NEW SYNTHESIS OF NAPHTHO- AND BENZOXAZOLES:
DECOMPOSITION OF NAPHTHO- AND
BENZOXAZINONES WITH KOH
Claudio Saitz a , Hernán Rodríguez a , Amelia Márquez a , Alvaro Cañete a , Carolina
Jullian a & Antonio Zanocco a
a Departamento de Química Orgánica y Físico-Química , Facultad de Ciencias Químicas y
Farmaceúticas Universidad de Chile , Casilla 233, Santiago, 1, Chile
Published online: 09 Nov 2006.
To cite this article: Claudio Saitz , Hernán Rodríguez , Amelia Márquez , Alvaro Cañete , Carolina Jullian & Antonio
Zanocco (2001) NEW SYNTHESIS OF NAPHTHO- AND BENZOXAZOLES: DECOMPOSITION OF NAPHTHO- AND BENZOXAZINONES
WITH KOH, Synthetic Communications: An International Journal for Rapid Communication of Synthetic Organic Chemistry,
31:1, 135-140, DOI: 10.1081/SCC-100000190
To link to this article: http://dx.doi.org/10.1081/SCC-100000190
PLEASE SCROLL DOWN FOR ARTICLE
Taylor & Francis makes every effort to ensure the accuracy of all the information (the “Content”) contained
in the publications on our platform. However, Taylor & Francis, our agents, and our licensors make no
representations or warranties whatsoever as to the accuracy, completeness, or suitability for any purpose of
the Content. Any opinions and views expressed in this publication are the opinions and views of the authors,
and are not the views of or endorsed by Taylor & Francis. The accuracy of the Content should not be relied
upon and should be independently verified with primary sources of information. Taylor and Francis shall
not be liable for any losses, actions, claims, proceedings, demands, costs, expenses, damages, and other
liabilities whatsoever or howsoever caused arising directly or indirectly in connection with, in relation to or
arising out of the use of the Content.
This article may be used for research, teaching, and private study purposes. Any substantial or systematic
reproduction, redistribution, reselling, loan, sub-licensing, systematic supply, or distribution in any
form to anyone is expressly forbidden. Terms & Conditions of access and use can be found at http://
www.tandfonline.com/page/terms-and-conditions

SYNTHETIC COMMUNICATIONS, 31(1), 135–140 (2001)
NEW SYNTHESIS OF NAPHTHO- AND
BENZOXAZOLES: DECOMPOSITION OF
NAPHTHO- AND BENZOXAZINONES
WITH KOH
Claudio Saitz,∗ Herna´n Rodr´ıguez, Amelia Ma´rquez,
Alvaro Can˜ete, Carolina Jullian, and Antonio Zanocco
Departamento de Qu´ımica Orga´nica y F´ısico-Qu´ımica,
Facultad de Ciencias Qu´ımicas y Farmaceu´ticas,
Universidad de Chile, Casilla 233, Santiago 1, Chile
ABSTRACT
A method that allows the synthesis of 4 different heterocyclic
systemsoffusedaryloxazoles, i.e., naphtho[1,2-d], naphtho[2,1-d],
naphtho[2,3-d], and benzo[d]oxazoles in reasonable yield is de-
scribed. This method consists of the decomposition of naphtho-
and benzoxazinones with KOH.
Benzoxazoleshave been obtained by heating o-aminophenolsand carboxylic
acids in the presence of polyphosphoric acid (1,2). The novel antibacterial agent
Boxazomicyn B has been synthesized by this method (3). Other options are the
Beckmann rearrangement of o-acylphenol oximes using zeolite catalysts (4) and,
morerecently, treatmentofN,O-diacylated2-aminophenolswithp-toluenesulfonic
acid under reflux in xylenes or toluene (5), or oxidative intramolecular cyclization
∗ To whom correspondence should be addressed. Fax: 562-678 2868; E-mail: clsaitz@
ll.ciq.uchile.cl
135
Copyright ꢀ 2001 by Marcel Dekker, Inc.
www.dekker.com
C

ORDER
REPRINTS
136
SAITZ ET AL.
