2436
E. Arnáiz et al. / Journal of Organometallic Chemistry 693 (2008) 2431–2437
reactive cooled to 0 °C were added. The resulting mixture was stir-
red during 2 h, isopropanol (3 mL) was added and the reaction
mixture was extracted with EtOAc (2 Â 25 mL). The organic layer
was washed with water until loss of its color, and it was dried over
MgSO4, filtered and concentrated. Purification by column chroma-
tography (hexane/EtOAc 4:1) gives 0.42 g (75%) of 14 as a yellow
oil. 1H NMR (300 MHz, CDCl3): d = 0.18 (s, 9H), 2.09 (s, 3H), 2.73
(t, 2H, J = 7.7 Hz), 2.97 (t, 2H, J = 7.7 Hz), 3.72 (s, 3H), 4.56 (s, 2H),
6.62 (dd, 1H, J1 = 8.8 Hz, J2 = 2.2 Hz), 6.67 (d, 1H, J = 2.2 Hz), 7.31
(d, 1H, J = 8.8 Hz) ppm. 13C NMR (75 MHz, CDCl3): d = À0.1, 20.3,
28.4, 38.9, 55.0, 67.7, 96.7, 103.3, 111.7, 114.4, 114.5, 133.8,
144.6, 159.7, 169.9, 202.8 ppm. IR (film): m = 2960, 2150, 1760,
1740 cmÀ1. Calc. for C18H24O4Si (332.47): C, 65.03; H, 7.28. Found:
C, 64.97; H, 7.19%.
ylcyclohexyl chlorocarbonate (0.1 g, 0.45 mmol) were added.
The mixture was stirred at room temperature for 2 h. Then, water
(10 mL) was added at 0 °C and the reaction mixture was ex-
tracted with DCM (3 Â 10 mL). The organic layer was washed
with water (10 mL) and brine (10 mL), dried over MgSO4, filtered
and concentrated. Purification was carried out by column chro-
matography using hexane/EtOAc (20:1) as eluent. Compound 17
was obtained (0.15 g, 93%) as a whitish oil. 1H NMR (300 MHz,
CDCl3): d = 0.79 (d, 3H, J = 6.6 Hz), 0.89–0.93 (m, 6H), 1.00–1.12
(m, 2H), 1.26–1.46 (m, 3H), 1.63–1.72 (m, 2H), 1.93–2.01 (m,
1H), 2.03–2.13 (m, 1H), 2.41 (t, 2H, J = 8,2 Hz), 2.93 (t, 2H,
J = 8,2 Hz), 3.18 (s, 1H), 3.79 (s, 3H), 4.22 (td, 1H, J1 = 10.9 Hz,
J2 = 4.4 Hz), 4.63 (s, 2H), 5.01 (s, 1H), 5.11 (s, 1H), 6.68–6.74
(m, 2H), 7.40 (d, 1H, J = 8.8 Hz) ppm. 13C NMR (75 MHz, CDCl3):
d = 16.2, 20.6, 21.9, 23.2, 26.0, 31.3, 33.0, 33.6, 34.0, 40.7, 46.9,
55.1, 69.7, 78.3, 79.5, 82.1, 111.5, 113.0, 113.6, 114.3, 134.2,
142.9, 145.9, 154.8, 159.8 ppm. IR (film): m = 2930, 2100, 1740,
1610 cmÀ1. Calc. for C25H34O4 (398.54): C, 75.34; H, 8.60. Found:
C, 75.08; H, 8.41%.
