Enzymatic synthesis of lipophilic esters of phenolic compounds, evaluation of their antioxidant activity and effect on the oxidative stability of selected oils

Article abstract of DOI:10.3390/biom11020314

The aim of the study was to compare the effect of the substituent and its position in the aromatic ring on the antioxidant activity of hexanoic acid esters obtained in reactions catalyzed by immobilized lipase B from Candida antarctica. 4‐Hydroxybenzyl hexanoate, 2‐hydroxybenzyl hexanoate, 4‐methoxybenzyl hexanoate, and vanillyl hexanoate were obtained with conversion yields of 50 to 80%. The antioxidant activity of synthesized esters, their alcohol precursors and BHT (Butylated HydroxyToluene) was compared with DPPH (2,2‐diphenyl‐1‐picrylhydrazyl), CUPRAC (cupric ion reducing antioxidant capacity), and CBA (crocin bleaching assay) methods. Furthermore, it was investigated whether the presence of vanillyl hexanoate in a concentration of 0.01 and 0.1% affected the oxidative stability of sunflower and rapeseed oils in the Rancimat test. It was observed that the antioxidant activity of hexanoic acid esters depends on the presence and position of the hydroxyl group in the aromatic ring. The highest activities were found for vanillyl alcohol, vanillyl hexanoate, and BHT. The addition of the ester and BHT significantly extended the induction times of the tested oils, and these compounds exhibited similar activity. Vanillyl hexanoate increased the induction time from 4.49 to 5.28 h and from 2.73 to 3.12 h in the case of rapeseed and sunflower oils, respectively.

Full text of DOI:10.3390/biom11020314

biomolecules
Article
Enzymatic Synthesis of Lipophilic Esters of Phenolic
Compounds, Evaluation of Their Antioxidant Activity and
Effect on the Oxidative Stability of Selected Oils
Bartłomiej Zieniuk 1,
* ,
, Katarzyna Groborz 1, Małgorzata Wołoszynowska 2 , Katarzyna Ratusz 3
Ewa Białecka-Florjan´czyk 1 and Agata Fabiszewska 1
1
Department of Chemistry, Institute of Food Sciences, Warsaw University of Life Sciences—SGGW,
159c Nowoursynowska St., 02-776 Warsaw, Poland; groborz.kasia@gmail.com (K.G.);
ewa_bialecka_florjanczyk@sggw.edu.pl (E.B.-F.); agata_fabiszewska@sggw.edu.pl (A.F.)
Analytical Department, Łukasiewicz Research Network—Institute of Industrial Organic Chemistry,
6 Annopol St., 03-236 Warsaw, Poland; malgorzata.woloszynowska@ipo.lukasiewicz.gov.pl
Department of Food Technology and Assessment, Institute of Food Sciences, Warsaw University of Life
Sciences—SGGW, 159c Nowoursynowska St., 02-776 Warsaw, Poland; katarzyna_ratusz@sggw.edu.pl
Correspondence: bartlomiej_zieniuk@sggw.edu.pl; Tel.: +48-22-59-37-621
2
3
*
Abstract: The aim of the study was to compare the effect of the substituent and its position in the
aromatic ring on the antioxidant activity of hexanoic acid esters obtained in reactions catalyzed
by immobilized lipase B from Candida antarctica. 4-Hydroxybenzyl hexanoate, 2-hydroxybenzyl
hexanoate, 4-methoxybenzyl hexanoate, and vanillyl hexanoate were obtained with conversion
yields of 50 to 80%. The antioxidant activity of synthesized esters, their alcohol precursors and BHT
(Butylated HydroxyToluene) was compared with DPPH (2,2-diphenyl-1-picrylhydrazyl), CUPRAC
(cupric ion reducing antioxidant capacity), and CBA (crocin bleaching assay) methods. Furthermore,
it was investigated whether the presence of vanillyl hexanoate in a concentration of 0.01 and 0.1%
affected the oxidative stability of sunflower and rapeseed oils in the Rancimat test. It was observed
that the antioxidant activity of hexanoic acid esters depends on the presence and position of the
hydroxyl group in the aromatic ring. The highest activities were found for vanillyl alcohol, vanillyl
hexanoate, and BHT. The addition of the ester and BHT significantly extended the induction times
of the tested oils, and these compounds exhibited similar activity. Vanillyl hexanoate increased the
induction time from 4.49 to 5.28 h and from 2.73 to 3.12 h in the case of rapeseed and sunflower
oils, respectively.
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Citation: Zieniuk, B.; Groborz, K.;
Wołoszynowska, M.; Ratusz, K.;
Białecka-Florjan´czyk, E.; Fabiszewska,
A. Enzymatic Synthesis of Lipophilic
Esters of Phenolic Compounds,
Evaluation of Their Antioxidant
Activity and Effect on the Oxidative
Stability of Selected Oils. Biomolecules
2021, 11, 314. https://doi.org/
10.3390/biom11020314
Academic Editors: Grzegorz Janusz,
Daniel Kracher and Anna Pawlik
Keywords: CALB; enzymatic esterification; phenolic compounds; antioxidant activity; oxidative
stability; vanillyl hexanoate
Received: 5 February 2021
Accepted: 18 February 2021
Published: 19 February 2021
Publisher’s Note: MDPI stays neutral
with regard to jurisdictional claims in
published maps and institutional affil-
iations.
1. Introduction
In recent years, the availability and consumption of highly processed and convenience
food products has increased in many countries. Based on a Spanish study, for example,
from 1990 to 2010, consumption of these food products increased threefold [1]. Many
technological steps in the production chain and high processing of raw material can
negatively affect the quality of the final product. Food additives are used in order to limit
the adverse effects of food processing [
of potential antioxidants.
Phenolic compounds are a large group of secondary metabolites that are diverse in
structure and widespread in plants and mushrooms. The main and most widely distributed
2] and phenolic compounds are an interesting group
Copyright:
© 2021 by the authors.
Licensee MDPI, Basel, Switzerland.