of phenolic Schiffs bases using iodobenzene diacetate as an oxidant (6), or man-
ganese triacetate, a relatively benign oxidizing reagent (7). On the other hand,
naphthoxazoles have been obtained, by cycloaddition of azomethine ylides (from
thermal cleavage of aziridines) to 1-nitroso-2-naphthol (8,9); by treatment of an
equimolecular mixture of 1-nitroso-2-naphthol and phenacyl piridinium bromide
with NaOH solution at −30◦C (10); by cycloaddition of masked azomethine ylide,
generated from 2-p-methoxyphenyl-4-phenyl-2-oxazolin-5-one, with 1-nitroso-2-
naphthol (11), and by reaction of 1,3-dipole, proceeding from 3-aroyl aziridines
cleavage, with 2-nitroso-1-naphthol. In this last reaction, naphthodiazepine is ob-
tained besides naphthoxazole (12). Some methods to obtain either benzo- or naph-
thoxazoles have been described: palladium-catalyzed condensation of aryl halides
with o-amino phenols or naphthols, followed by dehydrative cyclization (13); and
cycloadditionofo-hydroxyanilidesbyheatingwithaqueousHClat150◦C, (anilide
can be prepared in situ heating the corresponding o-substituted aniline with car-
boxylic acid, anhydride or acid chloride (14)). As an example, the benzoxazole
ringoftheantibioticCalcymicin(15)andtheanti-inflammatoryBenoxaprofen(16)
have been obtained by these methods. Reduction of the suitable 2-nitrophenyl, 2-
nitro-1-naphthyl or 1-nitro-2-naphthyl-benzoates or 4-nitrobenzoates with Sn-HCl
(17) is another suitable method, and 2-arylnaphtho[1,2-d]oxazoles have been pre-
pared by condensation of 1-amino-2-naphthol derivatives with aromatic aldehydes
in the presence of pyridine in BuOH (18).
Most of the existing methods referred to above consist of oxidative reactions
using uncommon oxidizing reagents, or they are cycloaddition reactions where
more than one product is obtained. The importance of the method we describe
lies on the easy and rapid way that these heterocyclic system are available. Both
substrate and product are heterocycles, the last readily obtained by decomposition
of the first.
In this work, the transformation of 2-phenyl-3H-naphtho[2,1-b][1,4]-
oxazin-3-one (1), 3-phenyl-2H-naphtho[1,2-b][1,4]oxazin-2-one (2), 3-phenyl-
2H-naphtho[2,3-b][1,4]-oxazin-2-one (3), and 3-phenyl-2H-benzo[b][1,4]oxazin-
2-one (4) on heating with KOH in MeOH to their corresponding naphtho- and
benzoxazoles: 2-phenylnaphtho[1,2-d]oxazole (5), 2-phenylnaphtho[2,1-
d]oxazole (6), 2-phenyl naphtho[2,3-d]oxazole (7) and 2-phenylbenzo[d]oxazole
(8), is described (Scheme 1).
Scheme 1.

ORDER
REPRINTS
NAPHTHO- AND BENZOXAZOLES
137
Table 1. Conversion of Aryl Oxazinones 1–4 into Aryloxazoles 5–8
Substrate Product Yield (%)
Entry
The oxazinones 1–4 were obtained, in satisfactory yields through a modifica-
tion of the Moffet’s method (19), which heats at 120◦C for 1.5 h an equimolecular
mixture of the respective o-aminophenol and -naphthol or their chlorohydrate with
the corresponding α-keto ester in pyridine as solvent.
We herein describe a rapid method that allows the synthesis of four differ-
ent heterocyclic systems of fused aryl oxazoles: naphtho[1,2-d]; naphtho[2,1-d];
naphtho[2,3-d]; and benzo[d]oxazoles in reasonable yields (Table 1), thus com-
plementing the existing methods to obtain these heterocyclic systems.
EXPERIMENTAL
Melting points were determined on a hot-stage apparatus and are
uncorrected. Spectra were recorded using the following instruments: IR, FT-IR
1
Bruker IFS 55; UV, ATI-UNICAM; H and 13C-NMR, Bruker DRX-300 (300
and 75 MHz), using tetramethylsilane as internal reference. Microanalyses were

ORDER
REPRINTS
138
SAITZ ET AL.
determinated using Fisons EA 1108 analizer and were performed in CEPEDEQ
(Centro Para el Desarrollo de la Qu´ımica), Facultad de Ciencias Qu´ımicas y Far-
maceu´ticas, Universidad de Chile. Column chromatography was performed on
Merck silica gel 60, 230–400 mesh, and TLC- on Merck silica gel G.
