Novel and practical synthesis of candesartan cilexetil

Article abstract of DOI:10.3987/COM-10-11944

A novel and convergent synthetic route of candesartan cilexetil (API of Atacand), an effective angiotensin II receptor blocker, is described. Cleavage of the N-Boc and N-trityl protective group are implemented simultaneously and formation of the benzimidazole ring is conducted at the last step of this route, which gives candesartan cilexetil in 55% yield over six steps with 99.1% purity (HPLC).

Full text of DOI:10.3987/COM-10-11944

HETEROCYCLES, Vol. 81, No. 6, 2010
1503
HETEROCYCLES, Vol. 81, No. 6, 2010, pp. 1503 - 1508. © The Japan Institute of Heterocyclic Chemistry
Received, 13th March, 2010, Accepted, 5th April, 2010, Published online, 7th April, 2010
DOI: 10.3987/COM-10-11944
NOVEL AND PRACTICAL SYNTHESIS OF CANDESARTAN
CILEXETIL
Yongjun Mao,1,§ Ruisheng Xiong,1,§ Zheng Liu,2 Haihong Li,2 Jingkang
Shen,1 and Jingshan Shen1,2*
1
Shanghai Institute of Materia Medica, Chinese Academy of Sciences, 555 Zu
Chong Zhi Road, Pudong, Shanghai 201203, China
2 Topharman Shanghai Co., Ltd., 1088 Chuansha Road, Pudong, Shanghai 201209,
China, email: jsshen@mail.shcnc.ac.cn
§ Both authors contributed equally to this work
Abstract – A novel and convergent synthetic route of candesartan cilexetil (API
of Atacand), an effective angiotensin II receptor blocker, is described. Cleavage of
the N-Boc and N-trityl protective group are implemented simultaneously and
formation of the benzimidazole ring is conducted at the last step of this route,
which gives candesartan cilexetil in 55% yield over six steps with 99.1% purity
(HPLC).
Angiotensin-converting enzyme (ACE) inhibitors or angiotensin II receptor blockers (ARBs) are known
in treating hypertension and heart failure effectively. Candesartan cilexetil (1, Atacand, Figure 1) is a
potent angiotensin II receptor antagonist that exhibits selective and antagonistic activity to the AT1
subtype for treatment of hypertension. It is clinically used as the prodrug form of cyclohexyl
1-hydroxyethyl carbonate ester, which is metabolised completely to the active moiety candesartan (2) by
esterases on the intestinal wall during absorption.1
N
N
N
N
N
N
OEt
OH
OEt
N N
NH
N N
NH
N N
NH
O
O
N
N
N
O
O
O
O
O
O
O
O
HO
O
1
2
3
Figure 1

1504
HETEROCYCLES, Vol. 81, No. 6, 2010
Several synthetic methods were developed for the preparation of 1 and most of these routes were linear.2
In general, candesartan (2) was prepared through 5–8 steps in medium overall yield. Protection of the
tetrazole of 2 with trityl group and alkylation with 1-chloroethyl cyclohexyl carbonate were the usual
methods. The detritylation reaction of the last step was carried out in strong acidic condition, which was
always accompanied with the formation of the 2-hydroxy-benzimidazole 3 (Figure 1) as a major impurity
in the final product. The impurity 3 has similar properties to 1 so that it is difficult to purify the final
product with satisfying recovery yield. Herein we will describe a novel and practical synthetic route of 1
with good yield and purity.3
NO2
N N
CO2t-Bu
NO2
N
N N
N
N
CPh3
b
a
Br
N
N
CO2t-Bu
CPh3
EtO
O
N
H
EtO
O
6
4
5
NO2
NO2
O
O
O
Cl
CO2t-Bu
CO2t-Bu
N
O
N
d
N N
N N
8
N
N
N
N
CPh3
CPh3
HO
O
O
O
O
O
c
9
7
NH2
NH
NO2
NH
e
f
N N
NH
O
O
N N
1
N
N
NH
O
O
O
O
O
O
O
O
11
10
Reagents and conditions: (a) K2CO3, MeCN, 92%; (b) NaOH, THF, H2O, 94%; (c) K2CO3, MeCN; (d) AcCl,
EtOH, 83%; (e) SnCl2 . 2H2O, EtOAc, 95%; (f) C(OEt)4, AcOH, toluene, 81%.
Scheme 1
The new synthetic route of 1 is outlined in Scheme 1. Commercially available benzyl bromide 5 can be
prepared from 4’-methyl-(1,1’-diphenyl)-2-carbonitrile through three steps according to the established
method.4 Commercially available aniline 4 is N-alkylated by treating with 5 in K2CO3-MeCN system to
give the intermediate 6 in 92% isolated yield. Hydrolysis of the ethyl ester group in 6 is carried out with
NaOH in THF-H2O solution to afford the corresponding acid 7 in high yield.5 By the similar conditions

