Deagostino et al.
SCHEME 1. Aminocarbonylative Coupling on
Lactam-Derived Triflate 1a
FIGURE 1. Heterocyclic Weinreb amides.
perform the reaction at room temperature, and after 3 h, a TLC
and a GC control showed the complete disappearance of the
starting triflate and a 100% conversion. The amide was
recovered with a 55% yield after workup and flash chromatog-
raphy purification. With THF as a solvent, the yield of the amide
2a after flash chromatography purification rose to 78%. The
use of Xantphos proved to be mandatory as experiments
conducted with dppp or dppf in the role of ligands gave only a
12% conversion (determined by GC as an average of two runs)
after 48 h at room temperature with dppp (5%). Longer reaction
times, various catalyst loadings, or different Pd(OAc)2/Xantphos
ratios did not improve the yield. The optimized experimental
conditions were thus applied to the synthesis of a series of
heterocyclic Weinreb amides as reported in Table 1.
Bearing in mind the importance of N-protecting groups in
determining the reactivity of these intermediates in multistep
synthetic sequences, we investigated the feasibility of the
aforementioned experimental conditions to the synthesis of a
series of lactam-derived N-methyl-N-methoxy amides. N-
COOMe and N-tosyl amides 2d and 2e were recovered in good
yields, and in these cases, the crude reaction mixtures could be
filtered through a short pad of Celite and directly used for
subsequent reactions. Different ring sizes are well-tolerated, so
that the pyrrolidinone-derived amide 2b and the caprolactam-
derived amide 2f were isolated in good yields.19 The same
experimental conditions were applied to the synthesis of lactone-
derived amides 2g-i and thiolactone-derived amides 2j-l.
Morpholino enamides are reported to successfully replace
classical Weinreb amides,20 as their use is often preferable due
to, besides their high reactivity, the low cost of morpholine with
respect to N-methoxy-N-methyl amine hydrochloride. To this
end, we envisioned the possibility of using morpholine as an
amine in the aminocarbonylative process: under the experi-
mental conditions set up for N-methoxy-N-methyl amides,
pyrimidyl urethane and Grignard reagents.11 Among palladium
catalysis based strategies, Stille cross-coupling between N-
methoxy-N-methylcarbamoyl chloride with vinyl or aryl stan-
nanes turned out to be an alternative to other synthetic
methods.12 An aminocarbonylative coupling of a dioxinone
moiety in the presence of dppp has been proposed.13 Further-
more, Buchwald proposed a new approach based on the
aminocarbonylation of aryl bromides, in which the efficiency
of the bidentate phosphine Xantphos, known to possess a large
bite angle, has been exploited. The scope of the reaction has
been extended to electron-deficient, -neutral, and -rich aryl
bromides.14 In the context of an ongoing total synthesis project,
we were interested in generating the Weinreb amides, whose
general structure is represented in Figure 1, from the corre-
sponding triflates. This was due to our recent interest in the
Nazarov reaction,15 which prompted us to investigate new and
convenient synthetic sequences leading to conjugated dienones.
To our knowledge, to date, there is only one reference which
concerns the synthesis of substituted N-methoxy-N-methyl-3,4-
dihydro-2H-pyran-6-carboxyamide (X ) O) using a hetero-
Diels-Alder cycloaddition catalyzed by bis(oxazoline) copper-
(II) complexes.16 We therefore decided to undertake an
investigation aimed at evaluating the feasibility of an aminocar-
bonylative coupling for the syntheses of heterocyclic Weinreb
amides and to identify the optimized reaction conditions in order
to establish this as a general method for the synthesis of
heterocyclic acylated derivatives.
Results and Discussion
Preliminary studies were conducted on the triflate prepared
from tert-butyl-2-oxopiperidine-1-carboxylate, according to the
literature procedure.17 The initially chosen conditions were those
proposed by Buchwald in his aminocarbonylative coupling of
aryl bromides;14 hence triflate 1a (Scheme 1) was treated with
2% of Pd(OAc)2, Na2CO3 (3 equiv), and Xantphos as the sup-
porting ligand in toluene as a solvent under 1 atm pressure of
CO.