This article is an open access article
distributed under the terms and
conditions of the Creative Commons
Attribution (CC BY) license (https://
creativecommons.org/licenses/by/
4.0/).
in nature classes of polyphenols are flavonoids, phenolic acids, stilbenes, and lignans [
The common part of these compounds is the presence of an aromatic ring with an attached
hydroxyl group [ ]. In addition to the previously mentioned classes, phenolics are a
group containing about 5000 to 8000 forms of different structures, and also include such
3].
4
Biomolecules 2021, 11, 314. https://doi.org/10.3390/biom11020314
https://www.mdpi.com/journal/biomolecules

Biomolecules 2021, 11, 314
2 of 11
compounds as phenolic terpenes, alkylphenols, curcuminoids, and coumarins, along with
phenolic derivatives of aldehydes, ketones, and alcohols [5]. The last aforementioned—
aromatic alcohols—are a group of organic chemical compounds composed of an aromatic
ring with an alkyl chain with a hydroxyl group attached, and the simplest example of
such compounds is benzyl alcohol [6]. Aromatic alcohols, as well as other phenolic
compounds, exhibit high biological activity, being antioxidant or antimicrobial agents
and attracting the attention of many researchers due to the anticancer or neuro-, cardio-
and hepatoprotective properties described in the literature [4]. Aromatic alcohols are
very often used as fragrances and flavorants, and some of them, such as gastrodigenin
(4-hydroxybenzyl alcohol), are found in plant extracts used in traditional medicine [7,8].
Biocatalysis provides opportunities for the sustainable production of chemical com-
pounds with interesting features, which can possibly be commercialized as food addi-
tives [9,10]. Esterification of phenolic compounds is the primary method of their modifi-
cation; moreover, the use of enzymes to catalyze these reactions has many advantages in
comparison with conventional chemical synthesis. Enzyme-catalyzed reactions are carried
out in milder conditions; fewer by-products are generated and they are environmental-
friendly [10]. Different esters of phenolic compounds are used in the food or cosmetic
industry and esterification improves their biological activity [4,9]. The approach has been
presented in the current study that aimed to evaluate the effect of the substituent and its
position in the aromatic ring on the antioxidant activity of hexanoic acid esters synthesized
in reactions catalyzed by immobilized lipase B from Candida antarctica (CALB). Further-
more, it was investigated whether the presence of an ester characterized by the highest
antioxidant activity in in vitro tests affected the oxidative stability of refined sunflower and
rapeseed oils.
2. Materials and Methods
2.1. Materials
The biocatalyst used in this study was lipase B from Candida antarctica (CALB) immo-
bilized on macroporous acrylic resin, which was purchased from Sigma-Aldrich (Poznan,
Poland). Chemicals were purchased from Avantor Performance Materials Poland S.A.
(Gliwice, Poland) and Sigma-Aldrich (Poznan, Poland). Refined vegetable oils—sunflower
and rapeseed oils—were acquired from the local supermarket in Warsaw (Poland).
2.2. Esters Synthesis
Syntheses of four esters were carried out with CALB as a biocatalyst (addition of
5% by weight of substrates). The esters were synthesized by reacting the appropriate
aromatic alcohol—2-hydroxybenzyl, 4-hydroxybenzyl, 4-methoxybenzyl or 4-hydroxy-3-
methoxybenzyl (vanillyl)—with hexanoic acid in a molar ratio of 1:2 (alcohol:acid) accord-
ing to the reaction in Figure 1. Reactions were carried out in flasks in tert-butyl methyl
ether at 37 ◦C at 200 rpm on a rotary shaker for 48 h.
Figure 1. Lipase-catalyzed synthesis of hexanoic acid esters.

Biomolecules 2021, 11, 314
3 of 11
2.3. Gas Chromatography
Samples were withdrawn from flasks after 1, 2, 24, and 48 h of reactions, and were
subsequently derivatized with BSTFA (N,O-bis(trimethylsilyl)trifluoroacetamide) + 1%
TMCS (trimethylchlorosilane) and pyridine added in equal volumes and heated for 30 min
◦
at 70 C. Then, derivatized samples were analyzed by gas chromatography equipped with
a flame ionization detector (GC-FID) using Agilent Technologies 7820A apparatus with
an HP-5 column (0.25 mm, 30 m, 0.25 µm) (Agilent Technologies, Santa Clara, CA, USA).
Nitrogen was used as a carrier gas at a flow rate of 1.5 mL/min. The temperature program
of the GC analysis was◦as follows: 70 ◦C for 3 min, 70 to 150 ◦C (3 ◦C/min), 150 to 300 ◦C
◦
(40 C/min), and 300 C for 10 min. Injector and detector temperatures were 250 and
◦
290 C, respectively, with an injection volume of 1
µL. The percentage conversion was
calculated based on the area under the peaks of aromatic alcohol and its ester.
2.4. Esters Purification
After 48 h, reactions were filtered through filter paper placed within the funnel
to separate the enzyme. The solvent was evaporated in a vacuum evaporator (BUCHI
Rotavapor R-200, Flawil, Switzerland) and the obtained mixtures were dissolved in 10 mL
of chloroform. Then, 10 mL of a saturated solution of sodium bicarbonate was added to
remove the excess of acid. Organic phases were collected and the solvent was evaporated.
Prepared samples were applied to a silica gel column chromatography with a mixture of
chloroform and methanol (9:1, v/v) as an eluent.
Structures of the synthesized esters were confirmed after their purification using 1H
NMR. Compound spectra were recorded using a Bruker AVANCE 300 MHz spectrometer
(Bruker, Billerica, MA, USA) with CDCl3 as a solvent. Proton chemical shifts of obtained
esters are reported below in ppm (δ) relative to tetramethylsilane (TMS), which was used
as an internal standard.
