PAPER
Alternative pathways in the ruthenium catalysed
hydrogenation of CO to alcohols†
Cite this: Catal. Sci. Technol., 2014,
4, 218
a
b
b
a
*
Jan H. Blank, Robert Hembre, James Ponasik and David J. Cole-Hamilton
Received 20th June 2013,
Accepted 8th November 2013
CO hydrogenation in [PBu4]Br in the presence of [Ru3(CO)12] gives predominantly methanol, ethanol and
propanol with small amounts of 1,2-ethanediol. Using RuO2 as the catalyst precursor, the same products are
formed along with higher alcohols (1-butanol –1-heptanol). Reactions carried out using added 13CH3OH or
13CO show that ethanol and propanol come from homologation reactions of methanol and ethanol
respectively, but that the higher alcohols are not formed through the lower alcohols as intermediates.
DOI: 10.1039/c3cy00423f
www.rsc.org/catalysis
in which we discovered that [Bu3PH]Br, sometimes pre-
sent as an adventitious impurity in the solvent acts as a
Introduction
The hydrogenation of carbon monoxide using heterogeneous
catalysts, the Fischer Tropsch (FT) process, has been well-
developed and fine-tuned on a huge scale for the production
of alkanes and alkenes from coal or natural gas.1–3 In these
processes all of the oxygen is discarded as water so oxygen
functionalised molecules are minor side-products. With the
significant promoter of the reaction by releasing HBr into
the system.
The main products were methanol, ethanol and propanol
in declining amounts. Significant amounts of ethylene glycol
were also formed. We now report that the product distribu-
tion obtained when using RuO2 as the ruthenium precursor
is significantly different from that obtained when using
[Ru3(CO)12] and use 13C labelling studies to examine the
mechanisms of formation of the various products.
rising scarcity of oil, the production of oxygenates such as
4–7
alcohols from coal, natural gas or CO2
(C1 feedstocks) has
become more attractive, but despite this, following a flurry of
activity in the 70's and 80's the conversion of CO into higher
alcohols is still underdeveloped, Homogeneous CO hydrogena-
tion may potentially give better selectivity and control over prod-
uct formation and especially selectivity towards oxygenates.8
Homogeneous carbon monoxide hydrogenation was
pioneered by Gresham and Schweizer using cobalt based sys-
tems at high temperatures and pressures.9 Lower pressure
operation was possible using rhodium10,11 or ruthenium,
mainly [Ru3(CO)12],12–14 based catalysts with the major prod-
ucts being methanol and 1,2-ethanediol.
Experimental
Unless stated otherwise, all chemicals where obtained from
Sigma Aldrich and used as received. Air-sensitive compounds
where handled under N2 using standard Schlenk techniques.
NMR spectra where recorded on Varian 300 NMR or Bruker
AM 300/400 NMR spectrometers. The chemical shifts where
referenced to the solvent, which were in turn referenced to a
TMS standard. IR spectra were recorded by pressing a sample
of the liquid product between two KBr plates in a holder. The
samples were recorded on a Thermo Nicolet Avatar FTIR
spectrometer with a nitrogen cooled MCT detector. For quan-
titation Gas Chromatography analysis was performed using
a Supelcowax-10 capillary column (60 m × 0.32 mm × 1.0 μm
film thickness) using an Agilent 6890 N Network GC system
equipped with a flame ionisation detector. For identification
a HP 6890 series GC system equipped with a HP 5973 mass
selective detector was used. Both machines used the same
column using 1 ml min−1 helium carrier gas flow and 250 °C
injector and detector temperatures. The temperature
programmes was as follows: 50 °C, hold 3 minutes, ramp
20 °C min−1, 150 °C, hold 5 min, ramp 20 °C min−1, 220 °C,
hold 13 minutes. Split ratio: 1 : 100.
Improvements were obtained by adding halides to the
ruthenium system and Knifton and co-workers introduced15–17
phosphonium bromides as the solvent as well as RuO2 as an
alternative catalyst precursor.15 In these cases, ethanol also
became a significant product.
We have recently reported18 studies on [Ru3(CO)12]
catalysed CO hydrogenation in [Bu4P]Br, under milder con-
ditions (250 bar, 200 °C), than those studied by Knifton
