Synthesis and screening of bifunctional radiolabelled
carborane-carbohydrate derivatives
*
Andrew E.C. Green, Shannon K. Parker, John F. Valliant
Departments of Chemistry and Medical Physics and Applied Radiation Sciences, McMaster University, 1280 Main Street West, Hamilton, ON, Canada L8S 4M1
a r t i c l e i n f o
a b s t r a c t
Article history:
A new bifunctional carborane ligand was prepared as a platform for the development of targeted molec-
ular radioimaging and therapy agents. The carborane derivative was synthesized bearing a glucose sub-
stituent to increase the water solubility of the ligand and a benzoic acid group as a site for linking to
amine containing targeting vectors. A convenient method to conjugate the ligand and the non-glycosyl-
ated analogue to amino groups was developed using simple active esters which were combined with a
model amine generating two new N,N-diethyl(aminoethyl) benzamide derivatives. These were labelled
with 125I in good yield and the logP values measured for [125I]-15 (logP = 0.82 0.04) and [125I]-16
(logP = 1.53 0.01). The benzamides were also evaluated for their capacity to bind to B16F10 melanoma
cells where the hydrophilic compound showed low binding while [125I]-16 showed modest uptake
(30.7 2.2%) after 24 h.
Received 9 November 2008
Accepted 15 December 2008
Available online 6 January 2009
Keywords:
Carboranes
Molecular imaging
Radioiodine
Benzamides
Melanoma
Ó 2009 Elsevier B.V. All rights reserved.
1. Introduction
One of the limitations associated with carborane-based radio-
pharmaceuticals is that they are generally lipophilic which can
Targeted radiopharmaceuticals are typically engineered such
that they contain two key components: a vector for achieving high
target-to-non-target ratios and a ligand or prosthetic group to en-
sure that there is a robust covalent linkage between the targeting
moiety and the radionuclide. Radiolabelled carboranes are attrac-
tive synthons in this regard because they can be readily conjugated
to, or incorporated within, targeting vectors using a number of cre-
ative strategies and they are conveniently prepared from virtually
any suitably protected alkyne [1–7]. 7,8-Dicarba-nido-undecab-
orate(-1) or nido-carborane ligands, which can be prepared from
the corresponding closo-carboranes [1,8–12], have a unique feature
in that they can be labelled with both radiometals, including tech-
netium, which is the most widely used radionuclide in diagnostic
medicine [13,14] and radiohalogens. Nido-carboranes form highly
promote non-specific binding. In this paper, we present the syn-
thesis and characterization of a bifunctional carborane-glucose
derivative where the hydrophilic nature of the carbohydrate is de-
signed to mask the non-polar carborane group. Several examples
for other classes of imaging agents have been reported in which
the addition of a carbohydrate reduces non-specific binding and
enhances pharmacokinetics (faster clearance from non-target tis-
sues) versus the underivatized counterparts [36–43].
2. Results and discussion
We recently described the preparation and labelling of simple
carboranyl glycoside derivatives of glucose with both Tc and iodine
[44,45]. Building on the success of the model system, a nido-carb-
oranyl glycoside 1 that contains a benzoic acid group for conjuga-
tion to targeting vectors such as peptides, proteins, or antibodies
was developed (Fig. 1). A non-glycosylated analogue (2) was pre-
pared in parallel so that the impact of the sugar on the overall
polarity of the compounds (i.e. logP) could be determined.
stable
g
5-complexes with metals [15–19] and they can be labelled
with halogens using electrophilic methods analogous to those cur-
rently used to prepare traditional radiopharmaceuticals [20–22].
Iodinated nido-carborane derivatives are attractive platforms for
developing molecular imaging probes because the B–I bond
formed is more robust than aryl C–I bonds, [22–24] thereby cur-
tailing de-iodination in vivo. Not surprisingly, there has been an in-
crease in the number of groups developing targeted
radiopharmaceuticals using radiohalogenated nido-carboranes
[21,22,24–35].
2.1. Preparation of nido-carborane precursors
Compound 1 was prepared in three steps in good overall yield
from the known alkyne 3 [46,47]. A Sonogashira type cross-cou-
pling reaction [48] between 3 and methyl 4-iodo-benzoate [49]
was used to incorporate the benzoic acid group which would later
serve as the location for conjugation to targeting vectors [50–52].
* Corresponding author. Fax: +1 905 522 2509.
E-mail address: valliant@mcmaster.ca (J.F. Valliant).
