T. Iwasawa et al. / Tetrahedron Letters 49 (2008) 7430–7433
14. Miura, M. Angew. Chem., Int. Ed. 2004, 43, 2201–2203.
7433
(d) Kastler, M.; Schmidt, J.; Pisula, W.; Sebastiani, D.; Müllen, K. J. Am. Chem.
Soc. 2006, 128, 9528–9534; (e) Pisula, W.; Menon, A.; Stepputat, M.;
Lieberwirth, I.; Kolb, U.; Tracz, A.; Sirringhaus, H.; Pakula, T.; Müllen, K. Adv.
Mater. 2005, 17, 684–689; (f) Simpson, C. D.; Wu, J.; Watson, M. D.; Müllen, K. J.
Mater. Chem. 2004, 14, 494–504; (g) Lee, M.; Kim, J.-W.; Peleshanko, S.; Larson,
K.; Yoo, Y.-S.; Vankin, D.; Markutsya, S.; Tsukruk, V. V. J. Am. Chem. Soc. 2002,
124, 9121–9128; (h) Van de Craats, A. M.; Warman, J. M.; Fechtenkötter, A.;
Brand, J. D.; Harbison, M. A.; Müllen, K. Adv. Mater. 1999, 11, 1469–1472; (i)
Adam, D.; Schuhmacher, P.; Simmerer, J.; Siemensmeyer, L.; Häussling, K.;
Etzbach, K. H.; Ringsdorf, H.; Haarer, D. Nature 1994, 371, 141–143.
5. (a) Tokunaga, M.; Harada, S.; Iwasawa, T.; Obora, Y.; Tsuji, Y. Tetrahedron Lett.
2007, 48, 6860–6862; (b) Iwasawa, T.; Komano, T.; Tajima, A.; Tokunaga, M.;
Obora, Y.; Tsuji, Y. Organometallics 2006, 25, 4665–4669; (c) Aoyama, H.;
Tokunaga, M.; Kiyosu, J.; Iwasawa, T.; Obora, Y.; Tsuji, Y. J. Am. Chem. Soc. 2005,
127, 10474–10475; (d) Komano, T.; Iwasawa, T.; Tokunaga, M.; Obora, Y.; Tsuji,
Y. Org. Lett. 2005, 7, 4677–4679; (e) Iwasawa, T.; Tokunaga, M.; Obora, Y.; Tsuji,
Y. J. Am. Chem. Soc. 2004, 126, 6554–6555.
15. Riihimaki, H.; Suomalainen, P.; Reinius, H. K.; Suutari, J.; Jaaskelainen, S.;
Klause, A. O. I.; Pakkanen, T. A.; Pursiainen, J. T. J. Mol. Catal. A: Chem. 2003, 200,
69–79.
16. Representative experimental procedure for Table 1, entry 7: KF (3.49 g, 60 mmol)
was dried in vacuo in a 50 mL flask with heating (heat gun), then o-tolylboronic
acid (3.27 g, 24 mmol), Pd2(dba)3ꢁCHCl3 (2.6 mg, 0.0025 mmol), and phosphine
3 (4.6 mg, 0.006 mmol) were added. The whole system was evacuated and
backfilled with argon three times, and the THF solution of 2-chloro-1,3-
dimethylbenzene (2.7 M, 10 mL) was added. The reaction mixture was stirred
at room temperature for 10 min, and then conducted in refluxing THF for 23 h.
After the reaction, the mixture was diluted with EtOAc, and was filtered.
Purification by silica gel column chromatography (hexane/CHCl3 = 4:1)
quantitatively afforded a desired biaryl5b (4.24 g) as a colorless oil. 1H NMR
(400 MHz, CDCl3) 7.41–7.33 (m, 3H), 7.30–7.21 (m, 3H), 7.16–7.13 (m, 1H),
2.10 (s, 3H), 2.08 (s, 6H). MS (EI) m/z: 196 (M+).
17. The P/Pd = 1.2, 2.0 and 3.0 in the reaction condition of Table 1 at entry 1 gave
the 2,20,6-trimethylbiphenyl in 92%, 86%, and 87% yields, respectively. The ratio
of 1.2 was used from the viewpoint of reaction efficiency.
6. Ito, S.; Wehmeier, M.; Brand, J. D.; Kübel, C.; Epsch, R.; Rabe, J. P.; Müllen, K.
Chem. Eur. J. 2000, 6, 4327–4342.
7. Li, D.; Kaner, R. B. Science 2008, 320, 1170–1171.
8. Iwasawa, T.; Kamei, T.; Hama, K.; Nishimoto, Y.; Nishiuchi, M.; Kawamura, Y.
Tetrahedron Lett. 2008, 49, 5244–5246.
