Azobenzene based 2D-MOF for high selective quinone fluorescence sensing performance

Article abstract of DOI:10.1016/j.ica.2020.119699

The present work describes development of a simple and cost-effective fluorescence sensor for determination of quinone specially 1,8-dihydroxyanthraquinone (danthron). A 2D-metal-organic framework (TMU-54) containing the azobenzene group has been synthesized and applied as an efficient fluorescent sensor for danthron detection. The key feature that has a great impact on the properties of the material is the presence and distribution of functional groups within the structure. We discuss the relationship between the nature and structure of the specifically designed organic linker as well as the properties of this framework in fluorescence recognition of quinones. TMU-54 ([Cd₃(adc)₆(DMF)₂]) is capable of distinguishing complementary and mismatched target sequences with high sensitivity and a significant K_sv (1049) value.

Full text of DOI:10.1016/j.ica.2020.119699

Inorganica Chimica Acta 510 (2020) 119699
Contents lists available at ScienceDirect
Inorganica Chimica Acta
journal homepage: www.elsevier.com/locate/ica
Research paper
Azobenzene based 2D-MOF for high selective quinone fluorescence sensing
performance
a
a
b,⁎
c
c
Fatemeh Parsa , Massomeh Ghorbanloo , Ali Morsali , Jun Wang , Peter C. Junk ,
d
Pascal Retailleau
a
Department of Chemistry, Faculty of Science, University of Zanjan, Zanjan, Iran
Department of Chemistry, Faculty of Sciences, Tarbiat Modares University, P.O. Box 14115-175, Tehran, Iran
College of Science & Engineering, James Cook University, Townsville, Qld 4811, Australia
Université Paris-Saclay, CNRS, Institut de Chimie des Substances Naturelles, UPR 2301, 91198 Gif-sur-Yvette, France
b
c
d
A R T I C L E I N F O
A B S T R A C T
Keywords:
The present work describes development of a simple and cost-effective fluorescence sensor for determination of
quinone specially 1,8-dihydroxyanthraquinone (danthron). A 2D-metal-organic framework (TMU-54) containing
the azobenzene group has been synthesized and applied as an efficient fluorescent sensor for danthron detection.
The key feature that has a great impact on the properties of the material is the presence and distribution of
functional groups within the structure. We discuss the relationship between the nature and structure of the
specifically designed organic linker as well as the properties of this framework in fluorescence recognition of
Metal-organic framework
Fluorescence sensing, Quinone sensing
Azobenzene groups
3 6 2
quinones. TMU-54 ([Cd (adc) (DMF) ]) is capable of distinguishing complementary and mismatched target
sequences with high sensitivity and a significant Ksv (1049) value.
1. Introduction
their tunability through targeted selection of ligands and metal nodes
for specific applications such as catalysis, sensing, and hazardous ma-
terial removal [13–20]. Over the recent years, the role of functional
groups in implementing various applications has been significant
[21–23]. MOFs containing photoresponsive building blocks, such as
azobenzene, aryl azide, and nitrobenzyl groups are currently in the
spotlight due to their potential applications in different areas including
molecular sensing and catalysis [24–27]. Thus, MOFs containing one of
these functional groups offer a leading strategy for realizing long-range
manipulation of their functions with adjustable specificity. Because of
their photochemical isomerization with ultraviolet or visible light,
azobenzene derivatives have been investigated as photo-switches that
provide extensive geometrical changes [28,29]. Their isomerization
ability could provide a significant alteration in polarity [30,31]. Due to
the advantages mentioned above, in the past decade, many MOFs em-
ployed as ideal luminescent materials, have been reported for sensing of
different kinds of pollutants [32]. MOFs have been applied as chemical
sensors for detecting different types of analytes such as metal ions,
small-molecules, volatile organic compounds, nitroaromatics, anions,
and bio-chemicals. Considering their widespread release in the nature
and their critical hazards on the environment and human body, de-
tection of metal ions through MOFs has received a lot of attention over
the past few years [33,34].
Quinones, hydroquinones, semiquinones, and their derivates have
been found to undergo rapid single-electron reduction that is highly
damaging to biological molecules [1,2]. Exposure of humans and
wildlife to quinones and the inherent reactivity of released single-
electrons may induce adverse health and toxicity effects [3,4]. An-
thraquinones are also a subgroup of quinone derivatives whose study is
very important because of their structural correlation with quinone
antitumor drugs and anthraquinoid vat dyes [5]. On the other hand, it
is all the more important as the α-hydroxy groups are present in a large
number of natural anthraquinones which have found many applications
in the composition of pharmaceuticals and physiologically active sub-
stances [6–8]. They are also important as dyes, analytical reagents,
indicators, and in other applications. Despite this importance, few
studies have been done to identify these substances and there is no
report in the literature on using porous materials as sensor probes for
determination of these materials [9,10].
