Synthesis and properties of a new water-soluble prodrug of the adenosine A2A receptor antagonist MSX-2

Article abstract of DOI:10.3390/molecules13020348

The compound L-valine-3-{8-[(E)-2-[3-methoxyphenyl)ethenyl]-7-methyl-1- propargylxanthine-3-yl}propyl ester hydrochloride (MSX-4) was synthesized as an amino acid ester prodrug of the adenosine A_2A receptor antagonist MSX-2. It was found to be

Full text of DOI:10.3390/molecules13020348

Molecules 2008, 13, 348-359
molecules
ISSN 1420-3049
© 2008 by MDPI
www.mdpi.org/molecules
Full Paper
Synthesis and Properties of a New Water-Soluble Prodrug of the
Adenosine A2A Receptor Antagonist MSX-2
Karl Vollmann, Ramatullah Qurishi, Jörg Hockemeyer and Christa E. Müller*
Pharma-Center Bonn, Pharmaceutical Institute, Pharmaceutical Chemistry I, An der Immenburg 4, D-
53121 Bonn, Germany; http://www.pharmazentrum.uni-bonn.de/ and
http://www.pharma.uni-bonn.de/pharmchem/
* Author to whom correspondence should be addressed; E-mail: christa.mueller@uni-bonn.de
Received: 29 January 2008; in revised form: 11 February 2008 / Accepted: 11 February 2008 /
Published: 12 February 2008
Abstract: The compound L-valine-3-{8-[(E)-2-[3-methoxyphenyl)ethenyl]-7-methyl-1-
propargylxanthine-3-yl}propyl ester hydrochloride (MSX-4) was synthesized as an amino
acid ester prodrug of the adenosine A2A receptor antagonist MSX-2. It was found to be
stable in artificial gastric acid, but readily cleaved by pig liver esterase.
Keywords: Prodrug; adenosine receptor antagonist; MSX-4; water-solubility; Parkinson’s
disease; esterase.
Introduction
Adenosine A2A receptor antagonists, such as istradefylline (1) and privadenant (2) are currently in
clinical trials as novel therapeutics for the treatment of Parkinson’s disease [1]. Such compounds have
also been proposed to possess activity as cognition enhancers, neuroprotectives, antidepressant agents,
and against neuropathic pain [1, 2, 3]. Different chemical classes of A2A antagonists have been
developed, including xanthine derivatives derived from the alkaloid caffeine, and adenine derivatives
and analogs [1, 5, 6]. MSX-2 (3, 3-(3-hydroxypropyl)-8-(m-methoxystyryl)-7-methyl-1-propargyl-
xanthine (3) is one of the most potent and selective adenosine A2A receptor antagonists [7, 8]. It is
used in tritiated form ([N7-methyl-3H]MSX-2) as a radioligand for the labelling of A2A receptors [9].

Molecules 2008, 13
349
However, a major problem of the high-affinity A2A antagonist is its low water-solubility, which limits
its usefulness in in vivo studies and for therapeutic application.
Figure 1. Structures of selected adenosine A2A receptor antagonists.
O
N
NH2
CH3
N
N
N
N
N
N
N
H3C
CH3
O
O
O
N
N
N
O
N
CH3
O
CH3
O
CH3
1 Istradefylline (KW6002)
2 Privadenant (SCH420814)
O
O
CH3
CH3
N
N
N
N
N
in vivo: enzymatic cleavage
N
N
O
O
N
O
P
O
CH3
O CH3
ONa
OH
O
ONa
3 MSX-2
4 MSX-3
An approach to increase water-solubility is the preparation of prodrugs, in which a polar moiety is
attached to the drug, but can be cleaved off in vivo by an enzymatic reaction to release the active drug
[10, 11]. Thus, we had developed a phosphate prodrug of MSX-2, named MSX-3 (4) [7, 8]. It was
found that MSX-3 is stable in aqueous solution at pH 7, but readily cleaved by phosphatases present in
biological membranes and fluids to liberate the drug MSX-2 [7]. The phosphate prodrug MSX-3 has
proven to be a very useful pharmacological tool allowing parenteral application in aqueous solutions
due to its high water-solubility [e.g. 12-15]. However, peroral application of phosphate prodrugs is less
favourable because it is highly unlikely that the intact – highly polar – prodrug can be absorbed.
Phosphoric acid esters usually undergo enzymatic hydrolysis prior to absorption and therefore
phosphate prodrugs are typically used for intravenous administration. There is a recent example,
however, showing that phosphate prodrugs can also increase the peroral bioavailability of slightly
soluble drugs: fosamprenavir, the phosphate prodrug of the HIV protease inhibitor amprenavir, is
readily dissolved in the intestine due to its high water-solubility, in contrast to its hardly soluble parent
drug, and the phosphate is cleaved by phosphatases in the intestinal cell membranes allowing the drug
to be absorbed [16]. Another approach to increase water-solubility would be to introduce polar
moieties into the molecule, however this has been shown to cause a decrease in potency as adenosine
receptor antagonists and/or central nervous system (CNS) bioavailability of styrylxanthine derivatives
[17].
As an alternative to the phosphate prodrug approach, we considered introducing a different
prodrug moiety into MSX-2 (3) which would increase water-solubility, enhance peroral absorption,
and release the drug not in the intestine already, but preferably after absorption. An amino acid ester
prodrug approach was selected. Amino acid ester prodrugs of drugs which bear an alcoholic function