9. Becht, J.-M.; Ngouela, S.; Wagner, A.; Mioskowski, C. Tetrahedron 2004, 60,
6853–6857.
18. Representative experimental procedure for Table 2, entry 7: KF (697 mg,
12 mmol) was dried in vacuo in a 25 mL flask with heating (heat gun), then
o-tolylboronic acid (816 mg, 6 mmol), Pd2(dba)3ꢁCHCl3 (2.6 mg, 0.0025 mmol),
and phosphine 3 (4.6 mg, 0.006 mmol) were added. The whole system was
evacuated and backfilled with argon three times, and the THF solution of 2-
chloro-3-methoxybenzaldehyde (0.8 M, 10 mL) was added. The reaction
mixture was stirred at room temperature for 10 min, and then conducted in
refluxing THF for 13 h. After the reaction, the mixture was diluted with EtOAc,
and was filtered. Purification by silica gel column chromatography (hexane/
10. For reviews on Suzuki–Miyaura coupling reaction see: (a) Martin, R.;
Molander, G. A.; Ellis, N. Acc. Chem. Res. 2007, 40, 275–286; (c) Bellina, F.;
Carpita, A.; Rossi, R. Synthesis 2004, 15, 2419–2440; (d) Kotha, S.; Lahiri, K.;
Kashinath, D. Tetrahedron 2002, 58, 9633–9695; (e) Hassan, J.; Sevignon, M.;
Gozzi, C.; Schulz, E.; Lemaire, M. Chem. Rev. 2002, 102, 1359–1470; (f) Miyaura,
N. Top. Curr. Chem. 2002, 219, 11–59; (g) Littke, A. F.; Fu, G. C. Angew. Chem., Int.
Ed. 2002, 41, 4176–4211; (h) Suzuki, A. J. Organomet. Chem. 1999, 576, 147–
168; (i) Miyaura, N.. In Advances in Metal-Organic Chemistry; Liebeskind, L. S.,
Ed.; JAI: London, 1998; Vol. 6, pp 187–243; (j) Suzuki, A. In Metal-Catalyzed
Cross-Coupling Reactions; Diederich, F., Stang, P. J., Eds.; Wiley-VCH: New York,
1998; Chapter 2; (k) Miyaura, N.; Suzuki, A. Chem. Rev. 1995, 95, 2457–2483.
11. (a) Hoshi, T.; Nakazawa, T.; Saitoh, I.; Mori, A.; Suzuki, T.; Sakai, J.; Hagiwara, H.
Org. Lett. 2008, 10, 2063–2066; (b) Özdemir, I.; Demir, S.; Çetinkaya, B.
Tetrahedron 2005, 61, 9791–9798; (c) Song, C.; Ma, Y.; Chai, Q.; Ma, C.; Jiang,
W.; Andrus, M. B. Tetrahedron 2005, 61, 7438–7446; (d) Kwong, F. Y.; Chan, K.
S.; Yeung, C. H.; Chan, A. S. C. Chem. Commun. 2004, 2336–2337; (e) Walker, S.
D.; Barder, T. E.; Martineli, J. R.; Buchwald, S. L. Angew. Chem., Int. Ed. 2004, 43,
1871–1876.
CHCl3 = 4:1) quantitatively afforded
a
desired biaryl23 (1.15 g) as white
needles. 1H NMR (400 MHz, CDCl3) d 9.62 (s, 1H), 7.63 (d, J = 7.8 Hz, 1H),
7.47 (dd, J = 7.8 Hz, 7.8 Hz, 1H), 7.35–7.24 (m, 3H), 7.21–7.19 (m, 1H), 7.14–
7.12 (m, 1H), 3.78 (s, 3H), 2.07 (s, 3H). 13C NMR (100 MHz, CDCl3) d 192.5,
157.2, 137.4, 135.3, 134.8, 133.3, 131.0, 130.0, 129.0, 128.4, 125.6, 119.1, 116.1,
56.1, 20.2. MS (EI) m/z: 226 (M+, 100%).
19. (a) Mizoroki, T.; Mori, K.; Ozaki, A. Bull. Chem. Soc. Jpn. 1971, 44, 581; (b) Heck,
R. F.; Nolley, J. P., Jr. J. Org. Chem. 1972, 37, 2320–2322; (c) Heck, R. F. Org. React.
1982, 27, 345–390; (d) Beletskaya, I. P.; Cheprakov, A. V. Chem. Rev. 2000, 100,
3009–3066.
