Stereoselective synthesis of α-methylene-γ-butyrolactams from ethyl 2-(bromomethyl)acrylate and chiral sulfinyl aldimines mediated by indium

Article abstract of DOI:10.3987/COM-09-S(S)27

The reaction of ethyl 2-(bromomethyl)acrylate (1) with chiral N-tert-butylsulfinyl aldimines 2 and indium powder in THF at 100°C for 48 h affords, after hydrolysis, a mixture of N-tert-butylsulfinyl aminoesters 3 and α-methylene-γ-butyrolactams 4. From the reaction mixture, compounds 3 were quantitatively converted to the expected butyrolactams 4 after removal of the tert-butylsulfinyl group under acidic conditions and final basic workup. The whole process takes place in high overall yields and with fairly good stereoselectivities.

Full text of DOI:10.3987/COM-09-S(S)27

HETEROCYCLES, Vol. 80, No. 1, 2010
125
HETEROCYCLES, Vol. 80, No. 1, 2010, pp. 125 - 131. © The Japan Institute of Heterocyclic Chemistry
Received, 15th May, 2009, Accepted, 13th July, 2009, Published online, 13th July, 2009
DOI: 10.3987/COM-09-S(S)27
STEREOSELECTIVE SYNTHESIS OF -METHYLENE--BUTYRO-
LACTAMS FROM ETHYL 2-(BROMOMETHYL)ACRYLATE AND
CHIRAL SULFINYL ALDIMINES MEDIATED BY INDIUM
Haythem K. Dema, Francisco Foubelo,* and Miguel Yus*
Department of Organic Chemistry, Faculty of Science, and Institute of Organic
Synthesis (ISO), University of Alicante, Apdo. 99, 03080 Alicante, Spain
Abstract – The reaction of ethyl 2-(bromomethyl)acrylate (1) with chiral
N-tert-butylsulfinyl aldimines 2 and indium powder in THF at 100 ºC for 48 h
affords, after hydrolysis, a mixture of N-tert-butylsulfinyl aminoesters 3 and
-methylene--butyrolactams 4. From the reaction mixture, compounds 3 were
quantitatively converted to the expected butyrolactams 4 after removal of the
tert-butylsulfinyl group under acidic conditions and final basic workup. The
whole process takes place in high overall yields and with fairly good
stereoselectivities.
Homoallylic amines,1 which are compounds of interest themselves because they can be intermediates in
the synthesis of other nitrogenated materials, are easily accessible in enantioenriched form by asymmetric
allylation of imines using chiral auxiliaries2 or under asymmetric catalysis,3 as well. Allyl indium species4
are ideal allylating reagents in these processes. They can be generated in the presence of the imine from
allyl halides and indium metal under mild reaction conditions and exhibit high tolerance to a wide range
of functional groups in many solvents.5 Among chiral auxiliaries, sulfinimines6 have been widely studied,
specially the N-tert-butylsulfinyl derivatives, due to the possibility of preparing both enantiomers in large
scale processes,7 and also because the chiral auxiliary can be easily removed under acidic conditions.8 In
addition, a practical process for recycling the tert-butylsulfinyl group upon deprotection of the
N-tert-butylsulfinylamines
has
been
recently
reported.9
On
the
other
hand,
the
-methylene--butyrolactone and -butyrolactam rings are present in many bioactive natural products
_____________________________________________________________________________________
This paper is dedicated to Professor Dr. Akira Suzuki on occasion of his 80th birthday.

