mechanism of action
as in platinum chemotherapy. The Ru(II) complex with Tröger’s base, p-cymene, and curcuminato
ligands shows fast cellular uptake and displays good luminescence and cytotoxicity against cervical
cancer cells [27]. Platinum(II) complexes with curcuminate can act as chemotherapeutic agents which
release photoactive curcumin and an active Pt(II) species upon irradiation with visible light [28,29].
–
Complexes of manganese and copper with cur have been examined for their SOD activity, free
radical-neutralizing abilities and antioxidant properties, e.g., [Cu(Cur)(OAc)(OH)][30–32].
Zinc is attractive as a central metal ion in coordination chemistry. It is the only metal that is
present in all enzyme classes, and is the second most abundant trace metal in humans after iron. In a
variety of biological processes zinc performs diverse physiological functions, e.g., as a structural
component (zinc fingers), as a catalytic factor (enzyme cofactors in six main enzyme classes), or as a
–
signaling mediator [33,34]. Combinations of Zn(II) with cur and one of the aromatic spectator ligands
(2,2’-bipyridine, phenanthroline, terpyridine derivatives, etc.) show antiproliferative activity in
–
different cancer cell lines in vitro [35]. Because of the cur moiety, these complexes emit fluorescence
light in the green part of the spectrum, which enables investigation of their interaction with DNA
–
and proteins by optical methods [36,37]. Furthermore, in some Zn(II) complexes with cur , anti-
diabetic activity has also been observed [38].
To the best of our knowledge, only one crystal structure of a zinc(II) complex with curcuminate
has been reported so far [36]. Our work has focused on Zn(II) complexes with curcuminate, 2,2’-
bipyridine, and carboxylates. The variation of ligand types and their steric effect around the metal
center is an essential parameter for modulating (tuning) the solubility, stability, and biological
activities of metal complexes. In some studies, bipyridine derivatives have proven to be suitable
–
spectator ligands to complete the metal ion coordination sphere along with cur , and thereby improve
the crystallization of the complex [36,39,40]. Acetate ions in Pt(II) complexes were shown to
significantly enhance their solubility in water and chemical stability compared to the parent
chlorides, while a benzoate ligand in a kiteplatin Pt(IV) analog has boosted its cytotoxicity [41,42].
Herein we report on the preparation, spectroscopic characterization, stability, and X-ray
structures of two novel Zn(II) compounds, [Zn(CH3COO)(cur)(bpy)](1)·CH3OH·2H2O and
[Zn(PhCOO)(cur)(bpy)] (2)·CH3OH (Scheme 2).

Molecules 2019, 24, 2540
3 of 20
Scheme 2. Structural formulae of [Zn(CH3COO)(cur)(bpy)](1) and [Zn(PhCOO)(cur)(bpy)](2).
2. Results and Discussion
2.1. Crystallographic Study
[Zn(CH3COO)(cur)(bpy)](1)·CH3OH·2H2O crystallizes in a monoclinic space group P 21/a, and
[Zn(PhCOO)(cur)(bpy)](2)·CH3OH crystallizes in a monoclinic space group C c. Their solid-state
structures consist of neutral complex molecules and solvent molecules of crystallization. The complex
molecules of both compounds are similar. Their ORTEP drawings are shown in Figures 1 and 2,
whereas relevant geometric parameters are listed in Table 1.
Table 1. Relevant structural parameters (Å, °) for [Zn(CH3COO)(cur)(bpy)]
(1)·CH3OH·2H2O and [Zn(PhCOO)(cur)(bpy)](2)·CH3OH.
1
2
Zn(1)–O(7)
1.973(1)
2.016(1)
2.001(1)
2.162(2)
2.123(1)
3.303(2)
1.263(2)
1.243(2)
Zn(1)–O(7)
1.987(3)
2.007(3)
2.051(3)
2.121(4)
2.112(4)
3.127(3)
1.266(5)
1.242(5)
Zn(1)–O(1)
Zn(1)–O(2)
Zn(1)–N(1)
Zn(1)–N(2)
Zn(1)–O(8)
C(8)–O(7)
C(8)–O(8)
Zn(1)–O(1)
Zn(1)–O(2)
Zn(1)–N(1)
Zn(1)–N(2)
Zn(1)–O(8)
C(31)–O(7)
C(31)–O(8)
O(7)–Zn(1)–O(1) 100.79(6) N(1)–Zn(1)–O(2) 162.9(1)
O(7)–Zn(1)–O(2) 101.48(6) N(1)–Zn(1)–N(2) 77.0(2)
O(7)–Zn(1)–N(1) 99.73(6) N(1)–Zn(1)–O(1) 90.5(1)
O(7)–Zn(1)–N(2) 123.32(6) N(1)–Zn(1)–O(7) 98.6(1)
O(1)–Zn(1)–N(1) 158.86(6) O(1)–Zn(1)–O(7) 127.3(1)
O(2)–Zn(1)–N(2) 134.18(6) O(7)–Zn(1)–N(2) 94.8(1)
O(1)–Zn(1)–O(2)
92.22(5) N(2)–Zn(1)–O(1) 124.8(1)
O(2)–Zn(1)–N(1) 88.61(5) O(2)–Zn(1)–O(1) 89.75(1)
N(1)–Zn(1)–N(2) 75.82(6) O(2)–Zn(1)–O(7) 94.8(1)
N(2)–Zn(1)–O(1) 88.66(5) O(2)–Zn(1)–N(2) 88.9(1)
The five-fold coordination environment of zinc(II) in [Zn(CH3COO)(cur)(bpy)](1) consists of a
monodentate acetate and two chelating bidentate ligands, 2,2’-bipyridine as a N,N-donor and
monoanionic curcuminate as an O,O-donor. The latter is a deprotonated enolic form of curcumin.
With the coordination of its central O,O-moiety to zinc(II), a six-membered chelate ring forms. The
O3N2 donor set defines a polyhedron, which more closely resembles a distorted square pyramid than
a trigonal bipyramid. The τ parameter amounts to 0.41. For an ideal tetragonal geometry, τ equals
zero, whereas it becomes unity in the case of a perfect trigonal bipyramidal geometry [43].

Molecules 2019, 24, 2540
4 of 20
Figure 1. ORTEP drawing of [Zn(CH3COO)(cur)(bpy)](1) with displacement ellipsoids drawn at the
30% probability level.
Figure 2. ORTEP drawing of [Zn(PhCOO)(cur)(bpy)](2) with displacement ellipsoids drawn at the
30% probability level.
2,2’-bipyridine nitrogen atoms and curcuminate oxygen atoms define the base of the square
pyramid whose apex is occupied with the acetate oxygen (Figure 3). The curcuminate-to-zinc bond
lengths are 2.001(1) and 2.016(1) Å, the 2,2’-bipyridine-to-zinc bond lengths are 2.123(1) and 2.162(2)
Å, and the carboxylate binds at 1.973(1) Å. The other carboxylate oxygen, O(8), is at 3.303(2) Å, a
–
distance which no longer suggests a significant bonding interaction. The cur ligand is slightly curved

Molecules 2019, 24, 2540
5 of 20
(Figure 4), and its chain backbone is almost planar with the phenyl rings deviating from the plane. A
dihedral angle of 16.75(9)° is formed between the planes of the phenyl rings. The orientations of the
phenyl rings are such that their methoxy substituents are located on the opposite sides of the
conjugated chain system. Within one aromatic ring, an intramolecular hydrogen-bond between its
OH and methoxy entities may be observed.
Figure 3. The square pyramidal environment of zinc ion in [Zn(CH COO)(cur)(bpy)](1).
3
Figure 4. Projections of complex molecules [Zn(CH COO)(cur)(bpy)](1) (a) and
3
[Zn(PhCOO)(cur)(bpy)](2) (b,c). The top drawing shows a slight curvature of the cur– ligand in 1,
whereas a twisted orientation of the aromatic planes in 2 is shown by the bottom ones.
Benzoate, the carboxylate anion in [(Zn(PhCOO)(cur)(bpy))](2), is bound in the same way as
acetate in 1. The coordination environment of the metal in 2 more closely resembles a trigonal
bipyramid, as shown by the value of the τ parameter, 0.63 (Figure 5). The 2,2’-bipyridine ligand is

