H.F. Xiang et al. / Electrochimica Acta 55 (2010) 5204–5209
5205
in the LiCoO2/Li cells. This approach provides an effective route to
overcome the shortcomings of pure RTIL-based electrolyte for the
application in Li-ion batteries.
2. Experimental
2.1. Synthesis of LiTFSI-RTIL electrolytes
N-methyl-N-propylpiperidinium bis(trifluoromethanesulfonyl)
imide (PP13TFSI) was prepared by stirring two aqueous solutions of
PP13-Br and LiTFSI (Ferro, battery grade) at room temperature for
12 h. The amount of LiTFSI was slightly in excess versus that of PP13-
Br. PP13-Br was obtained by adding propylbromide (Sinopharm
Chemical Reagent Co., Ltd, as received) to N-methylpiperidine
(Aldrich, as received) in acetonitrile at 70 ◦C with stirring for 24 h.
The resulting RTIL PP13TFSI was extracted by CH2Cl2 and then
washed with water. Finally, the RTIL was dried in vacuum at 80 ◦C
for 48 h, followed by a storage in an argon-filled glove box (Mbraun
Labmaster 130). The chemical structure and the purity of PP13TFSI
were confirmed by 1H NMR (Bruker, 300 M) and thermogravimetric
(TG) measurement (Shimadzu).
Fig. 1. Schematic illustration of the molecular structure of cation and anion from
the room temperature ionic liquid (PP13TFSI).
For the CV test, the voltage range was set at 3.0–0 V, and for the
LSV, the voltage was limited to 6.0 V.
The thermal stability of different electrolytes with charged
LiCoO2 electrode was evaluated by using a Calvet-type calorime-
ter (Setaram C80). LiCoO2/Li cells with different electrolytes were
charged to 4.2 V after three formation cycles, followed by being
disassembled in the glove box. The charged electrodes were rinsed
in dimethyl carbonate (DMC) and then dried in vacuum. Finally,
a mixture of 20 mg electrolyte supplied and 20 mg charged elec-
trode materials scraped from the aluminum foil was placed in a
high-pressure stainless steel vessel with dry argon atmosphere.
The measurement was performed in the temperature range from
ambient temperature to 300 ◦C at a 0.2 ◦C min−1 heating rate.
The binary LiTFSI-RTIL electrolytes were prepared with different
concentrations, i.e. 0.1, 0.2, 0.3 and 0.4 mol kg−1 in the glove box.
Another two electrolytes containing diethyl carbonate (DEC) were
prepared by adding LiTFSI into the mixture of RTIL and DEC; and
the two electrolytes have 20 wt.% and 40 wt.% DEC (compared to the
weight of RTIL) with the same amount of the salt corresponding to
3. Results and discussion
0.4 mol kg−1
.
3.1. Structure and thermal behavior of PP13TFSI
2.2. Thermal, electrical and electrochemical characterization of
LiTFSI-RTIL electrolytes
The structure of PP13TFSI (Fig. 1) was confirmed by 1H NMR
spectra (CDCl3, chemical shift, ppm relative to TMS): 3.4 (3H, 1),
1.1 (3H, 4), 3.8 (2H, 2), 3.6–3.7(4H, 5,9), 1.6–1.9(8H, 3,6,7,8). Fig. 2
shows the TG/DTA curves of the RTIL synthesized, which confirms
the expected high thermal stability. From the TG curve, the RTIL
only exhibits a decomposition process starting at 342 ◦C and ending
at 484 ◦C, with ∼100% weight loss. The DTA curve also indicates only
one endothermic decomposition process with a peak at 453 ◦C, and
the heat generation is −153.5 J g−1. The TG/DTA results also validate
that the RTIL that we have synthesized has the high purity.
The melting point of RTIL was measured by differential scan-
ning calorimetry (DSC, Shimadzu) in the temperature range from
−60 ◦C to 150 ◦C at the heating rate of 10 ◦C min−1. The ionic con-
ductivities of RTIL and the electrolyte solutions were measured
over a wide temperature range of −30 to 90 ◦C using a Model DDS-
307A conductometer (Shanghai Precision & Scientific Instrument
Co. Ltd., China). Each conductivity measurement at a given tem-
perature was carried out after holding the electrolyte solution at
the temperature for 30 min in order to reach full thermal equilibra-
tion. The temperature of the electrolyte solution and subsequent
cell testing at low temperatures was controlled by a WD4005
low-temperature chamber (Shanghai Experimental Equipment Co.
Ltd., China). The lithium transference number was determined
cursorily by a dc polarization method with a CHI604 Electro-
chemical Workstation [15]. By applying a small dc pulse (0.08 V
here) to a symmetrical Li/electrolyte/Li cell and measuring the
initial current, I0, and the steady-state current, Iss, which flow
through the cell, the lithium ion transference number, tLi+ , is sim-
ply given by the equation: tLi+ = Iss/I0 [16]. The self-extinguishing
time (SET) was measured to evaluate the flammability of the elec-
trolytes, and the detailed procedures were described elsewhere
[17,18].
The electrochemical stability of PP13TSFI is investigated by the
voltammetry, including CV and LSV shown in Figs. 3 and 4. As shown
in Fig. 3, the negligible electrochemical behavior with the peak cur-
CR2032 coin cells were used for measuring the electrochemical
properties and cell performances. A positive electrode consisting of
84 wt.% LiCoO2, 8 wt.% acetylene black and 8 wt.% PVDF were made
on aluminum foils, with the mass loading of 1.5 mg cm−2 active
material. All cells were assembled in the glove box and then gal-
vanostatically cycled on a multi-channel battery cycler (Neware
BTS2300, Shenzhen). For all the LiCoO2/Li cells, the cutoff voltages
were set at 2.8 and 4.2 V. Cyclic voltammetry (CV) and linear sweep
voltammetry (LSV) (CHI604 Electrochemical Workstation) were
used to study the electrochemical stability of the RTIL-based elec-
trolyte in the stainless steel (SS)/Li cells at a scan rate of 0.2 mV s−1
.
Fig. 2. TG/DTA curves of PP13TFSI synthesized. The heating rate is 10 ◦C min−1
.