2-Hydroxybenzyl hexanoate 1H–NMR (300 MHz, CDCl3):
δ
0.87 (3H, t, J = 7.1 Hz),
1.20–1.42 (4H, m), 1.66 (2H, m), 2.37 (2H, t, J = 7.1 Hz), 5.15 (2H, s), 6.87–7.02 (2H, m),
7.24–7.36 (2H, m), 7.87 (1H, s)
4-Hydroxybenzyl hexanoate 1H–NMR (300 MHz, CDCl3):
δ 0.87 (3H, t, J = 7.1 Hz),
1.28–1.31 (4H, m), 1.64 (2H, m), 2.34 (2H, t, J = 7.1 Hz), 5.05 (2H, s), 5.85 (1H, s), 6.81–6.83
(2H, m), 7.22–7.24 (2H, m)
4-Methoxybenzyl hexanoate 1H–NMR (300 MHz, CDCl3):
δ 0.88 (3H, t, J = 7.1 Hz),
1.25–1.42 (4H, m), 1.63 (2H, m), 2.36 (2H, t, J = 7.1 Hz), 3.83 (3H, s), 5.07 (2H, s), 6.86–6.97
(2H, m), 7.26–7.37 (2H, m)
Vanillyl hexanoate 1H–NMR (300 MHz, CDCl3):
δ 0.88 (3H, t, J = 7.1 Hz), 1.25–1.36
(4H, m), 1.66 (2H, m), 2.35 (2H, t, J = 7.1 Hz), 3.92 (3H, s), 5.05 (2H, s), 5.66 (1H, s), 6.85–6.97
(3H, m)
2.5. Evaluation of Antioxidant Activity
The following methods for the determination of the antioxidant activity of tested
compounds were applied: the method with DPPH
crocin bleaching assay (CBA).
•
radical, the CUPRAC method and
The DPPH
•
(2,2-Diphenyl-1-picrylhydrazyl) radical scavenging method was used
according to the previously reported protocol by Zanetti et al. [11]. The IC50 parameter, i.e.,
the concentration required for a 50% reduction of the DPPH
all esters and their precursors.
•
radical—was calculated for
The principle of the CUPRAC (cupric ion reducing antioxidant capacity) method is a
spectrophotometric measurement of the absorption of the formed complex of a Cu (I) ion
with neocuproine (2,9-dimethyl-1,10-phenanthroline). According to Özyürek et al. [12], the
Trolox equivalent antioxidant capacities (TEAC) were determined for the tested compounds
based on the absorbance of compounds and Trolox, used as a reference standard.
Compounds were characterized by the highest antioxidant activity in the DPPH
radical scavenging method and CUPRAC method; i.e., vanillyl alcohol and vanillyl hex-
•

Biomolecules 2021, 11, 314
4 of 11
anoate were used in crocin bleaching assay. CBA is an in vitro method for measuring
the antioxidant capacity of different samples (pharmaceuticals, pure compounds or plant
extracts). This method is based on the spectrophotometric measurement of the inhibition
of crocin discoloration by peroxide radicals in the presence of antioxidants. The protocol by
Ordoudi and Tsimidou [13] was used with AAPH (2,20-Azobis(2-methylpropionamidine)
dihydrochloride), a water-soluble azo-initiator that is responsible for the generation of
peroxyl radicals after its thermolysis.
In all of the above-mentioned methods, the known commercial synthetic antioxidant—
Butylated HydroxyToluene (BHT)—was used as a reference compound.
2.6. Determination of Oils Quality Parameters
The acid and peroxide values (AVs and PVs, respectively) were determined in re-
fined vegetable oils used in the current study. The AV was determined according to ISO
660:2009 and the results were expressed as mg KOH/g of oil. The PV was determined with
iodometric titration according to ISO 3960:2017 and expressed as mEq O2/kg of oil.
2.7. Determination of the Fatty Acid Composition of Vegetable Oils
The fatty acid compositions of rapeseed and sunflower oils were determined after
derivatization to methyl esters and analyzed by gas chromatography equipped with a
flame ionization detector (GC-FID) using Agilent Technologies 7820A with a ZB-FFAP
capillary column (30 m, 0.25 mm, 0.25 µm) (Agilent Technologies, Santa Clara, CA, USA)
with helium as the carrier gas. The temperat◦ure program of the sepa◦ration of FAME
◦
(fatty acid methyl esters) was as follows: 120 C for 2 min, 120 to 200 C (10 C/min),
200 ◦C for 5 min, 200 to 240 ◦C (3 ◦C/min), and then 240 ◦C for 10 min. The injector and
detector temperatures were 260 and 280 ◦C, respectively, with an injection volume of 1
µL.
Fatty acids were identified based on the comparison of their retention times with those of
analytical standards.
2.8. Oxidative Stability Measurements Using the Rancimat Method
To determine the oxidative stability of the oils, 743 Rancimat apparatus (Metrohm,
Herisau, Switzerland) with the following cond◦itions were used: 2.5 g of sample, constant
air flow of 20 L/h, and a temperature of 120 C [14,15]. The experiment examined the
effect of vanillyl hexanoate in two different concentrations (0.01% and 0.1%) on the ox-
idative stability of refined oils. BHT at a concentration of 0.01% was used as a control
antioxidant compound.
2.9. Statistical Analysis
Statistical analysis was performed using Statistica 13.3 software (TIBCO Software
Inc., Palo Alto, CA, USA). The results were analyzed using one-way analysis of variance
(ANOVA) and Tukey’s post-hoc test. The significance level was α = 0.05.
3. Results and Discussion
3.1. Enzymatic Esterification
As a result of the esterification reactions of hexanoic acid with aromatic alcohols,
the following four esters were obtained: 4-hydroxybenzyl hexanoate, 2-hydroxybenzyl
hexanoate, 4-methoxybenzyl hexanoate, and vanillyl hexanoate. The progress of the
reactions carried out in the current work was monitored after 1, 2, 24, and 48 h of reaction
by gas chromatography; the conversions are presented in Figure 2. All reactions catalyzed
by lipase B from C. antarctica were characterized by a high (over 50%) degree of reacting
of the substrates after two hours of reaction. Substrate conversion after 2 h was between
54 and 74%; up to 48 h, these values changed slightly and were 50 to 80%. The synthesis
of 4-hydroxybenzyl hexanoate was characterized by the highest conversion (about 80%
after 24 h). The reaction for which the lowest degree of conversion was observed was the
synthesis of 2-hydroxybenzyl hexanoate. The reaction equilibrium was established at about

Biomolecules 2021, 11, 314
5 of 11
50% conversion. It was observed that the presence of the hydroxyl group in the ortho-
position in the 2-hydroxybenzyl alcohol molecule negatively affected the esterification
reaction compared to the reaction with 4-hydroxybenzyl alcohol (with the hydroxyl group
in the para- position). The observed relationship is probably related to the substrate
specificity of the enzyme used as well as substrate access to the active site of the enzyme.