HETEROCYCLES, Vol. 81, No. 6, 2010
1505
applied for preparing 6, the acid 7 is converted into the ester 9 by treating with 1-chloroethyl cyclohexyl
carbonate (8) in satisfying yield. Further, cleavage of the N-Boc and the N-trityl group of 9 are carried out
concurrently in HCl-EtOH solution at room temperature to give the nitrobenzote 10 without hydrolysis of
the cilexetil ester chain. The nitro group in 10 is reduced with stannous chloride to the corresponding
amino intermediate 11. Ring closure of 11 is performed with tetraethyl orthocarbonate and acetic acid to
afford the final product 1. In 2008, we reported a facile one-pot reductive cyclization of benzimidazole
from 2-nitroanilines.6 Here, however, product 1 can not be prepared from 2-nitroaniline 10 in satisfying
results using the similar one-pot process.
In summary, we have developed a novel, convergent and practical synthetic route of candesartan cilexetil.
The overall yield of 1 obtained in this route is around 55% (from 5, six steps) with 99.1% purity (HPLC)
which makes it a potential convenient preparative method of 1.
EXPERIMENTAL
All commercially available materials and solvents were used as received products without further
purification. 1H NMR spectra were recorded on a Varian Gemini 300 spectrometer and 13C NMR spectra
were obtained from a Bruker AMX 400/600 at 400 MHz using TMS as an internal standard. Infrared
spectra were recorded using a Thermo-Nicolet MAGNA-IR 750. The mass spectra were obtained from a
Finnigan MAT-95/711 spectrometer.
Ethyl
2-[(N-t-butoxycarbonyl)-[[2'-[1-(triphenylmethyl)-1H-tetrazol-5-yl]biphenyl-4-yl]methyl]-
amino]-3-nitrobenzote (6). Ethyl 2-[(N-t-butoxycarbonyl)amino]-3-nitrobenzote (4) (31 g, 0.1 mol),
5-[4'-(bromomethyl)biphenyl-2-yl]-1-(triphenylmethyl)-1H-tetrazole (5) (56 g, 0.1 mol), and K2CO3 (28 g,
0.2 mol) were suspended in MeCN (500 mL). The reaction mixture was stirred and heated at reflux for 5
h. The resulting solution was then cooled to rt and filtered. The filtrate was concentrated and the residue
was partitioned between EtOAc and water. The organic layer was dried and concentrated to give a pale
yellow oil. i-PrOH (150 mL) was added and the mixture was stirred at rt for 30 min. The resulting solid
was filtered, washed with i-PrOH and dried to afford 6 as a pale yellow solid (72 g, 92%). IR (KBr): 3433,
1
3060, 2978, 2931, 1711, 1603, 1535, 1448, 1367, 1290, 1163, 1128, 1022, 760, 700 cm–1; H NMR
(DMSO-d6, 300 MHz): δ 1.20 (t, 3H, J = 7.2 Hz), 1.26–1.44 (2s, 9H), 4.09 (q, 2H, J = 7.2 Hz), 4.39–4.60
(2d, 2H), 6.80–8.10 (m, 26H); 13C NMR (DMSO-d6, 100 MHz): δ 13.74, 27.52, 27.88, 53.02, 61.66,
80.12, 82.25, 125.64, 126.61, 127.49, 127.79, 128.01, 128.25, 128.60, 128.73, 128.96, 129.13, 129.58,
130.29, 130.47, 131.77, 133.58, 134.50, 134.84, 139.41, 140.78, 141.20, 148.15, 153.07, 163.54, 164.19;
ESI-MS m/z 809.1 (M+23). Anal. Calcd for C47H42N6O6: C, 71.74; H, 5.38; N, 10.68. Found: C, 72.06; H,
5.58; N, 10.32.

