Synthesis and Optical Properties of a Rod-Coil Diblock Copolymer with
Polyoxometalate Clusters Covalently Attached to the Coil Block
Sanjiban Chakraborty,† Andrew Keightley,‡ Vladimir Dusevich,§ Yong Wang,§ and
Zhonghua Peng*,†
†Department of Chemistry, ‡School of Biological Sciences, and §Department of Oral Biology, University of
Missouri-Kansas City, Kansas City, Missouri 64110
Received March 10, 2010. Revised Manuscript Received June 4, 2010
A rod-coil diblock copolymer (DCP) containing an oligo(phenylene vinylene) (OPV) rigid block
and a polystyryl-type flexible block with polyoxometalate (POM) clusters as side chain pendants has
been successfully synthesized. The coil block of 2,6-dimethyl-4-vinyl aniline protected by phthalic
anhydride was prepared by atom transfer radical polymerization (ATRP). The terminal bromo-end
group was then converted to an azide which subsequently coupled with an ethynyl terminated OPV rod
block by “click” chemistry. After removing the phthalimide protection groups in the coil block to give
free aryl amines, POM clusters were finally attached to the coil block covalently to yield the first POM-
containing DCP. The hybrid DCP shows two absorption bands, one at 370 nm which is attributed to
the ligand-to-metal charge transfer transition associated with imido-functionalized POM clusters, and
the other at 450 nm which is due to the π-π* transition of the OPV backbone. Cyclic voltammetry
measurements show a distinct reversible reduction process at -1.1 eV, significantly cathodically shifted
compared to that of free hexamolybdate cluster. These results indicate that the POM clusters are indeed
covalently linked to the DCP. Although little fluorescence quenching is observed in solution, the POM
cluster is found to quench 74% of the OPV fluorescence in films. Such a significant fluorescence
quenching is likely due to a photoinduced electron-transfer process from the OPV donor to the POM
cluster, making it a potential candidate as an efficient photovoltaic material. Preliminary film
morphology studies show that the hybrid DCP aggregates very differently from its precursor DCPs.
Introduction
variations but also because of their often superior mate-
rials properties resulting from the realization of the desired
phase-separated morphologies.1 While all organic DCPs
continue to dominate the field, organic-inorganic hybrid
DCPs have drawn increasing attention.2 In particular,
Diblock copolymers (DCPs) are perhaps the most ex-
tensively studied polymer architectures in the past couple
of decades not only because of their unlimited combina-
tions of different blocks with compositional and structural
(2) (a) Ribot, F.; Banse, F.; Sanchez, C.; Lahcini, M.; Jousseaume, B.
J. Sol-Gel Sci. Technol. 1997, 8, 529. (b) Foerster, S.; Antonietti, M.
Adv. Mater. 1998, 10, 195. (c) Watson, K. J.; Zhu, J.; Nguyen, S. T.;
Mirkin, C. A. J. Am. Chem. Soc. 1999, 121, 462. (d) Okumura, A.;
Tsutsumi, K.; Hashimoto, T. Polym. J. 2000, 32, 520. (e) Pyun, J.;
Matyjaszewski, K.;Kowalewski, T.;Savin, D.; Patterson, G.;Kickelbick,
G.; Huesing, N. J. Am. Chem. Soc. 2001, 123, 9445–9446. (f)
Matsuura, Y.; Matsukawa, K.; Kawabata, R.; Higashi, N.; Niwa, M.;
Inoue, H. Polymer 2002, 43, 1549. (g) Gratt, J. A.; Cohen, R. E.
J. Appl. Polym. Sci. 2004, 88, 177. (h) Koh, K.; Ohno, K.; Tsujii, Y.;
Fukuda, T. Angew. Chem., Int. Ed. 2003, 42, 4194. (i) Laruelle, G.;
Parvole, J.; Francois, J.; Billon, L. Polymer 2004, 45, 5013. (j) Ro,
H. W.; Kim, K. J.; Theato, P.; Gidley, D. W.; Yoon, D. Y. Macro-
molecules 2005, 38, 1031. (k) Chen, Y.; Du, J.; Xiong, M.; Zhang, K.;
Zhu, H. Macromol. Rapid Commun. 2006, 27, 741. (l) Stone, D. A.;
Allcock, H. A. Macromolecules 2006, 39, 4935. (m) Zhou, J.; Wang,
L.; Dong, X.; Chen, T.; Yang, Q.; Chen, C.; Chen, X. Nanotechnology
2006, 17, 2745. (n) Zhang, L.; Abbenhuis, H. C. L.; Yang, Q.; Wang,
Y. M.; Magusin, P. C. C. M.; Mezari, B.; Van Santen, R. A.; Li, C.
Angew. Chem., Int. Ed. 2007, 46, 5003. (o) Masuda, T.; Yamamoto,
S.; Moriya, O.; Kashio, M.; Sugizaki, T. Polym. J. 2008, 40, 126. (p)
Hirai, T.; Leolukman, M.; Hayakawa, T.; Kakimoto, M.; Gopalan, P.
Macromolecules 2008, 41, 4558. (q) Liao, C. C.; Wu, H. Y.; Saikia,
D.; Pan, Y. C.; Chen, Y. K.; Fey, G. T. K.; Kao, H. M. Macromolecules
2008, 41, 8956. (r) Zhang, K.; Gao, L.; Chen, Y. Macromolecules
2008, 41, 1800. (s) Zhang, W.; Zhuang, X.; Li, X.; Lin, Y.; Bai, J.;
Chen, Y. React. Funct. Polym. 2009, 69, 124. (t) Monge, S.; Zhang,
X.; Giani, O.; Robin, J. J. React. Funct. Polym. 2009, 69, 380.