Molecules 2019, 24, 2540
6 of 20
coordinated in a chelating manner along one edge of the pyramid, and its nitrogen atoms occupy one
−
equatorial and one apical site (Figure 5). The cur ligand, coordinated in a similar manner, spans a
different edge of the pyramid with one donor atom located at the equatorial site and the other at the
opposite apex. The carboxylate oxygen occupies the remaining equatorial site. The bonding
parameters in 2 are similar to those determined for the acetate compound: The curcuminate-to-zinc
bond lengths are 2.007(3) and 2.051(3) Å, the 2,2’-bipyridine-to-zinc bond lengths are 2.112(4) and
2.121(4) Å, and the carboxylate binds at 1.987(3) Å. Surprisingly, the distance between the non-
coordinated carboxylate oxygen and zinc(II) ion is shorter than in 1, i.e., 3.127(3) vs. 3.303(2) Å,
–
respectively. The cur ligand of 2 deviates from planarity. Its conformation may be described as
twisted (Figure 4). An angle of 11.3(2)° is formed between the planes of the phenyl rings. As in 1, the
methoxy groups are in the trans position with respect to the conjugated chain, with neither being
engaged in intramolecular hydrogen-bonding with an adjacent OH group.
Figure 5. The trigonal bipyramidal environment of zinc ion in [Zn(PhCOO)(cur)(bpy)](2).
The composition of the only structurally characterized zinc(II) complex with curcuminate,
[ZnCl(cur)(bpy-9)], resembles that of the title compounds: It is a complex with a derivative of 2,2’-
bipyridine, i.e., a dinonyl-2,2’-bipyridine, with a chloride in place of a monodentate monoanionic
ligand [36]. In [ZnCl(cur)(bpy-9)], zinc(II) features a distorted square pyramidal environment with
chloride occupying its apex. The curcuminate-to-zinc distances, i.e., 2.016(2) and 2.031(2) Å, are
comparable to those in 1 and 2. Moreover, the comparison extends to the bite angle spanned by the
curcuminate donor atoms, 90.0(1)° for [ZnCl(cur)(bpy-9)] vs. 92.22(5)° for 1 and 89.75(11)° for 2. The
–
geometries of 1 and 2 find a close comparison to the complexes with acetylacetonate (acac ), a smaller
ligand that may be considered as a prototype of the curcuminate. For instance, in [Zn(bpy)(acac)
with a N donor set defining a distorted octahedron, the corresponding bond lengths are 2.042(1)–
2.089(1) Å and the acetylacetonate bite angles are 88.44(6) and 88.78(6)° [44].
In a dinuclear [Zn (tpy)(acac) ] with a O N donor set defining a trigonal bipyramidal
2
],
2
O4
2
4
4
environment, the acac-to-zinc bond lengths span a wider interval, 1.966(2)–2.089(2) Å, whereas the
bite angles are 88.39(6)–90.42(8)° [45]. In all known structures of the curcuminate metal complexes,
the ligand adopts a chelating bidentate O,O-donor coordination mode with the curcuminate-to-metal
bonds depending upon the nature of the metal ion [21,22,26,36,39,46–51]. For example, the La–O bond
–
distances involving the cur ligand in [La(R-tpy)(cur)(NO
3
)2
] (R-tpy = 4’-phenyl-2,2’:6’,2’’-terpyridine)
are as long as 2.400(4) and 2.410(4) Å [22]. In [VO(cur)(phen)Cl], the corresponding bond lengths are
slightly shorter than in the zinc complexes, i.e., 1.959(4) and 1.973(5) Å [21]. The shortest bonds,
1.878(4) and 1.880(4) Å, were determined for a cobalt(III) complex with the [Co(cur)L] (L = a

Molecules 2019, 24, 2540
7 of 20
tetradentate phenolate-based ligand) composition [49]. A close inspection of the structures reveals
that the curcuminate ligand typically shows at least a slight deviation from planarity and that a pair
of methoxy groups can be positioned either on the opposite sides of the chain backbone of the ligand,
as observed in 1 and 2, or on the same side, as demonstrated by [VO(cur)(phen)Cl][21]. In some
complexes, the hydroxyl group forms an intramolecular hydrogen-bond with the adjacent methoxy
group. The latter probably depends upon the involvement of the hydroxyl moiety in other
intermolecular interactions. The complex molecules of 1 and 2 possess functional groups capable of
hydrogen-bonding: hydroxyl groups, which can serve both as the acceptors and donors of hydrogen-
bonds, and methoxy oxygens and non-coordinated carboxylate oxygens, which can serve only as the
acceptors. In addition, the title compounds contain solvent molecules of crystallization, methanol,
and water, which also participate in hydrogen-bonding. The packing in the crystal lattices of both
compounds is thus governed by hydrogen-bonds. As expected, all good hydrogen-bond donors and
acceptors are involved in interactions [52]. In [Zn(PhCOO)(cur)(bpy)](2)·CH3OH, each complex
molecule makes four hydrogen-bonding interactions: Both hydroxyl groups, a non-coordinated
–
benzoate oxygen, and a coordinating oxygen of the cur ligand are involved (Table 2).
(a)
Table 2. Hydrogen-bonding interactions in [Zn(PhCOO)(cur)(bpy)](2)·CH3OH.
Groups engaged in interaction(b)
OH·CH3OH
Donor atom∙acceptor(c)
O(6)···O(9)i
Length (Å)
2.715(5)
2.788(4)
OH···O(cur–)
O(4)···O(1)ii
CH3OH···COO–
O(9)···O(8)
2.709(5)
(a)
The distances may be compared to the sum of the van der Waals radii for oxygen atoms, 3.04 Å
[53].(b) OH is a hydroxyl group of the cur– ligand, whereas O(cur–) denotes one of its two coordinating
oxygens. (c) Symmetry codes are: (i) x + 1, y, and z; (ii) x −0.5, –y + 0.5, and z−0.5.
One OH moiety is hydrogen-bonded to a methanol molecule, whereas the other interacts with
the dione oxygen. The free benzoate oxygen makes a hydrogen-bonding interaction with the
methanol molecule. As a result, each complex molecule is hydrogen-bonded to two adjacent
methanols and two complex molecules, producing an infinite two-dimensional array (Figure 6). The
layers that are corrugated stack along the b-axis. The packing of complex molecules is such that it
allows π–π stacking interactions of 2,2’-bipyridine and curcuminate phenyl rings (centroid–centroid
distance = 3.577(3) Å, interplanar distance = 3.428(2) Å, dihedral angle = 2.3(2)°, offset angle = 16.6°)
[54].
The presence of another structural element capable of hydrogen-bonding in
[Zn(CH3COO)(cur)(bpy)](1)·CH3OH·2H2O, i.e., water molecules of crystallization, leads to a more
complicated pattern of connectivity. Again, all good hydrogen-bond donors are involved (Table 3).
One of the two hydroxyl moieties is engaged in an intermolecular interaction with a free carboxylate
oxygen, whereas the other is hydrogen-bonded to a water molecule. The shortest O···O contact
involves the hydroxyl and the carboxylate. The [Zn(CH3COO)(cur)(bpy)](1) and water molecules are
linked into layers with methanol molecules attached to their surfaces (Figure 7). Methanol molecules
serve as linkers between the layers. The π–π stacking interactions between 2,2’-bipyridine rings may
also be observed (centroid–centroid distance = 3.815(1) Å, interplanar distance = 3.4214(8) Å, dihedral
angle = 0.95(9)°, offset angle = 26.3°) [54].