3.12. Synthesis of 4-(2-ethynyl-5-methoxyphenyl)-2-methylenebutyl
acetate, 15
Methyl triphenylphosphonium chloride (0.54 g, 1.5 mmol) was
suspended in anhydrous THF (8 mL) and KHMDS 0.5 M (2.6 mL,
1.3 mmol) was added dropwise. After stirring at rt for 30 min this
mixture was cannulated to a flask containing a solution of 14
(0.33 g, 1.0 mmol) in anhydrous THF (4 mL). The resulting mixture
was stirred for 30 min, poured onto a 1:1 mixture of water and
Et2O (20 mL), and extracted. The organic layer was washed with
water (2 Â 10 mL) and brine (2 Â 10 mL), dried over MgSO4 and
concentrated. After purification by column chromatography (hex-
ane/EtOAc 4:1), the resulting intermediate was solved in 6 mL of
anhydrous THF at 0 °C, and TBAF 1.0 M (2 mL, 2.0 mmol) was
added. The resulting mixture was stirred during 2 h and Et2O
(6 mL), hexane (6 mL) and water (6 mL) were added. The organic
layer was washed with water (12 mL), dried over MgSO4 and con-
centrated. Purification by column chromatography (hexane/EtOAc
4:1) gives 0.21 g (82%) of 15 as a colorless oil. 1H NMR (300 MHz,
CDCl3): d = 2.10 (s, 3H), 2.39 (t, 2H, J = 8.8 Hz), 2.92 (t, 2H,
J = 8.8 Hz), 3.19 (s, 1H), 3.79 (s, 3H), 4.58 (s, 2H), 5.00 (s, 1H),
5.08 (s, 1H), 6.70 (dd, 1H, J1 = 8.3 Hz, J2 = 2.2 Hz), 6.74 (d, 1H,
J = 2.2 Hz), 7.40 (d, 1H, J = 8.3 Hz) ppm. 13C NMR (75 MHz, CDCl3):
d = 20.9, 33.1, 33.8, 55.2, 66.8, 79.4, 82.1, 111.4, 112.9, 113.6, 114.4,
134.3, 143.2, 145.9, 159.9, 170.7 ppm. IR (film): m = 3280, 2940,
2100, 1740, 1610 cmÀ1. Calc. for C16H18O3 (258.31): C, 74.39; H,
7.02. Found: C, 74.44; H, 7.10%.
3.15. Synthesis of (7-methoxy-2-oxo-3,3a,4,5-tetrahydro-2H-
cyclopenta[a]naphthalen-3a-yl)methyl acetate, 21
To a solution of 15 (0.28 g, 1.1 mmol) in 5 mL of anhydrous
Et2O, 0.13 g (0.37 mmol) of dicobalt octacarbonyl were added.
The mixture was stirred at rt for 3 h and filtered through Celite.
Upon column chromatography (hexane/EtOAc 49:1) 0.55 g (90%)
of 18 were obtained as a brown oil. To a solution of 18 (0.55 g
1.0 mmol) in 15.0 mL of anhydrous toluene, powdered 4 Å molec-
ular sieves (two times the mass of the enyne) and Rh(PPh3)2ClCO
(0.05 mmol) were added. The mixture was stirred at 70 °C under
argon for 18 h. The crude residue was filtered through Celite, con-
centrated and purified by column chromatography (hexane/EtOAc
10:1), giving 0.17 g (60%) of 21 as a colorless oil. 1H NMR
(300 MHz, CDCl3): d = 1.88 (td, 1H, J1 = 13.2 Hz, J2 = 6.0 Hz), 2.01
(s, 3H), 2.23 (d, 1H, J = 18.1 Hz), 2.25–2.30 (m, 1H), 2.67 (d, 1H,
J = 18.1 Hz), 2.87 (dd, 1H, J1 = 17.6 Hz, J2 = 6.0 Hz), 2.96–3.08 (m,
1H), 3.82 (s, 3H), 3.87 (d, 1H, J = 11.0 Hz), 4.22 (d, 1H,
J = 11.0 Hz), 6.27 (s, 1H), 6.69 (br s, 1H), 6.81 (dd, 1H, J1 = 8.8 Hz,
J2 = 2.7 Hz), 7.54 (d, 1H, J = 8.8 Hz) ppm. 13C NMR (75 MHz, CDCl3):
d = 20.8, 26.3, 30.3, 44.8, 47.6, 55.4, 66.8, 113.6, 113.8, 121.9, 123.3,
129.3, 139.6, 161.9, 170.8, 173.3, 206.1 ppm. IR (film): m = 1750,
1690 cmÀ1. Calc. for C17H18O4 (286.32): C, 71.31; H, 6.34. Found:
C, 71.58; H, 6.17%.
