C5-Functionalized DNA, LNA, and a-l-LNA: Positional Control of Polarity-
Sensitive Fluorophores Leads to Improved SNP-Typing**
Michael E. Østergaard,[a] Pawan Kumar,[a, b] Bharat Baral,[a] Dale C. Guenther,[a]
Brooke A. Anderson,[a] F. Marty Ytreberg,[c] Lee Deobald,[d] Andrzej J. Paszczynski,[d]
Pawan K. Sharma,[b] and Patrick J. Hrdlicka*[a]
Abstract: Single nucleotide polymorph-
isms (SNPs) are important markers in
disease genetics and pharmacogenomic
monomers Y or Z result in a) larger in-
creases in fluorescence intensity upon
hybridization to complementary DNA,
b) formation of more brightly fluores-
cent duplexes due to markedly larger
fluorescence emission quantum yields
(FF =0.44–0.80) and pyrene extinction
coefficients, and c) improved optical
discrimination of SNPs in DNA targets.
Optical spectroscopy studies suggest
that the nucleobase moieties of mono-
mers X–Z adopt anti and syn confor-
mations upon hybridization with
matched and mismatched targets, re-
spectively. The polarity-sensitive 1-pyr-
enecarboxamido fluorophore is, there-
by, either positioned in the polar major
groove or in the hydrophobic duplex
core close to quenching nucleobases.
Calculations suggest that the bicyclic
skeletons of LNA and a-l-LNA mono-
mers Y and Z influence the glycosidic
torsional angle profile leading to al-
tered positional control and photophys-
ical properties of the C5-fluorophore.
studies.
Oligodeoxyribonucleotides
(ONs) modified with 5-[3-(1-pyrenecar-
boxamido)propynyl]-2’-deoxyuridine
monomer X enable detection of SNPs
at non-stringent conditions due to dif-
ferential fluorescence emission of
matched versus mismatched nucleic
acid duplexes. Herein, the thermal de-
naturation and optical spectroscopic
characteristics of monomer X are com-
pared to the corresponding locked nu-
cleic acid (LNA) and a-l-LNA mono-
mers Y and Z. ONs modified with
Keywords: bicyclic nucleotides
·
BNA · DNA targeting · pyrene ·
single nucleotide polymorphisms
Introduction
bility between duplexes of probes and complementary or
SNP-containing targets.[1,2] Moreover, these multistep proto-
cols often necessitate stringent control of assay conditions
(e.g., temperature, ionic strength). As a result, there has
been a major thrust to develop alternative SNP-typing ap-
proaches, which are operationally more simple and cost-effi-
cient. Examples include modified molecular beacons,[3] dual
probes,[4] quenched autoligation probes,[5] intercalator-modi-
fied probes,[6] charge transfer based approaches,[7] and base-
discriminating fluorescent (BDF) probes.[8] Oligodeoxyribo-
nucleotides (ONs) modified with 5-[3-(1-pyrenecarboxami-
do)propynyl]-2’-deoxyuridine monomer X (Figure 1) have
emerged as particularly promising BDF probes due to their
efficient optical discrimination of complementary over mis-
matched targets and moderately high fluorescence quantum
yields,[8d] which has enabled discrimination of SNPs in
human breast cancer cell lines at 50 nm target concentra-
tion.[9] Molecular modeling and photophysical studies sug-
gest that the polarity-sensitive 3-(1-pyrenecarboxamido)pro-
pynyl moiety of monomer X (Figure 1) intercalates into the
hydrophobic base stack upon hybridization with mismatched
targets resulting in fluorescence quenching, while it points
toward the polar major groove in duplexes with complemen-
tary DNA targets resulting in high fluorescence.[8d] These
differences in binding modes are suggested to correlate with
changes in the glycosidic torsion angle (O4’-C1’-N1-C2)
from anti to syn ranges.
Single nucleotide polymorphisms (SNPs) are the most fre-
quently occurring genetic variation in the human genome
(>9 million SNPs, one SNP per 1000 base pairs).[1] SNPs
often result in phenotypic changes, and are accordingly im-
portant markers in disease genetics and pharmacogenomic
studies. The most established SNP genotyping technologies
are enzyme-based or rely on small differences in thermosta-
[a] Dr. M. E. Østergaard, Dr. P. Kumar, B. Baral, D. C. Guenther,
B. A. Anderson, Prof. P. J. Hrdlicka
Department of Chemistry, University of Idaho
P.O. Box 442343, Moscow, ID 83844-2343 (USA)
Fax : (+1)208-885-6173
E-mail: hrdlicka@uidaho.edu
[b] Dr. P. Kumar, Prof. P. K. Sharma
Department of Chemistry, Kurukshetra University
Kurukshetra 136119 (India)
[c] Prof. F. M. Ytreberg
Department of Physics, University of Idaho
P. O. Box 440903, Moscow, ID 83844-0903 (USA)
[d] Dr. L. Deobald, Prof. A. J. Paszczynski
Environmental Biotechnology Institute, University of Idaho
P. O. Box 441052, Moscow, ID 83844-1052 (USA)
[**] LNA=locked nucleic acid; SNP=single nucleotide polymorphism.