General Procedure for Preparation of Naphtho- and
Benzoxazinones 1 to 4
A Modification of the Moffet’s Method
The required o-aminophenol and -naphthol, or their chlorohydrate and
methyl benzoyl formate, were mixed in pyridine as solvent under nitrogen and
the mixture was heated at 120◦C during 1.5–2 h. After this time, the reaction mix-
ture was poured into ice water. The precipitate was collected by filtration, washed
with water, and purified by column chromatography (chloroform) on silica gel.
All compounds gave satisfactory spectroscopic and analytical data. Rep-
resentative data for select compounds follows. Compounds 1 and 5 were fully
characterized by concerted use of one- and two-dimensional NMR techniques in
our previous paper (20).
2-Phenyl-3H-naphto[2,1-b] l,4-oxazin-3-one (1) was obtained in 95%
yield (crude) and 71% (purified). Recrystallization from carbon tetrachloride gave
yellow pales m.p 174◦–175◦C. Lit.19177◦–178◦C.1H NMR (CDCl3) δ: 8.86 (d, Jd
8.3 Hz, 1H), 8.53 (m, 2H), 7.93 (d, Jd 8.78 Hz, 1H), 7.86 (d, Jd 8.78 Hz, 1H),
7.71 (d, Jd 8.78 Hz,1H), 7.58 (dd, 1H), 7.55 (m, 3H), 7.39 (d, Jd 9.0 Hz,1H), 13
C
NMR (CDCl3) δ: 152.67, 148.28, 144.22, 134.50, 132.35, 131.31, 131.02, 130.45,
129.48, 128.40, 128.22, 128.03, 126.67, 126.30, 122.84, 115.64.
3-Phenyl-2H-naphto[1,2-b] l,4-oxazin-2-one (2) was obtained in 85%
yield (crude). Recrystallization from carbon tetrachloride gave yellow pales m.p.
166◦–167◦C 1H NMR (CDCl3) δ: 8.48 (m, 2H), 8.42 (m, 2H), 7.89 (m, 1H), 7.83
(d, Jd 8.78 Hz, 1H), 7.77 (d,Jd 8.81 Hz, 1H), 7.65 (m, 2H), 7.53 (m, 3H). 13C
NMR (CDCl3) δ: 152.41, 150.04, 142.62, 134.35, 134.26, 131.34, 129.34, 128.72,
128.43, 128.02, 127.90, 127.30, 125.63, 125.46, 126.30, 122.55, 122.13, 115.65.
IR (Kbr) ν/cm−1: 1724 (C O), 1639 (C N). Anal. Calcd. for C18H11NO2: C,
79.11; H, 4.06; N, 5.13. Found: C, 79.04; H, 4.06; N, 5.21.
==
==
3-Phenyl-2H-naphtho[2,3-d] l,4-oxazin-2-one (3) was obtained in 60%
yield (crude). Recrystallization from acetonitrile gave yellow pales m.p. 201◦–
203◦C. 1H NMR (CDCl3) δ: 8.37 (m, 2H), 8,34 (s,1H), 8.12 (d, Jd 7.93 Hz; 1H),
7.88 (d, Jd 7.96 Hz, 1H), 7.67 (s, 1H), 7.56 (m, 5H). 13CNMR (CDCl3) δ: 152.15,
151.02, 144.20, 134.24, 139.95, 131.48, 130.95, 130.82, 129.57, 129.21, 128.87,

ORDER
REPRINTS
NAPHTHO- AND BENZOXAZOLES
139
128.44, 128.41, 127.41, 126.03, 125.89, 112.27. IR (Kbr) ν/cm−1: 1724 (C O),
==
==
1639 (C N). Anal. Calcd. for C18H11NO2: C, 79.11; H, 4.06; N, 5.13. Found: C,
78.99; H, 4.03; N, 5.40.
3-Phenyl–2H-benzo[d]-l,4-oxazin-2-one (4) was obtained in 85% yield.