3.13. Synthesis of 4-(2-ethynyl-5-methoxyphenyl)-2-methylenebutan-
1-ol, 16
3.16. (1S,2R,5S)-2-isopropyl-5-methylcyclohexyl (7-methoxy-2-oxo-
3,3a,4,5-tetrahydro-2H-cyclopenta[a]naphthalen-3a-yl)methyl
carbonate, 23
To a solution of 15 (0.23 g, 0.9 mmol) in THF (5.3 mL), 12.6 mL
(37.9 mmol) of 3 N NaOH were added and the resulting mixture
was refluxed for 2 h. The reaction mixture was extracted with
EtOAc (2 Â 6 mL), washed with 0.1 N HCl (20 mL), water (20 mL)
and brine (20 mL), dried over MgSO4 and concentrated. Upon puri-
fication by column chromatography using hexane/EtOAc as eluent,
0.18 g (90%) of 16 were obtained as a yellow oil. 1H NMR (300 MHz,
CDCl3): d = 2.36 (t, 2H, J = 8.2 Hz), 2.90 (t, 2H, J = 8.2 Hz), 3.17 (s,
1H), 3.77 (s, 3H), 4.10 (s, 2H), 4.90 (s, 1H), 5.05 (s, 1H), 6.67 (dd,
1H, J1 = 8.2 Hz, J2 = 2.2 Hz), 6.72 (d, 1H, J = 2.2 Hz), 7.38 (d, 1H,
J = 8.2 Hz) ppm. 13C NMR (75 MHz, CDCl3): d = 33.3, 33.7, 55.2,
65.7, 79.3, 82.3, 109.8, 111.4, 113.6, 114.3, 134.3, 146.2, 148.3,
159.9 ppm. IR (film): m = 3400, 3290, 2930, 2100, 1610 cmÀ1. Calc.
for C14H16O2 (216.28): C, 77.75; H, 7.46. Found: C, 77.80; H, 7.51%.
Following the same procedure than for the synthesis of 21, from
0.10 g of 20, which was obtained from 0.06 g (0.15 mmol) of 17,
0.03 g (45%) of a (1:1) mixture of diastereomers was obtained as
a yellow oil. Data for the mixture: 1H NMR (300 MHz, CDCl3):
d = 0.74 (d, 3H, J = 7.2 Hz), 0.86–0.90 (m, 6H), 0.96–1.08 (m, 1H),
1.23 (s, 2H), 1.39–1.42 (m, 1H), 1.57–1.67 (m, 4H), 1.82–1.91 (m,
1H), 1.98 (d, 1H, J = 12.1 Hz), 2.24 (d, 1H, J = 18.2 Hz), 2.34 (dd,
1H, J1 = 13.2 Hz, J2 = 5.5 Hz), 2.74 (d, 1H, J = 18.2 Hz), 2.88 (dd,
1H, J1 = 17.6 Hz, J2 = 6.0 Hz), 3.02 (dd, 1H, J1 = 12.6 Hz, J2 = 5.5 Hz),
3.86–3.93 (m, 1H), 4.22–4.29 (m, 1H), 4.41–4.50 (m, 1H), 6.26 (s,
1H), 6.71 (br s, 1H), 6.81 (dd, 1H, J1 = 8.8 Hz, J2 = 2.2 Hz), 7.53 (d,
1H, J = 8.3 Hz) ppm. 13C NMR (75 MHz, CDCl3): d = 14.1, 16.3,
20.7, 21.8, 22.7, 23.3, 26.0, 26.3, 29.4, 29.5, 29.6, 29.7, 29.9, 30.9,
31.4, 32.0, 34.0, 40.6, 45.2, 46.9, 47.5, 55.4, 69.8, 78.8, 113.6,
113.8, 121.9, 123.5, 129.2, 139.7, 154.8, 161.9, 173.2, 190.0,
3.14. Synthesis of 4-(2-ethynyl-5-methoxyphenyl)-2-methylenebutyl
(1S,2R,5S)-2-isopropyl-5-methylcyclohexyl carbonate, 17
To a solution of 16 (0.86 g, 0.4 mmol) in anhydrous DCM
(5.5 mL) at 0 °C, pyridine (0.1 mL) and (+)-2-isopropyl-5-meth-
196.1 ppm. IR (film): m = 1740, 1600 cmÀ1
.