Owing to their unique characteristics like crystalline hybrid struc-
ture, high porosity and surface area, mixed inorganic-organic nature,
structural stability and designability in chemical functionality, metal-
organic frameworks (MOFs) have been applied in a large variety of
applications [11,12]. Perhaps the most important feature of the MOFs is
⁎
Corresponding author.
E-mail address: Morsali_a@modares.ac.ir (A. Morsali).
https://doi.org/10.1016/j.ica.2020.119699
Received 26 February 2020; Received in revised form 23 April 2020; Accepted 23 April 2020
Available online 01 May 2020
0020-1693/ © 2020 Elsevier B.V. All rights reserved.

F. Parsa, et al.
Inorganica Chimica Acta 510 (2020) 119699
2. Experimental
2.1. Synthesis of the azobenzene-based ligand
The azobenzene-4,4-dicarboxylic acid (adc) linker was synthesized
according to the previously reported procedure [17]. Also for more
information, the synthesis has been discussed in the supporting in-
formation (Scheme 1).
2.2. Synthesis of TMU-54 ([Cd
3
(adc)
6
(DMF)
2
])
Scheme 1. Schematic presentation of azobenzene-4,4-dicarboxylic acid (adc)
linker.
The single crystals of TMU-54 ([Cd
sized by heating a mixture of 1 mmol adc ligand (0.27 g), 1 mmol of Cd
NO ·4H O (0.3 g) and DMF (15 mL) in a Teflon-lined stainless steel
autoclave under autogenous pressure at 100 °C for 2 days. After cooling
3
(adc) (DMF) ]) were synthe-
6 2
(
3
)
2
2
Luminescent metal–organic frameworks (LMOFs) have several key
advantages over other luminescent probe materials [35]. The natural
crystallinity of metal–organic frameworks allows exact structure de-
termination by X-ray crystallography, providing precise information
about atomic positions and the interactions that may be used in various
applications. Long range interactions include radioactive energy
transfer, in which target molecules absorb emissions from the probe
material [36,37].
−1
to room temperature at the rate of 5 °C h , TMU-54 red crystals were
−
1
obtained in 40% yield. m.p.: 300 °C. FT-IR data (KBr pellet, cm ):
selected bands are: 673 (m), 789 (m), 1012 (m), 1388 (m), 1620 (s),
1665 (vs) and 3410 (br).
2.3. General method of quinine derivatives fluorescence sensing
Herein, inspired by this approach, we report the synthesis of a 2D
luminescent MOF containing an azobenzene group. The chosen ligand
was azobenzene-4,4-dicarboxylic acid (adc) (Scheme 1) which led to
synthesis of TMU-54 ([Cd (adc) (DMF) ]). The sensitivity of TMU-54
3 6 2
towards quinone derivatives was studied in an ethanolic solution. This
All the fluorescence titrations were carried out with a 3 mg stable
suspension of reported crystals in 3 mL ethanolic solution of quino-
lones. Excitation and emission wavelengths of the compound TMU-54
in ethanol were 370 nm and 430 nm, respectively.
It should be noted that before any sensing process, the crystal ac-
tivation was done. The trapped solvent was removed by soaking the
structure can act as a turn-off fluorescence sensor for quinones.
synthesized crystals in 15 mL of CH
onitrile was exchanged every 24 h and after 3 days the solvent was
decanted. Finally, the CH CN was evaporated by heating the crystals at
20 °C for 24 h. The activation was confirmed by FT-IR spectroscopy
3
CN solvent for 4 days. Fresh acet-
3
1
Fig. 1. Coordination environment around Cd atoms (A), separated chains of the supramolecular structure (B), 3D structure of TMU-54 (C), and simplified structure of
TMU-54 (D).
