Synthesis of Phenanthro[9,10-c]thiophenes by
2,3-Dichloro-5,6-dicyano-1,4-benzoquinone
(DDQ)-Promoted Cyclo-Oxidation
Han Gao,[a] David M. Connors,[a, b] and Nancy S. Goroff*[a]
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
A new method to prepare phenanthro[9,10-c]thiophenes has
been developed. In the presence of triflic acid, 3,4-diaryl
thiophenes undergo 2,3-dichloro-5,6-dicyano-1,4-benzoquinone
(DDQ)-promoted cyclo-oxidation. NMR and computational
studies indicate that protonation of the thiophene plays a key
role in this reaction. The reaction can be used to prepare
phenanthro[9,10-c]thiophene, as well as derivatives with alkyl,
bromo, and methoxy substituents. However, the yields and
selectivity of the reaction depend on both the nature and
location of the substituents. Bis(3-methoxyphenyl)thiophene
reacts under these conditions to give the desired product in
Figure 1. Benzo[c]thiophene, phenanthro[9,10-c]thiophene, and their conju-
gated polymer products.
57% yield, while bis(4-methoxyphenyl)thiophene gives no
product. Bis(3-bromophenyl)thiophene did not react, but cyclo-
oxidation of bis(4-bromophenyl)thiophene provides the desired
product in 34% yield.
characterized and processed. However, there have been very
few reported syntheses of phenanthro[9,10-c]thiophene or its
derivatives.
Arene-fused thiophenes have been used in polymers for
applications in organic field-effect transistors (OFETs), light-
emitting diodes (OLEDs) and solar cells (OSCs).[1] The bandgap
of poly(isothianaphthene) (Figure 1), for example, has been
measured at 1.0–1.2 eV, which is almost 1 eV smaller than that
of poly(3-hexylthiophene) (P3HT), due to the increased aromatic
stabilization in the quinoidal form of the polymer.[2]
Phenanthrene-fused thiophenes have aromatic stabilization
energies intermediate between those of thiophene and benzo
[c]thiophene.[3] making them promising starting materials for
conjugated polymers. Kathirgamanathan and Shepherd exam-
ined the polymerization of phenanthro[9,10-c]thiophene (1)
under electrochemical conditions, and obtained a red conduct-
ing material.[4] They reported that this polymeric material
changes color depending on oxidation state. The polymer was
not soluble, and there was no further characterization beyond
the electrochemical properties. These results led us to target
soluble derivatives of this polymer that can be more completely
The most straightforward approach to the phenanthrothio-
phenes is by oxidative cyclization of diaryl thiophenes (2,
Scheme 1); this route also benefits from the synthetic accessi-
bility of diaryl thiophenes with a variety of substituents.[5]
However, Schnapperelle and Bach attempted the cyclo-oxida-
tion of compound 2 under a wide variety of conditions, and
found no reaction.[6] To overcome this problem, they prepared
the more complicated desymmetrized chlorodiarylthiophene 3
and successfully converted it to phenanthrothiophene 1 by
irradiation with 254-nm light. Other approaches that have been
used to make phenanthro[9,10-c]thiophene and derivatives
include Hindsburg condensation of a diester sulfide with
phenanthroquinone;[7] ring closure using sodium sulfide and a
phenanthryl dihalide[8] or tetrahalide;[4] and Stille coupling of a
9-stannafluorene with a dibromothiophene.[9] To develop a
more efficient and versatile synthesis for substituted phenan-
threnes, we decided to reexamine the simple cyclo-oxidation of
diarylthiophenes.
Diaryl thiophene derivatives can be synthesized by a variety
of methods.[4,6,8,10] Dang and Chen reported the efficient syn-
[a] H. Gao, Dr. D. M. Connors, Prof. N. S. Goroff
Department of Chemistry
Stony Brook University
Stony Brook, NY 11794-3400 (USA)
E-mail: nancy.goroff@stonybrook.edu
[b] Dr. D. M. Connors
Department of Chemistry
Georgia State University
Atlanta, GA 30302 (USA)
Supporting information for this article is available on the WWW under
https://doi.org/10.1002/cplu.201900099
This article is part of a Special Issue on “Novel Aromatics”.
Scheme 1. Approaches to synthesize phenanthro[9,10-c]thiophene
ChemPlusChem 2019, 84, 1–5
1
© 2019 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
��
These are not the final page numbers!

Communications
the reaction of compound 2b (Table 1), based on Rathore’s
conditions for conversion of activated terphenyls to
triphenylenes.[11] Methanesulfonic acid and fluoroboric acid
provide only trace amounts of the desired product 1b, while
Lewis acid BF3-OEt2 gives none. Triflic acid, however, works well,
especially when an excess of DDQ is used. Reducing the
1
2
3
4
5
6
7
8
9
°
temperature to À 40 C improves the yield further, as does
increasing the dilution to discourage dimer formation. Under
optimized conditions, this reaction can be carried out in 47%
isolated yield.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
To further investigate the scope of this cyclo-oxidation,
several different diaryl thiophenes have been studied (Table 2).
These experiments demonstrate that both the substituents and
the regiochemistry affect the success of the reaction. Compar-
ing the methoxy-substituted substrates 2c–2e, bis(4-methox-
yphenyl) thiophene (2d) gives none of the desired phenanthro-
thiophene (1d), with recovery of 43% of starting material, while
bis(3-methoxyphenyl) thiophene (2c) undergoes reaction in
good yield, although forming an inseparable mixture of both a
symmetric and asymmetric product (Scheme 3); bis(3,4-dime-
thoxyphenyl) thiophene (2e) reacts in high yield to give
product 1e. For the bromine-substituted compounds, the
selectivity is the opposite: bis(4-bromophenyl) thiophene (2g)
reacts in reasonable yield, but reaction of bis(3-bromophenyl)
thiophene (2f) leads to no identifiable products and recovery of
40% of the starting material.
Scheme 2. Synthetic route to diaryl thiophenes.
thesis of diaryl thiophenes in three steps from the bromoaceto-
phenone (4).[5e] Based on their approach, we prepared a range
of diarylthiophenes (Scheme 2). First, the bromoacetophenone
(4a–g) reacts with sodium sulfide to provide the diketone
