Porphyrins with exocyclic rings. Part 23: Synthesis of porphyrins
with large exocyclic rings—cyclohexadeca[b]pyrroles
and porphyrins therefrom*
*
Timothy D. Lash, Thomas G. Marron and Jolie A. Bastian
Department of Chemistry, Illinois State University, Normal, IL 61790-4160, USA
Received 8 October 2006; revised 24 September 2007; accepted 25 September 2007
Available online 29 September 2007
Abstract—Knorr-type condensation of cyclododecanone, cyclopentadecanone, and cyclohexadecanone with phenylhydrazones derived from
acetoacetate esters in the presence of zinc dust at elevated temperatures gave the corresponding large ring cycloalka[b]pyrroles in excellent
yields. A cyclohexadeca[b]pyrrole was reacted with lead tetraacetate to give an acetate derivative, and this condensed with a-unsubstituted
pyrroles in the presence of p-toluenesulfonic acid in acetic acid to give a series of related dipyrrolic structures. Hydrogenolysis of the benzyl
ester protective groups, followed by ‘2+2’ condensations with dipyrrylmethane dialdehydes, gave unusual cycloalkanoporphyrins with
16-membered exocyclic rings. When an alkyl group is situated next to the carbocyclic ring, proton NMR spectroscopy indicates that the
conformational mobility of the carbocyclic unit is severely restricted.
Ó 2007 Elsevier Ltd. All rights reserved.
1. Introduction
mixtures can be used as chemical markers in petroleum
exploration4 and have been investigated for environmental
applications in monitoring the origins of oil spills.5 We
have previously explored the syntheses of natural petropor-
phyrins and related ‘type II’ isomers starting from cyclic
ketones.6,7 Knorr-type condensations of oximes or phenyl-
hydrazones with cyclohexanone, cycloheptanone, or cyclo-
octanone afford the related cycloalka[b]pyrroles 4 in good
yields,8–10 and these can be taken onto dipyrrolic intermedi-
ates 5 that represent the southern half of the CAP structures
(Scheme 1).9–11 Following the removal of the ester protec-
tive groups, the dipyrroles can be condensed with dipyrryl-
methane dialdehydes 6 in the presence of an acid catalyst
to give, following the addition of zinc acetate and air oxida-
tion, the corresponding unnatural type II porphyrins 7.9–12
These porphyrins have proven to be useful model com-
pounds in their own right,13,14 but more stepwise routes
have been developed for the synthesis of the less symmetri-
cal naturally occurring petroporphyrins.15 However, Mac-
Donald-type ‘2+2’ route to CAPs is very versatile and has
been applied to the synthesis of porphyrins with gem-dime-
thylpropano subunits16 and porphyrins with five-membered
exocyclic rings.11,12 As these straightforward procedures al-
low access to diverse CAP structures, the synthesis of more
complex systems using the same type of methodology was
considered a worthwhile goal. Given the many applications
for porphyrin based materials, ranging from catalysis17 to
supramolecular assemblies,18 molecular electronics,19 and
molecular scale data storage,20 the formation of more com-
plex CAP systems offers the potential to generate new types
Naturally Occurring Cycloalkanoporphyrins:
Me
R
Me
R
Me
R
Et
Et
Et
Me
Me
Me
Me
Me
Me
N
N
N
N
N
N
N
N
N
N
N
N
M
M
M
Me
Me
Me
R1
H
H
R2
R1
R3
3
2
1
M = Ni or VO
M = Ni or VO
R = H, Me or Et
M = Ni or VO
R = H, Me or Et
R = H, Me or Et
R1 = Me or CH2OH
R1 = H, Me, Et or Pr
R2,R3 = H or Me
Cycloalkanoporphyrins (CAPs; e.g., 1–3) are commonly
found in metalated form in organic-rich sediments such as
oil shales and petroleum.1,2 These geoporphyrins are primar-
ily derived from the photosynthetic pigments of algae and
bacteria, and can provide insights into the geological origins
of sedimentary materials.3 In addition, petroporphyrin
*
For Part 22 of this series, see: Lash, T. D.; Li, W.; Quizon-Colquitt, D. M.
Tetrahedron 2007, 63, 12324–12342.
Keywords: Porphyrin synthesis; Cycloalkenopyrroles; Pyrrole chemistry;
MacDonald reaction; Knorr condensation.