2

F. Parsa, et al.
Inorganica Chimica Acta 510 (2020) 119699
(
(
absence of the peak at 1666 cm−1) and powder X-ray diffraction
stability in the crystal structure).
directly. A very critical advantage of PL-methods is that both powder
and crystal of LMOFs can be applied in metal ion detection without the
need for film fabrication [35]. Therefore, considering the hybrid nature
of MOFs and, they can rise to optical emission and transduce special
kind of signals under photoinduced excitation conditions which is a
very favorable behavior for PL-methods. Various fluorescence-based
chemosensors were used for the detection of different analytes but
using LMOF due to the minimum material consumption is considered
cost-effective. As a result, MOF-based sensor materials have been ex-
tensively applied in photoluminescence-based methods as the most
widely explored technique for detection of metal ions to date. Due to
the fact that Cd2+ (d ) is the metal used to synthesize TMU-54, the
fluorescence is ligand-derived. Given the structural properties of the
structure’s ligands and their ability to form hydrogen bonding, electron
donation of azobenzene group, and probability of π-π stacking with the
guest molecule, quinone derivatives were selected as target structures
for detection. Model experiments were conducted to demonstrate our
assumption and evaluate the sensing ability of TMU-54 to benzoqui-
none, naphthoquinone, anthraquinone, phenol, and 1,8-dihydroxyan-
thraquinone. Stern–Volmer equation has generally been proposed to
investigate the response to quenching of various analytes (see the
supporting information). The results are presented in Table 1, which
show that TMU-54 is a turn-off fluorescence detector for quinone de-
rivatives. As it is shown in Table 1, the structure of TMU-54 acts as a
turn-off fluorescence sensor to quinone derivatives, but does not show
any particular reaction in the presence of 1,8-dihydroxyanthraquinone.
The order of quenching efficiency in the presence of TMU-54 is 1,8-
dihydroxyanthraquinone > Naphthoquinone > 1,4-
3. Results and discussion
3.1. Characterization of TMU-54
TMU-54, was synthesized to have a centrosymmetric triclinic space
group (P-1). Crystal data with data collection and refinement para-
meters are summarized in Table S1, also selected bond distances and
angles are given in Table S2. The hourglass-like [Cd
the TMU-54 ([Cd (adc) (DMF) ]) contains two different Cd(II) centers
in which Cd is connected by six oxygen atoms (Cd ) of six different
adc linkers creating an octahedral environment, while Cd has seven
coordinated geometry interacting with six oxygen atoms of three adc
ligands and one oxygen atom from a coordinated DMF molecule. The
3 6
(COO) ] SBUs of
10
3
6
2
1
1 6
O
2
distance between the two cadmium atoms in hourglass-like Cd
.412 Ȧ. The three ligands attached to each Cd atom are spaced apart
in the space between the three ligands attached to another Cd atom
3
SBU is
3
1
1
with opposite orientation (Fig. 1). This particular orientation and in-
terpenetration leads to the reduction of free space in the structure. The
supramolecular features of TMU-54 are controlled by weak directional
intermolecular interactions. The π-π stacking interactions through iso-
lated chains create a 3D supramolecular framework. To investigate the
porosity of these structures, the Brunauer-Emmett-Teller (BET) mea-
surements of N
2
gas were f demonstrate that TMU-54 has a surface area
2
of 35.7 m /g (Fig. 2).
Benzoquinone > Anthraquinone (Figs. S2 and S3 and Fig. 4).
3
.2. Thermal stability studies of TMU-54
Quinones have a low-lying unoccupied π* orbital, which can accept
an electron from the excited state chemophore, thus efficiently
quenching the fluorescence emission of this compound but in the case
of 1,8-dihydroxyanthraquinone sensing by TMU-54, the proximity of
the excitation wavelength of the guest to the emission wavelength of
the host justifies the observed effect. For compounds containing α-hy-
droxy group tautomerism involves a proton transfer along a conjuga-
tion chain from hydroxy group and adjacent carbonyl group [31]. In-
termolecular hydrogen bonding as well as the π-π stacking interaction
can also be effective in danthron sensing by TMU-54.
Thermogravimetric analysis (TGA) of the TMU-54 shows the good
thermal stability of the structure. The two-step gradual weight loss (in
temperature range of 325–500 °C) corresponds to the decomposition of
the framework (calc.: 67%, found: 65.5%) corresponding to the se-
paration of the ligand connected to the metal node. Therefore, the
structure is stable at temperatures up to 300 °C (Fig. 3 and Figs. S2–S5).
3
.3. Quinoline-sensing ability of TMU-54
The UV–Vis spectra of all the analytes have been studied (Fig. 5).
The overlap of the fluorescence emission spectrum of the sensor with
the absorption spectrum of the analytes is a more important factor.
