Synthesis and characterizations of star-shaped octupolar triazatruxenes-based two-photon absorption chromophores

Article abstract of DOI:10.1021/jo1017926

A series of star-shaped octupolar triazatruxenes (TATs, 1-6) with intramolecular "push-pull" structure were synthesized and their photophysical properties have been systematically investigated. These chromophores showed obvious solvatochromic effect, i.e.

Full text of DOI:10.1021/jo1017926

pubs.acs.org/joc
Synthesis and Characterizations of Star-Shaped Octupolar
Triazatruxenes-Based Two-Photon Absorption Chromophores
Jinjun Shao, Zhenping Guan, Yongli Yan, Chongjun Jiao, Qing-Hua Xu,* and Chunyan Chi*
Department of Chemistry, National University of Singapore, 3 Science Drive 3, Singapore, 117543
chmxqh@nus.edu.sg; chmcc@nus.edu.sg
Received September 15, 2010
A series of star-shaped octupolar triazatruxenes (TATs, 1-6) with intramolecular “push-pull”
structure were synthesized and their photophysical properties have been systematically investigated.
These chromophores showed obvious solvatochromic effect, i.e., significant bathochromic shift of
the emission spectra and larger Stokes shifts were observed in more polar solvents mainly due to
photoinduced intramolecular charge transfer (ICT). The two-photon absorption (2PA) cross-section
values were determined by two-photon excited fluorescence (2PEF) measurements in toluene and
THF. These chromophores exhibited large two-photon absorption cross-sections ranging from 280
to 1620 GM in the near-infrared (NIR) region. Compound 6 showed the largest 2PA action cross-
section (σ2Φ) of 564 GM and could be a potential two-photon fluorescent (2PF) probe. In addition,
compounds 1-6 all displayed good thermal stability and photostability.
Introduction
photodynamic therapy.6 These applications strongly depend
on the high 2PA cross-section of the specifically engineered
In recent years, two-photon absorption (2PA) has attracted
growing interest due to its potential applications in materials
science and biological imaging,1 including three-dimensional
optical data storage,2 lithographic microfabrication,3 optical
power limiting,4 two-photon fluorescence imaging,5 and
(3) (a) Zhou, W.; Kuebler, S. M.; Braun, K. L.; Yu, T.; Cammack, J. K.;
Ober, C. K.; Perry, J. W.; Marder, S. R. Science 2002, 296, 1106. (b) Kawata,
S.; Sun, H.-B.; Tanaka, T.; Takada, K. Nature 2001, 412, 697. (c) Maruo, S.;
Nakamura, O.; Kawata, S. Opt. Lett. 1997, 22, 132. (d) Cumpston, B. H.;
Ananthavel, S. P.; Barlow, S.; Dyer, D. L.; Ehrlich, J. E.; Erskine, L. L.;
Heikal, A. A.; Kuebler, S. M.; Lee, I. Y. S.; McCord-Maughon, D.; Qin, J.;
Rockel, H.; Rumi, M.; Wu, X. L.; Marder, S. R.; Perry, J. W. Nature 1999,
398, 51. (e) Joshi, M. P.; Pudavar, H. E.; Swiatkiewicz, J.; Prasad, P. N.;
Reinhardt, B. A. Appl. Phys. Lett. 1999, 74, 170. (f) Dvornikov, A. S.; Bouas-
Laurent, H.; Desvergne, J.-P.; Rentzepis, P. M. J. Mater. Chem. 1999, 9, 1081.
(g) Sun, H.-B.; Kawakami, T.; Xu, Y.; Ye, J.-Y.; Matuso, S.; Misawa, H.; Miwa,
M.; Kaneko, R. Opt. Lett. 2000, 25, 1110. (h) Wang, I.; Bouriau, M.; Baldeck,
P. L.; Martineau, C.; Andraud, C. Opt. Lett. 2002, 27, 1348. (i) Lu, Y.; Hasegawa,
F.; Goto, T.; Ohkuma, S.; Fukuhara, S.; Kawazu, Y.; Totani, K.; Yamashita, T.;
Watanabe, T. J. Mater. Chem. 2004, 14, 75. (j) Nguyen, L. H.; Straub, M.; Gu,
M. Adv. Funct. Mater. 2005, 15, 209. (k)Jhaveri, S. J.;McMullen, J. D.;Sijbesma,
R.; Tan, L.-S.; Zipfel, W.; Ober, C. K. Chem. Mater. 2009, 21, 2003.
(1) For a recent review, see: (a) He, G. S.; Tan., L.-S.; Zheng, Q.; Prasad,
P. N. Chem. Rev. 2008, 108, 1245. (b) Kim, H. M.; Cho, B. R. Chem.
Commun. 2009, 153. (c) Kim, H. M.; Cho, B. R. Acc. Chem. Res. 2009, 42,
863. (d) Terenziani, F.; Katan, C.; Badaeva, E.; Tretiak, S.; Blanchard-
Desce, M. Adv. Mater. 2008, 20, 4641. (e) Pawlicki, M.; Collins, H. A.;
Denning, R. G.; Anderson, H. L. Angew. Chem., Int. Ed. 2009, 48, 3244.
(2) (a) Parthenopoulos, D. A.; Rentzepis, P. M. Science 1989, 245, 843.
(b) Strickler, J. H.; Webb, W. W. Opt. Lett. 1991, 16, 1780. (c) Belfield, K. D.;
Schafer, K. J. Chem. Mater. 2002, 14, 3656. (d) Corredor, C. C.; Huang, Z.-L.;
Belfield, K. D.; Morales, A. R.; Bondar, M. V. Chem. Mater. 2007, 19, 5165.
780 J. Org. Chem. 2011, 76, 780–790
Published on Web 01/06/2011
DOI: 10.1021/jo1017926
r
2011 American Chemical Society

