Enantioselective Alkynylation of N-(Diphenylphosphinoyl)imines
(S)-N-(1,3-Diphenylprop-2-ynyl)-4-methylbenzenesulfonamide: Com-
pound 3a (20.7 mg, 99% ee, 0.1 mmol) was dissolved in CH2Cl2
(15 mL) in a 50 mL round-bottomed flask, and Et3N (21 µL,
0.15 mmol) was added. The mixture was then cooled to 0 °C, and
Tos-Cl (19 mg, 0.1 mmol) was added in one portion. The resulting
mixture was stirred overnight and then washed successively with
aqueous HCl (1 , 5 mL) and H2O (5 mL). The organic layer was
separated and dried with Na2SO4. After filtration and evaporation
of the solvents, the crude residue was purified by flash chromatog-
raphy (silica gel, hexane/CH2Cl2), giving the product as a white
solid, m.p. 213–216 °C, 85% yield. [α]2D0 = –94 (c = 1.2, CHCl3). 1H
NMR (300 MHz, CDCl3): δ = 7.82 (dd, J = 5.1, 1.5 Hz, 2 H), 7.56
(dd, J = 5.7, 1.8 Hz, 2 H), 7.36–7.23 (m, 8 H), 7.12 (dd, J = 6.6,
1.8 Hz, 2 H), 5.57 (d, J = 9 Hz, 1 H), 4.89 (d, J = 9.3 Hz, 2 H),
2.32 (s, 3 H) ppm. 13C NMR (75 MHz, CDCl3): δ = 143.6, 137.3,
131.5, 129.6, 128.7, 128.6, 128.5, 128.1, 127.5, 127.3, 121.9, 86.7,
yields and high to excellent enantioselectivities. The prod-
ucts could be conveniently converted into the correspond-
ing propargylic amines by treatment with HCl/MeOH. Al-
though the reaction required stoichiometric amounts of the
amino alcohols, the ligands could be recovered in 90% yield
by column chromatography, and the reaction conditions
were quite mild.
Experimental Section
N-(1,3-Diphenylprop-2-ynyl)-P,P-diphenylphosphinic Amide: In an
oven-dried Schlenk flask, under an inert atmosphere of argon, were
placed L7 (48.2 mg, 0.2 mmol), followed by anhydrous CH2Cl2
(2 mL). A solution of diethylzinc in CH2Cl2 (0.8 mL, 0.8 mmol,
4.0 equiv.) was then added. The reaction mixture was stirred for
30 min, and phenylacetylene (88 µL, 0.8 mmol, 4 equiv.) was
added. The resulting solution was stirred for an additional 7 h, and
N-benzylidene-P,P-diphenylphosphinic amide was then added. The
reaction mixture was stirred at 0 °C for 48 h. Subsequently, satu-
rated aqueous NH4Cl (2 mL) was added slowly at 0 °C, and the
resulting mixture was extracted with CH2Cl2 (3ϫ10 mL). The
combined organic layers were dried with Na2SO4. After filtration
and evaporation of the solvents, the crude residue was purified by
flash chromatography (silica gel, hexane/ethyl acetate) to give the
product as a white solid; m.p. 178–180 °C, 78% yield, 95% ee, as
determined by HPLC analysis (Daicel Chiralcel AD column, hex-
ane/2-propanol, 85:15, 1.0 mL/min, 254 nm). Retention times:
tmajor = 11.86 and tminor = 10.70 min. [α]2D0 = –92 (c = 1.0, CHCl3).
1H NMR (300 MHz, CDCl3): δ = 8.13–8.06 (m, 2 H), 7.90–7.83
(m, 2 H), 7.71–7.69 (m, 2 H), 7.54–7.46 (m, 4 H), 7.44–7.37 (m, 5
H), 7.35–7.30 (m, 5 H), 5.40 (t, J = 9.6 Hz, 1 H), 3.55 (t, J =
9.3 Hz, 1 H) ppm. 13C NMR (75 MHz, CDCl3): δ = 140.4 [d, JC,P
= 4.5 Hz], 133.4, 132.8 [d, JC,P = 9.8 Hz], 132.1 [d, JC,P = 6.8 Hz],
132.8 [d, JC,P = 9.8 Hz], 131.7, 131.5, 129.0, 128.7 [d, JC,P = 6 Hz],
128.4 [d, JC,P = 12 Hz], 128.0, 127.4, 122.8, 89.0 [d, JC,P = 6 Hz],
85.4, 49.8, 21.4 ppm. IR (KBr): ν = 3265, 2920, 2221, 1595, 1488,
˜
1326, 1153, 1088, 1047, 814, 752, 673, 556 cm–1. HRMS for
C22H19NO2S [M + Na+]: calculated 384.1029; found 384.1034.
Supporting Information (see also the footnote on the first page of
this article): Preparative details and NMR spectra.
Acknowledgments
We are grateful to the National Natural Science Foundation of
China (20525206, 20772052, 90813012, and 20621091) and the
Chang Jiang Program of the Ministry of Education of China for
financial support.
[1] a) Y. Mori, H. Hayashi, Tetrahedron 2002, 58, 1789–1797; b)
C. V. Galliford, M. A. Beenen, S. T. Nguyen, K. A. Scheidt,
Org. Lett. 2003, 5, 3487–3490; c) C. I. Garcia, A. Tillack, C. G.
Hartung, M. Beller, Tetrahedron Lett. 2003, 44, 3217–3221.
[2] For reviews, see: a) A. E. Shilov, G. B. Shul’pin, Chem. Rev.
