Synthesis of 14 h-naphtho[1′,2′:5,6][1,3]oxazino-[3,2-a] benzimidazole, a new heterocyclic system

Article abstract of DOI:10.1007/s10593-011-0727-y

The previously unreported 14 H-naphtho[1′,2′:5,6][1,3] oxazino[3,2-a]benzimidazole heterocyclic system was synthesized by the condensation of 1-dimethylaminomethyl-2-naphthols and 2-methyl- sulfanylbenzimidazole. A highly reactive o-methylenequinone deriv

Full text of DOI:10.1007/s10593-011-0727-y

Chemistry of Heterocyclic Compounds, Vol. 47, No. 1, April, 2011 (Russian Original Vol. 47, No. 1, January, 2011)
SYNTHESIS OF 14H-NAPHTHO[1',2':5,6][1,3]OXAZINO-
[3,2-a]BENZIMIDAZOLE, A NEW HETEROCYCLIC SYSTEM
V. A. Osyanin1*, D. V. Osipov1, and Yu. N. Klimochkin1
The previously unreported 14H-naphtho[1',2':5,6][1,3]oxazino[3,2-a]benzimidazole heterocyclic
system was synthesized by the condensation of 1-dimethylaminomethyl-2-naphthols and 2-methyl-
sulfanylbenzimidazole. A highly reactive o-methylenequinone derivative of naphthalene is proposed as
an intermediate in this reaction.
Keywords: 2-methylsulfanylbenzimidazole, o-methylenequinones, 14H-naphtho[1',2':5,6][1,3]oxazino-
[3,2-a]benzimidazoles, Mannich bases, cascade reactions.
-Methylenequinones, which contain both electrophilic and nucleophilic sites, are valuable starting
reagents in heterocyclization reactions [1]. The driving force in these reactions is aromatic stabilization
following 1,4-addition of nucleophilic agents under Michael reaction conditions. In the case of good leaving
groups, the initially formed adducts undergo subsequent cyclization to give benzocondensed heterocyclic
systems [2, 3].
R1
R1
NMe2
OH
N
SMe
N
H
DMF
O
– NHMe2
R
R
1a–d
H
N
N
N
SMe
Me
S
N
O
O
N
N
OH
R1
R1
R1
– MeSH
2a–d
R
R
R
1, 2 a–c R = H, a R1 = H, b R1 = Ph, c R1 = 4-МеOC6H4; d R = 1-adamantyl, R1 = H
_______
* To whom correspondence should be addressed, e-mail: vosyanin@mail.ru.
1Samara State Technical University, 244 Molodogvardeiskaya Str., Samara 443100, Russia.
__________________________________________________________________________________________
Translated from Khimiya Geterotsiklicheskikh Soedinenii, No. 1, pp. 136-139, January, 2011. Original
article submitted September 26, 2010.
108
0009-3122/11/4701-0108©2011 Springer Science+Business Media, Inc.

