164101-2
F. Raissi and R. Farivar
Appl. Phys. Lett. 87, 164101 ͑2005͒
curve. It saturates at about 500 ppm after which no change in
breakdown voltage is exhibited.
When doing measurements, the samples are placed up-
side down attached to the top cover of the gas enclosure. It is
possible to obtain larger sensitivity to gas with a funnel-type
top cover, in which the sample is placed at the tip. For ex-
ample, for the funnel shape top cover, the change in break-
down voltage due to 10 ppm of hydrogen is equal to 100
ppm of hydrogen in the regular gas enclosure. This is
because the effective hydrogen concentration is increased at
the sample surface as hydrogen replaces more air molecules
in this case.
FIG. 2. I-V curve of a sample in 15% humid air with no hydrogen and in the
presence of 500 ppm of hydrogen at room temperature. I-V curve moves to
larger voltages as hydrogen is introduced. It reaches its maximum at 500
ppm of hydrogen, after that it remains unchanged.
The response and recovery times were estimated to be
around 6 and 60 s, respectively, which are quite fast and are
due to the physical nature of the detection mechanism. The
longer recovery time may be due to hydrogen adsorption,
which take longer to be released. The same is observed for
1
4
walls. Connections were made to the PtSi layer and to the
substrate. For the tests which are carried out in air, we use
two closed gas chambers. The samples are placed inside one
cylindrical chamber which has an exact volume of 30
other gases.
The experiments were also carried at lower temperatures
down to 273 K and hydrogen gas sensitivity was exhibited in
a similar fashion. The change in the I-V curve was similar to
Fig. 2. Temperatures lower than 273 K were not tried be-
cause water vapor condenses on the sample and shields it
from hydrogen.
3
3
ϫ10 cm . Normal air is let inside the chamber to atmo-
spheric pressure. The air humidity is checked by a standard
humidity sensor, which for these experiments was 15% ͑we
have not introduced water vapor to change the humidity in
these measurements͒. This chamber is then isolated. A sec-
As was mentioned, it is very important to check hydro-
gen sensing in the presence of other reducing gases; there-
fore, experiments were carried out in the presence of differ-
ent concentrations of acetone, methanol, and ethanol up to
2000 ppm. The introduction of these gases did not have any
affect on the hydrogen gas sensing behavior. In other words,
these samples are able to sense hydrogen even in the pres-
ence of a large concentration of acetone, methanol, or etha-
nol. It seems that acetone, methanol, and ethanol cannot re-
place the gas content inside the pores perhaps because of
their large size and mass. As a result, they do not affect the
I-V curve and do not interfere with hydrogen gas sensing.
Durability of these samples was tested by biasing them
below their breakdown voltage and exposing them to hydro-
gen gas periodically. The samples have not shown any drift
in I-V curve for a period of 3 months. A current limit of 5
mA was set on the biasing circuit. Larger currents resulted in
a drift in I-V curve and caused some samples to be burnt.
We have demonstrated here that n-type PtSi/porous Si
Schottky junctions are capable of detecting hydrogen gas at
room temperature. Detection occurs in air and in presence of
hydrocarbons, such as acetone, methanol, and ethanol. The
detection mechanism is physical in nature, in which hydro-
gen replaces ambient gas inside the pores and this changes
the electric fringing fields. This results in a relatively fast
response and recovery times. The physical nature of detec-
tion mechanism also makes low-temperature operation pos-
sible. The detector is stable, robust, compact, easy to fabri-
cate, and is compatible with integrated circuit fabrication
technology.
3
ond smaller chamber with a volume of 150 cm is first con-
nected to a turbomolecular pump and its pressure is brought
−
5
down to 10 Pa. Then selected gases are let inside the cham-
ber to a predetermined pressure. This chamber is then dis-
connected from the turbopump and is connected to the larger
chamber in which the sample is placed. The relative concen-
tration is then calculated considering the volume of the two
chambers and their pressure before connection.
The reverse bias I-V curve of this device at 300 K in air
and in presence of 500 ppm hydrogen gas is provided in Fig.
2. As observed, I-V curve moves to larger voltages as hydro-
gen is introduced. In other words, the breakdown voltage
increases with hydrogen gas content. The change in the
breakdown voltage with hydrogen concentration is provided
in Fig. 3. We estimate an error of about 4 ppm in our mea-
surements. At 10 ppm of hydrogen concentration, the break-
down voltage increases by about 0.02 V. The change in
breakdown voltage follows more or less a piecewise linear
1
X. Bevenot, A. Trouillet, C. Veillas, H. Gagnaire, and M. Clementl, Sens.
Actuators B 67, 57 ͑2000͒.
W. Zhu, O. K. Tan, Q. Yan, and J. T. Ohl, Sens. Actuators B 65, 366
2
3͑
2000͒.
Y. D. Wang, C. L. Ma, X. H. Wu, X. A. Sun, and H. D. Li, Sens. Actuators
B 85, 270 ͑2002͒.
4
5
6
K. Hara and N. Nishida, Sens. Actuators B 20, 181 ͑1994͒.
V. N. Mishra and R. P. Agrawal, Sens. Actuators B 21, 209 ͑1994͒.
V. A. Chaudhary, I. S. Mulla, and K. Vijayamohanan, Sens. Actuators B
FIG. 3. The change in breakdown voltage as hydrogen concentration is
increased from zero. The relation can be estimated as a piecewise linear
curve which saturates at 500 ppm ͑not shown here͒.
