Pyrazin-1-one Antagonists
Journal of Medicinal Chemistry, 2009, Vol. 52, No. 8 2415
General Procedure for the Synthesis of 4-Amino-2-aryl-1,2-
dihydropyrido[2,3-e]-1,2,4-triazolo[4,3-a]pyrazin-1(2H)-ones 7-10.
A suspension of the 4-chloro derivatives 29-32 (2 mmol), in
absolute ethanol (30 mL) saturated with ammonia, was heated
overnight at 120 °C in a sealed tube. After the mixture was cooled
at room temperature, the solid was collected by filtration and washed
with water.
14: yield 70%; mp >300 °C (DMF); 1H NMR 2.46 (s, 3H, CH3),
7.40 (t, 1H, ar, J ) 7.3 Hz), 7.57-7.61 (m, 3H, 2ar + H-7), 8.11
(d, 2H, ar, J ) 8.0 Hz), 8.63 (d, 1H, H-7, J ) 4.8 Hz), 8.99 (d,
1H, H-9, J ) 8.1 Hz), 10.72 (br s, 1H, NH); IR 1715, 1695. Anal.
(C16H12N6O2) C, H, N.
1
15: yield 84%; mp 244-246 °C (2-methoxyethanol); H NMR
7.38 (t, 1H, ar, J ) 7.4 Hz), 7.55-7.69 (m, 6H, ar), 7.99 (d, 2H,
ar, J ) 7.6 Hz), 8.03-8.13 (m, 2H, ar), 8.57 (br s, 1H, ar), 8.98
(br s, 1H, H-9), 11.45 (br s, 1H, NH); IR 1719, 1654. Anal.
(C21H14N6O2) C, H, N.
1
7: yield 75%; mp >300 °C (AcOH); H NMR 7.25-7.40 (m,
4H, ar), 7.56 (t, 2H, ar, J ) 7.7 Hz), 7.90-8.06 (m, 4H, 2ar +
NH2), 8.42 (d, 1H, H-7, J ) 4.8 Hz), 8.85 (d, 1H, H-9, J ) 8.1
Hz); IR 3420, 3240, 1700. Anal. (C14H10N6O) C, H, N.
8: yield 70%; mp >300 °C (AcOH); 1H NMR 3.82 (s, 3H, CH3),
7.13 (d, 2H, ar, J ) 9.1 Hz), 7.27 (dd, 1H, H-8, J ) 8.0 and 4.8
Hz), 7.89-8.05 (m, 4H, 2ar + NH2), 8.43 (d, 1H, H-7, J ) 4.8
Hz), 8.85 (d, 1H, H-9, J ) 8.0 Hz); IR 3428, 3230, 1710. Anal.
(C15H12N6O2) C, H, N.
16: yield 35%; mp 240-241 °C (acetonitrile); 1H NMR 4.11 (s,
2H, CH2), 7.28-7.43 (m, 6H, ar), 7.58-7.62 (m, 3H, ar), 8.09 (d,
2H, ar, J ) 7.7 Hz), 8.64 (d, 1H, H-7, J ) 4.7 Hz), 8.99 (d, 1H,
H-9, J ) 8.1 Hz), 10.95 (s, 1H, NH); IR 3340-3430, 1727, 1688.
Anal. (C22H16N6O2) C, H, N.
1
17: yield 55%; mp 278-280 °C (2-ethoxyethanol); H NMR
1
2.42 (s, 3H, COCH3), 3.83 (s, 3H, OCH3), 7.14 (d, 2H, ar, J ) 9.0
Hz), 7.57 (dd, 1H, H-8, J ) 7.9 and 4.5 Hz), 7.96 (d, 2H, ar, J )
9.0 Hz), 8.63 (d, 1H, H-7, J ) 4.5 Hz), 8.98 (d, 1H, H-9, J ) 7.9
Hz), 10.73 (br s, 1H, NH); IR 3485-3358 1716, 1691. Anal.
(C17H14N6O3) C, H, N.
9: yield 95%; mp >300 °C (2-methoxyethanol); H NMR 7.28
(dd, 1H, H-8, J ) 8.0 and 4.8 Hz), 7.44 (t, 2H, J ) 8.8 Hz),
7.80-8.08 (m, 4H, 2ar + NH2), 8.44 (d, 1H, H-7, J ) 4.8 Hz),
8.85 (d, 1H, H-9, J ) 8.0 Hz); IR 3482, 1715. Anal. (C14H9FN6O)
C, H, N.
