New strategy for the synthesis of tetrahydrobenzothieno-[1,2]diazepines

Full text of DOI:10.1007/s10593-007-0231-6

Chemistry of Heterocyclic Compounds, Vol. 43, No. 11, 2007
NEW STRATEGY FOR THE SYNTHESIS
OF TETRAHYDROBENZOTHIENO-
[1,2]DIAZEPINES
A. S. Tolkunov and S. L. Bogza
Keywords:
3-amino-2-(3-benzo[b]thienylmethyl)quinazolines-4(3H)-one,
tetrahydrobenzothieno-
[2',3':4,5][1,2]diazepino[7,1-b]quinazolin-9-one, Pictet-Spengler reaction, cyclization.
Derivatives of 2,3-benzodiazepine display considerable biological activity and are under extensive
investigation [1]. Condensed benzodiazepines are less available and the methods for their synthesis are based on
adding on a heterocycle to one of the edges of the benzodiazepine system [2] or expansion of the pyran ring in
heterofused isocoumarins [3].
The heterocyclic [5H]benzothieno[2,3-e]diazepine system was first prepared in the recyclization of
1,3-disubstituted benzothieno[2,3-c]pyrilium salts by hydrazine hydrate [4]. The reaction of 3-amino-
2-(5-methyl-3-benzo[b]thienylmethyl)quinazolin-4(3H)-one (1) with aromatic aldehydes under conditions of the
Pictet-Spengler reaction was used to obtain derivatives of a new heterocyclic system, namely, tetrahydro-
benzothieno[2',3':4,5][1,2]diazepinoquinazolines 2a,b. The yields of products 2a,b were 57-65%. The reaction
O
RCHO
N
NH2
N
Me
CF3COOH
N
O
N
NH
S
S
R
2a,b
CF3COOH
Me
1
N
Me
N
O
N
S
R
3a,b
2, 3 a R = 4-MeOC6H4, b R = 4-ClC6H4
__________________________________________________________________________________________
L. M. Litvinenko Institute of Physical Organic and Coal Chemistry, National Academy of Sciences of
Ukraine, 83114 Donetsk; e-mail: s_tolkunov@yahoo.com. Translated from Khimiya Geterotsiklicheskikh
Soedinenii, No. 11, pp. 1740-1741, November, 2007. Original article submitted July 12, 2007.
0009-3122/07/4311-1485©2007 Springer Science+Business Media, Inc.
1485

proceeds through intermediate formation of Schiff bases 3, which was confirmed by the cyclization of
azomethine 3b to give benzothienoquinazolinodiazepine 2b under conditions of the basic reaction. The structure
1
1
of benzothienodiazepines 2a,b was demonstrated using H NMR spectroscopy. The H NMR spectra of 2a,b
have characteristic doublets for the CH2 group of the diazepine ring at 4.40-4.85 ppm with coupling constant
14-15 Hz, which indicates nonplanar structure of the diazepine ring.
The 1H NMR spectra were taken on a Varian Gemini 200 spectrometer at 200 MHz in DMSO-d6 at 50°C
with TMS as the internal standard.
General Procedure. A mixture of amine 1 (0.64 g, 2 mmol), an equivalent amount of an aromatic
aldehyde (or 2 mmol Schiff base 3a or 3b), and trifluoroacetic acid (4 ml) was heated at reflux for 5 h.
Trifluoroacetic acid was removed at reduced pressure and 10 ml 5% aqueous ammonia was added to the residue.
The crystals were filtered off, washed with water, and recrystallized from DMF–acetonitrile.
6-(4-Methoxyphenyl)-2-methyl-6,7,8,9-tetrahydrobenzothieno[2'3':4,5][1,2]diazepino[7,1-b]quin-
1
azolin-9-one (2a) was obtained in 57% yield; mp 219-220°C (DMF–acetonitrile). H NMR spectrum, δ, ppm
(J, Hz): 2.51 (3H, s, CH3); 3.78 (3H, s, OCH3); 4.39 (1H, d, J = 14.8, CH2); 4.85 (1H, d , J = 14.8, CH); 5.60
(1H, s, CH); 6.86-7.74 (6H, m, Harom); 7.61 (2H, d, J = 8.1, Harom-2',6' ), 7.75 (2h,d, J = 8.1, Harom-3',5'); 8.09 (1H,
d, J = 7.7, Harom-10). Found, %: C 71.05; H 4.82; N 9.56; S, 7.29. C26H21N3O2S. Calculated %: C 71.19; H 4.91;
N 9.42; S 7.12.
6-(4-Chlorophenyl)-2-methyl-6,7,8,15-tetrahydrobenzothieno[2',3':4,5][1,2]diazepino[7,1-b]quin-
azolin-9-one (2b) was obtained in 65% yield; mp 232°C (DMF–acetonitrile). 1H NMR spectrum, δ, ppm (J, Hz):
2.51 (3H, s, CH3); 4.42 (1H,d, J = 14.1, CH2); 4.85 (1H, d, J = 14.1, CH2); 5.73 (1H, s, CH); 7.15-7.79 (10H, m,
Harom); 8.10 (1H,d, J = 6.7, Harom10). Found, %: C 67.78; H 4.17; Cl 7.81; N 9.38; S 7.12. C25H18ClN3OS.
Calculated, %: C 67.64; H 4.09; Cl 7.99; N 9.46; S 7.22.
REFERENCES
1.
2.
E. J. Horvath, K. Horvath, T. Hamori, M. I. K. Fekete, S. Solyom, and M. Palkovits, Progress in
Neurobiology, 60, 309 (2000).
A. Gizella, S. Solyom, E. Csuzdi, P. Bersenyi, I. Ling, I. Tarnawa, T. Hamori, I. Pallagi, K. Horvath,
F. Andrassi, and G. Kapus, Bioorg. Med. Chem., 8, 2127 (2000).
3.
4.
J. Dusemund, Arch. Pharm., 316, No. 2, 110 (1983).
S. V. Tolkunov, S. Yu. Suykov, M. Yu. Zubritsky, and V. I. Dulenko, Khim. Geterotsikl. Soedin., 1137
(1998). [Chem. Heterocycl. Comp., 34, 983 (1998)].
