R- or ꢀ-Phosphoryl-Substituted Alkylarenes
TABLE 1. Effect of Catalyst in Cross-Coupling between 1a and 2a
reaction, we found another methodology to achieve the alkyl-
aryl cross-coupling with nonactiVated alkyl electrophiles.9 That
is, in our reaction, it is not the auxiliary components of the
catalysts but both the utility of the Rh as a catalyst and the
manipulation of the coupling components by introduction of
carbonyl groups near the reaction centers that could significantly
suppress the ꢀ-hydride elimination. In this investigation, we
studied the effect of phosphoryl groups on the alkyl-coupling
partners during the Rh-catalyzed alkyl-aryl cross-coupling,
intending to develop a new synthetic method for phosphoryl-
substituted alkylarenes, a useful class of compounds in such
fields as synthetic organic chemistry, represented by their utility
as intermediates of the Horner-Wadsworth-Emmons reac-
tion,10 medicinal chemistry,11 etc.12
entry
catalyst
time (h)
yieldb (%)
1
2
3
4
1/2[RhCl(cod)]2/dppf
1/2[RhCl(cod)]2/dppf
1/2[RhCl(cod)]2/BINAP
1/2[RhCl(cod)]2/PPh3
1/2[RhCl(cod)]2/dppp
1/2[RhCl(cod)]2/dppf
1/2[RhCl(cod)]2/dppf
Pd(PPh3)4
1
20
20
1
1
1
20
20
20
20
91
92
70
<5
39
92
39
<5
<5
14
5
6c
7d
8
9
10
PdCl2(dppf)
NiCl2(dppf)
a 1a (0.56 mmol), 2 (0.4 mmol), catalyst (0.02 mmol), and THF (0.47
mL) were employed for all entries, except for entry 2, where 0.008
mmol of catalyst was used. b GLC yield. c TMU was used as solvent.
d BrCH2CH2P(O)(OEt)2 4 was used in place of 2.
Results and Discussion
A reaction solution composed of phenylzinc iodide (1a; 1.4
equiv), diethyl 2-iodoethylphosphonate (2; 1.0 equiv), and a Rh
catalyst (2-5 mol %) in THF was stirred at 40 °C under nitrogen
(Table 1). Throughout this study, the Rh catalysts were prepared
in situ from [RhCl(cod)]2 (cod ) 1,5-cyclooctadiene) and
various phosphorus ligands (Rh/P ) 1:2), among which Rh-
dppf (dppf ) 1,1′-bis(diphenylphosphino)ferrocene) exhibited
an excellent catalytic activity in the reaction, giving the desired
coupling product 3a in high yield (entries 1 and 2). Rh-BINAP
was also effective for the reaction but required a longer reaction
time than Rh-dppf (entry 3). On the other hand, Rh-PPh3 and
Rh-dppp (dppp ) 1,3-bis(diphenylphosphino)propane) gave 3a
in low yields, though both starting materials 1a and 2 were
completely consumed under the stated conditions (entries 4 and
5). As the reaction solvent, TMU (TMU ) N,N,N′,N′-tetram-
ethylurea) was effective as THF (entry 6), but the reactivity of
the bromide 4 was lower than 2 (entry 7). For the same reaction,
the conventional Pd or Ni catalysts were far less effective than
Rh-dppf, even if dppf was used as a ligand (entries 8-10),
underlining the striking utility of Rh in the reaction.9,13 To the
best of our knowledge, this is the first example of synthesizing
the phosphoryl substituted alkylarenes by the catalytic alkyl-
aryl cross-coupling with nonactivated alkyl electrophiles.14
Various arylzinc compounds containing such functional groups
as CH3 (entry 2), OCH3 (entry 3), Cl (entry 4), or CO2R (entries
5 and 6) at the para or meta position, 1b-f, underwent catalysis
by Rh-dppf during the reaction with 2 to afford the correspond-
ing coupling products 3b-f in good isolated yields, as shown
in Table 2, whereas the substituent groups at the ortho position,
1g and 1h, completely inhibited the desired cross-coupling
(entries 7 and 8).
(5) (a) Zhou, J.; Fu, G. C. J. Am. Chem. Soc. 2004, 126, 1340–1341. (b)
Powell, D. A.; Fu, G. C. J. Am. Chem. Soc. 2004, 126, 7788–7789.