* Corresponding author. Tel.: +1 309 438 8554; fax: +1 309 438 5538;
e-mail: tdlash@ilstu.edu
0040–4020/$ - see front matter Ó 2007 Elsevier Ltd. All rights reserved.
doi:10.1016/j.tet.2007.09.060

12344
T. D. Lash et al. / Tetrahedron 63 (2007) 12343–12351
of porphyrin building blocks. For instance, porphyrins
linked via this type of carbocyclic unit could act as linkers
that enforce specific angle and distance connectivities be-
tween porphyrin within a larger assembly. In order to explore
the potential of this methodology, porphyrins with large
exocyclic rings were targeted for synthesis. The ability to
form CAPs of this type would demonstrate that far more
complex linkages can be introduced starting from simple
ketone precursors.
following precipitation in ice/water and recrystallization
from ethanol, pure cyclododeca[b]pyrrole 9a was obtained
in 33–37% yield.
Me
O
(CH2)n
Zn
AcOH
CH2
(CH2)n
CH2
O
O
Me
N
NH
O
CO2R
CH2
CH2
H2N
CO2R
Ph
a. n = 9
b. n = 12
c. n = 13
8
a. R = Et
b. R = Me
c. R = Bn
(CH2)n
Me
CO2R
R1
(CH2)n
Me
CO2R
Me
Me
O
33-62%
N
H
(CH2)n
Me
CO2R
CH2
(CH2)n
CH2
NH HN
RO2C
CO2R
4
n = 2-5
CH2
N
H
5
N
H
9
(CH2)n
1. p-TSA
2. [O]
a. n = 9; R = Et; b. n = 13; R = Et;
c. n = 13; R = Me; d. n = 13; R = Bn;
e. n = 12; R = Et; f. n = 12; R = Me ; g. n = 12; R = Bn
R1
Me
Me
CHO
Me
R2
Me
OHC
NH HN
NH
N
N
Scheme 2.
Me
R2
HN
The success of this pilot study encouraged us to investigate
the use of even large rings. Cyclopentadecanone is readily
available, and 8-cyclohexadecenone is also reasonably inex-
pensive and accessible. The latter compound is easily hydro-
genated over 10% Pd/C to give cyclohexadecanone in
quantitative yields. The 16- and 15-membered ring ketones
were reacted with phenylhydrazones 8a–c under the condi-
tions developed for cyclododecanone (Scheme 2), and the
related cycloalka[b]pyrroles 9b–g were isolated in excellent
yields (40–68%). All six of these pyrroles were fully charac-
terized and were obtained as white crystals or powders.25
6
Me
R2
R2
7
Scheme 1.
2. Results and discussion
In our previous studies, we prepared cycloalka[b]pyrroles
using a variant on Knorr pyrrole condensation.6,21 In this
chemistry, an aminoketone is generated in situ by reducing
an oxime or phenylhydrazone with zinc dust in acetic acid
and this condenses with the cyclic ketone to give the required
porphyrin. Although oximes are more commonly used in
Knorr syntheses,21 phenylhydrazones give superior yields
in some cases.8–10,22 Phenylhydrazones 8 are easily prepared
by reacting benzenediazonium chloride with esters of aceto-
acetic acid,8,23 while oximes can be generated by nitrosation
of the same starting materials.6 In most Knorr-type reac-
tions, the chemistry is initiated at ca. 70–80 ꢀC, and the
zinc metal reductant and aminoketone precursor are added
simultaneously to the ketone in acetic acid while maintain-
ing the temperature at 80–100 ꢀC.24 For cyclic ketones
with six- to eight-membered rings, slightly higher tempera-
tures were employed but yields plummeted if the reaction
temperature was allowed to get too high.8–10 With these con-
cerns in mind, the same chemistry was attempted using inex-
pensive cyclododecanone and phenylhydrazone 8a derived
from ethyl acetoacetate (Scheme 2). Under conventional
conditions, no pyrrolic products could be detected and
most of the cyclic ketones could be recovered. However, if
the reaction was conducted at the boiling point of acetic
acid, trace amounts of the desired pyrrole product could be
detected by NMR spectroscopy. Although the initial results
were unexpected, they nonetheless suggested that still higher
temperatures might facilitate pyrrole formation. Propionic
acid was selected as the solvent due to its higher boiling
point. Following further investigations, the best results
were obtained using relatively dilute conditions with 3.0 g
of sodium acetate for every 10 mL of propionic acid. Tem-
peratures were maintained as high as possible during the
initial phases of the chemistry (typically 145–150 ꢀC), and
In order to access the viability of synthesizing porphyrins
with large exocyclic rings, cyclohexadeca[b]pyrrole 9d was
reacted with lead tetraacetate in 1:1 v/v acetic acid/dichloro-
methane to give the 17-acetoxy derivative 10 (Scheme 3).