126
HETEROCYCLES, Vol. 80, No. 1, 2010
with interesting cytotoxic, allergenic, antiinflammatory, phytotoxic, and antimicrobial properties.10 These
compounds interact with nucleophiles in the active site of enzymes, due to the electrophilic character of
the ,-unsaturated carbonyl unit, acting as inhibitors. Lactone derivatives are more abundant in Nature,
however they exhibit higher cytotoxic activity than lactams, the last ones being more promising
candidates for drugs in the pharmaceutical industry. Synthetic methodologies to access efficiently to
-methylene--butyrolactams11 include nucleophilic addition of 2-alkoxycarbonyl allyl metal
intermediates to imines.12 More recently, an expeditious synthesis of these compounds through a three
component assembling of an aldehyde, ammonia and a 2-alkoxycarbonylallylboronate in a single
synthetic operation has been reported.13 Because of our interest in indium-promoted reactions,14 we report
here the use of this metal for the stereoselective preparation of -methylene--butyrolactams15 from ethyl
2-(bromomethyl)acrylate and chiral N-tert-butylsulfinyl aldimines.
Equimolecular amounts of ethyl 2-(bromomethyl)acrylate (1), indium powder and the corresponding
chiral N-tert-butylsulfinyl aldimines 2 in THF were heated at 100 ºC in a pressure flask for 48 h and then
hydrolyzed with water. After extraction and evaporation, a mixture of the corresponding
N-tert-butylsulfinyl aminoester 3 and -methylene--butyrolactam 4 was obtained (Scheme 1 and Table
1). This reaction did not take place when the process was performed at 66 ºC (THF reflux), and very low
conversion was observed at 80 ºC after one week. Fortunately, nucleophilic addition of the proposed
initially formed allylindium sesquihalide intermediate of type I (Scheme 1) to the imine 2 took place at
100 ºC, in spite of the thermal liability of the N-tert-butylsulfinyl group, leading first to
N-tert-butylsulfinyl aminoester 3. Under these reaction conditions, compound 3 could partially cyclize to
give -methylene--butyrolactam 4 and ethyl tert-butanesulfinate (5, Scheme 1), which was not detected.
Finally, the aminoester 3 was converted into butyrolactam 4 from the reaction mixture upon removal of
the tert-butylsulfinyl group under acidic conditions and final basic workup (Scheme 1).
O
O
S
O
O
S
S
HN
i,ii
NH
EtO
Br
N
+
+
+
OEt
[In]
EtO
R
R
O
R
H
2
O
5
1
3
4
iii,iv
EtO
[R = CH3(CH2)7, i-Pr, Ph(CH2)2, Ph]
O
I
Scheme 1. Reagents and conditions: (i) In, THF, 100 ºC, 48 h; (ii) H2O; (iii) HCl-dioxane, MeOH, 0 ºC, 2
h; (iv) NaHCO3-H2O, 20 ºC, 1 h.

HETEROCYCLES, Vol. 80, No. 1, 2010
127
Table 1. Preparation of -methylene--butyrolactams 4
Aldimine 2
Butyrolactam 4b
Entry No.
R
3:4 Ratioa No.
Structure
O
Yield (%)c
erd
tret (min)e
16.89
NH
1
2
3
4
5
6
7
8
(R)-2a CH3(CH2)7
1:1
1:5
1:3
3:1
1:1
1:5
1:3
3:1
4a
4b
4c
4d
4e
4f
74
84
75:25
( )7
O
NH
(R)-2b
i-Pr
81:19
70:30
91:9
20.26
43.84
36.92
11.25
14.20
12.01
33.20
i-Pr
O
NH
( )2
(R)-2c Ph(CH2)2
75
69
72
79
73
68
Ph
O
NH
Ph
(R)-2d
Ph
O
O
NH
( )7
(S)-2a CH3(CH2)7
68:32
71:29
80:20
92:8
NH
(S)-2b
i-Pr
i
-Pr
O
NH
( )2
(S)-2c Ph(CH2)2
4g
Ph
O
NH
Ph
(S)-2d
Ph
4h
a Ratio determined by 1H-NMR analysis of the crude reaction mixture. b All products were >95% pure (GLC and/or 300
MHz 1H RMN). c Isolated yield after column chromatography (silica gel, hexane/EtOAc) based on the starting aldimine
2. d Enantiomeric ratio determined by HPLC using a Chiralcel OD-H column (condidtions: hexane/isopropanol, 9:1; 0.5
mL/min). e Retention time of the major enantiomer.
