thermal vents close to the volcanic edifices have been found
to range from about 608C to 5008C. The potential existence of
photoactive g-CN semiconductors in primordial environ-
ments to induce photoredox transformations of water, CO2
and organics would enrich the discussion on the chemical
evolution of life. Furthermore, the study is also of relevance
for the artificial photosynthesis field.
Nucleobases [adenine (A), guanine (G), cytosine (C),
thymine (T) and uracil (U)] are readily available and stable
precursors. Surprisingly, according to our knowledge, there is
no report on the synthesis of carbon nitride from biomass-
derived building blocks. Here, we propose a facile synthesis of
carbon nitride based materials by thermal condensation of
1) urea with 2) A, G, C, T and U, respectively. We aim to
demonstrate that the incorporation of such building blocks
can lead to the development of carbon nitride for H2
production, and potentially to induce photoredox transfor-
mations under prebiotic conditions.
In a typical synthesis, a certain amount of nucleobase (0, 5,
15, 30, 50, 80 mg) and urea (10 g) were dissolved in water with
stirring, followed by heating at 808C to evaporate water.
Afterwards, the obtained mixture was calcined at 400–5508C
in air. The obtained samples are denoted as CNX, where X
represents the nucleobase. The reference sample from urea is
denoted as g-CN.
The chemical structure and composition of CNX samples
were characterized by X-ray diffraction (XRD) (Figure S2a in
the Supporting Information) and Fourier transform infrared
spectroscopy (FT-IR) (Figures S2b and S3). The XRD
patterns of the samples in Figure S2a show a strong peak at
27.48 related to the (002) interlayer reflection of a layered
crystal, plus a weak reflection at
to urea-derived g-CN under visible light irradiation. More-
over, the photocatalyst synthesized from urea with cytosine
(CNC) exhibits the best activity for producing hydrogen
among all these samples. The superior photocatalytic perfor-
mance of CNC is probably due to the better interaction and
structural matching between cytosine and urea. Since one
cytosine molecule could break into two molecules with the
similar structure to urea under thermal treatment, the
chemical structure of cytosine enables closer combination
with urea and better conjugation into the covalent carbon
nitride frameworks. On the contrary, the polymerization of
urea with other nucleobases with more functional groups is
less straightforward due to steric hindrance. Therefore,
cytosine, which could polymerize with the urea best, was
selected as the monomer to synthesize modified carbon
nitride polymers with high efficiency for photocatalytic
reactions.
A series of photocatalysts were prepared from mixtures of
urea and different amounts of cytosine. These materials are
denoted as CNCy, where y stands for the amount of cytosine
(y mg). As shown in Figure 1b and Figure S3 the XRD
pattern and FT-IR spectrum of CNCy, respectively, are very
similar to those of urea-derived g-CN, which demonstrates
that the graphitic carbon nitride based structure is maintained
with increasing amount of cytosine. The surface morphology
and texture of the CNC30 sample (after Pt deposition) were
investigated by scanning electron microscopy (SEM) and
transmission electron microscopy (TEM) (Figure 1a). In the
TEM image smooth, flat layers can be seen, and the Pt
particles were distributed uniformly on the surface after
reaction (Figure 1a). There was no obvious difference
138 due to the in-plane repeating
unit of heptazine. The FT-IR spec-
trum in Figure S2b features distinct
peaks from 1200 to 1600 cmÀ1 cor-
responding to the stretch modes of
aromatic CN heterocycles, while
the breathing mode of the triazine
units corresponds to 810 cmÀ1. The
broad peaks between 3500 and
3100 cmÀ1 originate from N H
À
stretches on the surface of the
carbon nitride due to the surface
defective sites as a result of incom-
plete condensation. These results
clearly confirmed that all of the
CNX materials are featuring sim-
ilar crystal and chemical structure
of graphitic carbon nitride.
Then, we investigated the pho-
tocatalytic activities of CNX sam-
ples in water splitting and revealed
the effect of different nucleobase
monomers on the photocatalytic
performances. As shown in Fig-
ure S4, the hydrogen evolution
rates (HER) of CNX materials
increase by 6–8 times as compared
Figure 1. a) TEM of Pt@CNC30 after reaction. Inset: HR-TEM of Pt nanoparticles. b) XRD patterns of
different CNC samples. c) XPS analysis of CNC30 sample. d) Solid-state 13C NMR spectrum of CNC30.
