C O M M U N I C A T I O N S
2008, 27, 418. (g) Braunschweig, H.; Fuss, M.; Radacki, K.; Uttinger, K.
Z. Anorg. Allg. Chem. 2009, 635, 208.
HOMO and HOMO-1 orbitals in Figure 2. Both 5 and 6 have
HOMO character similar to a π orbital of the diazaborole ring,
like hydroborane 4.10,11 The shape of HOMO-1 seems to be similar
to the HOMO of boryllithium 1·(THF)2, which has lone-pair
character on the central boron atom.10,11 Natural bond order (NBO)
analyses of 5 and 6 suggest that both of the HOMO-1 orbitals
have a shared two-center-two-electron bonding character with
hybridizations of B-Ti ) 0.5668(sp1.49)B + 0.4332(sp0.92d1.06)Ti
for 5 and B-Hf ) 0.6265(sp1.06)B + 0.3745(sp0.54d2.01)Hf for 6.22
Atoms-in-molecule analyses also afforded the same conclusion.
Negative ∇2F(r) values (-0.03079 e/a05 in 5; -0.33061 e/a05 in 6)
at the bond critical point between the boron and metal atoms
indicated covalent character for these B-metal bonds.23
(3) Segawa, Y.; Yamashita, M.; Nozaki, K. Angew. Chem., Int. Ed. 2007, 46,
6710.
(4) (a) Nguyen, P.; Blom, H. P.; Westcott, S. A.; Taylor, N. J.; Marder, T. B.
J. Am. Chem. Soc. 1993, 115, 9329. (b) Cho, J.-Y.; Iverson, C. N.; Smith,
M. R. J. Am. Chem. Soc. 2000, 122, 12868. (c) Iverson, C. N.; Smith,
M. R., III. J. Am. Chem. Soc. 1999, 121, 7696. (d) Cho, J.-Y.; Tse, M. K.;
Holmes, D.; Maleczka, R. E., Jr.; Smith, M. R., III. Science 2002, 295,
305. (e) Waltz, K. M.; He, X. M.; Muhoro, C.; Hartwig, J. F. J. Am. Chem.
Soc. 1995, 117, 11357. (f) Waltz, K. M.; Hartwig, J. F. Science 1997, 277,
211. (g) Chen, H. Y.; Hartwig, J. F. Angew. Chem., Int. Ed. 1999, 38,
3391. (h) Waltz, K. M.; Muhoro, C. N.; Hartwig, J. F. Organometallics
1999, 18, 3383. (i) Chen, H. Y.; Schlecht, S.; Semple, T. C.; Hartwig, J. F.
Science 2000, 287, 1995. (j) Waltz, K. M.; Hartwig, J. F. J. Am. Chem.
Soc. 2000, 122, 11358. (k) Kawamura, K.; Hartwig, J. F. J. Am. Chem.
Soc. 2001, 123, 8422. (l) Ishiyama, T.; Takagi, J.; Ishida, K.; Miyaura, N.;
Anastasi, N. R.; Hartwig, J. F. J. Am. Chem. Soc. 2002, 124, 390. (m)
Ishiyama, T. J. Synth. Org. Chem. Jpn. 2003, 61, 1176. (n) Ishiyama, T.;
Miyaura, N. J. Organomet. Chem. 2003, 680, 3. (o) Ishiyama, T.; Miyaura,
N. Chem. Rec. 2004, 3, 271. (p) Ishiyama, T.; Miyaura, N. Pure Appl.
Chem. 2006, 78, 1369.
(5) (a) Hartwig, J. F.; De Gala, S. R. J. Am. Chem. Soc. 1994, 116, 3661. (b)
Lantero, D. R.; Motry, D. H.; Ward, D. L.; Smith, M. R., III. J. Am. Chem.
Soc. 1994, 116, 10811. (c) Lantero, D. R.; Ward, D. L.; Smith, M. R., III.
J. Am. Chem. Soc. 1997, 119, 9699–9708. (d) Lantero, D. R.; Miller, S. L.;
Cho, J.-Y.; Ward, D. L.; Smith, M. R., III. Organometallics 1999, 18, 235.