In general, overall yields of the isolated products 4,16 after column chromatography, are good (Table 1).
Regarding the diastereoselectivity of the nucleophilic addition to the chiral imines, the er values were
determined by chiral HPLC analysis, ranging from 92:8 in the case of the aldimine (S)-2d derived from
benzaldehyde (Table 1, entry 8) to 68:32 in the case of aldimine (S)-2a derived from nonanal (Table 1,
entry 5). In order to determine the configuration of the newly created stereogenic centre in the major
22
diasteroisomer, we found that specific rotation of 4d {[]D -10 (c 0.54, CHCl3)}, which derived from
aldimine (R)-2d matched with that provided in the literature for (R)-3-methylene-5-phenylpyrrolidin-2-one
{[]D26 -17 (c 1.35, CHCl3)}.12b This result is consistent with an approach of the nucleophile from the

128
HETEROCYCLES, Vol. 80, No. 1, 2010
Re-face of C=N through an open transition state TSI (Chart 1)6g or a monochelate chair-like model TSII
(Chart 1)17 instead of a six-membered ring model TSIII (Chart 1), with a four-membered metallacycle, in
which the metal is chelated both by the oxygen and the nitrogen atoms of the imine moiety. The last one
has been proposed for the indium-promoted allylation of these chiral aldimines with allyl bromide14b and
it would lead to the opposite configuration. The imine adopts in all these cases a kind of s-cis
conformation which is the less energetic conformation in the N-tert-butylsulfinyl aldimines. After this
result, we assume that the nucleophilic attack occurs predominantly to the Re-face of the imine unit for
RS-isomers (Table 1, entries 1-4) and to the Si-face in the case of SS-derivatives (Table 1, entries 5-8)
according to the proposed transition states TSI and TSII (Chart 1).
‡
R
‡
R
H
Ph
O
Ph
[In]
[In]
‡
O
H
N
S
N
N
H
Ph
O
S
Nu
TSI
TSII
TSIII
Chart 1
In conclusion, we have reported herein a stereoselective synthesis of -methylene--butyrolactam from
ethyl 2-(bromomethyl)acrylate (1) and chiral N-tert-butylsulfinyl aldimines 3. The key step of the process
is an indium promoted nucleophilic addition to the chiral imine. Studies are currently in progress trying to
find milder reaction conditions and to improve the stereoselectivity.
ACKNOWLEDGEMENTS
This work was generously supported by the Spanish Ministerio de Educación y Ciencia (MEC; grant no.
Consolider Ingenio 2010-CSD2007-00006 and CTQ-2007-65218). H. K. D. thanks to the Generalitat
Valenciana for a predoctoral fellowship (programa Santiago Grisolía). We also thank MEDALCHEMY
S.L. for a gift of chemicals.
REFERENCES
1. (a) A. Bocoum, C. Boga, D. Savoia, and A. Umani-Ronchi, Tetrahedron Lett., 1991, 32, 1367; (b) N.
Kise, H. Yamazaki, T. Mabuchi, and T. Shono, Tetrahedron Lett., 1994, 35, 1561; (c) S. J. Veenstra
and P. Schmid, Tetrahedron Lett., 1997, 38, 997; (d) C. K. Z. Andrade, N. R. Azevedo, and G. R.
Oliveira, Synthesis, 2002, 928; (e) B. Das, G. Satyalakshmi, K. Suneel, and B. Shashikanth,

HETEROCYCLES, Vol. 80, No. 1, 2010
129
Tetrahedron Lett., 2008, 49, 7209; (f) K. K. Pasunooti, M. L. Leow, S. Vedachalam, B. K. Gorityala,
and X.-W. Liu, Tetrahedron Lett., 2009, 50, 2979; (g) C. Ochoa-Puentes and V. Kouznetsov, J.