100%
90%
80%
70%
60%
50%
40%
30%
20%
10%
0%
2-Hydroxybenzyl hexanoate
4-Hydroxybenzyl hexanoate
4-Methoxybenzyl hexanoate
Vanillyl hexanoate
0
12
24
36
48
Reaction time [h]
Figure 2. Percentage conversion (%
CALB after 1, 2, 24, and 48 h of reaction
±
SD) of aromatic alcohols and hexanoic acid to their esters with
Fuentes et al. [16] studied the relationship between lipase structure and its catalytic ac-
tivity. Molecular modelling studies compared two lipases of microbial origin—C. antarctica
and Thermomyces lanuginosus—investigating possible transition states for the sucrose and
vinyl laurate transesterification reaction. Both enzymes showed a broad ligand binding
spectrum in the substrate-binding pocket, while lipase B from C. antarctica had a wider
pocket size and hence showed less selectivity for reaction products.
In addition, Otto et al. [17] explained the potential and limitations of CALB in the
synthesis of aromatic glycolipids. The enzymatic reaction has been found to be influenced
by: (a) The chain length of acyl donors; at least one methylene bridge should be present
between the carboxylic group and the aromatic ring; (b) The substitution pattern of the
aromatic ring; the hydroxyl group in the ortho- position negatively affected the reaction
yield compared to the groups in the para or meta positions [17].
The above-mentioned studies confirmed that the catalyst used in this study is a
versatile enzyme, but still with some limitations. Nevertheless, the CALB enzyme is capable
of catalyzing the esterification reaction of some atypical carboxylic acids and alcohols.
3.2. Antioxidant Activity of Obtained Esters
The obtained compounds, as well as their precursors, were tested for antioxidant
properties by means of two methods: CUPRAC and DPPH (Table 1). It has been shown
that the tested compounds significantly differed in the values of their antioxidant activity
assessed by the CUPRAC method. The Trolox equivalent antioxidant capacity (TEAC)
values ranged between 0.026 (for 4-methoxybenzyl hexanoate) and 1.086 (for vanillyl
alcohol). In addition to vanillyl alcohol, a high TEAC value was also found for vanillyl
hexanoate (0.889). These compounds were characterized by higher antioxidant activity
than the industrially used antioxidant BHT (0.739). The antioxidant activity measured
using the DPPH radical method and the CUPRAC method were comparable. According to
the principle of the DPPH method, the lower the IC50 value (indicating the concentration

Biomolecules 2021, 11, 314
6 of 11
at which half of the DPPH radicals are scavenged), the higher the antioxidant activity. The
values obtained ranged between 0.28 (vanillyl alcohol) and 864.78 mM (4-methoxybenzyl
hexanoate). Outstanding antioxidant values were found also for vanillyl hexanoate (1.71)
and BHT (0.47).
Table 1. Comparison of antioxidant activity of tested compounds by means of methods with DPPH
radical and CUPRAC.
•
Antioxidant Activity
Compound
DPPH•
CUPRAC
TEAC **
IC50 (mM) *
0.28 ± 0.01 A ***
107.37 ± 2.47 B
126.81 ± 9.53 B
388.00 ± 34.98 C
1.71 ± 0.07 A
1.086 ± 0.025 A
0.452 ± 0.004 D
0.338 ± 0.025 E
0.032 ± 0.005 F
0.889 ± 0.025 B
0.407 ± 0.008 D
0.294 ± 0.007 E
0.026 ± 0.001 F
0.739 ± 0.048 C
Vanillyl alcohol
2-Hydroxybenzyl alcohol
4-Hydroxybenzyl alcohol
4-Methoxybenzyl alcohol
Vanillyl hexanoate
128.51 ± 2.78 B
137.32 ± 5.06 B
864.78 ± 56.32 D
0.47 ± 0.08 A
2-Hydroxybenzyl hexanoate
4-Hydroxybenzyl hexanoate
4-Methoxybenzyl hexanoate
Butylated hydroxytoluene (BHT)
* Concentration required for 50% reduction of the DPPH radical, ** Trolox equivalent antioxidant capacity, ***
The values with the same letter in a column did not differ significantly (α = 0.05).
•
The structure of aromatic alcohols used in the ester synthesis reactions significantly
affected the antioxidant properties of the obtained compounds. It was found that the
antioxidant activity of hexanoic acid esters depends on the presence and position of the
hydroxyl group in the aromatic ring. Ester, as well as its precursor with a hydroxyl group
in the ortho- position, showed higher antioxidant activity in the CUPRAC method than
ester with a hydroxyl group in the para- position (TEAC = 0.407 for 2-hydroxybenzyl
hexanoate, and TEAC = 0.294 for 4-hydroxybenzyl hexanoate). On the other hand, the
presence of a methoxy group in the aromatic ring did not affect the antioxidant activity
(
IC50 = 864.78 mM and TEAC = 0.026 for 4-methoxybenzyl hexanoate), but it has been
noticed that this group had an enhancing effect on the hydroxyl group; hence, the presence
of a hydroxyl group in the para- position and a methoxy group in the meta- position relative
to the carbon chain in the aromatic ring predisposed vanillyl alcohol and its derivatives
towards increased antioxidant properties.
The results obtained in the current study, as well as in study by Noriega-Iribe
et al. [18], confirmed that the presence of electron-donating groups such as hydroxy
and p-dimethylamino groups in the aromatic ring are relevant for the antioxidant ac-
tivity of chemical compounds. In the research by Dhiman et al. [19], similar obser-
vations regarding the position of the hydroxyl group in hydroxybenzyl alcohols have
been noted. 2-Hydroxybenzyl alcohol proved to be a better antioxidant compared with
4-hydroxybenzyl alcohol and was a better ABTS radical scavenger than the 3-hydroxybenzyl
and 4-hydroxybenzyl alcohols [19]. Velika and Kron [20] also confronted the position of
the hydroxyl group in hydroxybenzoic acids. 2-Hydroxybenzoic acid was found to be a
stronger antioxidant than 4-hydroxybenzoic acid and was far better than 3-hydroxybenzoic
acid [20].