When the proximity between a donor and an acceptor, with sufficient
spectral overlap, is of < 10 nm the energy transfer process can be
achieved. The large overlap of TMU-54 emission peak with the ab-
sorption spectrum of danthron and the lack of spectral overlap between
TMU-54 and other analytes confirm the energy transfer process me-
chanism in 1,8-dihydroxyanthraquinone sensing by TMU-54 (Fig. 5).
The XRD patterns of TMU-54 before and after the sensing process
are shown in Fig. 6. The intact patterns show that the structures remain
unchanged during the sensing process (see Fig. 6).
Owing to photophysical properties of MOFs in signal transduction
and advantages of photoluminescence (PL) methods, PL-based methods
have received more attention compared to other methods. PL methods
are highly sensitive with reachable single molecular detection limits,
easily manipulable, practical in real-life and in-field applications, with
rapid response time, and able to be addressed by powdered materials
As a result, we can clearly argue that fine tuning of MOF cavities
with ideal organic functional groups can provide situations resulting in
high sensing ability of MOFs despite their moderate surface areas.
Considering this point, we applied azobenzene decorated TMU-54 for
sensing of 1,8-dihydroxyantraquinone to take advantage of its strong
and improved characteristics. Therefore, TMU-54 shows high sensi-
tivity towards 1, 8-dihydroxyantraquinone (Ksv > 1040) compared
with other quinone derivatives.
4. Conclusion
In this work we synthesized a fluorescent MOF (TMU-54) by the
solvothermal method. The sensing ability of TMU-54 (containing the
same azobenzene functional group) toward quinone derivatives was
studied. The activated TMU-54 can selectively detect quinones and
2
Fig. 2. N adsorption–desorption isotherms of TMU-54 (B).
3

F. Parsa, et al.
Inorganica Chimica Acta 510 (2020) 119699
Fig. 3. Fluorescence emission spectra of TMU54 dispersed in EtOH solution of hydroxyanthraquinone at different concentrations, excited at 360 nm (b) Stern–Volmer
SV) plots in the presence of 5 mg of TMU-54 and in different concentration of 1,8-dihydroxyanthraquinone.
(
Table 1
especially 1,8 dihydroxyanthraquinone (danthron). Fluorescence titra-
tion experiments confirmed that TMU-54 shows selective detection
The Ksv values (S−1) obtained from quinones sensing by TMU-
5
4.
towards quinones in the presence of other compounds and also de-
−5
monstrates a detection limit of 1 × 10 M for 1,8-dihydroxyan-
thraquinone. On the other hand, TMU-54 can detect quinones with
lower Ksv values, expect for anthron. Investigations reveal that Lewis
basicity and electron donation of azobenzene (eCeN]NeCe) have
significant effects on danthron sensing by TMU-54. This type of inter-
action is beneficial to such fast and sensitive detection abilities.
Analyte
TMU-54
Naphthoquinone
,4-Benzoquinone
Anthraquinone
,8-dihydroxyanthraquinone
880
248
122
1049
1
1
Fig. 4. Fluorescence spectra of other studied analytes, excited at 370 nm.
4

F. Parsa, et al.
Inorganica Chimica Acta 510 (2020) 119699
quinone methides, and quinone-thioethers, Curr. Drug Metab. 3 (2002) 425–438.
4] I. Klopčič, M.S. Dolenc, Chemicals and drugs forming reactive quinone and quinone
imine metabolites, Chem. Res. Toxicol. 32 (2018) 1–34.
[
[
5] S. Celik, F. Ozkok, S. Akyuz, A.E. Ozel, The importance of anthraquinone and its
analogues and molecular docking calculation, in: Computational Models for
Biomedical Reasoning and Problem Solving, IGI Global, 2019, pp. 177–205.
6] R.J. Knox, Use of alpha-hydroxy carbonyl compounds as reducing agents, Google
Patents, 2018.
[
[
7] A.M. Ramezani, S. Yousefinejad, A. Shahsavar, A. Mohajeri, G. Absalan,
Quantitative structure-retention relationship for chromatographic behaviour of
anthraquinone derivatives through considering organic modifier features in mi-
cellar liquid chromatography, J. Chromatogr. A (2019).
[
[
8] V.Y. Fain, B. Zaitsev, M. Ryabov, Anthraquinones tautomerism: VII. Hydroxy-sub-
stituted anthraquinones, Russ. J. Org. Chem. 43 (2007) 1460–1465.
9] X.-Y. Chen, Z.-M. Ou, G.-Q. Ying, Separation and purification of (S)-β-hydroxy
phenylpropionate from microbe, Conv. Solution Zhejiang Chem. Ind. (2010) 7.