Molecules 2019, 24, 2540
8 of 20
(a).
Table 3. Hydrogen-bonding interactions in [Zn(CH3COO)(cur)(bpy)](1)·CH3OH·2H2O.
Groups engaged in interaction(b)
Donor atom∙∙∙acceptor(c)
O(6)···O(8)i
Length (Å)
2.653(2)
2.729(2)
3.012(2)
2.787(3)
2.702(3)
3.026(2)
OH···COO–
OH···H2O
O(4)···O(12)ii
OH···H2O
O(6)···O(12)iii
O(10)···O(8)i
CH3OH···COO–
CH3OH···H2O
H2O···OCH3
O(10)···O(11)iv
O(12)···O(3)ii
(a) Distances may be compared to the sum of the van der Waals radii for oxygen atoms, 3.04 Å [53].(b)
OH and OCH3 stand for hydroxyl and methoxy functional groups of the cur– ligand, respectively. (c)
Symmetry codes are: (i) –x + 1.5, y + 0.5, –z – 1; (ii) –x + 0.5, y – 0.5, –z; (iii) –x + 1.5, y + 0.5, –z − 1; (iv)
−x + 0.5, y + 0.5, –z − 1.

Molecules 2019, 24, 2540
9 of 20
Figure 6. Hydrogen-bonding in [Zn(PhCOO)(cur)(bpy)](2)·CH
3
OH: (a) Section of a layer of hydrogen-
bonded [Zn(PhCOO)(cur)(bpy)](2) and methanol molecules. (b) A view of the layer along a axis.

Molecules 2019, 24, 2540
10 of 20
Figure 7. Hydrogen-bonding in [Zn(CH
3
COO)(cur)(bpy)](1)·CH
3
OH·2H O: (a) A perpendicular view
2
of the layer. (b) A view along the layer. (c) Stacking of layers with the agency of methanol linkers.
Color code: light grey = [Zn(CH
molecules.
3
COO)(cur)(bpy)](1) molecules, orange = methanol, and green = water
2.2. Synthesis
Novel compounds of Zn(II), 1·CH
3
OH·2H
2
O, and 2·CH OH were prepared by a direct one-pot
3
reaction of Zn(II) aliphatic or aromatic carboxylates with 2,2’-bipyridine and curcuminate.
Deprotonation of curH was carried out in methanol by slow addition of potassium hydrogen
carbonate at room temperature. Syntheses were conducted in methanol at 45 °C. The mixtures were
heated for approximately 90 min. Crystals were obtained from the corresponding filtrates after a few
days at 5 °C.

Molecules 2019, 24, 2540
11 of 20
2.3. Solubility and Stability
The title compounds are poorly soluble in DMSO, DMF, methanol, and almost insoluble in
water, dichloromethane, acetone, chloroform, acetonitrile, and ethyl acetate. The stability of curH, 1
and 2 in DMSO, 90 vol.% 100 mM NaCl + 10 vol.% DMSO, and under pseudo-physiological
conditions (90 vol.% PBS (phosphate buffered saline) + 10 vol.% DMSO) were monitored for 160 min
and also after 24 h in DMSO and 90 vol.% 100 mM NaCl + 10 vol.% DMSO by UV-vis spectroscopy.
In the 420 to 460 nm spectral range, the DMSO solutions of complexes 1 and 2 showed two absorption
bands at 431 and 452 nm, while curH had only one broad band at 436 nm. For all, the strong band at
431 nm could be assigned to a π–π* transition [55]. When the solvent was replaced from DMSO to
aqueous buffered media with 10 vol.% DMSO or 100 mM NaCl with 10 vol.% DMSO, the position of
the π–π* transition remained at almost the same wavelength. In DMSO, the absorption bands at 430
and 452 nm for 1 and 2 and at 436 nm for curH retained their intensities for over 24 hours (Figures
S1–3). In 90 vol.% 100 mM NaCl + 10 vol.% DMSO, curH, 1, and 2 were stable in the first 160 min, but
after 24 h absorbance of the maximum band dropped by 52, 50, and 60%, respectively (Figures S4–6).
On the contrary, in buffered aqueous solutions at pH = 7.2 (Figure 8) the absorption band at 431 nm
for curH, 1, and 2 diminished quickly within 160 min by 44, 46, and 55%, respectively. At pH = 7.0,
the decompositions of curH, 1, and 2 were slower, and after 160 min their concentrations dropped by
36, 26, and 29%, respectively (Figures S7–9). Our results confirm the good stability of curH, 1, and 2
in aprotic solvents. In buffered solutions with pH between 7.2 and 7.4, 1 and 2 decompose as fast as
–
curH. For comparison, in the absorption spectra of similar Zn(II) complexes with cur , 2,2’-bipyridine
derivatives, and chlorido ligands recorded under physiological pH, absorption maxima in the range
of 408–450 nm drop only by ca. 25% in 24 hours and by ca. 35% in 48 hours [36]. The emission spectra
of 1 µM solutions of curH, 1, and 2 in DMSO obtained upon excitation with 430 nm light show 4013,
−1
5367, and 4634 cm Stokes shifts, respectively (Figure 9). The fluorescence intensity of complex 2 is
comparable with that of curH, while the intensity of 1 is considerably lower.

Molecules 2019, 24, 2540
12 of 20
Figure 8. Time-dependent UV-vis spectra of (a) curH, (b) 1, and (c) 2 in 90 vol.% phosphate buffered
saline (PBS, pH = 7.2) + 10 vol.% DMSO solutions.

Molecules 2019, 24, 2540
13 of 20
Figure 9. Emission spectra of 0.1 µM curH, 1, and 2 in DMSO (λex = 435 nm for curH; λex = 431 nm for
1 and 2).
2.4. Spectroscopic Studies
1
The H NMR spectra of the title compounds in DMSO-d
6
show signals for protons of bound
ligands, and the values of their integrals are consistent with the presence of curcuminato, 2,2’-
bipyridine and acetato (in 1)/ benzoato (in 2) ligands in a 1:1:1 ratio (Figures S10–11). Peaks were
1
assigned using COSY spectra of 1 and 2 in DMSO-d
6
and H NMR spectra of the Zn(II) starting
compound in DMSO-d
6
(Figure 10, Figures S12–14) and are listed in the experimental section. The
–
resonances belonging to cur were seen, although they were somewhat broadened. They are shifted
slightly upfield compared to curH (Δδ from 0.19 to 0.03 ppm for 1 and 2). The most substantial change
–
upon coordination of cur to Zn(II) ion is observed for methylene H-4 which is located closest to the
metal ion. Its resonance is shifted upfield by 0.4 ppm. The resonances of 2,2'-bipyridine are broad,
probably due to chemical exchange processes or intra- or intermolecular interactions, and therefore
cannot be interpreted precisely [56]. They appear in the 9.1–7.3 ppm range. All four are shifted
downfield (approximately Δδ = 0.07 ppm) compared to the free 2,2’-bipyridine, and have no cross
13
1
13
peaks in the COSY spectra. NMR spectra ( C NMR, ( H, C) HMQC), which could further assist in
the assignment process, could not be recorded due to the poor solubility of compounds in DMSO, as
well as in other solvents.