Molecules 2008, 13
350
have been reported to show enhanced bioavailability (i) because of increased water-solubility, and (ii)
due to absorption by active amino acid carrier mechanisms [18, 19, 20]. Valaciclovir is an example of
such an amino acid ester prodrug with improved bioavailability. It has been reported that the L-valine
ester of acyclovir provided the best bioavailability among a series of several different amino acid
esters [21]. Since acyclovir and MSX-2 are structurally related molecules, both being N-substituted
purine derivatives, we synthesized the L-valine ester of MSX-2, L-valine-3-{8-[(E)-2-[3-
methoxyphenyl)-ethenyl]-7-methyl-1-propargylxanthine-3-yl}propyl ester hydrochloride (MSX-4, 9)
and investigated its properties.
Results and Discussion
The synthesis of the target compound MSX-4 (9) was carried out as depicted in Scheme 1. The N-
Boc-protected valine (compound 5) was converted to the corresponding anhydride 6 by the addition of
dicyclohexylcarbodiimide (DCC) as a condensing agent.
Scheme 1. Synthesis of valine ester prodrug MSX-4 (9).
O
O
O
DCC
H
N
H
N
H
N
O
O
O
t-Bu
t-Bu
OH
O
t-Bu
O
O
O
Me
Me
Me
Me Me
Me
5
6
O
Me
OMe
N
O
N
Me
N
6
OMe
N
N
N
O
N
DMAP, DMF
88 %
N
O
O
H
N
O
OH
t-Bu
O
3 MSX-2
O
Me
Me
CF3CO2H
87 %
7
O
N
O
Me
Me
7
N
1
N
OMe
OMe
N
N
N
HCl
3
N
O
O
N
EtOH
92 %
O
O
NH+
NH2
Me
3 Cl
O
O
8
Me
Me
Me
9 MSX-4

Molecules 2008, 13
351
Compound 6 was not isolated, but rather reacted immediately with MSX-2 (3) [7, 8] in
dimethylformamide (DMF) in the presence of dimethylaminopyridine (DMAP) as a coupling reagent
to yield the N-Boc-protected ester 7 in high yield. Deprotection was achieved by treatment with
trifluoroacetic acid in dichloromethane at low temperature (0°C) yielding 8. Finally, the ester 8 was
converted to its hydrochloride salt 9 by reaction with a saturated solution of gaseous hydrogen chloride
in ethanol.
8-Styrylxanthine derivatives have previously been found to undergo light-induced E/Z-
isomerization in dilute solutions [17, 22]. Furthermore, in the solid state, photodimerization upon
exposure to light has been observed [8]. In fact, we found that the intermediate compound 7 also
undergoes dimerization when stored unprotected from light in the laboratory yielding cyclobutane
derivative 10. With regard to previous findings [8], a head-to-tail syn-configuration for the isolated
compound can be expected. Therefore, styrylxanthine derivatives have to be strictly protected from
light, in the solid state, as well as in solution.
Scheme 2. Photodimerization of styrylxanthine derivative 7.
OMe
O
Me
O
N
O
N
Me
Me
OMe
N
N
daylight, 2 d
solid state
N
N
N
N
2
N
O
N
N
N
O
O
O
OR
7
MeO
R
R
O
10
H
O
N
R = t-Bu
O
O
Me
Me
The water-solubility of product 7 (MSX-4) was determined by UV spectroscopy and found to be
7.3 mg/mL (13.8 mM), which is extraordinarily high compared to most if not all high affinity
adenosine receptor A2A antagonists [17]. It was in the same range as the solubility of the disodium salt
of the phosphate prodrug MSX-3 (4), which was determined to be 9 mg/mL (17 mM) [7].
The chemical and enzymatic stability of 9 was investigated by capillary electrophoresis with UV
detection. The amino acid ester prodrug was absolutely stable in aqueous solution at 25°C for at least 4
days (data not shown). It was subsequently incubated (i) with simulated gastric acid, and (ii) in the
presence of pig liver carboxyl esterase. Figure 3A shows the time course for the degradation of
prodrug 9 in simulated gastric acid (aqueous HCl solution pH 2 containing pepsin). The incubation
was performed for 4 hours since drugs usually do not stay in the stomach any longer. Prodrug 9 was
found to be relatively stable under these conditions: after 4 hours of incubation, 82% of the intact ester
9 could still be detected. The antiviral prodrug valaciclovir had also recently been shown to be stable
at acidic pH values below 4, but to be slowly cleaved under basic conditions [23].

