2-Amino- and 2-alkylthio-4H-3,1-benzothiazin-4-ones: Synthesis, interconversion and enzyme inhibitory activities

Article abstract of DOI:10.3390/molecules14010378

The synthetic access to 2-sec-amino-4H-3,1-benzothiazin-4-ones 2 was explored. Compounds 2 were available from methyl 2-thioureidobenzoates 1, 2-thioureidobenzoic acids 3, and novel 2-thioureidobenzamides 6, respectively, under different conditions. 2-Alk

Full text of DOI:10.3390/molecules14010378

Molecules 2009, 14, 378-402; doi:10.3390/molecules14010378
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
2-Amino- and 2-Alkylthio-4H-3,1-benzothiazin-4-ones:
Synthesis, Interconversion and Enzyme Inhibitory Activities
Hans-Georg Häcker 1, Florian Grundmann 1, Friederike Lohr 1, Philipp A. Ottersbach 1,
Jing Zhou 1, Gregor Schnakenburg 2 and Michael Gütschow 1,*
1
Pharmaceutical Institute, Pharmaceutical Chemistry I, University of Bonn, An der Immenburg 4, D-
53121 Bonn, Germany; E-mails: hhaecker@uni-bonn.de (H-G. H.), floriangrundmann@gmx.de (F.
G.), friederikelohr@gmx.de (F. L.), phil1984@uni-bonn.de (P-A. O.), moshla@uni-bonn.de (J. Z.)
2
Institute of Inorganic Chemistry, University of Bonn, Gerhard-Domagk-Straße 1, D-53121 Bonn,
Germany; E-mail: gschnake@uni-bonn.de (G. S.)
* Author to whom correspondence should be addressed; E-mail: guetschow@uni-bonn.de;
Tel: +49 228 732317; Fax: +49 228 732567.
Received: 26 November 2008; in revised form: 8 January 2009 / Accepted: 12 January 2009 /
Published: 14 January 2009
Abstract: The synthetic access to 2-sec-amino-4H-3,1-benzothiazin-4-ones 2 was
explored. Compounds 2 were available from methyl 2-thioureidobenzoates 1, 2-
thioureidobenzoic acids 3, and novel 2-thioureidobenzamides 6, respectively, under
different conditions. 2-Alkylthio-4H-3,1-benzothiazin-4-ones 5 have been prepared from
anthranilic acid following a two step route. Both, benzothiazinones 2 and 5 underwent ring
cleavage reactions to produce thioureas 1 and 6, respectively. Twelve benzothiazinones
were evaluated as inhibitors against a panel of eight proteases and esterases to identify one
selective inhibitor of human cathepsin L, 2b, and one selective inhibitor of human
leukocyte elastase, 5i.
Keywords: 4H-3,1-Benzothiazin-4-ones; Heterocyclisation; Protease inhibition.

Molecules 2009, 14
379
Introduction
It was the aim of this study to search for synthetic entries to 4H-3,1-benzothiazin-4-ones with
amino or alkylthio substituents at position 2. Representatives of this heterocyclic class are assumed to
possess biological activities since they might provide four heteroatoms as potential hydrogen bond
acceptors and the fused phenyl ring for possible π-π interactions. Analogous 4H-3,1-benzoxazin-4-
ones have attracted considerable attention as serine hydrolase inhibitors. Their interaction with serine
hydrolases involves the acylation of the active-site serine due to enzymatic ring cleavage, followed by
slow deacylation of the acyl-enzyme intermediate [1]. 2-Amino and 2-alkylthio substituted 4H-3,1-
benzoxazin-4-ones have been characterised as potent inhibitors of human leukocyte elastase (HLE) [2–
5], cathepsin G [6, 7], chymase [8], C1r serine protease of the complement system [9, 10], thrombin
[11], and human cytomegalovirus protease [12]. 6-Methyl-2-p-tolylamino-4H-3,1-benzoxazin-4-one
(URB754) was identified as a potent inhibitor of the endocannabinoid-deactivating enzyme
monoacylglycerol lipase [13]. 2-Aryl substituted 4H-3,1-benzoxazin-4-ones have been evaluated as
specific inhibitors of the tissue factor/factor VIIa-induced pathway of coagulation [14].
Biological activities of 4H-3,1-benzothiazin-4-ones and heterocyclic-fused analogues have been
investigated less extensively [15]. Examples include 6-thiaoxanosine, an imidazo[1,5-a][1,3]thiazin-
7(3H)-one riboside with strong antiviral and anticancer properties [16] and the antiproliferative
compound 2-(2,4-dihydroxyphenyl)-4H-3,1-benzothiazin-4-one [17]. 2-Arylamino substituted
thieno[1,3]thiazin-4-ones and analogous [1,3]thiazino[5,4-b]indole-4-ones have been reported as
inhibitors of HLE [18, 19].
We explored the synthetic access to 2-sec-amino-4H-3,1-benzothiazin-4-ones from different educts.
The preparation of 2-alkylthio-4H-3,1-benzothiazin-4-ones and their utility to synthesise 2-amino-4H-
3,1-benzothiazin-4-ones was also investigated. It has been found, that the 2-alkylthio derivatives can
indeed serve as precursors for 2-amino analogues in the course of a two-step conversion. The final
benzothiazinones were evaluated as inhibitors against a panel of proteases and esterases.
Results and Discussion
Our initial approach to produce 2-sec-amino-4H-3,1-benzothiazin-4-ones was the treatment of
methyl 2-thioureidobenzoates 1 with concentrated sulphuric acid. This procedure was introduced to
prepare 2-aminothieno[2,3-d][1,3]thiazin-4-ones [20] and successfully applied to other heterocyclic
systems [18, 19, 21–23]. Recently, Tarzia et al. have prepared the benzothiazine analogue of URB754
that way [24]. Ring closure to 4H-3,1-benzothiazine-4-ones was also achieved by treatment of 2-
benzoylaminothiobenzamide with concentrated sulphuric acid [25].
The new thioureas 1a–h were obtained from methyl 2-isothiocyanatobenzoate and secondary
amines (Scheme 1). The treatment of 1a–e with concentrated sulphuric acid at room temperature
conveniently afforded the desired benzothiazinones 2a–e. The benzyl(methyl)thiourea derivative 1g
was not converted to 2g due to N-debenzylation under the strong acidic conditions used. The
methyl(phenyl)thiourea 1f gave the corresponding benzothiazinone 2f in only 20% yield, and the
methyl(2-phenylethyl)thiourea 1h could not be transformed to 2h. Therefore, an extended synthetic
route was chosen. 1f–h were first hydrolyzed to the corresponding benzoic acid derivatives 3f–h, and
subsequently cyclised with acetic anhydride [26, 27] to yield 2f–h, thus allowing the facile

Molecules 2009, 14
380
introduction of aromatic structures within the 2-substituent of 2. Attempts to directly generate
thioureidobenzoic acids 3 from anthranilic acid, 1,1’-thiocarbonyldiimidazole and secondary amines
failed (data not shown).
Scheme 1. Synthesis and interconversion of 2-amino- and 2-alkylthio-4H-3,1-
benzothiazin-4-ones.
O
O
OMe
ii
OH
NH
NR1R2
NH
S
NR1R2
S
1a−h
3f−h
i
vi
O
iii
vi
(2e)
O
NR1R2
i or vii (6e)
v (2e)
S
N
NR1R2
NH
NR1R2
2a−h
S
6a,c,e
v
(5i)
O
O
iv
S
OH
NH
SR
N
SR
S
5i−l
4i−l
a R1 = R2 = Et
g R1 = Me, R2 = Bn
b R1 = Me, R2 = cyclohexyl h R1 = Me, R2 = CH2CH2Ph
c NR1R2 = 1-pyrrolidinyl
d NR1R2 = 1-piperidinyl
e NR1R2 = 4-morpholinyl
f R1 = Me, R2 = Ph
i R = Me
j R = Et
k R = Bn
l R = CH2CH2Ph
Reagents and conditions: i) concd. H2SO4, r.t.; ii) NaOH, EtOH, H2O, reflux; iii) Ac2O, r.t.;
iv) Ac2O, reflux; v) HNR1R2, acetone, r.t., then reflux; vi) HCl, MeOH, reflux, 3 h; vii) HCl,
MeOH, reflux, 2 min.

Molecules 2009, 14
381
A synthetic access to 2-alkylthio-4H-3,1-benzothiazin-4-ones was envisaged via dithiocarbamates
4i–l, which were prepared from anthranilic acid, carbon disulfide and alkyl halides. These
intermediates underwent an easy cyclocondensation upon treatment with acetic anhydride to furnish
the new 2-alkylthio derivatives 5i–l. Only one representative of this heterocyclic class, i.e. 6,7-
difluoro-2-(methylthio)-4H-3,1-benzothiazin-4-one, has already been described by Mazuoka et al.
[28].
To explore an alternative entry to 2-sec-amino-4H-3,1-benzothiazin-4-ones, the S-methyl derivative
5i was reacted with secondary amines. However, 2-aminobenzothiazinones 2 were not formed and
instead, we obtained 2-thioureidobenzamides 6a,c,e. The attack of an amine on 5i might either occur at
the C-2 or C-4 carbons. An attack at C-2 followed by C-2–S-3 bond breakage would not lead to 6. The
nucleophilic substitution with the release of the methanethiol would generate 2-amino-
benzothiazinones 2. Such intermediates could subsequently undergo ring cleavage due to the attack of
the amine at C-4 to produce 6. When treating the 2-morpholinobenzothiazinone 2e with morpholine
under the conditions used for the conversion of 5i to 6, compound 6e was indeed obtained. However, a
different mechanism was proposed based on the isolation of the intermediate 7 in the reaction of 5i
with morpholine (Scheme 2). Hence, the secondary amine attacks the 2-alkylthiobenzothiazinones 5 at
C-4, followed by ring opening and subsequent transformation of the dithiocarbamate substituent into a
thiourea. Leistner and Wagner reported on a similar formation of 2-thioureidothiobenzamides when
reacting 2-(methylthio)-4H-3,1-benzothiazin-4-thione with secondary amines [29].
With the novel 2-thioureidobenzamides 6 in hand, we also investigated their utility as precursors to
2. Indeed, the corresponding 2-aminobenzothiazinones 2a,c,e were obtained in quantitative yield and
high purity by reacting the benzamide derivatives 6 with concentrated sulphuric acid (Scheme 1).
Heating the 2-thioureidobenzamides 6a,c,e in methanolic hydrochloric acid yielded methyl
thioureidobenzoates 1a,c,e. This transformation is formally an acid-catalyzed amide alcoholysis under
conditions where a simple benzamide such as 4-benzoylmorpholine did not react [30]. A ring closure–
reopening mechanism operative in the conversion of 6 to 1 is initiated by the rapid cyclocondensation
to intermediate 2-aminobenzothiazinones 2. This could be concluded as the product 2e was identified
after short-time treatment of 6e with methanolic hydrochloric acid. Prolonged heating of 2e then led to
the formation of the methyl thioureidobenzoate 1e.
Scheme 2. Reaction pathway from 5i to 6e.
O
O
O
S
i
N
N
O
O
O
N
SMe
NH
SMe
NH
5i
S
S
N
7
6e
Reagents and conditions: i) morpholine, acetone, r.t., 1 h.

