Mech a n istic Stu d ies on Oxid a tive Ad d ition of Ar yl
Ha lid es a n d Tr ifla tes to P d (BINAP )2 a n d Str u ctu r a l
Ch a r a cter iza tion of th e P r od u ct fr om Ar yl Tr ifla te
Ad d ition in th e P r esen ce of Am in e
Luis M. Alcazar-Roman and J ohn F. Hartwig*
Department of Chemistry, Yale University, P.O. Box 208107,
New Haven, Connecticut 06520-8107
Received September 10, 2001
Kinetic studies of the oxidative addition of phenyl iodide and phenyl triflate to Pd(BINAP)2
(1) are reported. The products of the oxidative addition of phenyl trifluoromethanesulfonate
to 1 in the presence of the primary amines n-octylamine and isoamylamine are the cationic
aryl palladium(II) complexes [(BINAP)Pd(Ph)(H2NR)]OTf (2a ,b), and the product of the
oxidative addition of phenyl iodide to 1 is the phenylpalladium iodide {(BINAP)Pd(Ph)I}
(3). Structural characterization of the rare, stable σ-aryl Pd(II) triflate complex (2b), in this
case coordinated by isoamylamine, is reported. Initial mechanistic studies focused on
measuring the rates of reactions containing concentrations of aryl electrophile ranging from
8.94 × 10-7 to 0.2 M. Under these conditions, the oxidative addition of PhOTf and PhI to 1
was inverse first-order in added BINAP ligand when the concentration of ArX was low. The
oxidative addition reaction was first-order in ArX when the concentration of ArX was low
and was zero order in ArX when the concentration of ArX was high. At these high
concentrations, the reaction rate depended solely on the rate for dissociation of BINAP from
1. However, additional experiments using concentrations of aryl iodide and aryl bromide up
to 4.0 M led to a measurable increase in observed rate constants and detection of a second
concurrent reaction mechanism. This effect was not observed with phenyl triflate. The
relevance of this phenomenon to catalytic coupling and oxidative addition of aryl bromides
is discussed. Reactions of triflate complex 2a with several bases to form N-octylaniline are
also reported.
In tr od u ction
imines,36-40 azoles,39 alcohols,41-46 phenols47,48), as
well as in the palladium-catalyzed arylation of olefins
The oxidative addition of aryl halides and sulfo-
nates to Pd(0) is a fundamental organometallic trans-
formation.1,2 It is the first step in the palladium-
catalyzed coupling of organic electrophiles with a variety
of carbon nucleophiles (such as carbonyl enolates,3-6
organomagnesium,7-13 boron,14-24 and tin25,26 reagents)
and heteroatom nucleophiles (thiols,27-30 amines,31-35
(13) Kranenburg, M.; Kamer, P. C. J .; Van Leeuween, P. W. N. M.
Eur. J . Inorg. Chem. 1998, 155-157.
(14) Nicolau, K. C.; Li, H.; Boddy, C. N. C.; Ramanjulu, J . M.; Yue,
T.; Natarajan, S.; Chu, X.; Brase, S.; Rubsam, F. Chem.-Eur. J . 1999,
5, 2584-2601.
(15) Uozumi, Y.; Suzuki, N.; Ogiwara, A.; Hayashi, T. Tetrahedron
1994, 50, 4293-4302.
(16) Vanier, C.; Wagner, A.; Mioskowski, C. Tetrahedron Lett. 1999,
40, 4335-4338.
(1) Collman, J . P.; Hegedus, L. S.; Norton, J . R.; Finke, R. G.
Principles and Applications of Organotransition Metal Chemistry, 2nd
ed.; Wiley-Interscience: New York, 1987; pp 322-333.
(2) Stille, J . K.; Lau, K. S. Y. Acc. Chem. Res. 1977, 10, 4-442.
(3) Shaughnessy, K. H.; Hamann, B. C.; Hartwig, J . F. J . Org. Chem.
1998, 63, 6546-6553.
(17) Firooznia, F.; Gude, C.; Chan, K.; Marcopulos, N.; Satoh, Y.
Tetrahedron Lett. 1999, 40, 213-216.
(18) Gemma, E.; Lopez-Sanchez, M. A.; Martinez, M. E.; Plumet, J .
Tetrahedron 1998, 54, 197-212.
(19) Kowitz, C.; Wegner, G. Tetrahedron 1997, 53, 15553-15574.