Molecules 2008, 13
Figure 3. Stability of prodrug 9 (A) in artificial gastric acid (aq. HCl, pH 2, pepsin), (B)
352
in borate buffer pH 8 in the presence and in the absence of pig liver esterase, and (C) in
borate buffer pH 7 in the presence and in the absence of pig liver esterase. Data points
represent results from 3 independent experiments ± SEM. In some cases the SEM value
was smaller than the symbol.
A
100
50
0
0
60
120
180
240
time [min]
B
borate buffer (100 mM) pH 8.0
borate buffer pH 8.0, pig liver esterase (50 u)
100
50
0
0
60
120
180
240
time [min]
C
Borate buffer (100 mM), pH 7.0
Borate buffer, pH 7.0, pig liver esterase (100 u)
100
50
0
0
60
120
180
time [min]
Figure 3 shows the plots of the hydrolysis of 9 at 37°C by esterase (50 u) at pH 8 (Figure 3B), and
by twice the amount of esterase (100 u) at pH 7 (Figure 3C). The prodrug was readily hydrolyzed in

Molecules 2008, 13
353
the presence of esterase with a half-life of 6.9 min (100 u, pH 7) and 1.9 min (50 u, pH 8),
respectively. As expected, the hydrolysis was faster at the basic pH value of 8, which corresponds to
the pH optimum of the enzyme [24] than at pH 7. At pH 7, the prodrug appeared to be quite stable
(half life: 101 min), while it seemed to be somewhat less stable at the more alkaline pH of 8 (half-life:
43 min). However, the disappearance of the prodrug in the absence of esterase may also be at least
partly due to deprotonation at neutral to basic pH values and subsequent precipitation of the resulting
uncharged molecule 8. Overall we could show that the amino acid ester 9 is an excellent substrate for
pig liver esterase and should therefore also be cleaved in vivo by non-specific esterases releasing the
potent drug MSX-2 (3). In addition to dramatically increasing the water-solubility of MSX-2, the
gastrointestinal absorption of the L-valine ester prodrug 9 may be further increased by active transport
via amino acid transporters as previously demonstrated for other L-amino acid prodrugs, especially L-
valine esters of drugs with a purine scaffold bearing alcoholic functions. Furthermore, CNS
bioavailability may also be increased.
Conclusions
In conclusion, we have designed and synthesized L-valine-3-{8-[(E)-2-[3-methoxyphenyl)ethenyl]-
7-methyl-1-propargylxanthine-3-yl}propyl ester hydrochloride (MSX-4, 9) as a novel prodrug of the
potent and selective, but slightly water-soluble adenosine A2A receptor antagonist MSX-2 (3). Our data
indicate that compound 9 meets the requirements for an oral prodrug, it shows excellent water-
solubility, high stability towards gastrointestinal hydrolysis, and undergoes fast enzymatic hydrolysis
by esterases.
Experimental
General
Melting points were determined on a Büchi B-535 apparatus and are uncorrected. TLC was
performed on silica gel-coated aluminum sheets Merck 60 F254, and spots were detected by UV light
(254 nm). Column chromatography was performed on silica gel 63-200 µm (Merck). Elemental
analyses were performed on a VarioEL instrument (Elementar Analysensysteme GmbH). (HR)MS
spectra were performed on an MS-50 (Kratos) or a MAT95 (Thermo Quest) instrument. NMR spectra
(1H: 500 MHz, 13C: 126 MHz) were determined on a Bruker 500 spectrometer. The signals of the
1
remaining protons of the deuterated solvents served as internal standard: H: δ DMSO-d6 = 2.49,
13
CDCl3 = 7.24, MeOH-d6 = 3.35, 4.78; C: DMSO-d6 = 39.7, CDCl3 = 77.0, MeOH-d6 = 49.3. CE
measurements were performed on a P/ACE capillary electrophoresis MDQ instrument (Beckman
Coulter, Fullerton, CA, USA) equipped with a DAD detector. For incubations an Eppendorf
Thermomixer Comfort was used. Optical rotation was measured on a Perkin-Elmer 241 polarimeter
(Perkin-Elmer GmbH, Düsseldorf, Germany). DMF was dried over P2O5, CH2Cl2 was dried over
CaCl2. Ninhydrin solution was prepared as follows: 1 g ninhydrin, 2.5 g cadmium acetate and 10 mL
acetic acid were dissolved in ethanol (final volume: 500 mL). The TLC sheets were sprayed with the