[
10] Y.-T. Chou, F.-F. Hsu, D.-Y. Hu, Y.-C. Chen, Y.-H. Hsu, J.T.-A. Hsu, L.-Y. Chau,
Identification of danthron as an isoform-specific inhibitor of HEME OXYGENASE-1/
cytochrome P450 reductase interaction with anti-tumor activity, J. Biomed. Sci. 25
(2018) 6.
[
[
[
11] L.E. Kreno, K. Leong, O.K. Farha, M. Allendorf, R.P. Van Duyne, J.T. Hupp,
Metal–organic framework materials as chemical sensors, Chem. Rev. 112 (2011)
1
105–1125.
12] H. Furukawa, N. Ko, Y.B. Go, N. Aratani, S.B. Choi, E. Choi, A.Ö. Yazaydin,
R.Q. Snurr, M. O’Keeffe, J. Kim, Ultrahigh porosity in metal-organic frameworks,
Science 329 (2010) 424–428.
13] M. Joharian, A. Morsali, A.A. Tehrani, L. Carlucci, D.M. Proserpio, Water-stable
fluorinated metal–organic frameworks (F-MOFs) with hydrophobic properties as
efficient and highly active heterogeneous catalysts in aqueous solution, Green
Chem. 20 (2018) 5336–5345.
Fig. 5. Comparative Ksv of TMU-54 in different organics.
[
[
14] M.-L. Hu, M.Y. Masoomi, A. Morsali, Template strategies with MOFs, Coord. Chem.
Rev. 387 (2019) 415–435.
15] F. Rouhani, A. Morsali, P. Retailleau, Simple one-pot preparation of a rapid re-
sponse AIE fluorescent metal-organic framework, ACS Appl. Mater. Interfaces 10
(2018) 36259–36266.
[
16] N. Contreras-Pereda, P. Hayati, S. Suárez-García, L. Esrafili, P. Retailleau,
S. Benmansour, F. Novio, A. Morsali, D. Ruiz-Molina, Delamination of 2D co-
ordination polymers: the role of solvent and ultrasound, Ultrason. Sonochem. 55
(2019) 186–195.
[
17] F. Parsa, M. Ghorbanloo, M.Y. Masoomi, A. Morsali, P.C. Junk, J. Wang,
Ultrasound-assisted synthesis and characterization of a new metal-organic frame-
work based on azobenzene-4, 4-dicarboxylic acid: precursor for the fabrication of
Co3O4 nano-particles, Ultrason. Sonochem. 45 (2018) 197–203.
[
18] L. Esrafili, M. Gharib, A. Morsali, The targeted design of dual-functional meta-
l–organic frameworks (DF-MOFs) as highly efficient adsorbents for Hg 2+ ions:
synthesis for purpose, Dalton Trans. 48 (2019) 17831–17839.
[
19] L. Esrafili, A.A. Tehrani, A. Morsali, L. Carlucci, D.M. Proserpio, Ultrasound and
solvothermal synthesis of a new urea-based metal-organic framework as a precursor
for fabrication of cadmium (II) oxide nanostructures, Inorg. Chim. Acta 484 (2019)
3
86–393.
[
[
20] V. Safarifard, A. Morsali, Sonochemical syntheses of a nano-sized copper (II) su-
pramolecule as a precursor for the synthesis of copper (II) oxide nanoparticles,
Ultrason. Sonochem. 19 (2012) 823–829.
21] Z. Wang, L. Heinke, J. Jelic, M. Cakici, M. Dommaschk, R.J. Maurer, H. Oberhofer,
S. Grosjean, R. Herges, S. Bräse, Photoswitching in nanoporous, crystalline solids:
an experimental and theoretical study for azobenzene linkers incorporated in MOFs,
Phys. Chem. Chem. Phys. 17 (2015) 14582–14587.
Fig. 6. Comparison of TMU-54 XRD patterns before and after the sensing pro-
cess with the simulated one.
[
22] D.G.D. Patel, I.M. Walton, J.M. Cox, C.J. Gleason, D.R. Butzer, J.B. Benedict,
Photoresponsive porous materials: the design and synthesis of photochromic dia-
rylethene-based linkers and a metal–organic framework, Chem. Commun. 50
Declaration of Competing Interest
(
2014) 2653–2656.
The authors declare that they have no known competing financial
interests or personal relationships that could have appeared to influ-
ence the work reported in this paper.