Recrystallization from methanol gave light yellow pales m.p. 118–119◦C 1H NMR
(CDCl3) δ: 8.34 (dd, Jd S. 17; Jd 2.09 Hz, 2H), 7.85 (dd, Jd 7.90; Jd 1.55 Hz, 1H),
7.52 (m, 4H), 7.39 (td, J 7.70; J 7.62; J 1.30 Hz, 1H); 7.33 (dd, Jd 8.17; Jd 1.25 Hz,
1H). 13C NMR (CDCl3) δ: 152.26, 150.85, 146.47, 134.13, 131.66, 131.41, 131.11,
129.44, 128.37, 125.87, 116.16.
Typical Procedure for Transformation of Naphtho- and
Benzoxazinones in Naphtho- and Benzoxazoles 5 to 8
-Phenyl-3H-naphtho[2,1-b] l,4-oxazinone (40 mg, 0.146 mmol) and 10%
KOH solution (2mL) were refluxed in MeOH for 30 min. Immediately, the so-
lution became an intense brownish red. The mixture was left overnight and then
neutralizad with acetic acid (10%). The precipitate was collected by filtration,
washed with water, and purified by column choromatography (chloroform) on
silica gel.
2-Phenylnaphtho[1,2-d]oxazole (5) Recrystallization from ligroin gave
whiteneedles, m.p. 122◦–123◦C. Lit. (9)125◦–130◦C, Lit. (21)131◦C. SeeAbbady
(21) for synthesis of 5; however, nmr data were not reported. 1H-RMN (CDCl3) δ
8.63 (d, Jd 8.20 Hz, 1H), 8.37 (m, 2H), 8.01 (d, Jd 8.20 Hz, 1H), 7.84 (d, Jd 8.90 Hz,
1H), 7.76 (d, Jd 8.90 Hz, 1H), 7.71 (m, 1H), 7.58 (m, 4H). 13C-RMN (CDCl3) δ:
162.25, 148.09, 137.66, 130.96, 128.80, 128.48, 127.48, 127.27, 126.87, 126.64,
125.91, 125.27, 122.21, 110.53.
2-Phenylnaphtho[2,1-d]oxazole (6) m.p. 122◦C. 1H-RMN (CDCl3) δ: 8.30
(m, 3H), 7.96 (d, Jd 8.24 Hz, 1H), 7.91 (d, Jd 8.73 Hz, 1H), 7.78 (d, Jd 8.74 Hz, IH),
7.63 (td, J 9.0; J 9,0; J 1.14 Hz, 1H) (m, 1H), 7.54 (m, 4H). 13C-RMN (CDCl3)
δ: 162.43, 146.45, 138.60, 131.7, 131.14, 128.92, 128.68, 127.41, 127.29, 126.82,
125.62, 125.40, 125.03, 124.51, 119.98, 110.53.
2-Phenylnaphtho[2,3-d]oxazole (7) m.p. 203◦–205◦C. 1H-RMN (CDCl3)
δ: 8.34 (m, 2H), 8.20 (s, 1H), 7.99 (m, 2H), 7.95 (s, 1H), 7.55 (m, 3H), 7.49
(m, 2H). 13C-RMN (CDCl3) δ: 165.04, 149.73, 142.07, 132.08, 131.77, 131.56,
128.97, 128.53, 128.14, 127.91, 126.96, 125.47, 124.69, 117.33, 106.35.
1
2-Phenylbenzo [d]oxazole (8) m.p. 100◦–102◦C Lit (7) 101◦C. H-RMN
(CDCl3) δ: 8.24 (m, 2H), 7.77 (m, 1H), 7.54 (m, 1H), 7.49 (m, 3H), 7.32 (m, 2H).
13C-RMN (CDCl3,) δ: 162.96, 150.71, 142.10, 131.43, 128.83, 127.57, 127.14,
125.03, 124.51, 119.98, 110.53.

ORDER
REPRINTS
140
SAITZ ET AL.
ACKNOWLEDGMENTS
We thank the FONDECYT, Project 1940446 and DTI, Project Q 3336-
9323 Universidad de Chile, for the financial support and CEPEDEQ for use of
instruments. A. Can˜ete thanks CONICYT for a fellowship.
