Identification of a buried pocket for potent and selective
inhibition of Chk1: Prediction and verification
Nicolas Foloppe,* Lisa M. Fisher, Geraint Francis, Rob Howes,
Peter Kierstan and Andrew Potter
Vernalis (R&D) Ltd, Granta Park, Abington, Cambridge CB1 6GB, UK
Received 7 June 2005; revised 10 October 2005; accepted 18 October 2005
Available online 9 November 2005
Abstract—Inhibition of the Chk1 kinase by small molecules binding to its active site is a strategy of great therapeutic interest for
oncology. We report how computational modelling predicted the binding mode of ligands of special interest to the Chk1 ATP site,
for representatives of an indazole series and debromohymenialdisine. These binding modes were subsequently confirmed by X-ray
crystallography. The binding mode of a potent indazole derivative involves non-conventional C–Hꢀ ꢀ ꢀO and N–Hꢀ ꢀ ꢀp-aromatic
interactions with the protein. These interactions are formed in a buried pocket at the periphery of the ATP-binding site, the impor-
tance of which has previously been overlooked for ligand design against Chk1. It is demonstrated that filling this pocket can confer
ligands with dramatically enhanced affinity for Chk1. Structural arguments in conjunction with assay data explain why targeting this
pocket is also advantageous for selective binding to Chk1. Structural overlays of known inhibitors complexed with Chk1 show that
only the indazole series utilizes the pocket of interest. Therefore, the analysis presented here should prove helpful in guiding future
structure-based ligand design efforts against Chk1.
ꢀ 2005 Elsevier Ltd. All rights reserved.
1. Introduction
series elaborated around an indazole core, which in-
cludes at least 13 compounds.11,24 Structural information
for DBH bound to Chk1 is also lacking. Importantly, the
indazole series includes compound 1 (Table 1), one of the
most potent Chk1 inhibitors reported to date.
The human Chk1 kinase, which plays an essential role in
the regulation of the cell cycle G2/M checkpoint,1–10 is a
promising target for the development of small molecule
inhibitors against cancer.11–20 Selective Chk1 inhibitors
should also prove useful to study the regulation of the
G2/M checkpoint from a fundamental biology point of
view.
We present how molecular modelling successfully pre-
dicted the binding mode of key representatives of the
indazole series (compounds 1 and 2) and DBH to the
Chk1 ATP-binding site. Analysis of these docking
modes in conjunction with the associated binding affin-
ities led us to formulate a specific working hypothesis
regarding ligand design against Chk1, towards im-
proved binding affinity and selectivity. Specifically, the
comparative modelling of compounds 1 and 2 pinpoint-
ed a buried pocket at the periphery of the Chk1 ATP
site, suggesting convincingly that it is binding to this
pocket which explains the dramatic affinity difference
between these two compounds. A structural analysis of
several kinase active sites, combined with assay data,
also indicated that targeting this pocket ought to be
advantageous for selective binding to Chk1. Therefore,
the modelling work led us to devise a structure-based
strategy of general interest for elaboration of Chk1
inhibitors. This strategy was vindicated when the mod-
elled binding modes were subsequently confirmed with
Only a few chemical classes acting as Chk1 inhibitors
have been reported.9,11,15–17,19,21–26 Many of these
inhibitors are natural products such as debromohymen-
ialdisine (DBH),9 or staurosporine and its deriva-
tives.15–17,21–23 Crystal structures of staurosporine and
two analogs bound to the Chk1 kinase domain have been
described.18 This structural information is, however,
missing for the previously presented drug-like chemical
Abbreviations: DBH, debromohymenialdisine; PDB, Protein data
bank; RMSD, root mean square deviation; SAR, structure–activity
relationship.
Keywords: Drug design; Hydrogen bonds; Molecular modelling;
Molecular
*
recognition;
Oncology;
X-ray
crystallography.
Corresponding author. Tel.: +44 1223 895 338; fax: +44 1223 895
556; e-mail: n.foloppe@vernalis.com
0968-0896/$ - see front matter ꢀ 2005 Elsevier Ltd. All rights reserved.
doi:10.1016/j.bmc.2005.10.022