Molecules 2019, 24, 2540
14 of 20
Figure 10. 1H NMR (500 MHz) spectra of yellow pigment curcumin (curH, top), complex 1
(middle), and bpy (bottom) in DMSO-d
6
.
The FTIR spectra of curH and the title compounds are presented in Figures S15–17 and the
absorption bands are listed in the experimental section. The assignment of bands in the spectrum of
curH follows the literature report for the β-keto-enol tautomer [57,58]. Phenolic ν(OH) vibrations
−1
−1
absorb at 3510 cm . Strong bands at 1626 and 1601 cm have mixed ν(C=O) and ν(C=C) character.
−1
The most intense band in the spectrum of curH at 1500 cm belongs to mixed vibrations (ν(C=O),
δ(CC=O), and δ(CC C)). Bands at 1458 and 1427 cm have their origin in deformation vibrations of
the two methyl groups. Intense bands between 1277 and 1180 cm are attributed to the in-plane
1
-1
−1
deformation vibration of phenyl rings and skeletal in-plane deformations. However, for both
–
compounds the assignment of cur bands could be inaccurate due to the overlay with the byp and
acetate/benzoate absorptions (Figure S18). The latter also hampers identification of the carboxylate-
binding mode in their infrared spectra, which is possible for simpler complexes from the positions of
the νas(COO) and ν (COO) absorptions [59,60].
s
3. Materials and Methods
3.1. General
The commercial reagents were Aldrich or Fluka reagent-grade products. Curcumin was
synthesized according to the published procedure [61]. PBS was prepared following a published
procedure [62].
3.2. Measurements
Elemental C, H, N analyses were carried out on a Perkin-Elmer CHN Analyzer 2400. ATR-IR
spectra were measured on a Perkin Elmer Spectrum 100 Fourier Transform Infrared Spectrometer
−1
using a diamond crystal plate in the range of 4000–600 cm (PerkinElmer Ltd., Beaconsfield,
Buckinghamshire, UK). UV-vis absorbance spectra were recorded at 25 °C on a Perkin-Elmer
LAMBDA 750 UV/VIS spectrometer with 18 cycle measurements in a quartz cuvette with a 1 cm path
length in the 250–700 nm range. Each cycle lasted 600 s. Stock DMSO solutions of curH, 1, and 2 were
prepared with molar concentrations in the 0.1–0.2 mM range. The stock solution was diluted ten times
with DMSO or PBS buffer just before the measurement. Fluorescence measurements were carried out

Molecules 2019, 24, 2540
15 of 20
on
a
Perkin-Elmer LS 55 Fluorescence Spectrometer (PerkinElmer Ltd., Beaconsfield,
Buckinghamshire, UK).in a Perkin Elmer Quartz SUPRASIL cuvette (10 mm path length). Solutions
of curH, 1, and 2 in DMSO were prepared with molar concentrations in the 10–0.1 µM range. The
bandwidths for excitation and emission were 10 nm.
Thermogravimetric analyses (TGA) were run on a Mettler-Toledo TGA/DSC1 instrument
(Mettler-Toledo, GmbH, Greifensee, Switzerland) in an air atmosphere with a purge rate of 100 mL
−1
min . The samples were heated at 10 °K/min in a temperature range from 25 to 1000 °C. A sample
size of around 5 mg was put in 150 µL alumina crucible. The TGA curves were corrected by running
1
an automatic blank curve subtraction. H NMR spectra were recorded on a Bruker Avance III 500
spectrometer (Bruker Corporation, Billerica, MA, USA) with standard pulse programs at 500.10 MHz
1
1
1
( H). 2D ( H, H) COSY spectra were recorded in a gradient-enhanced mode on a Bruker Avance III
1
500 spectrometer with standard pulse programs at 500.10 MHz ( H). The NMR measurements were
performed in DMSO-d6 at 302 °K with TMS as an internal standard.
3.3. Syntheses
3.3.1. Synthesis of [Zn(PhCOO)2]
A suspension of ZnO (1.00 g, 12.3 mmol) in 10 mL of distilled water was treated with benzoic
acid (3.60 g, 29.5 mmol) and dissolved in 10 mL of methanol at the temperature of 50 °C. An additional
1.20 g of benzoic acid in 100 mL methanol was added until the solution became clear. After slow
evaporation of the colorless solution at room temperature for three days, the white crystalline product
was filtered off and washed with several portions of diethyl ether. The yield was 45%. Anal. C 54.79,
−1
H 2.97%, calcd for C14H10O4Zn, C 54.77, H 3.28%. IR, ν (cm ): 1632 (s), 1595 (vs), 1575 (vs), 1540 (vs),
1527 (s), 1494 (s), 1407 (vs), 1312 (m), 1175 (s), 1158 (vs), 1001 (vs), 1070 (vs) 1026 (b), 865 (vs), 841 (vs),
1
818(vs), 713 (s), 694(s), 684 (vs), 676 (m). H NMR (500 MHz), δ/ppm (DMSO-d6): 7.98–7.92 (m, 2H, a),
7.52–7.45 (m, 1H, c), 7.44–7.38 (m, 2H, b). TGA anal. Zn 21.19% calcd. for C33H34N2O10Zn, Zn 21.26%.
3.3.2. Synthesis of [Zn(CH3COO)(cur)(bpy)](1)·CH3OH·2H2O
A solution of 2,2’-bipyridine (79.4 mg, 0.508 mmol) in 2 mL of methanol was added dropwise to
a stirred 5 mL solution of [Zn(CH3CO2)2]·2H2O (118.2 mg, 0.538 mmol). Crushed KHCO3 (41.2 mg,
0.412 mmol) was slowly added to a stirred suspension of curH (188 mg, 0.510 mmol) in 30 mL of
–
methanol. The mixture was left stirring until the solution became red. Afterwards, the solution of cur
was added dropwise. The reaction mixture was stirred at 45 °C for an hour. Afterwards, the solution
was filtered and the resulting filtrate was left in an open beaker at 5 °C. Within a few days, red-orange
crystals of 1·CH3OH·2H2O formed. The yield was 30%. Note: The crystals became opaque when taken
out from the mother liquor. Based on the NMR spectrum, TGA and elemental analyses, the crystals
gave off weakly bound methanol. Anal. C 58.01, H 4.91, N 4.05%, calcd for C33H34N2O10Zn, C 57.94, H
−1
5.01, N 4.10%. IR, ν (cm ): 3600 – 3000 (vvb), 1622 (m), 1597 (m), 1579 (w), 1531 (s), 1504 (vvs), 1403
(vs), 1279 (vs), 1242 (s), 1216 (s), 1156 (vs), 1123 (vs), 1057 (w), 980 (vs), 966 (vs), 850 (s), 811(s), 760
1
(vs), 733 (s), 665 (w), 652 (m), 628 (w), 607 (m). H NMR (500 MHz), δ/ppm (DMSO-d6): 9.48 (s, 2H, -
OH), 8.75 ( br s, 2H, bpy), 8.46 ( br s, 2H, bpy), 8.02 ( br s, 2H, bpy), 7.54 ( br s, 2H, bpy), 7.41 (d, J =
15.5 Hz, 2H, H-1, H-7), 7.26 (br s, 2H, H-2’,H-2’’), 7.08 (d, J = 8.2 Hz, 2H, H-6’,H-6’’), 6.79 (d, J = 4.5
Hz, 2H, H-5’,H-5’’), 6.68 (d, J = 15.5 Hz, 2H, H-2,H-6), 5.70 (s, 1H, H-4), 3.83 (s, 6H, -OCH3), 1.82 (s,
3H, -OOCH3). TGA anal. Zn 9.18% calcd. for C33H34N2O10Zn, Zn 9.56%.
3.3.3. Synthesis of [Zn(PhCOO)(cur)(bpy)](2) CH3OH
A solution of 2,2’-bipyridine (79.4 mg, 0.508 mmol) in 2 mL of methanol was added dropwise to
a stirred 5 mL solution of [Zn(PhCOO)2] (156.4 mg, 0.508 mmol). Crushed KHCO3 (41.2 mg, 0.412
mmol) was slowly added to a stirred suspension of curH (188 mg, 0.510 mmol) in 30 mL of methanol.
–
The mixture was left stirring until the solution became red. The solution of cur was added dropwise
to the stirred solution of the Zn(II) starting material and 2,2’-bipyridine at 45 °C. After one hour, the
solution was filtered. The filtrate was left in an open beaker at 5 °C. Yellow-orange crystals of