The introduction of additional electron-donating groups to the phenolic ring enhances
the antioxidant activity. Intramolecular hydrogen bonding of two substituted phenolic
compounds contributed to the stabilization of the phenoxyl radical formed after hydrogen
donation [21]. Farhoosh et al. [22] acknowledged that an extra hydroxyl group was a more
powerful electron donor in comparison with methoxy group, which significantly increased
the antioxidant properties of the tested compounds.
Natalia et al. [23] and Park et al. [24] synthesized enzymatically fatty acid vanillyl
esters with menhaden and castor oils, respectively. The DPPH radical scavenging activity
of the tested compounds strongly depends on the solvent used in the test. Fatty acid

Biomolecules 2021, 11, 314
7 of 11
vanillyl esters showed similar IC50 values in 1-butanol and toluene, unlike their precursor,
vanillyl alcohol, where its activity decreased significantly in the more non-polar solvent [23].
The same observations were noticed by Park et al. [24] and ricinoleic acid vanillyl ester
exhibited comparable antioxidant activity in methanol, 2-propanol, 1-butanol, and toluene.
In the current study, the water–ethanol environment in the CUPRAC method and methanol
as a solvent in the DPPH radical method were used. The use of polar solvents may be the
reason that the obtained esters had a lower antioxidant potency than their precursors. Both
Roleira et al. [25] and Gaspar et al. [26] concluded that, in general, phenolic compounds
such as ferulic, caffeic, and sinapic acids have higher antioxidant activity than their ester or
amide derivatives, but esterification positively affects the lipophilicity of the compounds
obtained, which increases their utility as antioxidant agents in lipid-rich media.
3.3. Evaluation of Antioxidant Activity by Means of Crocin Bleaching Assay
Vanillyl hexanoate was selected for further analysis alongside its precursor—vanillyl
alcohol—and BHT was tested by crocin bleaching assay. Results of the comparison are
presented in Table 2 in three ways: percentage inhibitory effect, Trolox equivalent values
(TEVs), and IC50. Compounds showed similar activity, and vanillyl alcohol had the best
inhibitory effect of peroxyl radicals, which was about 46%. The rest of the compounds
exhibited slightly lower values—39% for vanillyl hexanoate and 34% for BHT. In the case of
TEV, vanillyl alcohol and its hexanoic ester obtained values were 0.50 and 0.42, respectively.
Table 2. Comparison of antioxidant activity of vanillin alcohol, vanillyl hexanoate, and BHT by
crocin bleaching assay.
Crocin Bleaching Assay
Compound
%
(%)
*
IC50 ***
(µM)
INH
TEV **
46 ± 2 A
39 ± 3 B
34 ± 1 B
0.50 ± 0.02 A
0.42 ± 0.03 B
0.37 ± 0.01 B
107 ± 3 A
128 ± 6 B
137 ± 4 B
Vanillyl alcohol
Vanillyl hexanoate
Butylated hydroxytoluene (BHT)
* Percentage inhibitory effect, ** Trolox Equivalent Values, *** Concentration corresponding to 50% inhibitory
effect; The values with the same letter in a column did not differ significantly (α = 0.05).
Most of the CBA applications relate to hydrophilic radical scavengers [27]. Vanil-
lyl alcohol is definitely a better soluble in hydrophilic media than its ester. CBA is a
method involving hydrogen-atom transfer (HAT) in contrast to single-electron transfer
(SET) methods like DPPH and CUPRAC assays. Nevertheless, the presence, quantity, and
arrangement of electron-donating groups are the most important factors determining high
antioxidant activity. Ordoudi and Tsimidou [13] investigated 39 phenolic compounds by
the CBA method. Single phenols were more active than their respective hydroxybenzoic
acids. Pyrogallol and gallic acid proved to be the best scavengers of the peroxyl radicals,
and the effect of proximity of the carboxylic group to the aromatic ring also affected the
compound activity.
3.4. The Effect of Vanillyl Hexanoate on the Oxidative Stability of Rapeseed and Sunflower Oils
The choice of antioxidant activity testing methods is often burdened with some
disadvantages. It should be taken into account that these methods show some specificity in
terms of mechanism of action, pH, temperature, time, etc. In addition, various compounds
are used as standards for the construction of calibration curves, such as Trolox, gallic,
chlorogenic or ascorbic acids. Therefore, in vitro methods can not accurately reflect the
antioxidant capacity of tested compounds [28,29]. In fact, the activity of antioxidants not
only depends on the structure, but also on the concentration, temperature, and type of
substrate, including the presence of prooxidants or synergists, or the system into which the
compound is introduced [30].

Biomolecules 2021, 11, 314
8 of 11
The esterification of phenolic compounds for the synthesis of molecules with medium
or long aliphatic chains can be used as a method for the modification of physical properties,
e.g., solubility, miscibility, and antioxidant activity in emulsion-based systems [31]. There-
fore, in the current study, it was verified whether the ester that had the best antioxidant
properties described by in vitro methods would be able to affect the oxidative stability
of commonly consumed vegetable oils. Oils are food products susceptible to the oxida-
tion processes in the presence of factors such as high temperature, light, enzymes or the
presence of microorganisms. The oxidative stability of the oil is a very important quality
feature and it determines the technological usefulness of a given product [30].
The acid and peroxide values as well as the fatty acid profiles of rapeseed and sun-
flower oils are shown in Table 3. These quality features are a measure of free fatty acids and
the extent to which an oil has undergone primary oxidation, respectively. The obtained
acid values were as follows: 0.22 mg KOH/g for rapeseed oil and 0.33 mg KOH/g for
sunflower oil. Moreover, plant oils were characterized by peroxide values of 1.79 mEq
O2/kg and 2.20 mEq O2/kg, respectively. The tested oils were of good quality, meeting the
requirements of PN-A-86908:2000, where, in the case of PV, it should not be higher than
5 mEq O2/kg, and the rate of fat hydrolysis (AV) not higher than 0.3 mg KOH/g. Similarly,
the fatty acid composition of the tested oils met the requirements of Codex Alimentarius
standards [32].