We have shown that 14H-naphtho[1',2':5,6][1,3]oxazino[3,2-a]benzimidazoles 2a-d, which are
representatives of a new heterocyclic system, can be obtained by heating naphthalene Mannich bases 1a-d with
2-methylsulfanylbenzimidazole in DMF at reflux in the presence of potassium carbonate. This is a cascade
reaction, proceeding in several steps: 1) a retro-Michael reaction with formation of the corresponding
o-methylenequinone from the Mannich base; 2) 1,4-addition of 2-methylsulfanylbenzimidazole to o-methyl-
enequinone, and 3) intramolecular nucleophilic replacement of the methylsulfanyl group.
The IR spectrum of products 2a-d lack the OH group stretching band, which indicates a cyclic structure
1
for these compounds. The H NMR spectra of 2a,d show methylene protons at 5.13-5.17 ppm. The signals for
the aliphatic methine protons in 2b,c are shifted strongly downfield and appear at 6.79-6.88 ppm.
EXPERIMENTAL
1
The IR spectra were taken on a Shimadzu FTIR-8400S spectrometer in KBr pellets. The H and 13C
NMR spectra were taken on a JEOL JNM-ECX400 spectrometer at 400 and 100 MHz, respectively, in CDCl3
with TMS as the internal standard. The mass spectra were obtained on a Finnigan Trace DSQ mass
spectrometer. The ionizing electron energy was 70 eV. The elemental analysis was carried out on a EuroVector
EA-3000 automatic CHNS analyzer.
Starting Mannich bases 1a-c were obtained from 2-naphthol according to reported procedures [4-6].
6-(1-Adamantyl)-1-dimethylaminomethyl-2-naphthol (1d). 33% Aqueous dimethylamine (3 ml,
20 mmol) and 37% aqueous formaldehyde (1.5 ml, 20 mmol) were added to a solution of 6-(1-adamantyl)-
2-naphthol [7] (5 g, 18 mmol) in ethanol (50 ml). The mixture was heated to reflux, cooled, and maintained for
20 h at 25°C and 48 h at -15°C. The precipitate formed was filtered off, washed with cold methanol, and
recrystallized from ethanol-DMF to give 6.1 g (83%) 1d as colorless crystals, mp 177-179°C (dec.). IR
spectrum, , cm-1: 3051 (OH), 2908, 2885, 2850 (CH Ad), 1604 (C=C), 1512, 1423, 1338, 1276, 1149, 844 (CH
arom). 1H NMR spectrum, , ppm (J, Hz): 1.77-1.85 (6H, m, 3CH2 Ad); 1.96-2.04 (6H, m, 3CH2 Ad); 2.14 (3H,
br. s, 3CH Ad); 2.41 (6H, s, 2CH3); 4.09 (2H, s, CH2); 7.08 (1H, d, J = 8.70, H arom); 7.53 (1H, dd, J = 8.70,
J = 1.83, H-7 arom); 7.65 (1H, d, J = 1.83, H-5 arom); 7.67 (1H, d, J = 8.70, H arom); 7.78 (1H, d, J = 8.70, H
arom); 9.91 (1H, br. s, OH). 13C NMR spectrum, , ppm: 29.07 (3CH Ad); 36.01 (C Ad); 36.97 (3CH2 Ad);
43.24 (3CH2 Ad); 44.79 (2CH3); 57.95 (CH2); 111.30 (C); 119.13 (CH); 120.87 (CH); 123.98 (CH); 124.48
(CH); 128.55 (C); 129.30 (CH); 130.81 (C); 145.29 (C); 156.34 (C). Mass spectrum, m/z (Irel, %): 335 [M]+ (2),
290 [M-NH(CH3)2] (30), 214 (66), 202 (32), 165 (30), 152 (32), 135 [Ad]+ (34), 44 (100). Found, %: C 82.39;
H 8.67; N 4.21. C23H29NO. Calculated, %: C 82.34; H 8.71; N 4.18.
14H-Naphtho[1',2':5,6][1,3]oxazino[3,2-a]benzimidazole (2a). A mixture of 2-methylsulfanylbenz-
imidazole (1 g, 6.1 mmol), Mannich base 1a (1.22 g, 6.1 mmol), and potassium carbonate (2.5 g, 18 mmol) in
DMF (15 ml) was heated at reflux with stirring for 4 h, cooled, and poured into cold water (50 ml). The
precipitate formed was filtered off, washed with water, dried, and recrystallized from DMF to give 1.11 g (67%)
benzimidazole 2a as colorless crystals, mp 216-218°C. IR spectrum, , cm-1: 3055 (CH arom), 2912, 1628
1
(C=N), 1539, 1516, 1454, 1304, 1288, 1254, 1219, 1072, 980, 814, 741. H NMR spectrum, , ppm (J, Hz):
5.13 (2H, s, CH2); 7.19-7.30 (4H, m, H arom); 7.39 (1H, ddd, J = 8.24, J = 6.41, J = 1.37, H arom); 7.53-7.63
(3H, m, H arom); 7.72-7.74 (2H, m, H arom). 13C NMR, , ppm: 40.44 (CH2); 106.58 (C); 108.55 (CH); 117.55
(CH); 118.62 (CH); 121.41 (CH); 121.70 (CH); 123.04 (CH); 125.59 (CH); 127.08 (CH); 128.81 (CH); 129.69
(C); 130.13 (CH); 130.43 (C); 132.12 (C); 139.77 (C); 146.01 (C); 150.24 (C). Mass spectrum, m/z (Irel, %): 272
[M]+ (74), 271 [M-H]+ (100), 243 (30), 127 (23), 44 (57). Found, %: C 79.45; H 4.39; N 10.34. C18H12N2O.
Calculated, %: C 79.39; H 4.44; N 10.29.
109