20. (a) Littke, A. F.; Fu, G. C. J. Am. Chem. Soc. 2001, 123, 6989–7000; (b) Littke, A. F.;
Fu, G. C. J. Org. Chem. 1999, 64, 10–11.
21. Representative experimental procedure for Table 3, entry 1: Cs2CO3 (358 mg,
1.1 mmol) was dried in vacuo in a 20 mL Schlenk tube with heating (heat gun),
and to the flask were added Pd2(dba)3ꢁCHCl3 (15.5 mg, 0.015 mmol) and
phosphine 3 (27.9 mg, 0.036 mmol). The whole system was evacuated and
backfilled with argon three times, and the 1,4-dioxane (1 mL) and p-
chlorotoluene (0.118 mL, 1 mmol) were added. The mixture was conducted
at 75 °C (bath temperature) for 5 min, and methyl acrylate (0.18 mL, 2 mmol)
was added. The reaction was carried out at 120 °C (bath temperature) for 16 h.
After the reaction, the mixture was diluted with Et2O, and was filtered.
Purification by silica gel column chromatography (hexane/CHCl3 = 4:1)
afforded methyl (E)-p-methylcinnamate24 in 50% yield (88 mg) as white
12. Synthetic procedure for the phosphine 3: To a solution of 2 (668 mg, 1 mmol) in
THF (12 mL) at –78 °C was added n-BuLi (1.2 mmol, 1.6 M in hexane) dropwise
over 5 min, and the mixture was stirred for 2 h. ClPPh2 (0.22 mL, 1.2 mmol)
was slowly added, and the reaction mixture was allowed to warm to room
temperature. After stirring for 18 h, the solvent was evaporated, and the
residue was dissolved in CHCl3, washed with brine, and dried over Na2SO4.
Purification by silica gel column chromatography (hexane/CHCl3 = 4:1)
quantitatively afforded
3
(787 mg) as white solid materials. 1H NMR
(400 MHz, CDCl3) d 7.28–7.16 (m, 6H), 7.13–7.10 (m, 1H), 7.01–6.90 (m, 5H),
6.85–6.79 (m, 5H), 6.75–6.58 (m, 14H), 6.42 (dd, J = 7.8 Hz, 7.8 Hz, 1H), 6.33 (d,
J = 7.8 Hz, 1H), 6.24 (dd, J = 7.8 Hz, 15.1 Hz, 2H), 2.11 (s, 3H), 2.08 (s, 3H), 2.07
(br s, 3H ꢂ 2). 13C NMR (100 MHz, CDCl3) d 148.2, 147.9, 141.0, 140.9, 140.6,
140.44, 140.37, 139.23, 139.18, 138.8, 138.7, 138.6, 138.4, 138.23, 138.20,
138.1, 137.6, 136.1, 136.0, 135.0, 134.7, 134.3, 134.11, 134.09, 133.9, 133.7,
133.5, 132.5, 132.3, 132.2, 131.9, 131.7, 131.3, 131.1, 128.3, 128.2, 128.12,
128.06, 127.7, 127.6, 127.3, 127.2, 126.9, 126.5, 126.2, 126.1, 124.9, 21.23,
21,17. 31P NMR (162 MHz, CDCl3) d ꢀ12.6. MS (ESI) m/z: 775 ([M+H]+). Anal.
Calcd for C58H47P: C, 89.89; H, 6.11. Found: C, 89.85; H, 6.28.
needles. 1H NMR (400 MHz, CDCl3)
d 7.67 (d, J = 16 Hz, 1H), 7.42 (d,
J = 8.2 Hz, 2H), 7.19 (d, J = 8.2 Hz, 2H), 6.39 (d, J = 16 Hz, 1H), 3.80 (s, 3H),
2.38 (s, 3H). MS (EI) m/z: 176 (M+).
22. The reaction system in Table
3 was undertaken with styrene, methyl
methacrylate, 1-hexene, and methyl vinylketone. The styrene gave the
desired (E)-1-methyl-4-styrylbenzene in 41% yield. However, little amounts
of the target molecule were observed in use of methyl methacrylate (<4%
yield), and no cross-coupling with 1-hexene and methyl vinylketone
proceeded.
23. Meyers, A. I.; Himmelsbach, R. J. J. Am. Chem. Soc. 1985, 107, 682–685.
24. Ruan, J.; Li, X.; Saidi, O.; Xiao, J. J. Am. Chem. Soc. 2008, 130, 2424–2425.
13. Barder, T. E.; Buchwald, S. L. J. Am. Chem. Soc. 2007, 129, 5096–5101.