10: yield 64%; mp >300 °C (DMF); 1H NMR 1.36 (t, 3H, CH3,
J ) 7.1 Hz), 4.36 (q, 2H, CH2, J ) 7.1 Hz), 7.29 (dd, 1H, H-8, J
) 8.0 and 4.8 Hz), 8.01 (br s, 2H, NH2), 8.16 (d, 2H, ar, J ) 8.7
Hz), 8.26 (d, 2H, ar, J ) 8.7 Hz), 8.45 (d, 1H, H-7, J ) 4.8 Hz),
8.85 (d, 1H, H-9, J ) 8.0 Hz); IR 3380, 1727, 1715. Anal.
(C17H14N6O3) C, H, N.
1
18: yield 88%; mp 250-252 °C (2-ethoxyethanol); H NMR
3.81 (s, 3H, CH3), 7.12 (d, 2H, ar, J ) 9.0 Hz), 7.55-7.69 (m, 4H,
ar), 7.85 (d, 2H, ar, J ) 8.3 Hz), 8.11-8.13 (m, 2H, ar), 8.52-8.56
(m, 1H, ar), 9.02 (br s, 1H, H-9), 11.42 (br s, 1H, NH); IR 1717.
Anal. (C22H16N6O3) C, H, N.
4-Dibenzoylamino-2-phenyl-1,2-dihydropyrido[2,3-e]-1,2,4-tria-
zolo[4,3-a]pyrazin-1(2H)-ones 19. A mixture of the 4-amino deriva-
tive 7 (1.8 mmol) and benzoyl chloride (16 mmol) in anhydrous
pyridine was refluxed for 28 h. After cooling at room temperature,
the suspension was diluted with water and the solid collected by
filtration and recrystallized. Yield 60%; mp 276-278 °C (DMF);
1H NMR 7.36 (t, 1H, ar, J ) 7.4 Hz), 7.51-7.55 (m, 6H, ar),
7.65-7.68 (m, 2H, ar), 7.73 (dd, 1H, H-8, J ) 8.2 and 4.5 Hz),
7.87 (d, 2H, ar, J ) 8.0 Hz), 7.93 (d, 4H, ar, J ) 7.4 Hz), 8.63 (d,
1H, H-7, J ) 4.5 Hz), 9.07 (d, 1H, H-9, J ) 8.2 Hz); IR 1725,
1710. Anal. (C28H18N6O3) C, H, N.
4-Amino-2-(4-hydroxyphenyl)-1,2-dihydropyrido[2,3-e]-1,2,4-
triazolo[4,3-a]pyrazin-1(2H)-one 11. A BBr3 methylene chloride
solution (1M, 5.8 mL) was dropwise added at 0 °C to a suspension
of compound 8 (0.97 mmol) in anhydrous methylene chloride (15
mL) under nitrogen atmosphere. The suspension was stirred at room
temperature for 4 days, then diluted with water (4 mL) and the
mixture neutralized with 1 M NaOH solution. The solid was
collected by filtration and washed with water. Yield 95%; mp >300
1
°C (DMF); H NMR 6.92 (d, 2H, ar, J ) 8.9 Hz), 7.26 (dd, 1H,
H-8, J ) 8.0 and 4.7 Hz), 7.75 (d, 2H, ar, J ) 8.9 Hz), 7.80 (br s,
2H, NH2), 8.43 (d, 1H, H-7, J ) 4.7 Hz), 8.85 (d, 1H, H-9, J )
8.0 Hz), 9.77 (s, 1H, OH); IR 3440, 3315, 1720. Anal. (C14H10N6O2)
C, H, N.
4-Dibenzoylamino-2-(4-methoxyphenyl)-1,2-dihydropyrido[2,3-
e]-1,2,4-triazolo[4,3-a]pyrazin-1(2H)-ones 20. A mixture of the
4-amino derivative 8 (1.3 mmol) and benzoyl chloride (3.9 mmol)
in anhydrous pyridine was refluxed for 30 h. After cooling at room
temperature, the suspension was diluted with water and the solid
was collected by filtration. The crude solid was a mixture of
4-Cyclohexylamino-2-phenyl-1,2-dihydropyrido[2,3-e]-1,2,4-tria-
zolo[4,3-a]pyrazin-1(2H)-one 12. A mixture of the 4-chloro deriva-
tive 29 (1 mmol) and cyclohexylamine (1.2 mmol) in absolute
ethanol (5 mL) was heated overnight at 120 °C in a sealed tube.