Molecules 2009, 14
382
In the course of this study, acetic anhydride was successfully used in cyclocondensations to convert
the benzoic acid derivatives 3 and 4 to benzothiazinones 2 and 5, respectively. Unexpectedly, the
replacement of acetic anhydride by trifluoroacetic anhydride (TFAA) produced different results
(Scheme 3). The treatment of 3h with this reagent gave a mixture of the benzothiazinone 2h and the
benzoxazinone 8h with the latter compound being the dominant product. On the other hand, the
benzothiazinone 5i was the main product of the reaction of 4i with TFAA while the corresponding
benzoxazinone 9i was only formed in traces. The formation of 8h is envisaged to occur by a
nucleophilic attack of the carboxyl oxygen at the activated thiocarbonyl carbon [31–36]. Further
investigations are needed to clarify the mechanism of this desulphurisation-cyclisation.
13
In the C-NMR spectra of the benzothiazinone representatives 2h and 5i the characteristic signals
for C-2/C-4 appeared at 156/184 ppm (2h) and 164/182 ppm (5i). The other benzothiazinones had
similar NMR data. The corresponding chemical shifts of the benzoxazinones were observed at
154/160 ppm (8h) and 164/159 ppm (9i). These values were in accordance with literature data for 4H-
3,1-benzoxazin-4-ones [14, 32, 37–39]. A similar influence of the sulphur-oxygen exchange on the
chemical shift of the C-4 carbon was observed for pairs of 2-thien-2-yl and 2-cyano substituted 4H-
3,1-benzothiazin(oxazin)-4-ones [32, 40]. The structure of the title compounds was furthermore
confirmed by X-ray crystal structure analyses [41] (Figure 1).
The bond lengths within the thiazinone ring of the 2-aminobenzothiazinone 2g and the 2-alkylthio-
benzothiazinone 5k were similar (see Electronic Supplementary Information). The thiazinone rings
adopt an almost planar conformation with the largest deviation from the least square planes defined by
the six atoms of the heterocyclic ring being 0.022(1) Å (2g) and 0.024(2) Å (5k).
Scheme 3. Cyclisation reactions of benzoic acid derivatives 3h and 4i with acetic
anhydride and trifluoroacetic anhydride.
O
N
O
N
X
X
N
SMe
Me
2h X = S
5i X = S
9i
8h
X = O
X = O
Ac2O
3h
3h
4i
2h
TFAA
Ac2O
2h (28%) + 8h (68%)
5i
TFAA
4i
5i
9i
(91%) + (2%)

Molecules 2009, 14
383
Figure 1. X-ray crystal structure of 2-(N-benzyl-N-methylamino)-4H-3,1-benzothiazin-4-
one 2g (left) and of 2-(benzylthio)-4H-3,1-benzothiazin-4-one 5k (right).
2-Aminobenzothiazinones 2a–h and 2-alkylthiobenzothiazinones 5i–l were evaluated as potential
inhibitors of HLE [42] (Table 1). Other representative members of serine proteases (human cathepsin
G, bovine chymotrypsin and bovine trypsin) were also investigated. The compounds were furthermore
assessed towards the cysteine protease human cathepsin L and the metalloprotease angiotensin-
converting enzyme (ACE). Two serine esterases, acetylcholinesterase (AChE) and cholesterol esterase
(CEase), which share the acyl transfer mechanism with serine proteases were also included in the
inhibition studies.
None of the investigated 2-aminobenzothiazinones inhibited HLE. As 2-aminosubstituted 4H-3,1-
benzoxazin-4-ones are potent inhibitors of HLE, a replacement of the ring oxygen by sulphur resulted
in a loss of activity, which can be attributed to the increased intrinsic stability of the benzothiazinones.
The second order rate constant for the alkaline hydrolysis of 2e (1.7 M-1s-1) was significantly lower
than that of the analogous 2-(morpholin-4-yl)-4H-3,1-benzoxazin-4-one (28 M-1s-1) [43]. 2-(N-
Cyclohexyl-N-methylamino)-4H-3,1-benzothiazin-4-one (2b) exhibited a remarkable inhibitory
capacity against human cathepsin L [44]. This compound was selective for cathepsin L with respect to
the other enzymes investigated in this study. It might therefore serve as a lead structure for cysteine
protease inhibitors. Further investigations are needed to inspect selectivity among cysteine proteases.
Two of the 2-alkylthiobenzothiazinones were identified as HLE inhibitors. The 2-methylthio and 2-
ethylthio derivatives, 5i and 5j, exhibited IC50 values in the low micromolar range. These compounds
carry 2-substituents with the least steric demand among all the benzothiazinones tested. HLE has a
primary substrate specificity for small aliphatic amino acid residues at P1 position. It can therefore be
assumed, that the alkylthio moiety is accommodated by the S1 subsite of HLE. The concentration-
dependent inhibition by 5i is presented in Figure 2. The progress curves of the HLE-catalyzed
substrate consumption were linear over the 10-min time course. Thus, the time-independent inhibition
indicated a non-covalent interaction of 5i with HLE. Provided that 5i behaved kinetically as a
competitive inhibitor, a Ki value of 1.2 µM corresponds to the IC50 value of 3.3 µM [45]. Noteworthy,
the 2-methylthiobenzothiazinone 5i did not inhibit any of the other enzymes studied here.

Molecules 2009, 14
384
Table 1. Enzyme inhibitory activities of 2-amino and 2-alkylthio-4H-3,1-benzothiazin-4-ones.
IC50 values
(µM)a
Compound HLE
Cathepsin G Chymotrypsin Trypsin
Cathepsin L ACE
> 50 > 100
AChE
CEase
> 100
> 100
> 100
> 100
> 100
> 25
>100
> 50
> 25
> 100
> 100
> 100
> 100
> 100
> 100
> 100
> 100
> 100
> 100
> 100
> 50
>25
> 25
> 50
> 100
> 50
> 25
> 50
25f
> 50
> 25
> 25
> 50
> 50
2a
2b
2c
2d
2e
2f
> 100
> 100
> 25
8.93 ± 1.58b > 100
> 50
> 50
> 25
> 25
> 100
> 50
> 100
> 50
> 100
> 50
19f
> 100
> 100
> 100
> 100
> 100
> 100
> 100
> 50
> 100
> 100
> 100
> 100
> 100
> 100
> 100
> 100
> 100
> 100
> 50
> 25
10.4 ± 0.5c
22d
> 50
> 25
22e
2g
2h
5i
> 25
> 50
> 50
3.31 ± 0.24g > 100
> 100
> 100
18d
> 100
> 100
> 100
> 100
8.11 ± 0.96b > 100
5j
> 25
> 50
> 100
> 100
5k
5l
> 25
a Limits were calculated from duplicate measurements at one or two inhibitor concentrations.
b Triplicate measurement @ five different inhibitor concentrations, see Electronic Supplementary Information.
c Duplicate measurement @ five different inhibitor concentrations, see Electronic Supplementary Information.
d Duplicate measurement @ one inhibitor concentration (10 µM).
e Duplicate measurement @ two inhibitor concentrations (10, 20 µM).
f Quadruplicate measurement @ one inhibitor concentration (5 µM).
g Duplicate measurement @ five different inhibitor concentrations.
Figure 2. Plot of the steady-state rates versus inhibitor concentration for the inhibition of
HLE by compound 5i.
0.006
0.004
0.002
0
0
4
8
12
[ ] (µM)
16
20
5i
Conclusions
Different routes have been explored to produce 2-sec-amino-4H-3,1-benzothiazin-4-ones 2. A
particularly versatile method involves the easy saponification of methyl 2-thioureidobenzoates 1 to 2-
thioureidobenzoic acids 3, followed by acetic anhydride-promoted cyclocondensation. The preparation
of a series of 2-alkylthio-4H-3,1-benzothiazin-4-ones 5 from anthranilic acid using a two step route

Molecules 2009, 14
385
was demonstrated. We could also show that compounds 5 were cleaved to 2-thioureidobenzamides 6,
which on their own proved to be further precursors to 2-sec-amino-4H-3,1-benzothiazin-4-ones 2.
Unexpectedly, one 2-aminobenzothiazinone, 2b, inhibited human cathepsin L, a cysteine protease of
therapeutic importance. In the course of this study, biological activities of 2-alkylthio-4H-3,1-
benzothiazin-4-ones have been evaluated for the first time, and compound 5i was identified as an
inhibitor of human leukocyte elastase.
Experimental
General
Solvents and reagents were obtained from Acros (Geel, Belgium), Fluka (Taufkirchen, Germany) or
Sigma (Steinheim, Germany), if commercially available. Human leukocyte elastase (HLE), human
cathepsin G, human cathepsin L and human angiotensin-converting enzyme (ACE) were obtained from
Calbiochem, Darmstadt, Germany. MeOSuc-Ala-Ala-Pro-Val-pNA, Suc-Ala-Ala-Pro-Phe-pNA, Suc-
Ala-Ala-Pro-Arg-pNA, Z-Phe-Arg-pNA, and 2-furanacryloyl-phenylalanylglycylglycine (FA-Phe-
Gly-Gly) were purchased from Bachem (Bubendorf, Switzerland). Bovine chymotrypsin was
purchased from Fluka (Deisenhofen, Germany). Trypsin from bovine pancreas, acetylcholinesterase
(AChE) from Electrophorus electricus, cholesterol esterase (CEase) from bovine pancreas, 5,5’-dithio-
bis-(2-nitrobenzoic acid) (DTNB), sodium taurocholate (TC), and para-nitrophenylbutyrate (pNPB)
were purchased from Sigma (Steinheim, Germany). Methyl 2-isothiocyanatobenzoate was prepared
under the conditions reported by Carpenter et al. [46]. Thin-layer chromatography was carried out on
Merck aluminum sheets, silica gel 60 F254. Preparative column chromatography was performed on
Merck silica gel 60, 70–230 mesh. Melting points were determined on a Boëtius melting point
apparatus (PHMK, VEB Wägetechnik Rapido, Radebeul, Germany) and are uncorrected. 1H- and 13C-
NMR spectra were acquired on a Bruker Avance DRX 500 spectrometer operating at 500 MHz for 1H
and 125 MHz for 13C. Chemical shifts δ are given in ppm referring to the signal center using the
solvent peaks for reference: CDCl3 7.26 ppm/77.0 ppm and DMSO-d6 2.49 ppm/39.7 ppm. The NMR
1
1
signals were assigned by two-dimensional H,1H COSY and H,13C correlation spectra (HSQC,
HMBC) using standard pulse sequences. Elemental analyses were carried out with a Vario EL
apparatus. The spectrophotometric assays were done on Varian Cary 50 Bio and Varian Cary 100 Bio
UV/VIS spectrometers with a cell holder equipped with a constant temperature water bath.
Methyl 2-(3,3-diethylthioureido)benzoate (1a)
Method 1: Diethylamine (0.476 g, 6.5 mmol) was added dropwise to a stirring solution of methyl 2-
isothiocyanatobenzoate (0.966 g, 5.0 mmol) in CH2Cl2 (20 mL). The reaction mixture was stirred at r.t.
for 3 h. The organic layer was washed with HCl (0.5 M, 2 × 5 mL), dried over Na2SO4, filtered, and
evaporated to dryness. Recrystallisation from EtOH yielded 1a (0.946 g, 71%) as colourless needles,
mp 85–87 °C (EtOH); 1H-NMR (CDCl3) δ 1.34 (t, J = 6.9 Hz, 6H, CH2CH3), 3.82 (q, J = 6.9 Hz, 4H,
CH2CH3), 3.88 (s, 3H, CO2CH3), 7.03 (ddd, J = 8.2, 7.3, 1.3 Hz, 1H, 5-H), 7.48 (ddd, J = 8.6, 7.3,
1.6 Hz, 1H, 4-H), 7.93 (dd, J = 8.2, 1.6 Hz, 1H, 6-H), 8.73 (dd, J = 8.6, 1.3 Hz, 1H, 3-H), 10.66 (s,