Molecules 2008, 13
354
ninhydrin solution and subsequently heated at 120° for 20 min. All other chemicals were used without
further purification. MSX-2 (3) was prepared as previously described [7, 8].
[N-tert-Butoxycarbonyl-L-valine]-3-{8-[(E)-2-(3-methoxyphenyl)ethenyl)]-7-methyl-1-propargyl-
xanthin-3-yl}propyl ester (7)
N-Boc-L-valine (1.07 g, 4.94 mmol) was dissolved in CH2Cl2 (20 mL) and dicyclohexyl-
carbodiimide (DCC, 602 mg, 2.92 mmol, 0.59 eq) was added. The solution was stirred at rt for 4 h.
Then it was filtered under an atmosphere of argon, and the filtrate was evaporated under vacuum. The
colorless, oily residue was taken up in DMF (20 mL), and 3 (650 mg, 1.65 mmol) and
dimethylaminopyridine (DMAP, 20.1 mg, 0.165 mmol), were added. The mixture was stirred at rt in
the dark for ca. 24 h until TLC monitoring indicated complete conversion. The solution was
evaporated and the resulting yellow oil was subjected to column chromatography (glass column 45
mm diameter, 46 cm height, 300 g of silica gel, elution with ethyl acetate-CH2Cl2-NH3 conc
120:80:0.1). Yield: 88 % (863 mg, 1.45 mmol). Rf -value: 0.64 (ethyl acetate-CH2Cl2-NH3 conc
=
=
120:80:0.1), orange-red color after spraying with ninhydrin solution (see above); Rf value (MSX-2):
0.34; 1H-NMR: δ (CDCl3) = 0.86 (d, J = 6.9 Hz, 3H, CHCH3), 0.93 (d, J = 6.9 Hz, 3H, CHCH3), 1.40
(s, 9H, OC(CH3)3), 2.15 (d br, 1H, Me2CH), 2.16 (t, J = 2.4 Hz, 1H, C≡CH), 2.19 (quint, J = 6.8 Hz,
2H, NCH2CH2CH2O), 3.83 (s, 3H, OCH3), 4.03 (s, 3H, NCH3), 4.17 (m br, 1H, NHCH), 4.25 (m, 4H,
NCH2, OCH2), 4.76 (d, J = 2.4 Hz, 2H, C≡CCH2), 5.04 (d, J = 8.9 Hz, 1H, NH), 6.86 (d, J = 15.8 Hz,
1H, C=CH), 6.89 (dd, J = 8.1 Hz, 2.3 Hz, 1H, Harom), 7.07 (s, 1H, Harom), 7.17 (d, J = 7.8 Hz, 1H,
Harom), 7.30 (dd, J = 8.1 Hz, 7.8 Hz, 1H, Harom), 7.73 (d, J = 15.8 Hz, 1H, C=CH); 13C-NMR: δ
(CDCl3) = 17.6 (CH-CH3), 19.1 (CH-CH3), 27.2 (CH-CH3), 28.3 (C(CH3)3), 30.4 (CH2C≡C), 31.2
(NCH2CH2CH2O), 31.6 (NCH3), 40.6 (NCH2), 55.2 (OC(CH3)3), 55.3 (OCH3), 58.5 (NH-CH), 62.8
(OCH2), 70.4 (C≡CH), 78.7 (HC≡C), 107.8 (C5), 111.4 (C=CH), 112.7, 115.2, 120.0, 129.9, 136.6
(C8), 136.8, 138.7 (C=CH), 148.5 (C4), 150.3 (C2), 154.0, 155.7 [OC(O)N], 160.0 (C6), 172.3 (COO);
IR (in CH2Cl2): ν (cm-1) = 3440 (N-H), 3300 (≡C-H), 3040 (=C-H), 2950 (C-H), 2920 (C-H), 2860 (C-
H), 2450, 1700 (O-CO-NHR, C=O), 1660 (RN-CO-NR), 1590 (CO-NR), 1490 (C=C), 1360, 1160 (C-
O), 1090, 1010, 860; [α]D = + 0.22 ° (c = 201.7 mg/mL in CHCl3, 21.5°C); EIMS: 593.3 (M+, 100 %),
519.2 (M+-H-Boc, 26 %), 395.2 (MSX-2); HRMS: calcd., 593.2850; found, 593.2837 (C31H39N5O7);
mp 46 - 49 °C.
L-Valine-3-{8-[(E)-2-(3-methoxyphenyl)ethenyl]-7-methyl-1-propargylxanthin-3-yl}propyl ester (8)
Compound 7 (863 mg, 1.45 mmol) was dissolved at 0°C in freshly distilled CF3CO2H (15 mL) and
stirred for 50 min in an ice-bath. The trifluoroacetic acid was then distilled off at 0°C in vacuo and the
residue was purified by column chromatography (glass column 45 mm diameter, 46 cm height, 300 g
of silica gel, ethyl acetate : CH2Cl2-NH3 conc = 200:300:1). Yield: 87 % (623 mg, 1.26 mmol); Rf
value: 0.67 (CH2Cl2-MeOH =10:2); 0.83 (starting compound); 1H-NMR: δ (CDCl3) = 1.08 (d, J = 7.0
Hz, 3H, CHCH3), 1.09 (d, J = 7.0 Hz, 3H, CHCH3), 2.19 (t, J = 2.4 Hz, C≡CH), 2.27 (quint, J = 6.4
Hz, 2H, NCH2CH2CH2O), 2.38 [m, 1H, (CH3)2CH], 3.99 (d, J = 4.8 Hz, 1H, H2NCH), 3.84 (s, 3H,
OCH3), 4.07 (s, 3H, NCH3), 4.28 (m, 4H, OCH2, NCH2), 4.73 (d, J = 2.2 Hz, 1H, C≡CCH2), 4.74 (d, J