REFERENCES AND NOTES
1. Hein, L.D.; Alheim, R.J., Leavitt, J.J. J. Am. Chem. Soc. 1957, 79, 427.
2. Ying-Hung, So; Heeschen, J.P. J. Org. Chem. 1997, 62, 3552.
3. Suto, M.J.; Turner, W.R. Tetrahedr. Lett. 1995, 36, 7213.
4. Bhawal, B.M.; Mayabhate, S.P.; Likhite, A.P.; Deshmukh, A.R.A.S. Syn-
thetic Commun. 1995, 25, 3315.
5. De Luca, M.R.; Kerwin, S.M. Tetrahedron 1997, 53, 457.
6. Varma, R.S.; Saini, R.K.; Prakash, O. Tetrahedr. Lett. 1997, 38, 2621.
7. Varma, R.S.; Kumar D. J. Heterocyclic Chem. 1998, 35, 1539.
8. Lown, J.W.; Moser, J.P. J. Chem. Soc. Chem. Commun. 1970, 247.
9. Lown, J.W.; Moser, J.P. Can. J. Chem. 1970, 48, 2227.
10. Krohnke, F. Angew. Chem. Int. Ed. Engl. 1963, 2, 380.
11. Saitz, C.; Can˜ete, A.; Ma´rquez, A.; Mun˜oz, L.; Rodr´ıguez, H. Bol. Soc. Chil.
Qu´ım. 1996, 41, 295.
12. Lown, J.W.; Moser, J.P. Tetrahedron 1970, 3019.
13. Perry, R.J.; Wilson, B.D.; Miller, R.J. J. Org. Chem. 1992, 57, 2883.
14. Katritzky, A.R. Handbook of Heterocyclic Chemistry; Pergamon Press:
Oxford, 1985; 468–469.
15. Evans, D.A.; Sacks, C.E.; Kleschick, W.A.; Taber, T.R. J. Am. Chem. Soc.
1979, 101, 6789.
16. Dunwell, D.W.; Evans, D.; Hicks, T.A.; Cashin, C.H.; Kitchen, A. J. Med.
Chem. 1975, 18, 53.
17. Marghlani, Y.A.M.; Metwally, S.A.M.; Mahmoud, A.M.; Osman, A.M. Pak.
J. Sci. Ind. Res. 1980, 23, 166.
18. Osman, L.A.M.; Mohamed, S.A.; Mahmoud, A.M. Egypt. J. Chem. 1973,
27.
19. Moffett, R.B. J. Med. Chem. 1966, 9, 475.
20. Marquez, A.;Saitz, C.;Can˜ete, A.;Rodr´ıguez, H.;Jullian, C. Mag. Resonance
in Chem. 1998, 36, 439.
21. Abbady, M.A. Indian J. Chem. 1979, 17B, 450.
Received April 6, 2000

Request Permission or Order Reprints Instantly!
Interested in copying and sharing this article? In most cases, U.S. Copyright
Law requires that you get permission from the article’s rightsholder before
using copyrighted content.
All information and materials found in this article, including but not limited
to text, trademarks, patents, logos, graphics and images (the "Materials"), are
the copyrighted works and other forms of intellectual property of Marcel
Dekker, Inc., or its licensors. All rights not expressly granted are reserved.
Get permission to lawfully reproduce and distribute the Materials or order
reprints quickly and painlessly. Simply click on the "Request
Permission/Reprints Here" link below and follow the instructions. Visit the
U.S. Copyright Office for information on Fair Use limitations of U.S.
copyright law. Please refer to The Association of American Publishers’
(AAP) website for guidelines on Fair Use in the Classroom.
The Materials are for your personal use only and cannot be reformatted,
reposted, resold or distributed by electronic means or otherwise without
permission from Marcel Dekker, Inc. Marcel Dekker, Inc. grants you the
limited right to display the Materials only on your personal computer or
personal wireless device, and to copy and download single copies of such
Materials provided that any copyright, trademark or other notice appearing
on such Materials is also retained by, displayed, copied or downloaded as
part of the Materials and is not removed or obscured, and provided you do
not edit, modify, alter or enhance the Materials. Please refer to our Website
User Agreement for more details.
Order now!
Reprints of this article can also be ordered at
http://www.dekker.com/servlet/product/DOI/101081SCC100000190