Molecules 2009, 14
386
1H, NH); 13C-NMR (CDCl3) δ 12.46 (CH2CH3), 45.68 (CH2CH3), 52.31 (CO2CH3), 116.86 (C-1),
122.22 (C-5), 123.62 (C-3), 130.22 (C-6), 132.82 (C-4), 143.28 (C-2), 168.99 (CO2CH3), 179.23
(NHCS); Anal. calcd. for C13H18N2O2S: C, 58.6; H, 6.8; N, 10.5. Found: C, 58.4; H, 6.8; N, 10.4.
Method 2: 2-(3,3-Diethylthioureido)-N,N-diethylbenzamide (6a, 0.307 g, 1.0 mmol) was heated to
reflux in anhydrous methanolic HCl (0.25 M, 5 mL) for 3 h. The mixture was allowed to cool to r.t.
and kept at -15 °C. The precipitate was removed by suction filtration to give 1a (0.169 g, 63%) as
white needles.
Methyl 2-(3-cyclohexyl-3-methylthioureido)benzoate (1b)
According to the preparation of 1a (Method 1), 1b (1.50 g, 98%) was obtained from methyl 2-
isothiocyanatobenzoate and N-methylcyclohexylamine as a semisolid crude material. 1H-
NMR (CDCl3) δ 1.05–1.95 (m, 10H, 2’/3’/4’/5’/6’-H), 3.20 (s, 3H, NCH3), 3.88 (s, 3H, CO2CH3), 7.03
(ddd, J = 8.2, 7.1, 1.3 Hz, 1H, 5-H), 7.48 (ddd, J = 8.8, 7.1, 1.6 Hz, 1H, 4-H), 7.93 (dd, J = 8.2,
1.6 Hz, 1H, 6-H), 8.71(d, J = 8.2 Hz, 1H, 3-H), 10.70 (s, 1H, NH); 13C-NMR (CDCl3) δ 25.48 (C-4’),
25.54 (C-3’/5’), 30.01 (C-2’/6’), 32.57 (NCH3), 52.29 (CO2CH3), 59.23 (C-1’), 116.74 (C-1), 122.16
(C-5), 123.35 (C-3), 130.23 (C-6), 132.86 (C-4), 143.27 (C-2), 168.99 (CO2CH3), 179.90 (NHCS);
Anal. calcd. for C16H22N2O2S: C, 62.7; H, 7.2; N, 9.1. Found: C, 62.7; H, 6.7; N, 9.0.
Methyl 2-[(1-pyrrolidinylthiocarbonyl)amino]benzoate (1c)
Method 1: According to the preparation of 1a (Method 1), 1c (1.32 g, 82%) was obtained from
1
methyl 2-isothiocyanatobenzoate and pyrrolidine as colourless needles, mp 124–127 °C (EtOH); H-
NMR (CDCl3) δ 1.87–2.16 (m, 4H, 3’/4’-H), 3.65–3.96 (m, 7H, CO2CH3, 2’/5’-H), 7.04 (ddd, J = 7.9,
7.3, 1.3 Hz, 1H, 5-H), 7.51 (ddd J = 8.5, 7.3, 1.6 Hz, 1H, 4-H), 7.95 (dd, J = 7.9, 1.6 Hz, 1H, 6-H),
13
9.00 (dd, J = 8.5, 1.0 Hz, 1H, 3-H), 10.82 (s, 1H, NH); C-NMR (CDCl3) δ 24.59, 26.20 (C-3’/4’),
48.30, 52.13 (C-2’/5’), 52.33 (CO2CH3), 116.40 (C-1), 122.26, 122.65 (C-3/5), 130.35 (C-6), 133.16
(C-4), 142.88 (C-2), 169.05 (CO2CH3), 176.47 (NHCS); Anal. calcd. for C13H16N2O2S: C, 59.1; H,
6.1; N, 10.6. Found: C, 59.1; H, 6.35; N, 10.5.
Method 2: According to the preparation of 1a (Method 2), 1c (0.222 g, 84%) was obtained from 6c
as colourless needles.
Methyl 2-[(1-piperidinylthiocarbonyl)amino]benzoate (1d)
According to the preparation of 1a (Method 1), 1d (1.11 g, 80%) was obtained from methyl 2-
isothiocyanatobenzoate and piperidine as colourless plates, mp 116–117 °C (EtOH); 1H-NMR (CDCl3)
δ 1.68–1.73 (m, 6H, 3’/4’/5’-H), 3.88 (s, 3H, CO2CH3), 3.95–4.01 (m, 4H, 2’/6’-H), 7.02 (ddd, J = 8.2,
7.3, 1.3 Hz, 1H, 5-H), 7.48 (ddd, J = 8.8, 7.3, 1.6 Hz, 1H, 4-H), 7.93 (dd, J = 8.1, 1.8 Hz, 1H, 6-H),
13
8.53 (dd, J = 8.5, 1.3 Hz, 1H, 3-H), 10.75 (s, 1H, NH); C-NMR (CDCl3) δ 24.40 (C-4’), 25.67 (C-
3’/5’), 49.68 (C-2’/6’), 52.33 (CO2CH3), 116.41 (C-1), 122.04 (C-5), 123.03 (C-3), 130.33 (C-6),
132.97 (C-4), 143.40 (C-2), 169.06 (CO2CH3), 179.60(NHCS); Anal. calcd. for C14H18N2O2S: C, 60.4;
H, 6.5; N, 10.1. Found: C, 60.6; H, 6.55; N, 10.1.

Molecules 2009, 14
387
Methyl 2-[(4-morpholinylthiocarbonyl)amino]benzoate (1e)
Method 1: According to the preparation of 1a, 1e (1.11 g, 80%) was obtained from methyl 2-
isothiocyanatobenzoate and morpholine as a white solid, mp 103–107 °C (EtOH), lit. [47] 106–
1
110 °C); H-NMR (CDCl3) δ 3.79 (t, J = 4.9 Hz, 4H, 2’/6’-H), 3.89 (s, 3H, CO2CH3), 4.04 (t,
J = 4.9 Hz, 4H, 3’/5’-H), 7.06 (ddd, J = 8.2, 6.9, 1.3 Hz, 1H, 5-H), 7.51 (ddd, J = 8.6, 7.3, 1.6 Hz, 1H,
4-H), 7.96 (dd, J = 8.1, 1.6 Hz, 1H, 6-H), 8.67 (dd, J = 8.5, 1.0 Hz, 1H, 3-H), 10.97 (s, 1H, NH); 13C-
NMR (CDCl3) δ 48.25 (C-3’/5’), 52.48 (CO2CH3), 66.29 (C-2’/6’), 116.57 (C-1), 122.58, 122.93 (C-
3/5), 130.43 (C-6), 133.19 (C-4), 142.95 (C-2), 169.19 (CO2CH3), 180.72 (NHCS); Anal. calcd. for
C13H16N2O3S: C, 55.7; H, 5.75; N, 10.0. Found: C, 56.0; H, 5.9; N, 9.8.
Method 2: According to the preparation of 1a (Method 2), 1e (0.229 g, 82%) was obtained from 6e
as a light yellow solid.
Method 3: 2-(Morpholin-4-yl)-4H-3,1-benzothiazin-4-one (2e, 0.160 g, 0.64 mmol) was heated to
reflux in anhydrous methanolic HCl (0.25 M, 3 mL) for 3 h. The mixture was allowed to cool to r.t.
and kept at -15 °C. The precipitate was removed by suction filtration to give 1e (0.151 g, 84%) as a
light yellow solid.
Methyl 2-(3-methyl-3-phenylthioureido)benzoate (1f)
According to the preparation of 1a (Method 1), 1f (1.28 g, 84%) was obtained from methyl 2-
1
isothiocyanatobenzoate and N-methylaniline as colourless needles, mp 70–71 °C (EtOH); H-
NMR (DMSO-d6) δ 3.61 (s, 3H, NCH3), 3.70 (s, 3H, CO2CH3), 7.15–7.17 (m, 1H, 5-H), 7.39–7.45 (m,
3H, 2’/4’/6’-H), 7.50–7.55 (m, 3H, 4/3’/5’-H), 7.77 (dd, J = 8.2, 1.6 Hz, 1H, 6-H), 8.24 (dd, J = 8.4,
13
1.0 Hz, 1H, 3-H), 9.67 (s, 1H, NH); C-NMR (DMSO-d6) δ 43.28 (NCH3), 52.44 (CO2CH3), 120.31
(C-1), 123.65 (C-5), 125.06 (C-3), 127.01 (C-2’/6’), 128.27 (C-4’), 130.01 (C-6), 130.26 (C-3’/5’),
132.46 (C-4), 141.32 (C-2), 143.71 (C-1’), 167.08 (CO2CH3), 180.48 (NHCS); Anal. calcd. for
C16H16N2O2S: C, 64.0; H, 5.4; N, 9.3. Found: C, 63.7; H, 5.4; N, 9.3.
Methyl 2-(3-benzyl-3-methylthioureido)benzoate (1g)
According to the preparation of 1a (Method 1), 1g (1.45 g, 92%) was obtained from methyl 2-
1
isothiocyanatobenzoate and N-benzylmethylamine as white plates, mp 88–92 °C (EtOH); H-
NMR (CDCl3) δ 3.30 (s, 3H, NCH3), 3.87 (s, 3H, CO2CH3), 5.25 (s, 2H, CH2Ph), 7.08 (ddd, J = 8.4,
7.1, 1.3 Hz, 1H, 5-H), 7.26–7.28 (m, 1H, 4’-H), 7.29–7.34 (m, 4H, 2’/3’/5’/6’-H), 7.53 (ddd, J = 8.5,
7.3, 1.6 Hz, 1H, 4-H), 7.96 (dd, J = 7.9, 1.6 Hz, 1H, 6-H), 8.87 (d, J = 8.6 Hz, 1H, 3-H), 10.93 (s, 1H,
13
NH); C-NMR (CDCl3) δ 37.63 (NCH3), 52.36 (CO2CH3), 56.78 (CH2Ph), 117.06 (C-1), 122.64 (C-
5), 123.42 (C-3), 127.52 (C-2’/6’), 127.58 (C-4’), 128.72 (C-3’/5’), 130.31 (C-6), 133.01 (C-4), 136.43
(C-1’), 142.98 (C-2), 168.95 (CO2CH3), 180.94 (NHCS); Anal. calcd. for C17H18N2O2S: C, 64.9; H,
5.8; N, 8.9. Found: C, 64.9; H, 6.05; N, 8.9.
Methyl 2-[3-methyl-3-(2-phenylethyl)thioureido]benzoate (1h)
According to the preparation of 1a (Method 1), 1h (1.47 g, 90%) was obtained from methyl 2-
isothiocyanatobenzoate and N-methyl phenethylamine as a semisolid crude material; 1H-

Molecules 2009, 14
388
NMR (CDCl3) δ 3.07 (t, J = 7.9 Hz, 2H, CH2CH2Ph), 3.28 (s, 3H, NCH3), 3.90 (s, 3H, CO2CH3),
4.05–4.14 (m, 2H, CH2CH2Ph), 7.06 (ddd, J = 8.2, 6.9, 1.3 Hz, 1H, 5-H), 7.19–7.23 (m, 1H, 4’-H),
7.27–7.31 (m, 4H, 2’/3’/5’/6’-H), 7.51 (ddd, J = 8.6, 7.2, 1.6 Hz, 1H, 4-H), 7.96 (dd, J = 7.9, 1.6 Hz,
13
1H, 6-H), 8.80 (d, J = 8.6 Hz, 1H, 3-H), 10.84 (s, 1H, NH); C-NMR (CDCl3) δ 33.38 (CH2CH2Ph),
39.22 (NCH3), 52.35 (CO2CH3), 55.82 (CH2CH2Ph), 116.80 (C-1) 122.41 (C-5), 123.27 (C-3), 126.52
(C-4’), 128.60 (C-2’/6’), 128.91 (C-3’/5’), 130.27 (C-6), 132.99 (C-4), 138.55 (C-1’), 143.05 (C-2),
169.02 (CO2CH3), 179.87 (NHCS); Anal. calcd. for C18H20N2O2S: C, 65.8; H, 6.1; N, 8.5. Found: C,
64.9; H, 5.8; N, 8.9.
2-(Diethylamino)-4H-3,1-benzothiazin-4-one (2a)
Method 1: Methyl 2-(3,3-diethylthioureido)benzoate (1a, 0.799 g, 3.0 mmol) was kept in
concd. H2SO4 (12 mL) at r.t. for 24 h. The solution was poored into a mixture of ice–water (100 mL)
and EtOAc (100 mL). After neutralization, the aqueous layer was further extracted with EtOAc (2 ×
100 mL). The combined organic layers were dried over Na2SO4, filtered, and evaporated to dryness.
Recrystallisation from MeOH yielded 2a (0.505 g, 72%) as colourless needles, mp 74–75 °C (MeOH),
1
lit. [43] 72–74 °C; H-NMR (CDCl3) δ 1.24 (t, J = 7.3 Hz, 6H, CH2CH3), 3.59 (q, J = 7.3 Hz, 4H,
CH2CH3), 7.10 (ddd, J = 8.2, 7.6, 1.3 Hz, 1H, 6-H), 7.37 (dd, J = 7.9, 1.3 Hz, 1H, 8-H), 7.55 (ddd,
J = 8.5, 6.9, 1.6 Hz, 1H, 7-H), 8.00 (dd, J = 8.0, 1.6 Hz, 1H, 5-H); 13C-NMR (CDCl3) δ 13.03
(CH2CH3), 43.35 (CH2CH3), 116.29 (C-4a), 122.93 (C-6), 124.71 (C-5), 128.21 (C-8), 135.61 (C-7),
151.50 (C-8a), 155.43 (C-2), 184.52 (C-4); Anal. calcd. for C12H14N2OS: C, 61.5; H, 6.0; N, 12.0.
Found: C, 61.5; H, 6.0; N, 12.0.
Method 2: 2-(3,3-Diethylthioureido)-N,N-diethylbenzamide 6a (0.615 g, 2.0 mmol) was treated
with concd. H2SO4 (8 mL) as described under Method 1 obtaining 2a (0.449 g, 96%) as a white solid.
2-(N-Cyclohexyl-N-methylamino)-4H-3,1-benzothiazin-4-one (2b)
According to the preparation of 2a (Method 1), 2b (0.607 g, 74%) was obtained from 1b as
1
colourless plates, mp 111–114 °C (EtOH); H-NMR (CDCl3) δ 1.05–1.88 (m, 10H, 2’/3’/4’/5’/6’-H),
3.05 (s, 3H, NCH3), 4.22 (br s, 1H, 1’-H), 7.10 (ddd, J = 8.2, 6.9, 1.3 Hz, 1H, 6-H), 7.38 (dd, J = 8.2,
13
1.3 Hz, 1H, 8-H), 7.56 (ddd, J = 8.5, 6.9, 1.6 Hz, 1H, 7-H), 8.00 (dd, J = 8.2, 1.6 Hz, 1H, 5-H); C-
NMR (CDCl3) δ 25.40 (C-4’), 25.73 (C-3’/5’), 30.14 (C-2’/6’), 30.45 (NCH3), 56.82 (C-1’), 116.50
(C-4a), 123.01 (C-6), 124.75 (C-5), 128.18 (C-8), 135.64 (C-7), 151.36 (C-8a), 156.68 (C-2), 184.48
(C-4); Anal. calcd. for C15H18N2OS: C, 65.7; H, 6.6; N, 10.2. Found: C, 65.4; H, 6.6; N, 10.1.
2-(Pyrrolidin-1-yl)-4H-3,1-benzothiazin-4-one (2c)
Method 1: According to the preparation of 2a (Method 1), 2c (0.514 g, 74%) was obtained from 1c
as white needles, mp 105–107 °C (EtOH); 1H-NMR (CDCl3) δ 1.97–2.04 (m, 4H, 3’/4’-H), 3.58 (br s,
4H, 2’/5’-H), 7.10 (ddd, J = 8.2, 6.9, 1.3 Hz, 1H, 6-H), 7.39 (dd, J = 8.2, 1.0 Hz, 1H, 8-H), 7.56 (ddd,
J = 8.5, 7.3, 1.6 Hz, 1H, 7-H), 8.01 (dd, J = 8.4, 1.6 Hz, 1H, 5-H); 13C-NMR (CDCl3) δ 24.97 (C-
3’/4’), 47.67 (C-2’/5’), 116.58 (C-4a), 122.87 (C-6), 124.86 (C-5), 128.06 (C-8), 135.65 (C-7), 151.57