1506
HETEROCYCLES, Vol. 81, No. 6, 2010
2-[(N-t-Butoxycarbonyl)-[[2'-[1-(triphenylmethyl)-1H-tetrazol-5-yl]biphenyl-4-yl]methyl]amino]-3-
nitrobenzoic acid (7). The benzoate 6 (70 g, 0.089 mol) was added to a solution of NaOH (4.3 g, 0.107
mol) in H2O (50 mL) and THF (500 mL). The reaction mixture was stirred and heated at reflux for 12 h.
The solvent was recovered and the residue was treated with water (500 mL), then acidified to pH~7 with
2 M HCl. The resulting solid was collected via suction filtration, dried to provide 7 as a pale yellow solid
(63 g, 94%). IR (KBr): 3448, 3060, 2978, 1686, 1608, 1533, 1448, 1367, 1161, 1014, 760, 698, 640 cm–1;
1H NMR (DMSO-d6, 300 MHz): δ 1.25–1.32 (2s, 9H), 4.31–5.15 (2d, 2H), 6.80–7.80 (m, 26H); 13C
NMR (DMSO-d6, 100 MHz): δ 27.67, 28.02, 52.87, 79.41, 82.27, 123.91, 125.72, 126.68, 127.24, 127.58,
127.82, 127.87, 128.33, 129.01, 129.61, 130.38, 130.49, 130.59, 132.18, 134.15, 135.72, 138.83, 140.81,
141.47, 147.82, 147.98, 153.55, 163.69, 168.26; ESI-MS m/z 757.0 (M–1). Anal. Calcd for C45H38N6O6:
C, 71.23; H, 5.05; N, 11.08. Found: C, 71.58; H, 5.28; N, 10.76.
(±)-1-[[(Cyclohexyloxy)carbonyl]oxy]ethyl
2-[(N-t-butoxycarbonyl)-[[2'-[1-(triphenylmethyl)-1H-
tetrazol-5-yl]biphenyl-4-yl]methyl]amino]-3-nitrobenzote (9). The benzoic acid 7 (61 g, 0.08 mol),
K2CO3 (23 g, 0.16 mol) and (±)-1-chloroethyl cyclohexyl carbonate (8) (25 g, 0.12 mol) were suspended
in MeCN (500 mL), and the reaction mixture was stirred and heated at reflux for 6 h. The resulting
solution was then cooled to rt and filtered. The filtrate was concentrated and the residue was partitioned
between EtOAc and water. The organic layer was dried and concentrated to afford crude 9 as a pale
yellow oil (~ 80 g) which was used directly in the next step. A small reference sample was obtained by
chromatography on silica gel. IR (KBr): 3433, 2937, 2862, 1755, 1714, 1537, 1450, 1379, 1288, 1255,
1163, 1074, 1007, 762, 700 cm–1; 1H NMR (DMSO-d6, 300 MHz): δ 1.20–1.85 (m, 22H), 4.20–4.80 (2d,
2H), 4.55 (m, 1H), 6.80–8.10 (m, 27H); 13C NMR (DMSO-d6, 100 MHz): δ 19.24, 22.89, 24.57, 27.53,
27.91, 30.75, 76.76, 80.31, 82.25, 92.14, 125.66, 127.84, 128.29, 128.69, 129.15, 129.61, 129.93, 130.14,
130.32, 130.49, 133.96, 134.05, 134.18, 135.29, 139.50, 139.60, 140.79, 141.20, 148.37, 151.94, 152.91,
162.12, 162.47, 163.56; ESI-MS m/z 951.3 (M+23). Anal. Calcd for C54H52N6O9: C, 69.81; H, 5.64; N,
9.05. Found: C, 69.47; H, 5.72; N, 8.99.
(±)-1-[[(Cyclohexyloxy)carbonyl]oxy]ethyl 2-[[[2'-(1H-tetrazol-5-yl)biphenyl-4-yl]methyl]amino]-3-
nitrobenzote (10). Acetyl chloride (30 mL) was added slowly to EtOH (220 mL) in an ice-water bath,
then the crude ester 9 (80 g, 0.08 mol) was added and the reaction mixture was stirred for 12 h. The
reaction solution was then diluted with EtOAc (600 mL) and ice-water, basified to pH~7 with 2 M NaOH.
The organic layer was separated, dried and concentrated to give crude 10, which was chromatographed on
silica gel using 20% EtOAc in PE to afford pure 10 as a white solid (39 g, 83%). IR (KBr): 3323, 2935,
2858, 1753, 1701, 1604, 1581, 1529, 1502, 1450, 1356, 1244, 1072, 1007, 762 cm–1; 1H NMR (DMSO-d6,