Molecules 2019, 24, 2540
16 of 20
2·CH3OH formed within few days. The yield was 35%. Note: The crystals became opaque when taken
out from the mother liquor. Based on the NMR spectrum, TGA and elemental analyses, the crystals
gave off weakly bound methanol. Anal. C 63.86, H 4.46, N 3.92%, calcd for C38H32N2O8Zn, C 64.28, H
−1
4.54, N 3.95%. IR, ν (cm ): 3200–3000 (vvb), 1622 (m), 1594 (m), 1562 (w), 1537 (m), 1503 (vvs), 1471
(w), 1462 (w), 1444 (w), 1403 (s), 1379 (vs), 1311 (w), 1279 (vs), 1254 (s), 1216 (m), 1187 (w), 1158 (vs),
1122 (vs), 1060 (w), 1025 (vs), 984 (vs), 969 (vs), 861 (w), 846 (m), 815 (m), 758 (vs), 732 (m), 719 (vs),
1
691 (w), 677 (m), 652 (m), 629 (w), 609 (w). H NMR (500 MHz), δ/ppm (DMSO-d6): 9.47 (s, 2H, –OH),
–
–
9.00–7.95 (m, 8H, bpy), 7.93 (d, J = 7.6 Hz, 2H, a (PhCOO ) ), 7.36–7.5 (m, 5H, H-1, and H-7 (cur ), b
–
and c (PhCOO )), 7.27 (br s, 2H, H-2’,H-2’’), 7.08 (d, J = 8.4 Hz, 2H, H-6’,H-6’’), 6.79 (d, J = 8.4 Hz, 2H,
H-5’,H-5’’), 6.69 (d, J = 15.7 Hz, 2H, H-2,H-6), 5.70 (s, 1H, H-4), 3.83 (s, 6H, -OCH3). TGA anal. Zn
9.21% calcd. for C38H32N2O8Zn, Zn 9.21%.
3.4. X-Ray Structure Determinations
Data were collected on an Agilent SuperNova dual source diffractometer (Agilent Technologies
XRD Products, Oxfordshire, UK) with an Atlas detector at 150 °K using Mo-Kα radiation (λ = 0.71073
Å). The data were processed using CrysAlis PRO software [63]. The coordinates of the majority of
non-hydrogen atoms were found via direct methods using the structure solution program SHELXS
[64]. The positions of the remaining non-hydrogen atoms were located by use of a combination of
least-squares refinement and difference Fourier maps in the SHELXL 97 program [64]. Figures
depicting the structures were prepared by Ortep3, CrystalMaker® X and Mercury [65–67].
–1
Crystal data for 1, C34H38N2O11Zn (716.03 g mol ): monoclinic P 21/a, a = 8.79160(13) Å, b =
3
–3
20.8829(3) Å, c = 17.7951(2) Å, β = 92.5369(13)°, V = 3263.88(8) Å , Z = 4, ρcalcd = 1.457 g cm , μ = 0.818
–1
mm ; 24502 reflections collected (8775 independent, Rint = 0.0285). The final residues were R = 0.0371,
and wR2 = 0.0817 (7011 reflections, I > 2σ(I)), and R = 0.0532, and wR2 = 0.0894 (all data).
–1
Crystal data for 2, C39H36N2O9Zn (742.07 g mol ): monoclinic C c, a = 13.8388(5) Å, b = 18.3164(6)
3
–3
–1
Å, c = 14.6960(5) Å, β = 114.141(4)°, V = 3399.3(2) Å , Z = 4, ρcalcd = 1.450 g cm , μ = 0.784 mm ; 9986
reflections collected (6067 independent, Rint = 0.0281). The final residues were R = 0.0425, and wR2 =
0.1000 (5225 reflections, I > 2σ(I)), and R = 0.0550, and wR2 = 0.1073 (all data).
CCDC-1909739 (1) and -1909738 (2) contain the supplementary crystallographic data for this
paper. These data can be obtained free of charge at http://www.ccdc.cam.ac.uk/conts/retrieving.html
(or from the Cambridge Crystallographic Data Centre, 12 Union Road, Cambridge CB2 1EZ, UK; fax:
+44 1223 336033).
4. Conclusions
To summarize, [Zn(CH3COO)(cur)(bpy)](1)·CH3OH·2H2O and [Zn(PhCOO)(cur)(bpy)]
(2)·CH3OH were crystallized from methanol solutions. Good quality single crystals were prepared
and subjected to X-ray structural analysis. The complexes 1 and 2 are the second only examples of X-
ray structurally characterized zinc(II) curcuminate compounds. The five-fold coordination
environments of zinc(II) in the pair, although similar, exhibit minor differences. The spatial
distribution of the monodentate carboxylate and bidentate chelating 2,2’-bipyridine and curcuminate
is such that the O3N2 donor set in the case of acetate complex 1 defines a distorted square pyramid,
whereas in complex with benzoate 2, a trigonal bipyramid is defined. 1·CH3OH·2H2O and 2·CH3OH
display different packing arrangements in the solid state. Hydrogen-bonding interactions govern the
packing. The acetate-curcuminate Zn(II) compound does not have the anticipated water solubility.
Both compounds are poorly soluble in aprotic solvents. Surprisingly, unlike the related heteroleptic
Zn(II) complex with curcuminate, which displays stability under physiological conditions, the
coordination of curcuminate to Zn(II) in 1 and 2 does not prevent its degradation in alkaline media.
Both complexes are fluorophores with a green emission after excitation at 430 nm. The synthesis of
several similar curcumin metal complexes with other carboxylate ligands is underway, and
investigation of their biological activity is under consideration.
Supplementary Materials: The following are available online at www.mdpi.com/xxx/s1,. Figure S1. Time-
dependent UV-Vis spectra of curH in DMSO. Figure S2. Time-dependent UV-Vis spectra of