Molecules 2009, 14
389
(C-8a), 154.62 (C-2), 184.22 (C-4); Anal. calcd. for C12H12N2OS: C, 62.0; H, 5.2; N, 12.1. Found: C,
61.9; H, 5.3; N, 11.9.
Method 2: According to the preparation of 2a (Method 2), 2c (0.435 g, 94%) was obtained from 6c
as a light yellow solid.
2-(Piperidin-1-yl)-4H-3,1-benzothiazin-4-one (2d)
According to the preparation of 2a (Method 1), 2d (0.594 g, 80%) was obtained from 1d as white
1
needles, mp 87–88 °C (EtOH); H-NMR (CDCl3) δ 1.60–1.72 (m, 6H, 3’/4’/5’-H), 3.67–3.72 (m, 4H,
2’/6’-H), 7.12 (ddd, J = 8.2, 6.9, 1.3 Hz, 1H, 6-H), 7.36 (dd, J = 8.2, 1.0 Hz, 1H, 8-H), 7.56 (ddd,
J = 8.5, 6.9, 1.6 Hz, 1H, 7-H), 8.00 (dd, J = 7.9, 1.6 Hz, 1H, 5-H); 13C-NMR (CDCl3) δ 24.64 (C-4’),
25.62 (C-3’/5’), 46.84 (C-2’/6’), 116.36 (C-4a), 123.28 (C-6), 124.81 (C-5), 128.13 (C-8), 135.69 (C-
7), 151.22 (C-8a), 156.27 (C-2), 184.29 (C-4); Anal. calcd. for C13H14N2OS: C, 63.4; H, 5.7; N, 11.4.
Found: C, 63.35; H, 5.9; N, 11.3.
2-(Morpholin-4-yl)-4H-3,1-benzothiazin-4-one (2e)
Method 1: According to the preparation of 2a (Method 1), 2e (0.395 g, 53%) was obtained from 1e
1
as colourless needles, mp 137–138 °C (EtOH), lit. [48] 136–137 °C; H-NMR (CDCl3) δ 3.71–3.79
(m, 8H, 2’/3’/5’/6’-H), 7.18 (ddd, J = 8.0, 6.9, 1.3 Hz, 1H, 6-H), 7.38 (dd, J = 8.2, 1.3 Hz, 1H, 8-H),
7.60 (ddd, J = 8.5, 6.9, 1.6 Hz, 1H, 7-H), 8.02 (dd, J = 8.1, 1.7 Hz, 1H, 5-H); 13C-NMR (CDCl3) δ
45.90 (C-3’/5’), 66.40 (C-2’/6’), 116.74 (C-4a), 124.08 (C-6), 124.95 (C-5), 128.32 (C-8), 135.88 (C-
7), 150.45 (C-8a), 156.75 (C-2), 183.44 (C-4); Anal. calcd. for C12H12N2O2S: C, 58.05; H, 4.9; N,
11.3. Found: C, 58.1; H, 4.9; N, 11.2.
Method 2: According to the preparation of 2a (Method 2), 2e (0.453 g, 92%) was obtained from 6e
as light yellow needles.
Method 3:
N-[2-(Morpholin-4-ylcarbonyl)phenyl]morpholine-4-carbothioamide (6e,
0.711 g,
2.0 mmol) was heated under reflux in anhydrous methanolic HCl (0.25 M, 10 mL) for 2 min. After
cooling to r.t., the precipitate was removed by suction filtration, washed with H2O (30 mL), dried
under vacuo to give 2e (0.380 g, 77%) as light yellow needles.
2-(N-Methyl-N-phenylamino)-4H-3,1-benzothiazin-4-one (2f)
Method 1: According to the preparation of 2a (Method 1), 2f (0.160 g, 20%) was obtained from 1f
1
as colourless needles, mp 78–79 °C (EtOH); H-NMR (CDCl3) δ 3.59 (s, 3H, NCH3), 7.18 (ddd,
J = 8.2, 6.9, 1.3 Hz, 1H, 6-H), 7.25–7.29 (m, 2H, 2’/6’-H), 7.37–7.42 (m, 1H, 4’-H), 7.42–7.47 (m,
2H, 3’/5’-H), 7.51 (dd, J = 8.2, 1.0 Hz, 1H, 8-H), 7.62 (ddd, J = 8.5, 6.9, 1.6 Hz, 1H, 7-H), 8.02 (dd,
13
J = 8.0, 1.6 Hz, 1H, 5-H); C-NMR (CDCl3) δ 39.93 (NCH3), 117.07 (C-4a), 123.93 (C-6), 125.00
(C-5), 128.26 (C-2’/6’), 128.29 (C-8), 128.76 (C-4’), 130.16 (C-3’/5’), 135.72 (C-7), 142.20 (C-1’),
150.50 (C-8a), 156.97 (C-2), 184.20 (C-4); Anal. calcd. for C15H12N2OS: C, 67.1; H, 4.5; N, 10.4.
Found: C, 67.0; H, 4.6; N, 10.4.

Molecules 2009, 14
390
Method 2: 2-(3-Methyl-3-phenylthioureido)benzoic acid (3f, 0.859 g, 3.0 mmol) and Ac2O (7.0 mL)
were kept at r.t. for 12 h. The solvent was removed under reduced pressure. Recrystallisation from
EtOH gave 2f (0.346 g, 43%).
2-(N-Benzyl-N-methylamino)-4H-3,1-benzothiazin-4-one (2g)
2-(3-Benzyl-3-methylthioureido)benzoic acid (3g, 0.150 g, 0.50 mmol) and Ac2O (1.0 mL) were
kept at r.t. for 8 h. The resulting crystals were removed by suction filtration to obtain 2g (0.109 g,
1
77%) as colourless needles, mp 70–71 °C; H-NMR (CDCl3) δ 3.13 (s, 3H, NCH3), 4.87 (s, 2H,
CH2Ph), 7.15 (ddd, J = 8.0, 6.9, 1.0 Hz, 1H, H-6), 7.26–7.36 (m, 5H, H-2’/3’/4’/5’/6’), 7.42 (dd,
J = 8.2, 1.0 Hz, 1H, H-8), 7.59 (ddd, J = 8.4, 6.9, 1.6 Hz, 1H, H-7), 8.03 (dd, J = 8.0, 1.6 Hz, 1H, H-
5); 13C-NMR (CDCl3) δ 35.95 (NCH3), 53.56 (CH2Ph), 116.34 (C-4a), 123.42 (C-6), 124.84 (C-5),
127.58 (C-2’/6’), 127.73 (C-4’), 128.30 (C-8), 128.79 (C-3’/5’), 135.76 (C-7), 136.31 (C-1’), 151.04
(C-8a), 157.07 (C-2), 183.95 (C-4); Anal. calcd. for C16H14N2OS: C, 68.1; H, 5.0; N, 9.9. Found: C,
67.7; H, 5.2; N, 9.8.
2-[N-Methyl-N-(2-phenylethyl)amino]-4H-3,1-benzothiazin-4-one (2h)
Method 1: According to the preparation of 2f (Method 2), 2h (0.578 g, 65%) was obtained from 3h
as a white solid, mp 72–75 °C (EtOH); 1H-NMR (CDCl3) δ 2.96 (t, J = 7.6 Hz, 2H, CH2CH2Ph), 3.08
(s, 3H, NCH3), 3.81 (t, J = 7.6 Hz, 2H, CH2CH2Ph), 7.14 (ddd, J = 8.2, 7.1, 1.3 Hz, 1H, 6-H), 7.20–
7.33 (m, 5H, 2’/3’/4’/5’/6’-H), 7.44 (dd, J = 8.2, 1.0 Hz, 1H, 8-H), 7.59 (ddd, J = 8.2, 6.9, 1.6 Hz, 1H,
7-H), 8.03 (dd, J = 7.9, 1.6 Hz, 1H, 5-H); 13C-NMR (CDCl3) δ 33.76 (CH2CH2Ph), 37.07 (NCH3),
53.03 (CH2CH2Ph), 116.23 (C-4a), 123.38 (C-6), 124.83 (C-5), 126.68 (C-4’), 128.18 (C-8), 128.70
(C-2’/6’), 128.84 (C-3’/5’), 135.77 (C-7), 138.32 (C-1’), 150.90 (C-8a), 156.35 (C-2), 183.91 (C-4);
Anal. calcd. for C17H16N2OS: C, 68.9; H, 5.4; N, 9.45. Found: C, 68.9; H, 5.4; N, 9.5.
Method 2: 2-[3-Methyl-3-(2-phenylethyl)thioureido]benzoic acid (3h, 0.940 g, 3.0 mmol) and
TFAA (7.0 mL) were kept at r.t. for 12 h. After removal of the solvent, the resulting crude material
was purified by column chromatography on silica using petroleum ether/EtOAc (8+1) as eluent to give
2h (0.249 g, 28%) as a yellowish solid.
2-(3-Methyl-3-phenylthioureido)benzoic acid (3f)
A mixture of methyl 2-(3-methyl-3-phenylthioureido)benzoate (1f, 0.601 g, 2.0 mmol), aqueous
NaOH (1 M, 10 mL) and EtOH (10 mL) was heated to reflux for 1 h. The reaction was allowed to cool
to r.t. and H2O (30 mL) was added. After filtration and cooling to 0 °C, the solution was slowly
acidified with concd. HCl. The precipitate was removed by suction filtration and washed with H2O
(50 mL) to obtain 3f (0.378 g, 66%) as a white solid, mp 135–138 °C; 1H-NMR (DMSO-d6) δ 3.61 (s,
3H, NCH3), 7.08 (ddd, J = 8.2, 6.9, 1.3 Hz, 1H, 5-H), 7.38–7.41 (m, 3H, 2’/4’/6’-H), 7.48–7.51 (m,
3H, 4/3’/5’-H), 7.80 (dd, J = 7.9, 1.6 Hz, 1H, 6-H), 8.68 (dd, J = 8.5, 1.0 Hz, 1H, 3-H), 10.54 (s, 1H,
NH), 13.33 (br s, 1H, CO2H); 13C-NMR (DMSO-d6) δ 43.23 (NCH3), 118.36 (C-1), 122.75, 122.98 (C-
3/5), 127.12 (C-2’/6’), 128.45 (C-4’), 130.32 (C-3’/5’), 130.40 (C-6), 132.43 (C-4), 142.13, 143.53 (C-

