SCHEME 3. Synthesis of Di-N-Boc Indolic
1,2-Diaminoethanes 12a-c
Experimental Section
1-[N-(tert-Butoxycarbonyl)-N-hydroxyamino]-3-methyl-1-(thien-
2-yl)butane (4a). To a stirred solution of sulfone 1a (200 mg, 0.58
mmol) in toluene (4 mL) under inert atmosphere was added 2 equiv
of 2-thienylmagnesium bromide (1.16 mL, 1.16 mmol, 1 M solution
in toluene) at room temperature. The resulting mixture was stirred
during 45 min before being quenched by addition of an aqueous
saturated solution of ammonium chloride. The mixture was then
extracted three times with EtOAc. The organic layers were washed
with brine and dried over anhydrous magnesium sulfate. After the
removal of the solvent, the crude mixture was then purified by
column chromatography on silica gel (eluent: CH2Cl2) to give the
pure product 4a (145 mg, 0.51 mmol). Yield: 88%. IR (film): 3211,
2961, 2931, 2871, 1686, 1476, 1399, 1319, 1236, 1170, 1136, 1096,
1
1043 cm-1. H NMR (CDCl3, 300 MHz): δ 0.94 (d, J ) 5.9 Hz,
3H, CH3), 0.96 (d, J ) 5.9 Hz, 3H, CH3), 1.46 (s, 9H, C(CH3)3),
1.55-1.75 (m, 2H, CH2), 2.05-2.20 (m, 1H, CH), 5.33 (dd, J )
5.6 and 9.8 Hz, 1H, CHN), 6.93 (dd, J ) 3.7 and 4.9 Hz, 1H, H
arom), 7.00 (d, J ) 3.2 Hz, 1H, H arom), 7.10 (s, 1H, OH), 7.18
(d, J ) 4.9 Hz, 1H, H arom). 13C NMR (CDCl3, 75.5 MHz): δ
21.7 (CH3), 22.9 (CH3), 24.8 (CH), 28.3 (C(CH3)3), 41.7 (CH2),
56.1 (CHN), 82.1 (C(CH3)3), 124.5 (CH arom), 125.2 (CH arom),
126.3 (CH arom), 142.6 (C arom), 156.7 (CdO). LRMS (ESI):
m/z ) 292 [(M + Li)+], 577 [(dimer + Li)+]. Anal. Calcd for
C14H23NO3S: C, 58.92; H, 8.13; N, 4.91. Found: C, 59.27; H, 8.22;
N, 4.83.
N-Hydroxylamine 7a was deprotected with hydrochloric acid
in Merino’s conditions,16 and the reaction of the resulting
primary N-hydroxylamine 8 with trimethylsilyl isocyanate
afforded racemic zileuton 9 in the excellent overall yield of 31%
in four steps from the commercially available tert-butyl N-
hydroxycarbamate.
Finally, we studied the reactions of sulfone 1b with indolyl-
magnesium bromides 10, obtained by metalation of the corre-
sponding indolic cores with methylmagnesium bromide.17 We
prepared R-indol-3′-yl-N-Boc-N-hydroxylamines 11a-e in ex-
cellent yields (Scheme 2). It is noteworthy that no transmetal-
ation occurred when halogenated indoles were used, allowing
access to halogenated products. The reduction of the N-OH bond
in compounds 11a, 11b, and 11e with samarium(II) diiodide
afforded 1,2-diamino indolic compounds 12a-c which could
be key intermediates in the synthesis of marine sponge
alkaloids18,19 of the spongotine and topsentin classes 13 and 14
(Scheme 3).
In conclusion, we have developed a novel method for the
synthesis of R-aryl-N-hydroxyamino compounds via the reaction
of N-Boc nitrone precursors 1a-e with aromatic and heteroaro-
matic Grignard reagents. We have shown that this reaction is
very general concerning the choice of the organometallic
reagent. We have applied this new methodology to the synthesis
of zileuton in an overall yield of 31% in four steps from the
commercially available tert-butyl N-hydroxycarbamate. Finally,
we have prepared the di-N-Boc indolic 1,2-diaminoethanes
12a-c, potential building blocks in the total syntheses of
spongotine and topsentin marine sponge products 13 and 14.