Molecules 2008, 13
355
= 2.2 Hz, 1H, C≡CCH2), 6.88 (d, J = Hz, 1H, C=CH), 6.93 (dd, J = 8.3 Hz, 2.5 Hz, 1H, Harom), 7.06 (s,
1H, Harom), 7.15 (d, J = 8.0 Hz, 1H, Harom), 7.32 (dd, J = 8.3 Hz, 8.0 Hz, 1H, Harom), 7.73 (d, J = 16.0
Hz, 1H, C=CH); 13C-NMR: δ (CDCl3) = 17.3 (CH-CH3), 17.7 (CH-CH3), 29.6 (CH-CH3), 30.6
(CH2C≡C), 31.7 (NCH2CH2CH2O), 32.3 (NCH3), 40.3 (NCH2), 55.3 (OCH3), 59.0 (NH-CH), 63.7
(OCH2), 70.9 (C≡CH), 78.3 (HC≡C), 106.7 (C5), 110.7, 112.7, 115.5, 120.0, 130.0, 136.4 (C8), 139.3,
139.7, 147.7 (C4), 150.6 (C2), 153.7, 160.0 (C6), 171.5 (COO) (the unassigned signals belong to the
eight vinyl and aromatic carbon atoms); Anal. calcd. for C26H31N5O5: C, 63.3; H, 6.33; N, 14, 2;
found: C, 63.4; H, 6.60; N, 14.1; EIMS: 493.3 (M+, 59 %), 450.2 (M+-C3H7, 34 %), 395.2 (MSX-2, 43
%), 378.2 (M+-C5H8NO-OH, 100 %), 174.2 ([C11H12NO]+, 63 %), 72.2 ([C4H10N]+, 88 %); HRMS:
calcd., 493.2325; found, 493.2329; mp 141 °C.
L-Valine-3-{8-[(E)-2-(3-ethoxyphenyl)ethenyl]-7-methyl-1-propargylxanthin-3-yl}propyl ester hydro-
chloride (9)
Compound 8 (61 mg, 0.123 mmol) was dissolved at 0°C in 3 mL absolute ethanol and 10 mL of a
cold saturated solution of HCl gas in ethanol, cooled to 0°C, was added. After 5 min the solvent was
partly removed by rotary evaporation, and the precipitated product was filtered off. It is washed twice
with 5 mL of CH2Cl2 each. The mother liquor was reduced by rotary evaporation, and the formed
precipitate was washed again as described above. Both fractions contained the pure product.Yield: 92
% (60 mg, 0.113 mmol); Rf value: 0.21 (CH2Cl2-MeOH-AcOH = 10:1:0.1); 1H-NMR: δ (methanol-d6)
= 1.12 (d, J = 6.9 Hz, 3H, CHCH3), 1.13 (d, J = 6.9 Hz, 3H, CHCH3), 2.28 (quin, J = 6.5 Hz, 2H,
NCH2CH2CH2O), 2.35 [m, 1H, (CH3)2CH], 2.62 (t, J = 2.1 Hz, C≡CH), 3.89 (s, 3H, OCH3), 3.99 (d, J
= 4.4 Hz, 1H, H3N+CH), 4.11 (s, 3H, NCH3), 4.32 (t, J = 6.8 Hz, 2H, OCH2), 4.43 (t, J = 6.2 Hz, 2H,
NCH2), 4.76 (d, J = 2.1 Hz, 2H, C≡CCH2), 6.98 (dd, J = 8.2 Hz, 2.2 Hz, 1H, Harom), 7.25 (m, 3H,
+
C=CH, 2 Harom), 7.35 (dd, J = 7.9 Hz, 7.8 Hz, 1H, ), 7.78 (d, J = 15.8 Hz, C=CH); (NH3 protons are
13
exchanged in methanol-d6); C-NMR: δ (methanol-d6) = 18.6 (CH-CH3), 18.8 (CH-CH3), 28.7 (CH-
CH3), 31.2 (CH2C≡C)*, 31.6 (NCH2CH2CH2O), 32.5 (NCH3), 42.0 (NCH2), 56.2 (OCH3), 59.8 (NH-
CH), 65.5 (OCH2), 72.1 (C≡CH), 80.1 (HC≡C), 109.4 (C5), 113.1, 114.0, 116.6, 121.6, 131.3, 138.5
(C8), 140.3, 149.6 (C4), 152.3, 152.4, 155.4 (C2), 161.9 (C6), 170.2 (COO); [α]D = -10.0 ° (c = 3.2
mg/mL, H2O, 21.0 °C); Anal. calcd. for C26H32ClN5O5·2.8 CH2Cl2: C, 49.4; H, 5.55; N, 11.1; found, C,
49.5; H, 5.74; N, 11.1; EIMS: 493.3 (M+, 23 %), 450.2 (M+ -C3H7, 13 %), 395.2 (M+-C5H8NO (MSX-
2), 24 %), 378.2 (M+-C5H8NO -OH, 47 %), 174.1 ([C11H12NO]+, 42 %),72.1 ([C4H10N]+, 100 %);
HRMS: calcd, 529.2092; found, 493.2315; mp 149 - 152 °C.
(1α, 2α, 3β, 4β)-1,3-Bis{3-[(N-tert-butoxycarbonyl-L-valine)-7-methyl-1-propargylxanthin-8-yl]propyl
ester}-2,4-bis(3-methoxyphenyl)cyclobutane (10)
A sample solid 7 (90 mg, 0.152 mmol) was left in the laboratory near the window in the sunlight
for 2 days and subsequently subjected to column chromatography (glass column, 25 mm diameter, 37
cm height, 70 g of silica gel; CH2Cl2-ethyl acetate = 20:1); Yield: 80 mg (0.0674 mmol). In addition
starting compound 7 was recovered (8.0 mg, 0.0135 mmol). Rf value: 0.42 (CH2Cl2-MeOH = 10:1);
0.27 (compound 7); 1H-NMR: δ (CDCl3) = 0.87 (d, J = 7.0 Hz, 3H, CHCH3), 0.89 (d, J = 7.0 Hz, 3H,