Table 3. Acid and peroxide values, and fatty acid profiles of rapeseed and sunflower oils.
According
to PN-A-86908:2000
Parameter
Rapeseed Oil
Sunflower Oil
Acid value (AV)
[mg KOH/g]
Peroxide value (PV)
[mEq O2/kg]
0.22 ± 0.004 A
1.79 ± 0.010 A
*
0.33 ± 0.004 B
2.20 ± 0.043 B
≤0.3
≤5.0
According
to Codex Alimentarius [32]
Fatty acid composition (%)
Rapeseed oil
(low erucic acid)
2.5–7.0
Fatty Acid name
Rapeseed oil
Sunflower oil
Sunflower oil
Palmitic (C16:0)
Stearic (C18:0)
Oleic (C18:1)
Linoleic (C18:2)
Linolenic (C18:3)
Arachidic (C20:0)
Eicosenoic (C20:1)
Behenic (C22:0)
Erucic (C22:1)
4.9
1.6
66.4
17.1
6.5
0.6
1.5
5.7
3.2
25.4
60.9
0.2
0.4
0.2
5.0–7.6
2.7–6.5
14.0–39.4
48.3–74.0
ND–0.3
0.1–0.5
ND–0.3
0.3–1.5
ND–0.3
0.8–3.0
51.0–70.0
15.0–30.0
5.0–14.0
0.2–1.2
0.1–4.3
ND**–0.6
ND–2.0
0.3
0.7
0.6
0.1
Saturated Fatty
Acids
∑
7.4
9.9
3.5–11.8
51.1–76.3
20.0–44.0
8.1–16.1
14.0–40.0
48.3–74.3
(SFA)
∑
Monounsaturated
Fatty Acids
∑
68.6
23.6
25.7
61.1
(MUFA)
∑
Polyunsaturated
Fatty Acids
∑
(PUFA)
∑
* The values with the same letter in a row did not differ significantly (α = 0.05); ** ND–Not Detected.
The oxidation induction times of rapeseed and sunflower oils with or without the
addition of vanillyl hexanoate (0.01% or 0.1%) or BHT (0.01%) are shown in Table 4. Rape-
seed oil proved to be more stable (induction time = 4.49 h) than sunflower oil (induction
time = 2.73 h), due to the lower content of polyunsaturated fatty acids. The latter is charac-
terized by a high content of linoleic acid (60.9%), which is more susceptible to oxidation.

Biomolecules 2021, 11, 314
9 of 11
The addition of ester and BHT significantly extended the induction time of the tested oils.
Based on the induction times, protection factors were calculated (Table 4). Values greater
than 1 confirm the beneficial effect of the used antioxidants on the oxidative stability of
the oils. Vanillyl hexanoate in the concentration of 0.1% exhibited similar activity to BHT
and increased the induction time from 4.49 h to 5.28 h and from 2.73 h to 3.12 h in the
case of rapeseed and sunflower oils, respectively. In the case of the first oil, the statistical
significance of using a higher concentration of vanillyl hexanoate is also noticeable with
oxidation induction times of: 5.28 h and 4.90 h, as well as protection factors of 1.18 and 1.09
.
Table 4. Oxidation induction times [h] for rapeseed and sunflower oils with or without addition of vanillyl hexanoate
(0.01% or 0.1%) or BHT (0.01%) and calculated protection factors.
Rapeseed Oil
Induction Time (h) Protection Factor
Sunflower Oil
Induction Time (h)
Protection Factor
4.49 ± 0.08 A
4.90 ± 0.01 B
5.28 ± 0.17 C
5.22 ± 0.07 C
*
2.73 ± 0.08 A
2.89 ± 0.09 AB
3.12 ± 0.06 B
3.10 ± 0.09 B
Control
-
-
Vanillyl hexanoate 0.01%
Vanillyl hexanoate 0.1%
BHT 0.01%
1.09
1.18
1.16
1.06
1.14
1.14
* The values with the same letter in a column did not differ significantly (α = 0.05)
The enzymatic synthesis of lipophilic esters as antioxidants for oil stability applica-
tion was investigated by Buisman et al. [31] and Viklund et al. [33]. The first research
group used CALB to obtain octanoate esters of benzyl alcohol derivatives. Synthesized
3,4-dihydroxyphenethyl and 3,5-di-tert-butyl-4-hydroxybenzyl octanoates significantly
increased the induction time of sunflower oil [31]. In the case of Viklund et al. [33], enzy-
matically obtained palmitate and oleate esters of ascorbic acid showed antioxidant activity,
which was noticed by the lower values of PV in accelerated storage tests of rapeseed oil
incubated with ascorbyl fatty acid esters compared to the oil without addition.
The subject of using esters of phenolic compounds as lipophilic antioxidants was also
explored by Sørensen et al. [34,35]. In acid-catalyzed reactions, they obtained methyl, butyl,
octyl, dodecyl, hexadecyl, and eicosyl esters of ferulic [34] and caffeic acids [35], respectively.
Alkyl chain length in tested ferulates influenced fish oil-enriched milk oxidative stability.
Interestingly, the most efficient compound proved to be methyl ferulate, followed by ferulic
acid and its butyl ester. Elongation of the alkyl chain, in the case of dodecyl and octyl
ferulates, caused counterproductive effects and prooxidative effects were observed [34].
Similar conclusions were also reported with the use of caffeic acid esters in O/W emulsions.
They have shown that antioxidant efficiency was dependent on the presence of endogenous
tocopherol, the use of various emulsifiers, and the partitioning of the antioxidants in
different phases, as well as interactions between the aforementioned factors [35].
4. Conclusions
Looking at the problems faced by the modern world, including the food industry, bio-
transformation processes can be an interesting alternative to traditional chemical synthesis.
The current work presents the synthesis of aromatic alcohol esters by biocatalysis with
lipase B from C. antarctica. It was observed that the antioxidant activity of hexanoic acid
esters depends on the presence and position of the hydroxyl group in the aromatic ring.