(6) Frisch, A. C.; Rataboul, F.; Zapf, A.; Beller, M. J. Organomet. Chem.
2003, 687, 403–409.
(7) (a) Terao, J.; Watanabe, H.; Ikumi, A.; Kuniyasu, H.; Kambe, N. J. Am.
Chem. Soc. 2002, 124, 4222–4223. (b) Terao, J.; Todo, H.; Watanabe, H.; Ikumi,
A.; Kambe, N. Angew. Chem., Int. Ed. 2004, 43, 6180–6182.
(8) (a) Giovannini, R.; Knochel, P. J. Am. Chem. Soc. 1998, 120, 11186–
11187. See also: (b) Giovannini, R.; Stu¨demann, T.; Dussin, G.; Knochel, P.
Angew. Chem., Int. Ed. 1998, 37, 2387–2390.
(9) (a) Takahashi, H.; Inagaki, S.; Nishihara, S.; Shibata, T.; Takagi, K. Org.
Lett. 2006, 3037–3040. See also: (b) Hossain, K. M.; Takagi, K. Chem. Lett.
1999, 1241–1242. (c) Takahashi, H.; Hossain, K. M.; Nishihara, Y.; Shibata,
T.; Takagi, K. J. Org. Chem. 2006, 71, 671–675.
(10) See for example: (a) Cai, C.; Liakatas, I.; Wong, M.-S.; Boesch, M.;
Bosshard, C.; Guenter, P.; Concilio, S.; Tirelli, N.; Suter, U. W. Org. Lett. 1999,
1, 1847–1849. (b) D.-Barra, E.; G.-Martinez, J. C.; R.-Lopez, J. Tetrahedron
Lett. 1999, 40, 8181–8184. (c) Brunner, H.; Le Cousturier de Courcy, N.; Genet,
J.-P. Synlett 2000, 201–204. (d) Lindner, E.; Khanfar, M. J. Organomet. Chem.
2001, 630, 244–252. (e) Kawano, T.; Kato, T.; Du, C.-X.; Ueda, I. Tetrahedron
Lett. 2002, 43, 6697–6700. (f) Cho, B. R.; Chajara, K.; Oh, H. J.; Son, K. H.;
Jeon, S.-J. Org. Lett. 2002, 4, 1703–1706. (g) Zheng, S.; Barlow, S.; Parker,
T. C.; Marder, S. R. Tetrahedron Lett. 2003, 44, 7989–7992. (h) Azzena, U.;
Dettori, G.; Idini, M. V.; Pisano, L.; Sechi, G. Tetrahedron 2003, 59, 7961–
7966. (i) G.-Nava, M.; Jaeggy, M.; Nierengarten, H.; Masson, P.; Guillon, D.;
Van Dorsselaer, A.; Nierengarten, J.-F. Tetrahedron Lett. 2003, 44, 3039–3042.
(j) Årstad, E.; Hoff, P.; Skattebøl, L.; Skretting, A.; Breistøl, K. J. Med. Chem.
2003, 46, 3021–3032. (k) Fabbrini, G.; Menna, E.; Maggini, M.; Canazza, A.;
Marcolongo, G.; Meneghetti, M. J. Am. Chem. Soc. 2004, 126, 6238–6239. (l)
Labrue, F.; Pons, B.; Ricard, L.; Marinetti, A. J. Organomet. Chem. 2005, 690,
2285–2290. (m) Nielsen, C. B.; Johnsen, M.; Arnbjerg, J.; Pittelkow, M.; McIlroy,