Molecules 2009, 14
391
2/1’), 169.33 (CO2H), 179.74 (NHCS); Anal. calcd. for C15H14N2O2S: C, 62.9; H, 4.9; N, 9.8. Found:
C, 62.7; H, 5.1; N, 9.7.
2-(3-Benzyl-3-methylthioureido)benzoic acid (3g)
According to the preparation of 3f, compound 3g (0.365 g, 61%) was obtained from 1g as a white
1
solid, mp 117–119 °C; H-NMR (DMSO-d6) δ 3.24 (s, 3H, NCH3), 5.19 (s, 2H, CH2Ph), 7.17 (ddd,
J = 8.2, 7.3, 1.0 Hz, 1H, 5-H), 7.25–7.29 (m, 5H, 2’/3’/4’/5’/6’-H), 7.54 (ddd, J = 8.5, 7.3, 1.3 Hz, 1H,
4-H), 7.92 (dd, J = 7.9, 1.3 Hz, 1H, 6-H), 8.44 (dd, J = 8.5, 1.0 Hz, 1H, 3-H), 10.75 (s, 1H, NH), 13.46
(br s, 1H, CO2H); 13C-NMR (DMSO-d6) δ 37.78 (NCH3), 55.92 (CH2Ph), 120.41 (C-1), 123.34 (C-5),
124.50 (C-3), 127.26 (C-2’/6’), 127.32 (C-4’), 128.66 (C-3’/5’), 130.54 (C-6), 132.42 (C-4), 137.11
(C-2), 142.55 (C-1’), 169.42 (CO2H), 180.53 (NHCS); Anal. calcd. for C16H16N2O2S: C, 64.0; H, 5.4;
N, 9.3. Found: C, 63.8; H, 5.5; N, 9.5.
2-[3-Methyl-3-(2-phenylethyl)thioureido]benzoic acid (3h)
According to the preparation of 3f, compound 3h (0.509 g, 81%) was obtained from 1h as a light
1
yellow solid, mp 130–133 °C; H-NMR (DMSO-d6) δ 2.97 (t, J = 7.9 Hz, 2H, CH2CH2Ph), 3.25 (s,
3H, NCH3), 4.02 (t, J = 7.6 Hz, 2H, CH2CH2Ph), 7.12–7.16 (m, 1H, 5-H), 7.19–7.23 (m, 1H, 4-H’),
7.28–7.31 (m, 4H, 2’/3’/5’/6’-H), 7.53 (ddd, J = 8.5, 7.3, 1.6 Hz, 1H, 4-H), 7.92 (dd, J = 7.9, 1.6 Hz,
1H, 6-H), 8.46 (d, J = 7.9 Hz, 1H, 3-H), 10.71 (s, 1H, NH), 13.52 (br s, 1H, CO2H); 13C-
NMR (DMSO-d6) δ 32.69 (CH2CH2Ph), 54.78 (CH2CH2Ph), 119.45 (C-1), 122.91 (C-5), 123.95 (C-3),
126.42 (C-4’), 128.54, 128.91 (C-2’/3’/5’/6’), 130.52 (C-6), 132.45 (C-4), 138.83 (C-2), 142.69 (C-1’),
169.69 (CO2H), 179.32 (NHCS); Anal. calcd. for C17H18N2O2S: C, 64.9; H, 5.8; N, 8.9. Found: C,
64.6; H, 6.1; N, 8.7.
2-[(Methylthio)thiocarbonylamino]benzoic acid (4i)
Triethylamine (1.70 g, 16.8 mmol) was added dropwise to an ice-cooled solution of anthranilic acid
(0.960 g, 7.0 mmol) and carbon disulfide (1.07 g, 14.0 mmol) in 1,4-dioxane (30 mL). The cooled
mixture was stirred for 5.5 h, followed by a dropwise addition of methyl iodide (1.09 g, 7.7 mmol) in
1,4-dioxane (20 mL). After stirring for further 1.5 h in the ice-bath, the reaction mixture was allowed
to warm to r.t. and stirred for 21 h under light protection. The solvent was removed under reduced
pressure, and the crude material was partionated between EtOAc (100 mL) and HCl (0.2 M, 100 mL).
The aqueous phase was further extracted with EtOAc (2 × 200 mL). The combined organic layers were
dried (Na2SO4), filtered and evaporated to dryness. Recrystallisation from PhMe gave 4i (1.22 g, 77%)
as light yellow needles, mp 148–150 °C (PhMe); 1H-NMR (DMSO-d6) δ 2.59 (s, 3H, SCH3), 7.36 (td,
J = 7.9, 1.3 Hz, 1H, 5-H), 7.61 (ddd, J = 8.2, 7.0, 1.6 Hz, 1H, 4-H), 7.94 (dd, J = 7.9, 1.6 Hz, 1H, 6-
H), 8.12 (d, J = 7.9 Hz, 1H, 3-H), 11.95 (br s, 1H, NH); 13C-NMR (DMSO-d6) δ 18.11 (SCH3), 124.15
(C-1), 125.71 (C-3), 126.37 (C-5), 131.06 (C-6), 132.95 (C-4), 139.93 (C-2), 167.96 (CO2H), 198.06
(NHCS); Anal. calcd. for C9H9NO2S2: C, 47.6; H, 4.0; N, 6.2. Found: C, 47.3; H, 4.3; N, 6.2.

Molecules 2009, 14
392
2-[(Ethylthio)thiocarbonylamino]benzoic acid (4j)
According to the preparation of 4i, compound 4j (1.42 g, 84%) was obtained from ethyl iodide as
1
light yellow needles, mp 132–135 °C (PhMe); H-NMR (DMSO-d6) δ 1.26 (t, J = 7.3 Hz, 3H,
CH2CH3), 3.20 (q, J = 7.3 Hz, 2H, CH2CH3), 7.36 (td, J = 7.6, 1.3 Hz, 1H, 5-H), 7.61 (ddd, J = 8.2,
6.9, 1.6 Hz, 1H, 4-H), 7.93 (dd, J = 7.9, 1.6 Hz, 1H, 6-H), 8.11 (d, J = 8.2 Hz, 1H, 3-H), 11.97 (br s,
1H, NH); 13C-NMR (DMSO-d6) δ 14.06 (CH2CH3), 29.08 (CH2CH3), 124.31 (C-1), 125.73 (C-3),
126.35 (C-5), 131.04 (C-6), 132.90 (C-4), 139.88 (C-2), 167.93 (CO2H), 197.11 (NHCS); Anal. calcd.
for C10H11NO2S2: C, 49.8; H, 4.6; N, 5.8. Found: C, 49.7; H, 4.7; N, 5.8.
2-[(Benzylthio)thiocarbonylamino]benzoic acid (4k)
According to the preparation of 4i, compound 4k (1.28 g, 60%) was obtained from benzyl bromide
1
as a yellow solid, mp 142–144 °C (EtOAc); H-NMR (DMSO-d6) δ 4.54 (s, 2H, CH2Ph), 7.25 (td,
J = 6.6, 1.6 Hz, 1H, H-4’), 7.30–7.34 (m, 2H, 2’/6’-H), 7.35–7.40 (m, 3H, 5/3’/5’-H), 7.62 (ddd,
J = 8.3, 7.1, 1.6 Hz, 1H, 4-H), 7.94 (dd, J = 7.9, 1.6 Hz, 1H, 6-H), 8.03 (d, J = 8.5 Hz, 1H, 3-H), 11.98
(br s, 1H, NH); 13C-NMR (DMSO-d6) δ 39.79 (CH2Ph), 124.71 (C-1), 126.10 (C-3), 126.63 (C-5),
127.43 (C-4’), 128.64 (C-2’/6’), 129.15 (C-3’/5’), 131.07 (C-6), 132.95 (C-4), 136.64 (C-1’), 139.75
(C-2), 167.78 (CO2H), 196.67 (NHCS); Anal. calcd. for C15H13NO2S2: C, 59.4; H, 4.3; N, 4.6. Found:
C, 59.6; H, 4.3; N, 4.65.
2-{[(2-Phenylethyl)thio]thiocarbonylamino}benzoic acid (4l)
According to the preparation of 4i, compound 4l (0.527 g, 24%) was obtained from 2-phenylethyl
1
bromide as a yellow solid, mp 125–128 °C (CHCl3); H-NMR (DMSO-d6) δ 2.94 (t, J = 8.2 Hz, 2H,
CH2CH2Ph), 3.47 (t, J = 7.9 Hz, 2H, CH2CH2Ph), 7.19–7.22 (m, 1H, 4’-H), 7.26–7.32 (m, 4H,
2’/3’/5’/6’-H), 7.37 (td, J = 7.9, 1.3 Hz, 1H, 5-H), 7.61 (td, J = 7.6, 1.6 Hz, 1H, 4-H), 7.94 (dd,
J = 7.9, 1.6 Hz, 1H, 6-H), 8.04 (d, J = 7.9 Hz, 1H, 3-H), 11.94 (br s, 1H, NH); 13C-NMR (DMSO-d6) δ
34.67 (CH2CH2Ph), 36.00 (CH2CH2Ph), 124.64 (C-1), 126.04 (C-3), 126.49 (C-5/4’), 128.54 (C-2’/6’),
128.67 (C-3’/5’), 131.04 (C-6), 133.83 (C-4), 139.81 (C-1’), 140.13 (C-2), 167.84 (CO2H), 196.98
(NHCS); Anal. calcd. for C16H15NO2S2: C, 60.5; H, 4.8; N, 4.4. Found: C, 60.2; H, 4.8; N, 5.0.
2-(Methylthio)-4H-3,1-benzothiazin-4-one (5i)
Method 1: 2-[(Methylthio)thiocarbonylamino]benzoic acid (4i, 0.909 g, 4.0 mmol) was heated to
reflux in Ac2O (10 mL) for 30 min. The solvent was removed under reduced pressure, and the crude
material was recrystallised from MeOH to obtain 5i (0.782 g, 93%) as colourless needles, mp 54–
56 °C (MeOH); 1H-NMR (DMSO-d6) δ 2.72 (s, 3H, SCH3), 7.58 (ddd, J = 7.9, 7.3, 1.3 Hz, 1H, 6-H),
7.72 (dd, J = 8.0, 1.2 Hz, 1H, 8-H), 7.92 (ddd, J = 8.5, 7.3, 1.9 Hz, 1H, 7-H), 8.06 (dd, J = 8.2, 1.9 Hz,
13
1H, 5-H); C-NMR (DMSO-d6) δ 13.92 (SCH3), 118.65 (C-4a), 124.68 (C-5), 128.33 (C-6), 129.86
(C-8), 136.84 (C-7), 147.50 (C-8a), 163.47 (C-2), 182.33 (C-4); Anal. calcd. for C9H7NOS2: C, 51.65;
H, 3.4; N, 6.7. Found: C, 51.7; H, 3.4; N, 6.7.
Method 2: 2-[(Methylthio)thiocarbonylamino]benzoic acid (4i, 0.682 g, 3.0 mmol) and TFAA
(7.0 mL) were kept at r.t. for 12 h. After removal of the solvent, the resulting crude material was