Molecules 2019, 24, 2540
17 of 20
[Zn(CH3COO)(cur)(bpy)](1) in DMSO. Figure S3. Time-dependent UV-Vis spectra of [Zn(PhCOO)(cur)(bpy)](2)
in DMSO. Figure S4. Time-dependent UV-Vis spectra of curH in 90 vol.% 100 mM NaCl - 10 vol. % DMSO.
Figure S5. Time-dependent UV-Vis spectra of [Zn(CH3COO)(cur)(bpy)](1) in 90 vol.% 100 mM NaCl - 10 vol. %
DMSO. Figure S6. Time-dependent UV-Vis spectra of [Zn(PhCOO)(cur)(bpy)](2) in 90 vol.% 100 mM NaCl - 10
vol. % DMSO. Figure S7. Time-dependent UV-Vis spectra of curH in 90 vol.% PBS (pH = 7.0) - 10 vol.% DMSO
solution. Figure S8. Time-dependent UV-Vis spectra of [Zn(CH3COO)(cur)(bpy)](1) in 90 vol.% PBS (pH = 7.0) -
10 vol.% DMSO solution. Figure S9. Time-dependent UV-Vis spectra of [Zn(PhCOO)(cur)(bpy)](2) in 90 vol.%
PBS (pH
= 7.0) - 10 vol.% DMSO solution. Figure S10. 1H NMR spectrum (500 MHz) of
[Zn(CH3COO)(cur)(bpy)](1) in DMSO-d6. Figure S11. 1H NMR spectrum (500 MHZ) of
[Zn(PhCOO)(cur)(bpy)](2) in DMSO-d6. Figure S12. 1H NMR spectrum (500 MHz) of [Zn(PhCOO)2] in DMSO-
d6. Figure S13. 2D [1H,1H] COSY NMR (500 MHZ) spectrum of [Zn(CH3COO)(cur)(bpy)](1) in DMSO-d6. Figure
S14. 2D [1H,1H] COSY NMR (500 MHZ) spectrum of [Zn(PhCOO)(cur)(bpy)](2) in DMSO-d6. Figure S15. ATR-
IR spectrum of curH. Figure S16. ATR-IR spectrum of [Zn(CH3COO)(cur)(bpy)](1)·CH3OH·2H2O. Figure S17.
ATR-IR spectrum of [Zn(PhCOO)(cur)(bpy)](2)·CH3OH. Figure S18. ATR-IR spectrum of [Zn(PhCOO)2]. Figure
S19. TGA curve of [Zn(CH3COO)(cur)(bpy)](1)·CH3OH·2H2O, recorded after being exposed to air. Figure S20.
TGA curve of crystals of [Zn(PhCOO)(cur)(bpy)](2)·CH3OH, recorded after being exposed to air. 23 Figure S21.
TGA curve of [Zn(PhCOO)2].
Author Contributions: Conceptualization S.G.; Investigation, S.G.; Visualization, S.G.; Formal Analysis, B.M.;
Writing—Original Draft Preparation, S.G. and B.M.; Writing—Review and Editing. S.G. and B.M.
Funding: This research was funded by the Slovenian research Agency, grant number P1-0134.
Acknowledgments: We are grateful to Darko Dolenc for critical review of spectroscopic characterization. We
also like to express our gratitude to Matej Rebec for his technical support.
Conflicts of Interest: The authors declare no conflict of interest.
References
1. Aggarwal, B.B.; Ichikawa, H.; Garodia, P.; Weerasinghe, P.; Sethi, G.; Bhatt, I.D.; Pandey, M.K.; Shishodia,
S.; Nair, M.G. From Traditional Ayurvedic Medicine to Modern Medicine: Identification of Therapeutic
Targets for Suppression of Inflammation and Cancer. Expert Opin. Ther. Targets 2006, 10, 87–118.
doi:10.1517/14728222.10.1.87.
2. Kunnumakkara, A.B.; Bordoloi, D.; Padmavathi, G.; Monisha, J.; Roy, N.K.; Prasad, S.; Aggarwal, B.B.
Curcumin, the Golden Nutraceutical: Multitargeting for Multiple Chronic Diseases: Curcumin: From
Kitchen to Clinic. Br. J. Pharmacol. 2017, 174, 1325–1348. doi:10.1111/bph.13621.
3. Shehzad, A.; Rehman, G.; Lee, Y.S. Curcumin in Inflammatory Diseases. BioFactors 2013, 39, 69–77.
doi:10.1002/biof.1066.
4. Zheng, J.; Cheng, J.; Zheng, S.; Feng, Q.; Xiao, X.; Curcumin, A Polyphenolic Curcuminoid With Its
Protective Effects and Molecular Mechanisms in Diabetes and Diabetic Cardiomyopathy. Front. Pharmacol.
2018, doi:10.3389/fphar.2018.00472.
5. Thangapazham, R.L.; Sharad, S.; Maheshwari, R.K. Skin Regenerative Potentials of Curcumin. BioFactors
2013, 39, 141–149. doi:10.1002/biof.1078.
6. Esatbeyoglu, T.; Huebbe, P.; Ernst, I.M.A.; Chin, D.; Wagner, A.E.; Rimbach, G. Curcumin-From Molecule
to Biological Function. Angew. Chem. Int. Ed. 2012, 51, 5308–5332. doi:10.1002/anie.201107724.
7. Moustapha, A.; Pérétout, P.; Rainey, N.; Sureau, F.; Geze, M.; Petit, J.-M.; Dewailly, E.; Slomianny, C.; Petit,
P. Curcumin Induces Crosstalk between Autophagy and Apoptosis Mediated by Calcium Release from the
Endoplasmic Reticulum, Lysosomal Destabilization and Mitochondrial Events. Cell Death Dis. 2015,
doi:10.1038/cddiscovery.2015.17.
8. Serafini, M.M.; Catanzaro, M.; Rosini, M.; Racchi, M.; Lanni, C. Curcumin in Alzheimer’s Disease: Can We
Think to New Strategies and Perspectives for This Molecule? Pharmacol. Res. 2017, 124, 146–155.
doi:10.1016/j.phrs.2017.08.004.
9. Hewlings, S.J.; Kalman, D.S. Curcumin: A Review of Its’ Effects on Human Health. Foods 2017,
doi:10.3390/foods6100092.
10. Tønnesen, Hanne Hjorth; Karlsen, Jan; Mostad, Arvid. Structural Studies of Curcuminoids. I. The Crystal
Structure of Curcumin. Acta Chem. Scand. Ser. B 1982, doi:10.3891/acta.chem.scand.36b-0475.
11. Milobędzka, J.; v. Kostanecki, St.; Lampe, V. Zur Kenntnis des Curcumins. Ber. Dtsch. Chem. Ges. 1910, 43,
2163–2170. doi:10.1002/cber.191004302168.

Molecules 2019, 24, 2540
18 of 20
12. Payton, F.; Sandusky, P.; Alworth, W.L. NMR Study of the Solution Structure of Curcumin. J. Nat. Prod.
2007, 70, 143–146. doi:10.1021/np060263s.
13. Bernabé-Pineda, M.; Ramı́rez-Silva, M.T.; Romero-Romo, M.; González-Vergara, E.; Rojas-Hernández, A.
Determination of Acidity Constants of Curcumin in Aqueous Solution and Apparent Rate Constant of Its
Decomposition. Spectrochim. Acta A 2004, 60, 1091–1097. doi:10.1016/S1386-1425(03)00342-1.
14. Kharat, M.; Du, Z.; Zhang, G.; McClements, D.J. Physical and Chemical Stability of Curcumin in Aqueous
Solutions and Emulsions: Impact of PH, Temperature, and Molecular Environment. J. Agric. Food Chem.
2017, 65, 1525–1532. doi:10.1021/acs.jafc.6b04815.
15. Schneider, C.; Gordon, O.N.; Edwards, R.L.; Luis, P.B. Degradation of Curcumin: From Mechanism to
Biological Implications. J. Agric. Food Chem 2015, 63, 7606–7614. doi:10.1021/acs.jafc.5b00244.
16. Gordon, O.N.; Luis, P.B.; Sintim, H.O.; Schneider, C. Unraveling Curcumin Degradation. J. Biol. Chem. 2015,
290, 4817–4828. doi:10.1074/jbc.M114.618785.
17. Pröhl, M.; Schubert, U.S.; Weigand, W.; Gottschaldt, M. Metal Complexes of Curcumin and Curcumin
Derivatives for Molecular Imaging and Anticancer Therapy. Coord. Chem. Rev. 2016, 307, 32–41.
doi:10.1016/j.ccr.2015.09.001.
18. Wanninger, S.; Lorenz, V.; Subhan, A.; Edelmann, F.T. Metal Complexes of Curcumin – Synthetic Strategies,
Structures and Medicinal Applications. Chem. Soc. Rev. 2015, 44, 4986–5002. doi.org/10.1039/C5CS00088B.
19. Kühlwein, F.; Polborn, K.; Beck, W. Metallkomplexe von Farbstoffen. VIII Übergangsmetallkomplexe des
Curcumins und seiner Derivate. Z. Anorg. Allg. Chem. 1997, 623, 1211–1219. doi:10.1002/zaac.19976230806.
20. Banerjee, S.; Chakravarty, A.R. Metal Complexes of Curcumin for Cellular Imaging, Targeting, and
Photoinduced Anticancer Activity. Acc. Chem. Res. 2015, 48, 2075–2083. doi:10.1021/acs.accounts.5b00127.
21. Banerjee, S.; Prasad, P.; Hussain, A.; Khan, I.; Kondaiah, P.; Chakravarty, A.R. Remarkable
Photocytotoxicity of Curcumin in HeLa Cells in Visible Light and Arresting Its Degradation on
Oxovanadium(IV) Complex Formation. Chem. Commun. 2012, doi.org/10.1039/c2cc33576j.
22. Hussain, A.; Somyajit, K.; Banik, B.; Banerjee, S.; Nagaraju, G.; Chakravarty, A.R. Enhancing the
Photocytotoxic Potential of Curcumin on Terpyridyl Lanthanide(III) Complex Formation. Dalton Trans.
2012, 42, 182–195. doi.org/10.1039/C2DT32042H.
23. Sarkar, T.; Banerjee, S.; Hussain, A. Remarkable Visible Light-Triggered Cytotoxicity of Mitochondria
Targeting Mixed-Ligand Cobalt(III) Complexes of Curcumin and Phenanthroline Bases Binding to Human
Serum Albumin. RSC Adv. 2015, 5, 16641–16653. doi:10.1039/C4RA17314G.
24. Sarkar, T.; Banerjee, S.; Mukherjee, S.; Hussain, A. Mitochondrial Selectivity and Remarkable
Photocytotoxicity of a Ferrocenyl Neodymium( III ) Complex of Terpyridine and Curcumin in Cancer Cells.
Dalton Trans. 2016, 45, 6424–6438. doi:10.1039/C5DT04775G.
25. Valentini, A.; Conforti, F.; Crispini, A.; De Martino, A.; Condello, R.; Stellitano, C.; Rotilio, G.; Ghedini, M.;
Federici, G.; Bernardini, S.; et al. Synthesis, Oxidant Properties, and Antitumoral Effects of a Heteroleptic
Palladium(II) Complex of Curcumin on Human Prostate Cancer Cells. J. Med. Chem. 2009, 52, 484–491.
doi:10.1021/jm801276a.
26. Caruso, F.; Rossi, M.; Benson, A.; Opazo, C.; Freedman, D.; Monti, E.; Gariboldi, M.B.; Shaulky, J.; Marchetti,
F.; Pettinari, R.; et al. Ruthenium–Arene Complexes of Curcumin: X-Ray and Density Functional Theory
Structure, Synthesis, and Spectroscopic Characterization, in Vitro Antitumor Activity, and DNA Docking
Studies of (p -Cymene)Ru(Curcuminato)Chloro. J. Med. Chem. 2012, 55, 1072–1081. doi:10.1021/jm200912j.
27. Shanmugaraju, S.; la Cour Poulsen, B.; Arisa, T.; Umadevi, D.; Dalton, H.L.; Hawes, C.S.; Estalayo-Adrián,
S.; Savyasachi, A.J.; Watson, G.W.; Williams, D.C.; et al. Synthesis, Structural Characterisation and
Antiproliferative Activity of a New Fluorescent 4-Amino-1,8-Naphthalimide Tröger’s Base–Ru(II)–
Curcumin Organometallic Conjugate. Chem. Commun. 2018, 54, 4120–4123. doi:10.1039/C8CC01584H.
28. Mitra, K.; Gautam, S.; Kondaiah, P.; Chakravarty, A.R. The Cis-Diammineplatinum(II) Complex of
Curcumin: A Dual Action DNA Crosslinking and Photochemotherapeutic Agent. Angew. Chem. Int. Ed.
2015, 54, 13989–13993. doi:10.1002/anie.201507281.
29. Mitra, K.; Gautam, S.; Kondaiah, P.; Chakravarty, A.R. Platinum(II) Complexes of Curcumin Showing
Photocytotoxicity in Visible Light. Eur. J. Inorg. Chem. 2017, 2017, 1753–1763. doi:10.1002/ejic.201601078.
30. Sumanont, Y.; Murakami, Y.; Tohda, M.; Vajragupta, O.; Watanabe, H.; Matsumoto, K. Effects of Manganese
Complexes of Curcumin and Diacetylcurcumin on Kainic Acid-Induced Neurotoxic Responses in the Rat
Hippocampus. Biol. Pharm. Bull. 2007, 30, 1732–1739. doi:/10.1248/bpb.30.1732.