HETEROCYCLES, Vol. 81, No. 6, 2010
1507
300 MHz): δ 1.57 (d, 3H, J = 4.8 Hz), 1.20–1.90 (m, 10H), 4.16 (d, 2H, J = 5.1 Hz), 4.55 (m, 1H),
6.70–6.80 (m, 2H), 7.07 (d, 2H, J = 7.8 Hz), 7.25 (d, 2H, J = 7.8 Hz), 7.50–7.70 (m, 4H), 8.03 (dd, 1H, J
= 8.1 Hz, 1.8 Hz), 8.13 (dd, 1H, J = 8.1 Hz, 1.8 Hz), 8.45 (t, 1H, J = 6.1 Hz); 13C NMR (DMSO-d6, 100
MHz): δ 19.25, 22.94, 24.63, 30.79, 49.67, 76.84, 91.97, 115.62, 116.00, 127.73, 127.89, 129.16, 130.69,
131.21, 131.97, 137.05, 137.18, 140.99, 144.56, 151.99, 164.82; ESI-MS m/z 587.4 (M+1), 609.2 (M+23).
Anal. Calcd for C30H30N6O7: C, 61.43; H, 5.15; N, 14.33. Found: C, 61.19; H, 5.28; N, 14.20.
(±)-1-[[(Cyclohexyloxy)carbonyl]oxy]ethyl 3-amino-2-[[[2'-(1H-tetrazol-5-yl)biphenyl-4-yl]methyl]-
amino]benzote (11). The nitrobenzote 10 (30 g, 0.051 mol) and stannous chloride dihydrate (32 g, 0.14
mol) were suspended in EtOAc (200 mL). The reaction mixture was stirred at 60 ºC for 1 h. The reaction
solution was then diluted with EtOAc (300 mL) and ice-water, basified to pH~7 with 2 M NaOH, and
filtered. The organic layer of the filtrate was separated, washed with water, dried and concentrated to
provide 11 as a pale yellow solid (27 g, 95%). IR (KBr): 3431, 3348, 2939, 2860, 1753, 1701, 1604, 1471,
1
1286, 1063, 750 cm–1; H NMR (DMSO-d6, 300 MHz): δ 1.49 (d, 3H, J = 6.0 Hz), 1.20–1.90 (m, 10H),
4.11 (s, 2H), 4.55 (m, 1H), 6.75–6.82 (m, 2H), 6.93 (dd, 1H, J = 7.7 Hz, 1.5 Hz), 7.02–7.08 (m, 4H), 7.24
(s, 1H), 7.27 (s, 1H), 7.52–7.70 (m, 5H); 13C NMR (DMSO-d6, 100 MHz): δ 19.28, 22.89, 24.57, 30.75,
48.55, 76.60, 91.39, 118.71, 118.95, 119.70, 121.62, 123.36, 127.69, 128.68, 130.58, 130.62, 131.04,
137.78, 138.13, 139.28, 141.24, 142.45, 151.93, 166.04; ESI-MS m/z 579.2 (M+23), 555.0 (M–1). Anal.
Calcd for C30H32N6O5: C, 64.73; H, 5.79; N, 15.10. Found: C, 64.46; H, 5.88; N, 14.91.
(±)-1-[[(Cyclohexyloxy)carbonyl]oxy]ethyl 2-ethoxy-l-[[2'-(1H-tetrazol-5-yl)biphenyl-4-yl]methyl]-
1H-benzimidazole-7-carboxylate (1). A mixture of the aminobenzote 11 (22 g, 0.04 mol), acetic acid
(2.3 mL, 0.04 mol) and tetraethyl orthocarbonate (9.2 mL, 0.044 mol) in toluene (100 mL) was stirred at
60 ºC for 2 h. The reaction mixture was then diluted with PE (~ 100 mL) and cooled to rt. The resulting
solid was filtered and dried to provide crude 1 as a pale solid (23 g). Recrystallization from EtOAc-PE
afforded product 1 (20 g, 81%), purity at 99.1% (HPLC). 1H NMR (DMSO-d6, 300 MHz): δ 1.41 (t, 3H, J
= 7.5 Hz), 1.42 (d, 3H, J = 5.4 Hz), 1.20–1.85 (m, 10H), 4.56 (m, 1H), 4.62 (q, 2H, J = 7.5 Hz), 5.52 (s,
2H), 6.80 (q, 1H, J = 5.4 Hz), 6.90 (d, 2H, J = 8.1 Hz), 7.01 (d, 2H, J = 8.1 Hz), 7.22 (t, 1H, J = 7.8 Hz),
7.45–7.75 (m, 5H); ESI-MS m/z 633.2 (M+23), 609.1 (M–1). HPLC Conditions: Waters XTerra MS C18
4.6 mm × 150 mm × 5 μm; Detection: 210 nm; Flow rate: 1.0 mL/min; Temperature: 30 °C; Injection
load: 5 μL; Concentration: 0.5 mg/mL; Run time: 20 min; Mobile phase A: buffer (water / o-phosphoric
acid, 85% = 100 mL / 0.1 mL); Mobile phase B: MeCN; Gradient program: time (min): 0 15 20; % of
mobile phase A: 45, 10, 0; % of mobile phase B: 55, 90, 100; Retention time of 1: 6.381 min.