1997, 97, 2879–2932; b) C. Wei, Z. Li, C.-J. Li, Synlett 2004,
1472–1483; c) P. G. Cozzi, R. Hilgraf, N. Zimmermann, Eur. J.
Org. Chem. 2004, 4095–4105; d) H. J. Zhu, J. X. Jiang, J. Ren,
Y. M. Yan, C. U. Pittman Jr., Curr. Org. Synth. 2005, 2, 547–
587; e) L. Zani, C. Bolm, Chem. Commun. 2006, 4263–4275; f)
M. Hatano, T. Miyamoto, K. Ishihara, Curr. Org. Chem. 2007,
11, 127–157.
[3] For examples, see: a) C. Wei, C.-J. Li, J. Am. Chem. Soc. 2002,
124, 5638–5639; b) F. Colombo, N. Gommermann, C. Kora-
din, K. Polborn, P. Knochel, Angew. Chem. 2003, 115, 5941–
5944; Angew. Chem. Int. Ed. 2003, 42, 5763–5766; c) C. Wei,
J. T. Mague, C.-J. Li, Proc. Natl. Acad. Sci. USA 2004, 101,
5749–5754; d) M. Benaglia, D. Negri, G. Dell’Anna, Tetrahe-
dron Lett. 2004, 45, 8705–8708; e) N. Gommermann, P. Kno-
chel, Chem. Commun. 2004, 2324; f) T. Knöpfel, P. P. Asch-
wanden, T. Ichikawa, E. M. Carreira, Angew. Chem. 2004, 116,
6097–6099; Angew. Chem. Int. Ed. 2004, 43, 5971–5973; g) S.
Orlandi, F. Colombo, M. Benaglia, Synthesis 2005, 1689–1692;
h) N. Gommermann, P. Knochel, Synlett 2005, 2799–2801; i)
J.-X. Ji, J. Wu, A. S. C. Chan, Proc. Natl. Acad. Sci. USA 2005,
102, 11196–11200; j) N. Gommermann, P. Knochel, Chem. Eur.
J. 2006, 12, 4380–4392; k) A. M. Taylor, S. L. Schreiber, Org.
Lett. 2006, 8, 143–146; l) A. Bisai, V. K. Singh, Org. Lett. 2006,
8, 2405–2408; m) M. Benaglia, S. Orlandi, F. Usuelli, G. Celen-
tano, J. Org. Chem. 2006, 71, 2064–2070; n) P. Aschwanden,
C. R. J. Stephenson, E. M. Carreira, Org. Lett. 2006, 8, 2437–
2440; o) J. Liu, B. Liu, X. Jia, X. Li, A. S. C. Chan, Tetrahe-
dron: Asymmetry 2007, 18, 396–399.
85.6, 47.2 ppm. IR (neat): ν = 3160, 1489, 1437, 1186, 1125, 1060,
˜
695, 544 cm–1. HRMS for C27H22NOP [M + H+]: calculated
408.1512; found 408.1524.
(1,3-Diphenylprop-2-ynyl)amine: N-(1,3-Diphenylprop-2-ynyl)-P,P-
diphenylphosphinic amide (40.7 mg, 99% ee, 0.1 mmol) was added
to a 50 mL round-bottomed flask. A mixture of MeOH (10 mL)
and concentrated aqueous HCl (1 mL) was added. The resulting
mixture was capped and stirred at room temperature for 2 h. The
reaction mixture was then concentrated by rotary evaporation, the
residue was dissolved in aqueous HCl (1 , 5 mL), and the precipi-
tate was removed by filtration. The filtrate was basified (pH Ͼ 12)
by the addition of NaOH (2 ), and the resulting mixture was ex-
tracted with CH2Cl2 (4ϫ20 mL). The combined organic layers
were dried with Na2SO4. After filtration and evaporation of the
solvents, the crude residue was purified by flash chromatography
(silica gel, hexane/ethyl acetate), giving the product as a colorless
oil, 94.2% yield, 99% ee, as determined by HPLC analysis (Daicel
Chiralcel AD column, hexane/2-propanol, 85:15, 1.0 mL/min,
254 nm). Retention times: tmajor = 8.30 and tminor = 9.08 min.
[α]2D0 = –27 (c = 0.6, CHCl3). 1H NMR (300 MHz, CDCl3): δ =
7.10 (d, J = 7.2 Hz, 2 H), 7.48–7.45 (m, 2 H), 7.39 (t, J = 7.2 Hz,
2 H), 7.33–7.30 (m, 4 H), 5.03 (s, 1 H), 2.31 (t, J = 7.5 Hz, 1 H)
ppm. 13C NMR (75 MHz, CDCl3): δ = 142.2, 131.6, 128.7, 128.3,
128.2, 127.9, 127.7, 126.8, 123.0, 91.3, 84.2, 48.1 ppm. IR (neat): ν
˜
[4] B. Liu, J. Liu, X. Jia, L. Huang, X. Li, A. S. C. Chan, Tetrahe-
dron: Asymmetry 2007, 18, 1124–1128.
[5] B. Liu, L. Huang, J. Liu, Y. Zhong, X. Li, A. S. C. Chan, Tetra-
hedron: Asymmetry 2007, 18, 2901–2904.
= 3384, 2924, 2855, 2517, 1737, 1654, 1456, 1441, 1381, 1071, 1025,
727, 696, 527 cm–1. HRMS for C15H13N [M + H+]: calculated
208.1121; found 208.1129.