1-[N-(tert-Butoxycarbonyl)-N-hydroxyamino]-1-(benzothien-
2-yl)ethane (7a). To a solution of thianaphthene (89 mg, 0.66
mmol) in ether (1 mL) at room temperature was added n-BuLi (1.28
M in hexane 0.52 mL, 0.66 mmol). After 55 min of reaction,
MgBr2‚OEt2 (171 mg, 0.66 mmol) was added in three portions to
give a suspension of 2-benzothienylmagnesium bromide. To this
solution was added a solution of sulfone 1f (100 mg, 0.33 mmol)
in toluene (4 mL) and THF (1 mL). The resulting mixture was
allowed to stir at room temperature during 1 h. It was then quenched
by addition of a saturated aqueous solution of ammonium chloride.
Aqueous layers were extracted twice with EtOAc. The combined
organic layers were washed with brine, dried over anhydrous
magnesium sulfate, and filtered. The solvents were removed under
reduced pressure, and the residue was purified by column chro-
matography on flash silica gel (eluent: CH2Cl2). The product 7a
was obtained as a pale amorphous solid (73 mg, 0.25 mmol).
Yield: 76%. IR (KBr): 3213, 3150, 2962, 2869, 1681, 1408, 1389,
1
1325, 1157, 1101, 1011 cm-1. H NMR (CDCl3, 300 MHz): δ
1.47 (s, 9H, C(CH3)3), 1.71 (d, J ) 6.9 Hz, 3H, CH3), 5.48 (dq, J
) 1.0 and 7.0 Hz, 1H, CHN), 7.20 (s, 1H, H arom), 7.18-7.35
(m, 2H, H arom), 7.65-7.80 (m, 2H, H arom). 13C NMR (CDCl3,
75.5 MHz): δ 18.0 (CH3), 28.2 (C(CH3)3), 54.5 (CHN), 82.6
(C(CH3)3), 121.5, (CH arom), 122.2 (CH arom), 123.4 (CH arom),
124.2 (CH arom),139.4 (C arom), 139.5 (C arom),144.5 (C arom),
156.6 (CdO). Anal. Calcd for C15H19NO3S: C, 61.41; H, 6.53; N,
4.78. Found: C, 61.19; H, 6.70; N, 4.70.
1-(N-Hydroxyamino)-1-(benzothien-2-yl)ethane (8). A cold
solution of hydrochloric acid was prepared at 0 °C by adding 271
µL (300 mg, 3.82 mmol) of freshly distilled acetyl chloride to 1
mL of dry methanol. The resulting solution was stirred for 15 min
at 0 °C. A solution of N-hydroxylamine 7a (80 mg, 0.273 mmol)
in 0.7 mL of methanol was then added to the acidic solution at 0
°C, and the resulting mixture was stirred for an additional 2 h.
Methanol was then slowly evaporated under vacuum (temperature
<20 °C). The residue was dissolved in EtOAc, and to the resulting
mixture was added a saturated solution of sodium hydrogenocar-
bonate. It was then extracted twice with CH2Cl2. The combined
organic layers were washed with brine and dried over anhydrous
magnesium sulfate. After removal of the solvents, the residue was
purified by column chromatography on silica gel (eluent: CH2-
Cl2). The product 8 was obtained as a yellow amourphous solid
(34 mg, 0.18 mmol). Yield: 66%. IR (KBr): 3171, 3049, 2977,
(14) (a) Kolasa, T.; Brooks, D. W. Synth. Commun. 1993, 23, 743. (b)
Basha, A.; Ratajczyk, J. D.; Brooks, D. W. Tetrahedron Lett. 1991, 32,
3783.
(15) (a) Hsiao, C.-N.; Kolasa, T. Tetrahedron Lett. 1992, 33, 2629. (b)
Rohloff, J. C.; Alfredson, T. V.; Schwartz, M. A. Tetrahedron Lett. 1994,
35, 1011.
(16) Merino, P.; Lanaspa, A.; Merchan, F. L.; Tejero, T. Tetrahedron:
Asymmetry 1997, 8, 2381.
(17) Bodwell, G. J.; Li, J. Org. Lett. 2002, 4, 127.
(18) (a) Guinchard, X.; Valle´e, Y.; Denis, J.-N. J. Org. Chem. 2007, 72,
3972. (b) Guinchard, X.; Valle´e, Y.; Denis, J.-N. Org. Lett. 2007, 9, 3761
and references cited therein.
(19) For a general review on bis(indole) alkaloids, see: Yang, C.-G.;
Huang, H.; Jiang, B. Curr. Org. Chem. 2004, 8, 1691.
2030 J. Org. Chem., Vol. 73, No. 5, 2008