One of the synthesized compounds—vanillyl hexanoate—could potentially be used as a
food additive with antioxidant properties. The addition of the mentioned ester significantly
extended the induction time of the tested oils from 4.49 to 5.28 h and from 2.73 to 3.12 h in
the case of rapeseed and sunflower oils, respectively. Phenolic compounds have known an-
tioxidant properties, but are characterized by low solubility in lipid matrices. Esterification
aimed at increasing their lipophilicity without losing their ability to neutralize free radicals.
It is worth continuing work on the use of the obtained esters to increase the oxidative
stability of food products subjected to various technological treatments or during storage.

Biomolecules 2021, 11, 314
10 of 11
Author Contributions: Conceptualization, B.Z. and E.B.-F.; methodology, B.Z., A.F., K.R., M.W.,
and E.B.-F.; formal analysis, B.Z.; investigation, B.Z., K.G., M.W., and K.R.; writing—original draft
preparation, B.Z.; writing—review and editing, B.Z., A.F., and E.B.-F.; visualization, B.Z., and
K.G.; supervision, A.F. and E.B.-F. All authors have read and agreed to the published version of
the manuscript.
Funding: This research received no external funding.
Institutional Review Board Statement: Not applicable.
Informed Consent Statement: Not applicable.
Data Availability Statement: The data presented in this study are available on request from the
corresponding author (B.Z.).
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
Rico-Campa, A.; Martinez-Gonzalez, M.A.; Alvarez-Alvarez, I.; de Deus Mendonca, R.; de la Fuente-Arrillaga, C.; Gomez-Donoso,
C.; Bes-Rastrollo, M. Association between consumption of ultra-processed foods and all cause mortality: SUN prospective cohort
study. BMJ 2019, 365, l1949. [CrossRef]
2.
3.
4.
5.
6.
7.
8.
9.
Carocho, M.; Barreiro, M.F.; Morales, P.; Ferreira, I.C.F.R. Adding Molecules to Food, Pros and Cons: A Review on Synthetic and
Natural Food Additives. Compr. Rev. Food Sci. Food Saf. 2014, 13, 377–399. [CrossRef]
Durazzo, A.; Lucarini, M.; Souto, E.B.; Cicala, C.; Caiazzo, E.; Izzo, A.A.; Novellino, E.; Santini, A. Polyphenols: A concise
overview on the chemistry, occurrence, and human health. Phytotherapy Research 2019, 33, 2221–2243. [CrossRef]
Białecka-Florjan´czyk, E.; Fabiszewska, A.; Zieniuk, B. Phenolic Acids Derivatives—Biotechnological Methods of Synthesis and
Bioactivity. Curr. Pharm. Biotechnol. 2018, 19, 1098–1113. [CrossRef]
Bravo, L. Polyphenols: Chemistry, dietary sources, metabolism, and nutritional significance. Nutr. Rev. 1998, 56, 317–333.
[CrossRef] [PubMed]
Nair, B. Final report on the safety assessment of Benzyl Alcohol, Benzoic Acid, and Sodium Benzoate. Int. J. Toxicol. 2001
20, 23–50.
,
Sá, A.G.A.; de Meneses, A.C.; Lerin, L.A.; de Araujo, P.H.H.; Sayer, C.; de Oliveira, D. Biocatalysis of aromatic benzyl-propionate
ester by different immobilized lipases. Bioprocess Biosyst. Eng. 2018, 41, 585–591. [CrossRef] [PubMed]
Tang, C.; Wu, B.; Wu, J.; Zhang, Z.; Yu, B. Novel Strategies Using Total Gastrodin and Gastrodigenin, or Total Gastrodigenin for
Quality Control of Gastrodia elata. Molecules 2018, 23, 270. [CrossRef]
Zieniuk, B.; Wołoszynowska, M.; Białecka-Florjan´czyk, E.; Fabiszewska, A. Synthesis of Industrially Useful Phenolic Compounds
Esters by Means of Biocatalysts Obtained Along with Waste Fish Oil Utilization. Sustainability 2020, 12, 5804. [CrossRef]
10. Zieniuk, B.; Wołoszynowska, M.; Białecka-Florjan´czyk, E.; Fabiszewska, A. Application of freeze-dried Yarrowia lipolytica biomass
in the synthesis of lipophilic antioxidants. Biotechnol. Lett. 2021, 43, 601–612. [CrossRef] [PubMed]
11. Zanetti, M.; Carniel, T.K.; Valerio, A.; de Oliveira, J.V.; de Oliveira, D.; de Araujo, P.H.H.; Riella, H.G.; Fiori, M.A. Synthesis of
geranyl cinnamate by lipase-catalyzed reaction and its evaluation as an antimicrobial agent. J. Chem. Technol. Biotechnol. 2017, 92,
115–121. [CrossRef]
12. Özyürek, M.; Güçlü, K.; Apak, R. The main and modified CUPRAC methods of antioxidant measurement. Trends Analyt. Chem.
2011, 30, 652–664. [CrossRef]
13. Ordoudi, S.; Tsimidou, M.Z. Crocin bleaching assay step by step: Observations and suggestions for an alternative validated
protocol. J. Agric. Food Chem. 2006, 54, 1663–1671. [CrossRef]
14. Ratusz, K.; Symoniuk, E.; Wroniak, M.; Rudzin´ska, M. Bioactive Compounds, Nutritional Quality and Oxidative Stability of
Cold-Pressed Camelina (Camelina sativa L.) Oils. Appl. Sci. 2018, 8, 2606. [CrossRef]
15. Symoniuk, E.; Ratusz, K.; Ostrowska-Lige˛za, E.; Krygier, K. Impact of Selected Chemical Characteristics of Cold-Pressed Oils on
their Oxidative Stability Determined Using the Rancimat and Pressure Differential Scanning Calorimetry Method. Food Anal.
Methods 2018, 11, 1095–1104. [CrossRef]
16. Fuentes, G.; Ballesteros, A.; Verma, C.S. Specificity in lipases: A computational study of transesterification of sucrose. Protein Sci.
