glyceraldehyde acetonide, stereoselective olefination, and
ester reduction.[13] Dichlorination of the free allylic alcohol 8,
although highly diastereoselective, was plagued with com-
petitive oxidation to an enal[14] that resisted chlorination; this
undesired reactivity could not be prevented by tuning of the
reaction conditions. Therefore, a one-pot sequence of in situ
trifluoroacetylation, dichlorination, and deacylation was
developed, which afforded higher overall yields and high
selectivity (> 10:1 d.r.). It is likely that the minimization of
1,3-allylic (A1,3) strain[15] in substrate 8 and its trifluoroacety-
lated derivative is important, and although the outcome
mirrors the studies of Chamberlin and Hehre on the
iodofunctionalization of allylic alcohols,[16,17] the mechanism
underlying stereocontrol is not completely understood. X-ray
crystallographic analysis on a mesylated derivative of alcohol
9[18] enabled the unequivocal assignment of the absolute and
relative configuration for compounds produced by this
synthetic route.
Oxidation of alcohol 9 to aldehyde 10 was followed by
methylenation or bromomethylenation to afford products
11a or 11b, respectively. Direct oxidative cleavage of the
dioxolane produced sensitive aldehydes 12a/12b in high yield.
Olefination of these products was plagued by b-elimination
under many conditions examined; however, the use of NaH in
toluene with the Horner–Wadsworth–Emmons reagent
shown provided enones 13a/13b in good yields with high
levels of stereocontrol. Finally, methylenation or chlorome-
thylenation provided targets 14–18 in the yields shown in
Scheme 2b. The chloromethylenation products were obtained
as mixtures at the newly formed alkenes, but they could be
separated easily by preparative HPLC.[19] Compounds 14–16
and 18 are known natural products,[2,3,10] but 17 has not yet
been reported.
lished by X-ray crystallographic analysis of the corresponding
aldehyde obtained by oxidation.[23] Dichloroalcohol 20 was
converted into 21 and 22 by similar reactions to those shown
in Scheme 2.[23,24] The final products thus produced are in the
unnatural enantiomeric series because we used the same
enantiomer of glyceraldehyde acetonide as we did for 14–18.
Clearly, natural products in both diastereomeric series, as well
as in both enantiomeric forms, are available by this route,
because glyceraldehyde acetonide is readily available in both
mirror-image forms. Each of the target molecules (14–18, 21,
and 22) was obtained in only six steps from allylic alcohols 8
or 19 (eight steps from inexpensive commercially available
mannitol derivative 7). Although some of the steps proceeded
in only moderate yields, and the chemistry is “classical”, these
small but complex molecules have never been synthesized
before, and the sequence is direct enough to procure plenty of
material for biological evaluation.[25]
Stereocontrolled access to the chloride-bearing stereo-
genic centers at the C3 and C4 positions of the Plocamium
monoterpenes would not be easily accomplished by other
existing methods. The two best currently available methods to
obtain vicinal dichlorides in enantioenriched form—the
asymmetric dichlorination of allylic alcohols put forth by
the Nicolaou group[26] and the stereospecific deoxydichlori-
nation of epoxides developed by the Yoshimitsu group[27]—do
not appear to tolerate the formation of tertiary chlorides, such
as that at the C3 position. Moreover, the ready availability of
substrate 8 and the utility of the dioxolane for more than just
the control of diastereoselectivity in the dichlorination (see
below) is particularly attractive.
Although the synthesis of a ten-carbon target by four
classical olefination reactions might seem far from ideal, this
approach permits maximum divergence both with respect to
constitution and configuration (Scheme 1) and suffers from
few non-productive operations. The biggest liability, at this
stage of development, is the lack of stereocontrol in the final
olefination step; this apparent problem is mitigated by the
fact that many of these natural products are found in both
The synthesis shown in Scheme 2 is highly divergent and
will provide access to many more naturally occurring
polyhalogenated natural products from Plocamium as well
as unnatural analogues. However, there remains another
important aspect of our design: The Z-isomer of allylic
alcohol 8 is also readily available (see 19, Scheme 3),[20–22] and
we have shown that it also undergoes stereocontrolled
dichlorination to procure the syn-configured C3/C4 dichlor-
ide 20. The relative configuration of product 20 was estab-
[2,3]
ꢀ
C7 C8 isomeric forms,
and that the isomers are readily
separable. Furthermore, in the context of compounds 4 and 5
at least, these isomers are known to readily equilibrate upon
exposure to minimally acidic medium.[19] Overall, the strate-
gic use of glyceraldehyde acetonide as a chiral glyoxal
equivalent is significant; it not only plays the role of a chiral
auxiliary to control the absolute configuration of the C3/C4
dichloride, it also serves as a truly effective linchpin for our
short synthesis by virtue of the one-step conversion of the
dioxolane into an aldehyde. At current count, we have made
four naturally occurring polyhalogenated Plocamium mono-
terpenes, one that is likely to be an as yet undiscovered
natural product, and two unnatural enantiomers, thereby
showcasing the generality of our approach.
Compounds 14–16 were subjected to the disk diffusion
assay, which provides an indication of the selectivity of
compounds for human solid-tumor cell lines compared with
the CCRF–CEM human leukemia cell line. These data were
compared with the data obtained for halomon (2) and
compound 4 using the same assay (Table 1).[11,28] All five
compounds exhibited selectivity for solid tumors, with some
Scheme 3. Synthesis of 3,4-syn Plocamium monoterpenes 21 and 22
through diastereocontrolled dichlorination of Z-allylic alcohol 19. See
the Supporting Information for details.
