Reactors have a central port, which receives the agitation
bearing through which the stirrer passes. Agitation speed
inside the reactors is fixed by stirring motors. Reactors also
have four connection pipes, which enable the introduction
of the temperature and calibration probes as well as any other
accessory (a pH probe, for example). Reagents are added in
the calorimeter using a dosing funnel or a driven syringe
pump. All the accessories are held in place using glass pipes.
Therefore, installing and starting up the DRC are very easy
operations.
Figure 5. Reaction scheme of the hydrolysis of acetic anhy-
dride.
same temperature as that of the measure reactor, avoiding
the perturbation by the sensible heat of addition. This
procedure allows for checking the effect of the sole viscosity
on calorimetric measurement. From the heat input of 15 kJ
the integration of the signal using a linear interpolation of
UA rends 13.5 kJ (-10.0%). As a comparison, a simulta-
neous addition of 50 mL of the PEG 3000 solution to both
reactors was performed: the integration of the signal gives
13.2 kJ (-12.0%). The results can be improved by taking
into account the nonlinear variation of calorific sensitivity
(UA) using a spreadsheet: the first experiment gives 14.7
kJ (-2.0%), and the second, 14.2 kJ (-5.3%).
These results are within the commonly accepted tolerance
of (15% for safety screening, showing that the approxima-
tion made in eq 1 is valid in this frame.
To test the calorimeter under more realistic conditions,
two reactions have been studied in the DRC, using the
isothermal batch and semi-batch operation.
Since this calorimeter is operated as a differential
calorimeter, the question of symmetry and especially of loss
of symmetry during a reaction arises.
3.4. Effect of Loss of Symmetry on the Performance
of the Differential Calorimeter. Equation 1 assumes the
same calorific sensitivity (UA) in both measure and reference
reactors, but during performance of a reaction this term may
vary either due to the change of the heat-exchange area of
the measure reactor resulting from addition of a reactant in
semi-batch operation or due to a viscosity change in the
measure reactor resulting from the chemical reaction.
To study the effect of a volume increase in the sole
measure reactor, a semi-batch reaction was simulated by
charging 100 mL of water into both measure and reference
reactors. Then 100 mL (doubling of volume) of water was
added to the measure reactor only with a simultaneous heat
input from the calibration heater. The added water was
maintained at the same temperature as that of the measure
reactor, avoiding the perturbation by the sensible heat of
addition. From the heat input of 15 kJ the integration of the
signal using a linear interpolation of UA rends 13.1 kJ
4. Example 1: Hydrolysis of Acetic Anhydride
4
.1. Reaction. The first reaction studied is a classical
“
calibration” reaction for calorimeters: the hydrolysis of
acetic anhydride (Figure 5). It is a fast reaction well suited
for checking the dynamic response of a calorimeter. It has
been studied in batch mode using the DRC and the 250-mL
reactors.
Acetic anhydride was obtained from Fluka (Fluka 45830,
puris. p.a. ACS g 99.5%). Deionized water was used.
(-12.7%). As a comparison, a simultaneous addition of 50
mL of water to both reactors was also performed: the
integration of the signal gives 13.4 kJ (-10.7%). The results
can be improved by taking into account the nonlinear
variation of the heat-exchange area (A) using a spreadsheet:
the first experiment gives 14.5 kJ (-3.3%), and the second,
4
.2. Experimental Procedure. The reaction has been
performed as an isothermal batch operation at three different
temperatures 10, 25, and 40 °C. The reactor is thermally
equilibrated at working temperature and only contains the
solvent: 150 g (8.33 mol) of water. A heated dosing funnel,
maintained at the temperature of the experiment, was used
to introduce 12 g (0.12 mol) of acetic anhydride in one
portion. The reference reactor contains 160 g of water, which
is almost equal to the final reaction mass in the working
reactor. In these conditions, symmetry is maintained between
both reactors; hence, U and A are very similar in both
reactors, and UA may be measured only once at the end of
the experiment.
14.2 kJ (-5.3%).
The other common cause for loss of symmetry is viscosity
change. A series of calibrations was performed with water
in the measure reactor and poly(ethylene glycol) (PEG 3000)
-
1
solutions 500 and 700 g‚L in water into the reference
reactor. These concentrations represent a change of the
viscosity by ca. 140 mPa‚s. The calorific sensitivities (UA)
-1
increased by 0.37 and 0.47 W‚K , but this had no significant
effect on the determination of the specific heat capacities,
-1
-1
which remained constant at 4.10 ( 0.03 J‚g ‚K . The PEG
solution was added into the reference reactor to maintain
the specific heat capacity of the measure reactor contents
constant.
4.3. Results. The evolution of the working reactor
temperature as a function of time allows following the
reaction progress qualitatively: that is, the temperature returns
to its initial value (baseline) after about 45 min at 40 °C. In
the example shown in Figure 6, the maximum heat release
To ensure conditions that are closer to practical ones, a
semi-batch reaction was simulated by charging 100 mL of a
-
1
5
00 g‚L solution of poly(ethylene glycol) in water into
-
1
both measure and reference reactors. Then 50 mL of water
was added to the measure reactor and within the same time
was added 50 mL of the same PEG solution into the
reference reactor with a simultaneous heat input from the
calibration heater. The added solution was maintained at the
rate was found ca. 90 W‚kg , which would require a rather
high cooling capacity for an industrial reactor. The reaction
enthalpy is obtained by integration of the temperature
difference with time using the Joule effect calibration
performed at the end of the experiment with a horizontal
918
•