Molecules 2009, 14
393
purified by column chromatography on silica using petroleum ether/EtOAc (8+1) as eluent to give 5i
(0.571 g, 91%) as yellowish needles.
2-(Ethylthio)-4H-3,1-benzothiazin-4-one (5j)
According to the preparation of 5i (Method 1), 5j (0.792 g, 89%) was obtained from 4j as yellow
1
needles, mp 53–54 °C (EtOH); H-NMR (DMSO-d6) δ 1.38 (t, J = 7.3 Hz, 3H, SCH2CH3), 3.35 (q,
J = 7.3 Hz, 2H, SCH2CH3), 7.58 (td, J = 7.6, 1.3 Hz, 1H, 6-H), 7.71 (dd, J = 8.1, 1.0 Hz, 1H, 8-H),
7.92 (ddd, J = 8.1, 6.8, 1.9 Hz, 1H, 7-H), 8.06 (dd, J = 7.9, 1.6 Hz, 1H, 5-H); 13C-NMR (DMSO-d6) δ
14.47 (SCH2CH3), 25.83 (SCH2CH3), 118.77 (C-4a), 124.66 (C-5), 128.36 (C-6), 129.89 (C-8), 136.82
(C-7), 147.52 (C-8a), 162.62 (C-2), 182.44 (C-4); Anal. calcd. for C10H9NOS2: C, 53.8; H, 4.1; N, 6.3.
Found: C, 54.1; H, 4.2; N, 6.2.
2-(Benzylthio)-4H-3,1-benzothiazin-4-one (5k)
According to the preparation of 5i (Method 1), 5k (1.01 g, 88%) was obtained from 4k as white
needles, mp 69–72 °C (EtOH); 1H-NMR (DMSO-d6) δ 4.64 (s, 2H, CH2Ph), 7.24–7.27 (m, 1H, 4’-H),
7.31–7.33 (m, 2H, 3’/5’-H), 7.49–7.50 (m, 2H, 2’/6’-H), 7.59 (ddd, J = 7.7, 7.6, 1.3 Hz, 1H, 6-H), 7.80
(dd, J = 8.5, 1.3 Hz, 1H, 8-H), 7.94 (ddd, J = 8.2, 7.3, 1.6 Hz, 1H, 7-H), 8.06 (dd, J = 7.9, 1.3 Hz, 1H,
5-H); 13C-NMR (DMSO-d6) δ 34.88 (CH2Ph), 118.73 (C-4a), 124.74 (C-5), 127.63 (C-4’), 128.50 (C-
6), 128.66 (C-2’/6’), 129.41 (C-3’/5’), 129.88 (C-8), 136.83 (C-7), 136.90 (C-1’), 147.34 (C-8a),
162.03 (C-2), 182.25 (C-4); Anal. calcd. for C15H11NOS2: C, 63.1; H, 3.9; N, 4.9. Found: C, 63.2; H,
3.95; N, 4.9.
2-[(2-Phenylethyl)thio]-4H-3,1-benzothiazin-4-one (5l)
According to the preparation of 5i (Method 1), 5l (0.671 g, 56%) was obtained from 4l as pink
1
blocks, mp 63–65 °C (twice from cyclohexane); H-NMR (CDCl3) δ 3.08 (t, J = 7.6 Hz, 2H,
CH2CH2Ph), 3.55 (t, J = 7.9 Hz, 2H, CH2CH2Ph), 7.23–7.34 (m, 5H, 2’/3’/4’/5’/6’-H), 7.44 (td,
J = 7.4, 1.3 Hz, 1H, 6-H), 7.68 (dd, J = 8.7, 1.6 Hz, 1H, 8-H), 7.76 (ddd, J = 8.4, 7.0, 1.6 Hz, 1H, 7-
13
H), 8.15 (dd, J = 7.9, 1.6 Hz, 1H, 5-H); C-NMR (CDCl3) δ 32.71 (CH2CH2Ph), 35.66 (CH2CH2Ph),
119.46 (C-4a), 125.04 (C-5), 126.73 (C-4’), 127.56 (C-6), 128.62 (C-2’/6’), 128.64 (C-3’/5’), 129.81
(C-8), 135.78 (C-7), 139.69 (C-1’), 148.06 (C-8a), 163.21 (C-2), 183.33 (C-4); Anal. calcd. for
C16H13NOS2: C, 64.2; H, 4.4; N, 4.7. Found: C, 64.3; H, 4.4; N, 4.7.
2-(3,3-Diethylthioureido)-N,N-diethylbenzamide (6a)
Diethylamine (0.914 g, 12.5 mmol) was added dropwise to a solution of 2-(methylthio)-4H-3,1-
benzothiazin-4-one (5i, 1.05 g, 5.0 mmol) in acetone (15 mL). After stirring for 1 h, the mixture was
heated to reflux for 1 h, and allowed to cool to r.t. The solvent was removed under reduced pressure.
Recrystallisation from EtOH gave 6a (0.998 g, 65%) as colourless prisms, mp 116–117 °C (EtOH);
1H-NMR (DMSO-d6) δ 1.01–1.08 (m, 6H, CH2CH3), 1.14 (t, J = 7.1 Hz, 6H, 2 × CH2CH3), 3.20 (q,
J = 6.9 Hz, 2H, CH2CH3), 3.37 (q, J = 6.9 Hz, 2H, CH2CH3), 3.67 (q, J = 6.9 Hz, 4H, CH2CH3), 7.20–
13
7.26 (m, 2H, 5/6-H), 7.33–7.38 (m, 1H, 4-H), 7.41 (d, J = 7.9 Hz, 1H, 3-H), 8.67 (s, 1H, NH); C-

Molecules 2009, 14
394
NMR (DMSO-d6) δ 12.44, 12.64, 13.91 (3 × CH2CH3), 38.20, 43.09, 44.88 (3 × CH2CH3), 125.37,
125.84 (C-5/6), 128.58 (C-4), 130.00 (C-3), 134.59 (C-1), 138.17 (C-2), 168.26 (CON), 179.34
(NHCS); Anal. calcd. for C16H25N3OS: C, 62.5; H, 8.2; N, 13.7. Found: C, 62.8; H, 8.1; N, 13.8.
N-[2-(Pyrrolidin-1-ylcarbonyl)phenyl]pyrrolidine-1-carbothioamide (6c)
According to the preparation of 6a, compound 6c (1.13 g, 74%) was obtained from 5i and
pyrrolidine as light yellow prisms, mp 160–162 °C (EtOH); 1H-NMR (DMSO-d6) δ 1.71–2.08 (m, 8H,
3/4/3’’/4’’-H), 3.38–3.70 (m, 8H, 2/5/2’’/5’’-H), 7.16 (td, J = 7.6, 1.3 Hz, 1H, 4’-H), 7.38 (td, J = 7.9,
1.6 Hz, 1H, 5’-H), 7.42 (dd, J = 7.7, 1.4 Hz, 1H, 3’-H), 7.88 (d, J = 7.9 Hz, 1H, 6’-H), 9.35 (s, 1H,
NH); 13C-NMR (DMSO-d6) δ 24.02, 25.91 (C-3/4/3’’/4’’), 46.03, 49.13 (C-2/5/2’’/5’’), 124.03 (C-4’),
126.53 (C-6’), 127.20 (C-3’), 129.26 (C-5’), 130.52 (C-2’), 138.44 (C-1’), 167.39 (CON), 176.74
(NHCS); Anal. calcd. for C16H21N3OS: C, 63.3; H, 7.0; N, 13.85. Found: C, 63.5; H, 7.1; N, 13.8.
N-[2-(Morpholin-4-ylcarbonyl)phenyl]morpholine-4-carbothioamide (6e)
Method 1: According to the preparation of 6a, compound 6e (1.51 g, 90%) was obtained from 5i
1
and morpholine as colourless prisms, mp 170–173 °C (EtOH); H-NMR (DMSO-d6) δ 3.48–3.63 (m,
12H, 2/6/2’/3’/5’/6’-H) 3.85 (t, J = 4.6 Hz, 4H, 3/5-H), 7.23–7.29 (m, 3H, 3’/4’/6’-H), 7.39 (ddd,
13
J = 7.8, 6.9, 1.9 Hz, 1H, 5’-H), 9.31 (s, 1H, NH); C-NMR (DMSO-d6) δ 41.70, 47.48, 48.85, 66.06,
66.12, 66.30 (C-2/3/5/6/2’’/3’’/5’’/6’’), 125.75 (C-3’), 127.26 (C-4’), 129.29 (C-5’), 129.35 (C-6’),
133.38 (C-2’), 138.38 (C-1’), 167.06 (CON), 181.93 (NHCS); Anal. calcd. for C16H21N3O3S: C, 57.3;
H, 6.3; N, 12.5. Found: C, 57.5; H, 6.35; N, 12.35.
Method 2: Morpholine (0.392 g, 4.5 mmol) was added dropwise to a solution of 2-(morpholin-4-
yl)-4H-3,1-benzothiazin-4-one (2e, 0.497 g, 2.0 mmol) in acetone (6 mL). After stirring for 1 h, the
mixture was heated to reflux for 1 h, and allowed to cool to r.t. The formed precipitate was removed by
suction filtration and washed with cold acetone (5 mL) to give 6e (0.490 g, 73%) as white solid.
Methyl 2-(morpholin-4-ylcarbonyl)phenyldithiocarbamate (7)
Morpholine (0.392 g, 4.5 mmol) was added dropwise to a solution of 2-(methylthio)-4H-3,1-
benzothiazin-4-one (5i, 0.418 g, 2.0 mmol) in acetone (6 mL). After stirring for 1 h, the resulting
precipitate was removed by suction filtration and washed with cold acetone (5 mL) to obtain
1
7 (0.299 g, 50%) as a white solid, mp 143–145 °C; H-NMR (DMSO-d6) δ 2.55 (s, 3H, SCH3), 3.15–
3.22, 3.45–3.64 (m, 8H, 2’/3’/5’/6’-H), 7.35–7.49 (m, 4H, 3/4/5/6-H), 11.52 (s, 1H, NH); 13C-
NMR (DMSO-d6) δ 18.24 (SCH3), 41.90, 47.39 (C-3’’/5’’), 66.09, 66.13 (C-2’’/6’’), 127.50, 127.98
(C-3’/4’), 128.65, 129.77 (C-5’/6’), 133.22 (C-2’), 136.57 (C-1’), 168.40 (CO), 199.94 (NHCS); Anal.
calcd. for C13H16N2O2S2: C, 52.7; H, 5.4; N, 9.45. Found: C, 52.8; H, 5.45; N, 9.5.
2-[N-Methyl-N-(2-phenylethyl)amino]-4H-3,1-benzoxazin-4-one (8h)
In the course of the preparation of 2h (Method 2) using TFAA, purification of the crude material by
column chromatography on silica gave 8h (0.570 g, 68%) as a white solid, mp 68–70 °C, lit. [8] 68.5–
1
69 °C; H-NMR (CDCl3) δ 2.94 (t, J = 7.3 Hz, 2H, CH2CH2Ph), 3.05 (s, 3H, NCH3), 3.75 (t,

Molecules 2009, 14
395
J = 7.3 Hz, 2H, CH2CH2Ph), 7.07–7.12 (m, 1H, 6-H), 7.18–7.30 (m, 6H, 8/2’/3’/4’/5’/6’-H), 7.58
13
(ddd, J = 7.8, 7.4, 1.8 Hz, 1H, 7-H), 7.97 (dd, J = 7.9, 1.6 Hz, 1H, 5-H); C-NMR (CDCl3) δ 34.01
(CH2CH2Ph), 35.68 (NCH3), 51.35 (CH2CH2Ph), 112.06 (C-4a), 123.00, 124.15, 128.61 (C-5/6/8),
126.54 (C-4’), 128.57 (C-2’/6’), 128.82 (C-3’/5’), 136.56 (C-7), 138.42 (C-1’), 150.93 (C-8a), 153.84
(C-2), 159.90 (C-4); Anal. calcd. for C17H16N2O2: C, 72.8; H, 5.75; N, 10.0. Found: C, 72.4; H, 6.05;
N, 9.7.
2-(Methylthio)-4H-3,1-benzoxazin-4-one (9i)
In the course of the preparation of 5i (Method 2) using TFAA, purification of the crude material by
column chromatography on silica yielded 9i (0.010 g, 2%) as a white solid, mp 103–105 °C, lit. [3]
1
108–109 °C; H-NMR (CDCl3) δ 2.58 (s, 3H, SCH3), 7.40 (ddd, J = 8.2, 7.2, 1.3 Hz, 1H, 6-H), 7.45
(d, J = 7.9 Hz, 1H, 8-H), 7.74 (ddd, J = 7.9, 7.3, 1.6 Hz, 1H, 7-H), 8.11 (dd, J = 8.0, 1.6 Hz, 1H, 5-H);
13C-NMR (CDCl3) δ 14.16 (SCH3), 115.59 (C-4a), 125.59, 127.22, 128.77 (C-5/6/8), 136.76 (C-7),
146.89 (C-8a), 158.80 (C-4), 164.00 (C-2).
HLE inhibition assay
Human leukocyte elastase was assayed spectrophotometrically at 405 nm at 25 °C [49]. Assay
buffer was 50 mM sodium phosphate buffer, 500 mM NaCl, pH 7.8. An enzyme stock solution of
50 µg/mL was prepared in 100 mM sodium acetate buffer, pH 5.5 and diluted with assay buffer.
Inhibitor stock solutions were prepared in DMSO. A stock solution of the chromogenic substrate
MeOSuc-Ala-Ala-Pro-Val-pNA was prepared in DMSO and diluted with assay buffer. The final
concentration of HLE was 50 ng/mL, of the chromogenic substrate MeOSuc-Ala-Ala-Pro-Val-pNA
was 100 µM, and of DMSO was 5.5%. Into a cuvette containing 870 µL assay buffer, 50 µL of an
inhibitor solution and 50 µL of the substrate solution were added and thoroughly mixed. The reaction
was initiated by adding 50 µL of the HLE solution and was followed over 10 min. IC50 values were
calculated from the linear steady-state turnover of the substrate.
Cathepsin G inhibition assay
Human cathepsin G was assayed spectrophotometrically at 405 nm at 25 °C [7, 8]. Assay buffer
was 20 mM Tris HCl buffer, 150 mM NaCl, pH 8.4. Inhibitor stock solutions were prepared in DMSO.
An enzyme stock solution of 200 mU/mL was prepared in 50 mM sodium acetate buffer, 150 mM
NaCl, pH 5.5. A 50 mM stock solution of the chromogenic substrate Suc-Ala-Ala-Pro-Phe-pNA in
DMSO was diluted with assay buffer. The final concentration of cathepsin G was 2.5 mU/mL, of the
substrate Suc-Ala-Ala-Pro-Phe-NHNp was 500 µM, and of DMSO was 1.5%. Into a cuvette
containing 882.5 µL assay buffer, 5 µL of an inhibitor solution and 100 µL of a substrate solution were
added and thoroughly mixed. The reaction was initiated by adding 12.5 µL of the cathepsin G solution
and was followed over 10 min. IC50 values were calculated from the linear steady-state turnover of the
substrate.