2004, 13, 3092–3103. [CrossRef] [PubMed]
17. Otto, R.T.; Scheib, H.; Bornscheuer, U.T.; Pleiss, J.; Syldatk, C.; Schmid, R.D. Substrate specificity of lipase B from Candida
antarctica in the synthesis of arylaliphatic glycolipids. J. Mol. Catal. B. 2000, 8, 201–211. [CrossRef]
18. Noriega-Iribe, E.; Díaz-Rubio, L.; Estolano-Cobián, A.; Barajas-Carrillo, V.W.; Padrón, J.M.; Salazar-Aranda, R.; Díaz-Molina, R.;
García-González, V.; Chávez-Santoscoy, R.A.; Chávez, D.; et al. In Vitro and In Silico Screening of 2,4,5-Trisubstituted Imidazole
Derivatives as Potential Xanthine Oxidase and Acetylcholinesterase Inhibitors, Antioxidant, and Antiproliferative Agents. Appl.
Sci. 2020, 10, 2889. [CrossRef]
19. Dhiman, S.B.; Kamat, J.P.; Naik, D.B. Antioxidant activity and free radical scavenging reactions of hydroxybenzyl alcohols.
Biochemical and pulse radiolysis studies. Chem. Biol. Interact. 2009, 182, 119–127. [CrossRef] [PubMed]

Biomolecules 2021, 11, 314
11 of 11
20. Velika, B.; Kron, I. Antioxidant properties of benzoic acid derivatives against superoxide radical. Free Radic. Antioxid. 2012, 2,
62–67. [CrossRef]
21. Mansouri, A.; Makris, D.P.; Kefalas, P. Determination of hydrogen peroxide scavenging activity of cinnamic and benzoic acids
employing a highly sensitive peroxyoxalate chemiluminescence-based assay: Structure–activity relationships. J. Pharm. Biomed.
2005, 39, 22–26. [CrossRef]
22. Farhoosh, R.; Johnny, S.; Asnaashari, M.; Molaahmadibahraseman, N.; Sharif, A. Structure-antioxidant activity relationships of
o-hydroxyl, o-methoxy, and alkyl ester derivatives of p-hydroxybenzoic acid. Food Chem. 2016, 194, 128–134. [CrossRef] [PubMed]
23. Natalia, A.; Kim, S.; Kim, H.K. Antioxidant and antibacterial activity of fatty acid vanillyl ester produced by Proteus vulgaris K80
lipase-mediated transesterification. J. Mol. Catal. B. 2016, 133, S475–S481. [CrossRef]
24. Park, C.G.; Kim, J.J.; Kim, H.K. Lipase-mediated synthesis of ricinoleic acid vanillyl ester and evaluation of antioxidant and
antibacterial activity. Enzyme Microb. Technol. 2020, 133, 109454. [CrossRef] [PubMed]
25. Roleira, F.M.F.; Siquet, C.; Orru, E.; Garrido, E.M.; Garrido, J.; Milhazes, N.; Podda, G.; Paiva-Martins, F.; Reis, S.; Carvalho, R.A.;
et al. Lipophilic phenolic antioxidants: Correlation between antioxidant profile, partition coefficients and redox properties. Bioorg.
Med. Chem. 2010, 18, 5816–5825. [CrossRef]
26. Gaspar, A.; Martins, M.; Silva, P.; Garrido, E.M.; Garrido, J.; Firuzi, O.; Miri, R.; Saso, L.; Borges, F. Dietary Phenolic Acids
and Derivatives. Evaluation of the Antioxidant Activity of Sinapic Acid and Its Alkyl Esters. J. Agric. Food Chem. 2010, 58,
11273–11280. [CrossRef]
27. Ordoudi, S.A.; Tsimidou, M.Z. Measuring Antioxidant and Prooxidant Capacity Using the Crocin Bleaching Assay (CBA). In
Advanced Protocols in Oxidative Stress III; Methods in Molecular Biology Vol. 1208; Armstrong, D., Ed.; Springer Science+Business
Media: New York, NY, USA, 2015; pp. 329–344.
28. Granato, D.; Shahidi, F.; Wrolstad, R.; Kilmartin, P.; Melton, L.D.; Hidalgo, F.J.; Elmore, S. Antioxidant activity, total phenolics and
flavonoids contents: Should we ban in vitro screening methods? Food Chem. 2018, 264, 471–475. [CrossRef]
29. Apak, R.; Gorinstein, S.; Bohm, V.; Schaich, K.M.; Özyürek, M.; Güçlü, K. Methods of measurements and evaluation of natural
antioxidant capacity/activity. Pure Appl. Chem. 2013, 85, 957–998. [CrossRef]
30. Gülcin, I. Antioxidant activity of food constituents: An overview. Arch. Toxicol. 2012, 86, 345–391. [CrossRef]
31. Buisman, G.; Van Helteren, C.; Kramer, G.; Valdsink, J.; Derksen, J.; Cuperus, F. Enzymatic esterifications of functionalized
phenols for the synthesis of lipophilic antioxidants. Biotechnol. Lett. 1998, 20, 131–136. [CrossRef]
32. Codex Standard for Named Vegetable Oils (CODEX-STAN 210 - 1999). Available online: http://www.fao.org/3/y2774e/y2774e0
4.htm (accessed on 5 February 2021).
33. Viklund, F.; Alande, J.; Hult, K. Antioxidative Properties and Enzymatic Synthesis of Ascorbyl FA Esters. J. Am. Oil Chem. Soc.
2003, 80, 795–799. [CrossRef]
34. Sørensen, A.D.M.; Lyneborg, K.S.; Villeneuve, P.; Jacobsen, C. Alkyl chain length impacts the antioxidative effect of lipophilized
ferulic acid in fish oil enriched milk. J. Funct. Foods 2015, 18, 959–967. [CrossRef]
35. Sørensen, A.D.M.; Villeneuve, P.; Jacobsen, C. Alkyl caffeates as antioxidants in O/W emulsion: Impact of emulsifier type and
endogenous tocopherols. Eur. J. Lipid Sci. Technol. 2017, 119, 1600276. [CrossRef]