(6) (a) Hartwig, J. F.; Muhoro, G. N.; He, X. M.; Eisenstein, O.; Bosque, R.;
Maseras, F. J. Am. Chem. Soc. 1996, 118, 10936. (b) Muhoro, C. N.;
Hartwig, J. F. Angew. Chem., Int. Ed. 1997, 36, 1510. (c) Muhoro, C. N.;
He, X. M.; Hartwig, J. F. J. Am. Chem. Soc. 1999, 121, 5033. (d) Hartwig,
J. F.; Muhoro, C. N. Organometallics 2000, 19, 30.
(7) A gallylzirconium complex possessing a heavier group-13 element, gallium,
has also been synthesized via oxidative addition of digallane to low-valent
zirconium. See: Baker, R. J.; Jones, C.; Murphy, D. M. Chem. Commun.
2005, 1339.
(8) Group-3 gallyl complexes have been synthesized using a gallyl anion. See:
(a) Arnold, P. L.; Liddle, S. T.; McMaster, J.; Jones, C.; Mills, D. P. J. Am.
Chem. Soc. 2007, 129, 5360. (b) Jones, C.; Stasch, A.; Woodul, W. D.
Chem. Commun. 2009, 113. (c) Liddle, S. T.; McMaster, J.; Mills, D. P.;
Blake, A. J.; Jones, C.; Woodul, W. D. Angew. Chem., Int. Ed. 2009, 48,
1077. (d) Liddle, S. T.; Mills, D. P.; Gardner, B. M.; McMaster, J.; Jones,
C.; Woodul, W. D. Inorg. Chem. 2009, 48, 3520.
(9) Segawa, Y.; Yamashita, M.; Nozaki, K. Science 2006, 314, 113.
(10) Segawa, Y.; Suzuki, Y.; Yamashita, M.; Nozaki, K. J. Am. Chem. Soc.
2008, 130, 16069.
Figure 2. HOMO and HOMO-1 of (left) 5 and (right) 6.
Preliminary studies of the catalytic activity of 3 for polymeri-
zation of ethylene and hex-1-ene were performed (see the Sup-
porting Information for details). An admixture of 3 with
Ph3CB(C6F5)4 in toluene could polymerize ethylene to form a linear
polyethylene (PE) [turnover frequency (TOF) ) 110 kg of PE (mol
of Hf)-1 h-1, Mn ) 4800, polydispersity index (PDI) ) 2.1, 2
branches per 1000 C]. The present system was also active for
polymerization of hex-1-ene to afford an atactic poly(hex-1-ene)
(PHex) (TOF ) 21 kg of PHex (mol of Hf)-1 h-1, Mn ) 3100,
PDI ) 2.2). Activities of 3/Ph3CB(C6F5)4 toward polymerization
were comparable to those of previously reported hafnium half-
sandwich complex-derived catalyst systems.24
(11) Yamashita, M.; Suzuki, Y.; Segawa, Y.; Nozaki, K. Chem. Lett. 2008, 37, 802.
(12) (a) Marder, T. B. Science 2006, 314, 69. (b) Braunschweig, H. Angew.
Chem., Int. Ed. 2007, 46, 1946.
In conclusion, two group-4 boryl complexes, boryltitanium 2
and borylhafnium 3, were synthesized via nucleophilic borylation
using boryllithium 1. Complexes 2 and 3 are the first examples of
group-4 borylmetals. Theoretical calculations on model molecules
5 and 6 indicated that the boron-metal bond in both complexes
has covalent character. Complex 3 has an activity for polymerization
of ethylene and hex-1-ene. Further studies on polymerization and
modification of the boryl ligand are ongoing.
(13) The reaction of 1 with Cp*HfCl3 presumably afforded Cp*HfCl2(boryl) or
Cp*HfCl3(boryl)-. It is noteworthy that the following reaction of PhCH2K
with them occured at the metal center, not on the boron atom.
(14) The stability of 2 and 3 shows that the boryl ligand can coexist in the
coordination sphere with other nucleophilic ligands such as alkoxides and alkyls.
(15) There has been one report of a borylosmium complex having intramolecular
coordination of an alcoholic OH group to the metal center. See: Rickard,
C. E. F.; Roper, W. R.; Williamson, A.; Wright, L. J. J. Organomet. Chem.
2004, 689, 1609.
(16) (a) Alcaraz, G.; Sabo-Etienne, S. Coord. Chem. ReV. 2008, 252, 2395. (b)
Lin, Z. In Contemporary Metal Boron Chemistry I: Borylenes, Boryls,
Borane; Springer-Verlag: Berlin, 2008; Vol. 130, pp 123-148.