*To whom correspondence should be addressed. E-mail: pengz@
umkc.edu.
(1) (a) Helfand, E.; Wasserman, Z. R. In Developments in Block
Copolymers-1; Goodman, I.; Ed.; Applied Science Publishers: New
York, 1982; Chapter 4. (b) Bates, F. S.; Fredrickson, G. H. Annu. Rev.
Phys. Chem. 1990, 41, 525. (c) Bates, F. S. Science 1991, 251, 898. (d)
Stalmach, U.; de Boer, B.; Videlot, C.; van Hutten, P. F.; Hadziioannou,
G. J. Am. Chem. Soc. 2000, 122, 5464. (e) Whitesides, G. M.;
Grzybowski, B. Science 2002, 295, 2418.(f) Hamley, I. W. The Physics
of Block Copolymers; Oxford University Press, Inc.: New York, 1998.
(g) Hadjichristidis, N.; Pitsikalis, M.; Iatrou, H Adv. Polym. Sci. 2005,
189, 1. (h) Fredrickson, G. H.; Bates, F. S. Annu. Rev. Mater. Sci.
1996, 26, 501. (i) Floudas, G.; Vazaiou, B.; Schipper, F.; Ulrich, R.;
Wiesner, U.; Iatrou, H.; Hadjichristidis, N. Macromolecules 2001, 34,
2947. (j) Khandpur, A. K.; Foerster, S.; Bates, F. S.; Hamley, I. W.;
Ryan, A. J.; Bras, W.; Almdal, K.; Mortensen, K. Macromolecules
1995, 28, 8796. (k) Matsen, M. W.; Bates, F. S. Macromolecules 1996,
29, 1091. (l) Simon, P. F. W.; Ulrich, R.; Spiess, H. W.; Wiesner, U.
Chem. Mater. 2001, 13, 3464. (m) Choucair, A.; Eisenberg, A. Eur.
Phys. J. E 2003, 10, 37. (n) Stewart, S.; Liu, G. Angew. Chem., Int. Ed.
2000, 39, 340. (o) Jain, S.; Bates, F. S. Science 2003, 300, 460. (p) Li,
Z.; Kesselman, E.; Talmon, Y.; Hillmyer, M. A.; Lodge, T. P. Science
2004, 306, 98. (q) Pochan, D. J.; Chen, Z. Y.; Cui, H. G.; Hales, K.; Qi,
K.; Wooley, K. L. Science 2004, 306, 94. (r) Spatz, J. P.; Moessmer, S.;
Moller, M. Angew. Chem., Int. Ed. Engl. 1996, 35, 1510. (s) Lodge,
T. P.; Muthukumar, M. J. Phys. Chem. 1996, 100, 13275. (t) Stupp,
S. I.; LeBonheur, V.; Walker, K.; Li, L. S.; Huggins, K. E.; Keser, M.;
Amstutz, A. Science 1997, 276, 384.
r
2010 American Chemical Society
Published on Web 06/15/2010
pubs.acs.org/cm

3996 Chem. Mater., Vol. 22, No. 13, 2010
Chakraborty et al.
metal-containing DCPs have been actively pursued in
recent years. For example, Manners has studied a variety
of DCPs with one block containing ferrocenes.3 Chan,4
Schubert,5 and others6 have explored DCPs containing
transition metal complexes. While these studies are ex-
emplary, they include only discrete metal centers; block
copolymers containing metal clusters, as far as we know,
have not yet been reported. Among various metal-oxygen
clusters, polyoxometalates (POM) are most attractive not
only because of their structural versatility and rich optoe-
lectronic properties but also because of their discrete
molecule structures which allow surface functionalization
in a controlled and rational way.7 Indeed, a number of
POM-containing organic-inorganic hybrids have recently
Figure 1. Structure of a hybrid rod-coil diblock copolymer.
been reported,8-26 among which a few examples involve
POM-containing polymers.27 While most POM-contain-
ing polymers are based on an insulating polymer back-
bone, we have previously reported both main chain and
side chain POM-containing conjugated polymers and have
demonstrated that POM clusters as electron acceptors, in
conjunction with organic π-conjugated segments as elec-
tron donors, may find applications as novel photovoltaic
(PV) materials.28 The PV performances of our reported
hybrid conjugated polymers are, however, not spectacular.
This is not surprising though as an efficient PV device
requires not only efficient photoinduced charge transfer
but also efficient and separate charge transporting path-
ways for positive and negative charge carriers. A conju-
gated polymer with POM clusters uniformly distributed
either in the main chain or in side chains may exhibit
efficient photoinduced charge separation, but possess no
separate charge transporting channels for electrons and
holes. Since electrons transport through hopping among
POM clusters while holes transport through aggregated
conjugated segments, a polymer system which can segre-
gate the two structural components may be able to provide
the separate domains for different charge transport. With
these considerations in mind, we have set out to synthesize
a rod-coil DCP with POM clusters linked to the coil
block. The rod block is a conjugated polymer which serves
as the electron donor, while the POM cluster in the coil
block acts as the electron acceptor. If bicontinuous phase
separated domains can be formed through DCP self-
assembly, such a hybrid DCP may possess significantly
improved PV performance over our previously reported
hybrid conjugated polymers. In this paper, we report the
synthesis and optical properties of the first such POM-
containing hybrid DCP.
