76
A. Baba, T. Yoshioka / Journal of Molecular Catalysis B: Enzymatic 69 (2011) 74–82
as an initial rate of decrease in the substrate concentration. For
the kinetic experiments on the hydrolysis of 7a–e, kinetic param-
eters (Km and Vmax) were obtained from double-reciprocal plots
of the initial rate data for LAS with 7a and 7b and for CSR with
7a–c. For other p-nitrophenyl ester substrates, pseudo first-order
rate constants were determined at low substrate concentrations.
The rate of enzymatic hydrolysis of 7a–e was corrected to account
for non-enzymatic hydrolysis. Kinetic measurement of the hydrol-
ysis of 3c, with initial concentration of 0.1 mM, was performed
using Lipozyme® CALBL, Novozyme 435, or CALB, at 100 l of the
enzyme solution, 25 mg of the immobilized enzyme, or 0.8 mg
of the enzyme per mL of incubation mixture, respectively. The
hydrolytic reaction obeys a pseudo-first order reaction and the rate
constants obtained for Lipozyme® CALBL, Novozym 435, and CALB
were 2.38 0.02, 1.18 0.10, and 3.81 0.01 h−1, respectively. For
preparative purposes, the initial concentrations of 2a–c were in the
range of 0.4–0.6 mM.
2.2.2. Methyl 1-O-(m-phenyl)benzoyl-ˇ-d-glucopyranuronate
(3b)
A solution of 2b (15.7 mg, 30.5 mol) in 51 mL of sodium citrate
buffer (20 mM, pH 5.0) containing 20% (v/v) DMSO was incubated
under stirring at 50 ◦C using CSR (510 mg). After 3 h, the conversion
yield was 98%, as determined by HPLC analysis. The product was
quantitatively extracted with EtOAc (50 mL × 3), and then EtOAc
was evaporated in vacuo. The residue was dissolved in 4 mL of 20%
(v/v) CH3CN containing 0.01% (v/v) AcOH and applied to an Amber-
lite XAD-4 column (2.5 g, height 6 cm). Product 3b was eluted with
30% (v/v) CH3CN containing 0.01% AcOH. Yield (11.5 mg, 97%). 1H
NMR (400 MHz, CD3OD) ı: 3.51–3.65 (m, 3H, C2-H, C3-H, and C4-H),
3.76 (s, 3H, CO2CH3), 4.06 (d, J 9.5 Hz, 1H, C5-H), 5.77 (d, J 7.8 Hz, 1H,
C1-H), 7.37 (t, J 7.6 Hz, 1H, aromatic H), 7.46 (t, J 7.1 Hz, 2H, aromatic
H), 7.58 (t, J 7.8 Hz, 1H, aromatic H), 7.65–7.67 (m, 2H, aromatic H),
7.89–7.91 (m, 1H, aromatic H), 8.05–8.08 (m, 1H, aromatic H), 8.32
(t, J 1.5 Hz, 1H, aromatic H). 13C NMR (100 MHz, CD3OD) ı: 52.9, 73.0
(C4), 73.7 (C2), 77.3 (C5), 77.4 (C3), 96.3 (C1), 128.1, 129.0, 129.3,
129.8, 130.1, 130.3, 131.1, 133.3, 141.2, 143.1, 166.5, 170.8. HR MS
(EI): calcd. for C20H20O8 [M+]: 388.1156; found 388.1162. MS (EI):
m/z 388 (0.2%), 198 (25), 181 (8), 152 (9), 105 (100).