14-Phenyl-14H-naphtho[1',2':5,6][1,3]oxazino[3,2-a]benzimidazole (2b) was obtained in 75% yield
analogously to 2a (1.59 g) from 2-methylsulfanylbenzimidazole (1 g, 6.1 mmol), Mannich base 1b (1.69 g,
6.1 mmol), and potassium carbonate (2.5 g, 18 mmol) in DMF (15 ml) as colorless crystals, mp 218-220°C
(benzene). IR spectrum, , cm-1: 3055 (CH arom), 2924, 1624 (C=N), 1543, 1516, 1474, 1450, 1285, 1258,
1219, 829, 733, 702. 1H NMR spectrum, , ppm (J, Hz): 6.88 (1H, s, CH); 7.14-7.26 (5H, m, H arom); 7.39-7.53
(6H, m, H arom); 7.64 (1H, d, J = 7.79, H arom); 7.81 (1H, d, J = 7.79, H arom); 7.87 (1H, d, J = 8.70, H arom);
7.89 (1H, d, J = 8.70, H arom). 13C NMR spectrum, , ppm: 56.48 (CH); 109.91 (CH); 112.44 (C); 117.62 (CH);
118.76 (CH); 121.67 (CH); 122.66 (CH); 122.96 (CH); 125.48 (CH); 127.76 (CH); 127.91 (CH); 128.92 (CH);
129.05 (CH); 129.22 (CH); 129.57 (C); 131.04 (CH); 131.17 (C); 131.26 (C); 139.10 (C); 140.04 (C); 146.41
(C); 150.54 (C). Mass spectrum, m/z (Irel, %): 348 [M]+ (55), 271 [M-Ph]+ (100), 242 [M-Ph-CHO]+ (12), 227
(5), 213 (11). Found, %: C 82.67; H 4.58; N 8.09. for C24H16N2O. Calculated, %: C 82.74; H, 4.63; N 8.04.
14-(4-Methoxyphenyl)-14H-naphtho[1',2':5,6][1,3]oxazino[3,2-a]benzimidazole (2c) was obtained
in 60% yield (1.38 g) analogously to 2a from 2-methylsulfanylbenzimidazole (1 g, 6.1 mmol), Mannich base 1c
(1.87 g, 6.1 mmol), and potassium carbonate (2.5 g, 18 mmol) in DMF (15 ml) as colorless crystals, mp
136-138°C (ethanol). IR spectrum, , cm-1: 3055 (CH arom), 2932, 2835, 1624 (C=N), 1609, 1539, 1512, 1447,
1285, 1254, 1219, 1177, 1030, 814, 741. 1H NMR spectrum, , ppm (J, Hz): 3.63 (3H, s, CH3); 6.73 (2H, d, J =
8.70, H arom); 6.79 (1H, s, CH); 7.15 (1H, td, J = 7.33, J = 1.37, H arom); 7.20 (1H, td, J = 7.79, J = 1.37, H
arom); 7.33-7.41 (4H, m, H arom); 7.45-7.50 (2H, m, H arom); 7.63 (1H, d, J = 7.79); 7.78 (1H, d, J = 7.79, H
arom); 7.84 (2H, d, J = 8.70, H arom). 13C NMR spectrum, , ppm: 55.26 (CH3); 55.87 (CH); 109.95 (CH);
112.63 (C); 114.49 (CH); 117.59 (CH); 118.75 (CH); 121.55 (CH); 122.73 (CH); 122.85 (CH); 125.40 (CH);
127.67 (CH); 129.01 (CH); 129.13 (CH); 129.57 (C); 130.87 (CH); 131.24 (C); 131.33 (C); 140.23 (C); 146.31