(17) (a) Prandi, C.; Ferrali, A.; Guarna, A.; Venturello, P.; Occhiato, E.
G. J. Org. Chem. 2004, 69, 7705. (b) Occhiato, E. G.; Prandi, C.; Ferrali,
A.; Guarna, A.; Venturello, P. J. Org. Chem. 2003, 68, 9728. (c) Occhiato,
E. G.; Prandi, C.; Ferrali, A.; Guarna, A.; Deagostino, A.; Venturello P. J.
Org. Chem. 2002, 67, 7144 and references therein.
On the basis of the remarkable reactivity of heterocyclic-
(18) Occhiato, E. G. Mini-ReV. Org. Chem. 2004, 1, 149.
derived triflates in cross-coupling reactions,18 we decided to
(19) In the case of caprolactam N-Cbz-protected triflate 1f (entry 6),
besides the foreseen amide, we came across an unexpected rearranged
product, isolated with 21% yield, whose structure has tentatively been
assigned and is represented in the figure. See Experimental Section. A
similar rearrangement in the presence of Cbz as protecting group leading
to an oxazolidinone framework has already been observed. For more details,
see ref 17c.
(10) Nemoto, H.; Ma, R.; Moriguchi, H.; Kawamura, T.; Kamiya, M.;
Shibuya, M. J. Org. Chem. 2007, 72, 9850.
(11) Lee, J. I. Bull. Korean Chem. Soc. 2007, 28, 695.
(12) Murakami, M.; Hoshino, Y.; Ito, H.; Ito, Y. Chem. Lett. 1998, 163.
(13) (a) Aungst, R. A.; Funk, R. L. J. Am. Chem. Soc. 2001, 123, 9455.
For the carbonylative synthesis of amides, see also: (b) Morera, E.; Ortar,
G. Tetrahedron Lett. 1998, 39, 2835. (c) Haffner, C. Tetrahedron Lett. 1994,
35, 6117. (d) Lan-Hargest, H. Y.; Elliott, J. D.; Egglestone, D. S.; Holt, D.
A.; Levy, M. A.; Metcalf, B. W. Tetrahedron Lett. 1987, 49, 6117.
(14) Martinelli, J. R.; Freckmann, D. M. M.; Buchwald, S. L. Org. Lett.
2006, 8, 4843.
(15) (a) Bartali, L.; Larini, P.; Guarna, A.; Occhiato, E. G. Synthesis
2007, 1733. (b) Bartali, L.; Larini, P.; Guarna, A.; Occhiato, E. G. Eur. J.
Org. Chem. 2007, 2152. (c) Cavalli, A.; Masetti, M.; Recanatini, M.; Prandi,
C.; Guarna, A.; Occhiato, E. G. Chem.sEur. J. 2006, 12, 2836. (d) Prandi,
C.; Deagostino, A.; Venturello, P:, Occhiato, E. G. Org. Lett. 2005, 7, 4345.
(16) Evans, D. A.; Johnson, J. S.; Edward, J. O. J. Am. Chem. Soc. 2000,
122, 1635.
(20) (a) Martin, R.; Romea, P.; Tey, C.; Urp`ı, F.; Vilarrasa, J. Synlett
1997, 1414. (b) Dhoro, F.; Kristensen, T. E.; Stockmann, V.; Yap, G. P.
A.; Tius, M. A. J. Am. Chem. Soc. 2007, 129, 7256. (c) delos Santos, D.
B.; Banaag, A. R.; Tius, M. A. Org. Lett. 2006, 8, 2579. (d) Banaag, A. R.;
Berger, G. O.; Dhoro, F.; delos Santos, D. B.; Dixon, D. D.; Mitchell, J.
P.; Tokeshi, B. K.; Tius, M. A. Tetrahedron 2005, 61, 3419. (e) Bee, C.,
Tius, M. A. Org. Lett. 2003, 5, 1681 and references therein.
1942 J. Org. Chem., Vol. 73, No. 5, 2008