Molecules 2019, 24, 2540
19 of 20
31. Barik, A.; Mishra, B.; Shen, L.; Mohan, H.; Kadam, R.M.; Dutta, S.; Zhang, H.-Y.; Priyadarsini, K.I.
Evaluation of a New Copper(II)–Curcumin Complex as Superoxide Dismutase Mimic and Its Free Radical
Reactions. Free Radical Biol. Med. 2005, 39, 811–822. doi:10.1016/j.freeradbiomed.2005.05.005.
32. Barik, A.; Mishra, B.; Kunwar, A.; Kadam, R.M.; Shen, L.; Dutta, S.; Padhye, S.; Satpati, A.K.; Zhang, H.-Y.;
Indira Priyadarsini, K. Comparative Study of Copper(II)–Curcumin Complexes as Superoxide Dismutase
Mimics and Free Radical Scavengers. Eur. J. Med. Chem. 2007, 42, 431–439. doi:10.1016/j.ejmech.2006.11.012.
33. Kambe, T.; Tsuji, T.; Hashimoto, A.; Itsumura, N. The Physiological, Biochemical, and Molecular Roles of
Zinc Transporters in Zinc Homeostasis and Metabolism. Physiol. Rev. 2015, 95, 749–784.
doi.org/10.1152/physrev.00035.2014.
34. Kaur, K.; Gupta, R.; Saraf, S.A.; Saraf, S.K. Zinc: The Metal of Life. Compr. Rev. Food Sci. Food Saf. 2014, 13
358–376. doi:10.1111/1541-4337.12067.
35. Pucci, D.; Crispini, A.; Mendiguchía, B.S.; Pirillo, S.; Ghedini, M.; Morelli, S.; De Bartolo, L. Improving the
Bioactivity of Zn(Ii)-Curcumin Based Complexes. Dalton Trans. 2013, doi:10.1039/c3dt50513h.
36. Pucci, D.; Bellini, T.; Crispini, A.; D’Agnano, I.; Liguori, P.F.; Garcia-Orduna, P.; Pirillo, S.; Valentini, A.;
Zanchetta, G. DNA Binding and Cytotoxicity of fluorescent Curcumin-Based Zn(II) Complexes. Med. Chem.
Commun. 2012, 3, 462–468.
37. Ricciardi, L.; Pucci, D.; Pirillo, S.; La Deda, M. Emission Solvatochromic Behavior of a Pentacoordinated
Zn(II) Complex: A Viable Tool for Studying the Metallodrug–Protein Interaction. J. Lumin. 2014, 151, 138–
142. doi:10.1016/j.jlumin.2014.02.020.
38. Al-Ali, K.; Abdel Fatah, H.S.; El-Badry, Y.A.-M. Dual Effect of Curcumin–Zinc Complex in Controlling
Diabetes Mellitus in Experimentally Induced Diabetic Rats. Biol. Pharm. Bull. 2016, 39, 1774–1780.
doi:10.1248/bpb.b16-00137.
39. Halevas, E.; Papadopoulos, T.A.; Swanson, C.H.; Smith, G.C.; Hatzidimitriou, A.; Katsipis, G.; Pantazaki,
A.; Sanakis, I.; Mitrikas, G.; Ypsilantis, K.; et al. In-Depth Synthetic, Physicochemical and in Vitro Biological
Investigation of a New Ternary V(IV) Antioxidant Material Based on Curcumin. J. Inorg. Biochem. 2019, 191,
94–111. doi:10.1016/j.jinorgbio.2018.10.010.
40. Li, Y.; Gu, Z.; Zhang, C.; Li, S.; Zhang, L.; Zhou, G.; Wang, S.; Zhang, J.; Synthesis, Characterization and
ROS-Mediated Antitumor Effects of Palladium(II) Complexes of Curcuminoids. Eur. J. Med. Chem. 2018,
144, 662–671. doi:10.1016/j.ejmech.2017.12.027.
41. Ma, E.S.F.; Bates, W.D.; Edmunds, A.; Kelland, L.R.; Fojo, T.; Farrell, N. Enhancement of Aqueous Solubility
and Stability Employing a Trans Acetate Axis in Trans Planar Amine Platinum Compounds While
Maintaining the Biological Profile. J. Med. Chem. 2005, 48, 5651–5654. doi:10.1021/jm050539d.
42. Margiotta, N.; Savino, S.; Marzano, C.; Pacifico, C.; Hoeschele, J.D.; Gandin, V.; Natile, G. Cytotoxicity-
Boosting of Kiteplatin by Pt(IV) Prodrugs with Axial Benzoate Ligands. J. Inorg. Biochem. 2016, 160, 85–93.
doi:10.1016/j.jinorgbio.2015.11.028.
43. Addison, A.W.; Rao, T.N.; Reedijk, J.; Rijn, J. van; Verschoor, G.C. Synthesis, Structure, and Spectroscopic
Properties of Copper(II) Compounds Containing Nitrogen–Sulphur Donor Ligands; the Crystal and
Molecular
Structure
of
Aqua[1,7-Bis(N-Methylbenzimidazol-2′-Yl)-2,6-Dithiaheptane]Copper(II)
Perchlorate. J. Chem. Soc. Dalton Trans. 1984, doi:10.1039/DT9840001349.
44. Brahma, S.; Sachin, H.P.; Shivashankar, S.A.; Narasimhamurthy, T.; Rathore, R.S. Adducts of
Bis(Acetylacetonato)Zinc(II) with 1,10-Phenanthroline and 2,2′-Bipyridine. Acta Cryst.. C Cryst. Struct.
Commun. 2008, doi:10.1107/S0108270108003818.
45. Granifo, J.; Gaviño, R.; Freire, E.; Baggio, R. Monodentate and Bridging Behaviour of the Sulfur-Containing
Ligand 4′-[4-(Methylsulfanyl)Phenyl]-4,2′:6′,4′′-Terpyridine in Two Discrete Zinc(II) Complexes with
Acetylacetonate. Acta Cryst. C Cryst. Struct. Commun. 2012, doi:10.1107/S010827011203483X.
46. Pettinari, R.; Marchetti, F.; Condello, F.; Pettinari, C.; Lupidi, G.; Scopelliti, R.; Mukhopadhyay, S.; Riedel,
T.; Dyson, P.J. Ruthenium(II)–Arene RAPTA Type Complexes Containing Curcumin and
Bisdemethoxycurcumin Display Potent and Selective Anticancer Activity. Organometallics 2014, 33, 3709–
3715. doi:10.1021/om500317b.
47. Pettinari, R.; Marchetti, F.; Pettinari, C.; Condello, F.; Petrini, A.; Scopelliti, R.; Riedel, T.; Dyson, P.J.
Organometallic Rhodium(III) and Iridium(III) Cyclopentadienyl Complexes with Curcumin and
Bisdemethoxycurcumin Co-Ligands. Dalton Trans. 2015, 44, 20523–20531. doi:10.1039/C5DT03037D.
48. Triantis, C.; Tsotakos, T.; Tsoukalas, C.; Sagnou, M.; Raptopoulou, C.; Terzis, A.; Psycharis, V.; Pelecanou,
M.; Pirmettis, I.; Papadopoulos, M. Synthesis and Characterization of Fac -[M(CO) 3 (P)(OO)] and Cis-Trans.
-[M(CO) 2 (P) 2 (OO)] Complexes (M = Re, 99m Tc) with Acetylacetone and Curcumin as OO Donor Bidentate
Ligands. Inorg. Chem. 2013, 52, 12995–13003. doi:10.1021/ic401503b.