Shao et al.
JOCArticle
organic molecules. This has led to a great number of
works on building π-conjugated dipolar,6 quadrupolar,7
and octupolar8 molecules with π-centers and functional
groups of electron-donating and/or electron-withdrawing
groups at the terminal sites.
building block has not been used to develop 2PA chromo-
phores. In this article, for the first time, we report the synthesis of
a series of TAT-based octupolar chromophores which show
large 2PA cross-section in the near-infrared (NIR) range.
Results and Discussion
Design of a star-shaped multipolar molecular structure is
one of the strategies7a,9 to obtain a large 2PA cross-section.
The coherent coupling between the branches will signifi-
cantly increase the 2PA cross-section. In addition, it was also
found that a planar, extended π-conjugated core usually
afforded better performance than the three-dimensionally
twisted, nonconjugated cores. Star-shaped octupolar triphenyl
amines and dendrimers based on planar truxene molecules10
have proved to be good 2PA chromophores. To further
exploit good 2PA active materials, we expect that the C3-
symmetry molecule, triazatruxene (TAT), could be another
good candidate (Figure 1). This idea is based on the follow-
ing considerations: (1) TAT can be considered as an extended
delocalized π-system in which three carbazole units share one
aromatic ring; (2) in comparison with its analogue truxene,
triazatruxene contains three nitrogen atoms which can serve
as good electron-donating groups like those in triphenyl
amines; and (3) selective chemical functionalizations around
the TAT core allow us to introduce electron-withdrawing groups
to form star-shaped octupolar chromophores such as 1-6
(Figure 1). So this design combines the advantages of the
electron-donating properties of aryl amines and the branched
feature of truxene. The additional thienylene vinylene units
in 4-6 can further improve the π-conjugation in each arm
and tune the 2PA properties. Although some research has
been done for the TAT-based materials,11 this interesting
Synthesis. The synthesis of the octupolar TAT molecules 1-6
is shown in Scheme 1. Three different electron-withdrawing
ꢀ