2.1.2. HPLC analysis of enzymatic hydrolyses
To analyse the time courses of the enzymatic hydrolyses of
2a–c, 3a–c, 5a–c, and 7a–e, at appropriate intervals, aliquots of
the reaction mixture were diluted with HPLC mobile phase, to
stop the enzymatic reaction. The HPLC samples were injected
onto a Shimadzu HPLC that was equipped with a reversed-phase
Symmetry C18 column (5 m, 4.6 mm × 150 mm, Waters), a C-R8A
Chromatopac data processor, a Shimadzu SPD-10A VP UV detector
anda ShimadzuCTO-10ASVPcolumn ovenat 30 ◦C. Thecolumn was
eluted with HPLC mobile phase at a flow rate of 0.7 mL/min with
detection at 260 nm for 2a–c, 3a–c, and 5a–c and 310 nm for 7a–e,
respectively. The mobile phase was aqueous CH3CN containing
10 mM tetra-n-butylammonium bromide and 50 mM ammonium
acetate buffer (pH 4.5) with variable concentrations (%, v/v) of
CH3CN; 35% for 3a–c, 45% for 5a–c and 7a, 50% for 2a, 7b,c, and
7e, 55% for 2b,c and 70% for 7d.
2.2.3. Methyl 1-O-(p-phenyl)benzoyl-ˇ-d-glucopyranuronate
(3c)
A solution of 2c (16.4 mg, 31.9 mol) in 80 mL of sodium citrate
buffer (20 mM, pH 5.0) containing 20% (v/v) DMSO was incubated
under stirring at 40 ◦C using LAS (800 mg) and CSR (800 mg). After
2 h, the conversion yield was 95%, as determined by HPLC analysis.
The product was quantitatively extracted with EtOAc (50 mL × 3),
and then EtOAc was evaporated in vacuo. The residue was dis-
solved in 4 mL of 20% (v/v) CH3CN containing 0.01% (v/v) AcOH and
applied to an Amberlite XAD-4 column (2.5 g, height 6 cm). Product
3c was eluted with 30% (v/v) CH3CN containing 0.01% AcOH. Yield
(11.7 mg, 95%). 1H NMR (400 MHz, CD3OD) ı: 3.51–3.65 (m, 3H,
C2-H, C3-H, and C4-H), 3.76 (s, 3H, CO2CH3), 4.06 (d, J 9.5 Hz, 1H,
C5-H), 5.77 (d, J 7.8 Hz, 1H, C1-H), 7.38–7.42 (m, 1H, aromatic H),
7.45–7.49 (m, 2H, aromatic H), 7.67–7.70 (m, 2H, aromatic H), 7.76
(d, J 8.5 Hz, 2H, aromatic H), 8.17 (d, J 8.5 Hz, 2H, aromatic H). 13C
NMR (100 MHz, CD3OD) ı: 52.9, 73.0 (C4), 73.7 (C2), 77.3 (C5), 77.4
(C3), 96.2 (C1), 128.2, 128.3, 129.2, 129.4, 130.1, 131.6, 166.4, 170.8.
HR MS (EI): calcd. for C20H20O8 [M+]: 388.1156; found 388.1128.
MS (EI): m/z 388 (2%), 198 (100), 181 (82), 152 (40).
2.1.3. Computational chemistry
To obtain the optimized structures of 2a–c, calculations were
performed with a molecular mechanics model with MMFF, a
semiempirical AM1 and PM3 models, and Hartree-Fock 3-21G and
6-31+G* models using Spartan ‘08 (Wave Function, Inc.).
2.2. Compound characterization
2.2.4. Methyl
1-O-(o-phenyl)benzoyl-2,4-di-O-acetyl-ˇ-d-glucopyranuronate
(5a)
2.2.1. Methyl 1-O-(o-phenyl)benzoyl-ˇ-d-glucopyranuronate
(3a)
A solution of 2a (17.5 mg, 34.0 mol) in 85 mL of sodium citrate
buffer (20 mM, pH 5.0) containing 20% (v/v) DMSO was incubated
under stirring at 40 ◦C using LAS (170 mg, 2.0 mg/mL of incubation
mixture). After 0.5 h, the product 5a was quantitatively extracted
with EtOAc (50 mL × 2), and then EtOAc was evaporated in vacuo.