Molecules 2008, 13
356
CHCH3), 0.96 (d, J = 6.7 Hz, 6 H, 2 CHCH3), 1.37 (s, 9H, OC(CH3)3), 1.42 (s, 9H, OC(CH3)3), 2.13
(m, 8 H, 2 Me2CH, 2 C≡CH, 2 NCH2CH2CH2O), 3.65 (s br, 3H, OCH3 or NCH3), 3.67 (s, 6H, NCH3
or OCH3), 3.68 (s, 3H, OCH3 or NCH3), 4.21 (m, 9H, 2 NCH2, 2 OCH2, CH), 4.28 (m, 1H, CH), 4.43
(dd, J = 10.1 Hz, 7.3 Hz, 1H, NHCH), 4.47 (m br, 1H, NHCH), 4.69 (d, J = 2.2 Hz, C≡CCH2), 4.98
(dd, J = 9.8 Hz, 7.3 Hz, 2H, 2 CH), 5.04 (d, J = 9.1 Hz, 2H, NH2), 6.67 (ddd, J = 7.6 Hz, 5.4 Hz, 1.9
13
Hz, 2H, Harom), 6.75 (m, 2H, Harom), 6.77 (d J = 7.6 Hz, 2H, Harom), 7.09 (m, 2H, Harom); C-NMR: δ
(CDCl3) = 17.6 (CH-CH3), 19.05 (CH-CH3), 19.08 (CH-CH3), 27.3 (CH3-CH), 27.4 (CH3-CH), 28.26
(C(CH3)3), 28.3 (C(CH3)3), 30.4 (C≡CCH2), 31.2 (NCH2CH2CH2O), 31.3 (NCH2CH2CH2O), 31.7
(NCH3), 40.4 (NCH2), 40.5 (NCH2), 44.3 (CH), 44.4 (CH), 55.10 (OC(CH3)3), 55.13 (OC(CH3)3),
58.56 (NH-CH), 58.6 (NH-CH), 62.7 (OCH2), 62.9 (OCH2), 70.3 (C≡CH), 78.7 (HC≡C), 107.7 (C5),
107.8 (C5), 112.0/112.1, 114.1/114.3, 119.8, 129.6, 139.8/139.9 (2 C8), 147.4/147.5(2 C4), 150.4 (2
C2), 152.6/152.7, 153.9/154.0, 155.6/155.7 (2 OC(O)N), 159.6/159.7 (2 C6), 172.3/172.4 (2 CO2);
EIMS (C62H78N10O14, MR = 1187.36 g/mol): 788.5 (M+- 2 C10H16NO3, 5 %), 394.2 (MSX-2, 100 %)
(the amino acid esters were cleaved off).
Determination of the water solubility of 9 by UV spectroscopy
A saturated solution of 9 was prepared by suspending the compound (15.1 mg, 28.5 μmol) in H2O
(1 mL). The suspension was subsequently centrifuged twice at 4000 rpm for 30 min each. The clear
supernatant was appropriately diluted in water analyzed by UV spectroscopy. A standard curve was
determined using known concentrations of 9: A stock solution was prepared (1 mg/10 mL water
corresponding to 189 µmol/L) and further diluted to obtain six different concentrations ranging from
9.45 µmol/L to 94.5 µmol/L. The concentration of the saturated solution was determined to be 13.8 ±
0.76 μmol/mL or 13.8 mmol/L corresponding to 7.3 ± 0.4 mg/mL.
Stability studies using capillary electrophoresis with UV detection
A fused-silica capillary of 60 cm length, internal diameter 75 µm was used; the temperature was
kept at 25°C. A 50 mM phosphate (KH2PO4) buffer pH 6.1 was used as running buffer, and a constant
current of 90 µA was applied. Samples were injected for 5 s with a pressure of 0.5 p.s.i. Injection was
made from the anodic side of the capillary. Compounds were detected by UV absorption at 254 nm.
Before each measurement the capillary was washed with 0.1 M NaOH, water, and running buffer, for 1
min each. The stability studies were performed in a volume of 500.0 µL at a concentration of 500
µg/mL in borate buffer (100 mM) at pH values of 7.0 and 8.0, respectively. An aqueous solution of
quinidine sulfate (50.0 µg/mL) was used as internal standard. Samples (50.0 µL) were drawn and
diluted with the internal standard solution (1:10, 450 µL). From the resulting solution, 50 µL were
taken and diluted 1:1 with demineralized water. The final concentration of 9 in the CE measurements
was therefore 25.0 µg/mL and for quinidine sulfate 22.5 µg/mL. Samples were taken after 10, 30, 60,
and 90 min, or after 1, 2, 3 and 4 d. Each of the three independent experiments was performed with
exclusion of light.
Enzymatic hydrolysis