Heterocycl. Chem., 2002, 39, 595.
2. (a) G. Alvaro and D. Savoia, Synlett, 2002, 651; (b) H. Ding and G. K. Friestad, Synthesis, 2005,
2815; (c) G. K. Friestad, C. S. Korapala, and H. Ding, J. Org. Chem., 2006, 71, 281; (d) P. V.
Ramachandran and T. E. Burghardt, Pure Appl. Chem., 2006, 78, 1397.
3. (a) H. Nakamura, K. Nakamura, and Y. Yamamoto, J. Am. Chem. Soc., 1998, 120, 4242; (b) D.
Ferraris, T. Dudding, B. Young, W. J. Drury, and T. Lectka, J. Org. Chem., 1999, 64, 2168; (c) K.
Nakamura, H. Nakamura, and Y. Yamamoto, J. Org. Chem., 1999, 64, 2614; (d) X. M. Fang, M.
Johannsen, S. L. Yao, N. Gathergood, R. G. Hazell, and K. A. Jørgensen, J. Org. Chem., 1999, 64,
4844; (e) M. Arend, Angew. Chem. Int. Ed., 1999, 38, 2873; (f) T. Gastner, H. Ishitani, R. Akiyama,
and S. Kobayashi, Angew. Chem. Int. Ed., 2001, 40, 1896; (g) D. Ferraris, B. Young, C. Cox, T.
Dudding, W. J. Drury, L. Ryzhkov, A. E. Taggi, and T. Lectka, J. Am. Chem. Soc., 2002, 124, 67;
(h) A. E. Taggi, A. M. Hafez, and T. Lectka, Acc. Chem. Res., 2003, 36, 10; (i) R. A. Fernandes, A.
Stimac, and Y. Yamamoto, J. Am. Chem. Soc., 2003, 125, 14133; (j) T. Hamada, K. Manabe, and S.
Kobayashi, Angew. Chem. Int. Ed., 2003, 42, 3927; (k) R. A. Fernandes and Y. Yamamoto, J. Org.
Chem., 2004, 69, 735; (l) R. Han, S. Choi, K. Son, Y. Jun, B. Lee, and B. Kim, Synth.
Commun., 2005, 35, 1725; (m) R. Wada, T. Shibuguchi, S. Makino, K. Oisaki, M. Kanai, and M.
Shibasaki, J. Am. Chem. Soc., 2006, 128, 7687; (n) O. A. Wallner, V. J. Olsson, L. Eriksson, and K.
J. Szabo, Inorg. Chim. Acta, 2006, 359, 1767; (o) U. K. Roy and S. Roy, Tetrahedron
Lett., 2007, 48, 7177.
4. (a) I. R. Cooper, R. Grigg, W. S. MacLachlan, M. Thornton-Pett, and V. Sridharan, Chem. Commun.,
2002, 1372; (b) T. Vilaivan, C. Winotapan, V. Banphavichit, T. Shinada, and Y. Ohfune, J. Org.
Chem., 2005, 70, 3464; (c) K. L. Tan and E. N. Jacobsen, Angew. Chem. Int. Ed., 2007, 46, 1315.
For reviews, see: (d) V. Nair, S. Ros, N. C. Jayan, and B. S. Pillai, Tetrahedron, 2005, 61, 2725; (e) J.
A. Marshall, J. Org. Chem., 2007, 72, 8153; (f) R. B. Kargbo and G. R. Cook, Curr. Org.
Chem., 2007, 11, 1287; (g) X.-W. Sun, M. Liu, M.-H. Xu, and G.-Q. Lin, Org. Lett., 2008, 10, 1259.