Molecules 2009, 14
396
Chymotrypsin inhibition assay
Bovine chymotrypsin was assayed spectrophotometrically at 405 nm at 25 °C. Assay buffer was
20 mM Tris HCl buffer, 150 mM NaCl, pH 8.4. Inhibitor stock solutions were prepared in DMSO. An
enzyme stock solution was prepared in 1 mM HCl and diluted with assay buffer. A 40 mM stock
solution of the chromogenic substrate Suc-Ala-Ala-Pro-Phe-pNA in DMSO was diluted with assay
buffer. The final concentration of chymotrypsin was 12.5 ng/mL, of the substrate Suc-Ala-Ala-Pro-
Phe-NHNp was 200 µM, and of DMSO was 6%. Into a cuvette containing 845 µL assay buffer, 55 µL
of an inhibitor solution and 50 µL of a substrate solution were added and thoroughly mixed. The
reaction was initiated by adding 50 µL of a chymotrypsin solution and was followed over 12.5 min.
IC50 values were calculated from the linear steady-state turnover of the substrate.
Trypsin inhibition assay
Trypsin from bovine pancreas was assayed spectrophotometrically at 405 nm at 25 °C. Assay buffer
was 20 mM Tris HCl buffer, 150 mM NaCl, pH 8.4. An enzyme stock solution of 10 µg/mL was
prepared in 1 mM HCl and diluted with assay buffer. Inhibitor stock solutions were prepared in
DMSO. A 40 mM stock solution of the chromogenic substrate Suc-Ala-Ala-Pro-Arg-pNA in DMSO
was diluted with assay buffer. The final concentration of trypsin was 12.5 ng/mL, of the substrate Suc-
Ala-Ala-Pro-Arg-pNA was 200 µM, and of DMSO was 6%. Into a cuvette containing 845 µL assay
buffer, 55 µL of an inhibitor solution and 50 µL of a substrate solution were added and thoroughly
mixed. The reaction was initiated by adding 50 µL of the trypsin solution and was followed over
12.5 min. IC50 values were calculated from the linear steady-state turnover of the substrate.
Cathepsin L inhibition assay
Human cathepsin L was assayed spectrophotometrically at 405 nm at 37 °C [50]. Assay buffer was
100 mM sodium phosphate buffer, pH 6.0, 100 mM NaCl, 5 mM EDTA, 0.01% Brij 35. An enzyme
stock solution of 50 µg/mL in 20 mM sodium acetate buffer, pH 5.0, 100 mM NaCl, 10 mM trehalose,
1 mM EDTA, 50% glycerol was diluted 1:100 with assay buffer containing 5 mM DTT and incubated
for 30 min at 37 °C. This enzyme solution was diluted 1:5 with assay buffer containing 5 mM DTT.
Inhibitor stock solutions were prepared in DMSO. A 10 mM stock solution of the chromogenic
substrate Z-Phe-Arg-pNA was prepared with DMSO. The final concentration of cathepsin L was
4 ng/mL, of the substrate Z-Phe-Arg-pNA was 100 µM, and of DMSO was 5%. Into a cuvette
containing 910 µL assay buffer, 40 µL of an inhibitor solution and 10 µL of a substrate solution were
added and thoroughly mixed. The reaction was initiated by adding 40 µL of the cathepsin L solution
and was followed over 10 min. IC50 values were calculated from the linear steady-state turnover of the
substrate.
ACE inhibition assay
Human ACE was assayed spectrophotometrically at 352 nm at 37 °C [51]. Assay buffer was 50 mM
Tris HCl buffer, 300 mM NaCl, pH 7.5. An enzyme stock solution of 434 µg/mL in 12.5 mM HCl,
pH 7.5, 75 mM NaCl, 500 nM ZnCl2, 40% glycerol was diluted 1:100 with assay buffer. After

Molecules 2009, 14
397
incubation for 10 min at 37 °C, the enzyme solution was stored at 0 °C and used within 90 min.
Inhibitor stock solutions were prepared in DMSO. A 300 mM stock solution of the chromogenic
substrate FA-Phe-Gly-Gly was prepared in DMSO. The final concentration of ACE was 86.8 ng/mL,
of the substrate FA-Phe-Gly-Gly was 3 mM, and of DMSO was 3%. Into a cuvette containing 950 µL
assay buffer, 20 µL of an inhibitor solution and 10 µL of a substrate solution were added and
thoroughly mixed. The reaction was initiated by adding 20 µL of the ACE solution and was followed
over 20 min. IC50 values were calculated from the linear steady-state turnover of the substrate.
AChE inhibition assay
Acetylcholinesterase inhibition was assayed spectrophotometrically at 412 nm at 25 °C [52–54].
Assay buffer was 100 mM sodium phosphate, 100 mM NaCl, pH 7.3. The enzyme stock solution
(~100 U/mL) in assay buffer was kept at 0 °C. Appropriate dilutions were prepared immediately
before starting the measurement. ATCh (10 mM) and DTNB (7 mM) were dissolved in assay buffer
and kept at 0 °C. Stock solutions of the test compounds were prepared in acetonitrile. The final
concentration of AChE was ~30 mU/mL, of ATCh was 500 µM, of DTNB was 350 µM, and of
acetonitrile was 6%. Into a cuvette containing 830 µL assay buffer, 50 µL of the DTNB solution,
50 µL acetonitrile, 10 µL of a solution of the test compound, and 10 µL of an enzyme solution
(~3 U/mL) were added and thoroughly mixed. After incubation for 15 min at 25 °C, the reaction was
initiated by adding 50 µL of the ATCh solution and was followed over 5 min. IC50 values were
calculated from the linear steady-state turnover of the substrate.
CEase inhibition assay
Cholesterol esterase inhibition was assayed spectrophotometrically at 405 nm at 25 °C [55, 56].
Assay buffer was 100 mM sodium phosphate, 100 mM NaCl, pH 7.0. A stock solution of CEase was
prepared in 100 mM sodium phosphate buffer, pH 7.0 and kept at 0 °C. A 1:122 dilution was done
immediately before starting the measurement. TC (12 mM) was dissolved in assay buffer and kept at
25 °C. Stock solutions of all test compounds and of pNPB (20 mM) were prepared in acetonitrile. The
final concentration of CEase was 10 ng/mL, of the substrate pNPB was 200 µM, of TC was 6 mM, and
of acetonitrile was 6%. Into a cuvette containing 430 µL assay buffer, 500 µL of the TC solution,
40 µL acetonitrile, 10 µL of the pNPB solution, and 10 µL of a solution of the test compound were
added and thoroughly mixed. After incubation for 5 min at 25 °C, the reaction was initiated by adding
10 µL of the enzyme solution (1 µg/mL). IC50 values were calculated from the linear steady-state
turnover of the substrate.
Acknowledgements
The authors are grateful to S. Hautmann, S. Terhart-Krabbe and A. Reiner for assistance. Help in
the ACE assay by M. Frizler is acknowledged. G.S. thanks Prof. Dr. Alexander C. Filippou for
support. This work has been supported by the German Research Society (GRK 804).

Molecules 2009, 14
398
Electronic Supplementary Information (ESI) available: Enzyme kinetic data, crystallographic
details, and selected two-dimensional NMR spectra (compounds 2c, 2g, 4i, 5i, 6a, 6c, and 6e).
References and Notes
1. Pietsch, M.; Gütschow, M. Alternate substrate inhibition of cholesterol esterase by thieno[2,3-
d][1,3]oxazin-4-ones. J. Biol. Chem. 2002, 277, 24006-24013.
2. Krantz, A.; Spencer, R. W.; Tam, T. F.; Thomas, E.; Copp, L. J. Design of alternate substrate
inhibitors of serine proteases. Synergistic use of alkyl substitution to impede enzyme-catalyzed
deacylation. J. Med. Chem. 1987, 30, 589-591.
3. Krantz, A.; Spencer, R. W.; Tam, T. F.; Liak, T. J.; Copp, L. J.; Thomas, E. M.; Rafferty, S. P.
Design and synthesis of 4H-3,1-benzoxazin-4-ones as potent alternate substrate inhibitors of
human leukocyte elastase. J. Med. Chem. 1990, 33, 464-479.
4. Uejima, Y.; Kokubo, M.; Oshida, J.; Kawabata, H.; Kato, Y.; Fujii, K. 5-Methyl-4H-3,1-
benzoxazin-4-one derivatives: Specific inhibitors of human leukocyte elastase. J. Pharmacol.
Exp. Ther. 1993, 265, 516-523.
5. Uejima, Y.; Oshida, J.; Kawabata, H.; Kokubo, M.; Kato, Y.; Fujii, K. Inhibition of human
sputum elastase by 7-substituted 5-methyl-2-isopropylamino-4H-3,1-benzoxazin-4-ones.
Biochem. Pharmacol. 1994, 48, 426-428.
6. Gütschow, M.; Neumann, U. Inhibition of cathepsin G by 4H-3,1-benzoxazin-4-ones. Bioorg.
Med. Chem. 1997, 5, 1935-1942.
7. Gütschow, M.; Kuerschner, L.; Pietsch, M.; Ambrozak, A.; Neumann, U.; Günther, R.; Hofmann,
H. J. Inhibition of cathepsin G by 2-amino-3,1-benzoxazin-4-ones: Kinetic investigations and
docking studies. Arch. Biochem. Biophys. 2002, 402, 180-191.
8. Neumann, U.; Schechter, N. M.; Gütschow, M. Inhibition of human chymase by 2-amino-3,1-
benzoxazin-4-ones. Bioorg. Med. Chem. 2001, 9, 947-954.
9. Hays, S. J.; Caprathe, B. W.; Gilmore, J. L.; Amin, N.; Emmerling, M. R.; Michael, W.;
Nadimpalli, R.; Nath, R.; Raser, K. J.; Stafford, D.; Watson, D.; Wang, K.; Jaen, J. C. 2-Amino-
4H-3,1-benzoxazin-4-ones as inhibitors of C1r serine protease. J. Med. Chem. 1998, 41, 1060-
1067.
10. Plummer, J. S.; Cai, C.; Hays, S. J.; Gilmore, J. L.; Emmerling, M. R.; Michael, W.; Narasimhan,
L. S.; Watson, M. D.; Wang, K.; Nath, R.; Evans, L. M.; Jaen, J. C. Benzenesulfonamide
derivatives of 2-substituted 4H-3,1-benzoxazin-4-ones and benzthiazin-4-ones as inhibitors of
complement C1r protease. Bioorg. Med. Chem. Lett. 1999, 9, 815-820.
11. Brown, A. D.; Powers, J. C. Rates of thrombin acylation and deacylation upon reaction with low
molecular weight acylating agents, carbamylating agents and carbonylating agents. Bioorg. Med.
Chem. 1995, 3, 1091-1097.
12. Abood, N. A.; Schretzman, L. A.; Flynn, D. L.; Houseman, K. A.; Wittwer, A. J.; Dilworth, V.
M.; Hippenmeyer, P. J.; Holwerda, B. C. Inhibition of human cytomegalovirus protease by
benzoxazinones and evidence of antiviral activity in cell culture. Bioorg. Med. Chem. Lett. 1997,
7, 2105-2108.