Supporting information for this article is available on the WWW
under http://dx.doi.org/10.1002/chem.201002109.
Chem. Eur. J. 2011, 17, 3157 – 3165
ꢀ 2011 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
3157

Results and Discussion
Synthesis: The Sonogashira reaction between known 5-iodo-
LNA uridine derivative 1Y[10c] and 1-pyrenylpropargyl-
AHCTUNGTRENNUNG
amide[8d] afforded C5-functionalized alcohol 2Y in 74%
yield (Scheme 1). Subsequent O3’-phosphitylation using
standard conditions afforded phosphoramidite 3Y in 61%
yield. The corresponding C5-functionalized a-l-LNA phos-
phoramidite 3Z, that is, the first example of this class of
LNAs, was obtained in an equivalent manner from 1Z
(Scheme 2; the synthesis of this intermediate will be pre-
sented elsewhere), while the 2’-deoxyuridine analogue was
prepared as reported in the literature.[8d] The identity of all
new compounds was fully ascertained by NMR spectroscopy
(1H, 13C, 31P, COSY and HSQC) and HRMS, while purity
was determined by 1D NMR spectroscopy (see the Support-
ing Information)
The phosphoramidites were used in automated solid-
phase DNA synthesis (0.2 mmol scale) to incorporate mono-
mers X, Y and Z into the center of 13-mer ONs that have
been previously used to study BDF probes.[8d] The nucleo-
tides flanking the X/Y/Z monomers were systematically
varied to explore the influence of neighbouring nucleotides
on biophysical properties (ON5–ON16). Coupling yields of
>98% were observed during incorporation of unmodified
monomers as well as for phosphoramidites 3X/3Y/3Z using
extended coupling times (15 min) and 4,5-dicyanoimidazole
as an activator (see the Supporting Information) The identi-
ty and purity of the ONs was verified by MALDI-TOF MS
analysis (see Table S2 in the Supporting Information) and
RP-HPLC (>80%), respectively.
Thermal denaturation studies: The thermostability of du-
plexes between ON5–ON16 and complementary or mis-
matched DNA targets was studied by UV thermal denatura-
tion experiments using medium salt buffer conditions
Figure 1. Chemical structures of 5-[3-(1-pyrenecarboxamido)propynyl]-2’-
deoxyuridine, LNA uridine and a-l-LNA uridine monomers X–Z studied
herein. Pyr=pyren-1-yl. Illustration of suggested interaction between H6
and furanose hydrogens.
AHCTUNGTRENNUNG
([Na+]=110 mm) and compared to the corresponding un-
modified DNA duplexes (Table 1). The UV thermal denatu-
ration curves of all modified DNA duplexes exhibit smooth
sigmoidal monophasic transitions (see Figures S1–S3 in the
Supporting Information). Less pronounced hyperchromicity
was observed in duplexes modified with C5-functionalized
LNA monomer Y or a-l-LNA monomer Z, which indicates
less efficient p–p stacking between nucleobases in the
duplex.[14] Incorporation of the known 5-[3-(1-pyrenecarbox-
amido)propynyl]-2’-deoxyuridine monomer X[8d] into ONs
(ON5–ON8) significantly decreases the thermal denatura-
tion temperatures (Tm) of duplexes with DNA complements
(DTm between ꢀ1.58C and ꢀ6.08C, Table 1). Interestingly,
incorporation of the corresponding C5-functionalized LNA
or a-l-LNA building blocks into ONs results in similar de-
stabilization of duplexes although with reduced sequence
variability (DTm between ꢀ2.0 and ꢀ4.58C for monomer Y,
and between ꢀ2.5 and ꢀ4.08C for monomer Z, Table 1).
Thus, the well-established stabilizing effects of conventional
LNA[11] and a-l-LNA[12] monomers appear to be fully com-
promised by the 3-(1-pyrenecarboxamido)propynyl moiety
As part of our ongoing interest in functionalized var-
iants[10] of LNA (Locked Nucleic Acid)[11] and a-l-LNA,[12]
we set out to synthesize and characterize the corresponding
C5-functionalized LNA and a-l-LNA monomers Y and Z in
a comparative study with monomer X (Figure 1). We hy-
pothesized that the extreme sugar puckering of the bicyclic
LNA and a-l-LNA nucleotides[13] would a) influence the
anti to syn rotational profile due to steric hindrance between
H6 and sugar protons (Figure 1), b) result in higher posi-
tional control of the polarity-sensitive 3-(1-pyrenecarboxa-
mido)propynyl fluorophore, and c) possibly lead to im-
proved SNP-typing properties.