After the mixture was cooled at room temperature, the solid was
collected by filtration and washed with water. Yield 78%; mp
199-200 °C (cyclohexane); 1H NMR 1.18-2.0 (m, 10H, al),
4.10-4.25 (m, 1H, al), 7.20-7.39 (m, 2H, ar + H-8), 7.57 (t, 2H,
ar, J ) 7.2 Hz), 8.06 (d, 2H, ar, J ) 7.2 Hz), 8.19 (d, 1H, NH, J
) 8.7 Hz), 8.41 (d, 1H, H-7, J ) 3.7 Hz), 8.85(d, 1H, H-9, J )
6.6 Hz); IR 3500, 3370, 1700. Anal. (C20H20N6O) C, H, N.
1
compounds 20 and 15 (about 1:1 ratio, from H NMR spectrum)
which where separated by column chromatography (eluent CH2Cl2/
EtOAc, 7:3). Evaporation of the first eluates afforded the desired
compound 20; from the second eluates the 4-benzoylamino deriva-
tive 15 and also the 1,4-dione 2 was obtained. Yield 8%; mp
287-289 °C (2-methoxyethanol); 1H NMR 3.79 (s, 3H, CH3), 7.10
(d, 2H, ar, J ) 9.1 Hz), 7.53 (t, 4H, ar, J ) 7.7 Hz), 7.67 (t, 2H,
ar, J) 7.7 Hz), 7.72-7.77 (m, 3H, 2ar + H-8), 7.93 (d, 4H, ar, J
) 7.7 Hz), 8.63 (d, 1H, H-7, J ) 4.7 Hz), 9.07 (d, 1H, H-9, J )
8.2 Hz); IR 1715, 1704. Anal. (C29H20N6O4) C, H, N.
(B) Computational Methodologies. All modeling studies were
carried out on a 16 CPU (Intel Core 2 Quad CPU 2.40 GHz) Linux
cluster. Homology modeling, energy calculation, and docking
studies were performed using the Molecular Operating Environment
(MOE, version 2007.09) suite.40 All docked structures were fully
optimized without geometry constraints using RHF/AM1 semiem-
pirical calculations. Vibrational frequency analysis was used to
characterize the minima stationary points (zero imaginary frequen-
cies). The software package MOPAC (version 7),41 implemented
in MOE suite, was utilized for all quantum mechanical calculations.
Homology Model of the hA3 AR. On the basis of the assumption
that GPCRs share similar TM boundaries and overall topology, a
homology model of the hA3 receptor was constructed. First, the
amino acid sequences of TM helices of the A3 receptor were aligned
with those of bovine rhodopsin,42 guided by the highly conserved
amino acid residues, including the DRY motif (Asp3.49, Arg3.50,
and Tyr3.51) and three proline residues (Pro4.60, Pro6.50, and
Pro7.50) in the TM segments of GPCRs. The same boundaries were
4-Cyclopentylamino-2-phenyl-1,2-dihydropyrido[2,3-e]-1,2,4-
triazolo[4,3-a]pyrazin-1(2H)-one 13. The title compound was
prepared by reacting derivative 29 (1.0 mmol) and cyclopentylamine
(1.2 mmol) in the conditions described above to prepare compound
1
12. Yield 75%; mp 190-191 °C (cyclohexane/EtOAc); H NMR
1.5-2.5 (m, 8H, al), 4.42-4.65 (m, 1H, al), 7.21-7.39 (m, 2H, ar
+ H-8), 7.57 (t, 2H, ar, J ) 7.3 Hz), 8.06 (d, 2H, ar, J ) 7.3 Hz),
8.29 (d, 1H, NH, J ) 7.7 Hz), 8.41 (d, 1H, H-7, J ) 4.7 Hz), 8.84
(d, 1H, H-9, J ) 8.0 Hz); IR 3290, 1730. Anal. (C19H18N6O) C, H,
N.
General Procedure for the Synthesis of 4-Amido-2-aryl-1,2-
dihydropyrido[2,3-e]-1,2,4-triazolo[4,3-a]pyrazin-1(2H)-ones 14-18.
A mixture of the 4-amino derivative 7 or 8 (1.1 mmol) and acetyl
chloride (1.2 mmol), benzoyl chloride (1.7 mmol), or phenylacetyl
chloride (3.2 mmol) in anhydrous pyridine (10 mL) was refluxed
until the disappearance (TLC monitoring) of the starting 4-amino
derivative (2-5 h). After cooling at room temperature, the
suspension was diluted with water (30 mL) and the solid was
collected and washed with water.