(20) Matos, K.; Soderquist, J . A. J . Org. Chem. 1998, 63, 461-470.
(21) Setayesh, S.; Bunz, U. H. F. Organometallics 1997, 15, 55470-
5472.
(4) Hamann, B. C.; Hartwig, J . F. J . Am. Chem. Soc. 1997, 119,
12382.
(5) Palucki, M.; Buchwald, S. L. J . Am. Chem. Soc. 1997, 119,
11108-11109.
(22) Fuerstner, A.; Seider, G. Tetrahedron 1995, 54, 11165-11176.
(23) Ohe, T.; Miyaura, N.; Suzuki, A. J . Org. Chem. 1993, 58, 2201-
2208.
(24) Ishiyama, T.; Kizaki, H.; Hayashi, T.; Suzuki, A.; Miyaura, N.
J . Org. Chem. 1998, 63, 4726-4731.
(25) Newhouse, B. J .; Meyers, A. I.; Sirisoma, N. S.; Braun, M. P.;
J ohnson, C. R. Synlett 1993, 573-574.
(6) Ahman, J .; Wolfe, J . P.; Troutman, M. V.; Palucki, M.; Buchwald,
S. L. J . Am. Chem. Soc. 1998, 120, 1918-1919.
(7) Rehm, J . D. D.; Ziemer, B.; Sziemies, G. Eur. J . Org. Chem. 1999,
2079, 9-2085.
(8) Bumagin, N. A.; Luzikova, E. V.; Beletskaya, I. P. Zh. Org. Khim.
1995, 31, 1663-1666.
(26) Attwood, M. R.; Raynham, T. M.; Smyth, D. G.; Stephenson,
G. R. Tetrahedron Lett. 1996, 37, 2731-2734.
(27) Hartwig, J . F. Acc. Chem. Res. 1998, 31, 852-860.
(28) Mann, G.; Baranano, D.; Hartwig, J . F.; Rheingold, A. L.; Guzei,
I. A. J . Am. Chem. Soc. 1998, 120, 9205-9219.
(29) Baran˜ano, D.; Hartwig, J . F. J . Am. Chem. Soc. 1995, 117,
2937-2938.
(9) Bumagin, N. A.; Sokolova, A. A.; Beletskaya, I. P.; Wolz, G. Zh.
Org. Khim. 1993, 29, 162-164.
(10) Bumagin, N. A.; Andryukhova, N. P.; Beletskaya, I. P. Dokl.
Akad. Nauk SSSR 1987, 297, 1126-1129.
(11) Hayashi, T.; Konishi, M.; Kumada, M. Tetrahedron Lett. 1979,
21, 1871-1874.
(12) Hayashi, T.; Konishi, M.; Kobori, Y.; Kumada, M.; Higuchi, T.;
Hirotsu, K. J . Am. Chem. Soc. 1984, 106, 158-163.
(30) Zheng, N.; McWilliams, J . C.; Fleitz, F. J .; Armstrong, J . D.;
Volante, R. P. J . Org. Chem. 1998, 63, 9606-9607.
10.1021/om0108088 CCC: $22.00 © 2002 American Chemical Society
Publication on Web 01/09/2002

492 Organometallics, Vol. 21, No. 3, 2002
Alcazar-Roman and Hartwig
(Heck reaction).49-68 Often, palladium complexes li-
gated by chelating bisphosphines are efficient cata-
lysts for these reactions. The use of palladium com-
plexes of chelating phosphines, such as DPPF,69 has
improved reaction selectivity relative to that of cata-
lysts ligated by monodentate phosphines such as
PPh3 and P(o-Tol)3.7-13,16-26,31,32,65-68,70-92 Likewise,
BINAP69 has been used as a ligand to confer enan-
tioselectivity in the product of a coupling reaction or
simply as an effective and convenient supporting
ligand.3,5,6,14,15,33,35,37,38,49-64,93-98 Oxidative addition ini-
tiates the catalytic cycle in many cross-coupling pro-
cesses, and it can even be the turnover-limiting step.99,100
It is, therefore, surprising that few studies have ad-
dressed the mechanism of oxidative addition of aryl
halides or sulfonates to Pd(0) ligated by chelating
phosphines,101-103 while many reports document mecha-
nistic features of the oxidative addition of aryl halides
and sulfonates to Pd(PPh3)4.104-109