Molecules 2008, 13
357
Carboxyl esterase from pig liver (Sigma, E2884, in 2 M (NH4)2SO4 solution pH 8.0) was used for
the experiments. The enzyme suspension was thoroughly shaken prior to use. An amount of 0.27 µL of
enzyme suspension corresponded to 1 unit (defined as the amount of enzyme which hydrolyzes 1.0
µmol of butyric acid ethyl ester at pH 8.0, 25°C within 1 min). Samples for studying enzymatic
hydrolysis were prepared as described above for stability studies. The sample (50 µL) for the time zero
was taken before the addition of the enzyme. To the remaining 450 µL of solution 100 u (27.0 µL
undiluted), or 50 u (27.0 µL, diluted 1:1 with buffer) of enzyme solution was added, and the mixture
was incubated at 37 °C. After addition of the enzyme solution, the resulting substrate concentration
was 472 µg/mL, and the reaction volume was 477 µL. After 5, 10, 20, 30, 60, 90 and 120 min samples
(50 µl) were taken and diluted 1:10 with 450 µL of a solution of the internal standard and heated at
99°C for 10 min in order to inactivate the enzyme. Heating at 99°C for 10 min did not lead to
hydrolysis of 9. After cooling to room temperature, 50.0 µL of the solutions were further diluted with
50.0 µL of demineralized water and subjected to analysis by capillary electrophoresis. The final
concentration of quinidine sulfate was 22.5 µg/mL and of 9 23.6 µg/mL (at time zero). In all cases,
three independent experiments were performed, with exclusion of light.
Acknowledgements
C.E.M. is grateful for support by the Fonds der Chemischen Industrie.
References and Notes
1. Müller, C.E.; Ferre, S. Blocking striatal adenosine A2A receptors : a new strategy for basal ganglia
disorders. Recent Pat.s CNS Drug Discov. 2007, 2, 1-21.
2. Müller, C.E. A2A Adenosine receptor antagonists – future drugs for Parkinson's disease? Drugs
Fut. 2000, 25, 1043-1052.
3. Yu, L.; Shen, H.-Y.; Coelho, J.E.; Araújo, I.M.; Huang, Q.-Y.; Day, Y.-J.; Rebola, N.; Canas,
P.M.; Rapp, E.K.; Ferrara, J.; Taylor, D.; Müller, C.E.; Linden, J.; Cunha, R.A.; Chen, J.-F. A2A
Receptors modulate motor activity and 1-methyl-4-phenyl-1,2,3,6-tetrahydropyridine
neurotoxicity by distinct cellular mechanisms. Ann. Neurol. 2008, 63, in press.
4. Takahashi, R.N.; Pamplona, F.A.; Prediger, R.D. Adenosine receptor antagonists for cognitive
dysfunction: a review of animal studies. Front. Biosci. 2008, 13, 2614-2632.
5. Yuzlenko, O.; Kieć-Kononowicz, K. Potent adenosine A1 and A2A receptor antagonists: recent
developments. Curr. Med. Chem. 2006, 13, 3609-3625.
6. Moro, S.; Gao, Z.G.; Jacobson, K.A.; Spalluto, G. Progress in the pursuit of therapeutic adenosine
receptor antagonists. Med. Res. Rev. 2006, 26, 131-159.
7. Sauer, R.; Maurinsh, J.; Reith, U.; Fülle, F.; Klotz, K.-N.; Müller, C.E. Water-soluble phosphate
prodrugs of 1-propargyl-8-styrylxanthine derivatives, A2A-selective adenosine receptor
antagonists. J. Med. Chem. 2000, 43, 440-448.
8. Hockemeyer, J.; Burbiel, J.C.; Müller, C.E. Multigram-scale syntheses, stability, and
photoreactions of A2A adenosine receptor antagonists with 8-styrylxanthine structure - potential
drugs for Parkinson's disease. J. Org. Chem. 2004, 69, 3308-3318.