5. For reviews, see: (a) P. Cintas, Synlett, 1995, 1087; (b) C.-J. Li, Tetrahedron, 1996, 52, 5643; (c) D.
Lainé, Synlett, 1999, 1331; (d) K. K. Chauhan and C. G. Frost, J. Chem. Soc., Perkin Trans. 1, 2000,
3015; (e) B. C. Ranu, Eur. J. Org. Chem., 2000, 2347; (f) J. Podlech and T. C. Maier, Synthesis,
2003, 633; (g) V. Nair, S. Ros, N. C. Jayan, and B. S. Pillai, Tetrahedron, 2004, 60, 1959.
6. For reviews, see: (a) F. A. Davis, P. Zhou, and B.-C. Chen, Chem. Soc. Rev., 1998, 27, 13; (b) J. A.
Ellman, T. D. Owens, and T. P. Tang, Acc. Chem. Res., 2002, 35, 984; (c) J. A. Ellman, Pure Appl.
Chem., 2003, 75, 39; (d) P. Zhou, B.-C. Chen, and F. A. Davis, Tetrahedron, 2004, 60, 8003; (e) D.

130
HETEROCYCLES, Vol. 80, No. 1, 2010
Morton and R. A. Stockman, Tetrahedron, 2006, 62, 8869; (f) G.-Q. Lin, M.-H. Xu, Y.-W. Zhong,
and X.-W. Sun, Acc. Chem. Res., 2008, 41, 831; (g) F. Ferreira, C. Botuha, F. Chemla, and A.
Pérez-Luna, Chem. Soc. Rev., 2009, 38, 1162.
7. (a) D. J. Weix and J. A. Ellman, Org. Lett., 2003, 5, 1317; (b) D. J. Weix and J. A. Ellman, Org.
Synth., 2005, 82, 157.
8. D. A. Cogan, G. Liu, and J. A. Ellman, Tetrahedron, 1999, 55, 8883.
9. M. Wakayama and J. A. Ellman, J. Org. Chem., 2009, 74, 264.
10. T. Janecki, E. Blaszczyk, K. Studzian, A. Janecka, U. Krajewska, and M. Rozalski, J. Med. Chem.,
2005, 48, 3516.
11. Examples on stereoselective synthesis of -methylene--butyrolactams: (a) L. R. Reddy, P.
Saravanan, and E. J. Corey, J. Am. Chem. Soc., 2004, 126, 6230; (b) H. Ooi, N. Ishibashi, Y.
Iwabuchi, J. Ishihara, and S. Hatakeyama, J. Org. Chem., 2004, 69, 7765; (c) L. R. Reddy, J.-F.
Fournier, B. V. Subba Reddy, and E. J. Corey, J. Am. Chem. Soc., 2005, 127, 8974; (d) K. Y. Lee, H.
S. Lee, and J. N. Kim, Tetrahedron Lett., 2007, 48, 2007; (e) R. B. Lettan II, C. C. Woodward, and K.
A. Scheidt, Angew. Chem. Int. Ed., 2008, 47, 2294; (f) H. Krawczyk, L. Albrecht, J. Wojciechowski,
W. M. Wolf, U. Krajewska, and M. Rozalski, Tetrahedron, 2008, 42, 6307.
12. Allyl zinc derivatives: (a) Y. A. Dembele, C. Belaud, P. Hitchcock, and J. Villiéras, Tetrahedron:
Asymmetry, 1992, 3, 351; (b) Y. A. Dembele, C. Belaud, and J. Villiéras, Tetrahedron: Asymmetry,
1992, 3, 511; (c) V. Nyzam, C. Belaud, F. Zammattio, and J. Villiéras, Tetrahedron: Asymmetry,
1996, 7, 1835. Allyl boron derivatives: (d) I. Chataigner, F. Zammattio, J. Lebreton, and J. Villiéras,
Synlett, 1998, 275; (e) M. Sugiura, K. Hirano, and S. Kobayashi, J. Am. Chem. Soc., 2004, 126,
7182; (f) I. Chataigner, F. Zammattio, J. Lebreton, and J. Villiéras, Tetrahedron, 2008, 64, 2441; (g)
T. G. Elford, A. Ulaczyk-Lesanko, G. De Pascale, G. D. Wright, and D. G. Hall, J. Comb. Chem.,
2009, 11, 155. Palladium catalysed addition: (h) R. A. Fernandes and Y. Yamamoto, J. Org. Chem.,
2004, 69, 3562.
