One step synthesis of azo compounds from nitroaromatics and anilines
Rui Zhao a,c, Chunyan Tan c, Yonghua Xie a,c, Chunmei Gao c, Hongxia Liu c, Yuyang Jiang b,c,
⇑
a Department of Chemistry, Tsinghua University, Beijing 100084, PR China
b School of Medicine, Tsinghua University, Beijing 100084, PR China
c Guangdong Provincial Key Laboratory of Chemical Biology, Graduate School of Shenzhen, Tsinghua University, Shenzhen 518055, PR China
a r t i c l e i n f o
a b s t r a c t
Article history:
A general and efficient method for synthesis of both symmetric and asymmetric aromatic azo compounds
in one single step has been developed. The nitro compounds were reduced and the substituted anilines
were oxidized by each other without any metal in the base condition. Various azo compounds with hal-
ogen, methyl and methoxy functional group were obtained by using available, cheap nitro compounds
and substituted anilines. In addition, the electronic effect and substituent effect of the compounds have
been discussed.
Received 5 March 2011
Revised 6 May 2011
Accepted 13 May 2011
Available online 19 May 2011
Keywords:
Nitro compounds
Aniline
Ó 2011 Elsevier Ltd. All rights reserved.
Aromatic azo compound
Asymmetric
Redox reaction
Aromatic azo compounds are widely used in various fields. For
example, the azo compounds are used as organic dyes,1 indicators,2
radical reaction initiators,3 and therapeutic4 and drug delivery
agents.5 They are also important units in the area of nonlinear
optics,6 optical storage media,7 chemo sensors,8 photochemical
switches9 and electronic devices.10 Therefore, synthesis of aromatic
azo compounds has attracted great attention. Preparation of
symmetric aromatic azo compounds are often performed by the
oxidation of aromatic amines using stoichiometric amounts of
oxidants including transition metals11 (permanganate, lead tetra-
acetate or other metal-containing compounds) and halo oxo acids12
(Eq. 1 in Fig. 1), or by the reduction of nitro aromatics using equiv-
alent amounts of metals (Eq. 2 in Fig. 1).13 Recently, several oxida-
tion and reduction methods using novel metal catalysts have been
nitrous acid. Herein, we report a transition metal-free mediated
approach to aromatic azo compounds via direct couplings of readily
available nitroaromatics and substituted anilines (Eq. 3 in Fig. 1).
In order to optimize reaction conditions, 1-chloro-2-nitroben-
zene (1c) and 2-methoxybenzenamine (2h) were chosen as the
model substrates, and the effects of bases, solvents and tempera-
tures were investigated under nitrogen atmosphere. As shown in
Table 1, five bases (10 equiv) (relative to the amount of 1-chloro-
2-nitrobenzene) were tested in toluene at 110 °C (entries 1–5),
KOH and NaOH provided (E)-1-(2-chlorophenyl)-2-(2-methoxy-
phenyl) diazene (3l) in 45% and 25% yields, respectively (entries
1 and 2), whereas only trace amount of target product was afforded
for other bases, K2CO3, Cs2CO3 and Et3N (entries 3–5). We also
screened different solvents in the presence of KOH (entries 6–
10), and DMF gave better yield (44%) (entry 6). Interestingly, the
yield was greatly improved to 85% when reaction temperature
was raised to 150 °C (entry 11), which implied that high tempera-
ture could promote the formation of the aromatic azo product.
Trace amount of target product was observed in the absence of
base (entry 12), which means strong base is important. Therefore,
the optimal reaction condition for synthesis of aromatic azo com-
pounds is as follows: couplings of nitro aromatics and substituted
anilines were carried out at 150 °C under nitrogen atmosphere
with 10 equiv of KOH as the base and DMF as the solvent.
developed.14 Examples include
a gold-catalyzed oxidation of
anilines and reduction of nitroaromatics,14c,14d reduction of nitro-
aromatics by nano-sized iron,14b and Cu-catalyzed oxidation of ani-
lines. For synthesis of asymmetric aromatic azo compounds, the
coupling of aryl diazonium salts with electron-rich aromatics is a
common strategy.15 This coupling requires the in situ preparation
of a diazonium salt from the oxidation of corresponding aromatic
amine with nitrous acid.16 Although these methods above are effec-
tive for synthesis of aromatic azo compounds, they do not meet the
sustainable and environmentally benign conditions because of use
of environmentally unfriendly transition metals or hazardous
We investigated the scope of couplings of nitro aromatics and
substituted anilines under the optimized condition above. As
shown in Table 2, most of the examined substrates provided good
to excellent yields. The nitroaromatics containing electron-
deficient groups showed higher reactivity than those containing
⇑
Corresponding author. Tel.: +7 552 603 6017; fax: +7 552 603 6018.
E-mail address: jiangyy@sz.tsinghua.edu.cn (Y. Jiang).
0040-4039/$ - see front matter Ó 2011 Elsevier Ltd. All rights reserved.
doi:10.1016/j.tetlet.2011.05.054

3806
R. Zhao et al. / Tetrahedron Letters 52 (2011) 3805–3809
N
N
N
oxidation
H2N
+
+
+
NH2
NO2
NO2
(1)
(2)
N
symmetric
R1
R1
R2
the previous method
R1
R1
R1
R1
R1
R2
R1
R1
R1
reduction
O2N
H2N
N
symmetric
the previous method
one step
(3)
N
symmetric and asymmetric
our method
Figure 1. The previous methods (Eq. 1 and 2) and our method (Eq. 3) for synthesis of aromatic azo compounds.