Molecules 2008, 13
358
9. Müller, C.E.; Maurinsh, J.; Sauer, R. Binding of [3H]MSX-2 (3-(3-hydroxypropyl)-7-methyl-8-
(m-methoxystyryl)-1-propargylxanthine) to rat striatal membranes - a new, selective antagonist
radioligand for A2A adenosine receptors. Eur. J. Pharm. Sci. 2000, 10, 259-265.
10. Testa, B.; Mayer, J.M. Hydrolysis in Drug and Prodrug Metabolism. Wiley-VCH: Weinheim,
2003.
11. Stella, V.J.; Nti-Addae, K.W. Prodrug strategies to overcome poor water solubility. Adv. Drug.
Deliv. Rev. 2007, 59, 677-694.
12. Bilkei-Gorzo, A.; Abo-Salem, O.M.; Hayallah, A.M., Michel, K.; Müller, C.E. Adenosine
receptor subtype-selective antagonists in inflammation and hyperalgesia. N-S Arch. Pharmacol.
2008, in press.
13. Blum, D.; Galas, M.-C., Pintor, A.; Brouillet, E.; Ledent, C.; Müller, C.E.; Bantubungi, K.;
Galluzzo, M.; Gall, D.; Cuvelier, L.; Rolland, A.-S.; Popoli, P.; Schiffmann, S.N. A dual role of
adenosine A2A receptors in the modulation of 3-nitropropionic acid-induced striatal lesions:
implications for the neuroprotective potential of A2A antagonists. J. Neurosci. 2003, 23, 5361-
5369.
14. Quarta, D.; Ferré, S.; Solinas, M.; You, Z.B.; Hockemeyer, J.; Popoli, P.; Goldberg, S.R. Opposite
modulatory roles for adenosine A1 and A2A receptors on glutamate and dopamine release in the
shell of the nucleus accumbens. Effects of chronic caffeine exposure. J. Neurochem. 2004, 88,
1151-1158.
15. Farrar, A.M.; Pereira, M.; Velasco, F.; Hockemeyer, J.; Müller, C.E. Adenosine A2A receptor
antagonism reverses the effects of dopamine receptor antagonism on instrumental output and
effort-related choice in the rat: implications for studies of psychomotor slowing.
Psychopharmacology 2007, 191, 579-586.
16. Wire, M.B.; Shelton, M.J.; Studenberg, S. Fosamprenavir: clinical pharmacokinetics and drug
interactions of the amprenavir prodrug. Clin. Pharmacokinet. 2006, 45, 137-168.
17. Müller, C.E.; Sandoval-Ramírez, J.; Schobert, U.; Geis, U.; Frobenius, W.; Klotz, K.-N. 8-
(Sulfostyryl)xanthines: water-soluble A2A-selective adenosine receptor antagonists. Bioorg. Med.
Chem. 1998, 6, 707-719.
18. Ganapathy, M.E.; Huang, W.; Wang, H.; Ganapathy, V.; Leibach, F.H. Valacyclovir: a substrate
for the intestinal and renal peptide transporters PEPT1 and PEPT2. Biochem. Biophys. Res.
Commun. 1998, 246, 470-475.
19. Sinko, P.J.; Balimnae, P.V. Carrier-mediated intestinal absorption of valacyclovir, the L-valyl
ester prodrug of acyclovir: 1. Interactions with peptides, organic anions and organic cations in rats
Biopharm. Drug Dispos. 1998, 19, 209-217.
20. Landowski, C.P.; Lorenzi, P.L.; Song, X,: Amidon, G.L. Nucleoside ester prodrug substrate
specifity of liver carboxylesterase. J. Pharmacol. Exp. Ther. 2006, 316, 572-580.
21. Beauchamp, L.M.; Ott, G.F.; de Miranda, P.; Burnette, T.; Krenitsky, T.A. Amino acid ester
prodrugs of acyclovir. Antivir. Chem. Chemother. 1992, 23, 157-164.
22. Nonaka, Y.; Shimada, J.; Nonaka, H.; Koike, N.; Aoki, N.; Kobayashi, H.; Kase, H.; Yamaguchi,
K.; Suzuki, F. Photoisomerization of a potent and selective adenosine A2 antagonist, (E)-1,3-
Dipropyl-8-(3,4-dimethoxystyryl)-7-methylxanthine. J. Med. Chem. 1993, 36, 3731-3733.

Molecules 2008, 13
359
23. Granero, G.E.; Amidon, G.L. Stability of valacyclovir: implications for its oral bioavailability. Int.
J. Pharm. 2006, 317, 14-18.
24. Lange, S.; Musidlowska, A.; Schmidt-Dannert, C.; Schmitt, J.; Bornscheuer, U.T. Cloning,
functional expression, and characterization of recombinant pig liver esterase. ChemBioChem
2001, 2, 576-582.
Sample Availability: Samples of the compounds are available from the authors.
© 2008 by MDPI (http://www.mdpi.org). Reproduction is permitted for noncommercial purposes.