13. T. G. Elford and D. G. Hall, Tetrahedron Lett., 2008, 49, 6995.
14. (a) P. K. Choudhury, F. Foubelo, and M. Yus, Tetrahedron Lett., 1998, 39, 3581; (b) P. K.
Choudhury, F. Foubelo, and M. Yus, Tetrahedron, 1999, 55, 10779; (c) F. Foubelo and M. Yus,
Tetrahedron: Asymmetry, 2004, 15, 3823; (d) M. Medjahdi, J. C. González-Gómez, F. Foubelo, and
M. Yus, Heterocycles, 2008, 76, 569; (e) J. C. González-Gómez, F. Foubelo, and M. Yus, Synlett,
2008, 2777.
15. Previous paper on the synthesis of racemic -methylene--butyrolactams from
2-(bromomethyl)acrylic acid: P. K. Choudhury, F. Foubelo, and M. Yus, J. Org. Chem., 1999, 64,
3376.

HETEROCYCLES, Vol. 80, No. 1, 2010
131
16. Typical procedure for the synthesis of 4d.- A mixture of aldimine (R)-2a (0.104 g, 0.5 mmol), ethyl
2-(bromomethyl)acrylate (1, 0.106 g, 0.55 mmol) and indium powder (0.075 g, 0.65 mmol) in THF
(3 mL) was stirred for 48 h at 100 C in a pressure flask. Then, the resulting mixture was hydrolyzed
with water (10 mL), extrated with EtOAc (3 × 10 mL), dried over anhydrous MgSO4 and evaporated
(15 Torr). The residue was dissolved in MeOH (1 mL) and a HCl 4M dioxane solution (0.5 mL) was
added at 0 ºC. After 2 h stirring at the same temperature, a NaHCO3 saturated aqueous solution (3
mL) was added, and after 1 h stirring at room temperature, the reaction mixture was extrated with
EtOAc (3 × 15 mL), dried over anhydrous MgSO4 and evaporated (15 Torr). The resulting residue
was purified by column chromatography (silica gel, hexane/EtOAc) to give 0.062 g (71%) of
(R)-3-methylene-5-phenylpyrrolidin-2-one (4d): White solid; mp 172-174 ºC (pentane/CH2Cl2) [mp
191-192 ºC (hexane/EtOAc)];12b []D22 -10 (c 0.54, CHCl3); 1H NMR (400 MHz, CDCl3) 2.64-2.78
(1H, m, CHH), 3.26-3.36 (1H, m, CHH), 4.75 (1H, dd, J = 4.7, 8.2 Hz, PhCH), 5.38 (1H, br s,
C=CHH), 6.06 (1H, t, J = 2.7 Hz, C=CHH), 6.55 (1H, br s, NH), 7.26-7.40 (5H, m, ArH); 13C NMR
(100 MHz, CDCl3)  36.8 (CH2), 54.8 (CH), 116.6 (CH2), 125.7, 128.1, 129.0 (CH), 138.6, 142.6 (C),
170.6 (CO); LRMS (EI) m/z 173 [(M+), 100%], 172 (56), 144 (31), 104 (57), 96 (18), 78 (19), 77
(40), 68 (21), 51 (33); HRMS (EI) calcd for C11H11NO 173.0841, found 173.0848.
17. (a) G. Kolodney, G. Sklute, S. Perrone, P. Knochel, and I. Marek, Angew. Chem. Int. Ed., 2007, 46,
9291; (b) I. Marek, Chem. Eur. J., 2008, 14, 7460.