(17) The Cambridge Crystallographic Database listed all of the structurally
characterized Ti and Hf complexes having relatively short interatomic metal-
boron distances. For all of these references, see the Supporting Information.
(18) Emsley, J. The Elements; Oxford University Press: New York, 1998.
(19) A similar shortening of the Ti-O bond was observed in the structure of
the alkyltitanium triaryloxide species (Me3SiCH2)Ti(O-2,6-Ph2C6H3)3. See:
Chesnut, R. W.; Durfee, L. D.; Fanwick, P. E.; Rothwell, I. P.; Folting,
K.; Huffman, J. C. Polyhedron 1987, 6, 2019.
Acknowledgment. This work was supported by KAKENHI
(21245023, 21685006, and 19027015, “Synergy of Elements”) from
MEXT, Japan.
Supporting Information Available: Details about preparations and
characterizations of 2 and 3, polymerization procedures, X-ray crystal-
lography (CIF), and the computational study. This material is available
(20) (a) Yasumoto, T.; Yamagata, T.; Mashima, K. Organometallics 2005, 24,
3375. (b) Swenson, D. C.; Guo, Z.; Crowther, D. J.; Baenzigera, N. C.;
Jordan, R. F. Acta Crystallogr. 2000, C56, E313. (c) Kissounko, D. A.;
Zhang, Y.; Harney, M. B.; Sita, L. R. AdV. Synth. Catal. 2005, 347, 426.
(21) It was confirmed that this difference in the orientation angles of the
diazaborole rings in 3 and 6 did not affect the bonding character. See the
Supporting Information.
References
(1) (a) Irvine, G. J.; Lesley, M. J. G.; Marder, T. B.; Norman, N. C.; Rice,
C. R.; Robins, E. G.; Roper, W. R.; Whittell, G. R.; Wright, L. J. Chem.
ReV. 1998, 98, 2685. (b) Smith, M. R., III. Prog. Inorg. Chem. 1999, 48,
505. (c) Braunschweig, H.; Colling, M. Coord. Chem. ReV. 2001, 223, 1.
(d) Aldridge, S.; Coombs, D. L. Coord. Chem. ReV. 2004, 248, 535. (e)
Braunschweig, H.; Kollann, C.; Rais, D. Angew. Chem., Int. Ed. 2006, 45,
5254. (f) Kays, D. L.; Aldridge, S. In Contemporary Metal Boron Chemistry
I: Borylenes, Boryls, Borane; Springer-Verlag: Berlin, 2008; Vol. 130, pp
29-122.
(22) For comparison, an NBO analysis of boryllithium 1 · (THF)2 with cc-pvdz
basis sets was independently performed in this study. The analysis indicates
that the boron center of boryllithium 1·(THF)2 has LP character in its sp1.237
hybridized orbital.
(23) This is in contrast to the case of 1·(THF)2, which has positive ∇2F(r) values,
indicating ionic character of the B-Li bond. See ref 10 and the Supporting
Information.
(24) For PE, see: (a) Shah, S. A. A.; Dorn, H.; Voigt, A.; Roesky, H. W.; Parisini,
E.; Schmidt, H.-G.; Noltemeyer, M. Organometallics 1996, 15, 3176. (b)
Hessen, B.; van der Heijden, H. J. Organomet. Chem. 1997, 534, 237. (c)
Lee, K.-S.; Kim, Y.; Ihm, S.-K.; Do, Y.; Lee, S. J. Organomet. Chem.
2006, 691, 1121. (d) Zhang, W.; Wei, J.; Sita, L. R. Macromolecules 2008,
41, 7829. For PHex, see refs 20a, c and 24d.
(2) (a) Zhu, J.; Lin, Z. Y.; Marder, T. B. Inorg. Chem. 2005, 44, 9384. (b)
Braunschweig, H.; Brenner, P.; Mu¨ller, A.; Radacki, K.; Rais, D.; Uttinger,
K. Chem.sEur. J. 2007, 13, 7171. (c) Braunschweig, H.; Radacki, K.;
Uttinger, K. Chem.sEur. J. 2008, 14, 7858. (d) Braunschweig, H.; Green,
H.; Radacki, K.; Uttinger, K. Dalton Trans. 2008, 3531. (e) Dang, L.; Zhao,
H.; Lin, Z.; Marder, T. B. Organometallics 2008, 27, 1178. (f) Braunsch-
weig, H.; Leech, R.; Rais, D.; Radacki, K.; Uttinger, K. Organometallics
JA905950G