0022-328X/$ - see front matter Ó 2009 Elsevier B.V. All rights reserved.
doi:10.1016/j.jorganchem.2008.12.063

A.E.C. Green et al. / Journal of Organometallic Chemistry 694 (2009) 1736–1746
1737
agents would not only be useful imaging agents but they would
also be attractive compounds for targeted radionuclide therapy
which requires robust complexes and high target-to-non-target ra-
tios in order to minimize the radiation dose to healthy tissue (see
Scheme 1).
-
OH
-
H
H
O
OH
OH
O
C
C
C
C
H
OH
H
O
O
The non-glycosylated nido-carboranyl benzamide 7 was pre-
pared from the benzoic acid derivative 2 (Scheme 2) using a conve-
nient active ester coupling strategy. The 2,3,5,6-tetrafluorophenyl
active ester 6 was obtained via DIC coupling and isolated by pre-
parative TLC. The benzamide target 7 was then prepared by com-
bining 6 with N,N-diethylethylenediamine in acetonitrile at room
temperature for 12 h; purification by preparative TLC gave the tar-
get in 26% yield.
An alternative route was established to prepare the glycosyl-
ated target 8 because the polar nature of the compounds compli-
cated the isolation of large quantities of the active ester
precursor. To address this issue, the protecting groups were altered
such that a benzyl ester was used in place of the methyl ester
(Scheme 3). This made it possible to liberate the acid without
removing the acetate protecting groups on the carbohydrate,
thereby making it simpler to purify the active ester and benzamide.
Each step in the synthesis had yields greater than 50% with the
exception of the final step which was 35%. This still represents
an improvement over the yield obtained when trying to prepare
the target directly from nido-carboranyl glycoside 1.
1
2
OH
OH
Fig. 1. Functionalized nido-carborane derivatives 1 and 2.
The corresponding carborane was then prepared using a standard
decaborane-alkyne insertion reaction. Simultaneous carborane
cage degradation and ester saponification was achieved using so-
dium hydroxide in methanol which, following work-up, gave 1 in
29% overall yield. The non-glycosylated nido-carborane-benzoic
acid precursor 2 was prepared via a similar route starting with
methyl 4-[1,2-dicarba-closo-dodecaboranyl] benzoate in excellent
yield.
2.2. Preparation of model conjugates
The optimal method for linking 1 and 2 to targeting amines was
investigated using a simple alkylamine (N,N-diethylethylenedi-
amine). This amine was selected to not only probe the reactivity
of the benzoic acid group but to also produce two novel benzam-
ides for use in targeting melanoma. There is a wealth of data in
the literature indicating that N,N-dialkyl(aminoalkyl) benzamides
have high uptake in melanin positive tumour types [22,53–75].
Moreover, Hawthorne and co-workers have demonstrated the
in vivo stability and rapid clearance in biodistribution studies of
radioiodinated benzamides derived from nido-carboranes [22].
The attractive feature of the target carborane-benzamides pro-
posed here over conventional agents containing aryl halides is that
the strength of the boron-iodine bond should prevent the prema-
ture catabolism while the carbohydrate group should decrease
non-specific binding and promote clearance from non-target tis-
sues. If these hypotheses are in fact valid, then the carborane-based
2.3. Syntheses of iodinated nido-carborane standards
The next step was to isolate the non-radioactive iodinated
derivatives 14–16 (Scheme 4), for which small quantities are
needed as reference standards for the radiolabelled analogues
[20]. A sample of 14 was prepared by treating precursor 1 with I2
in ethanol. Analysis by HPLC and electrospray mass spectrometry
indicated complete consumption of the starting material after 2 h
at room temperature, as evidenced by the absence of the HPLC
and MS signals corresponding to 1. The HPLC chromatogram of
the isolated product contained four peaks (Fig. 2, top), with each
peak showing the target anion mass of m/z = 572 for 14 in the
OAc
OAc
O
O
AcO
AcO
AcO
O
O
a
O
O
AcO
OAc
I
H
+
OAc
H
O
CH3
H
O
CH3
4
3
-
OH
O
OAc
O
H
C
O
H
AcO
AcO
b
c
C
O
C
C
O
O
H
OH
OAc
OH
O
CH3
H
H
O
O
5
1
Scheme 1. Reagents and conditions: (a) 5 mol% (Ph3P)4Pd, 5 mol% CuI, 1:1 THF:NEt3, reflux, 12 h; (b) B10H14 (2.0 equiv.), CH3CN, reflux, 48 h; (c) (i) NaOH (20 equiv.), MeOH,