S. P.; Ogilby, P. R.; Jorgensen, M. J. Org. Chem. 2005, 70, 7065–7079.
(11) See for example: (a) Yokomatsu, T.; Murano, T.; Suemune, K.; Shibuya,
S. Tetrahedron 1997, 53, 815–822. (b) Li, Z.; Yeo, S. L.; Pallen, C. J.; Ganesan,
A. Bioorg. Med. Chem. Lett. 1998, 8, 2443–2446. (c) Park, S. B.; Standaert,
R. F. Tetrahedron Lett. 1999, 40, 6557–6560. (d) Cockerill, G. S.; Easterfield,
H. J.; Percy, J. M.; Pintat, S. J. Chem. Soc., Perkin Trans. 1 2000, 2591–2599.
(e) Bhattacharya, A. K.; Stolz, F.; Schmidt, R. R. Tetrahedron Lett. 2001, 42,
5393–5395. (f) Beeton, C.; Pennington, M. W.; Wulff, H.; Singh, S.; Nugent,
D.; Crossley, G.; Khaytin, I.; Calabresi, P. A.; Chen, C.-Y.; Gutman, G. A.;
Chandy, K. G. Mol. Pharmacol. 2005, 67, 1369–1381. (g) Combs, A. P.; Yue,
E. W.; Bower, M.; Ala, P. J.; Wayland, B.; Douty, B.; Takvorian, A.; Polam,
P.; Wasserman, Z.; Zhu, W.; Crawley, M. L.; Pruitt, J.; Sparks, R.; Glass, B.;
Modi, D.; McLaughlin, E.; Bostrom, L.; Li, M.; Galya, L.; Blom, K.; Hillman,
M.; Gonneville, L.; Reid, B. G.; Wei, M.; Becker-Pasha, M.; Klabe, R.; Huber,
R.; Li, Y.; Hollis, G.; Burn, T. C.; Wynn, R.; Liu, P.; Metcalf, B. J. Med. Chem.
2005, 48, 6544–6548.
The Rh-dppf catalyzed cross-coupling of 1a with diethyl
3-iodopropylphosphonate (5) or diethyl 4-iodobutylphosphonate
(6) took place far less selectively, producing the desired cross-
coupling product 7 or 8 in reduced yields, i.e., 31% or 18%,
respectively (Scheme 1). Together with the fact that in the Rh-
dppf catalyzed reaction between 1a and iodoethane (9) the yield
(13) In comparison with the vast numbers of studies on Pd or Ni catalysis in
the cross-coupling of carbon electrophiles, R-X, with organometallic compounds,
R′-m, those on Rh remain few: (a) Larock, R. C.; Hershberger, S. S. J.
Organomet. Chem. 1982, 225, 31–41. (b) Larock, R. C.; Narayanan, K.;
Hershberger, S. S. J. Org. Chem. 1983, 48, 4377–4380. (c) Evans, P. A.;
Uraguchi, D. J. Am. Chem. Soc. 2003, 125, 7158–7159. (d) Evans, P. A.; Leahy,
D. K. J. Am. Chem. Soc. 2003, 125, 8974–8975. (e) Uemura, K.; Satoh, T.;
Miura, M. Org. Lett. 2005, 7, 2229–2231. (f) Yasui, H.; Mizutani, K.; Yorimitsu,
H.; Oshima, K. Tetrahedron 2006, 62, 1410–1415. (g) Wu, J.; Zhang, L.; Luo,
Y. Tetrahedron Lett. 2006, 47, 6747–6750. (h) Wu, J.; Zhang, L.; Gao, K. Eur.
J. Org. Chem. 2006, 5260–5263. (i) Kantam, M. L.; Roy, S.; Roy, M.; Sreedhar,
B.; Choudary, B. M.; De, R. L. J. Mol. Catal. A: Chem. 2007, 273, 26–31. (j)
Zhang, L.; Wu, J. AdV. Synth. Catal. 2008, 350, 2409–2413.
(14) There exists no precedent for the catalytic alkyl-aryl cross-coupling with
alkyl electrophiles leading to phosphoryl-substituted alkylarenes, except for two
examples using R-phosphoryl-substituted alkyl halides as an actiVated alkyl
electrophile. Strotman, N. A.; Sommer, S.; Fu, G. C. Angew. Chem., Int. Ed
2007, 47, 3556–3558.
(12) See for example: (a) Grawe, T.; Schrader, T.; Zadmard, R.; Kraft, A. J.
Org. Chem. 2002, 67, 3755–3763. (b) Freisinger, E.; Griesser, R.; Lippert, B.;
Moreno-Luque, C. F.; Niclos-Gutierrez, J.; Ochocki, J.; Operschall, B. P.; Sigel,
H. Chem. Eur. J. 2008, 14, 10036–10046.