1508
HETEROCYCLES, Vol. 81, No. 6, 2010
REFERENCES
1. K. J. McClellan and K. L. Goa, Drugs, 1998, 56, 847; S. E. Easthope and B. Jarvis, Drugs, 2002, 62,
1253; P. A. Meredith, Curr. Med. Res. Opin., 2007, 23, 1693.
2. T. Naka, K. Nishikawa, and T. Kato, EP459136, 1991; K. Kubo, Y. Kohara, E. Imamiya, Y. Sugiura,
Y. Inada, Y. Furukawa, K. Nishikawa, and T. Naka, J. Med. Chem., 1993, 36, 2182; K. Kubo, Y.
Kohara, Y. Yoshimura, Y. Inada, Y. Shibouta, Y. Furukawa, T. Kato, K. Nishikawa, and T. Naka, J.
Med. Chem., 1993, 36, 2343; H. Hashimoto, T. Hanaoka, and M. Kato, EP881212, 1998; M.
Porcs-Makkay, T. Mezei, and G. Simig, Org. Process Res. Dev., 2007, 11, 490; Y. P. Wang, Y. G.
Li, Y. L. Li, G. J. Zheng, Y. Li, and S. Koecher, DE102004060699, 2006; S. R. Gorantla, M.
Bandari, and N. R. Karusala, WO2007094015, 2007; S. Zupancic, P. Benkic, P. Smrkolj, S. Senicar,
N. Sostaric-Virc, and J. Hvala, WO2008012372, 2008.
3. H. H. Li, C. Yang, Z. Liu, J. F. Li, and J. S. Shen, WO2008131582, 2008; H. H. Li, X. R. Jiang, Q. J.
Zhao, C. Yang, and J. S. Shen, WO2009003339, 2009.
4. P. E. Aldrich, M. E. Pierce, and J. J. V. Duncia, EP291969, 1988.
5. H. N. Pati, S. Lahiri, R. K. Sabbam, V. B. Vangala, B. Ramalingam, S. G. Hiriyanna, and P. Bose, J.
Heterocycl. Chem., 2008, 45, 917; S. Kumar .N, S. B. Reddy, B. K. Sinha, K. Mukkanti, and R.
Dandala, Org. Process Res. Dev., 2009, 13, 1185.
6. Z. Liu, H. H. Li, Q. J. Zhao, and J. S. Shen, Heterocycles, 2008, 75, 1907.