[
23] T. Zhou, Y. Du, A. Borgna, J. Hong, Y. Wang, J. Han, W. Zhang, R. Xu, Post-
synthesis modification of a metal–organic framework to construct a bifunctional
photocatalyst for hydrogen production, Energy Environ. Sci. 6 (2013) 3229–3234.
24] H. Huang, H. Sato, T. Aida, Crystalline nanochannels with pendant azobenzene
groups: steric or polar effects on gas adsorption and diffusion? J. Am. Chem. Soc.
139 (2017) 8784–8787.
25] J. Hao, X. Xu, H. Fei, L. Li, B. Yan, Functionalization of metal-organic frameworks
for photoactive materials, Adv. Mater. 30 (2018) 1705634.
26] X. Yang, X. Lin, Y.S. Zhao, D. Yan, Recent advances in micro-/nanostructured metal-
organic frameworks towards photonic and electronic applications, Chemis. Eur. J.
[
Acknowledgement
[
This investigation was supported by Tarbiat Modares University and
University of Zanjan.
[
2
4 (2018) 6484–6493.
[
27] F. Zhao, Optical Control of “All Visible” Fluoroazobenzene-Containing
Architectures: From Small Molecules to 3D Networks, (2018).
Appendix A. Supplementary data
[
28] D. Bléger, J. Schwarz, A.M. Brouwer, S. Hecht, o-Fluoroazobenzenes as readily
synthesized photoswitches offering nearly quantitative two-way isomerization with
visible light, J. Am. Chem. Soc. 134 (2012) 20597–20600.
Supplementary data to this article can be found online at https://
doi.org/10.1016/j.ica.2020.119697.
[
[
[
29] H.-T. Zhang, J.-W. Zhang, G. Huang, Z.-Y. Du, H.-L. Jiang, An amine-functionalized
metal–organic framework as a sensing platform for DNA detection, Chem. Commun.
50 (2014) 12069–12072.
References
30] D. Samanta, J. Gemen, Z. Chu, Y. Diskin-Posner, L.J. Shimon, R. Klajn, Reversible
photoswitching of encapsulated azobenzenes in water, Proc. Nat. Acad. Sci. 115
[
[
1] R. Mopton, Biochemistry of quinones, Biochemistry of quinones, (1965).
2] J.L. Bolton, M.A. Trush, T.M. Penning, G. Dryhurst, T.J. Monks, Role of quinones in
toxicology, Chem. Res. Toxicol. 13 (2000) 135–160.
(2018) 9379–9384.
31] M.R. Molla, P. Rangadurai, L. Antony, S. Swaminathan, J.J. de Pablo,
S. Thayumanavan, Dynamic actuation of glassy polymersomes through isomeriza-
tion of a single azobenzene unit at the block copolymer interface, Nat. Chem. 10
[3] T.J. Monks, D.C. Jones, The metabolism and toxicity of quinones, quinonimines,
5

F. Parsa, et al.
Inorganica Chimica Acta 510 (2020) 119699
[36] A. Mallick, A.M. El-Zohry, O. Shekhah, J. Yin, J. Jia, H. Aggarwal, A.-H. Emwas,
O.F. Mohammed, M. Eddaoudi, Unprecedented ultralow detection limit of amines
using a thiadiazole-functionalized Zr (IV)-based metal-organic framework, J. Am.
Chem. Soc. 141 (2019) 7245–7249.
[37] C.-X. Yao, N. Zhao, J.-C. Liu, L.-J. Chen, J.-M. Liu, G.-Z. Fang, S. Wang, Recent
progress on luminescent metal-organic framework-involved hybrid materials for
rapid determination of contaminants in environment and food, Polymers 12 (2020)
691.
(2018) 659.
[
[
[
[
32] O. Shekhah, J. Liu, R. Fischer, C. Wöll, MOF thin films: existing and future appli-
cations, Chem. Soc. Rev. 40 (2011) 1081–1106.
33] A.U. Czaja, N. Trukhan, U. Müller, Industrial applications of metal–organic fra-
meworks, Chem. Soc. Rev. 38 (2009) 1284–1293.
34] Y.-R. Lee, J. Kim, W.-S. Ahn, Synthesis of metal-organic frameworks: a mini review,
Korean J. Chem. Eng. 30 (2013) 1667–1680.
35] Y. Zhang, S. Yuan, G. Day, X. Wang, X. Yang, H.-C. Zhou, Luminescent sensors based
on metal-organic frameworks, Coord. Chem. Rev. 354 (2018) 28–45.
6
