Heteroatom-Annulated Perylenes: Practical
Synthesis, Photophysical Properties, and
Solid-State Packing Arrangement
Wei Jiang,†,‡ Hualei Qian,†,‡ Yan Li,†,‡ and
Zhaohui Wang*,†
Beijing National Laboratory for Molecular Sciences, Key
Laboratory of Organic Solids, Institute of Chemistry,
Chinese Academy of Sciences, Beijing 100190, China, and
Graduate School of the Chinese Academy of Sciences,
Beijing 100190, China
S-heterocyclic annulated perylene, namely perylo[1,12-
b,c,d]thiophene (PET, 3), which has first prepared from 3,4:9,
10-perylenetetracarboxylic dianhydride by Rogovik,6 has been
synthesized by several groups in harsh conditions such as flash
vacuum pyrolysis (FVP).7 However, its electrical property is
rarely studied, probably due to the difficulties in scale-up, long
reaction sequences, and poor yields. Recently, we reported its
extraordinary solid-state packing arrangement with marked
S· · ·S short contacts of 3.51 Å between the neighboring columns
and the likelihood of double-channel superstructure, which is
responsible for effective intermolecular carrier transport.5c
Herein, we describe our endeavors to develop a new and
practical synthetic route toward PET up to gram-scale success-
fully. Furthermore, Se-heterocyclic annulated perylene is syn-
thesized by incorporating selenium into the perylene skeleton.
Accordingly, detailed investigation of photophysical properties
and single-crystal analysis of heterocyclic annulated perylenes
is presented to fully explore the influence of different heteroa-
toms on the inherent electronic properties and solid-state packing
arrangement.
wangzhaohui@iccas.ac.cn
ReceiVed June 12, 2008
A practical strategy for the preparation of a series of
heterocyclic annulated perylenes in good yields is presented.
UV-vis absorption spectra indicate hypsochromic shift of
the absorption maxima relative to the corresponding parent
perylene. Single-crystal X-ray diffraction analysis reveals that
they all adopt planar conformation, but the solid-state packing
arrangements are significantly altered by annulation of
various heterocycles.
The key starting material is 1-nitroperylene 2. Previous
synthetic reports8 of 2 were unsatisfactory in that the yield of
the regiospecific mononitration of perylene at position 1 was
rather low or the reaction was irreproducible.9 Successful
preparation of 2 from perylene is achieved in a modified
mononitration of the perylene process, by which the temperature
is reduced and the reaction time is shortened to 25-30 min.
There are three main fractions in the crude products. The first
(2) (a) Dopper, J. H.; Wynberg, H. J. Org. Chem. 1975, 40, 1957–1966. (b)
Klemm, L. H.; Hall, E.; Cousins, L.; Klopfenstein, C. E. J. Heterocycl. Chem.
1987, 24, 1749–1755. (c) Klemm, L. H.; Hall, E.; Cousins, L.; Klopfenstein,
C. E. J. Heterocycl. Chem. 1989, 26, 345–348. (d) Lawson, J.; DuVernet, R.;
Boekelheide, V. J. Am. Chem. Soc. 1973, 95, 956–957. (e) DuVernet, R.; et al.
J. Am. Chem. Soc. 1978, 100, 2457–2464. (f) Langhals, H.; Kirner, S. Eur. J.
Org. Chem. 2000, 365–380.
(3) (a) Werner, T. C.; Chang, J.; Hercules, D. M. J. Am. Chem. Soc. 1969,
92, 5560–5565. (b) Rathore, R.; Kumar, A. S.; Lindeman, S. V.; Kochi, J. K. J.
Org. Chem. 1998, 63, 5847–5856. (c) Shkrob, I. A. J. Phys. Chem. A 1998,
102, 4976–4989.
(4) Qian, H.; Liu, C.; Wang, Z.; Zhu, D. Chem. Commun. 2006, 4587–4589.
(5) (a) Briseno, A. L.; Miao, Q.; Ling, M.; Reese, C.; Meng, H.; Bao, Z.;
Wudl, F. J. Am. Chem. Soc. 2006, 128, 15576–15577. (b) Wu, Y.; Li, Y.;
Gardner, S.; Ong, B. S. J. Am. Chem. Soc. 2005, 127, 614–618. (c) Sun, Y.;
Tan, L.; Jiang, S.; Qian, H.; Wang, Z.; Yan, D.; Di, C.; Wang, Y.; Wu, W.; Yu,
G.; Yan, S.; Wang, C.; Hu, W.; Liu, Y.; Zhu, D. J. Am. Chem. Soc. 2007, 129,
1882–1883. (d) Zhou, Y.; Liu, W.; Ma, Y.; Wang, H.; Qi, L.; Cao, Y.; Wang,
J.; Pei, J. J. Am. Chem. Soc. 2007, 129, 12386–12387. (e) Yamamoto, T.;
Takimiya, K. J. Am. Chem. Soc. 2007, 129, 2224–2225. (f) Usta, H.; Lu, G.;
Facchetti, A.; Marks, T. J. J. Am. Chem. Soc. 2006, 128, 9034–9035.
(6) Rogovik, V. I. J. Org. Chem. (USSR) 1974, 10, 1072.
Highly π-extended heteroarenes, which contain chalcogen,
nitrogen, etc. in fused aromatic rings, are the subjects of
considerable current research interest due to their fundamental
optoelectronic properties and their potential applications such
as organic field-effect transistors (OFETs), light emitting diodes
(LEDs), photovoltaic devices, and other organic optoelectronic
devices.1 Attempts to construct bay-region heterocyclic annu-
lated polycyclic aromatic hydrocarbons (PAHs) such as triph-
enylene, pyrene, perylene, and perylene bisimides have been
performed during the past decades.2 However, due to the
difficulty in the establishment of efficient and practical synthetic
protocols, further investigation of structure/properties relation-
ship of the heterocyclic annulated PAHs is rather limited.
Perylene is unique in the family of PAHs and has been
extensively studied due to its excellent optical and electronic
(7) (a) Imamura, K.; Hirayama, D.; Yoshimura, H.; Takimiya, K.; Aso, Y.;
Otsubo, T. Tetrahedron Lett. 1999, 40, 2789–2792. (b) Bluemer, G. P.; et al.
Chem. Ber. 1977, 110, 269–272. (c) Solomentseva, T. I.; Rogovik, V. I.;
Chibisova, T. A.; Traven, V. F.; Stepanov, B. I. J. Org. Chem. (USSR) 1986,
943–946.
(8) Looker, J. J. J. Org. Chem. 1972, 37, 3379–3381.
(9) Eberson, L.; Radner, F. Acta Chem. Scand. B 1985, 39, 357–374.
† Institute of Chemistry, Chinese Academy of Sciences.
‡ Graduate School, Chinese Academy of Sciences.
(1) (a) Anthony, J. E. Chem. ReV 2006, 106, 5028–5048. (b) See a special
issue on organic electronics: Chem. Mater. 2004, 16,4381. (c) Takimiya, K.;
Jigami, T.; Kawashima, M.; Kodani, M.; Aso, Y.; Otsubo, T. J. Org. Chem.
2002, 67, 4218–4227.
10.1021/jo8012622 CCC: $40.75
Published on Web 08/09/2008
2008 American Chemical Society
J. Org. Chem. 2008, 73, 7369–7372 7369

SCHEME 1. Preparation of Heterocyclic Annulated
Perylenesa
Crystals of 4, 5, and 7 suitable for single-crystal X-ray
analysis are obtained by slow evaporation of their dilute solution.
The crystal structure of perylo[1,12-b,c,d]selenophene 4 shows