Molecules 2019, 24, 2540
20 of 20
49. Garai, A.; Pant, I.; Banerjee, S.; Banik, B.; Kondaiah, P.; Chakravarty, A.R. Photorelease and Cellular
Delivery of Mitocurcumin from Its Cytotoxic Cobalt(III) Complex in Visible Light. Inorg. Chem. 2016, 55,
6027–6035. doi:10.1021/acs.inorgchem.6b00554.
50. Pettinari, R.; Condello, F.; Marchetti, F.; Pettinari, C.; Smoleński, P.; Riedel, T.; Scopelliti, R.; Dyson, P.J.
Dicationic Ruthenium(II)-Arene-Curcumin Complexes Containing Methylated 1,3,5-Triaza-7-
Phosphaadamantane: Synthesis, Structure, and Cytotoxicity: Dicationic Ruthenium(II)-Arene-Curcumin
Complexes Containing Methylated 1,3,5-Triaza-7-Phosphaadamantane: Synthesis, Structure, and
Cytotoxicity. Eur. J. Inorg. Chem. 2017, 2017, 2905–2910. doi:10.1002/ejic.201700183.
51. Bhattacharyya, U.; Kumar, B.; Garai, A.; Bhattacharyya, A.; Kumar, A.; Banerjee, S.; Kondaiah, P.;
Chakravarty, A.R. Curcumin “Drug” Stabilized in Oxidovanadium(IV)-BODIPY Conjugates for
Mitochondria-Targeted
Photocytotoxicity.
Inorg.
Chem.
2017,
56,
12457–12468.
doi:10.1021/acs.inorgchem.7b01924.
52. Etter, M.C. Encoding and Decoding Hydrogen-Bond Patterns of Organic Compounds. Acc. Chem. Res. 1990,
23, 120–126. doi.org/10.1021/ar00172a005.
53. Douglas, B. B.; McDaniel, D.H.; Alexander, J.J. Concepts and Models of Inorganic Chemistry, 3rd ed.; Wiley:
New York, NY, USA, 1994.
54. Janiak, C. A Critical Account on π–π Stacking in Metal Complexes with Aromatic Nitrogen-Containing
Ligands. J. Chem. Soc. Dalton Trans. 2000, doi:10.1039/b003010o.
55. Priyadarsini, K.I.; Photophysics, Photochemistry and Photobiology of Curcumin: Studies from Organic
Solutions,
Bio-Mimetics
and
Living
Cells.
J.
Photochem.
Photobiol.
2009,
81–95.
doi:10.1016/j.jphotochemrev.2009.05.001.
56. Hotze, A.C.G.; van der Geer, E.P.L.; Kooijman, H.; Spek, A.L.; Haasnoot, J.G.; Reedijk, J. Characterization
by NMR Spectroscopy, X-Ray Analysis and Cytotoxic Activity of the Ruthenium(II) Compounds
[RuL3](PF6)2(L
= 2-Phenylazopyridine Oro-Tolylazopyridine) and [RuL’2L’’](PF6)2(L’, L’’ = 2-
Phenylazopyridine, 2,2’-Bipyridine). Eur. J. Inorg. Chem. 2005, 2005, 2648–2657. doi:10.1002/ejic.200500110.
57. Kolev, T.M.; Velcheva, E.A.; Stamboliyska, B.A.; Spiteller, M. DFT and Experimental Studies of the Structure
and Vibrational Spectra of Curcumin. Int. J. Quantum Chem. 2005, 102, 1069–1079. doi:10.1002/qua.20469.
58. Sanphui, P.; Goud, N.R.; Khandavilli, U.B.R.; Bhanoth, S.; Nangia, A. New Polymorphs of Curcumin. Chem.
Commun. 2011, 47, 5013. doi:10.1039/c1cc10204d.
59. Zeleňák, V.; Vargová, Z.; Györyová, K. Correlation of Infrared Spectra of Zinc(II) Carboxylates with Their
Structures. Spectrochim. Acta A 2007, 66, 262–272. doi:10.1016/j.saa.2006.02.050.
60. Nakamoto, K. Infrared and Raman Spectra of Inorganic and Coordination Compounds; Part. B: Applications in
Coordination, Organometallic, and Bioinorganic Chemistry, 6th ed.; John Wiley & Sons, Inc.: Hoboken, NJ, USA,
2008; pp.64–67. doi:10.1002/9780470405840.
61. Krackov, M.H.; Bellis, H.E. Process for the Synthesis of Curcumin-Related Compounds. WO9716403 (A1),
9 May 1997.
62. Phosphate-buffered saline (PBS) Available online: http://cshprotocols.cshlp.org/content/2006/1/pdb.rec8247
(accessed on 2 June 2019).
63. CrysAlis PRO. Version 1.171.35.11. Agilent Technologies.Yarnton, Oxfordshire, England, 2011.
64. Sheldrick, G.M. SHELXS97 and SHELXL97.Program for Crystal Structure Solution and Refinement. University
of Göttingen. Göttingen, 1997.
65. Macrae, C.F.; Edgington, P.R.; McCabe, P.; Pidcock, E.; Shields, G.P.; Taylor, R.; Towler, M.; van de Streek,
J. Mercury: Visualization and Analysis of Crystal Structures. J. Appl. Cryst. 2006, 39, 453–457.
doi:10.1107/S002188980600731X.
66. Farrugia, L.J. ORTEP -3 for Windowa–A Version of ORTEP -III with a Graphical User Interface (GUI). J.
Appl. Cryst. 1997, 30, 565–565. doi:10.1107/S0021889897003117.
67. CrystalMaker® X. Version 10.4.0. CrystalMaker Software Ltd. Oxfordshire, UK, 2019.
Sample Availability: Samples of the compounds are not available from the authors.
© 2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