N. Foloppe et al. / Bioorg. Med. Chem. 14 (2006) 1792–1804
Table 1. Structures of compounds 1–3 and their binding affinitiesa to kinases of interest
1793
Compound
Structure
Ki (lM)
IC50 (lM)
Chk1
Chk1
CDK1
CDK2
GSK3b
PDK1
Akt1
PKA
O
O
N
N
N
N
1
2
0.026
(0.005)
0.042
(0.013)
0.040
(0.018)
0.104
(0.039)
0.314
(0.066)
0.443
(0.142)
23.600
(1.840)
171.719
(38.850)
N
N
N
8.580
(3.060)
6.296
(4.160)
0.845
(0.200)
14.309
(5.529)
0.744
(0.166)
2.706
(2.100)
>50
>200
N
N
N
N
O
N
3 (DBH)
0.659
(0.021)
0.353
(0.285)
0.266
(0.096)
0.856
(0.788)
0.168
(0.013)
8.830
(0.495)
0.190
(0.760)
>50
N
O
a Every reported affinity is the average of at least two measurements, with standard deviations given in parentheses.
X-ray crystallography. As predicted, the X-ray binding
mode includes a number of non-conventional protein–
ligand interactions such as C–Hꢀ ꢀ ꢀO and N–Hꢀ ꢀ ꢀp-aro-
matic interactions. The present work also provides new
and careful determinations of the affinities of com-
pounds 1–3 for Chk1.
ed here for the first time, is important to interpret the SAR
of substituents grafted on this core. Indeed, the influence
of the substituents on affinity can only be deduced if the
affinity of the core itself is known. This shows that the
additional methoxyphenol moiety in compound 1 leads
to a 330-fold increase in affinity for Chk1. It is therefore
important to characterize the structural positioning of
this methoxyphenol in its Chk1-binding site, to gain a bet-
ter understanding of the factors which lead to such a dra-
matic increase in affinity.
Structural overlays of the known chemical inhibitors
complexed to Chk1 show that only the indazole series
takes advantage of the pocket of interest. This suggests
that there is scope for further elaboration of other inhib-
itors, and will provide helpful guidance for future struc-
ture-based design efforts towards more potent and
selective Chk1 inhibitors.
DBH was also found to inhibit Chk1 in an ATP-com-
petitive manner, confirming a previous report which
characterized the binding of DBH to Chk1 in terms of
an IC50.9 We obtained a Ki of ꢁ0.6 lM for the affinity
of DBH to Chk1.
2. Results and discussion
2.2. Prediction and confirmation of the binding mode of
the indazole scaffold
Given the excellent agreement between predicted mod-
elled binding modes and their subsequently determined
X-ray counterparts (see Section 2.2), only the X-ray
binding modes are shown (Figs. 1, 2 and 4).
Compounds 1 and 2 were initially docked computational-
ly into the ATP-binding site of the crystal structure of apo
human Chk1 (PDB28 entry 1IA829). This suggested con-
vincing binding modes for compounds 1 and 2, in view
of their sensible interactions with the protein, which could
explain the affinity difference between 1 and 2 (Section
2.4). The root mean square deviation (RMSD) between
the predicted and X-ray coordinates of compounds 1
Compounds 1 and 2 were prepared by previously pub-
lished literature routes24,27 (see Methods and Schemes
1–3).
2.1. Binding affinities of selected indazole compounds and
DBH
˚
and 2 was ꢁ0.4 A (see Methods and Supplementary
Information). Although the X-ray structure of the
Chk1-compound 1 complex is of medium resolution
(Table 2), the crystallographic electron density maps
clearly support the conformation of the methoxyphenol
of compound 1 as shown in Figure 2, as well as the orien-
tation of the protein backbone for residues Ser147 and
Asp148. These peptide units adopt the same conforma-
tion in Chk1 X-ray structures of better resolutions.18,25,29
Compounds 1 and 2 inhibit human Chk1 in an ATP-com-
petitive manner, with Ki values of 0.026 and 8.58 lM,
respectively (Table 1). Each Ki was derived from several
independent measurements confirming that compound 1
is a potent Chk1 inhibitor, although its affinity appears
to be six times less than previously reported.11,24 The affin-
ity for Chk1 of the core of the indazole series (2), present-

1794
N. Foloppe et al. / Bioorg. Med. Chem. 14 (2006) 1792–1804
Tyr86
Glu85
Val68
Cys87
Asn59
Glu55
Figure 1. Crystallographic binding mode of compound 2 in the ATP-binding site of Chk1. For clarity, only selected residues and hydrogen atoms are
shown. Hydrogen bonds between the compound and the kinase backbone are depicted with green dotted lines. The three red spheres represent water
molecules. The shown protein residues are labeled.
A
Glu85
Tyr86
Val68
Cys87
Asn59
Glu55
B
Glu85
Leu84
Tyr86
Asn59
Glu55
Cys87
Asp148
Ser147
Figure 2. (A and B) Different views of the crystallographic binding mode of compound 1 in the ATP-binding site of Chk1. For clarity, only selected
residues and hydrogen atoms are shown. Conventional hydrogen bonds between the compound and the protein are depicted with green dotted lines,
while C–Hꢀ ꢀ ꢀO and N–Hꢀ ꢀ ꢀp-aromatic electron interactions are traced in magenta. For the N–Hꢀ ꢀ ꢀp-aromatic interaction, the phenyl ring is
represented by its centroid. The shown protein residues are labelled.
The indazole core of 1 and 2 largely overlaps with the vol-
ume typically occupied by the adenine base of ATP when
complexed to kinases, with the indazole hydrogen-bond-
ed to the highly conserved kinase backbone motif at the
hinge between the two lobes of the kinase domain
(Fig. 1). The hydrogen-bond interactions between inda-

N. Foloppe et al. / Bioorg. Med. Chem. 14 (2006) 1792–1804
1795
OMOM
OMe
Mts
H
Mts
N
H
N
NH2
N
I
N
I
a
b
N
c
N
N
N
4
6
5
OMOM
OMOM
OMOM
OMe
H
H
H
N
d
N
f
e
N
N
OMe
N
N
OMe
OHC
8
9
I
7
OH
OMOM
OMe
H
N
H
N
h
N
OMe
g
N
H
H
N
N
N
1
N
10
Scheme 1. Reagents and conditions: (a) Concd HCl (aq), NaNO2, KI, H2O, 0–50 ꢁC, 3 h, (39%); (b) NaOtBu, MtsCl, THF, 0–23 ꢁC, 2.5 h, (92%); (c)
