such as CO oxidation, water–gas shift, and steam reforming of
methane [40–42]. In this paper, the role of CeO2 addition in im-
proving the stability of Co-based catalysts, as examined through
characterization studies that included N2 physisorption, X-ray pho-
toelectron spectroscopy (XPS), temperature-programmed oxidation
were sandwiched between two layers of quartz wool and subjected
to an oxidative cleaning step in air for 30 min, at the calcination
temperature of the sample, followed by a reduction step at 400 C
◦
for 2 h. After the system was flushed with He to remove any mois-
◦
ture, the O2 pulses were introduced at 300 C. The m/z = 32 signal
(TPO), laser Raman spectroscopy (LRS), diffuse reflectance infrared
was continuously detected by the MS until there was no variation
between two consecutive peaks.
Fourier transform spectroscopy (DRIFTS), O2 pulse chemisorption,
16
18
O2/ O2 exchange, and transmission electron microscopy (TEM)
techniques, is reported.
16
18
O2/ O2 exchange experiments were performed using
a
Thermo Finnegan Trace Ultra DQC GC/MS. ∼50 mg samples were
placed in a U-tube quartz reactor. Following a cleaning step un-
2. Experimental
◦
der He at 400 C for 30 min to remove impurities adsorbed during
◦
storage, the reactor was cooled down to 300 C, at which tempera-
2.1. Catalysts preparation
ture the 16 O2/ O2 exchange took place. The m/z = 32, 34, and 36
18
(
mass-to-charge ratio) signals were monitored by the mass spec-
Supported cobalt catalysts with 10 wt% metal loading were
trometer during the exchange process. 10% Ar was included in the
prepared in air by incipient wetness impregnation from cobalt(II)
nitrate hexahydrate (Aldrich 99.999%) aqueous solutions. The pure
16
2%
O2/He stream to account for the gas-phase hold-up time, as
2
described previously [43–45]. In addition, blank experiments were
also performed and showed no exchange in the gas phase when
no catalyst was present.
The TEM experiments were performed by using Philips Tecnai
TF-20 TEM instrument operated at 200 kV. An X-ray analyzer for
EDS is incorporated into the instrument for elemental analysis un-
der STEM mode for improving image contrast between C and Co
phases. The sample was first dispersed in ethanol and supported
on Lacey-formvar carbon on a 200 mesh Cu grid before the TEM
images were recorded.
supports used were ZrO2 (Saint Gobain, surface area: 55 m /g,
3
pore volume: 0.21 cm /g) and CeO2 (powder <5 μm, 99.9%
2
3
Aldrich, surface area: 71 m /g, pore volume: 0.34 cm /g). The
0 wt%CeO2–ZrO2 support was prepared by impregnating the ZrO2
1
support using an aqueous solution of cerium(III) nitrate (Aldrich
◦
9
9.999%). All the supports were calcined for 3 h in air at 500 C
prior to metal impregnation. After repeating the impregnation of
◦
cobalt precursor and drying steps (at 95 C) as many times as de-
termined by the pore volume of the corresponding supports, the
◦
resulting samples were calcined at 400 C for 3 h in the air and
stored for use. The term “fresh sample” is used to represent the
sample after calcination; the “reduced sample” denotes the sam-
DRIFTS was performed with a Thermo NICOLET 6700 FTIR spec-
trometer equipped with a liquid-nitrogen-cooled MCT detector and
a KBr beam splitter. The in situ experiments were performed using
a Smart collector DRIFT environmental chamber with ZnSe win-
◦
ple reduced at 400 C for 2 h; and the “spent sample” refers to the
sample after reduction treatment and exposure to reaction atmo-
sphere for various time periods.
◦
dows. Following the pretreatment under He at 400 C for 30 min
◦
and reduction under 5%H2/He at 400 C for 2 h, the environmen-
tal chamber was heated to 450 C for 1 h under He for removing
2
.2. Catalysts characterization and reaction performance measurement
◦
moisture generated from the reduction step. The reactant vapors
generated from a two-bubbler system were then flowed over the
sample for 1 h at room temperature using He as a carrier gas. The
sample was then flushed with He for 10 min. Spectra were taken at
The surface areas of the fresh and spent catalysts were mea-
sured using nitrogen adsorption at 77 K (Micromeritics ASAP 2010).
◦
Before each measurement, the sample was degassed under 130 C
overnight to remove any impurities adsorbed from the atmosphere
during storage.
pre-set intervals while the sample temperature was ramped from
◦
2
5 to 500 C.
XPS analysis was performed using an AXIS His, 165 Spectrom-
eter manufactured by Kratos Analytical with a monochromatized
AlKα X-ray source. 2.3 V voltage was chosen to make the charge
balance. A stainless steel sample holder was used. Survey scans
were performed to identify all the elements within the sample,
followed by more detailed regional scans for Co 2p, C 1s, O 1s, Zr
The catalytic performance measurement and analysis methods
used were reported elsewhere [38]. Briefly, all catalysts were first
◦
pretreated at 400 C for 30 min. under He and then reduced in
◦
situ at 400 C for 2 h under 5%H2/He. The reactant liquid consist-
ing of ethanol and water at 1:10 molar ratio was delivered into an
evaporator. The generated reactant vapor was carried by He and in-
troduced into the reactor. The dilution ratio varied between 40 and
75 (inert-to-ethanol molar ratio). For neat experiments, gas phase
reactants were directly fed to the reactor without dilution with an
inert gas. Subsequently the catalytic performances were tested in
3
d orbitals in order to achieve the high resolution for these ele-
ments of interest. A controlled-atmosphere transfer chamber was
used for transferring the sample to the XPS instrument without
exposure to atmosphere.
Temperature-programmed oxidation (TPO) experiments were
performed using Autochem-2920 (Micromeritics) with an online
mass spectrometer (MS) (MKS Instruments, 1–300 amu). The sam-
◦
the temperature range of 300 to 550, in 50 C increments. The cat-
alyst was held at each temperature for at least 2 h. At the end of
◦
ples were first pretreated at 300 C with He for 30 min in order to
the catalytic test, the flow of EtOH +H2O was stopped and the cat-
remove adsorbed contaminants during storage. After cooling down
to room temperature under helium, 10%O2/He (30 ml/min) was in-
troduced into the reactor and TPO experiments were subsequently
alyst was cooled under He stream. The hydrogen yield is defined
moles of H2 produced
×(moles of ethanol fed)
as H2 yield % = 6
× 100. The time-on-stream
◦
◦
(TOS) tests were performed at 450 C for different time periods
depending on the deactivation rate of various samples. The spent
samples after TOS experiments were cooled down to room temper-
ature under helium before characterization.
performed with a heating rate of 10 C/min after the MS signal
was stable.
Raman spectra were taken with a LabRAM HR-800 spectrometer
equipped with an OLYMPUS BX41 microscope (50× magnification)
and a CCD detector. An argon ion green laser (514.5 nm, operated
at 3 mW) was used as the excitation source during spectra collec-
tion.
O2 pulse chemisorption experiments were conducted using Au-
toChem II 2920 (Micrometrics) connected with a Cirrus Mass Spec-
trometer (MKS Instruments, 1–300 amu). Catalysts of ∼200 mg
The turnover frequency (TOF) reported in the paper is calcu-
lated based on the ethanol conversion rate divided by the total
available metallic cobalt active sites contained over the samples
charged in the reactor. The cobalt dispersion is estimated using
a H2 chemisorption technique, which is described in detail previ-
ously [38].