The residue was dissolved in 4 mL of 40% (v/v) CH3CN containing
0.01% (v/v) AcOH and applied to an Amberlite XAD-4 column (2.5 g,
height 6 cm). Product 5a was eluted with 50% (v/v) CH3CN contain-
ing 0.01% AcOH. Yield (13.0 mg, 81%). 1H NMR (400 MHz, d6-DMSO)
ı: 2.04 (s, 3H, OCOCH3), 2.05 (s, 3H, OCOCH3), 3.62 (s, 3H, CO2CH3),
3.96 (dt, J 6.1 and 9.5 Hz, 1H, C3-H), 4.45 (d, J 9.5 Hz, 1H, C5-H),
4.79 (t, J 9.5 Hz, 1H, C4-H), 4.86 (dd, J 8.1 and 9.5 Hz, 1H, C2-H),
5.86 (d, J 6.1 Hz, 1H, OH), 5.93 (d, J 8.1 Hz, 1H, C1-H), 7.26 (dd, J 2.0
and 6.8 Hz, 2H, aromatic H), 7.36–7.41 (m, 3H, aromatic H), 7.44
(dd, J 1.2 and 7.8 Hz, 1H, aromatic H), 7.54 (dt, J 1.2 and 7.8 Hz, 1H,
aromatic H), 7.68 (dt, J 1.2 and 7.8 Hz, 1H, aromatic H), 7.72 (dd, J
1.2 and 7.8 Hz, 1H, aromatic H). 13C NMR (100 MHz, d6-DMSO) ı:
20.5, 20.6, 52.4, 70.0 (C3), 71.3 (C4), 71.7 (C5), 72.1 (C2), 91.5 (C1),
127.3, 127.6, 128.1, 128.3, 128.5, 129.3, 131.1, 132.4, 140.0, 142.4,
165.0, 167.4, 169.2, 169.5. HR MS (EI): calcd. for C24H24O10 [M+]:
A solution of 2a (14.1 mg, 27.4 mol) in 68 mL of sodium citrate
buffer (20 mM, pH 5.0) containing 20% (v/v) DMSO was incubated
under stirring at 40 ◦C using LAS (680 mg). After 5 h, the conversion
yield was 98%, as determined by HPLC analysis. The product was
quantitatively extracted with EtOAc (50 mL × 3), and then EtOAc
was evaporated in vacuo. The residue was dissolved in 4 mL of 20%
(v/v) CH3CN containing 0.01% (v/v) AcOH and applied to an Amber-
lite XAD-4 column (2.5 g, height 6 cm). Product 3a was eluted with
30% (v/v) CH3CN containing 0.01% AcOH. Yield (10.3 mg, 97%). 1H
NMR (400 MHz, CD3OD) ı: 3.30 (dd, J 8.1 and 9.5 Hz, 1H, C2-H), 3.44
(t, J 9.5 Hz, 1H, C3-H or C4-H), 3.53 (t, J 9.5 Hz, 1H, C3-H or C4-H), 3.78
(s, 3H, CO2CH3), 3.93 (d, J 9.5 Hz, 1H, C5-H), 5.54 (d, J 8.1 Hz, 1H, C1-
H), 7.30–7.41 (m, 6H, aromatic H), 7.45 (dt, J 1.2 and 7.8 Hz, 1H,
aromatic H), 7.60 (dt, J 1.2 and 7.8 Hz, 1H, aromatic H), 7.93 (dd,
J 1.2 and 7.8 Hz, 1H, aromatic H). 13C NMR (100 MHz, CD3OD) ı:
52.9, 72.8 (C4), 73.6 (C2), 77.2 (C5), 77.3 (C3), 96.1 (C1), 128.2, 128.3,
129.2, 129.8, 129.9, 131.1, 132.0, 133.0, 142.1, 144.5, 168.0, 170.7.
HR MS (EI): calcd. for C20H20O8 [M+]: 388.1156; found 388.1140.
MS (EI): m/z 388 (1%), 198 (100), 181 (98), 152 (46).
