DNA double-strand break repair in cell-free extracts from
Ku80-deficient cells: implications for Ku serving as an
alignment factor in non-homologous DNA end joining
Elke Feldmann, Viola Schmiemann, Wolfgang Goedecke, Susanne Reichenberger and
Petra Pfeiffer*
Institut für Zellbiologie des Universitätsklinikums Essen, Virchowstraße 173, D-45122 Essen, Germany
Received February 18, 2000; Revised and Accepted May 18, 2000
ABSTRACT
sequence at the break; (ii) single-strand annealing (SSA), a
process that leads to the formation of deletions; or (iii) non-
homologous DNA end joining (NHEJ) that joins two broken
ends directly. While HRR and SSA involve the members of the
Rad52 epistasis group and strictly require extensive sequence
homology, the Rad52-independent NHEJ process can dispense
with sequence homology (1–4). Although increasing evidence
indicates that vertebrate cells are also quite proficient at
repairing DSB by HRR (5) during S and G2, NHEJ is still
considered the major pathway of DSB repair.
Non-homologous DNA end joining (NHEJ) is considered
the major pathway of double-strand break (DSB) repair
in mammalian cells and depends, among other
things, on the DNA end-binding Ku70/80 hetero-
dimer. To investigate the function of Ku in NHEJ we
have compared the ability of cell-free extracts from
wild-type CHO-K1 cells, Ku80-deficient xrs6 cells and
Ku80-cDNA-complemented xrs6 cells (xrs6-Ku80) to
rejoin different types of DSB in vitro. While the two
Ku80-proficient extracts were highly efficient and
accurate in rejoining all types of DNA ends, the xrs6
extract displayed strongly decreased NHEJ efficiency
and accuracy. The lack of accuracy is most evident in
non-homologous terminus configurations containing
3′-overhangs that abut a 5′-overhang or blunt end.
While the sequences of the 3′-overhangs are mostly
preserved by fill-in DNA synthesis in the Ku80-
proficient extracts, they are always completely lost in
the xrs6 extract so that, instead, small deletions
displaying microhomology patches at their break-
points arise. In summary, our results are consistent
with previous results from Ku-deficient yeast strains
and indicate that Ku may serve as an alignment
factor that not only increases NHEJ efficiency but
also accuracy. Furthermore, a secondary NHEJ
activity is present in the absence of Ku which is
error-prone and possibly assisted by base pairing
interactions.
First reports on NHEJ date back to the early eighties (6–8).
In the following years, the mechanisms of NHEJ were studied
in detail in mammalian cells (9–12), extracts from Xenopus
eggs (13,14) and later in yeast (15–17). NHEJ includes (i) the
simple ligation of complementary (cohesive) protruding single
strands (PSS) or blunt (bl.) ends which leads to the precise
restoration of the broken sequence and (ii) the joining of non-
complementary (non-homologous) DNA termini. Studies in
Xenopus egg extracts showed that NHEJ is a highly accurate
process that tends to preserve the sequences of interacting non-
homologous DNA ends by generating two major types of
products (overlap and fill-in). The type of product formed depends
on the structure of ends being joined; overlap junctions typically
arise during the joining of DNA ends containing anti-parallel
PSS (5′/5′ and 3′/3′) while fill-in junctions are formed between
abutting DNA ends (bl./5′, bl./3′ and 5′/3′). In the first case, the
ends form by pairing of single fortuitously complementary
bases, incompletely matched overlaps whose structure determines
the patterns of subsequent repair reactions (Fig. 1; 18,19). In
the second case, the sequences of participating 5′- and/or 3′-PSS
are fully preserved by fill-in DNA synthesis in a process in
which the ends are transiently held together by non-covalent
interactions while the 3′-hydroxyl group of the 5′-PSS or blunt
end is used as a primer to direct repair synthesis of the 3′-PSS
(Fig. 1B; 14). Based on these data, we postulated in 1990 that
an alignment factor may function to maintain the two ends in
alignment to facilitate their biochemical reconfiguration into a
ligatable structure (14). Similar joining events have been
observed in vivo and in vitro in mammalian cells (10,11,20,21)
indicating that the mechanisms found in the Xenopus system
also apply for mammalian systems. The identity of the putative
alignment factor, however, remained unknown.
INTRODUCTION
Double-strand breaks (DSB), probably the most disruptive
type of lesion in DNA, may arise spontaneously in the cell or
after exposure to DNA-damaging agents, such as ionizing
radiation (IR). If left unrepaired, DSB leads to broken chromo-
somes and cell death; if repaired improperly, mutations,
chromosome rearrangements and oncogenic transformation
may arise. Repair of DSB is achieved by at least three different
mechanisms: (i) homologous recombination repair (HRR), a
highly accurate process that usually restores the precise DNA