Molecules 2009, 14
399
13. Makara, J. K.; Mor, M.; Fegley, D.; Szabó, S. I.; Kathuria, S.; Astarita, G.; Duranti, A.; Tontini,
A.; Tarzia, G.; Rivara, S.; Freund, T. F.; Piomelli, D. Selective inhibition of 2-AG hydrolysis
enhances endocannabinoid signaling in hippocampus. Nat. Neurosci. 2005, 8, 1139-1141.
14. Jakobsen, P.; Pedersen, B. R.; Persson, E. Inhibitors of the tissue factor/factor VIIa-induced
coagulation: Synthesis and in vitro evaluation of novel specific 2-aryl substituted 4H-3,1-
benzoxazin-4-ones. Bioorg. Med. Chem. 2000, 8, 2095-2103.
15. Besson, T.; Rees, C. W.; Cottenceau, G.; Pons, A. M. Antimicrobial evaluation of 3,1-
benzoxazin-4-ones, 3,1-benzothiazin-4-ones, 4-alkoxyquinazolin-2-carbonitriles and N-arylimino-
1,2,3-dithiazoles. Bioorg. Med. Chem. Lett. 1996, 6, 2343-2348.
16. Hara, S.; Kaneko, C.; Matsumoto, H.; Nishino, T.; Takeuchi, T.; Mori, T.; Mizuno, Y.; Ikeda, K.
Synthesis of 6-sulfur analogues of oxanosine and closely related derivatives thereof. Nucleosides
Nucleotides 1992, 11, 571-582.
17. Matysiak, J. Synthesis, antiproliferative and antifungal activities of some 2-(2,4-dihydroxy-
phenyl)-4H-3,1-benzothiazines. Bioorg. Med. Chem. 2006, 14, 2613-2619.
18. Romeo, G.; Russow, F.; Guccione, S.; Chabin, R.; Kuo, D.; Knight, W. B. Synthesis of new
thiazinoindole derivatives and their evaluation as inhibitors of human leukocyte elastase and other
related serine proteases. Bioorg. Med. Chem. Lett. 1994, 4, 2399-2404.
19. Santagati, N. A.; Salerno, L.; Di Giacomo, C.; Vanella, L.; Ronsisvalle, S. Inhibition of human
leucocyte elastase by novel thieno 1,3-oxazin-4-ones and thieno-1,3-thioxazin-4-ones. Lett. Drug
Des. Discov. 2007, 4, 386-393.
20. Leistner, S.; Gütschow, M.; Wagner, G. The facile synthesis of 2-aminothieno[2,3-d][1,3]thiazin-
4-ones, in some cases 5,6-anellated. Synthesis 1987, 466-470.
21. Kaneko, C.; Hara, S.; Matsumoto, H.; Takeuchi, T.; Mori, T.; Ikeda, K.; Mizuno, Y. Synthesis of
N1-sulfur analogues of acyclovir, directed toward improved antiviral activities. Chem. Pharm.
Bull. 1991, 39, 871-875.
22. Gütschow, M. Novel heterocycles derived from substituted aroylthioureas: Synthesis of 3,1-
benzothiazin-4-ones,
thieno[3,2-d][1,3]thiazin-4-ones
and
1,2,4-thiadiazolo[2,3-a][3,1]-
benzothiazin-5-ones. J. Heterocycl. Chem. 1996, 33, 355-360.
23. Guccione, S.; Monsù Scolaro, L.; Russo, F. Synthesis of 3-methyl-substituted
pyrazolotriazolopyrimidin-4-one and pyrazolothiazolopyrimidin-4-one derivatives. J. Heterocycl.
Chem. 1996, 33, 459-463.
24. Tarzia, G.; Antonietti, F.; Duranti, A.; Tontini, A.; Mor, M.; Rivara, S.; Traldi, P.; Astarita, G.;
King, A.; Clapper, J. R.; Piomelli, D. Identification of a bioactive impurity in a commercial
sample of 6-methyl-2-p-tolylaminobenzo[d][1,3]oxazin-4-one (URB754). Ann. Chim. 2007, 97,
887-894.
25. Hanusek, J.; Hejtmánková, L.; Kubicová, L.; Sedlák, M. Synthesis of substituted 2-
benzoylaminothiobenzamides and their ring closure to substituted 2-phenylquinazoline-4-thiones.
Molecules 2001, 6, 323-337.
26. Papadopoulos, E. P.; Torres, C. D. Convenient preparation of N-substituted 2-amino-4H-3,1-
benzoxazin-4-ones and 3-substituted 2,4(1H,3H)-quinazolinediones. J. Heterocycl. Chem. 1982,
19, 269-272.

Molecules 2009, 14
400
27. El-Deen, I. M. A convenient preparation of 3-substituted-2-N-phenylamino-4(1H,3H)-
quinazolones. J. Serb. Chem. Soc. 1998, 63, 915-920.
28. Matsuoka, M.; Segawa, J.; Makita, Y.; Ohmachi, S.; Kashima, T.; Nakamura, K. I.; Hattori, M.;
Kitano M.; Kise, M. A practical synthesis of ethyl 6,7-difluoro-1-methyl-4-oxo-4H-
[1,3]thiazeto[3,2-a]quinoline-3-carboxylate, a key intermediate for the new tricyclic quinolone,
prulifloxacin (NM441) and versatile new syntheses of the 2-thioquinoline skeleton. J. Heterocycl.
Chem. 1997, 34, 1773-1779.
29. Leistner, S.; Wagner, G. Synthesis of 2-amino-4-thioxo-4H-3,1-benzothiazines. Z. Chem. 1973,
13, 135.
30. Gütschow, M. One-pot reactions of N-(mesyloxy)phthalimides with secondary amines to 2-
ureidobenzamides, 2-ureidobenzoic acids, ethyl 2-ureidobenzoates, or isatoic anhydrides. J. Org.
Chem. 1999, 64, 5109-5115.
31. Looney-Dean, V.; Lindamood, B. S.; Papadopoulos, E. P. Synthesis of derivatives of pyrrole
using methyl 2-isothiocyanatobenzoate. Synthesis 1984, 68-71.
32. Deck, L. M.; Turner, S. D.; Deck, J. A.; Papadopoulos, E. P. Synthesis of derivatives of thiophene
using methyl 2-isothiocyanatobenzoate. J. Heterocycl. Chem. 2001, 38, 343-347.
33. Gütschow, M.; Neumann, U. Novel thieno[2,3-d][1,3]oxazin-4-ones as inhibitors of human
leukocyte elastase. J. Med. Chem. 1998, 41, 1729-1740.
34. Hanusek, J.; Sedlák, M.; Keder, R.; Štĕrba, V. Kinetics and mechanism of desulfurization reaction
of 1-methyl-2-phenylquinazoline-4(1H)-thiones. Collect. Czech. Chem. Commun. 2004, 69, 2212-
2222.
35. Besson, T.; Emayan, K.; Rees, C. W. 1,2,3-Dithiazoles and new routes to 3,1-benzoxazin-4-ones,
3,1-benzothiazin-4-ones and N-arylcyanothioformamides. J. Chem. Soc. Perkin Trans. 1 1995,
2097-2102.
36. Besson, T.; Emayan, K.; Rees, C. W. 3,1-Benzoxazin-4-ones, 3,1-benzothiazin-4-ones and N-
arylcyanothioformamides. J. Chem. Soc., Chem. Commun. 1995, 1419-1420.
37. Petridou-Fischer, J.; Papadopoulos, E. P. Carbon-13 nuclear magnetic resonance spectra of N-
substituted 2-amino-4H-3,1-benzoxazin-4-ones and 3-substituted 2,4(1H,3H)-quinazolinediones.
J. Heterocycl. Chem. 1982, 19, 123-126.
38. Robinson, V. J.; Spencer, R. W. 13C nuclear magnetic resonance and reactivity of 4H-3,1-
benzoxazin-4-ones. Can. J. Chem. 1988, 416, 416-419.
39. Gütschow, M.; Neumann, U.; Sieler, J.; Eger, K. Studies on 2-benzyloxy-4H-3,1-benzoxazin-4-
ones as serine protease inhibitors. Pharm. Acta Helv. 1998, 73, 95-103.
40. Alexandre, F. R.; Berecibar, A.; Wrigglesworth, R.; Perreux, L.; Guillon, J.; Léger, J. M.; Thiéry,
V.; Besson, T. Synthesis of novel 1,3,4-benzotriazepine derivatives from 4-oxo-3,1-benzoxazine
and 3,1-benzothiazine-2-carbonitriles. Tetrahedron 2005, 61, 8288-8294.
41. CCDC 704614 and 704615 contain the supplementary crystallographic data for this paper. These
data can be obtained free of charge via www.ccdc.cam.ac.uk/conts/retrieving.html (or from the
CCDC, 12 Union Road, Cambridge CB2 1EZ, UK; fax: +44 1223 336033; e-mail:
deposit@ccdc.cam.ac.uk).

Molecules 2009, 14
401
42. Korkmaz, B.; Moreau, T.; Gauthier, F. Neutrophil elastase, proteinase 3 and cathepsin G:
Physicochemical properties, activity and physiopathological functions. Biochimie 2008, 90, 227-
242.
43. Neumann, U.; Gütschow, M. 3,1-Benzothiazin-4-ones and 3,1-benzoxazin-4-ones: Highly
different activities in chymotrypsin inactivation. Bioorg. Chem. 1995, 23, 72-88.
44. Vasiljeva, O.; Reinheckel, T.; Peters, C.; Turk, D.; Turk V.; Turk, B. Emerging roles of cysteine
cathepsins in disease and their potential as drug targets. Curr. Pharm. Des. 2007, 13, 387-403.
45. Mehner, C.; Müller, D.; Kehraus, S.; Hautmann, S.; Gütschow, M.; König, G. M. New peptolides
from the cyanobacterium Nostoc insulare as selective and potent inhibitors of human leukocyte
elastase. ChemBioChem 2008, 9, 2692-2703.
46. Carpenter, R. D.; Lam, K. S.; Kurth, M. J. Microwave-mediated heterocyclization to
benzimidazo[2,1-b]quinazolin-12(5H)-ones. J. Org. Chem. 2007, 72, 284-287.
47. Hunter, D. L.; Kitasaki, K.; Le Fevre, C. W. Fr. Demande FR 1509718, 1968, Chem. Abstr. 1969,
70, 37822.
48. Leistner, S.; Wagner, G. Synthesis of 4H-3,1-benzothiazine-4-thiocarbonyl S-oxides. Z. Chem.
1980, 20, 187-188.
49. Gütschow, M.; Pietsch, M.; Themann, A.; Fahrig, J.; Schulze, B. 2,4,5-Triphenylisothiazol-3
(2H)-one 1,1-dioxides as inhibitors of human leukocyte elastase. J. Enzyme Inhib. Med. Chem.
2005, 20, 341-347.
50. Eilfeld, A.; González Tanarro, C.; Frizler, M.; Sieler, J.; Schulze, B.; Gütschow, M. Synthesis and
elastase-inhibiting activity of 2-pyridinyl-isothiazol-3(2H)-one 1,1-dioxides. Bioorg. Med. Chem.
2008, 16, 8127-8135.
51. Holmquist, B.; Bünning, P.; Riordan, J. F. A continuous spectrophotometric assay for angiotensin
converting enzyme. Anal. Biochem. 1979, 95, 540-548.
52. Ellman, G. L.; Courtney, K. D.; Andres V.; Feather-Stone, R. M. A new and rapid colorimetric
determination of acetylcholinesterase activity. Biochem. Pharmacol. 1961, 7, 88-95.
53. Eyer, P.; Worek, F.; Kiderlen, D.; Sinko, G.; Stuglin, A.; Simeon-Rudolf, V.; Reiner, E. Molar
absorption coefficients for the reduced Ellman reagent: reassessment. Anal. Biochem. 2003, 312,
224-227.
54. Elsinghorst, P. W.; González Tanarro, C.; Gütschow, M. Novel heterobivalent tacrine derivatives
as cholinesterase inhibitors with notable selectivity toward butyrylcholinesterase. J. Med. Chem.
2006, 49, 7540-7544.
55. Feaster, S. R.; Lee, K.; Baker, N.; Hui, D. Y.; Quinn, D. M. Molecular recognition by cholesterol
esterase of active site ligands: Structure−reactivity effects for inhibition by aryl carbamates and
subsequent carbamylenzyme turnover. Biochemistry 1996, 35, 16723-16734.
56. Pietsch, M.; Gütschow, M. Synthesis of tricyclic 1,3-oxazin-4-ones and kinetic analysis of
cholesterol esterase and acetylcholinesterase inhibition. J. Med. Chem. 2005, 48, 8270-8288.
Sample Availability: Samples of the compounds are available from authors.

Molecules 2009, 14
402
© 2009 by the authors; licensee Molecular Diversity Preservation International, Basel, Switzerland.
This article is an open-access article distributed under the terms and conditions of the Creative
Commons Attribution license (http://creativecommons.org/licenses/by/3.0/).