(C); 150.64 (C); 159.67 (C). Mass spectrum, m/z (Irel, %): 378 [M]+ (12), 377 [M-H]+ (11), 271 [M-C6H4OCH3]+
(86), 270 [M-C6H4OCH3]+ (100), 189 (14), 44 (99). Found, %: C 79.30; H 4.83; N 8.14. C25H18N2O2. Calculated, %:
C 79.35; H 4.79; N 7.40.
3-(1-Adamantyl)-14H-naphtho[1',2':5,6][1,3]oxazino[3,2-a]benzimidazole (2d) was obtained
analogously to 2a in 88% yield (2.16 g) from 2-methylsulfanylbenzimidazole (1 g, 6.1 mmol), Mannich base 1d
(2.04 g, 6.1 mmol), and potassium carbonate (2.5 g, 18 mmol) in DMF (15 ml) as yellow crystals, mp 259-
261°C (DMF). IR spectrum, , cm-1: 3066 (CH arom), 2905, 2847 (CH Ad), 1624 (C=N), 1612, 1585, 1535,
1516, 1470, 1285, 1211, 1072, 980, 806, 741. 1H NMR spectrum, , ppm (J, Hz): 1.76-1.84 (6H, m, 3CH2 Ad);
1.92-2.00 (6H, m, 3CH2 Ad); 2.13 (3H, br. s, 3CH Ad); 5.17 (2H, s, CH2); 7.19-7.23 (2H, m, H arom); 7.25-7.31
(2H, m, H arom); 7.57-7.62 (2H, m, H arom); 7.67-7.72 (3H, m, H arom). 13C NMR spectrum, , ppm: 28.96
(3CH Ad); 36.36 (C Ad); 36.82 (3CH2 Ad); 40.48 (CH2); 43.09 (3CH2 Ad); 106.31 (C); 108.59 (CH); 117.32
(CH); 118.57 (CH); 121.28 (CH); 121.61 (CH); 122.98 (CH); 124.03 (CH); 126.03 (CH); 127.90 (C); 130.15
(CH); 130.64 (C); 132.18 (C); 139.84 (C); 145.62 (C); 148.77 (C); 150.47 (C). Mass spectrum, m/z (Irel, %): 406
[M]+ (90), 405 [M-H]+ (100), 349 (24), 311 (30), 271 [M-Ad]+ (62), 216 (54), 202 (52), 44 (92). Found, %:
C 82.77; H 6.40; N 6.93. C28H26N2O. Calculated, %: C 82.73; H 6.45; N 6.89.
This work was carried out in the framework of the Federal Program Priorities for Science and Science
Teaching Personnel for Innovation in Russia 2009-2013 (State Contract P1104, August 26, 2009).
REFERENCES
1. R. W. Van der Water and T. R. R. Pettus, Tetrahedron, 58, 5367 (2002).
2. V. A. Osyanin, D. V. Osipov, and Yu. N. Klimochkin, Khim. Geterotsikl. Soedin., 469 (2010). [Chem.
Heterocycl. Comp., 46, 377 (2010)].
110

3.
V. A. Osyanin and N. E. Sidorina, Khim. Geterotsikl. Soedin., 1741 (2006). [Chem. Heterocycl. Comp.,
42, 1499 (2006)].
4.
5.
6.
7.
L. M. Tolbert and S. M. Nesselroth, J. Phys. Chem., 95, 10331 (1991).
J. B. Littman and W. R. Brode, J. Am. Chem. Soc., 52, 1655 (1930).
W. R. Brode and J. B. Littman, J. Am. Chem. Soc., 53, 1531 (1931).
V. A. Sokolenko, N. M. Svirskaya, and N. I. Pavlenko, Zh. Org. Khim., 43, 783 (2007).
